mikroElektronika mikromedia+ for PIC32MX7 User manual

Amazingly compact, all-on-single-pcb development board carring 4.3’’ TFT
Touch Screen and lots of multimedia peripherals, all driven by powerful
PIC32MX795F512L microcontroller.
for PIC32MX7®
mikromedia+

Page 2
I want to express my thanks to you for being interested in our products and for having
condence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic products
and to constantly improve the performance thereof in order to better suit your needs.
TO OUR VALUED CUSTOMERS
Nebojsa Matic
General Manager
The PIC32®and Windows®logos and product names are trademarks of Microchip Technology®and Microsoft®in the U.S.A. and other countries.

Introduction to mikromedia+ for PIC32MX7®4
System Specication 4
Package Contains 5
1. Power Supply 6
2. PIC32MX795F512L Microcontroller 8
Key Microcontroller Features 8
3. Programming the Microcontroller 9
Programming with mikroBootloader 10
step 1 – Connecting mikromedia 10
step 2 – Browsing for .HEX le 11
step 3 – Selecting .HEX le 11
step 4 – Uploading .HEX le 12
step 5 – Finish upload 13
Programming with mikroProg™Programmer 14
mikroProg suite™for PIC®Software 16
Software Installation Wizard 17
4. Reset Button 18
5. Crystal Oscillators a nd 2.048V Reference 20
6. Port Expander 22
7. MicroSD Card Slot 24
8. Touch Screen 26
9. Audio Module 28
10. USB DEVICE Connection 30
11. USB HOST Connection 32
12. Accelerometer 34
13. Flash Memory 36
14. RF Transceiver 38
15. Ethernet Transceiver 40
16. Buzzer 42
17. Other Modules 44
18. Pads 46
19. mikromedia+ for PIC32MX7®SHIELD 48
20. Click boards are plug and play! 50
21. Dimensions 52
22. What’s next 53
Page 3
Table of Contents

Page 4
The mikromedia+ for PIC32MX7®is a compact development
system which allows development of devices with multimedia
contents. The central part of the system is a 32-bit 100-pin
PIC32MX795F512L microcontroller. The mikromedia+ for
PIC32MX7®feature lots of on board modules such as stereo
MP3 codec, 4.3’’ TFT 480x272 touch screen display, port
expander, accelerometer, microSD card slot, buzzer, IR receiver,
RGB LED diode, PIN photodiode, temperature sensor, 2.4GHz
RF transceiver, Ethernet transceiver, 8 Mbit ash memory,
Li-Polimer battery charger etc. The board also contains MINI-B
USB connector, power screw terminals, 2x5 mikroProg™
connector, two 1x26 connection pads, ON/OFF switch and
other. It comes pre-programmed with USB HID bootloader, but
can also be programmed with mikroProg™for PIC®, dsPIC®and
PIC32®external programmer. mikromedia is compact and slim,
and perfectly ts in the palm of your hand, which makes it a
convenient platform for mobile and other multimedia devices.
We have also prepared a mikromedia+ SHIELD for PIC32MX7®
extension board which enables you to easily expand the
functionality of your board.
Introduction to mikromedia+ for PIC32MX7®
System Specication
power supply
Via USB cable (5V DC) or via screw
terminals (5 - 12V DC)
power consumption
65mA with erased MCU
(when on-board modules are inactive)
board dimensions
119.54 x 78mm (4.71 x 3.07inch)
weight
~115g (0.253lbs)

