en Operating Instructions Vacuum Cleaner
fr Instructions d'utilisation Aspirateur
es Manual de Uso y Manejo Aspiradora
SGDE0, SGEE0, SGFE0, SGJE0
M.-Nr. 10 093 350
HS15

2
Only Miele FilterBags, filters and accessories with
the "Original Miele" logo can be used with this
vacuum. Only then can the suction power of the
vacuum cleaner reach its optimum potential creating
the best possible cleaning results.
USE OF NON-MIELE COMPONENTS MAY VOID
THE WARRANTY.
,The use of FilterBags made of paper or a similar
material, or FilterBags with a cardboard retaining
plate can lead to serious damage to the vacuum
cleaner and may void the warranty, just as with the
use of FilterBags without the "Original Miele" logo.
The "Original Miele" Logo will appear on the
packaging or directly on the FilterBag.
Purchasing new FilterBags and filters
Original Miele FilterBags and filters can be purchased
from an authorized Miele vacuum dealer or by visiting the
Miele store at www.mieleusa.com.

IMPORTANT SAFETY INSTRUCTIONS
Guide to the vacuum cleaner
Before using the vacuum cleaner
Using the included accessories
Use
Power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Turning the vacuum cleaner on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Selecting the suction power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Opening the auxiliary air regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
While vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Illuminating the work area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Parking, transport and storage
Maintenance and care
Purchasing new filter bags and filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Which filter bags and filters are the right ones? . . . . . . . . . . . . . . . . . . . . . . . . . . 16
When to change the filter bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
How to change the filter bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
When should I change the dust compartment filter?. . . . . . . . . . . . . . . . . . . . . . . 17
How to change the dust compartment filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
When should I change the exhaust filter? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
How to replace the AirClean exhaust filter?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
How do I change the Active AirClean 50 or the HEPA AirClean 50 exhaust filter? 18
Exchanging exhaust filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Service indicator with reset button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing the batteries on the LED handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
When to change the thread catcher of the standard floor brush . . . . . . . . . . . . . 19
Replacing the thread catchers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning and care
Frequently asked questions
Technical service
Optional accessories
Caring for the environment
LIMITED WARRANTY - VACUUM CLEANERS USA
3
en - Contents

When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE
USING THIS APPLIANCE
Keep these operating instructions in a safe place and pass them on to any
future user.
WARNING-
To reduce the risk of fire, electric
shock or injury:
Before using
~Check the voltage rating of the
vacuum cleaner before connecting the
power cord to an electrical outlet. Your
power source should correspond with
the voltage rating plate located on the
underside of the vacuum. Use only
household AC outlets. Never use DC
power sources. If you are not sure of
your home’s voltage supply, consult a
qualified electrician. Connecting the
vacuum cleaner to a higher voltage
than indicated in these instructions may
result in damage to the vacuum cleaner
or injury.
~To reduce the risk of electric shock,
this appliance has a polarized plug
(one blade is wider than the other.) This
plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does
not fit, contact a qualified electrician to
install the proper outlet. Do not alter the
plug in any way.
~A damaged vacuum cleaner can be
dangerous. Check the packaging,
vacuum cleaner and accessories for
any signs of damage. Do not use a
damaged appliance.
~Do not use with a damaged cord or
plug. If the appliance is not working as
it should, has been dropped, damaged,
left outdoors or submerged in water,
bring it to a service center.
~The electrical outlet must be fitted
with a 15 A fuse.
en - IMPORTANT SAFETY INSTRUCTIONS
4

