MiLAN MIL-S8001TG User manual

8-Port 10/100/1000 + 1 MiniGBIC Gigabit
Ethernet Smart Workgroup Switch
MIL-S8001TG
User Guide

Regulatory Approval
- FCC Class A
- UL 1950
- CSA C22.2 No. 950
- EN60950
- CE
- EN55022 Class A
- EN55024
Canadian EMI Notice
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numerique de la classe A respecte toutes les exigences du Reglement sur le materiel brouilleur du
Canada.
European Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive
(73/23/EEC) issued by the Commission of the European Community Compliance with these directives imply conformity
to the following European Norms:
EN55022 (CISPR 22) - Radio Frequency Interference
EN61000-X - Electromagnetic Immunity
EN60950 (IEC950) - Product Safety
Five-Year Limited Warranty
MiLAN Technology warrants to the original consumer or purchaser that each of it's products,
and
all components thereof, will be free from defects in material and/or workmanship for a
period of five years from the original factory shipment date. Any warranty hereunder is
extended to the original consumer or purchaser and is not assignable.
MiLAN Technology makes no express or implied warranties including, but not limited to, any
implied warranty of merchantability or fitness for a particular purpose, except as expressly set
forth in this warranty. In no event shall MiLAN Technology be liable for incidental or
consequential damages, costs, or expenses arising out of or in connection with the
performance of the product delivered hereunder. MiLAN Technology will in no case cover
damages arising out of the product being used in a negligent fashion or manner.
Trademarks
The MiLAN logo and MiLAN Technology trademarks are registered trademarks of MiLAN Technology in the
United States and/or other countries.
To Contact MiLAN Technology
For prompt response when calling for service information, have the following information ready:
- Product serial number and revision
- Date of purchase
- Vendor or place of purchase
You can reach MiLAN Technology technical support at:
E-mail: [email protected]m
Telephone: [phone]
Fax: [phone]
MiLAN Technology
1329 Moffett Park Drive
Sunnyvale, CA 94089
United States of America
Telephone: [phone]
Fax: [phone]
http://www.milan.com
[email protected]
© Copyright 2005 MiLAN Technology P/N: 90000xxx Rev. x

Table of Contents
1. Introduction
Features
Software Features
Package Contents
Ethernet Switching Technology
Management Methods
2. Hardware Description
Front Panel
LED Indicators
Rear Panel
Desktop Installation
Attaching Rubber Feet
Power On
3. Network Application
Small Workgroup
Segment Bridge
4. Console Management
Connecting a Terminal or PC to the Console Port
4-1. Main Menu
4-2. VLAN Mode
4-2-1. 802.1Q VLAN Configuration
4-2-1-1. Enabling 802.1Q VLAN
4-2-1-2. VLAN Configuration
4-2-1-3. Create VLAN Group
4-2-1-4. VLAN Status
4-2-2. Port-Based VLAN Configuration
4-2-2-1. Port-Based VLAN Group Configuration
4-3. QoS Control

4-4. Broadcast Storm Suppression
4-5. Restore to Default
4-6. Reset System
5. Troubleshooting
6. Technical Specifications

1
1.
Introduction
The MIL-S8001TG switch is a multi-port switch that can be used to build
high-performance switched workgroup networks. This switch is a
store-and-forward device that offers low latency for high-speed networking. The
switch is targeted at workgroup, department or backbone computing
environments.
Figure 1-1. The MIL-S8001TG switch
The 8-Port 10/100/1000 + 1 MiniGBIC Gigabit Ethernet Smart Workgroup Switch
features a “store-and-forward“ switching scheme. This allows the switch to
auto-learn and store source addresses in a 4K-entry MAC address table.
The MIL-S8001TG switch has 8 auto-sensing 10/100/1000 Base-TX RJ-45 ports
plus one MINI GBIC slot which enables long-distance connection.

