mikroElektronika mikromedia MIKROE-606 User manual

for dsPIC33®
mikromedia™
Compact development system rich with on-board peripherals for all-round
multimedia development on dsPIC33FJ256GP710A device.

I want to express my thanks to you for being interested in our products and for having
condence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic products
and to constantly improve the performance thereof in order to better suit your needs.
The dsPIC®and Windows®logos and product names are trademarks of Microchip Technology®and Microsoft®in the U.S.A. and other countries.
TO OUR VALUED CUSTOMERS
Nebojsa Matic
General Manager

Page 3
Introduction to mikromedia for dsPIC33®4
Package contains 5
Key features 6
System specication 7
1. Power supply 8
USB power supply 8
Battery power supply 8
2. dsPIC33FJ256GP710A microcontroller 10
Key microcontroller features 10
3. Programming the microcontroller 11
Programming with mikroBootloader 12
step 1 – Choosing COM port 13
step 2 – Choosing device family 14
step 3 – Choosing device 14
step 4 – Browse for .HEX le 15
step 5 – Set Baud rate 16
step 6 – Uploading .HEX le 16
Programming with mikroProg™programmer 18
mikroProg Suite™for PIC Software 19
Programming with ICD2 or ICD3 programmer 20
4. Reset buttons 22
5. Crystal oscillator 24
6. microSD card slot 26
7. Touch screen 28
8. Audio module 30
9. USB-UART connection 32
10. Accelerometer 34
11. Flash memory 36
12. Pads 38
13. Pinout 39
14. Dimensions 40
15. mikromedia accessories 41
What’s next? 42
Table of Contents

Page 4
Introduction to mikromedia for dsPIC33®
mikromedia for dsPIC33®is a compact
development system with lots of on-board
peripheralswhichallow development of devices
with multimedia contents. The central part of
the system is a 16-bit dsPIC33FJ256GP710A
microcontroller. mikromedia for dsPIC33
features integrated modules such as stereo
MP3 codec, TFT 320x240 touch screen
display, accelerometer, USB connector, audio
connector, MMC/SD card slot, 8 Mbit ash
memory, 2x26 connection pads and other. It
comes pre-programmed with UART bootloader,
but can also be programmed with external
programmers, such as mikroProg™or ICD2/3.
Mikromedia is compact and slim, and perfectly
ts in the palm of the hand, which makes it a
convenient platform for mobile devices.

Page 5
for dsPIC33®
mikromedia™
SCHEMATICS
We present you with a complete color schematics for mikromedia™for dsPIC33®
development board. We want you to know what your board is consisted of and
how it actually works.
mikromedia for dsPIC33®- pinout
SPI LinesInterrupt LinesAnalog Lines
Programming lines I2C Lines UARTlines PWMlines Comparator lines
5V RST Reset pin5V power supply
GND GND Reference GroundReference Ground
RB1 L
RB2 R
left ch.AN10
right ch.AN2/SS1/CN4
RB3 RD0 OC1AN3/CN5
RB4 RD1 OC2AN4/CN6
RB5 RD2 OC3AN5/CN7
RB8 RD3 OC4AN8
RB9 RD4 OC5/CN13AN9
RA12 RD5 OC6/CN14AN20/INT1
RA13 RD8 IC1AN21/INT2
RA14 RD9 IC2 INT3
RA15 RD14 IC7/U1CTS/CN20INT4
RB6 RD15 IC8/U1RTS/CN21PGEC1/AN6/OCFA
RB7 RD6 OC7/CN15
PGED1/AN7
RF6 RC2 AN17/T3CK/T6CKSCK1/INT0
RF7 RF12 U2CTSSDI1
RF8 RF13 U2RTSSDO1
RG15 RF0 C1RXCOFS
RG0 RF1 C1TX C2RX
RD10 RF2 U1RXIC3
RG6 RF3 U1TXSCK2/CN8
RG7 RG2 SCL1SDI2/CN9
RG8 RG3 SDA1SDO2/CN10
3.3V 3.3V 3.3V power supply3.3V power supply
GND GND Reference GroundReference Ground
Pin functions Pin functions
audio out
CAN
UART
I2C
SPI2
SPI1
Package contains
01 Damage resistant protective box
04 USB cable, two 1x26, one 1x6 and one 1x5 male headers
02 mikromedia for dsPIC33®development system
for dsPIC33®
mikromedia™
Compact development system rich with on-boardperipherals for all-round
multimedia development on dsPIC33FJ256GP710A device.
03 User’s guide, schematic and pinout