Use
~Do not use on people or animals.
~Do not use outdoors or on wet
surfaces. Only dry surfaces should be
vacuumed.
~Use only as described in this
manual. Use only Miele recommended
accessories.
~Do not alter or modify the vacuum
cleaner.
~This appliance is intended for
household use only.
~Do not allow the vacuum cleaner to
be used as a toy. Close attention is
necessary when used near children.
~Keep batteries out of the reach of
children.
~Important information on the
handling of batteries:
- Do not short circuit or recharge
batteries, or throw them into a fire.
- Disposing of batteries: Remove the
batteries from the LED handle and
dispose of them in your recycling bin.
Do not dispose of them with the normal
household waste.
~Never use the vacuum cleaner
without the filter bag or filters in place.
Otherwise it could be damaged.
~If a filter bag is not inserted, the dust
compartment lid will not close. Do not
force it shut.
~Do not leave the vacuum plugged
in. Unplug it from the outlet when not in
use and before servicing.
~On the underside of the vacuum
handpiece is a metal insert designed to
absorb static electricity. Please make
certain that your hand remains around
this metal insert when vacuuming.
~Persons which lack physical,
sensory or mental abilities or
experience with the machine should not
use it without supervision or instruction
by a responsible person.
~Unwind the cord completely to aid
the vacuum cleaner in dissipating heat.
~This vacuum should not be used to
entrap or retain any hazardous
materials.
~Do not use the vacuum cleaner to
pick up liquids or damp dirt. This could
impair the electrical safety of the
vacuum cleaner. Wait for freshly
shampooed carpets to dry.
~Do not vacuum anything that is
burning or smoking such as cigarettes,
matches or hot ashes. The vacuum
cleaner could catch fire.
~Do not vacuum toner dust. Toner,
such as that used in printers and
photocopiers can conduct electricity.
~Do not use to pick up any flammable
or combustible liquids, such as
gasoline, or use in areas where they
may be present. The vacuum cleaner
could explode.
~Do not vacuum up items which are
heavy, hard or have sharp edges. They
could cause a blockage and damage
the appliance.
en - IMPORTANT SAFETY INSTRUCTIONS
5

~Do not pull or carry by the cord, use
the cord as a handle, close a door on
the cord, or pull the cord around sharp
edges or corners. Do not run the
appliance over the cord. Keep the cord
away from heated surfaces.
~Do not unplug by pulling on the
cord. To unplug, grasp the plug, not the
cord.
~Do not handle the plug or vacuum
with wet hands.
~Keep the power cord, hair, loose
clothing, fingers and all parts of the
body away from openings and moving
parts.
~Do not place anything into the
openings of the vacuum cleaner. Do
not use if any openings are blocked;
keep them free of dust, lint, hair, or
anything that may reduce air flow.
~This appliance is equipped with a
power cord reel. Hold plug when
rewinding onto cord reel. Do not allow
plug to whip when rewinding.
~Turn off all controls before
unplugging.
~Use extra care when cleaning on
stairs.
~Floor attachments, accessories and
wands must not be used at head level
to avoid injury to eyes and ears.
~Monitor the filter bag change
indicator and inspect all filters regularly.
For best performance, the filter bag
and filters should be replaced when
necessary. A full bag or blocked filter
will reduce the vacuum cleaner’s
suction power. A temperature limiter
automatically switches the vacuum
cleaner off if it gets too hot, see
"Frequently asked questions".
Using accessories
~The hose and the telescopic wand
contain electrical wires. Do not use the
vacuum cleaner if these parts are
damaged, cut or punctured. Avoid
picking up sharp objects. Danger of
electric shock!
~Unplug the vacuum when changing
accessories, especially the Hose,
Telescopic wand, Turbobrush and
Powerbrush.
~To avoid the risk of injury when
vacuuming with a Miele Power or
Turbobrush do not touch the rotating
roller brush. Danger of injury.
~The socket on the vacuum cleaner
(depending on model) must only be
used for the Miele Powerbrush
specified for use with this appliance.
~Danger of injury. The Miele
Powerbrush is a motor driven
accessory for use only with Miele
vacuum cleaners. The vacuum cleaner
must not be used with another
manufacturer’s powerbrush.
en - IMPORTANT SAFETY INSTRUCTIONS
6

~Do not use the vacuum cleaner
without an accessory attached. The rim
could be damaged and injuries could
result from sharp edges.
~Miele filter bags are disposable and
intended to be used only once. Do not
attempt to reuse. An over stuffed filter
bag will reduce the efficiency of the
vacuum cleaner.
~Only use genuine Miele filter bags
with the Miele quality signet and
original Miele filters and accessories.
Only then will the manufacturer
guarantee its safety.
Cleaning, maintenance and
repairs
~Turn the vacuum cleaner off after
each use and before every cleaning /
maintenance. Pull the plug from the
outlet.
~Never submerge the vacuum
cleaner in water. Clean only with a dry
cloth or slightly damp cloth when
disconnected from the mains supply. If
moisture gets into the appliance there
is a risk of electric shock.
~The electro-suction hose and the
telescopic wand contain electrical
wires. The plug connectors must not
come in contact with water. These
items may only be cleaned with a dry
cloth, no moisture can touch them.
Danger of electric shock.
~Repairs must only be performed by
an authorized service agent in
accordance with national and local
safety regulations. Unauthorized repairs
could cause injury or machine damage.
~If the power cord is damaged it
should be replaced along with a new
cable reel by Miele Technical Service.
Disposing of an old appliance
~Before discarding an old vacuum
cleaner, please cut off the power cord
and render the plug useless. Ensure
the appliance presents no danger to
children while being stored for
disposal.
SAVE THESE
INSTRUCTIONS
en - IMPORTANT SAFETY INSTRUCTIONS
7

