mikroElektronika mikromedia 7 User manual

V
Amazingly compact, all-on-single-pcb development board
carring7”TFTTouchScreenandlotsofmultimediaperipherals,
all driven by powerful STM32F407ZG microcontroller from
ARM® Cortex™-M4 family
for STM32F4
mikromedia 7

I want to express my thanks to you for being interested in our products and for
having condence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic
products and to constantly improve the performance thereof in order to better
suit your needs.
To our valued customers
Nebojsa Matic
General Manager

Page 3
Table of Contents
Introduction to mikromedia 7 for STM32F4 4
System Specication 4
Package Contains 5
1. Power supply 6
2. STM32F407ZG microcontroller 8
Key microcontroller features 8
3. Programming the microcontroller 9
Using mikroProg™ programmer 10
mikroProg™suite for ARM®software 12
Software installation wizard 13
4. RTC Battery and Reset Button 14
5. Crystal oscillators and 2.048V reference 16
6. MicroSD Card Slot 18
7. Touch Screen 20
8. Audio Module 22
9. USB DEVICE connection 24
10. USB HOST connection 26
11. Accelerometer 28
12. Flash Memory 30
13. RF transceiver 32
14. Wi-Fi 34
15. Ethernet transceiver 36
16. CAN communication 38
17. Buzzer 40
18. Other modules 42
19. Pads 44
What’s next 46

Page 4
Introduction to mikromedia 7 for STM32F4
The mikromedia 7 for STM32F4 is a compact development
system with lots of on-board peripherals which allow
development of devices with multimedia contents. The central
part of the system is a 32-bit ARM®Cortex™-M4 STM32F407ZG
144-pin microcontroller. The mikromedia 7 for STM32F4
features integrated modules such as stereo MP3 codec, 7” TFT
800x480 touch screen display. The increased screen size is ideal
for displaying larger amounts of data. The board also contains
an accelerometer, microSD card slot, buzzer, IR receiver, RGB
LED diode, PIN photodiode, temperature sensor, 2.4GHz RF, WiFi,
Ethernet and CAN transceivers, 8 Mbit ash memory, RTC battery,
Li-Polimer battery charger, etc. The board also contains MINI-B
USB connector, power screw terminals, 2x5 JTAG connector, two
1x26 connection pads, ON/OFF switch and other. It comes with
an onboard mikroProg™ for STM32 programmer and debugger,
but can also be programmed with external programmers, such
as ST-LINK programmer.
System Specication
power supply
Via USB cable (5V DC) or via connector
(5-12V DC)
power consumption
~108 mA with empty MCU via USB cable
(when on-board modules are disabled)
board dimensions
179 x 111 mm
~(7 x 4.37 inch)
weight
~250g
(0.55 lbs)

Page 5
Package Contains
Damage resistant protective box Development board
User’s guide Schematic
Roll USB and ethernet cables and headers
Distancers, plastic pen and microSD card
123
456

Page 6
1. Power Supply
Figure 1-3:
Battery power supply
Figure 1-4: Adapter
connector power supply
Figure 1-1:
mikroProg power supply
Figure 1-2:
USB power supply
The mikromedia 7 for STM32F4 board can be powered in four dierent ways: via two USB connectors using MINI-B USB cable provided
with the board (CN4 or CN11),via battery connector using Li-Polymer battery (CN5) or via adapter connector using adapter power supply
(CN3). After you plug in the appropriate power supply turn the power switch ON (SW1). The USB connection can provide up to 500mA of
current which is more than enough for the operation of all on-board modules and the microcontroller as well. If you decide to use external
power supply via screw terminals, voltage values must be within 5-12V DC range. Power LED ON (GREEN) indicates the presence of power
supply. On-board battery charger circuit MCP73832 enables you to charge the battery over USB connection or via screw terminals. LED
diode (RED) indicates when battery is charging. Charging current is ~250mA and charging voltage is 4.2V DC.

