mikroElektronika RFid click MIKROE-1434 User manual

1. Introduction
Once you have soldered the headers your
board is ready to be placed into desired
mikroBUS™socket. Make sure to align the
cut in the lower-right part of the board
with the markings on the silkscreen at
the mikroBUS™socket. If all of the pins are
aligned correctly, push the board all
the way into the socket.
3. Plugging the board in
2 3
2. Soldering the headers
1
4. Essential features
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click™board, make sure
to solder 1x8 male headers to both left
and right side of the board. Two 1x8 male
headers are included with the board in
the package.
click
BOARD
www.mikroe.com
RFid click Manual
ver. 1.00
0 100000 024140
RFid click™is an accessory board in
mikroBUS™form factor. It’s a compact and
easy solution for adding RFid to your design.
It features CR95HF 13.56 MHz contactless
transceiver as well as trace antenna. RFid
click™communicates with the target board
microcontroller via mikroBUS™ UART (TX,
RX), SPI (MISO, MOSI, SCK, CS) INT, RST,
PWM and AN lines. The board is designed
to use 3.3V power supply only. LED diode
(GREEN) indicates the presence of power
supply.
RFid click
RFid click ™ with its CR95HF IC is a RFid
module with integrated transceiver for
contactless applications. The board contains
dedicated internal frame controller and analog
front end (AFE) for RF communications. It
supports ISO/IEC 14443 type A and B, ISO/IEC
15693 and ISO/IEC 18092 protocols (tags) as
well as the detection, reading and writing of
NFC forum type 1, 2, 3 and 4 tags.
Downloaded from DatasheetLib.com - datasheet search engine

8. Support
MikroElektronika oers Free Tech Support
(www.mikroe.com/esupport) until the
end of product lifetime, so if something goes
wrong, we are ready and willing to help!
7. Code Examples
.com
Once you have done all the necessary
preparations, it’s time to get your click™
board up and running. We have provided
the examples for mikroC™, mikroBasic™and
mikroPascal™compilers on our Libstock
website. Just download them and you are
ready to start.
VCC3.3
SSI0
SSI1AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
C6
10pF
C10
10pF
C8
1nF
C4
10nF
C3
4.7uF
C7
1uF
C11
100nF
1
2
3
4
5
6
7
8
9
10
11 12 13
TX1
TX2
NC
NC
RX1
RX2
NC
GND_RX
ST_R0
NC NC URX VPS
UTX
14 15 16
17
18
19
20
21
22
23
24
25 26 27 28 29 30
31 32
CS MISO
MOSI
SCK
SSI_0
SSI_1
ST_R1
GND
NC
NC
VPS_TX
GND_TX
XOUT
XIN
NC NC NC NC
CR95HF
U8 CR95HF
R1
10K
R2
3K3
X1
27.12MHz
C5 150pF
C15150pF
C13
220pF
C12
15pF
C9
N.M.
C14
N.M.
R27 330
R8 330
R4
N.M.
VCC3.3
C1
100nF
C2
10nF
VCC3.3
VCC3.3
VCC3.3
URX
UTX
SCK
MISO
MOSI
CS#
R3
100K
CS#
SCK
MISO
MOSI
J1
INT_O
TX
INT_O
INT_I
UTX
TX
J2
INT_I
RX
URX
RX
SSI1
SSI0
R5
3K3
VCC3.3
R6
3K3
VCC3.3
A
A
ANTENNA
FP1
FERRITE
R13
2K2
LD1
VCC3.3
R7 0
R10 0
R9
3K3
VCC3.3
B
B
MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.
Specication and information contained in the present schematic are subject to change at any time without notice. Copyright © 2013 MikroElektronika. All rights reserved.
6. SMD jumpers
5. RFid click™ Board Schematic
Two SMD jumpers are
provided on the board. In
case you want to use UART
interface, it is necessary
to solder SMD jumpers in
Bposition. Otherwise if you want to use
SPI interface, jumpers should be left in its
default position (A). In that case interrupt
pins (IN and OUT) are usable.
