Texas Instruments TPS53915EVM-PWR587 User manual

User’s Guide
TPS53915 Step-Down Converter Evaluation Module User's
Guide
Table of Contents
1 Introduction.............................................................................................................................................................................2
2 Description.............................................................................................................................................................................. 2
2.1 Typical Applications............................................................................................................................................................2
2.2 Features............................................................................................................................................................................. 2
3 Electrical Performance Specifications................................................................................................................................. 2
4 Schematic................................................................................................................................................................................3
5 Test Setup................................................................................................................................................................................4
5.1 Test Equipment.................................................................................................................................................................. 4
5.2 Recommended Test Setup.................................................................................................................................................5
6 Configurations........................................................................................................................................................................ 6
6.1 PMBus Address Selection..................................................................................................................................................6
6.2 Mode Selection.................................................................................................................................................................. 6
6.3 VDD Pin Supply Selection..................................................................................................................................................6
7 Test Procedure........................................................................................................................................................................ 8
7.1 Line and Load Regulation and Efficiency Measurement Procedure.................................................................................. 8
7.2 PMBUS Setup and Verification.......................................................................................................................................... 8
7.3 Control-Loop Gain and Phase-Measurement Procedure.................................................................................................10
7.4 List of Test Points............................................................................................................................................................. 11
7.5 Equipment Shutdown....................................................................................................................................................... 11
8 EVM Assembly Drawing and PCB Layout.......................................................................................................................... 12
9 Bill of Materials..................................................................................................................................................................... 16
10 Revision History................................................................................................................................................................. 17
List of Figures
Figure 4-1. TPS53915EVM-PWR587 Schematic........................................................................................................................ 3
Figure 5-1. Tip and Barrel Measurement for VOUT Ripple............................................................................................................4
Figure 5-2. TPS53915EVM-587 Top Layer for Test Setup.......................................................................................................... 5
Figure 7-1. Select Device Scanning Mode.................................................................................................................................. 9
Figure 7-2. GUI for the Fusion Digital Power Designer............................................................................................................. 10
Figure 8-1. TPS53915EVM-587 Top-Layer Assembly Drawing.................................................................................................12
Figure 8-2. TPS53915EVM-587 Bottom-Layer Assembly Drawing........................................................................................... 12
Figure 8-3. TPS53915EVM-587 Top Layer, Copper.................................................................................................................. 13
Figure 8-4. TPS53915EVM-587 Layer Two, Copper................................................................................................................. 13
Figure 8-5. TPS53915EVM-587 Layer Three, Copper.............................................................................................................. 14
Figure 8-6. TPS53915EVM-587 Layer Four, Copper................................................................................................................ 14
Figure 8-7. TPS53915EVM-587 Layer Five, Copper.................................................................................................................15
Figure 8-8. TPS53915EVM-587 Bottom Layer, Copper............................................................................................................ 15
List of Tables
Table 3-1. TPS53915EVM-PWR587 Electrical Performance Specifications(1) ...........................................................................2
Table 6-1. PMBus Address Selection Settings............................................................................................................................ 6
Table 6-2. Mode Selection........................................................................................................................................................... 6
Table 6-3. Enable Selection......................................................................................................................................................... 7
Table 7-1. Test Point Functions..................................................................................................................................................11
Table 9-1. EVM Components List (Based on the Schematic, see Figure 4-1)...........................................................................16
Trademarks
D-CAP3™ is a trademark of Texas Instruments.
All trademarks are the property of their respective owners.
www.ti.com Table of Contents
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 1
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