2
Features
Conforms to IEEE 802.3 10BASE-T,IEEE 802.3u 100BASE-TX,IEEE
802.3ab 1000BASE-T,IEEE 802.3z gigabit fiber and IEEE 802.3x
8 x 10/100/1000 Base-TX RJ-45 ports
1 MINI GBIC socket for MINI GBIC Fiber transceiver
Auto-MDIX on all ports and N-Way Auto-Negotiation
16 Gbps back-plane
Quality of service (QoS) supported
IEEE802.3x Flow control
Back pressure half duplex (10/100Mbps)
Flow control full duplex (10/100/1000Mbps)
Store-and-Forward switching architecture
1.5Mbits memory buffer
Supports 9.5KB JUMBO packet
Supports Port-based VLAN and 4K 802.1Q Tag VLAN
Supports Broadcast Storm Filtering
4K MAC address table
Optional 19” rack mount kit
10” size for desktop and internal power

3
Software Features
VLAN Port Based VLAN, support up to 8 groups
4K IEEE802.1Q Tag VLAN
QOS 2 Types of quality of service: 1.Port based
priority. 2. 802.1p/TOS priority tag
Priority Queue
System provide 4 queues for High and Low
priority.
Queue Ratio: High:Middle:Low:Lowest =8:4:2:1
Broadcast Storm filter Disable or Enable
Package Contents
Unpack the contents of the package and verify them against the checklist
below.
MIL-S8001TG Switch
Power Cord
Four Rubber Feet
RS-232 cable
User Guide
Warranty Card
If any item is missing or damaged, please contact your local dealer for service.

4
Ethernet Switching Technology
Ethernet Switching Technology dramatically boosted the total bandwidth of a
network, eliminated congestion problems inherent with CSMA/CD (Carrier
Sense multiple access with Collision Detection) protocol, and greatly reduced
unnecessary transmissions.
This revolutionized networking. First, by allowing two-way, simultaneous
transmissions over the same port (Full-duplex), which essentially doubled the
bandwidth. Second, by reducing the collision domain to a single switch-port,
which eliminated the need for carrier sensing. Third, by using the
store-and-forward technology’s approach of inspecting each packet to intercept
corrupt or redundant data, switching eliminated unnecessary transmission that
slow the network. By employing address learning, which replaced the inefficient
receiving port.
Auto-negotiation regulates the speed and duplex of each port, based on the
capability of both devices. Flow-control allows transmission from a 100Mbps
node to a 10Mbps node without loss of data. Auto-negotiation and flow-control
may require disablement for some networking operations involves legacy
equipment. Disabling the auto-negotiation is accomplished by fixing the speed
or duplex of a port.
Ethernet Switching Technology supplied higher performance at costs lower
than other solutions. Wider bandwidth, no congestion, and the reduction in
traffic is why switching is replacing expensive routers and inefficient hubs as
the ultimate networking solution. Switching brought a whole new way of
thinking to networking.

5
Management Methods
The MIL-S8001TG switch series supports Console Management methods
Console Management is done through the RS-232 Console Port. Managing the
switch in this method requires a direct connection between a PC and the
switch.

6
2.
Hardware Description
Front Panel
The Front Panel of the MIL-S8001TG switch consists of eight
10/100/1000Base-TX RJ-45 ports, one MINI GBIC slot, one LED-Indicator for
Power, three LED-Indicators (100/1000, LNK/ACT, FDX/COL) for each UTP
port, and two LED-Indicators (LNK/ACT) for the Mini-GBIC slot.
Figure 2-1. Front panel for MIL-S8001TG
RJ-45 Ports (Auto MDI/MDIX): 8x 10/100/1000 N-way auto-sensing for
10Base-T, 100Base-TX or 1000Base-T connections.
[In general, MDI means connecting to another Hub or Switch while MDIX
means connecting to a workstation or PC. Therefore, Auto MDI/MDIX means
that you can connect to another Switch or workstation without changing
non-crossover or crossover cabling. ]
Mini GBIC slot: The optional MINI GBIC port is shared with port 1 and
supports 3.3V. There are 2 LED indicators for the Mini GBIC port – LNK and
ACT.

7

8
LED Indicators
The LED Indicators give real-time information of systematic operation status.
The following table provides descriptions of LED statuses and their meaning.
Figure 2-2. LED Indicators
LED Status Color Description
Power On Green Power On
On Green The port is operating at the speed of
1000Mbps.
On Orange The port is operating at the speed of
100Mbps.
100/1000
Off
The port is operating at the speed of
10Mbps mode or no device is
attached.
On Green The port is successfully connecting
with the device.
Blinks Green The port is receiving or transmitting
data.
LNK /ACT
Off No device attached.

