Miele PWM 514 User manual

Operating and installation Instructions
Commercial Washing Machine
PWM 514
PWM 520
To avoid the risk of accidents or damage to the
appliance, it is essential to read these
instructions before it is installed and used for the
first time.
en-AU, NZ
M.-Nr. 11 874 800

Caring for the environment
2
Disposal of the packing material
The packaging is designed to protect the washing machine from
damage during transportation. The packaging materials used are
selected from materials which are environmentally friendly for
disposal and should be recycled.
Recycling the packaging reduces the use of raw materials in the
manufacturing process and also reduces the amount of waste in
landfill sites. Ensure that any plastic wrappings, bags etc. are
disposed of safely and kept out of the reach of babies and young
children. Danger of suffocation!
Disposing of your old appliance
Electrical and electronic appliances often contain valuable materials.
However, they also contain harmful substances which were essential
for their correct functioning and safety. These could be hazardous to
human health and to the environment if disposed of with general
waste or if handled incorrectly. Please do not, therefore, dispose of
your old appliance with general waste.
Please dispose of it at your local community waste collection /
recycling centre for electrical and electronic appliances. Consult with
Miele if necessary.
Please ensure that your old appliance presents no danger to children
while being stored awaiting disposal.
Energy saving tips
Energy and water
consumption
- To get the most out of your machine, load the maximum dry load
for the programme you are using.
The most efficient use of energy and water is achieved when a full
load is washed.
Detergent - Do not exceed the amounts of detergent recommended by the
manufacturer on the packaging.
- Reduce the amount of detergent for smaller loads.
When drying with
a tumble dryer
Selecting the highest possible spin speed for the wash programme
will save energy when drying in a tumble dryer afterwards.

Contents
3
Caring for the environment ............................................................................................ 2
Warning and Safety instructions.................................................................................... 6
Correct application............................................................................................................ 7
Preventing problems ......................................................................................................... 8
Technical safety................................................................................................................. 9
Correct use........................................................................................................................ 11
Chlorine and component damage..................................................................................... 13
Anti-chlorine treatment.................................................................................................. 13
Accessories ....................................................................................................................... 14
Disposing of your old appliance.................................................................................... 14
Guide to the machine (with detergent dispensing drawer) ......................................... 15
Models with detergent dispenser drawer (WEK) ............................................................... 15
Models without detergent dispensing drawer (WEK) ........................................................ 16
Operation.......................................................................................................................... 17
Control panel..................................................................................................................... 17
Sensors and touch display with sensors........................................................................... 17
Main menu......................................................................................................................... 18
Examples on how to operate the appliance ...................................................................... 18
Operating the launderette version ..................................................................................... 20
Preparing for use............................................................................................................. 22
Emptying pockets ............................................................................................................. 22
Max. load........................................................................................................................... 22
Loading the washing machine........................................................................................... 23
Preparing for use............................................................................................................. 24
4. Selecting programme settings................................................................................... 26
Washing with dispensing drawer................................................................................... 27
Adding detergent using the detergent dispensing drawer. ............................................... 27
Bleaching agent................................................................................................................. 28
Dyes, dye removers and descaling agents ....................................................................... 28
Detergent dispensing ........................................................................................................ 28
Detergent dispensing .................................................................................................... 28
Amount of detergent ..................................................................................................... 28
Water hardness levels ................................................................................................... 28
6. Starting the programme - the end of the programme ............................................. 30
Timer................................................................................................................................. 31
Problem solving guide .................................................................................................... 32
After sales service ............................................................................................................. 34
Problem solving guide .................................................................................................... 35
Problem solving guide ....................................................................................................... 35
The programme does not start.......................................................................................... 35
An unsatisfactory wash result ........................................................................................... 36
General problems with the washing machine ................................................................... 37
Possible reasons for increased levels of foaming ............................................................. 38
Large items stretched........................................................................................................ 38
Continuing a programme after an interruption to the power supply ................................. 38