en - Guide to the vacuum cleaner
8

The illustrations show the vacuum cleaner and all available options.
aSuction hose *
bAccessory compartment lid release
cAirflow indicator
dDisplay panel *
eFoot switch for automatic cord rewind
fPark-System for breaks in vacuuming
gFoot switch On/Off s
hPower cord
iSwivel casters *
jExhaust filter *
kPark-System for storage (on both sides of the vacuum cleaner,
illuminated depending on model)
lDust compartment filter (motor protection)
mBracket cover for the Powerbrush outlet
nOriginal Miele filter bag
oCarrying handle
pFloor tool *
qLock release button
rTelescopic wand *
sDust compartment lid release
tTelescopic wand release button
uPowerbrush outlet *
vElbow *
wLED *
xStandby button for brief breaks in vacuuming *
ySuction power buttons +/-*
zHandpiece (depending on model with auxiliary air regulator) *
{Thermo indicator light §*
|Reset button *
}Standby indicator *
~Service indicator with reset button *
The features marked *may vary or not be available on your model.
en - Guide to the vacuum cleaner
9

The illustrations referred to in the text
are shown on the fold-out pages at the
end of these operating instructions.
Before using the vacuum
cleaner
Attaching the suction hose (see fig. 1)
^Insert the elbow into the suction
socket until it clicks into place.
Disconnecting the hose (see fig. 2)
^Press the release buttons on the
sides of the elbow and lift the hose
from the socket.
Connecting the suction hose and
handpiece (see fig. 3)
Depending on the model, the hand-
piece is already pre-fitted at the other
end of the hose at the factory. If the
handpiece of your model is separate, it
just needs to be connected to the hose.
^Insert the hose into the handpiece
until it clicks into place.
Connecting the telescopic wand and
handpiece (see fig. 4)
^Insert the handpiece into the
telescopic wand until it clicks into
place. Use the inlet guides of both
parts to direct insertion.
^To separate the parts from each
other, press the wand release button
and pull the handpiece away from
the telescopic wand with a slight
rotation.
Adjusting the telescopic wand (see
fig. 5)
This telescopic wand is composed of
two interlocking tube sections that can
be adjusted to the desired length.
^Press the adjustment button and
slide the tubes to the desired length.
Attaching the standard floor brush
AllTeQ or AirTeQ (see fig. 6)
(depending on model)
Observe the cleaning instructions of
the floor manufacturer.
^Place the floor brush on the
telescopic wand and twist back and
forth until it clicks into place.
^To remove the floor brush from the
telescopic wand, press the release
button.
The floor brush is intended for everyday
use on carpets, rugs, and hard flooring
that is not susceptible to scratching.
For other floor coverings, we recom-
mend using the special Miele brushes
(see the section on "Optional accesso-
ries").
Adjusting the standard floor brush
AllTeQ or AirTeQ (see fig.7+8)
(depending on model)
Observe the cleaning instructions of
the floor manufacturer.
To clean carpets and rugs, lower the
bristles by
^pressing the foot switch %.
en
10

