Miele DA 2050 User manual

Operating and Installation instructions
Rangehood
DA 2050
To avoid the risk of accidents
or damage to the appliance,
it is essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 09 723 310
en - AU, NZ

Caring for the environment..........................................3
Warning and Safety instructions .....................................4
Modes of operation ................................................9
Guide to the appliance ............................................10
Operation .......................................................11
To switch the lighting on and off ......................................11
To switch the fan on................................................11
To select a power level .............................................11
Intensive setting ................................................11
Switching off .....................................................11
Cleaning and care ................................................12
Housing .........................................................12
Grease filter ......................................................12
Fitting and replacing the charcoal filters ................................14
Changing a halogen lamp ...........................................15
Appliance dimensions.............................................16
Safety distances between cooktop and rangehood (S) ..................16
Installation ......................................................18
Fitting the non-return flap............................................18
Building in .......................................................18
Preparation for extraction ...........................................19
Electrical connection ...............................................20
Connection for air extraction .......................................21
Condensate trap ..................................................22
Silencer .........................................................23
Electrical connection..............................................24
After sales service ................................................25
Technical data ...................................................26
Contents
2

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
or machine
Electrical and electronic appliances /
machines often contain materials
which, if handled or disposed of
incorrectly, could be potentially
hazardous to human health and to the
environment. They are, however,
essential for the correct functioning of
your appliance or machine. Therefore,
please do not dispose of your old
machine or appliance with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person.
The plug must be rendered useless
and the cable cut off directly behind the
appliance or the machine to prevent
misuse.
Caring for the environment
3

This appliance complies with all
relevant local and national safety
requirements. Inappropriate use
can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before using it for the first time.
They contain important information
on the safety, installation, use and
maintenance of the appliance.
Keep these instructions in a safe
place and ensure that all users are
familiar with the contents. Pass them
on to any future owner of the
appliance.
Correct application
~This rangehood is designed for
domestic use and for use in similar
environments by guests in hotel or
motel rooms, bed & breakfasts and
other typical living quarters. This does
not include common/shared facilities or
commercial facilities within hotels,
motels or bed & breakfasts.
~It must only be used as a domestic
appliance to extract vapours and
remove odours from cooking.
~Any other usage is not supported by
the manufacturer and could be
dangerous. Miele cannot be held liable
for damage resulting from incorrect or
improper use or operation of the
appliance.
~This appliance is not suitable for
outdoor use.
~This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience or knowledge, unless they
are supervised whilst using it or have
been been shown how to use it by a
person responsible for their safety.
~This appliance may only be used in
mobile installations if a risk assessment
of the installation has been carried out
by a suitably qualified engineer.
Safety with children
~This appliance is only intended for
use by adults who have read these
instructions.
~This appliance is not a toy! To avoid
the risk of injury, keep children well
away and do not allow them to play with
it or to use the controls. They will not
understand the potential dangers
posed by it. They should be supervised
whenever you are working in the
kitchen.
~Older children may use the
rangehood only when its operation has
been clearly explained to them and
they are able to use it safely,
recognising the dangers of misuse.
~Please be aware that on rangehood
with halogen lighting, the lamps will get
very hot during use and remain hot for
some time after switching off. To
safeguard against burning, keep
children well away from the lamps at all
times.
Warning and Safety instructions
4

