Introduction to mikromedia™for PIC18FJ®
The mikromedia™for PIC18FJ®is a compact
development system with lots of on-board
peripherals which allow development of
devices with multimedia contents. The central
part of the system is a 8-bit PIC18F87J50
microcontroller. The mikromedia™for PIC18FJ®
features integrated modules such as stereo
MP3 codec, TFT 320x240 touch screen display,
accelerometer, USB connector, audio connector,
MMC/SD card slot, 8 Mbit flash memory,
2x26 connection pads and other. It comes
preprogrammed with USB bootloader, but can
also be programmed with external programmers,
such as mikroProg™or ICD2/3. Mikromedia is
compact and slim, and perfectly fits in the palm
of the hand, which makes it convenient platform
for mobile devices.

Page 5
mikromedia™for PIC18FJ®- pinout
VSYS RST
GND GND
RA2 L
RA5 R
RF2 RC1
RF5 RG0
RF6 RG3
RH4 RG4
RH6 RA3
RB0 RE1
RB1 RE2
RB2 RE3
RB3 RE4
RJ0 RE5
RJ1 RE6
RJ2 RE7
RJ3 RB6
RJ4 RB7
RJ5 RG2
RC0 RG1
RA4 RC7
RC3 RC6
RC4 RD6
RC5 RD5
3.3V 3.3V
GND GND
SPI LinesInterrupt LinesAnalog Lines
Digital lines I2C Lines UART lines PWM lines
Reset pin
5V power supply Reference Ground
Reference Ground leftch.
right ch.
3.3V power supply
3.3V power supply
Reference Ground
Reference Ground
Pin functions Pin functions
audio out
UART
I2C
SPI2
SCK2
SDI2
SDO2
RX
TX
SCL2
SDA2
Analog Lines
Interrupt Lines
PWM lines
Digital I/O lines
Digital I/O lines
Package Contains
01 02
04 05
03
06
Damage resistant
protective box
mikromedia™for PIC18FJ®
development system
mikromedia™for PIC18FJ®
user’s guide
mikromedia™for PIC18FJ®
schematics and pinout
Two 1x26 male headers
and one 1x5 header
USB cable

Page 6
Key Features
01
09
02
16
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
Connection Pads
TFT 320x240 display
USB MINI-B connector
CHARGE indication LED
LI-Polymer battery connector
3.5mm headphone connector
Power supply regulator
Serial Flash memory
RESET button
VS1053 Stereo mp3 coder/decoder
PIC18F87J50 microcontroller
Accelerometer
Crystal oscillator
Power indication LED
microSD Card Slot
ICD2/3 connector
mikroProg connector
17

Page 7
03
06
07
08
11
10
12
13
14
15
16
04 05
17
System Specication
power supply
Via USB cable (5V DC)
board dimensions
81.2 x 60.5 mm (3.19 x 2.38 inch)
weight
~45.5g (0.10lbs)
power consumption
52 mA with erased MCU (when back-light is ON)
CAUTION: Electrostatic Sensitive Device
Permanent damage may occur on devices subjected to high energy
electrostatic discharges which readily accumulate on the human
body or test equipment and can discharge without detection.
class B product
Product complies with the Class B limit of EN 55022 and can be used
in the domestic, residential, commercial and industrial environments.

Page 8
1. Power supply
You can apply power supply to the board
using MINI-B USB cable provided with
the board. On-board voltage regulators
provide the appropriate voltage levels
to each component on the board. Power
LED (GREEN) will indicate the presence of
power supply.
You can also power the board using Li-Polymer
battery, via on-board battery connector. On-board
battery charger circuit MCP73832 enables you to
charge the battery over USB connection. LED diode
(RED) will indicate when battery is charging. Charging
current is ~250mA and charging voltage is 4.2V DC.
Battery power supply
USB power supply
Figure 1-1: Connecting
USB power supply
Figure 1-2: Connecting Li-Polymer battery