Page 5
01 02
04 05
03
06
Damage resistant
protective box
mikromedia+ for PIC32MX7®
development system
mikromedia+ for PIC32MX7®
user’s guide
mikromedia+ for PIC32MX7®
schematic
DVD with documentation
and examples
USB cable and microSD card
Package Contains
Copyright ©2012 Mikroelektronika.
All rights reserved. MikroElektronika, MikroElektronika logo and other
MikroElektronika trademarks are the property of MikroElektronika.
All other trademarks are the property of their respective owners.
Unauthorized copying, hiring, renting, public performance
and broadcasting of this DVD
is strictly prohibited.
M
I
K
R
O
M
E
D
I
A
B
O
A
R
D
S
•
•
•
•
•
•
•
•
•
M
A
N
U
A
L
S
•
•
•
•
•
•
•
•
•
D
E
V
E
L
O
P
M
E
N
T
B
O
A
R
D
S
•
•
•
•
•
•
•
•
•
S
C
H
E
M
A
T
I
C
S
•
•
•
•
•
•
•
•
•
A
C
C
E
S
S
O
R
Y
B
O
A
R
D
S
•
•
•
•
•
•
•
•
•
E
X
A
M
P
L
E
S
•
•
•
•
•
•
•
•
•
A
D
D
I
T
I
O
N
A
L
S
O
F
T
W
A
R
E
•
•
•
•
•
•
•
•
•
C
O
M
P
I
L
E
R
S
•
•
•
•
•
•
•
•
•
M
I
K
R
O
C
,
M
I
K
R
O
B
A
S
I
C
,
M
I
K
R
O
P
A
S
C
A
L
C
O
M
P
I
L
E
R
S
•
•
•
•
•
•
•
•
•
D
R
I
V
E
R
S
•
•
•
•
•
•
•
•
•
P
R
O
G
R
A
M
M
E
R
S
A
N
D
D
E
B
U
G
G
E
R
S
•
•
•
•
•
•
•
•
•
PRODUCT DVD
www.mikroe.com
www.libstock.com

Page 6
1. Power Supply
Figure 1-2:
Battery power supply
Figure 1-3:
Screw terminals power supply
Figure 1-1:
USB power supply
The mikromedia+ for PIC32MX7® board can be powered in three dierent ways: via USB connector using MINI-B USB cable provided with
the board (CN4), via battery connector using Li-Polymer battery (CN5) or via screw terminals using laboratory power supply (CN3). After
you plug in the appropriate power supply turn the power switch ON (SW1). The USB connection can provide up to 500mA of current
which is more than enough for the operation of all on-board modules and the microcontroller as well. If you decide to use external power
supply via screw terminals, voltage levels must be within 5-12V DC range. Power LED ON (GREEN) indicates the presence of power
supply. On-board battery charger circuit MCP73832 enables you to charge the battery over USB connection or via screw terminals. LED
diode (RED) indicates when battery is charging. Charging current is ~250mA and charging voltage is 4.2V DC.

Page 7
CN3
Vusb_OUTVdc
Vbat_IN
CN5
R42
10K
R46
10K
R41
100K
L2
1.5uH
R43
1K
C66
22uF
C71
100nF
C70
10pF
C67
22uF
C68
22uF
R45
10K
R50
100K
L3
1.5uH
R52
12KC74
22uF
C77
100nF
C78
10pF
C75
22uF
C76
22uF
R53
4K7
VCC-5V
VCC-3.3V
VCC-5V
R38
10K
USB-PSW
E7
10uF
1
2
3
OUT
GND
IN
5
4OCEN
U6
TPS2041B
E8
10uF
E9
10uF
USB-D_N
USB-D_P
USB-ID
USB-VBUS
R47
1K
Vusb_IN
D5
B340A
D2
B340A
D4
PMEG3010ER
D3
PMEG3010ER
10
9
8
7
65
4
3
2
1
PG
VIN
L1
EN
PS
VAUX
GND
FB
L2
VOUT
PGND
U7
TPS63060
10
9
8
7
65
4
3
2
1
PG
VIN
L1
EN
PS
VAUX
GND
FB
L2
VOUT
PGND
U9
TPS63060
USB-D_N
USB-D_P
USB-ID
USB-VBUS
USB-PSW
R49
1M
R51
1M
R54
1M
BAT-VSENSE
R55
1K
C73
22uF
C69
22uF
LD1
R44
470
POWER
VCC-3.3V
1
2
3
4
5
GND
ID
D+
D-
VBUS
CN4
USB MINIB
C136
100nF
VIN
PWR-EN
PWR-EN
1
2
3
SW1
JS202011AQN
R29
100K
C72
1uF
C79
100nF
C140
10nF
C141
100pF
C142
1uF
C143
100nF
C144
10nF
C145
100pF
V_INPUT
FP5
VIN
VIN
M2
DMP2160UW
M1
DMP2160UW
1
23
R1
R2
Q1
PDTC114EU
BAT-VSENSE
USB-PSW
USB-VBUS
USB-D_N
USB-D_P
USB-ID
Vbat_IN
R62
3K9
Charging Current approx. 250mA
R57
1K
VCC-3.3V
E1210uF
R60
10K
R58
10K
VCC-3.3V
BAT-STAT
R61
10K
R59
1K
VCC-3.3V
R56
10K
VCC-3.3V
3
2
1 5
4
STAT
VSS
VBAT VDD
PROG
U12
MCP73832
Q3
BC846
Q4
BC846
C81
10uF
LD2
CHARGE
C80
2.2uF
VCC-5V
R104
10K
R105
1K
VCC-5V
M3
DMP2160UW
M4
DMG3420UV_INPUT
BAT-STAT
Figure 1-4: Power supply schematic

