Miele CS 1221 User manual

Operating and Installation
Instructions
Ceramic combiset with Induction
CS 1221
To prevent accidents and
appliance damage,
read these instructions
before
installation or use. M.-Nr. 07 346 540
en-US

2

IMPORTANT SAFETY INSTRUCTIONS.................................4
Guide to the combiset ..............................................9
Display ..........................................................10
Burner data ......................................................10
Before using for the first time.......................................11
Clean the combiset ................................................11
Induction........................................................12
How it works......................................................12
Noises ..........................................................13
Cookware........................................................14
Use ............................................................15
Turning the burner On/Off ...........................................15
Residual heat indicator .............................................15
Settings .........................................................16
Auto-heat ........................................................17
Booster function...................................................18
Keep warm.......................................................19
Tipps zum Energiesparen ..........................................20
Safety features ...................................................21
Child Safety Lock..................................................21
Safety cut-out.....................................................21
Overheating protection .............................................22
Cleaning and care ................................................23
Frequently asked questions .......................................25
Technical Service.................................................27
IMPORTANT INSTALLATION SAFETY INSTRUCTIONS ..................30
Installation ......................................................33
Installation dimensions .............................................34
Installation of multiple appliances .....................................36
Attach the spring clips and support bars ...............................39
Sealing ..........................................................42
Tiled surfaces ....................................................42
Electrical connection..............................................43
Help protect our environment.......................................44
Contents
3

WARNING- When using your gas
appliance follow basic
precautions, including the
following:
This gas combiset conforms to all
uniform safety codes and
regulations.
Read all instructions before
installation or use to prevent
injury and appliance damage.
These instructions contain
important information on
installation, safety, use and
maintenance of this appliance.
They will help you avoid injury
and damage to the appliance.
Keep these operating instructions
in a safe place and pass them on
to any future user.
SAVE THESE INSTRUCTIONS
Correct usage
~This appliance is not designed for
commercial use. It is intended for use in
domestic households and in similar
working and residential environments
such as:
–shops, offices and similar work
environments,
–by customers in hotels, motels, Bed
& Breakfasts or similar residential
environments.
~This appliance is not intended for
outdoor use.
~Only use the combiset for residential
cooking, and for the purposes
described in this manual.
Other uses are not permitted and can
be dangerous.
~Persons who lack physical, sensory
or mental abilities, or experience with
the appliance should not use it without
supervision or instruction by a
responsible person.
Children
~Activate the Child Safety Lock so
that the combiset cannot be turned on
inadvertently.
~Children should not be left
unattended in an area where the
appliance is in use. Never allow
children to sit or stand on any part of
the appliance.
Caution: Do not store items of interest
to children in cabinets above the
appliance. Children climbing on the
appliance to reach these items could
be injured.
~The appliance is hot during use and
remains so for some time after being
switched off. Keep children away from
the appliance.
~Ensure that any packing material, is
disposed of safely and kept out of the
reach of children. Danger of
suffocation!
~Keep all pots and pans out of the
reach of children. Danger of burning or
scalding.
IMPORTANT SAFETY INSTRUCTIONS
4

Technical Safety
~Installation, repair and maintenance
work should be performed by a Miele
authorized service technician. Work by
unqualified persons could be
dangerous and may void the warranty.
~Be sure your appliance is properly
installed and grounded by a qualified
technician.
~Before installing the combiset,
check for externally visible damage.
Do not operate a damaged appliance.
~To guarantee the electrical safety of
this appliance, continuity must exist
between the appliance and an effective
grounding system. It is imperative that
this basic safety requirement be met. If
there is any doubt, have the electrical
system of the house checked by a
qualified electrician.
~Before installation, make sure that
the voltage and frequency listed on the
data plate correspond with the
household electrical supply. This data
must correspond to prevent injury and
appliance damage. Consult a qualified
electrician if in doubt.
~The combiset is not designed for
use with an external timer or a remote
control system.
~Do not use an extension cord to
connect this appliance to electricity.
Extension cords do not guarantee the
required safety of the appliance.
~Before servicing, disconnect the
appliance from the main power supply.
~Do not operate any appliance with a
damaged cord or plug, or if the
appliance has been damaged in any
manner. Contact Miele’s Technical Ser-
vice Department.
~Under no circumstances open the
outer casing of the appliance.
~While the appliance is under
warranty repairs should only be
performed by an authorized service
technician. Otherwise the warranty is
void.
~In the event of any damage to the
appliance, it must be turned off immedi-
ately and disconnected from the main
power supply. Contact Miele’s
Technical Service Department.
Do not use the appliance until it has
been repaired. Ensure power is not
supplied to the appliance until repair
work is completed.
~Defective components should be
replaced by Miele original spare parts
only. Only with these parts can the
manufacturer guarantee the safety of
the appliance.
IMPORTANT SAFETY INSTRUCTIONS
5