Contents
4
Cleaning and care ........................................................................................................... 39
Build-up of rust.................................................................................................................. 39
Cleaning the detergent drawers, detergent compartments and siphons.......................... 40
Installation........................................................................................................................ 42
Installing the washing machine ......................................................................................... 42
Securing the machine........................................................................................................ 42
General operating conditions ............................................................................................ 42
For easy maintenance ....................................................................................................... 43
Installation on a raised plinth............................................................................................. 43
Transport safety devices ................................................................................................... 44
Removing the transport safety devices............................................................................. 44
Water connection .............................................................................................................. 45
Dispensing agent connection to the liquid dispensing mixing compartment ................... 46
Drainage ............................................................................................................................ 47
Electrical connection ......................................................................................................... 47
Extra options.................................................................................................................... 48
Pre-wash..................................................................................................................... 48
Pre-rinse...................................................................................................................... 48
Rinse plus................................................................................................................... 48
Soak............................................................................................................................ 48
Intensive....................................................................................................................... 48
Water plus ................................................................................................................... 48
Rinse hold................................................................................................................... 48
Fill stop........................................................................................................................ 48
Special features in the programme sequence.............................................................. 49
Spinning ............................................................................................................................ 49
Omitting the final spin (Rinse hold)................................................................................ 49
Anti-crease .................................................................................................................... 49
Changing the programme sequence ............................................................................. 50
Changing a programme..................................................................................................... 50
Altering the wash programme ....................................................................................... 50
Cancelling a programme ................................................................................................... 50
Switching on the washing machine after an interruption to the power supply ................. 50
Adding or removing laundry .............................................................................................. 51
Supervisor level ............................................................................................................... 52
Opening the Supervisor level ............................................................................................ 52
Code-based access .......................................................................................................... 52
Changing the code............................................................................................................ 52
Closing the settings menu................................................................................................. 52

Contents
5
Operation/display .............................................................................................................. 53
Language....................................................................................................................... 53
Language menu............................................................................................................. 53
Set languages................................................................................................................ 53
Display brightness......................................................................................................... 53
Time............................................................................................................................... 54
Date ............................................................................................................................... 54
Volume........................................................................................................................... 54
Visibility parameters ...................................................................................................... 54
Sorting Extras................................................................................................................ 54
“Machine” off status...................................................................................................... 54
Delay start ..................................................................................................................... 55
Memory ......................................................................................................................... 55
Temperature unit............................................................................................................ 55
Weight unit .................................................................................................................... 55
Programme selection ........................................................................................................ 56
Controls......................................................................................................................... 56
Programme packages ................................................................................................... 57
Sort programmes .......................................................................................................... 57
Prog. colour allocation .................................................................................................. 57
Hygiene ......................................................................................................................... 57
Expert code ................................................................................................................... 57
Process technology........................................................................................................... 58
Anti-crease .................................................................................................................... 58
Service interval .............................................................................................................. 58
Water intake .................................................................................................................. 59
Legal information........................................................................................................... 59
Technical data.................................................................................................................. 60
PWM514 machine data.................................................................................................... 60
Electrical connection ..................................................................................................... 60
Installation dimensions.................................................................................................. 60
Weight and floor load .................................................................................................... 60
Emissions data .............................................................................................................. 60
Product safety ............................................................................................................... 60
Wi-Fi .............................................................................................................................. 60
PWM520 machine data.................................................................................................... 61
Electrical connection ..................................................................................................... 61
Installation dimensions.................................................................................................. 61
Weight and floor load .................................................................................................... 61
Emissions data .............................................................................................................. 61
Product safety ............................................................................................................... 61
Wi-Fi .............................................................................................................................. 61
Wi-Fi data protection ...................................................................................................... 62
Data protection and data security..................................................................................... 62
Factory default settings for network configuration............................................................ 62
Copyright and licenses...................................................................................................... 62

Warning and Safety instructions
6
This washing machine complies with all current local and national
safety requirements. However, inappropriate use can lead to
personal injury and damage to property.
Read the operating instructions carefully before using the washing
machine. They contain important information on safety, installation,
use and maintenance of the appliance. This prevents both personal
injury and damage to the washing machine.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in
“Installation”, as well as in the “Warning and Safety instructions”.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating instructions in a safe place and pass them on
to any future owner.
When instructing other people how to use the washing machine,
they must be made aware of these Warning and Safety instructions.