Technical safety
~Before installation, check the
rangehood for visible signs of damage.
Under no circumstances should you
use a damaged appliance. A damaged
appliance is dangerous.
~Before connecting the appliance to
the mains supply, make sure that the
voltage and frequency details given on
the data plate correspond with the
on-site electricity supply, otherwise the
appliance could be damaged. Consult
a qualified electrician if in any doubt.
~The electrical safety of this
appliance can only be guaranteed
when continuity is complete between
the appliance and an effective earthing
system which complies with current
local and national safety regulations. It
is most important that this basic safety
requirement is present and tested
regularly and, where there is any doubt,
the household wiring system should be
inspected by a qualified electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
~For safety reasons, this appliance
may only be used when it has been
fully installed.
~Only open the housing as described
in the instructions given in the
installation sheet and in the Cleaning
and care section of this booklet. Under
no circumstances should any other
parts of the housing be opened.
Tampering with electrical connections
or components and mechanical parts is
highly dangerous to the user, and can
cause operational faults.
~Installation, maintenance and
repairs may only be carried out by a
Miele authorised person in accordance
with current national and local safety
regulations.
Repairs and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable for
unauthorised work.
~A damaged connection cable must
only be replaced by an approved and
suitably qualified technician.
~Faulty components must only be
replaced by genuine Miele original
parts. The manufacturer can only
guarantee the safety of the appliance
when Miele replacement parts are
used.
~During installation, maintenance and
repair work, the appliance must be
disconnected from the mains electricity
supply. It is only completely isolated
from the electricity supply when:
–it is switched off at the isolator, or
–the screw-out fuse is removed (in
countries where this is applicable), or
–the mains fuse is disconnected, or
–it is switched off at the wall socket
and the plug withdrawn.
Warning and Safety instructions
5

~Do not connect the appliance to the
mains electricity supply by a
multi-socket unit or an extension lead.
These do not guarantee the required
safety of the appliance (e.g. danger of
overheating).
~This rangehood must not be
installed and operated in mobile
installations (e.g. on a ship).
~In areas which may be subject to
infestation by cockroaches or other
vermin, pay particular attention to
keeping the appliance and its
surroundings in a clean condition at all
times. Any damage which may be
caused by cockroaches or other vermin
will not be covered by the warranty.
Using at the same time as other
heating appliances that depend on
the air from the room
Warning - danger of toxic fumes
~Great care should be taken when
using the rangehood at the same time
and in the same room or area of the
house as another heating appliance
which depends on the air in the room.
Such appliances include gas, oil, wood
or coal-fired boilers and heaters,
continuous flow or other water heaters,
gas cooktops or ovens which draw air
in from the room and duct exhaust
gases out through a chimney or
extraction ducting.
When used in extraction mode, the
appliance draws air in from the room in
which it is installed and from
neighbouring rooms.
If there is insufficient air, an
underpressure will occur. The heating
appliance may be starved of oxygen,
impairing combustion.
Harmful gases could be drawn out of
the chimney or extraction ducting back
into the room, with potentially fatal
consequences.
Warning and Safety instructions
6

In order to ensure safe operation, and
to prevent gases given off by the
heating appliances from being drawn
back into the room when the rangehood
and the heater are in operation
simultaneously, an underpressure of
0.04 mbar (4 pa) is the maximum
permissible in the room.
Ventilation can be maintained by air
inlets which must not be blocked, in
windows, doors and outside wall vents,
or by other technical measures, such
as ensuring that the rangehood can
only be switched on when the heating
appliance is switched off or vice versa.
A ventilation brick alone is not generally
sufficient to ensure safe ventilation.
,The overall ventilation condition
of the dwelling must be taken into
account. If in any doubt, the advice
of a competent builder or, for gas, a
qualified gas fitter must be sought.
If the rangehood is being operated in
recirculation mode, the above
restrictions do not apply.
Correct use
~Never use an open flame beneath
the rangehood. To avoid the danger of
fire, do not flambé or grill over an open
flame.
When switched on, the rangehood
could draw flames into the filter. Fat
particles drawn into the rangehood
present a fire hazard.
~When using the rangehood over a
gas cooktop, ensure that any burners in
use are always covered by a pan.
Switch the cooking zone off when a pan
is removed, even for a short time.
Regulate the flame so that it does not
burn up the sides of the pan.
Do not allow the pans to overheat
excessively (e.g. when using a wok).
The rangehood can become damaged
when exposed to excessive heat.
~Always switch the rangehood on
when a cooking zone is in use,
otherwise condensation may collect in
the hood, which could cause corrosion.
~When cooking with oil or fat, chip
pans and deep fat fryers etc., do not
leave the pans unattended. Never leave
an open grill unattended when grilling.
Overheated oil and fat can ignite and
could set the rangehood on fire.
If in any doubt , the advice of a
qualified builder, gas fitter or
electrician must be sought.
Warning and Safety instructions
7

