mikroElektronika mikroProg for PIC User manual

mikroProg
mikroProg™ is a fast USB programmer with mikroICD™
hardware In-Circuit Debugger support. Smart engineering
allows mikroProg to support PIC10, PIC12, PIC16, PIC18,
dsPIC30/33, PIC24 and PIC32 devices
in a single programmer!
for PIC®
™

Page 3
I want to express my thanks to you for being interested in our products and for having
condence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic products
and to constantly improve the performance thereof in order to better suit your needs.
The Microchip, Atmel, NXP, CYPRESS and Windows name, logo and products names are trademarks of Microchip, Atmel, NXP, CYPRESS and Windows Inc. in the U.S.A.
and other countries.
TO OUR VALUED CUSTOMERS
Nebojsa Matic
General Manager

Page 3
Introduction to mikroProg for PIC 4
Key features 5
1. Driver installation 6
step 1 – Start installation 7
step 2 – Accept EULA 7
step 3 – Installing the drivers 8
step 4 – Finish installation 8
2. Connecting to a PC 9
3. mikroProg Suite for PIC software 10
4. Powering device via mikroProg 11
5. Connecting with a target device 12
6. IDC10 Pinout 13
7. Connection examples 14
Using 1x5 male headers 14
Using 2x5 male headers 15
8. Multiplexer 16
Multiplexer in programming mode 17
Multiplexer in operating mode 17
9. Connection schematic examples 18
Connection examples - PIC 19
PIC DIP8 19
PIC DIP14 19
PIC DIP18 20
PIC DIP20 20
PIC DIP28 21
PIC DIP40 21
PIC TQFP 64 22
PIC TQFP 80 23
Connection examples - PIC18FJ 24
PIC18FJ DIP28 24
PIC18FJ QFN28 24
PIC18FJ DIP40 25
PIC18FJ TQFP44 26
PIC18FJ QFN44 26
PIC18FJ TQFP64 27
PIC18FJ TQFP80 28
PIC18FJ TQFP100 29
Connection examples - dsPIC 30
dsPIC DIP18 30
dsPIC TQFP44 30
dsPIC DIP28 31
dsPIC DIP40 31
dsPIC TQFP64 32
dsPIC TQFP80 33
Connection examples - PIC24 34
PIC24 DIP18 34
PIC24 DIP20 34
PIC24 DIP28 35
PIC24 TQFP44 35
PIC24 TQFP64 36
PIC24 TQFP80 37
PIC24 TQFP100 38
PIC24 TQFP100 39
Connection examples - PIC32 40
PIC32 TQFP64 40
PIC32 TQFP100 41
Table of Contents

Page 4
Page 5
mikroProg for PIC represents fast and reliable programmer with ICD support. Specially designed rmware allows programming of all
Microchip®microcontrollers: PIC, dsPIC and PIC32. And there’s no need for the rmware update each time you select a new microcontroller
architecture. With mikroProg™, single rmware takes care of all supported architectures. Supporting new microcontrollers is easy. Just by
downloading the latest version of mikroProg Suite™ your programmer is ready to program new devices.
Introduction to
mikroProg for PIC

Page 4
Page 5
Key features
- In-Circuit Debugging (ICD).
- Unique rmware for PIC, dsPIC and
PIC32 microcontrollers
- No need for rmware update
- New microcontrollers support via
latest version of mikroProg Suite
for PIC software
- Power supply for target device
01
02
03
04
05
06
07
Flat cable
USB MINIB connector
IDC10 connector
DATA transfer indication LED
ACTIVE indication LED
LINK indication LED
POWER indication LED
03
07
06
05
04
01 02

Page 6
Page 7
1. Driver installation
To install drivers for mikroProg for PIC go to download section on
MikroElektronika website or follow link below.
After download is complete extract les and begin installation:
Folder with extracted les contains folders with drivers for
dierent operating systems. Depending on which operating
system is in use chose adequate folder and open it. Under opened
folder is located setup le for driver installation. Double click on
setup le and begin installation.
http://www.mikroe.com/eng/downloads/get/1202/
mikroprog_for_pic_drivers_v200.zip