Page 8
The mikromedia+ for PIC32MX7® development board comes
with the 100-pin PIC32MX795F512L microcontroller. This
high-performance 32-bit microcontroller has integrated
modules, such as 512K of ash and 128K of RAM easily handling
demanding applications.
Key microcontroller features
2. PIC32MX795F512L Microcontroller
- Up to 125 DMIPS Operation (80MHz);
- 512K bytes of Flash memory;
- 128K bytes of RAM memory;
- up to 85 I/O pins;
- 16-bit timers;
- 8MHz internal oscillator, 32kHz RTCC, PLL;
- 6xUART, 4xSPI, 5xI2C, 2xCAN, ADC etc., and
- Ethernet, USB etc.
Bus Matrix
Peripherial Bus
PIC32
MIPS M4K 32-bit core
- 80MHz, 1.56 DMIPS/MHz
- 5 Stage Pipeline, 32-bit ALU
Trace 32-bit
HW
Mul/Div
32 Core
Registers
Shadow Set
JTAG
Instruction Data
RTCC
Analog
Comparators
(2)
I2C
(5)
16 Ch
10-bit
ADCs
UARTs
(6)
Input
Capture
(5)
SPI
(4)
Output
Compare
PWM(5)
16-bit
Timers
(5)
Prefetch
Buffer Cache Flash RAM Interrupt
Controller
GPIO
(85) VREG
DMA
8Ch
2-wire
Debug
USB
OTG
16-bit
Parallel
Port

Page 9
01
02
Using USB mikroBootloader
Using external mikroProg™for PIC®, dsPIC®, PIC32®programmer
Figure 3-1:
PIC32MX795F512L
microcontroller
The microcontroller can be programmed in two ways:
3. Programming the Microcontroller

Page 10
Microcontroller is pre-programmed with USB HID Bootloader,
which can be used to upload new device rmware. To transfer
rmware .HEX le from a PC to MCU you need to use mikroBoot-
loader USB HID application, which can be downloaded from:
Upon download, unzip it to desired location and start the mikro-
Bootloader application:
http://www.mikroe.com/downloads/get/2031/mikro-
media_plus_pic32mx7_bootloader.zip
01
02
Programming with mikroBootloader
Figure 3-2: USB HID mikroBootloader window
step 1 – Connecting mikromedia
01 In order to start, connect the USB cable or (if already
connected) press the Reset button on your mikromedia+
board. Click the Connect button within 5s to enter the
bootloader mode, otherwise the existing microcontroller
program will be executed.