~Do not use the rangehood without
the filters in place. This way you will
avoid the risk of grease and dirt getting
into the appliance and hindering its
smooth operation.
~The filters should be regularly
cleaned or changed as appropriate.
Saturated filters are a fire hazard. See
"Cleaning and care".
~The rangehood can get very hot
during cooking due to heat rising from
the cooktop.
Do not touch the housing or the grease
filters until the rangehood has cooled
down.
~Do not use a steam-cleaner to clean
this appliance. Steam could reach the
electrical components and cause a
short circuit.
Correct installation
~Refer to the cooktop manufacturer's
instructions as to whether a rangehood
may be operated above the cooktop.
~The minimum safety distances
between the top of the cooktop and the
bottom of the rangehood given in the
"Appliance dimensions" section of this
booklet must be maintained, unless the
cooktop manufacturer states that a
greater safety distance is required.
If more than one cooking appliance is
fitted beneath the rangehood, and they
have different minimum safety
distances to the rangehood, select the
greater distance.
~Safety regulations prohibit the fitting
of a rangehood over solid fuel stoves.
~All ducting, pipework and fittings
must be of non-flammable material.
These can be obtained from Miele or
from builders' merchants.
~The appliance must not be
connected to a chimney or vent flue
which is in use. Neither should it be
connected to ducting which ventilates
rooms with fireplaces.
~If exhaust air is to be extracted into
a chimney or ventilation duct no longer
used for other purposes, seek
professional advice.
Accessories
~Only use genuine Miele spare parts
and accessories with this appliance. If
spare parts or accessories from other
manufacturers are used, this will
invalidate the warranty, and Miele
cannot accept liability.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
8

The rangehood works with
. . . air extraction:
The air is drawn in, cleaned by the
grease filter and then directed outside.
If the on-site ventilation system does
not have a non-return flap, then the
non-return flap supplied with the
appliance must be fitted in the exhaust
socket in the motor unit.
Having a non-return flap fitted in the
ducting ensures that air, once ducted
to the outside, cannot get back into the
room again.
The flap is closed when the rangehood
is switched off.
When the rangehood is switched on,
the non-return flap opens for the
cooking vapours to be blown directly
outside.
Please note, the performance of
this rangehood hinges greatly on
the installed ducting to vent the
vapours. Poor choice of ducting
results in poor rangehood
performance. For ducting
recommendations, please refer to
the relevant section in these
operating instructions or contact
a specialised installer.
. . . air recirculation:
(requires a conversion kit and charcoal
filters: see "Technical Data")
The air is drawn in and cleaned first by
the grease filter and then by two
charcoal filters. The cleaned air is then
recirculated back into the kitchen.
Before using the rangehood in
recirculation mode, ensure that the
charcoal filters are in place. See
"Cleaning and care".
Modes of operation
9

aLighting switch
bFan switch
cCooktop lighting
dCharcoal filters
Special accessory for recirculation
mode
eGrease filter
Guide to the appliance
10

To switch the lighting on and
off
The cooktop lighting acan be
switched on and off independently of
the fan.
"0" - lighting off
"1" - lighting on
To switch the fan on
^Turn switch bfor the fan to "1".
To select a power level
You can select one of three power
levels with switch bdepending on how
much the air needs to be filtered.
Depending on the intensity of the
cooking vapours, levels "1" and "2" are
usually sufficient for normal cooking.
Intensive setting
For short periods of cooking food with
intensive vapours and a strong aroma,
e.g. when searing meat, you may wish
to select the Intensive Setting "IS".
After cooking
If the air still needs to be cleared after
cooking, we recommend letting the
rangehood continue to run for a further
ten minutes.
Then switch the appliance off.
Switching off
^Turn switch bfor the fan to "0".
Operation
11