To clean hard flooring, raise the tool by
^pressing the foot switch ).
Always use the floor brush with the
bristles raised to clean floors with
very deep joints or gaps.
AirTeQ floor brush (see fig. 8)
This floor brush is specially designed to
achieve good cleaning results with low
energy consumption. It is especially
aerodynamic and powerful.
,If the floor tool is difficult to move
across the carpeting reduce the
suction power.
Activating the exhaust filter change
indicator
Depending on the model, one of the
following standard exhaust filters is
installed (see fig. 9).
aAirClean Filter
bActive AirClean 50 Filter (black)
cHEPA AirClean 50 Filter (white)
If your vacuum cleaner is equipped
with a type bor cexhaust filter, you will
need to activate the exhaust filter
change indicator.
^Open the dust compartment lid and
raise until it clicks into place (see fig.
10).
^Remove the marker strip (see fig. 11).
^Press the exhaust filter change
indicator ~(see fig. 12).
^After about 10-15 seconds, a small
red marker will appear in the
left-hand side of the display (see fig.
13).
^Close the dust compartment lid until
it clicks into place. Take care not to
catch the dustbag in the lid.
How the exhaust filter change indica-
tor works
The exhaust filter change indicator
displays the usable life of the exhaust
filter. The indicator will turn fully red
after approx. 50 hours of operation,
which is equivalent to one year of
average use (see fig. 14).
Inserting batteries into the LED
handle (see fig. 15 + 16)
(depending on model)
aLoosen the screws on the cover.
bPress down on both sides of the
cover to remove.
cTake out the battery holder and insert
the three batteries supplied making
sure they are inserted correctly.
dReplace the batter holder in the
direction of the arrows on the holder
and battery compartment, so that
both line up.
eReplace the cover and tighten the
screws.
en
11

Using the included accessories
(see fig. 17)
The following accessories are included:
aCrevice nozzle
For cleaning in folds, crevices and
corners.
bDust brush with natural bristles
For cleaning moldings, ornate,
carved or especially sensitive items.
The brush head can be swiveled to
the optimal cleaning position.
cUpholstery tool
For cleaning upholstery, mattresses,
cushions, curtains, covers, etc.
Certain models come with one of the
following accessories that are not
shown.
– Powerbrush
– Turbobrush
– Comfort handle with light
These vacuum cleaners have separate
operating instructions for the
corresponding accessory.
Removing the accessories (see fig. 18)
^Press the release button.
The accessory compartment opens.
^Take out the accessory needed.
^Close the accessory compartment by
pressing on the lid.
Standard floor brush AllTeQ or Air-
TeQ (see fig. 19)
(depending on model)
Also suitable for vacuuming stairs.
,For your own safety, always
vacuum stairs from bottom to top.
Use
Power cord
,Unwind the cord completely to
aid the vacuum in dissipating heat.
Do not pull or carry by the cord, use
the cord as a handle, close a door on
the cord, or pull the cord around
sharp edges or corners. Do not run
the appliance over the cord. Keep
the cord away from heated surfaces.
Do not unplug by pulling the cord. To
unplug grasp the plug, not the cord.
This appliance is equipped with a
power cord reel. Hold the plug when
rewinding onto cord reel. Do not
allow plug to whip when rewinding.
Unwinding (see fig. 20)
^Pull the cord out to the desired length
(max. approx. 24.6 ft. / 7.5 m).
^Insert the plug into the electrical
outlet.
Depending on model, the lighting of the
Park-System on both sides of the
vacuum cleaner switches on.
The first time the vacuum cleaner is
used, the lighting turns on after
approx. two minutes.
en
12

,If you intend to use the vacuum
cleaner for more than 30 minutes,
you will need to pull the cord all the
way out. This is to help prevent
overheating and damage to the
appliance.
Rewinding (see fig. 21)
^Unplug the power plug from the
electrical outlet.
If your vacuum cleaner is equipped
with an illuminated Park-System, the
lighting switches off again automatically
approx. 30 seconds after disconnecting
the power.
^Press the rewind foot switch and the
power cord will automatically rewind.
Turning the vacuum cleaner on and
off (see fig. 22)
^Press the On/Off foot switch s.
Selecting the suction power
You can adjust the suction power to suit
the situation. When you reduce the
suction power, the floor brush can be
moved with less effort.
On the vacuum cleaner you will see
various symbols showing examples of
which power level is recommended for
which purpose.
The selected power level light is yellow.
#- Draperies, fabrics
$- Upholstery, pillows
%- Thick pile carpets, rugs and
runners.
Auto = Automatic adjustment of the
suction power to the flooring
(depending on model)
,Do NOT use the "Auto" power
level to vacuum draperies or other
lightweight fabrics. Excessive
suction may cause damage to such
items.
*- Energy-efficient everyday
vacuuming, low noise
(- Low pile carpets
)- Hard flooring and intensive
cleaning of carpets.
,If the floor tool is difficult to move
across the carpeting reduce the
suction power.
Depending on the model, your vacuum
cleaner will be equipped with one of the
following suction settings.
Foot switches (see fig. 23)
When used for the first time, the
vacuum cleaner will turn itself on to the
highest power level.
The next time it is used, it will turn on to
the power level last selected.
^To select a higher power setting,
press the +foot switch.
^To select a lower power setting,
press the -foot switch.
13
en