Page 11
01
01
02
step 3 – Selecting .HEX le step 2 – Browsing for .HEX le
Figure 3-3: Browse for HEX Figure 3-4: Selecting HEX
01 Click the Browse for HEX button and from a
pop-up window (Figure 3.4) choose the .HEX le
that will be uploaded to MCU memory.
01
02
Select .HEX le from the Open dialog window.
Click the Open button.
01

Page 12
01
01
step 4 – Uploading .HEX le
Figure 3-5: Begin uploading Figure 3-6: Progress bar
01 01
In order to upload .HEX le click the
Begin uploading button.
.HEX le uploading can be monitored via progress bar.

Page 13
01
step 5 – Finish Upload
Figure 3-7: Restarting MCU Figure 3-8: mikroBootloader ready to use
01 Click the OK button after uploading is nished.
The board will be automatically reset and after 5
seconds your new program will be executed.
01

Page 14
The microcontroller can be programmed with external mikroProg™for PIC®, dsPIC®and PIC32®programmer and mikroProg Suite™
for PIC®software. The external programmer is connected to the development system via 2X5 mikroProg™connector, Figure 3-9.
mikroProg™is a fast USB 2.0 programmer with hardware Debugger support. It supports IC10®, PIC12®, PIC16®, PIC18®, dsPIC30/33®,
PIC24®and PIC32®devices from Microchip®. Outstanding performance, easy operation and elegant design are it’s key features.
Programming with mikroProg™Programmer
Figure 3-9:
mikroProg™
connector

Page 15
C133
1uF
C135
10nF
FP4
VCC-ADC VCC-3.3V
C134
100nF
VCC-3.3V
C114
100nF
C115
100nF
C116
100nF
VCC-3.3V
C111
100nF
C112
100nF
C113
100nF
75
74
73
72
71
70
69
68
67
66
64
65
63
62
61
60
59
58
57
56
55
54
53
52
51
50 49 48
47
46 45 44
43 42 41
40 39 38 37
36 35
34 33
32 31
30 29 28 27
26
9
11
12
4
3
78 77
24
23
18
17
16
15
14
13
5
6
7
8
10
79 80
1
2
22
21
20
19
25
76
PIC32MX795F512L
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
RB11 RB10 RB9
RB8
RB13 RB12
RE7
RC1
RC2
RC3
RD9
RD8
RA15
D+/RG2
RB15 RB14
RF8
VBUS
VUSB
D-/RG3
VSS
VDD
RA6
RG0 RG1
RE0
RF1 RF0
RD7 RD6
RE6
RE5
RE2
RG13
RG12
RG14
RE1
RA7
RG8
RA9
RB2
RB3
RB4
RB5
RE9
RE8
RD11
RD10
RF2
RF3
RG9
RG7
RG6
RA1
RE3 RE4
RG15
VDD
RB7 RB6
RB0
RB1
RF4 RF5
RA14
RA5
RD14 RD15
RA2
RF13
VDD
RA3
VDD
VDD
RA0
VDD
VSS
VSS
RF12
RA4
VSS
VCAP/VDDCORE
AVSS
AVDD
RA10
MCLR
RC4
OSC1/RC12
OSC2/RC15
RD0
RD3
RD1
SOSCI/RC13
SOSCO/RC14
VSS
RD2
RD12 RD13
RD4 RD5
U18
VCC-3.3V
MCLR#
HDR-AN4/PGC HDR-AN5/PGD
VCC-3.3V
C117
100nF
C124
1uF
C125
1uF
VCC-3.3V
C126
1uF
C127
10nF
C128
10nF
C129
10nF
E10
10uF
X5
32.768KHz
C109
22pF
C110
22pF
X4
16MHz
C107
22pF
C108
22pF
VCC-3.3V
HDR-AN4/PGC
HDR-AN5/PGD
MCLR#
1 2
3 4
5 6
7 8
9 10
CN7
VCC-ADC
Figure 3-10: mikroProg™connection schematic