Page 7
Vusb_OUT
Vdc
Vbat_IN
Charging Current approx. 250mA
E10 10uF
3
2
1STAT
VSS
VBAT VDD
PROG
U11
MCP73832
Vbat_IN
CN5
R42
10K
R46
10K
R41
100K
L2
1.5uH
R43
1K
C66
22uF
C71 100nF
C70
10pF
C67
22uF
C68
22uF
R45
10K
R50
100K
L3
1.5uH
R52
12K C74
22uF
C77 100nF
C78
10pF
C75
22uF
C76
22uF
R53
4K7
VCC-5V
VCC-3.3V
VCC-5V
R38
10K
R39
10K
USB-PSW
E7
10uF
1
2
3
OUT
GND
IN
5
4OCEN
U6
TPS2041B
VCC-3.3V
E8
10uF
USB-VBUS_ER
E9
10uF
USB-ID
USB-VBUS
R47
1K
Vusb_IN
D5
B340A
D2
B340A
D4
PMEG3010ER
D3 PME G3010ER
10
9
8
7
65
4
3
2
1
PG
VIN
L1
EN
PS
VAUX
GND
FB
L2
VOUT
PGND
U7
TPS63060
10
9
8
7
65
4
3
2
1
PG
VIN
L1
EN
PS
VAUX
GND
FB
L2
VOUT
PGND
U9
TPS63060
USB-ID
USB-VBUS
USB-PSW
USB-VBUS_ER VBUS_ER
PSW
VBUS
ID
USB
R49
1M
R51
1M
R54
1M
BAT-VSENSE BAT-VSENSE
USB-CONN
R55
1K
C73
22uF
C69
22uF
POWER
C72
100nF
C79
100nF
VCC-3.3V
1
2
3
4
5
GND
ID
D+
D-
VBUS
CN4
USB M INIB
C138
100nF PWR-EN
R101
100K
M1
DMP2160UW
M2
DMP2160UW
C139
1uF
C140
10nF
C141
100pF
C142
1uF
C143
10nF
C144
100pF
LD1
R44
470R
1
2 3
R1
R2
Q1
PDTC114EU
R2
10K
VCC-3.3V
DC-VBUS# DC-VBUS#
VIN
V_INPUT
FP5
R132
1M
C167
3.3nF
D9
ESDA5V3L
1
2
3
CN3
PJ-002AH-SMT
VCC-PROG
D10
PMEG3010ER
R57
2K2
R60
10K
BAT-STAT
R61
10K
R59
1K
R56
10K
VCC-3.3V
C81
10uF
LD2
CHARGE
V_INPUT
V_INPUT
M5
DMP2305U
D11
BAT43
1 2 3
4
5 6
SW1
JS202011AQN
USB-GND
1
2
3
4
5
GND
ID
D+
D-
VBUS
CN11
PROG USB MINIB
FP7
R134
1M
C156
3.3nF
E11
10uF
USB-STLink-GND
VCC-PROG
R62
3K9
5
4
C80
2.2uFC157
2.2uF
C159
2.2uF
1
2
3
VIN
GND
VOUT
5
4ENPWRGD
U21 MCP1755
C160
470pF
V_INPUT
VCHG
D6
PMEG3010ER
D7
PMEG3010ER
Vusb_IN VCC-PROG
BAT-STAT
Figure 1-4: Power supply schematic

Page 8
2. STM32F407ZG microcontroller
APB2 84MHz
3 x ADC
temperature sensor
1 x SPI
1 x USART
3 x TIMER 16-bit
3 x TIM/PWM 16-bit
SDIO/MMC
2 x CAN
3 x I2C
2 x SPI
2 x UART
2 x USART
5 x TIMER 16-bit
2 x TIMER 32-bit
APB1 42MHz
2 x DAC
3 x TIMER 16-bit
WWDG
RTC
IWDG
SRAM 176 KB
FLASH 1MB
EXT. MEM. CONTR
DMA 2
ETH. MAC 10/100
JTAG & SW
USB OTG FS
CAM. INTERFACE
RNG
DMA 1 SRAM 16KB USB OTG HS
AHB BUS - MATRIX
POWER / RESET
GPIO PORT
(A,B,C,D,E,F,G,H,I) ARM
Cortex™-M4
STM32F407ZG
Key microcontroller features
- Up to 210 DMIPS Operation (168MHz);
- 1 MB of Flash memory;
- 192 + 4 KB of SRAM memory;
- up to 140 I/O pins;
- 16/32-bit timers
- 16MHz internal oscillator, 32kHz RTCC, PLL;
- 4xUART, 3xSPI, 3xI2C, 2xCAN, 3xADC, 3XADC etc.
- Ethernet, USB etc.
The mikromedia 7 for STM32F4 development board comes
with the 144-pin ARM® Cortex™-M4 STM32F407ZG
microcontroller. This high-performance 32-bit microcontroller
with its integrated modules and in combination with other
onboard modules is ideal for multimedia applications.

