mikroElektronika SmartGLCD User manual

user's guide to
SmartGLCD
240x128
Smart GLCD 240x128
represents development tool
and nal product specially
designed for graphical
applications which use PIC
microcontroller PIC18F8722

Page 3
I want to express my thanks to you for being interested in our products and for having
condence in Mikroelektronika.
The primary aim of our company is to design and produce high quality electronic products
and to constantly improve the performance thereof in order to better suit your needs.
The Microchip, Atmel, NXP and CYPRESS name, logo and products names are trademarks of Microchip, Atmel, NXP and CYPRESS Inc. in the U.S.A and other countries.
TO OUR VALUED CUSTOMERS
Nebojsa Matic
General Manager

Page 3
Introduction to SmartGLCD 240x128 4
Package contains 5
Key Features 6
System Specication 7
1. Connecting power supply 8
2. PIC18F8722 Microcontroller 9
Key microcontroller features 9
3. Programming with bootloader 10
Identifying device COM port 11
step 1 – Choosing COM port 11
step 2 – Connecting with a PC 12
step 3 – Browse for .hex le 12
step 4 – Select .hex le 13
step 5 – Uploading .hex le 13
step 6 – Progress bar 14
step 7 – Reset MCU 14
Tips and Tricks: Speed-up UART data transfer 15
4. Programing with external programmer 16
5. Touch Screen 18
6. microSD Card Slot 20
7. USB UART 22
8. Pinout 24
Dimensions 25
Table of Contents

Page 4
Page 5
The SmartGLCD 240x128 is a
full-featured development tool
for experimenting
with Graphical
LCD display.
Main advantage
of SmartGLCD is
resistive Touch Panel
which in combination with
Graphical LCD display makes
perfect tool for developing
devices which can be used
as control for home automation,
industrial equipment etc.
Microcontroller PIC18F8722 is a heart
of the SmartGLCD. It comes with preinstaled
bootloader program so you don’t need external
programer for MCU programming. To utilize MCU pins
SmartGLCD is equipped with marked pads.
Introduction to SmartGLCD 240x128

Page 4
Page 5
Package contains
01 02
05 05
03
06
Damage resistant
protective box
SmartGLCD 240x128
development tool
SmartGLCD 240x128
user’s guide
SmartGLCD 240x128
schematic
CD with documentation
and examples
USB cable
schematic
Compact development tool with on-board peripherals for
all-round graphical development on PIC18F8722
SmartGLCD
240x128
user's guide to
SmartGLCD
240x128
Smart GLCD 240x128
represents developmenttool
and nal product speci ally
designed for graphical
applications which use PIC
microcontroller
PIC18F8722

Page 6
Page 7
01
02 03
01
02
03
04
05
06
07
08
09
10
11
GLCD 240x128 display
RESET button
Power supply pads
I/O pads
Pads for mikroProg programmer
USB connector
Touch panel connector
Microcontroler PIC18F8722
Contrast potentiometer
mcroSD card slot
USB UART module
Key Features

Page 6
Page 7
08
10 11
06
07
09
04 05 power supply
Over a USB cable (5V DC)
weight
~200g (0.11 lbs)
board dimensions
140x90cm (5.51x3.24’’)
power consumption
~350mA in idle state
(backlight is ON)
System Specication

Page 8
Page 9
Connect the development system to a PC via a USB cable, Figure 1-1.
The GLCD display will be automatically turned on.
1. Connecting
power supply
Figure 1-1: Powering the
development system

Page 8
Page 9
The SmartGLCD development tool comes with the PIC18F8722
microcontroller. This 8-bit microcontroller with its integrated modules
and in combination with other on-board modules is ideal for creating
graphical applications..
2. PIC18F8722 Microcontroller
Key microcontroller features
- Up to 10 MIPS Operation;
- 8-bit architecture;
- 128KB of Flash memory;
- 3,936 bytes of RAM memory;
- 1024 bytes of EEPROM
- 80 pin TQFP;
- 16 ch, 10-bit ADC;
- UART, SPI, ; etc.
Data/Memory Bus
Data Bus
PIC18F
10 MIPS 8-bit Core
- nanoWatt
- Up to 40MHz
31 Level
Stack
Program
Counter
Instruction Data
I/O
Timers Comparators ADC
10-Bit EUSARTCCP MSSP
Flash
(Up to 128KB)
RAM
(Up to 3.9KB)
Data
Address
Addresse
Decode
BOR

Page 10
Page 11
3. Programming with bootloader
For programming, microcontroller use bootloader program which
is preinstaled in to MCU memory. To transfer .hex le from a PC
to MCU you need bootloader software (mikroBootloader) which
can be downloaded from:
After software is downloaded unzip it to desired location and
start mikroBootloader software.
http://www.mikroe.com/eng/products/view/443/
smartglcd-240x128-board/
Figure 3-1: mikroBootloader software
Connect SmartGLCD with a PC before
starting mikroBootloader software
note

Page 10
Page 11
Identifying device COM port
Figure 3-2: Identifying COM port
step 1 – Choosing COM port
Figure 3-3: Selecting COM port
02
03
04
01 Click on Change Settings button
Select USB COM port (in this case COM5)
Set Baud rate to 115200
Click OK button
In Device Manager you can see which COM port is
assigned to mikromedia (in this case COM5)
note
01
02
03
04

Page 12
Page 13
01 Click on Browse for HEX and from pop-up window (gure 3-6)
select .hex le which will be uploaded to MCU memory
step 2 – Connecting with a PC step 3 – Browse for .hex le
Figure 3-4: Connecting mikromedia with mikroBootloader
01
02
From drop down list Select MCU chose PIC18
Reset SmartGLCD and within 5s click on Connect button
Figure 3-5: Browsing for .hex le
02
01
01