Warning and Safety instructions
7
Correct application
 The washing machine is only suitable for washing fabrics with a
care label stating that they are suitable for machine washing. Any
other applications may be dangerous. The manufacturer cannot be
held liable for damage resulting from incorrect or improper use or
operation of the machine.
 This washing machine must be used as described in the operating
instructions and must be checked on a regular basis to make sure it
is functioning correctly. Maintenance must be carried out when
necessary.
 The washing machine is not suitable for outdoor use.
 Do not install your washing machine in a room where there is a risk
of frost. Frozen hoses can tear or burst. The reliability of the electronic
control unit may be impaired at temperatures below freezing point.
 The washing machine is designed for commercial use only.
 If the machine is used in a commercial environment, it may only be
operated by instructed/trained personnel. If the machine is to be
operated in an area accessible to the public, the supervisor must
ensure that it can be operated safely without risk of danger to others.
 The machine must not be installed and operated in mobile
locations (e.g. on a ship).
 This washing machine is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning its use by a person responsible
for their safety.
 Young children must not be allowed to use this appliance.
 Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely. They
must be able to understand and recognise the possible dangers of
misuse.
 Cleaning work may only be carried out by older children under the
supervision of an adult.
 Always supervise any children in the vicinity of the washing
machine. Never allow children to play with the washing machine.
 Disinfection programmes must not be interrupted, as this can have
a limiting effect on the disinfection result. It is the operator's
responsibility to ensure that the standard of disinfection in thermal as
well as chemo-thermal procedures is maintained by carrying out
suitable validation tests.

Warning and Safety instructions
8
Preventing problems
 Never use solvent-based detergents, e.g. those containing
benzine, in this washing machine. This may result in damage to
component parts and create toxic fumes. Risk of fire and explosion!
 When washing with high temperatures, remember that the porthole
glass becomes hot. Therefore, prevent children from touching the
porthole glass during the wash process.
Danger of burning!
 Close the drum door after each wash programme. This is to avoid
the risk of children trying to climb into the washing machine or hiding
things in it, and animals getting into the machine.
 Do not damage, remove or bypass the safety components or
control elements of the washing machine.
 Machines with a damaged control panel or damage to wire
insulation must not be used until they have been repaired.
 If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualified person in order to
avoid a hazard.
 The water generated during washing is suds solution and not
drinking water. Drain the suds solution into an appropriate sewage
system.
 Always make sure that the drum is stationary before reaching in to
remove laundry. Reaching into a moving drum is extremely
dangerous. Danger of injury!
 Be careful not to put your hands in the gap between door and
frame when closing the drum door.
Caution! The drum door is locked automatically as soon as the
machine starts.
 It is particularly important to observe manufacturer's instructions
when using a combination of cleaning agents and special application
products. Products must only be used for applications approved by
the manufacturer to avoid any material damage or the occurrence of
strong chemical reactions.