Figure 3-1:
STM32F407ZG
ARM®Cortex™-M4
Microcontroller
The microcontroller can be programmed in two ways:
1. Using onboard mikroProg™for STM32 programmer
2. Using external programmers for STM32 (like ST-LINK)
3. Programming the microcontroller
Page 9

Page 10
Figure 3-10:
mikroProg™JTAG connector
Using mikroProg™ programmer
The microcontroller can be programmed with onboard
mikroProg™for STM programmer and mikroProg Suite™for
ARM®software. Connection with PC is established over an PROG
USB connector. For proper insertion of the MINI-B USB cable refer
to Figure 3-9. Signalization LED (LINK) is also provided on the
opposite side of the PROG USB connector. It is also possible to
program the microcontroler with external porogrammers, via 2x5
JTAG connector (CN1) with an appropriate adapter, Figure 3-10.
Figure 3-9:
On-board mikroProg™programmer

Page 11
VCC-3.3V
VCC-3.3V
R140
2K2
LED_LINK
LINK
R126 22
R127 22
USB-PROG N
USB-PROG P
R133
100K
1
2
3
4
5
GND
ID
D+
D-
VBUS
CN11
PROG USB MINIB
FP7
R134
1M
C156
3.3nF
E11
10uF
I/O1
1
GND
2
I/O2
3
I/O1
6
I/O2
4
VBUS
5
U24 USBLC6-2SC6
USB-STLink-GND
ST-LINK
X5
25MHz
C111
22pF
C110
22pF
X4
32.768KH z
C108
10pF
C109
10pF
TM S-SWDI O
TCK-SWCLK
RESET #
6
8
109
7
5
1 2
3 4
CN1
JTAG
OSC32_I N
OSC32_OU T
VCC -3.3V
O SC_ IN
OSC_OU T
R87 100K
R86 100K
C107
2.2uF
C114 2.2uF
VCC -3.3V
Vbat_m cu
TM S-SWDI O
TC K-SWCLK
O SC_ IN
OSC_OU T
144 143
142
141 140 139 138 137 136 135 134 133 132
131 130
129 128
127 126 125
124 123 122
121 117 118 119
120
116 115 114
113 112
111
110
109
106
108
107
102
103
104
105
73
30
29
28
27
34
33
58 57
56 55 54
53 52
46
36
35
42
43
44
45
37
50
9
48 49
11
12
32
72
69 68
67 66 65 64 63
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
62
61
60 59
38
39
40
41 47 71
31
51
70
26
25
76
75
74
STM32F407ZG
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
PA1
PA0
VDD A
VRE F+
PA6
PA5
PE6
VBAT
PC13
PC14
PB10
PE15
PE14
PG0
PC4
PA7
VD D PF13
PF14
PF15 PC5 PB0
PG6
PG5
PG4
PG8
PG3
PG2
VD D
VSS
PE5
PE4
PC8
PC7
PC6
VD D
VSS
PG7
PF2
PC2
PH0
PF10
PF9
PF8
PF7
PF6
VCA P1
PB11 PE12
PF4
PF1
PF0
VSS
PC9
PA8
PE2
PE3
PC1
PC0
NRST
PH1
PF11
PF12 PE13
PE9
PB1
PB2 PG1
VD D PA3
PE7 VSS
PD15
VD D
VSS
PF5
PA2
PA4 PE8
PE11
PD14
VSSA
VD D
PC3
PF3
PC15
VD D PE10
VD D
PD9
PB15
PB12
PB13
PB14
PD8
PD10
PD11
PD12
PD13
PA9
PA11
VD D
VSS
VCAP2
PA13
PA12
PA10
PG12 PG11 PG10 PG14
PG9
PD7
VSS
PD5
PB4
PB3
PG15
VD D
VSS
PG13
PB5
PB6
PD6
VD D
PD0
PC11
PA14
PA15
PC10
PC12
PD1
PD2
PD3
PD4
PB7
PB8
VD D
PDR_ O N
PE1 PE0
PB9
BOOT 0
101
VSS
U18
BAT 1
3000T R
OSC32_I N
OSC32_OU T VCC -3.3V
C118 100nF
C115 100nF
C116 100nF
C117 100nF
VCC -3.3V
C119 100nF
C120 100nF
C121 100nF C122 100nF
VCC -3.3V
C123 100nF C124 100nF C125 100nF C126 100nF
C127 100nF
C130 10nF C131 1uF
C134 4.7uF
VCC -3.3V
TCK/SWCLK
RESET#
TMS/SWDIO
Figure 3-11: mikroProg™JTAG connector connection schematic