1 Introduction
The TPS53915EVM-PWR587 evaluation module (EVM) uses the TPS53915 device. The TPS53915 device is a
D-CAP3™ mode, 12-A synchronous buck-converter with integrated MOSFETs. The device provides a fixed 1.2-V
output at up to 12 A from a 12-V input bus.
2 Description
The TPS53915EVM-PWR587 is designed for a regulated 12-V bus to produce a regulated 1.2-V output at up to
12 A of load current. The TPS53915EVM-PWR587 is designed to demonstrate the TPS53915 device in a typical
low-voltage application while providing a number of test points to evaluate the performance of the TPS53915
device.
2.1 Typical Applications
• Servers and storage
• Workstations and desktops
• Telecommunication infrastructure
2.2 Features
The TPS53915EVM-PWR587 features include the following:
• 12-A DC steady-state output current
• Support for a prebias-output voltage at start-up
• Jumper, J2, for enable function
• Jumper, J5, for auto-skip and forced-continuous-conduction-mode (FCCM) selection
• Jumper, J7, for extra 5-V input for further power saving purpose
• Convenient test points for probing critical waveforms
3 Electrical Performance Specifications
Table 3-1. TPS53915EVM-PWR587 Electrical Performance Specifications(1)
PARAMETER TEST CONDITIONS MIN TYP MAX UNITS
Input Characteristics
Voltage range VIN 5 12 18 V
Maximum input current VIN = 5 V, Io = 8 A 2.5 A
No load input current VIN = 12 V, IO = 0 A with auto-skip mode 1 mA
Output Characteristics
Output voltage VOUT 1.2 V
Output voltage regulation Line regulation (VIN = 5 V – 14 V) with FCCM 0.2 %
Load regulation (VIN = 12 V, IO = 0 A – 8 A) with FCCM 0.5 %
Output voltage ripple VIN = 12 V, IO = 8 A with FCCM 10 mVpp
Output load current 0 12 A
Output over current 15 A
Soft-start 1 ms
Systems Characteristics
Switching frequency VIN = 12 V, 1.2 V / 4 A 1000 kHz
Peak efficiency VIN = 12 V, 1.2 V / 8 A 88.5 %
Full load efficiency 86.9 %
Operating temperature 25 °C
(1) Jumpers set to default locations, See Section 6.
Introduction www.ti.com
2TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

4 Schematic
CLK
DATA
VREG
ALERT#
OPEN= ENABLE
VIN
PGND
VOUT
PGND
SW
PGOOD
ADDR/RF
TRIP
AGND
EN
VDD
MODE
CHB CHA
PMBus Connector
Input: 8-14V
Output: 1.2V/0-12A
Ext. VDD
LabView Connector
300k
R4
1.00k
R3
0
R5
1
1
2
2
PEC02SAAN
J2
1
2
3
4
5
6
7
8
9
10
PEC05DAAN
J4
100k
R14
100k
R1
3.01
R9
22uF
C1
22uF
C4
22uF
C3
0.1uF
C7
100k
R2
57.6k
R10
22uF
C2
0.1uF
C5
TP1
TP4
0
R8
TP7
TP9
TP3
TP6
TP2
100k
R15
C15
DNP
C16
DNP
R7
DNP
C17
DNP
C9
DNP
0
R19
1uF
C18
1uF
C20
10.0k
R20
10.0k
R21
10
R22
1
2
3
4
5
6
7
8
9
10
PEC05DAAN
J5
20.0kR11
150kR12
150kR13
TP5 TP8
TP10
TP11
TP12
22uF
C6
22uF
C10
22uF
C11
22uF
C12
22uF
C13
22uF
C14
22uF
C19
22uF
C21
22uF
C22
22uF
C23
1
1
2
2
ED120/2DS
J1
1
1
2
2
ED120/2DS
J3
TP13
200k
R6
1
122
1.0 uH
L1
11 22
DNP
L1A
DNP
TP14
TP15
470pF
C8
ADDR/RF
1
PGOOD
2
EN
3
VBST
4
NC
5
SW
6
SW
7
SW
8
SW
9
PGND 10
PGND 11
PGND 12
PGND 13
PGND 14
VIN 15 VIN 16 VIN 17
NC 18
VDD 19
VREG 20
MODE 21
AGND 22
FB 23
VO
24
TRIP
25
26
27
28
PWPD
29
TPS53915RVE
U1
1uF
C25
1uF
C26
1
2
3
4
5
6
7
8
9
10
PEC05DAAN
J6
1
R16
1
1
2
2
ED555/2DS
J7
C24
DNP
C27
DNP
VDD_19
VREG
VREG
VREG
VREG
VIN
VIN
VOUT
VOUT
VOUT
VOUT
VDD
VDD
VDD
SW
FB
FB
MODE
PGOOD
PGOOD
AGND
AGND
AGND
AGND
VIN
VOUT
PGND
AGND
PGND
PGND
FB
VREG
PGND
VREG
PGND
VOUT
PGND
MODE
AGND
AGND
AGND
VREG
PGOOD
FB
VOUT
VREG
VDD
VDD
PGOOD
VOUT
VIN
VDD
PGND
SW
SW
PGND
SW
1
TPS53513
NOTES:
PIN 26
PIN 27
PIN 28
TPS53515TPS53915
ALERT#
SDA
SCL
NC
GND1
GND2
NC
GND1
GND2
1
IC
VARIANT PIN-OUT FOR U1
TABLE 1
Figure 4-1. TPS53915EVM-PWR587 Schematic
www.ti.com Schematic
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 3
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

