Miele INDUCTION WOK CS 1223 User manual

Operating and Installation
Instructions
Induction Wok
CS 1223
To prevent accidents and
machine damage,
read the Operating Manual
before
installation or use. M.-Nr. 07 353 930
en-CA

IMPORTANT SAFETY INSTRUCTIONS.................................3
Description of the unit..............................................8
Before using for the first time........................................9
Induction........................................................10
How it works......................................................10
Noises ..........................................................11
Cookware........................................................11
Use ............................................................12
Turning the combiset On/Off .........................................12
Residual heat indicator .............................................12
Settings .........................................................13
Auto-heat ........................................................13
Booster function...................................................14
Safety features ...................................................15
Child Safety Lock..................................................15
Safety cut-out.....................................................15
Overheating protection .............................................16
Cleaning and care ................................................17
Frequently asked questions .......................................19
Technical Service.................................................21
SAFETY INSTRUCTIONS FOR INSTALLATION.........................24
Installation ......................................................27
Installation dimensions .............................................28
Cutout..........................................................29
Installation of multiple appliances .....................................30
Attach the spring clips and support bars ...............................33
Installing the appliance .............................................35
Sealing ..........................................................36
Tiled surfaces ....................................................36
Electrical connection..............................................37
Help protect our environment.......................................38
Contents
2

WARNING- When using your
appliance follow basic
precautions, including the
following:
Read all instructions before
installation or use to prevent
injury and appliance damage.
This appliance conforms to all
uniform safety codes and
regulations. The manufacturer
cannot be held responsible for
damage or injury caused by
improper use of this appliance.
Keep these operating instructions
in a safe place and pass them on
to any future user.
SAVE THESE INSTRUCTIONS
Correct usage
~Only use the combiset for residential
cooking, and for the purposes
described in this manual.
Other uses are not permitted and can
be dangerous. The manufacturer will
not be held liable for damage caused
by unauthorized use or improper
operation of any kind.
~Persons who lack physical, sensory
or mental abilities, or experience with
the appliance should not use it without
supervision or instruction by a
responsible person.
IMPORTANT SAFETY INSTRUCTIONS
3

Children
~Activate the Child Safety Lock so
that the combiset cannot be turned on
inadvertently.
~Children should not be left
unattended in an area where the
appliance is in use. Never allow
children to sit or stand on any part of
the appliance.
Caution: Do not store items of interest
to children in cabinets above the
appliance. Children climbing on the
appliance to reach these items could
be injured.
~The appliance is hot during use and
remains so for some time after being
switched off. Keep children away from
the appliance.
~Ensure that any packing material, is
disposed of safely and kept out of the
reach of children. Danger of
suffocation!
~Keep all pots and pans out of the
reach of children. Danger of burning or
scalding.
Technical Safety
~Installation, repair and maintenance
work should be performed by a Miele
authorized service technician. Work by
unqualified persons could be
dangerous and may void the warranty.
~Before installing the combiset,
check for externally visible damage.
Do not operate a damaged appliance.
~To guarantee the electrical safety of
this appliance, continuity must exist
between the appliance and an effective
grounding system. It is imperative that
this basic safety requirement be met. If
there is any doubt, have the electrical
system of the house checked by a
qualified electrician. The manufacturer
will not be held responsible for
damages caused by the lack, or
inadequacy, of an effective grounding
system.
~Before installation, make sure that
the voltage and frequency listed on the
data plate correspond with the
household electrical supply. This data
must correspond to prevent injury and
appliance damage. Consult a qualified
electrician if in doubt.
~Do not use an extension cord to
connect this appliance to electricity.
Extension cords do not guarantee the
required safety of the appliance.
~Do not use the appliance until it has
been properly installed in the
countertop.
IMPORTANT SAFETY INSTRUCTIONS
4

