Miele CS 1418 User manual

CS 1418
en-GB Scales Operating and installation instructions
da-DK Bordvægt Brugs- og monteringsanvisning
no-NO Vekt Bruks- og monteringsanvisning
pl-PL Waga kuchenna Instrukcja u¿ytkowania i monta¿u
M.-Nr. 07 228 840

en-GB ...........................................................3
Guide to the appliance ..............................................3
Warning and Safety instructions .......................................4
Before using for the first time..........................................5
Changing from metric to imperial measurements ..........................6
Switching on and weighing ...........................................6
Switching off ......................................................6
Zero setting .......................................................6
Over loading / under loading..........................................7
Replacing the batteries ..............................................7
Cleaning and care ..................................................8
Optional accessories ................................................9
Appliance and building-in dimensions .................................10
Preparing the worktop ..............................................10
Installation of several appliances .....................................11
Fixing the spring clamps and spacer bars ..............................14
Installing the appliance(s) ...........................................16
General installation tips .............................................17
After sales service, data plate ........................................18
da-DK ..........................................................19
no-NO ..........................................................39
pl-PL ...........................................................56
Contents
2

Guide to the appliance
aScales
bDisplay
cSensor for On/Off and for setting the scales to 0
dBattery compartment (underneath the appliance)
eBuilding-in frame
Weighing area
Load bearing capacity: 10 kg/22 lb
Weight displayed in5g/0.2ozsteps
Minimum weight: 15 g / 0.6 oz
Accessories supplied
Lever
For lifting the scales out of the building-in frame
4 batteries
AA Mignon LR 6/AM-3
en-GB
3
a
b
e
d
c

Warning and Safety
instructions
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before using it for the first time. They
contain important notes on its
installation, safety, use and
maintenance.
Keep these instructions in a safe
place for reference, and pass them
on to any future user.
Correct functioning can only be
guaranteed when the scales are
fitted in the building-in frame.
~This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless they
are supervised whilst using it or have
been shown how to use it correctly by a
person responsible for their safety.
~This appliance is intended for
domestic use only and is not to be used
for commercial purposes.
~Do not drop pots, pans or other
objects on the ceramic surface. Even a
light object could cause the ceramic
surface to crack or break in certain
circumstances.
~While the appliance is under
guarantee, repairs should only be
undertaken by a service technician
authorised by the manufacturer.
Otherwise the guarantee will be
invalidated.
~To avoid damage such as
scratches or marks on the surface,
please note the following:
–Do not use knives to cut food on the
weighing surface.
–Do not push pots and pans etc. back
and forth across the weighing
surface. Soiling such as sand can
also cause scratches to occur.
–Do not place hot, dirty or damp
containers or pans etc. on the
weighing surface. Please note that
soiling containing starches or acids
can cause marks to appear which
cannot be removed.
~Do not let liquid get into the
building-in frame through the gap
around the appliance. This could
damage the electronic unit. If liquid
does get into the building-in frame,
wipe it up immediately to avoid any
damage or unpleasant odours building
up.
~Do not place hot pans on the area
around the display. The electronic unit
underneath could get damaged.
~Also make sure that food particles
cannot get lodged in the gap around
the appliance or get into the building-in
frame. This could result in an incorrect
weight being shown in the display.
~In countries where there are areas
which may be subject to infestation by
cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage caused by cockroaches or
other vermin will not be covered by the
guarantee.
en-GB
4

Disposal of the packing
material
The transport and protective packaging
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure that they
are recycled.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste. Please
dispose of it at your local community
waste collection/recycling centre or
contact your dealer for advice. Ensure
that it presents no danger to children
while being stored for disposal.
Disposal of used batteries
Used batteries should be disposed of
safely. Do not dispose of them with the
normal household waste.
Before using for the first time
^Please stick the extra data plate for
the appliance supplied with this
documentation in the space provided
in the "After sales service" section of
this booklet.
^Insert the batteries supplied. See
"Replacing the batteries".
^Before using the appliance, wipe it
with a damp cloth.
en-GB
5

Changing from metric to
imperial measurements
The weight can be displayed in kg or in
lb/oz.
The switch afor changing from metric
to imperial measurements is located in
the battery compartment.
^Use the lever supplied to lift the
scales from the building-in frame.
^Remove the scales with both hands
and place them with the underside
facing upwards on a clean, smooth
surface.
^Open the lid to the battery
compartment.
^Use a ball-point pen or similar to
push switch ato the right or left.
^Close the battery compartment lid
and replace the scales in the
building-in frame.
Switching on and weighing
^Touch the ON/OFF sensor s.
"8.8.8.8.8" will appear in the display first
of all, followed automatically by "0" (kg)
or "0.00" (lb/oz).
The weighing function is now ready for
use.
^If possible, the items to be weighed
should be placed in the middle of the
weighing surface.
The weight will appear in the display.
Switching off
^Touch sensor suntil the display
goes out.
If the weighing function is not used for a
period of two minutes, it will switch itself
off automatically.
Zero setting
You can set the display to zero to add
items to those already weighed.
^Touch the ssensor.
0will appear in the display.
You can keep setting the sensor to zero
to weigh additional items.
en-GB
6