Automatic foot switches (see fig. 24 +
25)
When used for the first time, the
vacuum cleaner turns on to the "Auto"
power level.
Auto = Automatic adjustment of the
suction power to the flooring
,Do NOT use the "Auto" power
level to vacuum draperies or other
lightweight fabrics. Excessive
suction may cause damage to such
items.
^To select a higher power setting,
press the +foot switch.
^To select a lower power setting,
press the -foot switch.
The next time it is used, it turns on to
the power level last selected.
Opening the auxiliary air regulator
(see fig. 26)
(depending on model)
You can easily reduce the suction
power briefly to prevent the brush from
sticking to textile flooring, for example.
^Open the auxiliary air regulator just
far enough so that the suction nozzle
moves easily.
This reduces the suction so the floor
tool is easier to push.
While vacuuming (see fig. 27 + 28)
The vacuum cleaner can also stand on
its end for vacuuming stairs, drapes
etc.
,To prevent static electricity your
hand must touch the metal inlay on
the underside of the vacuum hand-
piece. Be certain to continuously
touch this inlay when vacuuming
fine dust, flour or sawdust as these
materials are more likely to create a
static electricity. To further prevent
static discharge while vacuuming,
pull the vacuum along by the hose
with one hand while continuing to
hold the handpiece in the other
hand.
Illuminating the work area (see fig. 29)
(depending on model)
Your vacuum cleaner is equipped with
an LED on the handle to illuminate the
work area.
^Press the Ibutton on the LED
handle.
It will turn itself off automatically after
approx. 30 seconds.
Parking, transport and storage
Park-System (see fig. 30)
(not for use with Powerbrushes
SEB 228 / EB03 and SEB 236 / EB01)
The Park-System allows you to park the
telescopic wand and the suction unit on
the vacuum cleaner during brief pauses.
^Insert the parking clip attachment on
the suction unit into the parking slot
from above.
If the vacuum is on an incline, e.g. a
ramp, slide the tube sections of the
telescopic wand all the way in.
en
14

Turning on and off with the
Park-System
(depending on model)
The vacuum cleaner is automatically
turned off if you insert the suction unit
with the parking slot into the
Park-System.
Lifting the suction unit out turns the
vacuum cleaner automatically back on
using the last selected power level.
Park-System for storage (see fig. 31)
,Turn the vacuum cleaner off
after use. Unplug the power plug
from the electrical outlet.
After approx. 30 seconds the parking
system lighting turns off if your vacuum
cleaner is equipped with an illuminated
Park-System.
^Stand the vacuum cleaner upright.
It is helpful to completely insert the
tubes into the telescopic wand.
^Insert the suction unit with the
parking slot from above into either
side of the Park-System (cannot be
used with Powerbrushes SEB 228 /
EB03 and SEB 236 / EB01).
This makes the vacuum cleaner easier
to carry and store.
Maintenance and care
,Turn off and unplug the vacuum
cleaner before performing any
maintenance work.
The Miele filter system consists of the
following three components.
–Filter bag
–Exhaust filter
–Dust compartment filter
Each of these components must be
changed periodically to maintain the
vacuum cleaner’s efficiency.
Only use Miele filter bags, filters and
accessories with the "Original Miele"
logo. Only then can the suction
power of the vacuum cleaner reach
its optimum potential for the best
possible cleaning results.
,The use of filter bags made of
paper or a similar material, or filter
bags with a cardboard retaining
plate can lead to serious damage to
the vacuum cleaner and may
possibly voiding the warranty, just
as with the use of filter bags without
the "Original Miele" logo.
Purchasing new filter bags and filters
Original Miele filter bags and filters can
be purchased from an authorized Miele
vacuum dealer or by visiting the Miele
store at http://store.miele.com.
en
15

