mikroElektronika Shake2Wake click User manual

2 3
click
BOARDS™
www.mikroe.com
2. Soldering the headers
3. Plugging the board in
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the cut
in the lower-right part of the board with the
markings on the silkscreen at the mikroBUS™
socket. If all the pins are aligned
correctly, push the board all the
way into the socket.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click board™, make sure
to solder 1x8 male headers to both left and
right side of the board. Two 1x8 male headers
are included with the board in the package.
4. Essential features
Shake2Wake click has two main operating
modes: “measuring” and “wake-up” To use
it as a regular accelerometer, for continuous
sensing, use the Measurement mode.
Shake2Wake click outputs 12-bit resolution
data (8-bit also available). The “wake-up”
modeisforactivitydetection, ideal for motion
activated on/o switches. The detection
threshold is congurable (both intensity and
duration). The duration of inactivity that leads
to switching o is also programmable. In
wake-up mode, the power consumption drops
dramatically (270nA at 2V).
1
Shake2Wake click carries an ADXL362
ultralow power, 3-axis MEMS accelerometer
from Analog Devices. The distinguishing
feature of this IC is that it incorporates
several activity detection modes. The
interrupt pins from the chip are connected
to an onboard ADP195 power switch IC
that in turn controls an external device
connected through a screw terminal.
Otherwise, Shake2Wake click communicates
with the target MCU through mikroBUS™ SPI
interface. Uses 3.3V power supply only.
Shake2Wake click
1. Introduction
Shake2Wake click Manual v100
0100000089453

GND12
INT111
MOSI
6
GND13
NC
2
RSVD
3
GND 16
VDDI/O
1
SCLK
4
RSVD
5
MISO
7
CS
8
RSVD 10
INT29
NC 15
VS 14
U1
ADXL362
EN 4
VIN2 5 VOUT2
2
GND
3
VIN1 6 VOUT1
1
U2
ADP195
AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
R1
470
PWR
VCC_3V3VCC_3V3
VCC_3V3VCC_3V3
SCK
EN
MOSI MISO
CS
CS
MISO
MOSI
SCK
EN
V_OUT
CN1
V_OUT
C2
1uF
C1
100nF
VCC_3V3
EN
INT SEL.
INT1
INT2
INT1
INT2
VCC_3V3
C4
1uF
C3
100nF
VCC_3V3VCC_3V3
8. Code examples
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end of
the product’s lifetime, so if something goes
wrong, we’re ready and willing to help!
Once you have done all the necessary
preparations, it’s time to get your click board™
up and running. We have provided examples
for mikroC™, mikroBasic™and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
.com
6. Dimensions
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specication and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
mm mils
LENGTH 28.6 1125
WIDTH 25.4 1000
HEIGHT* 3.3 130
5. Schematic
7. Interrupt selection 10. Disclaimer
9. Support
25.4 mm / 1000 mils
28.6 mm / 1125 mils
* without headers
Shak2Wake
click
features
an INT SEL.
jumper for specifying which of the available
interrupt pins are utilized (the specied pin is
connected both to the onboard power switch
as well as to the mikroBUS™ socket).