9
On Orange The port is operating in Full-duplex
mode.
Blinks Orange Collision of Packets is occurring in
the port.
FDX /COL
Off The port is operating in Half-duplex
mode or no device attached.
LNK (MINI
GBIC) On Green The port is successfully connecting
with the device.
ACT (MINI
GBIC) Blinks Green The port is receiving or transmitting data.
Table 2-1. Description of LED Indicators

10
Rear Panel
The 3-pronged power plug and console port are located at the rear panel of the
MIL-S8001TG as shown in Figure 2-3. The switch will work with AC in the
range 100-240V AC, 50-60Hz.
Figure 2-3. The Rear Panel of MIL-S8001TG switch
Desktop Installation
Set the switch on a sufficiently large flat space with a power outlet nearby. The
surface where you put your switch should be clean, smooth, level and sturdy.
Provide enough clearance around the switch to allow attachment of cables,
power cord and air circulation.
Attaching Rubber Feet
A. Make sure the mounting surface on the bottom of the switch is grease and
dust free.
B. Remove adhesive backing from the rubber feet.
C. Apply the rubber feet to each corner on the bottom of the Switch.
These footpads can prevent the switch from shock/vibration.

11
Power On
Connect the power cord to the power socket on the rear panel of the switch.
Connect the other end of the cord to an appropriate power outlet. The internal
power supply in the switch works with AC in the voltage range of 100-240VAC
and frequency 50~60Hz.
Check the power indicator on the front panel to see if power is properly
supplied.

12
3.
Network Application
This section provides you a few samples of network topology in witch the Switch
is used. In general, the 8 Gigabit Copper with one MINI GBIC Smart switch is
designed as a segment switch. That is, with its address table (4000 MAC address)
and high performance, it is ideal for interconnecting networking segments.
PC, workstations, and servers can communicate each other by directly
connecting with 8 Gigabit Copper with one MINI GBIC Smart switch. The switch
automatically learns nodes address, which are subsequently used to filter and
forward all traffic based on the destination address.
By using Uplink port, the Switch can connect with another switch or hub to
interconnect other small-switched workgroups to form a larger switched network.
Meanwhile, you can also use fiber ports to connect switches. The distance
between two switches via fiber cable can be up to 220 or 550 meters (multi-mode
fiber) or 60 kilometers (single-mode fiber).
Small Workgroup
The MIL-S8001TG switch can be used as a standalone switch to which
personal computers, servers, and printer servers are directly connected to form
a small workgroup.

13
Segment Bridge
For enterprise networks where large data broadcasts are constantly processed,
this switch is an ideal solution for department users to connect to the corporate
backbone.
In the illustration below, two Ethernet switches with PCs, print server, and local
server attached, are both connect to the switch. All the devices in this network
can communicate with each other through the Switch. Connecting servers to
the Switch allow other users to access the data on server.
In the below illustration, two 8 Gigabit Copper with one MINI GBIC Smart
switch are used to interconnect two small workgroups. By using fiber ports to
connect switches, the distance between two switches via fiber cable can be up
to 2Km or 30Km (SC single-mode fiber connector).

14
4.
Console Management
Connecting a Terminal or PC to the Console Port
Console management involves the administration of the switch via a direct
connection to the RS-232 console port. This port is a female DB-9 connector.
From the main menu of the console program, the user has access to manage
the functions of the switch.
Use the supplied RS-232 cable to connect a terminal or PC to the console port.
The terminal or PC to be connected must support the terminal emulation
program.

15
After the connection between the Switch and PC is finished, turn on the PC and
run a terminal emulation program or Hyper Terminal and configure its
communication parameters to match the following default characteristics of
the console port:
Baud Rate: 9600 bps
Data Bits: 8
Parity: none
Stop Bit: 1
Flow Control: None
Figure 4-1. The settings of communication parameters
After you have entered the parameter settings, press the Enter Key and the
Main Menu of console management appears.

16
4-1. Main Menu
There are five items for selection as follows.
VLAN Mode: Configure the VLAN function.
QOS Control: Configure the QoS function.
Broadcast Storm Suppression:Enable or disable Broadcast Storm filtering
function.
Restore to Default: Set the system to the default value settings.
Reset System: Restart the system.