Over loading / under loading
If the item(s) being weighed is more
than 10 kg / 22 lb, the fault message "E"
will appear in the display.
If the item(s) being weighed is less than
0.015 kg / 0.6 oz, a value will appear in
the display. However, this value will be
incorrect as the appliance is not
designed for items weighing less than
0.015 kg / 0.6 oz.
Replacing the batteries
The batteries need to be replaced
when the following appears in the
display:
Four batteries are required.
^Use the lever supplied to lift the
scales from the building-in frame.
^Remove the scales with both hands
and place them with the underside
facing upwards on a clean, smooth
surface.
^Open the lid of the battery
compartment and remove the used
batteries.
^Insert the new batteries and replace
the lid. Make sure it clicks into
position.
^Replace the scales in the building-in
frame.
Only use the lever supplied to lift the
scales out of the building-in frame.
Do not use any metal implements as
these could scratch the frame.
Used batteries should be disposed
of safely. Do not dispose of them
with the normal household waste.
en-GB
7

Cleaning and care
Do not use a steam cleaning
appliance to clean this appliance.
The steam could cause lasting
damage to the surface material and
other components for which the
manufacturer cannot be held liable.
Only use the lever supplied to lift the
scales out of the building-in frame.
Do not use any metal implements as
these could scratch the frame.
To avoid damaging the surface of
your appliance, do not use:
- cleaning agents containing soda,
alkalines, ammonia, acids or
chlorides,
- cleaning agents containing
descaling agents,
- stain or rust removers,
- abrasive cleaning agents, e.g.
powder cleaners and cream
cleaners
- solvent-based cleaning agents,
- dishwasher cleaner,
- grill and oven cleaners,
- hard, abrasive sponges e.g. pot
scourers, or sponges which have
been previously used with abrasive
cleaning agents,
- sharp pointed objects
(these can damage the seal between
the frame and the worktop)
Clean the appliance using an E-Cloth or
with a solution of washing-up liquid and
hot water applied with a soft sponge.
Stubborn soiling should be soaked first.
After cleaning, dry all surfaces with a
clean cloth.
Ceramic surface
The ceramic surface of the appliance
should be cleaned after each use.
Remove light soiling with a damp cloth.
Finally wipe the surface with a damp
cloth and then dry it with a clean, soft
cloth.
Building-in frame
Clean the building-in frame regularly.
Remove any food deposits or liquid im-
mediately.
The ceramic and stainless steel hob
cleaner can be used when required
(see "Optional accessories"). Apply with
an even pressure following the direction
of the "grain".
A conditioning agent for stainless steel
can be used after cleaning to help
prevent re-soiling (see "Optional
accessories").
Apply sparingly with a soft cloth
following the instructions on the
packaging.
en-GB
8

Optional accessories
Miele branded cleaning and conditioning products are
available for your appliance.
These can be ordered via the internet at
www.miele-shop.com.
Ceramic and stainless steel hob cleaner 250 ml
Removes heavy soiling, limescale deposits and light
discolouration
Stainless steel conditioning agent 250 ml
Removes water marks, flecks and finger prints.
Helps prevent resoiling.
E-Cloth (microfibre cloth)
Removes finger marks and light soiling.
en-GB
9

Appliance and building-in
dimensions
aSpring clamps
bCasing depth
Preparing the worktop
^Make the worktop cut-out for one or
several appliances following the
dimensions applicable.
^Seal the cut surfaces with a suitable
heat-resistant sealant to avoid
swelling caused by moisture.
The materials used must be
heat-resistant.
If, during installation, you find that the
seals on the corners of the frame are
not flush with the worktop surface,
the corner radius (ßR4) can be
carefully scribed to fit.
en-GB
10
15
520
288
500
50
272
ß
R4
040
32
b
+
-1
+
-1
a

Installation of several
appliances
When installing two or more appliances next to each other a spacer bar bmust
be used between each one.
See "Fixing the spring clamps and spacer bars".
Worktop cut-out
- two appliances
When installing two appliances, the
width of the cut-out required D is
calculated by adding dimensions A and
C.
Worktop cut-out
- three appliances
When installing three appliances the
width of the cut-out required D is
calculated by adding dimensions A, B
and C.
A = appliance width (288 mm or 380 mm or 576 mm) less 8 mm
B = appliance width (288 mm or 380 mm or 576 mm)
C = appliance width (288 mm or 380 mm or 576 mm) less 8 mm
D = width of worktop cut-out
When installing more than three
appliances for each additional
appliance add the relevant appliance
width (288 mm or 380 mm or 576
mm) to dimensions A, B and C.
en-GB
11