Page 6
Key features
16
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
Connection pads
TFT 320x240 display
USB MINI-B connector
CHARGE indication LED
LI-Polymer battery connector
3.5mm headphone connector
Power supply regulator
FTDI chip
Serial ash memory
RESET button
VS1053 Stereo mp3 coder/decoder
dsPIC33FJ256GP710A microcontroller
Accelerometer
Crystal oscillator
Power indication LED
microSD card slot
ICD2/3 connector
mikroProg connector
18
17
02
01

Page 7
03
06
07
08 09
1110
12 13
14
15 16
04 05
17 18
System specication
power supply
Via USB cable (5V DC)
board dimensions
81.2 x 60.5 mm (3.19 x 2.38 inch)
weight
~50g (0.11lbs)
power consumption
77 mA with erased MCU (when on-board modules are inactive)
CAUTION: Electrostatic sensitive device
Permanent damage may occur on devices subjected to high energy
electrostatic discharges which readily accumulate on the human
body or test equipment and can discharge without detection.
class B product
Product complies with the Class B limit of EN 55022 and can be used
in the domestic, residential, commercial and industrial environments.

Page 8
1. Power supply
You can apply power supply to
the board using MINI-B USB
cable provided in the package.
On-board voltage regulators
provide the appropriate voltage
levels to each component of
the board. Power LED (GREEN)
will indicate the presence of
power supply.
You can also power the board using a Li-Polymer
battery, via on-board battery connector. On-board battery
charger circuit MCP73832 enables you to charge the
battery over a USB connection. LED diode (RED) will
indicate when the battery is charging. Charging current
is ~250mA and charging voltage is 4.2V DC.
Battery power supply
USB power supply
Figure 1-1:
Connecting USB
power supply
Figure 1-2: Connecting Li-Polymer battery

Page 9
2
3
5
4
1
VCC-SYS VCC-3.3
E3
10uF E4
10uF
R26
2K2 3
1
2
GND
Vin
Vout
REG1
LD29080DT33
VCC-BAT
D1
PMEG3010ER
R44
3K9
Charging Current approx. 250mA
R39
4K7
VCC-3.3
E7
10uF
C40
2.2uF
R34
4K7
R6
4K7
VCC-BAT
VSENSE
VCC-SYS
VCC-SYS
R43
10K
R37
10K
R36
10K
VCC-3.3
STAT
R38
10K
R45
1K
VCC-3.3
E5
10uF
R35
10K
VCC-3.3
R49
4K7
+
-CN1
BATT CONN
M1
DMP2160UW
STAT
VSS
VBAT VDD
PROG
U5
MCP73832
Q4
BC846
Q5
BC846
C28
10nF
FP2
FERRITE 1
2
3
4
5GND
ID
D+
D-
VBUS
CN3
USB MINIB
VCC-USB
C29
2.2uF
VCC-3.3
R46
22K
E10
10uF
R47
120K
VCC-1.8
VCC-1.8
R50
0R
1
2
3
5
4
Vin
GND
EN ADJ
Vout
U3
MIC5205-ADJ
DATA BUS
LD2
CHARGE
LD1
POWER
VCC-BAT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
HDR1
M1X26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
HDR2
M1X26
VCC-3.3 VCC-3.3
VCC-SYS
VCC-1.8VREF-1.8
E11
10uF
FP3
FERRITE
Figure 1-3: Power supply schematics

Page 10
2. dsPIC33FJ256GP710A microcontroller
mikromedia for dsPIC33®development system comes with the
dsPIC33FJ256GP710A microcontroller. This high-performance
16-bit microcontroller with its integrated modules and in combination
with other on-board modules is ideal for multimedia applications.
Key microcontroller features
- Up to 40 MIPS Operation;
- 16-bit architecture;
- 256KB of program memory;
- 30.720 Bytes of RAM;
- 85 I/O pins;
- Internal Oscillator 7.37 MHz, 512kHz;
- nanoWatt features: Fast Wake/Fast Control;
- 2-UART, 2-SPI, 2-I2C, 2-CAN;
- DAC, ADC, etc.
Data/Memory Bus
Data Bus
40/60 MIPS 16-bit Core
- Optimal for ‘C’
- MCU + DSP Resources
40-bit
Accumulator
DSP
Engine
16 Core
Registers
16x16 Multiply
Shadow Set
Instruction Data
Motor
Control
PWM
32-bit
CRC
Audio
DAC
Control
DAC
10/12-bit
ADC
Analog
Comparator
I2C
CAN
UART
Input
Capture
SPI
Output
Compare
PWM
16-bit
Timers RTCC
PMP 32-bit
QEI
DMA
8 Ch.
Flash
(256KB)
RAM
(30KB) GPIO VREG
2-wire
Debug
Interrupt
Controller

