Miele SmartLine CSDA 7000 FL User manual

Operating and installation instructions
SmartLine downdraft extractor
To prevent the risk of accidents or damage to the appliance, it is
essential to read these instructions before it is installed and used for
the first time.
en-AU, NZ M.-Nr. 11 037 890

Contents
2
Warning and Safety instructions.......................................................................... 4
Caring for the environment ................................................................................ 14
Overview............................................................................................................... 15
Downdraft extractor............................................................................................... 15
Controls / Indicators.............................................................................................. 16
Cleaning the SmartLine appliance for the first time ........................................ 17
Description of the functions............................................................................... 18
Tips on saving energy ........................................................................................ 19
Operation.............................................................................................................. 20
FlameGuard........................................................................................................... 20
Switching the downdraft extractor on ................................................................... 20
Setting/Changing the power level ......................................................................... 20
Switching the downdraft extractor off ................................................................... 20
Run-on time........................................................................................................... 21
Cleaning and care ............................................................................................... 22
Ceramic surface .................................................................................................... 23
Moisture collection tray ......................................................................................... 23
Grease filter ........................................................................................................... 24
Problem solving guide ........................................................................................ 25
Optional accessories .......................................................................................... 26
Safety instructions for installation..................................................................... 27
Installation notes ................................................................................................. 28
Installation of surface-mounted appliances .......................................................... 28
Flush-fit installation ............................................................................................... 29
Installing several SmartLine appliances ................................................................ 30
Minimum plinth height........................................................................................... 30
Worktop depth....................................................................................................... 30
Installation examples............................................................................................. 31
Building-in dimensions ....................................................................................... 32
Installation of surface-mounted cooktops ............................................................ 32
Flush-fit installation ............................................................................................... 33
Worktop cut-out for surface-mounted installation .......................................... 34
Surface-mounted installation............................................................................. 37

Contents
3
Worktop cut-out for flush-fit installation........................................................... 38
Flush-fit installation............................................................................................. 41
Spacer bars.......................................................................................................... 42
Installation............................................................................................................ 44
Preparing the worktop........................................................................................... 44
Fitting the spacer bars .......................................................................................... 45
Installing the downdraft extractor.......................................................................... 46
E-box..................................................................................................................... 47
Connection for air extraction ............................................................................. 50
Electrical connection .......................................................................................... 52
Service.................................................................................................................. 54
Contact in case of fault ......................................................................................... 54
Data plate .............................................................................................................. 54
Warranty ................................................................................................................ 54

Warning and Safety instructions
4
This downdraft extractor complies with current local and national
safety requirements. Inappropriate use can, however, lead to
personal injury and damage to property.
To avoid the risk of accidents and damage to the appliance, please
read these instructions carefully before using it for the first time.
They contain important notes on the safety, installation, use and
maintenance of the appliance. Miele cannot be held liable for non-
compliance with these instructions.
Keep these instructions in a safe place and ensure that all users
are familiar with the contents. Pass them on to any future owner of
the appliance.
For safe operation, please also refer to the operating and
installation instructions for the SmartLine appliances and cooktops
installed adjacent to the downdraft extractor.

Warning and Safety instructions
5
Correct application
 This downdraft extractor is designed for domestic use and for use
in similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
 The downdraft extractor is not suitable for outdoor use.
 The downdraft extractor must only be used to extract vapours and
remove odours from cooking.
Any other usage is at the owner's risk. Miele cannot be held liable for
damage resulting from incorrect or improper use or operation.
 This downdraft extractor is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they are
supervised whilst using it or have been given instruction concerning
its use by a person responsible for their safety.
They must be able to recognise the dangers of misuse.

Warning and Safety instructions
6
Safety with children
 Young children must be kept away from the downdraft extractor.
 Older children may only use the downdraft extractor without
supervision if they have been shown how to use it in a safe manner.
They must be aware of the potential dangers caused by incorrect
operation.
 Cleaning work may only be carried out by older children under the
supervision of an adult.
 Please supervise children in the vicinity of the downdraft extractor
and do not let them play with it.
 Danger of suffocation!
Whilst playing, children may become entangled in packaging
material (such as plastic wrapping) or pull it over their head with the
risk of suffocation. Keep packaging material away from children.