~Do not cook on a broken combiset.
Any breakages or cracks in the ceramic
surface of the appliance are defects
and must be treated as such. If the
combiset should break, cleaning
solutions and spills may penetrate the
broken combiset and create a risk of
electric shock. Do not use the
appliance until it has been repaired.
~Do not use the appliance until it has
been properly installed in the
countertop.
~Be sure that the power cord does
not come in contact with any "hot spots"
after installation.
Safety
~Individuals with a pacemaker or
similar medical device:
Please note that an electromagnetic
field develops when the combiset is
turned on. It is not likely that this will
affect the pacemaker or similar device.
If in doubt contact the manufacturer of
the device or your doctor.
~Keep magnetized items, e.g. credit
cards, disks, etc. away from the
combiset while in operation. Damage
may result.
~Do not touch the combiset or the
surrounding areas during or immediate-
ly after use. The combiset may be hot
even though it is dark in color. Wait until
the residual heat indicators go out.
~Protect your hands with oven mitts
or potholders when using the
appliance. Use only dry, heat resistant
potholders. Moist or damp potholders
used on hot surfaces can result in
steam burns. Do not let the potholder
touch the hot heating elements. Do not
use towels or other bulky items near the
appliance.
~Do not heat unopened containers.
Built-up pressure may cause the
container to burst and result in injury.
~Do not flambé under an exhaust
hood. Flames could be drawn up into
the hood by the suction and the grease
filters may ignite.
~Do not use the appliance until it has
been properly installed in the
countertop.
~Do not store items on the appliance
when not in use. Items could melt or
catch fire from residual heat or if the
appliance is turned on inadvertently.
Always switch the burner(s) off after
use.
~Do not store aerosols, combustibles
or any other easily flammable materials
underneath or adjacent to the
appliance.
IMPORTANT SAFETY INSTRUCTIONS
6

~The combiset is fitted with a cooling
fan. Drawers under the combiset are
not recommended. If a drawer is fitted
directly underneath the combiset,
ensure that there is sufficient space
between the drawer, its contents and
the underside of the appliance in order
to ensure sufficient ventilation for the
combiset. Do not store small items or
paper in the drawer. They could get
sucked into the housing by the fan and
cause damage or impair cooling.
Ensure that no aerosols, combustible
liquids or other flammable materials are
kept in this drawer. If cutlery inserts are
to be placed in the drawer they must be
made of heat-resistant material.
~Metallic items kept in a drawer
under the combiset can become hot
when the appliance is used for a longer
period of time. Use caution.
~If the combiset is installed above a
pyrolytic oven it should not be used
during the pyrolytic process. The
overheating protection feature of the
combiset might be activated.
~Never cover the burner with a cloth
or protective oven foil. If inadvertently
turned on or if there is residual heat, a
fire could result.
~When more than one combiset is
installed next to each other, be sure not
to place hot pots or pans on the center
line. This could damage the seal.
~Be aware of loose fitting or hanging
garments when operating the
appliance, they may present a fire
hazard.
~Never leave a combiset unattended
at high settings or when cooking with oil
or fat. Overheated oil could ignite.
Always heat oil slowly, monitoring it as it
heats.
~Never heat an empty pan unless the
pan manufacturer states that you can
do so.
~Do not use water on grease fires.
Smother or use a dry chemical or
foam-type extinguisher on any fire or
flame.
~Make certain that the power cords of
small appliances do not come in
contact with the appliance. The
insulation of the cable could become
damaged. Danger of electric shock!
~Be careful not to drop anything on
the ceramic surface of the combiset.
Even lightweight objects may cause
damage.
~Pot and pan handles should be
turned inward and not extend over the
countertop to reduce the risk of burns,
ignition of flammable materials, and
spills.
~Be careful not to drop anything on
the ceramic surface of the combiset.
Even lightweight objects may cause
damage.
IMPORTANT SAFETY INSTRUCTIONS
7