Page 12
mikroProg Suite™ for ARM® software
Figure 3-1:
mikroProg
Suite™for
ARM®
window
mikroProg™for STM32 programmer requires special programming software called
mikroProg Suite™ for ARM®. This software is used for programming ALL of STM32 ARM®
Cortex-M3™and Cortex-M4™ microcontroller families. It features intuitive interface and
SingleClick™ programming technology. Software installation is available on following link:
www.mikroe.com/downloads/get/1809/mikroprog_suite_for_arm.zip
After downloading, extract the package and double click the executable setup le to start
installation.
Quick Guide
1. Click the Detect MCU button in order to recognize the device ID.
2. Click the Read button to read the entire microcontroller memory. You can click the Save
button to save it to the target HEX le.
3. If you want to write the HEX le into the microcontroller, rst make sure to load the
target HEX le using the Load button. Then click the Write button to begin programming.
4. Click the Erase button to clear the microcontroller memory.

Page 13
Software installation wizard
1. Start Installation
4. Choose destination folder
2. Accept EULA and continue
5. Installation in progress
3. Install for all users
6. Finish installation

Page 14
RTC Battery
Reset Button
The board is equipped with reset button, which is
located on the front side of the board. If you want to
reset the circuit, press the reset button. It will gen-
erate low voltage level on the microcontroller reset
pin (input). A reset can also be externally provided
through the pin 26 on the side headers.
4. RTC Battery and Reset Button
mikromedia 7 for STM32F4 features an RTC
battery holder for microcontroller RTC module.
Battery is used as alternate source of power, so
the RTC module can continue to keep time while
the primacy source of power is o or currently
unavailable. Three types of coin battery are
supported: CR1216, CR1220 and CR1225.

Page 15
R87 100K
R86 100K
C107
2.2uF
C114 2.2uF
VCC -3. 3V
Vbat_mcu
RESET #
144 143
142
141 140 139 138 137 136 135 134 133 132
131 130
129 128
127 126 125
124 123 122
121 117 118 119
120
116 115 114
113 112
111
110
109
106
108
107
102
103
104
105
73
30
29
28
27
34
33
58 57
56 55 54
53 52
46
36
35
42
43
44
45
37
50
9
48 49
11
12
32
72
69 68
67 66 65 64 63
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
62
61
60 59
38
39
40
41 47 71
31
51
70
26
25
76
75
74
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
PA1
PA0
VDD A
VRE F+
PA6
PA5
PE6
VBAT
PC13
PC14
PB10 PE15
PE14
PG0
PC4 PA7
VD D PF13
PF14
PF15 PC5 PB0
PG6
PG5
PG4
PG8
PG3
PG2
VD D
VSS
PE5
PE4
PC8
PC7
PC6
VD D
VSS
PG7
PF2
PC2
PH0
PF10
PF9
PF8
PF7
PF6
VCAP1
PB11 PE12
PF4
PF1
PF0
VSS
PC9
PA8
PE2
PE3
PC1
PC0
NRST
PH1
PF11 PF12 PE13 PE9
PB1
PB2 PG1 VD D PA3
PE7
VSS
PD15
VD D
VSS
PF5
PA2
PA4 PE8
PE11
PD14
VSSA
VD D
PC3
PF3
PC15
VD D PE10
VD D
PD9
PB15
PB12
PB13
PB14
PD8
PD10
PD11
PD12
PD13
PA9
PA11
VD D
VSS
VCAP2
PA13
PA12
PA10
PG12
PG11 PG10
PG14
PG9
PD7
VSS
PD5
PB4
PB3
PG15
VD D
VSS
PG13
PB5
PB6
PD6
VD D
PD0
PC11
PA14
PA15
PC10 PC12
PD1 PD2 PD3
PD4
PB7
PB8
VD D
PDR_ ON
PE1 PE0
PB9
BOO T 0
101
VSS
U18
BAT 1
3000T R
VCC -3. 3V
VCC -3. 3V
VCC -3. 3V
C118 100nF
C123 100nF C124 100nF C125 100nF C126 100nF
C127 100nF
C130 10nF C131 1uF
C134 4.7uF
VCC -3. 3V
C115 100nF
C116 100nF
C117 100nF
C119 100nF
C120 100nF
C121 100nF C122 100nF
HDR 2
M1X26
Vd cVCC -3. 3V
VCC -3. 3V
R69
10K
R70
220
C99
100nF
RESET
T1
RESET #
RESET #
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
STM32F407ZG
Figure 4-1: Reset circuit and RTC battery schematic