5 Test Setup
5.1 Test Equipment
Oscilloscope A digital or analog oscilloscope measures the output ripple. The oscilloscope must be set for
the following:
• 1-MΩ impedance
• 20-MHz bandwidth
• AC coupling
• 1-µs / division horizontal resolution
• 20-mV / division vertical resolution
Test points TP7 and TP9 measure the output ripple voltage by placing the oscilloscope probe
tip through TP7 and holding the ground barrel on TP9 as shown in Figure 5-1. Using a leaded
ground connection can induce additional noise due to the large ground loop.
Voltage Source The input voltage source VIN must be a 0 to 14-V variable-DC source capable of supplying 10
ADC. Connect VIN to J1 as shown in Figure 5-2.
Multimeters V1: VIN at TP1 (VIN) and TP4 (GND).
V2: VOUT at TP7 (VOUT) and TP9 (GND).
Output Load The output load must an electronic constant-resistance-mode load capable of 0 to 15 ADC at
1.2 V.
T 9P
T 7P
Metal Ground Barrel
Probe Tip
Figure 5-1. Tip and Barrel Measurement for VOUT Ripple
Recommended Wire Gauge:
1. VIN to J1 (12-V input)
• The recommended wire size is 1× AWG number 14 per input connection, with the total length of wire less
than four feet (2 feet input, 2 feet return).
2. J3 to LOAD
• The minimum recommended wire size is 2× AWG number 14, with the total length of wire less than four
feet (two feet output, two feet return).
Test Setup www.ti.com
4TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

5.2 Recommended Test Setup
Figure 5-2. TPS53915EVM-587 Top Layer for Test Setup
Input Connections:
1. Prior to connecting the DC input-source, VIN, TI recommends to limit the source current from VIN to 10-A
maximum. Ensure that VIN is initially set to 0 V and connected as shown in Figure 5-2.
2. Connect the voltmeter V1 at TP1 (VIN) and TP4 (GND) to measure the input voltage.
Output Connections:
1. Connect the load to J3 and set the load to constant-resistance-mode to sink 0-ADC before VIN is applied.
2. Connect the voltmeter V2 at TP7 (VOUT) and TP9 (GND) to measure the output voltage.
www.ti.com Test Setup
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 5
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

6 Configurations
All jumper selections must be made prior to applying power to the EVM. Configure this EVM using the following
configuration selections.
6.1 PMBus Address Selection
The PMBus address can be changed as shown in Table 6-1.
Table 6-1. PMBus Address Selection Settings
PMBus ADDRESS
RESISTOR DIVIDER RATIO (Ω) (RHIGH) (kΩ)
HIGH-SIDE
RESISTOR
(RLOW) (kΩ)
LOW-SIDE
RESISTOR
(RLOW/RLOW+RHIGH) MIN MAX
0011111 > 0.557 1 300
0011110 0.5100 0.4958 0.5247 160 165
0011101 0.4625 04482 0.4772 180 154
0011100 0.4182 0.4073 0.4294 200 143
0011011 0.3772 0.3662 0.3886 200 120
0011010 0.3361 0.3249 0.3476 220 110
0011001 0.2985 0.2905 0.3067 249 105
0011000 0.2641 0.2560 0.2725 249 88.7
0010111 0.2298 0.2215 0.2385 240 71.5
0010110 0.1955 0.1870 0.2044 249 60.4
0010101 0.1611 0.1524 0.1703 249 47.5
0010100 0.1268 0.1179 0.1363 249 36.0
0010011 0.0960 0.0900 0.1024 255 27.0
0010010 0.0684 0.0622 0.0752 255 18.7
0010001 0.0404 0.0340 0.0480 270 11.5
0010000 < 0.013 300 1
For different switching frequency setting, please change R3 and R4 as shown in Table 6-1.
6.2 Mode Selection
The MODE can be set by J5.
Table 6-2. Mode Selection
JUMPER SET TO: MODE SELECTION
1 to 2 pin shorted FCCM with 2× RC time constant
3 to 4 pin shorted(1) FCCM(2) with 1× RC time constant(1)
5 to 6 pin shorted FCCM(2) with 2× RC time constant
7 to 8 pin shorted Auto-skip mode with 2× RC time constant
9 to 10 pin shorted Auto-skip mode with 1× RC time constant
(1) Default setting
(2) The device enters FCCM after PGOOD goes high.
6.3 VDD Pin Supply Selection
The controller can be enabled and disabled by J7.
Configurations www.ti.com
6TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

