Mikado LOGO 10 User manual

Mikado Modellhubschrauber • Clara-Zetkin-Str.8 • 14471 Potsdam • Germany
Phone [phone] • Fax [phone] • www.Mikado-Heli.de
© Mikado Modellhubschrauber, V1.4
Modellhubschrauber
www.Mikado-Heli.de
Manual
LOGO 10
Modellhubschrauber

Manual LOGO 10 Page2 ©MikadoModellhubschrauber
Index
1 Main Frame .........................................6
1.1 Motorplate 6
1.2 Main Frame 7
1.3 Bearing Case 8
2 Landing Gear.....................................9
3 Motor Installation .............................10
3.1 Motor Adaptor Plate 10
3.2 Motor Attachment 11
4 Main Gear ..........................................12
4.1 Hub 12
4.2 Adjusting Gear Backlash 13
5 Tail Rotor............................................14
5.1 Tail Rotor Shaft 14
5.2 Vertical Fin 15
5.3 Pitch Slider 16
5.4 Tail Rotor Lever 17
5.5 Tail Rotor Hub 18
5.6 Final Assembly 19
6 Tail Boom...........................................20
6.1 Tail Boom Assembly 20
6.2 Tail Boom Holder 21
6.3 Tail Drive Pulley 22
6.4 Tail Control Rod 23
6.5 Installation 24
6.6 Horizontal Fin 25
6.7 Tail Rotor Blades 25
7 Finished Main Frame & Tail Boom.26
8 Preparation for Servo Installation .27
8.1 120° CCPM 27
8.2 90° CCPM 27
8.3 Servo Arms 28
8.4 Servo Centering 28
8.5 Linkage 29
9 Servo Installation .............................30
9.1 Tail Rotor Servo 30
9.2 Elevator Servo 31
9.3 Elevator Linkage/Swashplate 32
9.4 Canopy Fixing Bolts 32
9.5 Aileron Servo left 33
9.6 Aileron Servo right 34
9.7 Aileron Linkage 35
10 Wash-Out Hub ................................36
10.1 Assembly 36
10.2 Installation 37
11 Main Rotor Head ............................38
11.1 Blade Grips 38
11.2 Mixing Arms 38
11.3 Yoke 39
11.4 Seesaw 40
11.5 Flybar Control Bridge 41
11.6 Ball Bolts 41
11.7 Flybar 42
11.8 Flybar Paddles 42
11.9 Final Assembly 43
11.10 Rotor Head Linkage 44
12 Logo 10 assembled.......................46
13 RC Installation................................47
13.1 Receiver, Gyro, Speed Controller 47
13.2 Battery 48
14 RC Programming ...........................49
15 Canopy............................................55
15.1 Trimming and Taping 55
15.2 Decals 56
16 Rotor Blades...................................57
17 Final Pre-Flight Check ..................58
17.1 Direction of Main and Tail Rotation 58
17.2 Blade Tracking Adjustment 58
18 Control Movements.......................59
18.1 Pitch/Throttle 59
18.2 Rudder 59
18.3 Elevator 60
18.4 Aileron 60
19 Overview ........................................61
19.1 Chassis 61
19.2 Rotor Head 62
19.3 Tail Boom/Tail Rotor 62
19.4 Upgrades/Accessories 63
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160mm
123456
inches

Manual LOGO 10 Page3 ©MikadoModellhubschrauber
Safety Instructions
OPERATING YOUR MODEL SAFELY
Operate the helicopter in spacious areas with no people nearby.
! Warning: Do NOT operate the helicopter in the following places and situations
(or else you risk severe accidents):
in places where children gather or people pass through
in residential areas and parks
indoors and in limited space
in windy weather or when there is any rain, snow, fog or other precipitation
If you do not observe these instructions you may be held reliable for personal injury or property damage!
Always check the R/C system prior to operating your helicopter.
When the R/C system batteries get weaker, the operational range of the R/C system decreases. Note that you
may lose control of your model when operating it under such conditions.
Keep in mind that other people around you might also be operating a R/C model.
Never use a frequency which someone else is using at the same time. Radio signals will be mixed and you will
lose control of your model.
If the model shows irregular behavior, bring the model to a halt immediately. Turn off all power switches and
disconnectthebatteries.Investigate the reason and fixtheproblem.Do not operate the modelagainaslong as the
problem is not solved, as this may lead to further trouble and unforeseen accidents.
! Warning: In order to prevent accidents and personal injury, be sure to observe the following:
Beforeflyingthe helicopter, ensure thatall screwsare tightened.Asingle loose screwmaycause amajor accident.
Replace all broken or defective parts with new ones, as damaged parts lead to crashes.
Never approach a spinning rotor. Keep at least 10 meters/yards away from a spinning rotor blades.
Do not touch the motor immediately after use. It may be hot enough to cause burns.
Perform all necessary maintenance.
PRIOR TO ADJUSTING AND OPERATING YOUR MODEL, OBSERVE THE FOLLOWING
!Warning:Operate the helicopter only outdoors and out of people’s reach as the main rotor operates at high rpm!
! Warning: While adjusting, stand at least 10 meters/yards away from the helicopter!
Novice R/C helicopter pilots should always seek advice from experienced pilots to obtain hints with assembly
and for pre-flight adjustments. Note that a badly assembled or insufficiently adjusted helicopter is a safety hazard!
In the beginning, novice R/C helicopter pilots should always be assisted by an experienced pilot and never fly
alone!
Throttle channel should be in motor OFF position while powering up.
When switching the R/C system ON or OFF, always proceed in the following order:
When switching ON:
Position the throttle control stick (on transmitter) to a position where the LOGO 10 motor does not operate.
Turn on the transmitter.
Turn on the receiver.
Connect the motor battery.
Operate your model.
When switching OFF:
Turn off the motor (move throttle control to a position where motor does not operate).
Wait until the rotor head has stopped spinning.
Disconnect the motor battery.
Turn off receiver.
Turn off transmitter.