~Pot and pan handles should be
turned inward and not extend over the
countertop to reduce the risk of burns,
ignition of flammable materials, and
spills.
~Do not use pots or pans with
pronounced edges or ridges on the
ceramic combiset. These could scratch
the combiset permanently. See
"Cookware" for more information. Grains
of salt and sand can cause scratches.
Make sure that the bases of any pots
and pans are clean, free of any fat or
oils, and are dry.
~To prevent burns and breathing
difficulty, allow the combiset to cool
before cleaning. Some cleaners may
produce toxic fumes if applied to a hot
surface.
~Keep the combiset clean. Salt,
sugar, and grit can cause scratches.
~When wiping spills on a hot
combiset with a wet sponge or cloth, be
careful to avoid steam burns.
~Do not let flammable materials,
i.e. cooking grease, accumulate on the
appliance.
~Do not use a steam cleaner to clean
this appliance. Steam could penetrate
electrical components and cause a
short circuit.
~Do not allow solid or liquid sugar,
pieces of plastic or foil to fall on the
burner when hot. If these residues are
allowed to cool on the ceramic surface
pitting or even cracking may occur.
~Any spills should be removed as
quickly as possible to prevent them
from burning on and becoming difficult
to remove.
SAVE THESE INSTRUCTIONS
AND REVIEW THEM
PERIODICALLY
IMPORTANT SAFETY INSTRUCTIONS
8

aBurner with booster
bDisplay
cIndicators
dControl knob
Indicators
lOn/Off indicator
mBooster indicator
n"Residual Heat" indicator
Guide to the combiset
9

Display
ß= No pan on burner or pan is unsuitable
A= Auto-heat
F= Fault (see "Frequently asked questions")
C/0= Safety cut-out feature (see "Safety features")
I= Booster activated
H= Overheating protection (see "Safety features")
L= Child safety lock (see "Safety features")
Burner data
CS 1221
Minimum to maximum
diameter*
Rating in watts 240 V**
7" - 11 3/4"
(18 cm - 30 cm)
normal:
with Booster:
2,400
3,700
* Pots with a bottom diameter in the stated range may be used.
** The stated power may vary depending on the size and material of the
cookware.
Guide to the combiset
10

Clean the combiset
^Before using for the first time, clean
the appliance with a damp cloth and
dry with a soft cloth.
Do not use liquid dish soap to clean
the combiset, this may cause
permanent blue discolorations.
Heat the appliance
When the combiset is first connected to
the power supply and after a power
failure, all indicators in the display will
light up for approx. 1 second. The
combiset can be used as normal once
the indicators go out.
Metal components of the appliance
have a protective coating which may
give off a slight odor the first time
the appliance is heated.
The smell will dissipate after a short
time and does not indicate a faulty
connection or appliance defect.
Before using for the first time
11

How it works
An induction coil is located under the
burner. When the burner is switched
on, this coil creates a magnetic field
which impacts directly on the base of
the pan and heats it up. The burner
itself is heated indirectly by the heat
given off by the pan.
Induction burners only work when a
magnetic based pan is placed on it
(see "Cookware").
Induction automatically recognizes the
size of the pan, i.e. heat is only
generated in the area covered by the
base of the pan.
The burner will not work:
– if it is switched on without a pan in
place, or if the pan is unsuitable
(non-magnetic base).
– if the diameter of the pan is too small.
– if the pan is taken off the burner
when it is turned on.
If this happens, ßwill flash in the
display.
If a suitable pan is placed on the burner
within 3 minutes, ßwill go out and you
can continue cooking as normal.
If no pan or an unsuitable pan is placed
on the burner, the burner and the
combiset will switch off automatically
after 3 minutes. 0will flash alternately
with Cin the display.
To use the burner again as normal, first
turn the control knob to "0".
Be careful not to place cutlery or
other metal objects on the combiset.
When the appliance is switched on,
or when there is residual heat
present, there is the risk of metal
objects heating up quickly.
Beware of burns.
Depending on the material, other
objects left on the combiset could
also melt or catch fire.
Turn off the burner after use.
Induction
12

Noises
When using an induction burner, the
following noises can occur in the pan,
depending on what it is made of and
how it is constructed.
–Higher power settings may cause a
buzz. This will decrease or cease
altogether when the power setting is
reduced.
–If the pan base is made of layers of
different materials (e.g. a
sandwiched base), a cracking sound
may be heard.
– You may hear a clicking sound from
the electronic switches, especially on
lower settings.
The appliance has a cooling fan to help
extend the life of the electronics. When
the combiset is being used at high
levels for a long period of time, this will
come on and you will hear a whirring
sound. The fan may continue to run
after the appliance has been switched
off.
Induction
13

Cookware
Suitable pans include:
–stainless steel pans with a magnetic
base
–enameled steel pans
–cast iron pans
Unsuitable pans:
–stainless steel pans without a
magnetic base
–aluminum and copper pans
–glass, ceramic or earthenware pots
and pans
To test whether a pot or pan is suitable
for use on an induction combiset, hold
a magnet to the base of the pan. If the
magnet sticks, the pan is suitable.
Unless the pan manufacturer states
that you can do so, do not use pans
with very thin bases on this
combiset, and never heat empty
pans. This could damage the
appliance and cookware, and effect
the uniformity of the cooking.
Pan size
To make optimum use of the burner,
choose cookware that fits between the
inner and outer marking of the burner. If
the base diameter of the pan is smaller
than the inner marking, the induction
heating will not work. The burner will
behave as if it has no pan on it.
Induction
14