Page 6
Page 7
step 2 – Accept EULAstep 1 – Start installation
01 In welcome screen click on Next> button 01
02
In order to proceed select: I accept the this EULA
(End User License Agreement)
Click Next> button
01
01 02

Page 8
Page 9
step 3 – Installing the drivers step 4 – Finish installation
01 Drivers are installed automatically 01 Click on Finish button to end installation process
01
01

Page 8
Page 9
Figure 2-1: Connecting
USB MINIB cable
In order to use mikroProg for PIC connect it with
a PC via USB cable, Figure 2-1.
When connection is established green POWER LED will turn ON.
Amber-colored LINK LED will turn ON when link between mikroProg
and PC is established. Link can be established only when correct
drivers are installed on your PC.
2. Connecting to a PC

Page 10
Page 11
Program mikroProg Suite for PIC™ is intended
for programming PIC®, dsPIC® and PIC32®
microcontrollers from Microchip®. The graphic
interface of this program is clear and easy-to-use,
which makes the use of this program faster. The
program’s main window includes basic options
for programming microcontrollers. In addition,
there are advanced programming options that
enable experienced users to set conguration
bits on their own. The program includes views
providing basic information about the selected
MCU, voltage monitoring, etc.
3. mikroProg Suite
for PIC software

Page 10
Page 11
4. Powering device
via mikroProg
One of key benets on mikroProg is power supply mode which
can be activated from mikroProg Suite for PIC software. Under
mikroProg Suite for PIC window (MCU INFO button) you can set
power supply voltage in range from 1.8V to 5V with output current
up to 250mA. When you select MCU family under mikroProg Suite
for PIC window, mikroProg will automatically detect which MCU is
in use and it will set maximum power supply which can be used.
Voltage supply value can be set by moving slider under mikroProg
Suite for PIC window, Figure 4-1.
To enable power supply, rst set desired voltage and then click on
check box “Power board from programmer”. 01
03
02
Setting supply voltage value from 1.8 to 5V (max 250mA)
Check box for enabling supply voltage from programmer
Box with selected supply voltage
02
01 03
Figure 4-1: Voltage options

Page 12
Page 13
5. Connecting with
a target device
For connection with a target device mikroProg for PIC uses IDC10
connector, Figure 5-1. In order to make proper connection with the
target board it is necessary to pay attention to IDC10 connector
pinout. Every pin has a dierent purpose and for easy orientation
IDC10 connector is marked with a little knob and incision, Figure
5- 2. First pin on IDC10 is marked with colored wire on a at cable.
Front side of IDC10 connector is marked with a knob and incision.
Front side holds PGC, PGD and MCLR pins which are used for
microcontroller programming.
Figure 5-1: IDC10
connector
Figure 5-2: Knob
and incision for easy
orientation
First pin

Page 12
Page 13
Figure 6-1: IDC10 pinout
01
03
05
07
09 10
08
06
04
02
01
03
05
07
09
MCU-VCC (colored wire) - MCU power supply
MCU-PGC - Serial programming clock
MCU-PGD - ICSP data
MCU-MCLR - Master clear/Programming voltage
GND - Ground
6. IDC10 Pinout
02
04
06
08
10
VCC
PGC
PGD
MCLR
GND
These pins are used
for multiplexing (see
section 8.0 for more
information)

Page 14
Page 15
When connecting mikroProg with your device
via 1x5 header make sure to use front side of IDC10 connector (side with a knob and
incision), Figure 7-2. For example, if you use some of Mikroelektronika’s products
you may notice a clear markings for mikroProg IDC10
connector header, Figure 7-2.
For connecting mikroProg with your target device a best solution is to provide 1x5 or
2x5 male headers which are connected with programing pins on microcontroller.
When soldering header make sure that to use correct pinout for IDC10
connector.
7. Connection examples
Using 1x5 male headers
Figure 7-2: Connecting mikroProg to
SmartGLCD 128x240 via 1x5 male header
Figure 7-1: Use only front
row for programming