~Install the appliance so that the
power cord does not come into contact
with any portion of the cooktop which
may become hot during use.
~Before servicing, disconnect the
appliance from the main power supply.
~Do not operate any appliance with a
damaged cord or plug, or if the
appliance has been damaged in any
manner. Contact Miele’s Technical Ser-
vice Department.
~Under no circumstances open the
outer casing of the appliance.
~The combiset must not be installed
outdoors.
~While the appliance is under
warranty repairs should only be
performed by an authorized service
technician. Otherwise the warranty is
void.
~In the event of any damage to the
appliance, it must be turned off immedi-
ately and disconnected from the main
power supply. Contact Miele’s
Technical Service Department.
Do not use the appliance until it has
been repaired. Ensure power is not
supplied to the appliance until repair
work is completed.
~Defective components should be
replaced by Miele original spare parts
only. Only with these parts can the
manufacturer guarantee the safety of
the appliance.
~Do not cook on a broken combiset.
Any breakages or cracks in the ceramic
surface of the appliance are defects
and must be treated as such. If the
combiset should break, cleaning
solutions and spills may penetrate the
broken combiset and create a risk of
electric shock. Do not use the
appliance until it has been repaired.
IMPORTANT SAFETY INSTRUCTIONS
5

Safety
~Individuals with a pacemaker or
similar medical device:
Please note that an electromagnetic
field develops when the combiset is
turned on. It is not likely that this will
affect the pacemaker or similar device.
If in doubt contact the manufacturer of
the device or your doctor.
~Keep magnetized items, e.g. credit
cards, disks, etc. away from the
combiset while in operation. Damage
may result.
~Do not touch the combiset or the
surrounding areas during or immediate-
ly after use. The combiset may be hot
even though it is dark in color. Wait until
the residual heat indicators go out.
~Protect your hands with oven mitts
or potholders when using the
appliance. Use only dry, heat resistant
potholders. Moist or damp potholders
used on hot surfaces can result in
steam burns. Do not let the potholder
touch the hot heating elements. Do not
use towels or other bulky items near the
appliance.
~Do not heat unopened containers.
Built-up pressure may cause the
container to burst and result in injury.
~Do not flambé under an exhaust
hood. Flames could be drawn up into
the hood by the suction and the grease
filters may ignite.
~Only use the wok supplied with the
appliance. See "Use - Cookware".
Risk of fire.
~Do not store items on the appliance
when not in use. Items could melt or
catch fire from residual heat or if the
appliance is turned on inadvertently.
Always switch the cooking zone(s) off
after use.
~Flammable materials should not be
stored on or near the appliance.
~If there is a drawer directly
underneath the appliance, ensure that
there is sufficient space between the
drawer, its contents and the underside
of the appliance to ensure sufficient
ventilation.
~Metallic items kept in a drawer
under the combiset can become hot
when the appliance is used for a longer
period of time. Use caution.
~Never cover the appliance with a
cloth. A fire may result.
~Be aware of loose fitting or hanging
garments when operating the
appliance, they may present a fire
hazard.
~Never leave a combiset unattended
at high settings or when cooking with oil
or fat. Overheated oil could ignite.
Always heat oil slowly, monitoring it as it
heats.
~Never heat an empty pan unless the
pan manufacturer states that you can
do so.
~Do not use water on grease fires.
Smother or use a dry chemical or
foam-type extinguisher on any fire or
flame.
IMPORTANT SAFETY INSTRUCTIONS
6

~Make certain that the power cords of
small appliances do not come in
contact with the appliance. The
insulation of the cable could become
damaged. Danger of electric shock!
~Be careful not to drop anything on
the ceramic surface of the combiset.
Even lightweight objects may cause
damage.
~Pot and pan handles should be
turned inward and not extend over the
countertop to reduce the risk of burns,
ignition of flammable materials, and
spills.
~Do not use pots or pans with
pronounced edges or ridges on the
ceramic combiset. These could scratch
the combiset permanently. See
"Cookware" for more information. Grains
of salt and sand can cause scratches.
Make sure that the bases of any pots
and pans are clean, free of any fat or
oils, and are dry.
~To prevent burns and breathing
difficulty, allow the combiset to cool
before cleaning. Some cleaners may
produce toxic fumes if applied to a hot
surface.
~Keep the combiset clean. Salt,
sugar, and grit can cause scratches.
~When wiping spills on a hot
combiset with a wet sponge or cloth, be
careful to avoid steam burns.
~Do not let flammable materials,
i.e. cooking grease, accumulate on the
appliance.
~Do not use a steam cleaner to clean
this appliance. Steam could penetrate
electrical components and cause a
short circuit.
~Do not allow solid or liquid sugar,
pieces of plastic or foil to fall on the
burners when they are hot. If these
residues are allowed to cool on the
ceramic surface pitting or even
cracking may occur.
~Any spills should be removed as
quickly as possible to prevent them
from burning on and becoming difficult
to remove.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these
Important Safety instructions.
SAVE THESE INSTRUCTIONS
AND REVIEW THEM
PERIODICALLY
IMPORTANT SAFETY INSTRUCTIONS
7