Page 16
Figure 5-1:
Crystal oscillators
and 2.048V reference
5. Crystal oscillators
and 2.048V reference
The board is equipped with 125MHz
crystal oscillator (X5) circuit that
provides external clock waveform to the
microcontroller OSCO and OSCI pins. This
base frequency is suitable for further clock
multipliers and ideal for generation of
necessary USB clock, which ensures proper
operation of bootloader and your custom
USB-based applications. The board also
contains 232.768 kHz crystal oscillator
(X4) which provides external clock for
internal RTCC module. Microcontroller ADC
requires an accurate source of reference
voltage signal. That is why we provide the
external 3voltage reference to the
microcontroller VREF pin which is 2.048V.
1 2 3

Page 17
R87 100K
R86 100K
C107
2.2uF
C114 2.2uF
VCC -3. 3V
Vbat_mcu
144 143
142
141 140 139 138 137 136 135 134 133 132
131 130
129 128
127 126 125
124 123 122
121 117 118 119
120
116 115 114
113 112
111
110
109
106
108
107
102
103
104
105
73
30
29
28
27
34
33
58 57
56 55 54
53 52
46
36
35
42
43
44
45
37
50
9
48 49
11
12
32
72
69 68
67 66 65 64 63
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
62
61
60 59
38
39
40
41 47 71
31
51
70
26
25
76
75
74
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
PA1
PA0
VDD A
VRE F+
PA6
PA5
PE6
VBAT
PC13
PC14
PB10 PE15
PE14
PG0
PC4 PA7
VD D PF13
PF14
PF15 PC5 PB0
PG6
PG5
PG4
PG8
PG3
PG2
VD D
VSS
PE5
PE4
PC8
PC7
PC6
VD D
VSS
PG7
PF2
PC2
PH0
PF10
PF9
PF8
PF7
PF6
VCAP1
PB11 PE12
PF4
PF1
PF0
VSS
PC9
PA8
PE2
PE3
PC1
PC0
NRST
PH1
PF11 PF12 PE13 PE9
PB1
PB2 PG1 VD D PA3
PE7
VSS
PD15
VD D
VSS
PF5
PA2
PA4 PE8
PE11
PD14
VSSA
VD D
PC3
PF3
PC15
VD D PE10
VD D
PD9
PB15
PB12
PB13
PB14
PD8
PD10
PD11
PD12
PD13
PA9
PA11
VD D
VSS
VCAP2
PA13
PA12
PA10
PG12
PG11 PG10
PG14
PG9
PD7
VSS
PD5
PB4
PB3
PG15
VD D
VSS
PG13
PB5
PB6
PD6
VD D
PD0
PC11
PA14
PA15
PC10 PC12
PD1 PD2 PD3
PD4
PB7
PB8
VD D
PDR_ ON
PE1 PE0
PB9
BOO T 0
101
VSS
U18
BAT 1
3000T R
X5
25MHz
C111
22pF
C110
22pF
X4
32.768KH z
C108
10pF
C109
10pF
OSC32_I N
OSC32_OU T
O SC_ IN
OSC_OU T
VCC -3. 3V
VCC -3. 3V
VCC -3. 3V
C118 100nF
C123 100nF C124 100nF C125 100nF C126 100nF
C127 100nF
C130 10nF C131 1uF
C134 4.7uF
VCC -3. 3V
C115 100nF
C116 100nF
C117 100nF
C119 100nF
C120 100nF
C121 100nF C122 100nF
1
2
3
VI N
VOU T
VSS
REF1
MAX6106EUR +
VCC -3. 3V
C105
1uF
C104
100nF
1 2 3
J4
C113 10nF C112 1uF
REF
VCC -3. 3V
STM32F407ZG
Figure 5-2: Crystal oscillator and voltage reference schematic