Warning and Safety instructions
7
Technical safety
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and
repairs must only be carried out by a Miele authorised technician.
 The downdraft extractor must only be installed and operated in
combination with those SmartLine appliances and cooktops
specified by Miele.
 A damaged appliance is dangerous. Check it for any visible
damage. Never install or attempt to use a damaged appliance.
 Reliable and safe operation of this downdraft extractor can only
be assured if it has been connected to the mains electricity supply.
 The downdraft extractor must not be connected to the inverter of
an autonomous power supply, e.g. a solar power system. When the
downdraft extractor is switched on, power surges could result in a
safety switch-off. This may damage the electronic unit.
 The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is most important that this basic safety requirement is
present and tested regularly and, where there is any doubt, the
household wiring system should be inspected by a qualified
electrician.
 Before connecting the appliance to the mains electricity supply,
make sure that the rating on the data plate (voltage and frequency)
corresponds to that of the household supply.
This data must correspond in order to avoid risk of damage to the
appliance. Consult a qualified electrician if in any doubt.
 Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (fire hazard). Do not use these to
connect the downdraft extractor to the mains electricity supply.
 For safety reasons, this downdraft extractor may only be used
after it has been built in.

Warning and Safety instructions
8
 This downdraft extractor must not be installed and operated in
mobile installations (e.g. on a ship).
 Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.
Only open the housing as described in the installation instructions
and in the Cleaning and care section of this booklet. Under no
circumstances should any other parts of the housing be opened.
 The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele approved service technician.
 Faulty components must only be replaced by genuine Miele spare
parts. The manufacturer can only guarantee the safety of the
appliance when Miele replacement parts are used.
 The downdraft extractor is not intended for use with an external
timer switch or a remote control system.
 If the plug is removed from the connection cable or if the cable is
supplied without a plug, the downdraft extractor must be connected
to the mains electricity supply by a suitably qualified electrician.
 If the mains connection cable is damaged, it must be replaced
with a special connection cable type H 05 VV-F (PVC insulated),
available from Miele, by a Miele authorised service technician or
suitably qualified and competent electrician in order to avoid a
hazard (see “Electrical connection”).

Warning and Safety instructions
9
 During installation, maintenance and repair work, the downdraft
extractor must be completely disconnected from the mains
electricity supply. It is only completely isolated from the electricity
supply when:
– the mains circuit breaker is switched off, or
– the screw-out fuse is removed (in countries where this is
applicable), or
– it is switched off at the wall socket and the plug is withdrawn from
the socket. Do not pull the mains connection cable but the mains
plug to disconnect your appliance from the mains electricity
supply.

Warning and Safety instructions
10
Using at the same time as other heating appliances that depend on the air
from the room
Warning - danger of toxic fumes!
Great care should be taken when using the downdraft extractor at
the same time and in the same room or area of the house as
another heating appliance which depends on the air in the room.
Such appliances include gas, oil, wood or coal-fired boilers and
heaters, continuous flow or other water heaters, gas cooktops, or
ovens which draw air in from the room and duct exhaust gases out
through a chimney or extraction ducting.
When used in extraction mode, with or without an external motor
fitted, or in recirculation mode with a recirculation box installed
outside the room, the downdraft extractor draws air in from the
room in which it is installed and from neighbouring rooms.
If there is insufficient air, an underpressure will occur. The heating
appliance will be starved of oxygen, impairing combustion.
Harmful gases could be drawn out of the chimney or extraction
ducting back into the room, with potentially fatal consequences.

Warning and Safety instructions
11
In order to ensure safe operation, and to prevent gases given off
by the heating appliances from being drawn back into the room
when the downdraft extractor and the heater are in operation
simultaneously, an underpressure in the room of 0.04 mbar (4 pa)
is the maximum permissible.
Ventilation can be maintained by air inlets which cannot be
blocked, in windows, doors or outside wall vents, or by other
technical measures, such as ensuring that the downdraft extractor
can only be switched on when the heating appliance is switched
off or vice versa. A ventilation brick alone is not generally sufficient
to ensure safe ventilation.
The overall ventilation condition of the dwelling must be taken into
account. If in any doubt, the advice of a competent builder or, for
gas, a qualified gas fitter (registered with an official gas safety
body in accordance with national safety regulations) must be
sought.
If the downdraft extractor is used in recirculation mode, where the
air is directed back into the room in which it is located, operating a
heating appliance which depends on the room air at the same time
is not hazardous.