aWok burner C11 3/4" (30 cm)
Rating in watts: 2400 W
with Booster: 3200 W
bWok pan (included)
cControl knob
dIndicators
Indicators
fOn/Off indicator
gBooster indicator
h"Residual Heat" indicator
eDisplay
ßNo wok on burner
AAuto-heat
FFault (see "Frequently
asked questions")
C/0Safety cut-out feature
(see "Safety features")
IBooster "On"
HOverheating protection
(see "Safety features")
LChild safety lock
(see "Safety features")
Description of the unit
8

Clean the combiset
^Before using for the first time, clean
the appliance with a damp cloth and
dry with a soft cloth.
Do not use liquid dish soap to clean
the combiset, this may cause
permanent blue discolorations.
Heat the appliance
When the combiset is first connected to
the power supply, and after a power
failure, all indicators in the display will
light up for approx. 1 second. The
combiset can be used as normal once
the indicators go out.
Metal components of the appliance
have a protective coating which may
give off a slight odor the first time
the appliance is heated.
The smell will dissipate after a short
time and does not indicate a faulty
connection or appliance defect.
Before using for the first time
9

How it works
An induction coil is located under the
burner. When the burner is switched
on, this coil creates a magnetic field
which impacts directly on the base of
the pan and heats it up. The burner
itself is heated indirectly by the heat
given off by the pan.
This appliance will only work properly
when the wok pan (supplied) is used
(see "Cookware").
The burner will not work:
–if it is switched on without the wok
pan in place.
– if the wok pan is taken off the burner
when it is switched on.
If this happens, ßwill flash in the
display.
If the wok pan is placed on the burner
within 3 minutes, the ßwill go out and
you can continue cooking as normal.
If the wok pan is not placed on the
burner, the burner and the combiset will
switch off automatically after 3 minutes.
0will flash alternately with Cin the
display.
To use the burner again as normal, first
turn the control knob to "0".
Be careful not to place cutlery or
other metal objects on the combiset.
When the appliance is switched on,
or when there is residual heat
present, there is the risk of metal
objects heating up quickly.
Beware of burns.
Depending on the material, other
objects left on the combiset could
also melt or catch fire.
Turn the burner off after use.
Induction
10

Noises
The following noises can occur when
the induction wok is in use.
–Higher power settings may cause a
buzz. This will decrease or cease
altogether when the power setting is
reduced.
–You may hear a clicking sound from
the electronic switches, especially on
lower settings.
The appliance has a cooling fan to help
extend the life of the electronics. When
the combiset is being used at high
levels for a long period of time, this will
come on and you will hear a whirring
sound. The fan may continue to run
after the appliance has been switched
off.
Cookware
Only the wok pan supplied should be
used with this appliance. The wok pan
is designed specifically for this
induction wok.
,There is a danger of fat or food
overheating and burning if other
woks are used.
Induction
11

Turning the combiset On/Off
,Do not leave the appliance
unattended while in use.
To turn the combiset on turn the control
knob clockwise ato the desired power
level.
To turn the combiset off turn the control
knob counterclockwise bto "0".
The knob must only be turned
clockwise to turn the burner on and
counterclockwise to turn the burner
off.
When the combiset is turned on the
On/Off indicator lights up. Once the
combiset has reached a factory set
temperature the residual heat indicator
will light.
When the combiset is turned off the
On/Off indicator will go out.
Residual heat indicator
The residual heat indicator will go out
once the combiset has cooled to a safe
temperature.
As long as the residual heat
indicator is lit do not touch or place
any heat sensitive items on the
burner. Danger of burns, and fire
hazard.
Use
12