Page 11
The microcontroller can be programmed in three ways:
01
02
03
Over UART bootloader
Using mikroProg™external programmer
Using ICD2/3 external programmer
3. Programming the microcontroller

Page 12
Programming with mikroBootloader
You can program the microcontroller with the bootloader which
is preprogrammed into the device by default. To transfer .HEX
le from a PC to MCU you need bootloader software (ds30
Loader) which can be downloaded from:
Upon download, unzip the le to the desired location and start
ds30 Loader software.
Figure 3-1: ds30 Loader open-source software
Connect mikromedia for dsPIC33®with a
PC before starting ds30 Loader software
www.mikroe.com/eng/downloads/get/1493/
mikrommb_dspic33_bootloader.zip
note

Page 13
Identifying device COM port
Figure 3-2: Identifying COM port
step 1 – Choosing COM port
Figure 3-3: Selecting COM port
01 From drop down list select USB COM port which is used
for communication with a PC (in this case COM5)
In Device Manager you can see which COM port
is assigned to mikromedia (in this case COM5)
01
note

Page 14
01 From drop down list select MCU chip (256GP710A)
step 2 – Choosing device family step 3 – Choosing device
Figure 3-4: Selecting MCU family
01 From drop down list select MCU family (dsPIC33FJ)
01
Figure 3-5:
Selecting MCU chip
01

Page 15
Figure 3-6: Browse for .HEX le
Figure 3-7: Pop-up window for .HEX le choosing
step 4 – Browse for .HEX le
01 Click on Browse button and from pop-up window (gure
3-7) select .HEX le which will be uploaded to MCU memory
01
03
02
01 Select desired .HEX le
Folder list
Click on Open button
03
02
step 3 – Choosing device
01

Page 16
step 6 – Uploading .HEX le
Figure 3-9: Write program
01 First RESET mikromedia and then, within 5s
click on Write button
01
Figure 3-8: Seting baud rate
step 5 – Set Baud rate
01 From drop down list set baud rate value to 256000
Check Write program check box
02
02 01

Page 17
Figure 3-11: Uploading is nishedFigure 3-10: Program uploading
0101 After uploading is nished you will get a
notice in ds30 Loader history window
Progress bar indicates .HEX le upload process
01
01
If you accidently erase bootloader program from MCU memory it is possible to load it again with external programer.
mikromedia for dsPIC33® bootloader rmware.hex le is located in Firmware subfolder, Page 12.
note

Page 18
Programming with mikroProg™programmer
Figure 3-12:
Connecting mikroProg™to mikromedia™
The microcontroller can be programmed with mikroProg™programmer and mikroProg Suite™fo PIC®software.
The mikroProg™programmer is connected to the development system via the CN6 connector, Figure 3-12.
mikroProg™is a fast USB 2.0
programmer with mikroICD™
hardware In-Circuit Debugger.
Smart engineering allows mikroProg™
to support PIC10®, PIC12®, PIC16®, PIC18®,
dsPIC30/33®, PIC24®and PIC32®devices in a single
programmer. It supports over 570 microcontrollers from
Microchip®. Outstanding performance, easy operation and
elegant design are it’s key features.

Page 19
mikroProg Suite™for PIC®software
mikroProg™programmer requires special
programming software called mikroProg
Suite™for PIC®. This software is used
for programming all Microchip®microcon-
troller families, including PIC10®, PIC12®,
PIC16®, PIC18®, dsPIC30/33®, PIC24®
and PIC32®. Software has intuitive
interface and SingleClick™programming
technology. Just by downloading the
latest version of mikroProg Suite™your
programmer is ready to program new
devices. mikroProg Suite™is updated
regularly, at least four times a year, so
your programmer will be more and more
powerful with each new release.
Figure 3-13: Main Window of mikroProg Suite™for PIC®programming software

Page 20
The microcontroller can be
also programmed with ICD2®
or ICD3®programmer. These
programmers connects with
mikromedia board via ICD2
CONNECTOR BOARD.
Programming with
ICD2®or ICD3®
programmer
In order to enable the ICD2®and ICD3®programmers to be connected to the development system, it is
necessary to provide an appropriate connector such as the ICD2 CONNECTOR BOARD. This connector should
be rst soldered on the CN5 connector. Then you should plug the ICD2®or ICD3®programmer into it, Figure 3-14.
Figure 3-15:
Connecting ICD2®
or ICD3®programmer