Table 6-3. Enable Selection
SET ON CONNECTION ENABLE SELECTION
R19 = 0 Ω(1) VDD pin connected to VIN pins(1)
R19 = Open VDD pin disconnected to VIN pins
(1) Default setting: the VDD pin connected to the VIN pins through R19.
For power up, input J7 with proper voltage. The VDD pin input voltage range is from 4.5 V to 25 V.
www.ti.com Configurations
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 7
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

7 Test Procedure
7.1 Line and Load Regulation and Efficiency Measurement Procedure
1. Set up the EVM as described in Section 5 and Figure 5-2.
2. Ensure the load is set to constant-resistance mode and to sink at 0 ADC.
3. Ensure all jumper setting are configured as shown in Section 6.
4. Ensure the jumper provided in the EVM shorts on J2 before VIN is applied.
5. Increase VIN from 0 V to 12 V. Use V1 to measure input voltage.
6. Remove the jumper on J2 to enable the controller.
7. Use V2 to measure the VOUT voltage.
8. Vary the load from 0 ADC to 10 ADC, VOUT must remain in load regulation.
9. Vary VIN from 8 to 14 V, VOUT must remain in line regulation.
10. To disable the converter, place the jumper on J2.
11. Decrease the load to 0 A
12. Decrease VIN to 0 V.
7.2 PMBUS Setup and Verification
The TPS53915EVM-PWR587 contains a 10-Ω series resistor in the feedback loop for loop response analysis.
1. Download the Graphical User Interface (GUI) from www.TI.com.
2. Type fusion in the TI search bar.
3. Select FUSION_DIGITAL_POWER_DESIGNER from the search result.
4. Download and install the latest release version of the software. The most current version to date is version
1.8.325 of the Fusion Digital Power Designer.
5. Connect the USB Interface Adaptor EVM (see www.ti.com for more information) to J4 of the EVM. Ensure
that Pin 1 of the USB interface adaptor (red wire) is connected correctly to Pin 1 of J4 on the EVM.
6. Connect the USB wire of the USB interface adaptor to one of the USB ports on the computer tower.
7. Ensure that the EVM is powered up and connected to the USB interface adaptor before opening the Fusion
Designer GUI.
8. Double click the shortcut icon on the desktop for the Fusion Designer GUI. Use the online version.
9. Double click on the TPS40400, TPS4042x, ect (DEVICE CODE) from the Select Device Scanning Mode
window as shown in Figure 7-1.
10. When the GUI is loaded (see Figure 7-2), verify communication between the GUI and the EVM by changing
the frequency of the EVM.
Note
The TPS53915EVM is pre-set to a 400-KHz switching frequency.
11. Use the oscilloscope to monitor the switching frequency on the EVM on TP6.
12. Select a different frequency by clicking on the drop down box of the FREQUENCY_CONFIG:TPS53819
(TPS5391X).
13. Click on Write to Hardware and monitor the change of the switching frequency on the oscilloscope.
See the TPS53915 1.5 to 18 V (4.5 to 25 V bias) Input, 12-A Single Synchronous Step-Down SWIFT™
Converter Data Sheet for more information regarding PMBUS registers.
Test Procedure www.ti.com
8TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

Figure 7-1. Select Device Scanning Mode
www.ti.com Test Procedure
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 9
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

Figure 7-2. GUI for the Fusion Digital Power Designer
7.3 Control-Loop Gain and Phase-Measurement Procedure
The TPS53915EVM-PWR587 contains a 10-Ω series resistor in the feedback loop for loop response analysis.
1. Set up the EVM as described in Section 5 and Figure 5-2.
2. Connect the isolation transformer to the test points marked TP5 and TP8.
3. Connect the input-signal amplitude-measurement probe (channel A) to TP10. Connect the output-signal
amplitude-measurement probe (channel B) to TP11.
4. Connect the ground lead of channel A and channel B to TP15.
5. Inject around 20 mV or less signal through the isolation transformer.
6. To measure control-loop gain and phase margin, change the frequency from 100 Hz to 1 MHz using a 10-Hz
or less post filter.
7. Disconnect the isolation transformer from the bode-plot test points before making other measurements.
• Signal injection into feedback can interfere with the accuracy of other measurements.
Test Procedure www.ti.com
10 TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