Warning and Safety instructions
9
Technical safety
 Before installing and operating the washing machine, check it for
any visible exterior damage. Do not install or operate a damaged
washing machine.
 The electrical safety of this washing machine can only be
guaranteed when continuity is complete between it and an effective
earthing system which complies with current local and national safety
regulations. It is most important that this basic safety requirement is
present and regularly tested and, where there is any doubt, the on-
site wiring system should be inspected by a qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
 Unauthorised repairs could result in unforeseen dangers for the
user, for which the manufacturer cannot accept liability. Repairs
should only be carried out by a Miele approved service technician,
otherwise any subsequent damage will not be covered by the
warranty.
 Do not make any alterations to the machine, unless authorised to
do so by Miele.
 The washing machine must be disconnected from the mains
electricity supply before any maintenance, cleaning or repair work is
carried out. The washing machine is only isolated from the electricity
supply when
- it is switched off at the wall socket and the plug is withdrawn, or
- the mains fuse is disconnected, or
- the circuit breaker has been tripped and locked out where
appropriate.
See “Installation and connection - Electrical connection”.
 The washing machine may only be connected to the water supply
using the new hose set supplied with the machine. Old hoses must
not be re-used. Check the hoses regularly for signs of wear. Change
the hoses in good time to avoid the risk of leaks and water damage.
The water flow pressure must be at least 100 kPa and must not
exceed 1000 kPa.
 If leakages occur, remedy their cause before operating the washing
machine again. Immediately disconnect the washing machine from
the electricity supply when leaking occurs.
 In case of malfunctions of the steam heater, temperatures in the
area of the drum door, the front of the detergent dispensing drawer
and the inside of the drum (especially the drum edge) may be
elevated. There is a risk of minor burns.
This only applies to appliances with steam heating.

Warning and Safety instructions
10
 Faulty components must only be replaced by genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the machine when Miele replacement parts are used.
 Please observe the instructions in “Installation and connection”
and “Technical data”.
 The plug of the washing machine (if fitted) must be accessible at all
times to ensure that the washing machine can be disconnected from
the electricity supply at any time.
 If the machine is hard wired, an all-pole isolator must be installed.
The means for disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules, AS/NZS 3000.
 If the washing machine is hard wired, provision must be made on
site to switch off all poles from the electricity supply. The
disconnection switch must be located in the immediate area around
the washing machine, and must always be visible, accessible and
easily reachable.
 For washing machine versions without a separate emergency stop
switch, there must be a central emergency stop mechanism at the
place of installation.

Warning and Safety instructions
11
Correct use
 The maximum dry laundry weight for the PW514 is 14kg, and for
the PW520 it is 20kg. See the "Programme chart" for the maximum
recommended loads for individual programmes.
 Before using the machine for the first time, ensure that the transit
bars have been removed (see "Installation - Removing the transit
bars"). During spinning, transit bars which are still in place can cause
damage to both the machine and adjacent furniture or appliances.
 Never try to open the drum door of the washing machine using
force. The drum door can only be opened if appropriate information is
shown in the display.
 Do not push back the soft mount drum of the machine while the
machine is running.
 When closing the drum door there is a risk of injury between the
door frame and drum opening, as well as at the hinges.
Caution! The drum door is locked automatically when the machine is
started.
 Turn off the tap if the machine is to be left for any length of time
(e.g. while on holiday), especially if there is no floor drain (gully) in the
immediate vicinity.
 Take care to ensure that foreign objects (e.g. nails, pins, coins,
paper clips) do not find their way into the machine with the laundry.
These may damage components of the machine (e.g. suds container,
drum). Damaged components can, in turn, result in damage to the
laundry.
 If the correct amount of detergent is dispensed, the washing
machine should not need to be descaled. If, however, you do wish to
descale your washing machine, only use proprietary non-corrosive
descaling agents and strictly observe the instructions on the
packaging. Special descaling agent is available from Miele. Strictly
observe the instructions for the descaling agent.
 Fabrics that have been pre-treated in solvent-based cleaning
agents must be thoroughly rinsed in clean water before being placed
in the machine. Note that solvent residues may only be discharged
into waste water in compliance with local legislation.
 Never use solvent based cleaning agents, e.g. those containing
benzine, in this washing machine. This may result in damage to
component parts and create toxic fumes. Risk of fire and explosion!
 Gasoline, petrol, paraffin, or any easily flammable liquid must not
be stored or used near the washing machine. Do not use the machine
lid as storage space.
Risk of fire and explosion!