Manual LOGO 10 Page4 ©MikadoModellhubschrauber
Tools for Assembly & R/C Equipment
Scissors
Rubber Hammer
Drill with
1.5mm bit
(.059 in)
Marker
Screwdrivers
(plus and minus)
Hex Wrenches
1.5/2.0/2.5/3.0mm
(.055/.079/.098/.118in)
Radio with Heli-Software
4x Mini Servos (Graupner DS361
or Graupner C341)
Receiver Battery
(Sanyo AR500)
Battery (Sanyo RC2400 or Sanyo 3000 NiMH)
Receiver (Graupner DS 19
or SMC 19 SPCM)
Gyro (Futaba GY240
or GY401)
Fast Charger (Schulze isl 6-330d or isl 6-636+)
Motor + Speed Controller (check the Mikado
webpages for recommended motors)
Alle shown products are examples.You may use different brands.
Ball link pliers
Threadlock
BEC, replaces
receiver battery

Manual LOGO 10 Page5 ©MikadoModellhubschrauber
Listing of Parts
Chassis, Bag 1 1965 3 socket head cap screw M3 x 18
1914 2 countersunk screw M4x10 2013 2 washer 4 x 8 x 1
1915 2 countersunk screw M3 x 8 2064 8 self-tapping screw 2.9 x 16
1953 6 socket head cap screw M3 x 10 2074 1 hex locknut M3
1961 1 cylinder screw M3x35 2370 2 hex spacer 27 mm
1964 2 socket head cap screw M3 x 12 flat head 2370 2 hex spacer 23 mm
2012 2 washer 3 x 7 x 0,5 2485 1 tail boom holde
r
2062 4 self-tapping screw 2.9 x 13 2488 1 cylindrical pin 4 x 31.5
2064 2 self-tapping screw 2.9 x 16 2491 1 horizontal stabilize
r
2072 8 hex nut M3 2728 1 driven belt gear, 40 Z
2189 1 rod end 8 mm 2760 1 tail boom 565 mm
2370 1 hex spacer, 38 mm 2762 1 tail rotor rod, 545mm
2370 2 hex spacer, 19 mm 2763 2 rudder control guide
2384 1 thread rod M3
2724 2 O-ring battery holders, 38x3,5 + 46x3,5 Main Rotor Head, Bag 7
2379 1 motor plate 909 1 yoke
2380 1 bearing case 933 1 stabilizer control bridge
2382 2 canopy fixing bolt 935 1 seesaw
2383 1 swashplate guide bracket 2314 2 blade holde
r
2499 1 motor adaptor plate 2346 1 rotorhead shaft
2720 1 LOGO 10 mainframe right 2358 2 stabilizer blade 3 mm
2721 1 LOGO 10 mainframe left 2361 2 ball bolt
912 2 pin
Main Gear, Bag 2 939 1 seesaw bolt
1344 1 C-Ring 965 2 double ball-link
1915 4 countersunk screw M3 x 8 1570 4 balls
1940 3 socket head cap screw M4x5 1900 2 cylinder screw M2 x 3
2010 2 washer 10x16x0,5 1902 8 cylinder screw M2 x 8
2386 1 fixing colla
r
1903 4 cylinder screw M2 x 10
2725 1 main gear, 200 teeth 1921 2 set screw M3 x 3
2731 1 one-way hub 1956 2 socket head cap screw M3 x 16
2740 1 main rotor shaft 1965 1 cap screw (yoke) M3 x 18
1972 2 socket head cap screw M3 x 12
Wash-out / Swashplate Bag 3 1975 2 cap screw (blade holder) M3 x 25
969 1 washout-block 2012 4 Washer 3x7x0,5
978 2 mixing arm for slide bearing 2015 2 washer 4 x 12 x 1
980 2 bolt for no. 981 2070 4 hex nut M2
981 2 Y-rod 2072 1 hex nut M3