Warning and Safety instructions
12
Correct use
 Never use an open flame beside the downdraft extractor. To avoid
the danger of fire, do not flambé or grill over an open flame.
When switched on, the downdraft extractor could draw flames into
the filter. Fat deposits could ignite, presenting a fire hazard.
 Overheated oil and fat can ignite, causing fire damage to the
downdraft extractor.
When cooking with oil or fat, chip pans and deep fat fryers etc., do
not leave the pans unattended. Similarly, never leave an open grill
unattended when grilling.
 Do not use the downdraft extractor without the filter in place. This
way you will avoid the risk of grease and dirt getting into the
appliance and hindering its smooth operation.
 The downdraft extractor can get very hot during cooking due to
the heat from the cooktop.
Do not touch the housing or the grease filter until the downdraft
extractor has cooled down.
 Do not use the downdraft extractor for resting objects on.
 Keep liquids away from the downdraft extractor.
Liquids can damage the extractor if they get into it.
 Light objects can be drawn into the downdraft extractor and
impair its operation.
Do not place any light objects (e.g. paper towels) within close
proximity of the downdraft extractor.
 If you are operating a gas cooking appliance directly next to the
downdraft extractor, the FlameGuard must be placed between the
downdraft extractor and the appliance.

Warning and Safety instructions
13
Cleaning and care
 The steam from a steam cleaning appliance could reach electrical
components and cause a short circuit.
Do not use a steam cleaner to clean the downdraft extractor.
 There is a risk of fire if cleaning is not carried out as described in
these operating instructions.
Accessories
 Use only genuine original Miele spare parts. If spare parts or
accessories from other manufacturers are used, the warranty will be
invalidated, and Miele cannot accept liability.

Caring for the environment
14
Disposal of the packing
material
The transport and protective packaging
has been selected from materials which
are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances. You are also responsible for
deleting any personal data that may be
stored on the appliance prior to
disposal. Please ensure that your old
appliance poses no risk to children
while being stored prior to disposal.

Overview
15
Downdraft extractor
aFlameGuard
bGrease filter
cMain unit with controls
dCasing
eMoisture collection tray
fAir duct
gFan
hE-box

Overview
16
Controls / Indicators
aFor switching the downdraft extractor on/off
bNumerical keybank for setting the power level

Cleaning the SmartLine appliance for the first time
17
Please stick the extra data plate for
the appliance supplied with this
documentation in the space provided
in the “Service” section of this
booklet. Alternatively, the additional
label can be stuck near the appliance
if the appliance markings are not
visible after installation.
Remove any protective wrapping and
stickers (except the data plate).
Clean the ceramic surface with a
damp cloth, and then wipe dry.

Description of the functions
18
Depending on the model of the
downdraft extractor, the following
options are available:
Air extraction mode
The air is drawn in and cleaned by the
grease filter and directed outside.
Recirculation mode
(DUU 1000(-1) conversion kit required)
The air is drawn in and cleaned by the
grease filter. The air is then directed into
the recirculation box where it is also
cleaned by the charcoal filter. The
cleaned air is then recirculated back
into the kitchen.

Tips on saving energy
19
This downdraft extractor operates very
efficiently and economically. The
following will help you to save even
more energy when using it:
– It is important to ensure that the
kitchen is well ventilated during
operation. In extraction mode if there
is insufficient air flow, the downdraft
extractor cannot operate efficiently
and this causes increased operating
noise levels.
– Always cook with the lowest possible
cooking setting. This produces fewer
cooking vapours, so you can use a
lower extractor power level and
therefore benefit from reduced energy
consumption.
– Check the selected power level on
the downdraft extractor. A low power
level is usually sufficient. Only use the
Booster setting when necessary.
– When a large volume of cooking
vapours are being produced, switch
to a high power level in good time.
This is more efficient than operating
the downdraft extractor for longer to
try to capture cooking vapours which
have already been distributed
throughout the kitchen.
– Switch the downdraft extractor off
after cooking.
– Clean or replace the filters at regular
intervals. Heavily soiled filters reduce
performance, increase the risk of fire
and are unhygienic.

Operation
20
FlameGuard
Fit the magnetic FlameGuard in
position next to the downdraft
extractor when you are operating a
gas cooktop or a gas wok burner
directly next to the extractor.
Switching the downdraft
extractor on
The downdraft extractor must only be
operated when the FlameGuard has
been removed from completely
covering the extractor.
Remove the FlameGuard.
Touch the  sensor.
The sensor controls will light up.
If no further entry is made, the
downdraft extractor will switch itself
off after a few seconds.
Setting/Changing the power
level
For light to heavy cooking vapours and
odours, select from power levels 1 to 3.
For short periods of cooking food with
intensive vapours and a strong aroma,
e.g. when searing meat, select Booster
settingB.
Touch the required power level.
Booster
The maximum duration for the Booster
is 10minutes.
To switch the Booster off early, set a
different power level.
Switching the downdraft
extractor off
Touch the  sensor.
The sensor controls go out.
If the downdraft extractor is not
switched off, it will switch itself off
12hours after the last automatic
operation.