Warning and Safety instructions
12
 Do not store chemicals (liquid detergents, additives) on the
machine lid. They may cause discolouration or lacquer damage.
Accidently spilled chemicals should be removed from the surface
immediately with a wet cloth.
 A vent outlet is situated at the rear of the machine. It should never
be closed or covered. Observe the minimum distance in the
installation plan.
 Only use dyes, dye removers, and descaling agents suitable for
use in a washing machine. The manufacturer's instructions on the
packaging must be observed.
 Dye removers contain sulphur compounds which can cause
damage such as corrosion. Dye removers must not be used in the
washing machine.
 Avoid contact of stainless steel surfaces with cleaning and
disinfecting agents containing liquid chlorine or sodium hypochlorite.
These agents can cause corrosion on stainless steel. Aggressive
chlorine bleach vapour can also cause corrosion. Do not store open
containers of these agents near the appliance.
 Do not use a pressure washer or hose to clean the washing
machine.

Warning and Safety instructions
13
Chlorine and component damage
 Frequent use of chlorine products increases the risk of damage to
components.
 The use of substances containing chlorine, such as sodium
hypochlorite and chlorine bleach in powder form, can however result
in damage to the protective layer of stainless steel and corrosion on
components. Therefore, refrain from using agents containing chlorine.
Use oxygen-based bleaching agents instead.
If, however, chlorine bleaching agents are used, an anti-chlorine
treatment must always be carried out. Otherwise, the washing
machine components and the load may suffer lasting and irreparable
damage.
Anti-chlorine
treatment
Anti-chlorine treatment must be carried out immediately after chlorine
bleach has been used. Hydrogen peroxide and oxygen-based
detergents and bleaching agents are suitable for anti-chlorine
treatment. The suds must not be drained in between.
Treatments with thiosulphates can result in gypsum-like deposits,
particularly in combination with hard water. This gypsum can build up
in the washing machine or cause incrustations on the laundry.
Treatment with hydrogen peroxide is recommended over treatment
with thiosulphates because hydrogen peroxide neutralises chlorine.
The exact dispensing quantities and the treatment temperatures
required must be set and tested on site in accordance with the
dispensing recommendations of the detergent and additive
manufacturers. The laundry must also be tested to check whether it
contains any active chlorine residues.

Warning and Safety instructions
14
Accessories
 Only use genuine Miele spare parts and accessories with this
machine. Using spare parts or accessories from other manufacturers
will invalidate the warranty, and Miele cannot accept liability.
Disposing of your
old appliance
 Ensure that the door locks are unusable when disposing or
scrapping old washing machines. This way you will prevent the risk of
playing children accidentally locking themselves in and endangering
their lives.
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.

Guide to the machine (with detergent dispensing drawer)
15
Models with detergent dispenser drawer (WEK)
⑪
⑥ ⑦ ⑧ ⑨
⑩
⑫
① ②
③
④
⑤
⑧
⑬
⑮
⑭
⑯
⑰
⑱
aDisplay
see "Control panel"
bEmergency stop switch
see "Control panel"
cDoor handle
dDrum door
eFour adjustable feet
fDetergent dispenser drawer
gElectrical connection
hCold water connection
iHot water connection
j2x hard water connection
(Optional)
kConnections for external dispenser
pumps
lVapour extraction / free outlet TypeAB
mDrainage
nCold water connection for liquid
dispensing
(Optional)
oFan housing
pConnection option for direct/indirect
steam
(depending on model)
q button
rInterface for communicating with
external devices

Guide to the machine (with detergent dispensing drawer)
16
Models without detergent dispensing drawer (WEK)
① ②
③
④
⑤
⑥ ⑦ ⑧
⑨
⑩
⑪
⑦
⑫
⑭
⑬
⑮
⑯
⑰
aDisplay
see "Control panel"
bEmergency stop switch
see "Control panel"
cDoor handle
dDrum door
eFour adjustable feet
fElectrical connection
gCold water connection
hHot water connection
i2x hard water connection
(Optional)
jConnections for dispenser pumps
kVapour extraction / free outlet TypeAB
lDrainage
mCold water connection for liquid
dispensing
nFan housing
oConnection option for direct/indirect
steam
(depending on model)
p button
qInterface for communicating with
external devices