Page 12
Page 13
Figure 3-6: Selecting .hex le
Figure 3-7: Begin uploading
step 4 – Select .hex le
01 Click on Begin uploading button to start .hex le transfer from
a PC to microcontroler
01 Select desired .hex le
Folder list
Click on Open button
03
02
step 5 – Uploading .hex le
01
03
02
01

Page 14
step 7 – Reset MCU
Figure 3-9: Uploading is nished
01 Click on OK button after uploading is nished. Reset MCU and
you can see product of your work
01
Figure 3-8: Bootloading progress bar
step 6 – Progress bar
01 Via progress bar you can monitor .hex le uploading process
01

Page 14
Page 15
01
02
03
04
Right click on USB Serial Port (COM5) and click on Properties
In USB Serial Port (COM5) Properties select Port Settings tab
Click on Advanced... button
Set latency Timer to 1 (or chose another value) and click on OK button
Tips and Tricks: Speed-up UART data transfer
If .hex le transfer from your PC to MCU
is to slow you can try to speed-up data
transfer by seting latency time of COM
port to 1. To change latency time go to
Device manager:
02
03
04
note
01

Page 16
Page 17
The microcontroller can be programmed with external programmer mikroProg.
The external programmer is connected to the development system via marked
pads CN3, Figure 4-1.
In order to connect the external programmer to the development system, it is
necessary to provide a 1x5 header that should be soldered to pads CN3.
If bootloader program is accidently erased you can upload it again via mikroProg
programmer. Program Bootloader18F8722.hex can be found under Firmware
folder (page 10).
4. Programing with
external programmer
Figure 4-1: Connecting
external programmer

Page 16
Page 17
mikroProg programmer can be also attached on the front side of
the SmartGLCD. Just solder 1x5 header to pads CN3. This is ideal
placment if you prefer using mikroProg
instead of bootloader.
Figure 4-2: Connecting
external programmer (GLCD side)
IDC10
connector
VCC MCU-VCC
MCU-PGD
MCU-PGC
MCU-MCLR
PGD-RB7
MCLR
PGC-RB6
Always use side with a knob of
IDC connector for connecting
with 1x5 header.

Page 18
Page 19
The development system features
a Graphical LCD 240x128 display
covered with a resistive touch panel.
Together they form a functional unit
called a touch screen. It enables data
to be entered and displayed at the same
time. The way of entering and displaying
data depends on the program loaded into
the microcontroller.
Resistive touch panel is suitable for
usage with a plastic pen which have
rounded tip. Finger press is always available
but bare in mind that you use touch
panel and there’s no need for too
much pressing force.
5. Touch Screen
Figure 5-1:
Touch Screen

Page 18
Page 19
TOUCH PANEL
VCC
PIC18F8722
RH1
RH5
RH4
RF1
RF0
AVCC
AGND
RA3
RA2
RA1
RA0
GND
VCC
RA5
RA4
RC1
RC0
RC6
RC7
RJ4
RJ5
RH0
RE2
RE3
RE4
RE5
RE6
RE7
RD0
VCC
GND
RD1
RD2
RD3
RD4
RD5
RD6
RD7
RJ0
RJ1
RH2 RJ2
RJ3
RB0
RB1
RB2
RB3
RB4
RB5
RB6
GND
OSC2
OSC1
VCC
RB7
RC5
RC4
RC3
RC2
RJ7
RJ6
RH3
RE1
RE0
RG0
RG1
RG2
RG3
MCLR
RG4
GND
VCC
RF7
RF6
RF5
RF4
RF3
RF2
RH7
RH6
VCC
VCC
VCC
VCC
GLCD-D2
GLCD-D3
LED-B
DRIVEA
DRIVEB
mRST#
GLCD-D7
GLCD-D6
GLCD-D5 GLCD-D4
LEFT BOTTOM
LED-G MMC-CS# UART-RX UART-TX
GLCD-RES# GLCD-MD
GLCD-FS
LED-R
RC3-SCK
RC4-MISO
RC5-MOSI
PGD
PGC
MMC-CD#
GLCD-CE#
GLCD-WR#
GLCD-RD#
GLCD-CD
RD6-SCK
RD5-MISO
SPI-MOSI
GLCD-D0 GLCD-D1
VCC
1K
1K
R34
R23
GLCD-FS
GLCD-MD
D1
BAT43
R22
1K
VCC
TOUCH PANEL
CONTROLLER
Q6
BC556
Q4
BC546
VCC
VCC
VCC
VCC
Q8
BC556
Q
BC546
5
R
1K
21
R
1K
15
R
1K
7
R
1K
14
R
1K
13
R
K
17
100
R
1K
18
R
1K
19
R
K
20
100
C6
100nF
C9
100nF
R
1K
26
Q
BC546
7
LEFT
TOP
RIGHT
BOTTOM
DRIVEB
DRIVEA
CN6
C5
100nF
VO
GLCD-CD
GLCD-RD#
GLCD-WR#
GLCD-D0
GLCD-D1
GLCD-D2
GLCD-D3
GLCD-D4
GLCD-D5
GLCD-D6
GLCD-D7
GLCD-CE#
GLCD-RES#
Vee
GLCD-MD
GLCD-FS
GLCD
CONTROLLER
RA6963
Figure 5-2-: Touch screen connection schematic

Page 20
Page 21
There is a
built-in microSD
card slot for microSD
cards provided on the
development system. It
enables the system to additionally
expand available memory space. The
Serial Peripheral Interface (SPI) is used for
communication between the microcontroller and
microSD card.
6. microSD Card Slot
Figure 6-2: Inserting
microSD card
Figure 6-1: microSD card
inserted in SmartGLCD