982 2 bolt + e-ring 2074 2 hex locknut M3
1570 2 ball 2320 2 mxing arm, slide bearing 3x5x6
1902 2 cylinder screw M2 x 8 2750 1 stabilizer bar 360 mm
2365 2 swashplate 2755 6 dumper rubber 8x2,5 (4x), 7x2,5 (2x)
Tail Rotor, Bag 5 Landing frame, Bag 8
1570 1 ball 1954 4 socket head cap screw M3 x 12
1902 1 cylinder screw M2 x 8 2012 4 washer 3 x 7 x 0,5
1921 1 set screw M3 x 3 2074 4 hex locknut
1953 1 socket head cap screw M3 x 10 2495 2 landing gear strut
1954 2 socket head cap screw M3 x 12 2775 2 landing gear skid
1955 3 socket head cap screw M3 x 14
1958 2 socket head cap screw M3 x 25 Control rods, Bag 9
2004 2 washer 5 x 10 x 0.1 1567 6 ball-links 2.5 mm
2074 5 hex locknut M3 1569 2 ball-links, angular 2.5 mm
2442 1 tail rotor case 1570 4 ball
2446 1 tail rotor lever + washer 3x4x10,5 1586 4 control rod 60 x 2.5 mm
2450 1 tail rotor pitch plate 1902 4 cylinder screw M2 x 8
2452 1 control ring 2070 4 hex nut M2
2455 1 control sleeve 2770 3 control rod 30 x 2,5mm (swashplate)
2458 1 tail rotor housing
2460 1 tail rotor blades Ball Bearings, Bag 10
2462 2 tail rotor blade holde
r
937 3 ball bearing 4 x 13 x 5
2463 2 bushing 3 x 5 x 2.1 941 2 ball bearing 3 x 10 x 4
2466 1 driven belt gea
r
1329 2 ball bearing 10 x 19 x 5
2467 1 gear drive
r
1440 2 ball bearing 6 x 10 x 2,5
2468 1 driving pin 2 x 8 mm 2351 4 ball bearing 8 x 14 x 4
2476 1 tail rotor shaft 2423 4 ball bearing 3 x 8 x 3
2490 1 vertical stabilize
r
2470 2 ball bearing 5 x 10 x 4
2765 1 driven belt 490 XL 2489 1 ball bearing 4 x 9 x 4
Tail Boom, Bag 6 2478 1
A
ntenna tube
1560 2 ball link 2 mm 2790 1 LOGO 10 canopy
1921 1 set screw M3 x 5 2792 1 decals LOGO 10

Manual LOGO 10 Page6 ©MikadoModellhubschrauber
#2379
1x 10x19x5 #1329
6x M3 #2072
1 Main Frame
1.1 Motorplate
Bag 1 • Bag 10

Manual LOGO 10 Page7 ©MikadoModellhubschrauber
#2720
#2721
6x M3x10 #1953
2x 2,9x16 #2064
1x 38 mm #2370
1x M3x35 #1961
#2189
1 Main Frame
Please avoid overtightening the
2.9x16 mm selftapping screws and
the socket head cap screw M3x35
when drilling them into the plastic
side-frames.
Use the 8 mm ball end #2189, so
you have the option of attaching the
tailboombracelater(#2761,notinclu-
ded in the kit), if desired.
1.2 Main Frame
Bag 1

Manual LOGO 10 Page8 ©MikadoModellhubschrauber
#2380
1x 10x19x5 #1329
2x 19 mm #2370
4x 2,9x13 mm
#2062
1 Main Frame
Please avoid overtightening the
2.9x13 mm selftapping screws when
drilling them into the plastic side-fra-
mes.
1.3 Bearing Case
Bag 1 • Bag 10

Manual LOGO 10 Page9 ©MikadoModellhubschrauber
#2495
#2775
4x M3x12 #1954
4x M3 #2074
4x 3x7x0,5 #2012
2 Landing Gear
Bag 8
Align the skids and secure them
with superglue.