Operation
17
Control panel
a language sensor
For selecting the current user
language.
The operating language is
displayed again at the end of
the programme.
b back sensor
Takes you back one level in the
menu.
cTouch display
dStart/Stop sensor
For starting the selected
programme and cancelling a
programme that has already
started. The programme
selected can be started as
soon as the sensor starts
flashing.
eOptical interface
For service technicians.
fbutton
For switching the washing
machine on and off. To save
energy, the washing machine
will switch off automatically. It
is switched off 15minutes after
the end of the programme/Anti-
crease phase, or after being
switched on if no further
selection is made.
Sensors and touch display with sensors
The sensors,  and Start/Stop and the sensors in the display
respond to fingertip contact. Every touch of the sensors is confirmed
by a keypad tone. You can adjust the volume of the keypad tone or
switch it off (see “Supervisor level”).
The control panel with the sensors and the touch display can be
scratched by pointed or sharp objects, e.g. pens.
Only touch the control panel with your fingers.

Operation
18
Main menu
After switching on the washing machine, the main menu will appear in
the display.
You can access all important sub-menus from the main menu.
Touch the  sensor at any time to return to the main menu. Values
that have not yet been confirmed are not saved when you return to
the main menu.
 11:02

Programmes Favourites Supervisor
Help
 Programmes For selecting wash programmes.
Favourites For selecting one of 12 favourite wash programmes which can be set
up and saved by the operator (see “Supervisor level - Favourite
programmes”).
 Supervisor At the Supervisor level you can alter the washing machine's
electronics to suit changing requirements (see “Supervisor level”).
Examples on how to operate the appliance
Selection lists Programme menu (single selection list)
 11:02
White items Minimum iron Express
Coloured
items
Delicates Woollens
Programmes
You can scroll to the right or the left by swiping your finger across the
screen. To do this, place your finger on the touch display and swipe it
in the direction you want.
The orange bar under the pictures shows that there are further
options to choose from.
Touch a programme name to select a wash programme.
The display will change to the standard menu for that programme.
Extras menu (multiple selection)

Operation
19
 11:02




OK
Pre-wash Rinse plus
Soak Intensive
Extras
Touch one or several Extras to select it/them.
Currently selected Extras are marked orange.
To deselect an Extra, simply touch the Extra again.
Use the OK sensor to activate the selected Extras.
Setting numerical
values
You can set numerical values in some menus.
OK
12 00
10 58
14 02


11 59
13 01
Time
Enter the numbers by swiping upwards or downwards. Place your
finger on the number that you want to change and move your finger
in the desired direction. Use the OK sensor to accept the set
numerical value.
Useful tip: With some settings, a value can also be entered using a
numerical keypad.
OK


12 00
11 59
10 58
13 01
14 02
Time
Briefly touching the number between the two lines will bring up the
numerical keypad.
OK
12:00
3
4
21

5 6
7

8
0
9
Time
Once a valid number has been entered, the OK sensor will be
highlighted green.

Operation
20
Pull-down menu The pull-down menu can be used to display information, e.g. about a
wash programme.
 11:02
2:27



Coloured
items
Status
Time left h
Main
wash
Add laundry
If an orange bar appears at the top of the screen in the middle of the
display, you can open the pull-down menu. Touch the bar and drag it
down with your finger on the display.
Exiting a menu Touch the sensor to return to the previous screen.
Entries you have made before this which have not yet been confirmed
withOK will not be saved.
Help display With some menus Help appears in the bottom line of the display.
Touch the Helpsensor to display the text.
Touch the Closesensor to return to the previous screen.
Operating the launderette version
The entry menu will vary depending on the programming status (see
"Supervisor level - Controls").
Shortcuts are the easiest way to operate the machine. Operators
cannot change the preset programmes.
Launderette, basic
 11:02




Coloured
items
Woollens Delicates
Minimum iron
Help
Between 4 and 12 preset programmes are available. These cannot be
changed by the operator.
Launderette Logo
 11:02
 
Coloured
items
Woollens
Minimum iron
Help 
