Miele T 8001 WP SUPERTRONIC User manual

Operating instructions
for heat pump tumble dryer
T 8001 WP SUPERTRONIC
To avoid the risk of accidents or
damage to the appliance, it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 09 148 220
en - AU, NZ

Disposal of the packing
material
The packing material protects the
tumble dryer from transport damage.
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Rather than just throwing these
materials away, please ensure they are
recycled.
Disposing of your old
appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the
environment.They are, however,
essential for the correct functioning of
your appliance. Please do not therefore
dispose of the appliance with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your Chartered Agent
for advice.
Ensure that your old appliance presents
no danger to children while being
stored for disposal.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
–Load according to the optimum
amount of laundry recommended for
the programme being used.
Underloading is uneconomical.
Overloading gives poorer quality of
drying and may cause unnecessary
creasing.
– Make sure that the room temperature
is not too high. If there are other heat
producing appliances in the room in
which the dryer is located, make sure
the room is well ventilated and switch
the other appliances off if possible.
– After every cycle, remove the fluff
from the surfaces and the fluff filters
(see "Cleaning and Care").
Caring for the environment
2

Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................15
Control panel .....................................................15
Selector sensors ..................................................16
Layout of the menu structure in the main menu ..........................18
Before using for the first time.......................................20
Notes on laundry care .............................................22
Garment care label symbols .........................................22
Tips on drying ....................................................22
1. Preparing the laundry and loading the tumble dryer ..................23
2. Selecting a programme ..........................................24
Switch the dryer on by pressing K..................................24
– Programmes with drying levels ...................................24
– Time drying programmes .......................................25
– Other programmes.............................................25
Selecting Extra options ...........................................26
Delay start.....................................................26
3. Starting the programme .........................................27
To start a programme ............................................27
Note on time remaining...........................................27
Changing a programme ..........................................27
Start at/Finish at: Changing the time.................................27
Cancelling a programme .........................................28
Adding or removing laundry after a programme has started ..............28
4. Removing the laundry when the programme has finished .................29
Contents
3

Extra options ....................................................30
Freshen up.......................................................30
Gentle tumble ....................................................30
Favourite programmes ............................................31
Programme chart .................................................33
Cleaning and care ................................................38
Emptying the condensed water container...............................38
Adhering to cleaning intervals ........................................39
When to clean the surfaces of the fluff filters ..........................39
When to clean the fine filter .......................................39
Surfaces of the fluff filters ...........................................40
Cleaning without water ...........................................40
Cleaning with water .............................................41
Refitting the filters ...............................................41
Fine filter ........................................................42
Removing the fine filter ...........................................42
Cleaning the fine filter ............................................42
Cleaning the fine filter cover panel ..................................43
Cleaning the heat exchanger unit compartment .......................43
Replacing the fine filter ...........................................44
Cleaning the tumble dryer ...........................................44
Problem solving guide ............................................45
Problem solving guide ..............................................45
Fault messages in the display ........................................45
An unsatisfactory drying result .......................................48
Other problems ...................................................49
Cleaning the cooling fins (Grille at bottom right) ..........................51
Changing the lamp ................................................52
Contents
4

After Sales service................................................53
Future updates (PC) ...............................................53
Optional accessories ...............................................53
Installation and connection ........................................54
Front view........................................................54
Rear view ........................................................55
Transporting the dryer ..............................................55
Installation site ....................................................56
Building under a continuous worktop/in a row of kitchen units ............56
Levelling the machine............................................57
Washer-dryer stack..............................................57
External condensed water outlet ......................................58
Arranging the drain hose .........................................58
External drainage via a sink or gully ................................59
Installation conditions requiring a non-return valve .....................59
Electrical connection ...............................................61
Consumption data ................................................62
Technical data ...................................................63
Settings menu ...................................................64
To open the Settings menu...........................................64
Language J......................................................64
Time ............................................................65
Drying levels .....................................................65
Code ...........................................................66
Buzzer ..........................................................68
Keypad tone .....................................................68
Brightness .......................................................68
Contrast .........................................................68
Display / Keypad illumination ........................................68
Memory .........................................................69
Anti-crease.......................................................69
Contents
5

~It is essential to read these instructions.
This tumble dryer conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
~This tumble dryer is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
~This tumble dryer must only be used to dry items which have
been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. "Dry
cleaning kits" for freshening up garments in a tumble dryer are
increasingly available on the market. If using, do so at your own risk,
and follow the instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation of the tumble dryer.
Warning and Safety instructions
6