Manual LOGO 10 Page10 ©MikadoModellhubschrauber
#2499 2x M3x8 #1915
3 Motor Installation
3.1 Motor Adaptor Plate
Bag 1
Some electric motors (e.g. Kontro-
nik, Plettenberg, Speed 700 Neody-
me motors) are constructed such
that they cannot be moved along the
motor plate. If you are using one of
these motors, please use the motor
adaptor plate #2499.The plate is not
needed for Hacker motors.
Please check from the Mikado
website which pinion works best with
the motorset you have (on
www.mikado-heli.de go to LOGO 10
and click “Motorization”). When a
wrong pinion is chosen, the perfor-
mance of your electric helicopter will
deteriorate and the motor or speed
controller can be damaged.
Donottightenthesetscrewfullyuntil
the final position of the pinion on the
motor shaft is determined. This is
done after installing the main gear.
There are two options for attaching
thepinion:
1. For securing the pinion, you may
flatten the motor shaft where the set
screwmeets the motor shaft -without
making a flat surface on the motor
shaft.
2. Alternatively, you may screw the
set screw directly onto the motor
shaft. For this it is required that the
set screw has an appropriate rim for
engaging the motorshaft (all Mikado
pinionshavethisrim).Note,however,
that after attaching the set screw
once,the rimbecomesbluntandmay
not be used again.

Manual LOGO 10 Page11 ©MikadoModellhubschrauber
2x M3x12 #1964
2x 3x7x0.5 #2012
3 Motor Installation
3.2 Motor Attachment
Bag 1
When installing the motor, tighten
the socket head cap screws only
slightly, making sure that the motor
can still be moved on the motor pla-
te.

Manual LOGO 10 Page12 ©MikadoModellhubschrauber
#2731
#2725
#2386
4x M3x8 #1915
3x M4x5 #1940
2x 10x16x0.5 #2010
1x #1344
#2740
4 Main Gear
4.1 Hub
Bag 2
Do not yet tighten the three M4x5
set screws on the mainshaft collar.

Manual LOGO 10 Page13 ©MikadoModellhubschrauber
4 Main Gear
Bag 2
After having attached the freeway
hubofthemain geartothe rotorshaft,
pulltherotorshaftslightlyupwardand
simultaneously push the main shaft
collar down onto ball bearing. Next
tightenthe set screws.The rotor shaft
should turn easily and it should not
have any axial play.
4.2 Adjusting Gear Backlash
The gear backlash must be adju-
sted (see drawings). Excess back-
lashcan causeprematurewearof the
maingearandwillleadtoshorterflight
times.
too much backlash correct backlash too little backlash

Manual LOGO 10 Page14 ©MikadoModellhubschrauber
# 2442
#2467
#2476
#2466
#2442
#2765
1x 2x8mm #2468
2x 5x10x4 #2470
2x 5x10x0.1 #2004
5 Tail Rotor
5.1 Tail Rotor Shaft
Bag 5 • Bag 10
Shouldyou have difficultymounting
the 2x8 mm pin, carefully tap it with a
rubber hammer, or use a vice. The
5x10x4 bearings can also be moun-
tedon the rotor shaft using a vice and
tapping the shaft softly with a rubber
hammer. If the tail rotor shaft shows
axial play after closing the two hal-
ves of the tail rotor case, use one or
two of the 5x10x0.1 washers which
are included in the bag.

Manual LOGO 10 Page15 ©MikadoModellhubschrauber
#2490
2x M3x25
#1958
1x M3x10 #1953
3x M3 #2074
5 Tail Rotor
5.2 Vertical Fin
Bag 5

Manual LOGO 10 Page16 ©MikadoModellhubschrauber
#2455
#2452
#2450
2x 6x10x2,5 #1440
5 Tail Rotor
5.3 Pitch Slider
Bag 5 • Bag 10
It is important that the tail pitch pla-
te #2450 is aligned properly on the
control sleeve #2455. In the case of
misalignment,the control sleeve may
be deformed. The mounted tail pitch
plate should be able to move on the
tail rotor shaft with little resistance.

Manual LOGO 10 Page17 ©MikadoModellhubschrauber
1x M3x14 #1955
1x M2x8 #1902
1x 4,8 mm #1570
1x 3x4x10,5 #2446
#2446
5 Tail Rotor
5.4 Tail Rotor Lever
Bag 5
The mounted tail rotor lever should
be able to move with little resistance.

Manual LOGO 10 Page18 ©MikadoModellhubschrauber
#2462
#2458
2x M3x12 #1954
2x 3x5x2 #2463
4x 3x8x3 #2423
1x M3x3 #1920
5 Tail Rotor
5.5 Tail Rotor Hub
Bag 5 • Bag 10

Manual LOGO 10 Page19 ©MikadoModellhubschrauber
5 Tail Rotor
5.6 Final Assembly
All movable parts of the tail rotor
bladeholders should be abletomove
with little resistance. When there is
toomuchresistance,the tail rotor will
notreacttosubtleinputandthegyro’s
maximum sensitivity cannot be fully
exploited.

Manual LOGO 10 Page20 ©MikadoModellhubschrauber
#2760
#2763
6 Tail Boom
6.1 Tail Boom Assembly
Bag 6
Note that the two tail rotor pushrod
guides are different in height.
The tail boom has two round cut-
outs on one end.These should be fit-
ted into the matching shapes in the
tail rotor case.