Page 18
Figure 6-1:
microSD card slot
6. microSD Card Slot
Board contains 1microSD card slot for using 2microSD cards in your projects.
It enables you to store large amounts of data externally, thus saving microcontroller
memory. microSD cards use Serial Peripheral Interface (SPI) for communication with the
microcontroller. Ferrite and capcitor are provided to compensate the voltage and current
glitch that can occur when pushing-in and pushing-out microSD card into the socket.
Proper insertion of the microSD card is shown in Figure 6-1.
1
2

Page 19
R87 100K
R86 100K
C107
2.2uF
C114 2.2uF
VCC -3. 3V
Vbat_mcu
SD-CD#
SD-DAT 0
SD-DAT 1
SD-DAT2
SD-DAT3
SD-CMD
SD-CLK
O SC_ IN
OSC_OU T
144 143
142
141 140 139 138 137 136 135 134 133 132
131 130
129 128
127 126 125
124 123 122
121 117 118 119
120
116 115 114
113 112
111
110
109
106
108
107
102
103
104
105
73
30
29
28
27
34
33
58 57
56 55 54
53 52
46
36
35
42
43
44
45
37
50
9
48 49
11
12
32
72
69 68
67 66 65 64 63
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
62
61
60 59
38
39
40
41 47 71
31
51
70
26
25
76
75
74
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
PA1
PA0
VDD A
VREF+
PA6
PA5
PE6
VBAT
PC13
PC14
PB10 PE15
PE14
PG0
PC4 PA7
VD D PF13
PF14
PF15 PC5 PB0
PG6
PG5
PG4
PG8
PG3
PG2
VD D
VSS
PE5
PE4
PC8
PC7
PC6
VD D
VSS
PG7
PF2
PC2
PH0
PF10
PF9
PF8
PF7
PF6
VCAP1
PB11 PE12
PF4
PF1
PF0
VSS
PC9
PA8
PE2
PE3
PC1
PC0
NRST
PH1
PF11 PF12 PE13 PE9
PB1
PB2 PG1 VD D PA3
PE7
VSS
PD15
VD D
VSS
PF5
PA2
PA4 PE8
PE11
PD14
VSSA
VD D
PC3
PF3
PC15
VD D PE10
VD D
PD9
PB15
PB12
PB13
PB14
PD8
PD10
PD11
PD12
PD13
PA9
PA11
VD D
VSS
VCAP2
PA13
PA12
PA10
PG12
PG11 PG10
PG14
PG9
PD7
VSS
PD5
PB4
PB3
PG15
VD D
VSS
PG13
PB5
PB6
PD6
VD D
PD0
PC11
PA14
PA15
PC10 PC12
PD1 PD2 PD3
PD4
PB7
PB8
VD D
PDR_ O N
PE1 PE0
PB9
BOO T 0
101
VSS
U18
BAT 1
3000T R
OSC32_I N
OSC32_OU T
X5
25MHz
C111
22pF
C110
22pF
X4
32.768KH z
C108
10pF
C109
10pF
OSC32_I N
OSC32_OU T
O SC_ IN
OSC_OU T
VCC -3. 3V
VCC -3. 3V
VCC -3. 3V
C118 100nF
C123 100nF C124 100nF C125 100nF C126 100nF
C127 100nF
C130 10nF C131 1uF
C134 4.7uF
VCC -3. 3V
C115 100nF
C116 100nF
C117 100nF
C119 100nF
C120 100nF
C121 100nF C122 100nF
FP3
FERRIT E
VCC -3. 3V VCC-MMC
VCC-MMC
SD-CD#
C106
100nF
microSD
CA R D S LO T
3
8
1
2
4
5
6
7
DAT 3
CMD
+3.3 V
CLK
GN D
DAT 0
CD
GND
DAT 2
DAT 1
CN6
R79
10K
SD-DAT 0
SD-DAT 1
SD-DAT 2
SD-DAT 3
SD-CMD
SD-CLK
R80 27
R81 27
R82 27
R83 27
R84 27
R85 27
C152
22uF
STM32F407ZG
Figure 6-2: microSD Card Slot module connection schematic

The development system features a 7‘‘
TFT 800x480 display covered with a
resistive touch panel. Together they form
a functional unit called a touch screen,
(Figure 7-1).It enables data to be entered
and displayed at the same time. The TFT
display is capable of showing graphics in
262K die rent colors.
Figure 7-1: Touch Screen
7. Touch Screen
Page 20