7.4 List of Test Points
Table 7-1. Test Point Functions
TEST POINTS NAME DESCRIPTION
TP1 VIN Converter input supply voltage
TP2 VREG LDO voltage
TP3 PGOOD Power good output
TP4 PGND Power ground
TP5 CHB Input B for loop injection
TP6 SW Switch Node
TP7 VOUT VOUT terminal +
TP8 CHA Input A for loop injection
TP9 PGND Power ground
TP10 RF RF pin
TP11 TRIP TRIP pin
TP12 EN Enable pin
TP13 VDD VDD pin
TP14 MODE MODE pin
TP15 AGND Analog ground
7.5 Equipment Shutdown
Follow these steps when shutting down the equipment.
1. Shut down load
2. Shut down VIN
www.ti.com Test Procedure
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 11
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

8 EVM Assembly Drawing and PCB Layout
The following figures show the design of the TPS53915EVM-PWR587 printed circuit board (see Figure 8-1
through Figure 8-8). The EVM has been designed using a six-layer 2-oz copper-circuit board.
Figure 8-1. TPS53915EVM-587 Top-Layer Assembly Drawing
Figure 8-2. TPS53915EVM-587 Bottom-Layer Assembly Drawing
EVM Assembly Drawing and PCB Layout www.ti.com
12 TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

Figure 8-3. TPS53915EVM-587 Top Layer, Copper
Figure 8-4. TPS53915EVM-587 Layer Two, Copper
www.ti.com EVM Assembly Drawing and PCB Layout
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 13
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

Figure 8-5. TPS53915EVM-587 Layer Three, Copper
Figure 8-6. TPS53915EVM-587 Layer Four, Copper
EVM Assembly Drawing and PCB Layout www.ti.com
14 TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

Figure 8-7. TPS53915EVM-587 Layer Five, Copper
Figure 8-8. TPS53915EVM-587 Bottom Layer, Copper
www.ti.com EVM Assembly Drawing and PCB Layout
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 15
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