Worktop cut-out calculation example for three appliances
A
Appliance width
less 8
B
Appliance
width
C
Appliance width
less 8
D
Worktop
cut-out
280 288 280 848
280 380 372 1032
280 576 568 1424
372 288 280 940
372 380 372 1124
372 576 568 1516
568 288 280 1136
568 380 372 1320
568 - 568 1136
All dimensions are given in mm
en-GB
12

aSpring clamps
bSpacer bars
cGap between spacer bar and worktop
dSealing strip
The illustration shows a worktop cut-out with spring clamps aand spacer bars b
for 3 appliances.
An additional spacer bar is required for each additional appliance. The position
for securing each additional spacer bar will depend on the width of appliance B
(288 mm / 380 mm / 576 mm).
en-GB
13

Fixing the spring clamps and
spacer bars
Wooden worktops
^Position the spring clamps supplied
aand spacer bars bon the top
edge of the cut-out in the positions
marked.
^Secure the spring clamps and
spacer bars with the 3.5 x 25 mm
screws supplied.
en-GB
14

Granite and marble worktops
The screws are not required for
granite or marble worktops.
^Position and secure the spring
clamps aand spacer bars busing
strong, double-sided adhesive tape
c.
^Apply silicone to the side edges and
the lower edges of spring clamps a
and spacer bars b.
^Then fill gap ebetween the spacers
bars and the worktop with silicone
from the tube supplied.
en-GB
15

Installing the appliance(s)
^Starting at the front, position the
building-in frame in the worktop
cut-out.
^Using both hands, press down
evenly on the sides of the building-in
frame until it clicks into position.
When doing this make sure that the
seal sits flush with the worktop on all
sides. This is important to ensure an
effective seal all round. Do not use
sealant.
When installing several appliances, a
sealing strip must be fitted into each
spacer bar.
^Push the building-in frame to the side
until the long slots in the spacer bar
can be seen.
^Fit the sealing strip dinto the long
slots in the spacer bar b.
^Starting at the front, position the next
appliance in the worktop cut-out.
Once installed, the building-in frame
can only be removed using a special
tool.
It can also be pushed up out of the
cut-out from below. It must be
pushed up from the back first.
en-GB
16

General installation tips
Do not use any sealant unless
expressly instructed to do so. The
sealing strip under the edge of the top
part of the appliance provides a
sufficient seal for the worktop.
Do not use sealant between the
frame of the top part of the
appliance and the worktop.
This could cause difficulties if the
appliance ever needs to be taken
out for servicing and possibly result
in damage to the frame or the
worktop.
Tiled worktop
Grout lines aand the hatched area
underneath the surface of the
appliance must be smooth and even. If
they are not, the appliance will not sit
flush with the worktop and the sealing
strip underneath the top part of the
appliance will not provide a good seal
between the appliance and the
worktop.
en-GB
17

After sales service, data plate
In the event of any faults which you cannot remedy yourself, or if the appliance is
under guarantee, please contact:
–Your Miele dealer, or
–Miele (see back cover for contact details).
Please note that telephone calls may be monitored and recorded to improve
our service.
When contacting Miele, please quote the model and serial number of your
appliance. These are given on the data plate.
Space in which to stick the extra data plate supplied with the appliance. Ensure
that the model number is the same as the one on the front of these instructions.
en-GB
18

da-DK ..........................................................20
Beskrivelse af bordvægten ..........................................20
Råd om sikkerhed og advarsler.......................................21
Inden vægten tages i brug ..........................................22
Vægtenhed indstilles ...............................................23
Vægten tændes og betjenes .........................................23
Vægten slukkes ...................................................23
Tara-funktion .....................................................23
Overvægt / undervægt .............................................24
Batterier udskiftes .................................................24
Rengøring og vedligeholdelse........................................25
Ekstra tilbehør ....................................................26
Indbygningsmål ...................................................27
Bordpladen forberedes .............................................27
Indbygning af flere produkter ........................................28
Montering af spændfjedre og afstandslister .............................31
Produkt / produkter monteres ........................................33
Service / reklamationsfrist .........................................34
Generelle indbygningsanvisninger ....................................37
Typeskilt.........................................................38
Indholdsfortegnelse
19

Beskrivelse af bordvægten
aVægt
bDisplay
cBerøringsfelt til Tænd/Sluk og tara
dBatterirum (på undersiden af vægten)
eIndbygningsdel
Vejeområde
Vejning af op til 10 kg / 22 lb.
Måling i trina5g/0,2oz.
Min. vægt: 15 g / 0,6 oz.
Medfølgende tilbehør
Specialværktøj
Anvendes til at løfte vægten ud af indbygningsdelen
4 batterier
AA Mignon LR 6/AM-3
da-DK
20
a
b
e
d
c