~The tumble dryer is not intended for outdoor use.
~This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it correctly by a person
responsible for their safety.
~This tumble dryer must not be installed and operated in mobile
installations (e.g. on a ship).
Safety with children
~Keep children away from the tumble dryer at all times. It is not a
toy! To avoid the risk of injury do not allow them to play on or near it
or to play with its controls. Supervise children whilst you are using it.
~Older children may only use it if its operation has been clearly
explained to them, and they are able to use it safely, recognising the
dangers of incorrect use.
Warning and Safety instructions
7

Technical safety
~Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
~Before connecting the appliance, make sure that the connection
data on the data plate (voltage and rated load) match the mains
electricity supply. If in doubt, consult a qualified electrician.
~The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is most important that this basic safety requirement is
present and regularly tested, and where there is any doubt, the
household wiring system should be inspected by a qualified
electrician. Miele cannot be held liable for the consequences of an
inadequate earthing system (e.g. electric shock).
~The heat pump technology in the
tumble dryer uses a refrigerant which is condensed by a
compressor. It is led in a closed circuit through the heat exchanger
unit where heat exchange with the circulating drying air takes place.
It is normal for humming noises caused by the heat pump
technology to be heard during the drying process. This does not
impair the efficient functioning of the dryer.
–The refrigerant is not flammable or explosive.
–In general it is not necessary to leave the dryer standing for any
length of time before it is connected to the mains provided it has
been transported and installed correctly (see "Installation").
~Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the appliance (e.g. danger of overheating).
Warning and Safety instructions
8

~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liabilty. Repairs should only be
undertaken by a Miele approved service technician.
~Faulty components must only be replaced by genuine Miele
spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
~If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
~In the event of a fault or for cleaning purposes, the tumble dryer
is only completely isolated from the electricity supply when:
– it is switched off at the wall socket and the plug is withdrawn, or
– it is switched off at the mains, or
– the mains fuse is withdrawn.
~Do not make any alterations to the tumble dryer, unless
authorised to do so by Miele.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the warranty.
Warning and Safety instructions
9

Correct use
,Caution! Risk of fire.
To avoid the possible danger of fire, please
read these warnings carefully.
,A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
~Remove all objects from pockets such as lighters and matches.
~To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have not been washed.
– Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
desposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned, there is a danger that
these might ignite when heated, even after they have been
removed from the dryer at the end of the programme.
–Items that have been soiled with substances such as cooking oil,
acetone, petrol, kerosene, spot removers, turpentine, waxes, wax
removers and other chemicals (e.g. mops and floor cloths) should
be washed in hot water with extra detergent before being dried in
the tumble dryer.
–Items which have been splashed with hair lacquer, hair spray, nail
polish remover or similar substances.
Warning and Safety instructions
10

When washing such heavily soiled items, ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.
~Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
~To prevent the risk of fire, the following textiles or products must
not be dried in this tumble dryer:
– Items which have been dry-cleaned (for example with a chemical
treatment).
–Fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
–Fabrics which contain padding or fillings (e.g. pillows, jackets). If
these were damaged, the filling could get out with the risk of
igniting in the dryer.
Warning and Safety instructions
11

~In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase is complete.
Ensure that you always wait until the end of the programme before
removing the laundry.
~Warning: Do not switch the tumble dryer off before the end of the
drying programme. If this was done, remove and spread out all
items quickly so that the heat is dissipated.
~Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.
~The tumble dryer is not to be used if industrial chemicals have
been used to clean it.
Warning and Safety instructions
12

~The tumble dryer must not be used
–without the fluff filters in place or if the fluff filters are damaged.
–without the fine filter in place or if the fine filters are damaged.
This would cause an excessive build-up of fluff which in turn would
cause a fault!
~After every cycle, remove the fluff from the surfaces and the fluff
filters (see "Cleaning and care").
~Fluff must not be allowed to accumulate around the tumble dryer.
~The fluff filters and the fine filter must be thoroughly dried after
cleaning. Damp or wet filters could cause operational faults.
~Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly.
There is a risk of damage if the condensed water is allowed to
freeze in the pump and in the drain hose.
~If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
~Condensed water is not drinking water. It can cause health
problems in both people and animals.
Warning and Safety instructions
13

~Always keep the area around the tumble dryer free of dust and
fluff.
Dust drawn into the tumble dryer can cause blockages in the
condenser unit over time.
~Do not lean on the door. This can cause the tumble dryer to tip
over.
~Always close the door after use. This way you will avoid the
danger of
–children climbing onto or into the dryer or hiding things in it.
–pets or other small animals climbing into it.
~The tumble dryer must not be hosed down.
Accessories
~Only use genuine Miele spare parts and accessories with this
tumble dryer. If non-Miele parts are used, warranty, performance
and product liabilty claims may be invalidated.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
14