Page 9
VCC-1.8VREF-1.8
E11
10uF
FP3
FERRITE
VCC-SYS VCC-3.3
E3
10uF
E4
10uF
R26
2K2
VCC-BAT
R44
3K9
Charging Current approx. 250mA
R39
4K7
VCC-3.3
E7 10uF C40
2.2uF
R34
4K7
R6
4K7
VCC-BAT
VSENSE
VCC-SYS
R37
10K
R36
10K
VCC-3.3
STAT
R38
10K
R45
1K
VCC-3.3
E5
10uF
R35
10K
VCC-3.3
C29
2.2uF
VCC-3.3
R46
100K
E10
10uF
R47
220K
VCC-1.8
VCC-1.8
R50
0R
1
2
3
5
4
Vin
GND
EN ADJ
Vout
U3
MIC5250-ADJ
R49
4K7
3
1
2
GND
Vin
Vout
REG1
LD29080DT33
VCC-BAT
LD1
GREEN
LD2
RED
1
2
CN1
BATT CONN
2
3
5
4
1STAT
VSS
VBAT VDD
PROG
U5
MCP73832
Q4
BC846
Q5
BC846
D1
PMEG3010ER
VCC-SYSVCC-BAT
VCC-USB
R43
10K
M1
DMP2160UW
DATA BUS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
HDR1
M1X26
HDR2
M1X26
VCC-3.3 VCC-3.3
VCC-SYS
VCC-USB
C28
10nF
FP2
FERRITE 1
2
3
4
5GND
ID
D+
D-
VBUS
CN3
USB MINIB
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
Figure 1-3: Power supply schematics

Page 10
2. PIC18F87J50 microcontroller
The mikromedia™for PIC18FJ®development system comes with
the PIC18F87J50 microcontroller. This high-performance 8-bit
microcontroller with its integrated modules and in combination
with other on-board modules is ideal for multimedia applications.
Key microcontroller features
- Up to 12 MIPS Operation;
- 8-bit architecture;
- 128KB of program memory;
- 3.904 bytes of RAM;
- 65 I/O pins;
- Internal Oscillator 8 MHz, 32 kHz;
- 2-UART, 2-SPI, 2-I2C, USB 2.0;
- DAC, ADC, etc.
Data/Memory Bus
Data Bus
PIC18FJ
12 MIPS 8-bit Core
- nanoWatt
- 48MHz
31 Level
Stack
Program
Counter
Instruction Data
PMP
Timers Comparators ADC
10-Bit EUSARTCCP MSSP
Flash
(Up to 128KB)
RAM
(Up to 3.9KB) VREG
Data
Address
Addresse
Decode
USB

Page 11
The microcontroller can be programmed in three ways:
3. Programming the microcontroller
01
02
03
Via USB HID mikroBootloader
Using mikroProg™external programmer
Using ICD2/3®external programmer
Figure 3-1:
PIC18F87J50
microcontroller

Page 12
Programming with mikroBootloader
Figure 3-2: USB HID mikroBootloader window
step 1 – Connecting mikromedia
01
01 In order to start, connect the USB cable or (if already
connected) press the Reset button on your mikromedia
board. Click the Connect button within 5s to enter the
bootloader mode, otherwise the existing microcontroller
program will be executed.
Microcontroller is preprogrammed with USB HID Bootloader, which
can be used to upload new device firmware. To transfer firmware
.HEX file from a PC to MCU you need to use mikroBootloader USB
HID application, which can be downloaded from:
Upon download, unzip it to desired location and start the mikro-
Bootloader application:
http://www.mikroe.com/downloads/get/1682/
mikrobootloader_pic18f87j50_v210.zip

Page 13
step 3 – Selecting .HEX le step 2 – Browsing for .HEX le
Figure 3-3: Browse for HEX Figure 3-4: Selecting HEX
01
02
01
01
02
01 Click the Browse for HEX button and from a
pop-up window (Figure 3.4) choose the .HEX le
which will be uploaded to MCU memory.
Select .HEX le using open dialog window.
Click the Open button.

Page 14
step 4 – Uploading .HEX le
Figure 3-5: Begin uploading Figure 3-6: Progress bar
01
01
01 01
In order to upload .HEX le click the
Begin uploading button.
.HEX le uploading can be monitored via progress bar.

Page 15
step 5 – Finish upload
Figure 3-7: Restarting MCU Figure 3-8: mikroBootloader ready for next job
01
01
Click the OK button after uploading is nished.
The board will be automatically reset and after 5
seconds your new program will be executed.