Settings
Use for Power
level
Keeping food warm,
Melting chocolate, etc.
1-2
Warming food 3 - 6
Stir-frying 7- 9
Auto-heat
Continued
power level
Heat-up time
(approx.)
min : sec
1 0:15
2 0:15
3 0:25
4 0:50
5 2:00
6 5:50
7 2:50
8 2:50
9-
When Auto-heat has been activated,
the burner switches on automatically at
the highest setting and then switches to
the continued power level which was
selected. The "heat-up" time depends
on which continued power level has
been chosen (see table).
Taking the wok off the burner while
Auto-heat is in operation interrupts the
function. It will resume if the wok is
placed back on the burner within
3 minutes.
To activate Auto-heat
^Turn the control knob
counterclockwise as far as it will go
and hold until an Aappears.
^Turn the control knob clockwise to
the desired continued power level.
Once Auto-heat has been activated the
continued power level must be set
within 10 seconds. After this time the
level cannot be changed.
Changing the continued power level
after 10 seconds will deactivate the
Auto-heat function.
During the Auto-heat phase an Awill
show in the display.
Use
13

Booster function
The induction wok is equipped with a
booster function to temporarily increase
the power level. When the Booster is
activated the burner will operate at
power level 9with an extra boost of
power for 10 minutes.
Taking the wok pan off the burner while
the booster is in operation interrupts the
booster function. It will resume if the
pan is placed back on the burner within
3 minutes.
If the wok reaches the maximum
temperature before the 10 minutes
has elapsed, the booster function
will switch off and the appliance will
resume at power level 9.
This function only works with the
supplied wok, which ensures that
the appliance will switch off if it gets
too hot.
Activating the booster function
^Turn the control knob past power
level 9 to BI, then back to 9.
Iappears in the display and the B
indicator lights up.
After 10 minutes the burner will
automatically switch back to power
level 9, the Isymbol and the Bindicator
will go out.
Deactivating the booster function
The booster function can be turned off
early if desired.
^Turn the control knob past power
level 9 to BI; or simply reduce the
power level.
Use
14

Child Safety Lock
Keep children away from the
combiset for their own safety.
The combiset has a Child Safety Lock
to prevent children from turning on the
burners.
To activate the Child Safety Lock:
^Turn the control knob
counterclockwise as far as it will go,
and hold until Lappears in the
display.
If the control knob is touched after the
lock is activated an Lwill appear in the
display for 3 seconds.
To deactivate the Child Safety Lock:
^Turn the control knob
counterclockwise as far as it will go,
and hold until the Lgoes out and 0
appears briefly in the display.
Safety cut-out
The combiset has a safety cut-out
feature in case it is not turned off after
use.
If the burner is heated for an unusually
long period of time (see table), and the
power level settings are not adjusted,
the combiset will turn itself off
automatically and the residual heat
indicator will light.
Cand 0will flash alternately in the
burner display.
^To use the combiset again, first turn
the control knob to "0".
The On/Off indicator and the display
will go out.
Power level Maximum
operating hours
110
25
35
44
53
62
72
82
91
Safety features
15

Overheating protection
The induction coils are fitted with an
overheating protection feature. This
prevents the induction coils from
overheating by:
–If the booster function is being used,
it will be switched off.
–If the temperature continues to rise
after the booster function is switched
off, the power level will be reduced.
–If the temperature still continues to
rise after the power level has been
reduced, the appliance will switch off
and an Hwill appear in the display.
^Turn the control knob to "0".
Once the Hhas gone out the combiset
can be used again as normal.
If the control knob is not turned back to
"0", Cand 0will flash in the display once
the burner has cooled. To use the
combiset again, first turn the control
knob to "0".
Overheating can be caused by:
–using the appliance for too long at
the maximum power level.
–there being insufficient ventilation to
the appliance.
If a drawer is installed directly under
the combiset, sufficient space must be
kept between the drawer and its
contents and the underside of the
appliance in order to ensure sufficient
ventilation of the appliance.
If the overheating protection feature
triggers again, contact Miele Technical
Service.
Safety features
16