Page 14
Page 15
Instead of 1x5 male header you can use 2x5 male header.
Main dierence is that via 2x5 male connector you can use
multiplexing feature of mikroProg for PIC (explained in
section 8.0).
Figure 7-3: Use entire
IDC10 connector for
multiplexing feature
Figure 7-4: Connecting
mikroProg with Ready for PIC
via 2x5 male header
Using 2x5 male headers

Page 16
Page 17
8. Multiplexer
Multiplexer is specially designed circuit which serves as a switch.
Purpose of multiplexer is that there’s no need for disconnecting
mikroProg programmer from a device when programming is
over. Multiplexing is always available, but can only be used
with 2x5 male header on target board as shown on Figure 8-1.
Multiplexer allows the usage of programmable pins as I/O, in
non-programming mode.
While pins on MCU are separated from rest of the circuit
they can not be used as I/O. By connecting mikroProg to the
device programming is enabled and due to multiplexer when
programming is nished programmable pins can be used as I/O
without mikroProg removal, Figure 8-2.
VCC-MCU
MCU-VCC VCC
VCC-MCU
PIC16F887
OSC2
RC0
RC1
RC2
RC3
RD0
RD1
OSC1
GND
GND
RD7
RD6
RD5
RD4
RC7
RC6
RC5
RC4
RD3
RD2
VCC
MCLR
RA0
RA1
RA2
RA3
RA4
RA5
RE0
RE1
RE2
VCC
RB0
RB1
RB2
RB3
RB4
RB5
RB6
RB7
DIP40
R
R R
MCU-PGD
MCU-PGC
MCU-MCLR
PGD-RB7
MCLR
PGC-RB6
VCC-MCU
MCU-VCC
MCU-PGD
MCU-PGC
MCU-MCLR
VCC
VCC-MCU
PIC16F887
OSC2
RC0
RC1
RC2
RC3
RD0
RD1
OSC1
GND
GND
RD7
RD6
RD5
RD4
RC7
RC6
RC5
RC4
RD3
RD2
VCC
MCLR
RA0
RA1
RA2
RA3
RA4
RA5
RE0
RE1
RE2
VCC
RB0
RB1
RB2
RB3
RB4
RB5
RB6
RB7
DIP40
R
R R
PGD-RB7
MCLR
PGC-RB6
Figure 8-1: By placing 2x5
header programmable pins on
MCU will be separated from rest
of the circuit
VCC-MCU
MCU-VCC VCC
VCC-MCU
PIC16F887
OSC2
RC0
RC1
RC2
RC3
RD0
RD1
OSC1
GND
GND
RD7
RD6
RD5
RD4
RC7
RC6
RC5
RC4
RD3
RD2
VCC
MCLR
RA0
RA1
RA2
RA3
RA4
RA5
RE0
RE1
RE2
VCC
RB0
RB1
RB2
RB3
RB4
RB5
RB6
RB7
DIP40
R
R R
MCU-PGD
MCU-PGC
MCU-MCLR
PGD-RB7
PGC-RB6
Figure 8-2: mikroProg
is connected with
target board and
multiplexing is enabled
Figure 8-3: When mikroProg
is removed place jumpers
over 2x5 male header in
order to use programmable
pins as I/O