Page 16
The microcontroller can be programmed with mikroProg™
programmer and mikroProg Suite™for PIC®software. The
mikroProg™programmer is connected to the development
system via the CN6 connector, Figure 3-9.
mikroProg™is a fast
USB 2.0 programmer with
mikroICD™hardware In-Circuit
Debugger. Smart engineering allows
mikroProg™to support PIC10®, PIC12®, PIC16®,
PIC18®, dsPIC30/33®, PIC24®and PIC32®devices in
a single programmer. It supports over 570 microcontrollers
from Microchip®. Outstanding performance, easy operation and
elegant design are it’s key features.
Programing with mikroProg™
programmer
Figure 3-9:
Connecting mikroProg™to mikromedia™

mikroProg Suite™for PIC®Software
Figure 3-10: Main Window of mikroProg Suite™for PIC®programming software
mikroProg™programmer requires
special programming software called
mikroProg Suite™for PIC®. This
software is used for programming
of ALL Microchip®microcontroller
families, including PIC10®, PIC12®,
PIC16®, PIC18®, dsPIC30/33®, PIC24®
and PIC32®. Software has intuitive
interface and SingleClick™programming
technology. Just by downloading the
latest version of mikroProg Suite™
your programmer is ready to program
new devices. mikroProg Suite™is
updated regularly, at least four times a
year, so your programmer will be more
and more powerful with each new
release.
Page 17

Page 18
The microcontroller can be also
programmed with ICD2®or ICD3®
programmer. These programmers
connects with mikromedia board
via ICD2 CONNECTOR BOARD.
Programing with
ICD2®or ICD3®programmer
In order to enable the ICD2®and ICD3®programmers to be connected to the development system, it is
necessary to provide the appropriate connector such as the ICD2 CONNECTOR BOARD. This connector should
be first soldered on the CN5 connector. Then you should plug the ICD2®or ICD3®programmer into it, Figure 3-11.
Figure 3-11:
Connecting ICD2®
or ICD3®programmer

Page 19
Figure 3-12: mikroProg™and ICD2®/ICD3®programmer connection schematic
X1 8MHz
C2 22pF
C1 22pF
E9
10uF
PGD1
PGC1MCLR#
CLKO
CLKI
RA0/AN0
30 RA1 29 RA2 28 RA3 27
RA4
34 RA5 33
RB0 58
RB1 57
RB2 56
RB3 55
RB4 54
RB5 53
RB6 52
RB7 47
RC0
36 RC1 35
RC2 43
RC3 44
RC4 45
RC5 46
RC6
37
RC7
38
MCLR
9
OSC1 49
OSC2 50
GND
11
VCCcore/Vcap
12
VCC
32
RD0 72 RD1 69 RD2 68 RD3 67 RD4 66 RD5 65 RD6 64 RD7 63
RE0
4RE1
3
RE2 78 RE3 77
ENVREG
24 VUSB 23
RF2
18 RF3/D-
17 RF4/D+
16 RF5
15 RF6
14 RF7
13
RG0
5
RG1
6
RG2
7
RG3
8
RG4
10
RH0 79 RH1 80
RH2
1
RH3
2
RH4
22 RH5 21
RH6
20 RH7
19
RJ0 62 RJ1 61
RJ2 60
RJ3 59
RJ4
39
RJ5
40
RJ6 41
RJ7 42
VCC 48
VCC 71
GND
31
GND 51
GND 70
AGND
26 AVCC 25 RE4 76
RE5 75 RE6 74 RE7 73
U1
PIC18F87J50
VCC-3.3
Vcap
Vcap
ICD2/3
MCLR#
PGD1
PGC1
VCC-3.3
MCLR#
PGD1
PGC1
R14 100
R15 100
RB6
RB7
mikroProg
1
2
3
4
5
CN6
M1X5
1
2
3
4
5
6
CN5
M1X6
VCC-3.3

Page 20
Board is equipped with reset button, which is located at
the top of the front side (Figure 4-2). If you want to
reset the circuit, press the reset button. It will generate
low voltage level on microcontroller reset pin (input). In
addition, a reset can be externally provided through pin
27 on side headers (Figure 4-3).
4. Reset Button
Figure 4-2: Frontal reset button
Figure 4-1: Location of additional reset button
You can also solder additional reset button
on the appropriate place at the back side
of the board, Figure 4-1.
NOTE