Do not use a steam cleaner to clean
this appliance. Steam could
penetrate electrical components and
cause a short circuit. Pressurized
steam could cause permanent
damage to the surface and to
components for which the
manufacturer cannot accept
responsibility.
Do not use any sharp pointed
objects which could damage the
seal between the ceramic surface,
the surrounding frame and the
countertop.
Never use abrasive cleaners,
caustic (oven) cleaners, dishwasher
detergent, scouring pads, steel wool
or hard brushes. They will damage
the surface.
The ceramic surface can be cleaned
using a cleaner for ceramic
surfaces. Follow the manufacturer’s
instructions.
Make sure that no cleaner residue
remains on the ceramic surface by
carefully wiping the combiset with a
damp cloth. They may damage the
combiset or produce toxic fumes
when heated.
Be sure that pot and pan bases are
clean and dry.
After cleaning dry the ceramic
surface with a soft cloth to prevent a
build up of limescale deposits.
Clean any spills immediately before
they become difficult to remove.
Clean the appliance regularly,
preferably after each use. Allow the
appliance to cool before cleaning.
Ceramic surfaces
^Wipe off any soiling using a damp
cloth. Stubborn soiling is best
removed with a shielded scraper
blade.
^Apply a ceramic cleaner (available
from Miele) using a soft cloth or
paper towel.
^To remove any limescale deposits or
metallic residue apply a ceramic
cleanser using a soft cloth or use a
shielded scraper blade if necessary.
^After cleaning wipe the ceramic
surface with a damp cloth and dry.
A cleaner with a special additive to
prevent water marks and smears on the
ceramic surface may be used.
Any melted solids like sugar, plastic or
aluminum foil should be removed as
soon as possible, while the burner is
still warm. If they are allowed to harden
the combiset may become pitted.
^Turn the burner off.
^Using a shielded scraper blade,
scrape the melted item immediately
off the burner while it is still hot.
Use caution: Danger of burns!
^Allow the combiset to cool and clean
as previously described.
Cleaning and care
17

Stainless steel
Clean stainless steel surfaces with
warm water and liquid dish soap
applied with a non-abrasive sponge
and then wipe dry with a soft cloth.
Soak baked or hardened spills first to
loosen them.
Stainless steel surfaces can be cleaned
using a non-abrasive stainless steel
cleaner (available from Miele).
To help prevent resoiling, a conditioner
for stainless steel can also be used.
Apply sparingly with even pressure.
Do not use stainless steel cleaner on
or around the printing, it may rub
off. Use only a soft sponge with
some dish liquid and warm water to
clean this area.
Cleaning and care
18

,Repairs should only be carried out by an authorized technician in
accordance with local and national safety regulations. Unauthorized repairs
could cause injury or appliance damage. The manufacturer cannot be held
responsible for unauthorized work.
What if the appliance does not heat up after it is turned on?
Possible fault Solution
The Child safety lock is activated. See "Child safety lock".
The Overheating protection feature has
activated.
See "Overheating protection".
The main fuse has blown. Check the main fuse.
Remove the fuse or "trip" the circuit
breaker.
If none of the above is the case, turn the control to "0", and disconnect the
appliance from the electrical supply for 1 minute.
Reconnect the power and turn the appliance on. If it still does not heat, contact
Miele Technical Service.
What if ßappears in the display?
Possible fault Solution
The burner is turned but the wok is not
placed on it.
Turn the burner off and place the wok
on the burner.
What if Fand 01 flash alternately in the display?
Possible fault Solution
The control knob is either damaged or
stuck.
If this is not the case contact Miele
Technical Service.
What if Fand a number flash alternately in the display?
Contact Miele Technical Service.
Frequently asked questions
19

What if the combiset turns itself off automatically?
Possible fault Solution
Either the "Safety cut-out" feature or the
"Overheating protection" feature has
been activated.
See "Overheating protection" or "Safety
cut-out".
What if one of the following errors occurs:
- The booster function turns off automatically ahead of time.
-Cand 0flash alternately in the display.
Possible fault Solution
The overheating protection feature has
been activated.
See "Overheating protection".
The food does not cook when using auto-heat.
Possible fault Solution
Large amounts of food are being
cooked.
Select a higher continued power level
or begin cooking at the highest level
and turn the power back by hand.
The cooling fan continues to run after the combiset was turned off.
Possible fault Solution
This is not a fault. The fan continues to run until the
appliance has cooled sufficiently. It will
turn off automatically.
Frequently asked questions
20