Page 16
Page 17
MCU-PGD
Multiplexer
PGD
PROG USB
VCC
MCU-VCCVCC
IDC10
connector
D+
GND
D-
mikroProg for PIC
MCU-PGC PGC
MCLR MCLR
MCU-VCCVCC
MCU-PGD
MCU-PGC
MCU-MCLR
PGD-RB7
MCLR
PGC-RB6
DATA
MCU-PGD
Multiplexer
PGD
PROG USB
VCC
MCU-VCCVCC
IDC10
connector
D+
GND
D-
mikroProg for PIC
MCU-PGC PGC
MCLR MCLR
MCU-VCCVCC
MCU-PGD
MCU-PGC
MCU-MCLR
PGD-RB7
MCLR
PGC-RB6
DATA
During programming, the multiplexer disconnects the
microcontroller pins used for programming from the target
device. This enables the programming process to be safely
performed without aecting the operation of the device itself. It
also prevents external signals from aecting the programming
process. When the programming process has been completed,
the multiplexer releases the microcontroller pins used for
programming so that they can be used as I/O pins.
When the programming process has been completed, the
multiplexer releases the microcontroller pins used for
programming, thus enabling them to be used as I/O pins. This
also enables the programmer to remain connected to the target
device without aecting its operation.
Figure 8-4: The
multiplexer in the
programming mode
Figure 8-5: The
multiplexer in the
operating mode
Multiplexer in programming mode
Multiplexer in operating mode

Page 18
Page 19
Following examples demonstrate
connections with some of the most
popular supported MCUs. For all other
MCUs consult manufacturer’s datasheet.
All PIC, dsPIC and PIC32 MCUs use PGC, PGD
and MCLR/Vpp pins for programming. Some MCUs
have several groups of programming pins. For example
dsPIC33FJ128GP710A has three pairs of programmable
pins PGED1-PGEC1, PGED2-PGEC2 or PGED3-PGEC3 (MCLR/Vpp
pin is same for all pin groups). Which ever group of programming
pins you decide to use, make sure to connect each pin properly.
9. Connection schematic examples
PGC - Serial programming clock
PGD - ICSP data
MCLR/Vpp - Master clear/Programming voltage
Also it is necessary to attach power supply to microcontroller VCC and GND pins.

Page 18
Page 19
RA0
RC0
RA5
RC5
GND
VCC
RA1
RC1
RA4
RC4
RA2
RC2
RA3
RC3
MCU-VCC VCC
RA0/MCU- PGD
RA1/MCU- PGC
MCU- MCLRRA3/
RA0PGD-
MCLR
RA1PGC-
1K
100nF
14 PIN
On-board
2x5 male
connector
PIC16F676
USER
INTERFACE
Figure 9-2: Connection schematic for
14-pin DIP MCU via 2x5 male header
Connection examples - PIC
GND
VCC
GP3
NC
NC
GP2
GP0
8 PIN
PIC10F200
GP1
MCU-VCC VCC
GP0/PGDMCU-
GP1/PGCMCU-
MCU-GP3/MCLR
GP0PGD-
MCLR
GP1PGC-
100nF
USER
INTERFACE
On-board
2x5 male
connector
Figure 9-1: Connection schematic for
8-pin DIP MCU via 2x5 male header
PIC DIP8
PIC DIP14

Page 20
Page 21
Connection examples - PIC
RA0
RC0
OSC1
RC5
GND
VCC
RA1
RC1
OSC2
RC4
RC6
RA2
RC2
RB4
RB5
RB6
MCLR
RC3
RC7
RB7
MCU-VCC VCC
RA0/MCU- PGD
RA1/MCU- PGC
MCU-MCLR
RA0PGD-
MCLR
RA1PGC-
1K
100nF
20 PIN
PIC16F631
On-board
2x5 male
connector
USER
INTERFACE
Figure 9-4: Connection schematic for
20-pin DIP MCU via 2x5 male header
PIC DIP20
PIC DIP18
RA0
VCC
RA3
GND
RA1
RA2
OSC1
RB7
RA4
RB0
RB2
OSC2
RB6
RB5
RB4
MCLR
RB1
RB3
MCU-VCC VCC
RB7/MCU- PGD
RB6/MCU- PGC
MCU-MCLR
RB7PGD-
MCLR
RB6PGC-
1K
100nF
18 PIN
PIC16F1220
On-board
2x5 male
connector
USER
INTERFACE
Figure 9-3: Connection schematic for
18-pin DIP MCU via 2x5 male header