Which filter bags and filters are the
right ones?
This vacuum cleaner uses Original
Miele filter bags Type G/N and Original
Miele filters, the "Original Miele" Logo
will appear on the packaging or directly
on the filter bag.
An "AirClean" exhaust filter and a dust
compartment filter are supplied with
every box of Miele filter bags.
If you would like to purchase additional
Miele filters separately, contact your
vacuum cleaner dealer or Miele, please
quote the model number of your Miele
vacuum cleaner to ensure correct parts
are ordered. These parts are also
available to order from the online Miele
store.
The exhaust filter supplied with the
vacuum cleaner can be exchanged
with another type of Original Miele filter
(see "Exchanging exhaust filters").
When to change the filter bag (see
fig. 32)
Change the filter bag when the colored
marker in the airflow indicator
completely fills the display in red.
Filter bags are disposable and are
designed to be used only once.
Dispose of full filter bags. Do not
attempt to reuse.
Clogged pores reduce the suction
power of the vacuum cleaner.
Check the airflow indicator
^Attach the standard floor brush
AllTeQ or AirTeQ (depending on mo-
del) to the vacuum cleaner. All other
suction tools may affect the function
of the airflow indicator.
^Switch the vacuum cleaner on and
select the highest power level.
^Lift the floor brush slightly off the
floor. If the marker completely fills the
indicator window, the filter bag needs
to be changed.
How the airflow indicator works
The airflow indicator is designed to
show when the bag is full of common
household dust and measures the
amount of air flow through the filter bag.
Normal household dust is a mixture of
dust, hair, carpet fluff, threads, sand,
etc.
However, if fine dust, such as drill dust,
sand, plaster or flour is vacuumed, the
pores of the filter bag may become
blocked. The marker will indicate that
the bag is "full" even when it is not. The
filter bag should be changed as the
suction power is greatly reduced.
en
16

If the bag is bulging with pet fur, hair,
carpet fluff, etc. the indicator may not
register "full". This is because the air
flow of the filter bag may still be high
enough not to activate the marker to
show maximum. The filter bag should
still be changed.
How to change the filter bag (see fig.
33 + 34)
^Lift the release button and open the
dust compartment lid upwards until it
clicks into place (see fig. 10).
The filter bag has a flap that
automatically closes to prevent dust
from escaping when the bag is
removed.
^Grasp the collar and remove the filter
bag from the holder.
^Insert the new filter bag into the blue
holder as far as it will go. Note: Do
NOT unfold the filter bag when you
take it out of the box.
^Unfold the filter bag in the dust
compartment when possible.
^Now close the dust compartment lid
until it clicks into place, take care not
to catch the filter bag in the lid.
,If you do not insert a replacement
filter bag, the dust compartment lid is
designed not to close. Do not use
force!
When should I change the dust
compartment filter?
Change the filter each time you open a
new box of genuine Miele filter bags. A
dust compartment filter is supplied with
every box of Miele filter bags.
How to change the dust
compartment filter (see fig. 35)
^Open the dust compartment lid.
^Grasp the finger grip and pull the
filter bag out of the holder.
^Open the blue filter frame until it
clicks into place, use the clean
corner to remove the used dust
compartment filter.
^Insert a new dust compartment filter.
^Close the filter frame.
^Insert the new filter bag into the blue
holder as far as it will go.
^Close the dust compartment lid until
it clicks into place.
When should I change the exhaust
filter?
Depending on the model, your vacuum
cleaner will use one of the following
standard exhaust filters (see fig. 9):
aAirClean Filter
Change the exhaust filter each time you
open a new box of Miele filter bags.
A new AirClean exhaust filter is included
in every box of Miele filter bags.
en
17

bActive AirClean 50 Filter (black)
cHEPA AirClean 50 Filter (white)
If the display of the exhaust filter
change indicator has turned fully red
(see fig. 14).
The indicator light will come on after
approx. 50 hours of operation, which is
equivalent to one year of average use.
The vacuum cleaner can still be used
however, the filter performance and
suction power will be reduced.
How to replace the AirClean exhaust
filter? (see fig. 36 + 37)
Make sure that only one exhaust
filter is inserted in the frame.
^Open the dust compartment lid.
^Squeeze the release for the filter
frame and open until it clicks.
^Grasp one of the two clean corners
(see arrow) to remove the used
AirClean exhaust filter.
^Insert a new AirClean exhaust filter.
But if you want to install an Active
AirClean 50 filter or HEPA AirClean 50
filter, you must heed the section
"Maintenance and care -
Exchanging exhaust filters".
^Close the filter frame.
^Close the dust compartment lid until
it clicks into place.
How do I change the Active AirClean
50 or the HEPA AirClean 50 exhaust
filter? (see fig. 38 + 39)
Make sure that only one exhaust
filter is inserted in the frame.
^Open the dust compartment lid.
^Lift the exhaust filter and remove it.
^Install the new Active AirClean 50 or
HEPA AirClean 50 exhaust filter and
press it downwards.
^Press the exhaust filter change
indicator ~(see fig. 12).
^After about 10-15 seconds, a small
red marker will appear in the left-hand
side of the display (see fig. 13).
If you want to install an AirClean
exhaust filter, you must adhere to
the section "Maintenance and
care - Exchanging exhaust filters".
^Close the dust compartment lid until
it clicks into place.
Exchanging exhaust filters
Depending on the model, your vacuum
cleaner will use one of the following
standard exhaust filters (see fig. 9):
aAirClean Filter
bActive AirClean 50 Filter (black)
cHEPA AirClean 50 Filter (white)
en
18