Before any cleaning or maintenance
work is carried out, disconnect the
rangehood from the mains supply.
Ensure that:
– it is switched off at the isolator,
or – it is switched off at the wall
socket and the plug
removed, or – the mains fuse is
withdrawn, or
– the screw-out fuse is removed
(in countries where this is
applicable).
A range of Miele branded cleaning and
conditioning agents are available to
order through your Miele Chartered
Agent from Miele or via the internet on
www.miele-shop.com.
Housing
The surfaces and controls are
susceptible to scratches and
abrasions. Please observe the
following cleaning instructions.
^All external surfaces and controls can
be cleaned using the Original Miele
all purpose microfibre cloth, or with
warm water and a small amount of
washing-up liquid applied with a well
wrung-out soft sponge or cloth.
^Wipe the surfaces dry using a soft
cloth.
Do not use:
–cleaning agents containing soda,
acids, chlorides or solvents,
–abrasive cleaning agents, e.g.
powder cleaners or cream cleaners
and abrasive sponges, as well as pot
scourers or sponges which have
been used previously with abrasive
cleaning agents.
These will damage the surface
material.
Grease filter
The re-usable metal grease filter in the
appliance removes solid particles from
the kitchen vapours (grease, dust, etc.)
preventing soiling of the rangehood.
Clean the grease filter when it looks
dirty, and avoid letting it become so
dirty that the filtering effect is inefficient.
To avoid a build-up of fat, it should be
cleaned every 3-4 weeks on average,
but sooner if necessary.
,An oversaturated filter is a fire
hazard.
^To take out the grease filter, release
the locking clip on the filter, lower the
filter 45°, unhook it at the back and
remove it.
Cleaning and care
12

To avoid damaging the filter or the
cooktop below, make sure you hold
the filter securely at all times when
handling it.
Cleaning the grease filter by hand
^Clean the filter with a soft nylon brush
in a mild solution of hot water and a
small amount of washing-up liquid.
Do not use undiluted washing-up liquid.
Do not use:
–cleaning agents containing
descaling agents,
– powder cleaners, cream cleaners or
abrasive all-purpose cleaning agents,
– oven sprays.
Cleaning the grease filter in the
dishwasher
^Place the filters as upright as
possible in the lower basket. Ensure
the spray arm is not obstructed.
^Do not wash at more than 65 °C. If a
Miele dishwasher is being used,
select the Sensor wash programme.
^Use a mild dishwasher detergent.
Depending on the cleaning agent
used, cleaning the filters in a
dishwasher can cause permanent
discolouration to the surface.
However, this will not affect the
functioning of the filters in any way.
^After cleaning, leave the filter to dry
for a while on an absorbent surface
before putting it back in place.
^When removing the filter for cleaning,
also clean off any residues of oil or
fat from the now accessible housing
to prevent the risk of these catching
fire.
When putting the grease filter back in
position, ensure that the locking clip is
visible facing down towards the
cooktop.
^If the grease filter is inadvertently
replaced upside down, insert a small
screwdriver blade into the slit to
disengage the clip.
Cleaning and care
13

Fitting and replacing the
charcoal filters
If the rangehood is connected for
recirculation, two charcoal filters must
be inserted in addition to the grease
filter. They are designed to absorb
cooking odours and are fitted in the
canopy above the grease filter.
New filters can be purchased from
your Miele Chartered Agent or from
Miele. See back cover for contact
details, and "Technical data" for the
model number of the filter.
^Before fitting or replacing the active
charcoal filters, the grease filter must
first be taken out, (see previous
section for instructions on how to do
this).
^Unwrap the charcoal filters.
^Insert the charcoal filters into the
canopy.
^Replace the grease filter.
Replace the charcoal filters when they
no longer absorb kitchen odours
effectively.
They should, however, be replaced at
least every 6 months.
Used charcoal filters can be disposed
of with the normal household waste.
Cleaning and care
14