9 Bill of Materials
Table 9-1. EVM Components List (Based on the Schematic, see Figure 4-1)
DESIGNATOR QUANTITY VALUE DESCRIPTION PACKAGE REFERENCE PART NUMBER MANUFACTURER
C1, C2, C3, C4 4 22 µF Capacitor, Ceramic, 25 V, X5R, 10% 1206 GRM31CR61E226KE15L Murata
C5 1 0.1 µF CAP CER 0.1 µF 25 V 10% X5R 0402 0402 GRM155R61E104KA87D Murata
C6, C10, C11, C12,
C13, C14, C19,
C21, C22, C23
10 22 µF Capacitor, Ceramic, 6.3 V, X5R, 20% 1206 GRM31CR60J226KE19L Murata
C7 1 0.1 µF CAP CER 0.1 µF 50 V 10% X7R 0603 0603 GRM188R71H104KA93D Murata
C8 1 470 pF CAP CER 470 pF 50 V 10% X7R 0603 0603 GRM188R71H471KA01D Murata
C9, C17 0 Open Capacitor, Ceramic, 50 V, X7R, 10% 0603 Standard Standard
C15, C16, C24, C27 0 Open Capacitor, POSCAP, SMT, 2.5 V, 330 µF, 8 mΩ 7343(D) 2R5TPE330M9 or 6TPE330MIL Sanyo
C18, C20, C25, C26 4 1 µF CAP CER 1 µF 16 V 10% X7R 0603 0603 GRM188R71C105KA12J Murata
FID1, FID2, FID3,
FID4, FID5, FID6 0 Fiducial mark. There is nothing to buy or mount. Fiducial N/A N/A
J1, J3 2 ED120/2DS Terminal Block, 2-pin, 15-A, 5,1 mm 0.4 × 0.35 inch ED120/2DS OST
J2 1 PEC02SAAN Header, Male 2-pin, 100-mil spacing, 0.1 × 2 inch PEC02SAAN Sullins
J4, J5, J6 3 PEC05DAAN Header, Male 2×5-pin, 100-mil spacing 0.1 × 2 × 5 inch PEC05DAAN Sullins
J7 1 ED555/2DS Terminal Block, 2-pin, 6-A, 3,5 mm 0.27 × 0.25 inch ED555/2DS OST
L1 1 1 µH Inductor, Power Chokes SMD 6,6 × 7,1 mm PIMB065T-1R0MS Cyntec
L1A 0 DNP Inductor, High Fq Power, ±15% 0.283 × 0.433 inch 69P987xN Vitec
LBL1 1 Thermal Transfer Printable Labels, 0.650 (W) × 0.2 inch (H) — 10,000 per roll PCB Label
0.65 (H) × 0.2 inch (W) THT-14-423-10 Brady
R1, R2, R14, R15 4 100 k RES, 100 kΩ, 1%, 0.1 W, 0603 0603 CRCW0603100KFKEA Vishay-Dale
R3 1 1 k RES, 1 kΩ, 1%, 0.1 W, 0603 0603 CRCW06031K00FKEA Vishay-Dale
R4 1 300 k RES, 300 kΩ, 1%, 0.1 W, 0603 0603 RC0603FR-07300KL Yageo America
R5, R8, R19 3 0 RES, 0 Ω, 5%, 0.1 W, 0603 0603 CRCW06030000Z0EA Vishay-Dale
R6 1 200 k RES, 200 kΩ, 1%, 0.1 W, 0603 0603 CRCW0603200KFKEA Vishay-Dale
R7 0 Open Resistor, Chip, 1/16 W, 1% 0603 Standard Standard
R9 1 3.01 RES, 3.01 Ω, 1%, 0.125 W, 0805 0805 CRCW08053R01FKEA Vishay-Dale
R10 1 57.6 k RES, 57.6 kΩ, 1%, 0.1 W, 0603 0603 RC0603FR-0757K6L Yageo America
R11 1 20 k RES, 20.0 kΩ, 1%, 0.1 W, 0603 0603 CRCW060320K0FKEA Vishay-Dale
R12, R13 2 150 k RES, 150 kΩ, 1%, 0.1 W, 0603 0603 CRCW0603150KFKEA Vishay-Dale
R16 1 1 RES, 1 Ω, 1%, 0.1 W, 0603 0603 CRCW06031R00FKEA Vishay-Dale
R20, R21 2 10k RES, 10 kΩ, 1%, 0.1 W, 0603 0603 CRCW060310K0FKEA Vishay-Dale
R22 1 10 RES, 10 Ω, 1%, 0.1 W, 0603 0603 CRCW060310R0FKEA Vishay-Dale
TP1, TP2, TP3,
TP5, TP6, TP7,
TP8, TP10, TP11,
TP12, TP13, TP14,
TP15
13 5000 Test Point, Red, Thru Hole Color Keyed 0.1 × 0.1 inch 5000 Keystone
TP4, TP9 2 5001 Test Point, Black, Thru Hole Color Keyed 0.1 × 0.1 inch 5001 Keystone
U1 1 TPS53915RVE IC, High Performance, 12-A Single Sync. Step-Down Converter with PMBus. TPS53915RVE TI
Bill of Materials www.ti.com
16 TPS53915 Step-Down Converter Evaluation Module User's Guide SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

10 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Revision B (February 2014) to Revision C (November 2021) Page
• Updated the numbering format for tables, figures, and cross-references throughout the document. ................2
• Edited user's guide for clarity .............................................................................................................................2
• Changed user's guide title.................................................................................................................................. 2
Changes from Revision A (December 2013) to Revision B (February 2014) Page
• Changed the test points in the Tip and Barrel Measurement for VOUT Ripple image from TPS5 and TPS7 to
TPS7 and TPS9 (respectively from left to right)................................................................................................. 4
www.ti.com Revision History
SLUUAS2C – OCTOBER 2013 – REVISED NOVEMBER 2021
Submit Document Feedback
TPS53915 Step-Down Converter Evaluation Module User's Guide 17
Copyright © 2021 Texas Instruments Incorporated
All manuals and user guides at all-guidesbox.com

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.
All manuals and user guides at all-guidesbox.com

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
All manuals and user guides at all-guidesbox.com

www.ti.com
3
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.
All manuals and user guides at all-guidesbox.com