Important
Make sure that only one exhaust
filter is inserted in the frame.
1. If you replace exhaust filter awith
exhaust filter bor c, you must be sure
to remove the filter frame before
inserting the new filter type. The
exhaust filter change indicator must
also be activated (see fig. 12).
2. If you replace exhaust filter bor c
with exhaust filter a, you must be sure
to place the new filter in the filter frame
*(see fig. 37).
*Filter frame - see section on "Optional
accessories"
Service indicator with reset button
(see fig. 40)
(depending on model)
The indicator light will come on after
approx. 50 hours of operation, which is
equivalent to one year of average use.
Check if the motor protection filter and
the exhaust filters need to be replaced
as well. You will need to reset the
indicator after replacing any of these
components.
To do this, the vacuum cleaner must be
turned on.
^Press the reset button.
The service indicator will go out and be
reset to its original position.
The reset feature only works properly
if the indicator light has already come
on, but not if the reset button is pres-
sed in between filter changes.
Changing the batteries on the LED
handle (see fig. 15 + 16)
(depending on model)
You will need three AAA (1.5V) batteries.
aLoosen the screws on the cover.
bPress down on both sides of the
cover to remove.
cTake out the battery holder and
change the 3 batteries, making sure
they are inserted correctly.
dReplace the battery holder in the
direction of the arrows on the holder
and battery compartment, so that
both line up.
eReplace the cover and tighten the
screws.
Cleaning the floor roller of the floor
brush AllTeQ (see fig. 41)
(depending on model)
aRelease the roller pin using a coin.
bPush and take out the roller axle.
cTake out the roller.
^Remove all threads, hair etc. and
reinstall the roller and lock the roller
pin.
When to change the thread catcher
of the standard floor brush
(depending on model)
The thread catcher on the standard
floor brush can be replaced when the
pile is worn out.
en
19

Replacing the thread catchers
(see fig. 42 + 43)
^Use a screwdriver or similar object to
remove the thread catchers from the
slots.
^Insert the new thread catchers.
New thread catcher pads can be
purchased from any authorized Miele
vacuum dealer or Miele.
Cleaning and care
,Turn off the vacuum and unplug
it from the outlet before performing
any maintenance work.
Vacuum cleaner and accessories
The vacuum cleaner and other plastic
accessories can be cleaned with a damp
cloth or a cleaner suitable for plastics.
,Do not use abrasive, oil-based,
glass or all purpose cleaners!
Dust compartment
The dust compartment can, if necessary,
be cleaned using a dry cloth, dusting
brush or a second vacuum to remove any
dust.
Monitor the filter bag change indicator
and inspect all filters regularly. Clean or
replace them when necessary according
to these Operating Instructions.
,Do not submerge the vacuum in
water. If moisture gets into the
appliance there is the risk of an
electric shock.
Frequently asked questions
The vacuum cleaner shuts off
automatically.
A warning light §comes on to
indicate overheating, depending on
model (see fig. 44).
A temperature sensor will turn off the
vacuum cleaner if it becomes too warm.
This problem can occur if, for example,
an object is blocking the suction hose or
the filter bag pores have become
clogged with fine dust. The cause could
also be a heavily soiled exhaust or dust
compartment filter. If this happens, turn
off the vacuum cleaner (press the On/Off
foot switch s) and unplug the power
plug from the electrical outlet.
Once the cause has been addressed,
allow the vacuum cleaner to cool for
approx. 20 - 30 minutes before
resuming vacuuming.
Technical service
In the event of a fault which you cannot fix
yourself please contact the Miele Service
Department at the phone number listed
on the back of this booklet.
^Please quote the model type of your
appliance.
This can be found on the data plate on
the bottom of the vacuum.
Optional accessories
Always follow the flooring
manufacturer's cleaning and care
instructions.
You can order these and many other
products via the Miele website.
en
20