Control panel
aMiele{home
The appliance is compatible with the
Miele|home system (available in
selected countries).
bSensor :(Information)
If this sensor is lit up, information is
available for the menu displayed.
cPF interface
Used by service technicians to run
diagnostic checks on your
appliance, or to update
programming data in the future.
dSelector sensors
If a selector sensor is illuminated, it is
active. See the next page for more
information.
eDisplay
For displaying:
–The selected functions.
–The programme sequence.
–Info texts.
–Fault messages.
–Time of day.
–Position of an item in the list via the
scroll bar.
fSensor U(Clear)
–Returns to the previous menu
screen.
– Returns to the main menu if pressed
twice.
– Discards previously set values.
– Cancels a programme.
gStart sensor
The selected programme is started
via the sensor illuminated in green.
hKbutton
For switching the dryer on and off.
To save energy, the dryer will switch
off automatically 15 minutes after the
end of a programme/Anti-crease, or
if no other function is selected after
switching on.
i/button
For opening the door, even if the
dryer is switched off.
Operating the tumble dryer
15

Selector sensors
The selector sensors are located on either side of the display.
If a selector sensor is active, it will be illuminated. The
following functions can be carried out using the selector
sensors:
Selecting an option in the menu
If a menu option can be selected, it will be marked with a dot
(#). If the selector sensors on the left are active, the dot (#) will
be in front of the word. If the selector sensors on the right are
active, the dot (#) will be behind the word.
Scrolling through the menu display
If the menu contains more text (a list) than which if visible in
the display, a scroll bar will appear on the right that shows
the position of items in the list:
\
\
\
Main menu 10:21 [
[
$Favourite programmes
#Cottons
!Minimum iron m
Touch the sensor on the right to move the text in the display
upwards or downwards. The list is moved one line at a time
with each touch of the sensors.
The last item in the list will be indicated by a dotted line.
Changing a displayed value
Time [
[
[
+$
10 :21 –#
OK !
The +und –sensors on the right can be used to change the
highlighted time. The changed time then needs to be
confirmed with the OK sensor.
Operating the tumble dryer
16

Favourite programmes
You can save up to 10 programmes
under a name of your choosing.
Drying assistant
This will provide you with assistance in
searching for the right programme for
your drying needs. The drying assistant
leads you step-by-step to the correct
choice for your fabrics.
Settings menu
The Settings !menu is used to alter the
dryer's electronics to suit different
requirements. See "Settings menu" for
more details.
Sensor :
If additional information is available for
an option in the menu, the :sensor will
light up. Touch the sensor if you would
like to read this information.
Programme sequence display
The current stage of the programme is
represented by symbols in the display.
Symbol Programme sequence
RDelay start
GDrying
IMachine iron
GHand iron rr
HHand iron r
ENormal
FNormal +
7Cooling down / Cancel
CCool air
DWarm air
OAnti-crease / Finish
Operating the tumble dryer
17

Layout of the menu structure in the main menu
Favourite programmes
–Favourite programmes
(sorted alphabetically)
–Create
–Change
–Delete
Cottons
– Minimum iron
– Delicates
– .... – Drying level: (depending on programme)
– .... – Duration (depending on programme)
– Extra options (depending on programme)
– Start at
– Finish at
Drying tips
– Cottons*
–Delicates*
–Cotton + Delicates*
–Woollens handcare
–Silks
–Microfibre*
–Linen*
* More options are available here
Operating the tumble dryer
18

Settings !
–Language !
–Time*
–Buzzer
–Drying levels*
–Code
–Keypad tone
–Brightness
–Contrast
– Display / Keypad illumination
– Memory
– Anti-crease
– Miele|home**
– Remote control**
* More sub-menus are available here.
** Only appears if the tumble dryer has been fitted with a communication module.
Operating the tumble dryer
19

Before using the tumble dryer for the first time, ensure that
it is correctly installed and connected. See "Installation
and connection".
,If the tumble dryer has not been transported as
described, then it must be left to stand for at least 1 hour
before it is connected to the electricity supply.
Otherwise the heat pump can get damaged.
The initial operation consists of five steps. The tumble dryer
guides you automatically through steps 1to 5.
1. Welcome screen
^Switch the dishwasher on with the On/Off button K.
The "Willkommen" screen will appear for three seconds. The
display will then switch to the screen for setting the language.
2. Setting the language
\
\
\
Language 10:21 [
[
[
$deutsch (
#english p
!español OK !
^Select the language you want the display to appear in.
^Press the sensor on the right to move the text in the display
upwards or downwards.
^Confirm the selected language with OK.
Before using for the first time
20