Changing a halogen lamp
Before any cleaning or maintenance
work is carried out, disconnect the
rangehood from the mains supply.
Ensure that:
– it is switched off at the isolator,
or – it is switched off at the wall
socket and the plug removed,
or
– the mains fuse is withdrawn, or
– the screw-out fuse is removed
(in countries where this is
applicable).
^Remove the grease filter.
^Remove the charcoal filters if the
rangehood is being used in
recirculation mode.
,Exercise caution when changing
halogen lamps. They get very hot
during use, and remain hot for some
time after being switched off.
Do not touch the surface directly
when changing a lamp, as grease
particles from your fingers will
adhere to the surface and damage
it. Please follow the manufacturer's
instructions.
^Push down the lighting unit slightly
via the opening in the safety panel.
^The halogen lamp is now accessible
and should be unscrewed
anti-clockwise.
^Replace it with a new halogen lamp
(specification: GU/GZ 10, 230 V,
50 W). Screw the lamp into the
socket and push it upwards.
Please follow the manufacturer's
instructions.
We recommend only using lamps of the
same specification and also made by
the same manufacturer as the ones
being replaced.
^Replace the grease filter and, if being
used in recirculation mode, the
charcoal filters.
Cleaning and care
15

*Cut-out dimensions
A depth Tof at least 25 mm must be
provided at the back of the building-in
niche.
Safety distances between cooktop
and rangehood (S)
The minimum safety distances
between the top of a cooktop and
the bottom of the rangehood are
as follows, unless a greater
distance is specified by the
manufacturer of your cooking
appliance:
Cooking appliance Distance
S
Electric cooktop 600 mm
Open electric grill 650 mm
Deep fat fryer (electric) 650 mm
Multi-burner gas cooktop
with maximum 45.4 MJ/h
total output, with no burner
having a greater output
than 16.2 MJ/h.
650 mm
Multi-burner gas cooktop
with total output greater
than 45.4 MJ/h, or a gas
cooktop including a single
burner with an output
greater than 16.2 MJ/h.
760 mm
Single gas cooktop with a
maximum output of
21.6 MJ/h
650 mm
Single gas cooktop with a
maximum output greater
than 21.6 MJ/h
760 mm
See "Warning and Safety"
instructions for further information.
Appliance dimensions
16

–When deciding on the safety
distance between the cooktop and
rangehood, please note that a
distance of 650 mm above electric
cooktops may be preferable to give
more working space under the hood.
–Account should also be taken of the
height of the person who will be
using the hood most often. The
person should have sufficient space
to work comfortably at the cooktop,
and also be able to reach the
rangehood controls with ease.
–Please be aware that if positioned
too high, extraction will be inefficient.
Appliance dimensions
17

Fitting the non-return flap
(Air extraction mode only)
^If a non-return flap is not present in
the venting system, the non-return
flap supplied must be fitted onto the
exhaust socket in the motor unit. The
flaps must open upwards.
Building in
The rangehood is intended to be built
into wall units, rangehood housing
units, and above breakfast bars or
island areas.
Check prior to installation that the top of
the appliance will be accessible after
installation.
If this is not the case, install the exhaust
ducting and prepare the electrical
connection before installation.
^Place the appliance in the cut-out
from below and align it.
^Secure the rangehood by the frame
using 3.5 x 16 mm screws.
^Before using the appliance for the
first time, take the grease filters out
and remove the protective foil from
the filter frame. Then replace the
grease filters.
Installation
18

Preparation for extraction
^When using C150 mm ducting,
secure the exhaust connection
supplied to exhaust ducting with
hose clips.
^Place the exhaust ducting on the fan
connection for the rangehood.
^See "Connection for air extraction" for
further instructions on fitting the
ducting.
Recirculation
If site conditions are not suitable for the
rangehood to be used with air
extraction, the appliance must be set
up for recirculation.
For this, conversion kit DUU 151
(available from Miele Chartered Agent
or Miele) is required.
You will also need two charcoal filters
(see “Technical data”).
Installation
19

^Dismantle the non-return flap.
^Take the on-site conditions into
account when fitting the conversion
kit.
When fitting the exhaust grille, make
sure that the slats in the grille point
towards the centre of the room and
not directly towards a wall or the
ceiling.
^Fit the charcoal filters.
Electrical connection
Before connecting the appliance,
read the safety notes in "Warning
and Safety instructions" and
"Electrical connection".
Installation
20