Page 16
mikroProg Suite™for PIC®Software
The mikroProg™programmer requires
special programming software called
mikroProg Suite™for PIC®. It can be
used for programming all Microchip®mi-
crocontroller families, including PIC10®,
PIC12®, PIC16®, PIC18®, dsPIC30/33®,
PIC24®and PIC32®. Software has
intuitive interface and SingleClick™pro-
gramming technology. Download the
latest version of mikroProg Suite™
and your programmer is ready to pro-
gram new devices. mikroProg Suite™
is updated regularly, at least four
times a year, so your programmer will
be more and more powerful with each
new release.
Figure 3-11: Main window of mikroProg Suite™for PIC®programming software
PIC32
Page 16

Page 17
01
04
02
05
03
06
Start Installation
Choose destination folder
Accept EULA and continue
Installation in progress
Install for all users
Finish installation
Software Installation Wizard

4. Reset Button
Figure 4-1:
Reset button
The board is equipped with reset button, which is located on the front side of
the board. One press on the reset button will generate a low voltage level
on the microcontroller reset pin (input). Reset button can also be
externally provided through the pin 27 on the side headers.

Page 19
75
74
73
72
71
70
69
68
67
66
64
65
63
62
61
60
59
58
57
56
55
54
53
52
51
50 49 48 47 46 45 44 43 42
41
40
39
38 37 36 35
34
33 32 31 30
29
28 27 26
9
11
12
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79 80
1
2
22
21
20
19
25
76
PIC32MX795F512L
81
82
83 84 85
86 87 88
89
90 91 92 93
94
95
96
97
98 99
100
RB11
RB10 RB9
RB8
RB13
RB12
RE7
RC1
RC2
RC3
RD9
RD8
RA15
D+/RG2
RB15
RB14
RF8
VBUS
VUSB
D-/RG3
VSS VDD
RA6
RG0 RG1
RE0
RF1
RF0
RD7 RD6
RE6
RE5
RE2
RG13 RG12
RG14
RE1
RA7
RG8
RA9
RB2
RB3
RB4
RB5
RE9
RE8
RD11
RD10
RF2
RF3
RG9
RG7
RG6
RA1
RE3 RE4
RG15
VDD
RB7 RB6
RB0
RB1
RF4
RF5
RA14
RA5
RD14 RD15
RA2
RF13
VDD
RA3
VDD
VDD
RA0
VDD
VSS
VSS RF12
RA4
VSS
VCAP/VDDCORE
AVSS AVDD
RA10
MCLR
RC4
OSC1/RC12
OSC2/RC15
RD0
RD3
RD1
SOSCI/RC13
SOSCO/RC14
VSS
RD2
RD12
RD13
RD4 RD5
U18
VCC-3.3V
MCLR#
VCC-ADC
E10
10uF
VCC-3.3V
R69
10K
C99
100nF
RESET
T1
Vdc
HDR2
M1X26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
VCC-3.3V
C133
1uF
C135
10nF
FP4
VCC-ADC VCC-3.3V
C134
100nF
VCC-3.3V
C114
100nF
C115
100nF
C116
100nF
VCC-3.3V
C111
100nF
C112
100nF
C113
100nF
VCC-3.3V
C117
100nF
C124
1uF
C125
1uF
VCC-3.3V
C126
1uF
C127
10nF
C128
10nF
C129
10nF
X5
32.768KHz
C109
22pF
C110
22pF
X4
16MHz
C107
22pF
C108
22pF
Figure 4-2: Reset button connection schematic

Page 20
The board is equipped with 01 16MHz
crystal oscillator (X4) circuit that
provides external clock waveform
to the microcontroller OSC1 and OSC2
pins. This base frequency is suitable for
further clock multipliers and ideal for generation
of necessary USB clock, which ensures proper
operation of bootloader and your custom USB-based
applications. The board also contains 02 32.768kHz crystal
oscillator (X5) which provides external clock for internal RTCC
module. Microcontroller ADC requires an accurate source of reference
voltage signal. That is why we provide the external 03 voltage reference
to the microcontroller VREF pin which is 2.048V.
5. Crystal Oscillators and 2.048V Reference
01 02
Figure 5-1: Crystal oscillator
and 2.048V reference
03
03
01
02