Turning the burner On/Off
^To turn the burner on, press the
control knob down and turn it
clockwise ato the desired setting.
^To turn the burner off, turn the
control knob counterclockwise bto
"0".
Do not turn the burner on without
pressing the control knob down, and
do not turn the knob past "B I" to
reach "0".
When the combiset is turned on the
On/Off indicator lights up. Once the
combiset has reached a factory set
temperature the residual heat indicator
will light.
When the combiset is turned off the
On/Off indicator will go out.
Residual heat indicator
The residual heat indicator will go out
once the combiset has cooled to a safe
temperature.
As long as the residual heat
indicator is lit do not touch or place
any heat sensitive items on the
burner. Danger of burns, and fire
hazard.
Use
15

Settings
Use for Power level*
Melting butter, chocolate, etc.
Dissolving gelatin
Prepare yogurt
1-2
Warming small quantities of food or liquid
Keeping delicate dishes warm
Cooking rice,
Thawing frozen vegetables
1-3
Warming liquid or half-set foods
Thickening sauces, e.g., hollandaise sauce
Cooking rice pudding
2-4
Defrosting frozen foods
Steaming vegetables, fish, etc.
Cooking pasta, soups, etc.
Steaming grains
3-5
Boiling and continued cooking of large quantities of food 5 - 6
Gently sautéing fish, cutlets, sausages, fried eggs, etc.
(without smoking the oil/fat)
7
Frying pancakes, crepes, etc. 7 - 8
Boiling large quantities of water
Parboiling
9
Keep warm (
* These settings are intended as guidelines only. When cooking with large pots,
large quantities of food/liquid or without using a lid, a higher setting is needed.
For smaller quantities select a lower setting.
Use
16

Auto-heat
When Auto-heat has been activated,
the burner switches on automatically at
the highest setting and then switches to
the continued power level which was
selected. The "heat-up" time depends
on which continued power level has
been chosen (see table).
Continued
power level*
Heat-up time
(approx.)
min : sec
1 0:15
2 0:15
3 0:25
4 0:50
5 2:00
6 5:50
7 2:50
8 2:50
9-
The higher continued cooking settings
are generally used for frying, a short
heat-up time is needed to heat up the
pan initially.
Taking a pan off the burner while
Auto-heat is in operation interrupts the
function. It will resume if a pan is
placed back on the burner within
3 minutes.
Activating Auto-heat
^Turn the control knob
counterclockwise as far as it will go
and hold until an Aappears in the
display.
If the knob is held too long, an Lwill
appear in the display and the Lock
is activated (see "Child safety lock").
^Turn the control knob clockwise to
the desired continued power level.
If a continued power level is not
selected within 5 seconds, the
Auto-heat feature is not activated.
Once Auto-heat has been activated the
continued power level must be set
within 10 seconds. After this time the
level cannot be changed.
Changing the continued power level
after 10 seconds will deactivate the
Auto-heat function.
During the Auto-heat phase an Awill
show in the display.
Use
17

Booster function
The burner is equipped with a booster
function to temporarily increase the
power level. This boost is intended to
quickly bring large quantities of water
to the boil, e.g. cooking pasta. When
the Booster is activated the burner will
operate with extra power for 10
minutes.
Once the booster time has elapsed the
burner will automatically revert to power
level 9. The Bindicator and Iin the
display will go out.
Taking a pan off the burner while the
booster is in operation interrupts the
booster function. It will resume if a pan
is placed back on the burner within 3
minutes.
To activate the Booster
^Turn the control knob past power
level 9 to BI, then turn back to level 9.
Iappears in the display and the B
indicator lights up.
To deactivate the Booster function
The booster function can be turned off
early if desired.
^Turn the control knob past power
level 9 to BI and then back to 9; or
simply reduce the power level.
Use
18

Keep warm
This function can be used for keeping
food warm right after it has been
cooked. It is not for reheating food
which has already cooled.
Once activated the keep warm function
will switch off automatically after 2
hours.
Tips
–Cover the pan with a lid.
–It is not necessary to stir the food
while it is being kept warm.
–Nutrients are lost when food is
cooked, therefore try to keep the
warming time to a minimum.
Use
19

–Whenever possible, keep pots and
pans covered while cooking. This
helps keep in the most possible heat.
–When cooking small guantities of
food, use a small pot or pan. This will
required less energy to heat up than
a large pot.
–Cook with a small amount of water.
– Using a pressure cooker will greatly
reduce cooking time.
– Lower the flame after browning or
parboiling.
Energy saving tips
20
