Shinybow USA 8x2 MultiVideo To VGA Switcher Series User manual

Instruction Manual
Part No.: ENCL003866000A0
Thank you for purchasing the SB-3866 MultiVideo To VGA Switcher. You will find this unit easy to install
and highly reliable but it is essential that you read this manual throughly before attempting to use 8x2
Multivideo To VGA Switcher.
8x2 MultiVideo To VGA Switcher Series
8x2 MultiVIDEO TO VGA SWITCHER
M U LT I M E D I A A U D I O A N D V I S U A L
MODEL : SB-3866

SAFETY INFORMATION
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL
1. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original
factory packing.
2. Read all documentation before operating your equipment. Retain all documentation for future reference.
3. Follow all instructions printed on unit chassis for proper operation.
4. Do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
5. Make sure power outlets conform to the power requirements listed on the back of the unit.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not likely to be walked on
or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit
7. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the means of grounding of
a piece of equipment is not defeated.
8. Mains voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC voltage is not covered by
any warranty.
9. Power down & disconnect unit from mains voltage before making connections.
10. Never hold a power switch in the ＂ON＂position.
11. Do not use the unit near stoves, heat registers, radiators, or other heat Producing devices.
12. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal flow of air around the unit,
13.
such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky environment, the unit should be
Periodically ＂blown free＂of foreign matter.
14.
Do not remove the cover. Removing the cover will expose you to potentially dangerous voltages. There are no user serviceable parts inside.
15.
Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
16.
Non-use periods. The power cord of equipment should be unplugged from the outlet when left unused for a long period of time.
Service Information Equipment should be serviced by qualifier service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
from the appliance.
IMPORTANT SAFETY INSTRUCTIONS
To insure the best from this product, please read this manual carefully. Keep it in a safe place for future reference.
To reduce the risk of electric shock, do not remove the cover from the unit. No user serviceable parts inside. Refer servicing to qualified personnel.
To reduce the risk of fire, do not expose the unit to rain, water or excessive moisture.
Do not force switched or external connections.
When moving the unit disconnect the serial port connections first then the power cable and finally the interconnecting cables to other devices.
Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Use a clean dry cloth.
Installation of this unit should be in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold.

PAGE 3SB-3866 INSTRUCTION & OPERATION MANUAL
INTRODUCTION AND TABLE OF CONTENTS
3
IR EXTENDER
4
5
6
7
This symbol is intended to alert the user to the presence of uninsulated
enclosure tha may be of sufficientmagnitude to constitue a risk of
electric shock to persons.
This symbol is intended to alert the user to the presence of important
operational and maintenance (serving) instructions in the literature
accompanying the appliance.
T prevent electric shock do not use this (polarised) plug with ano
extension cord, receptacle or other outlet unless the blades can
be fully inserted to prevent blade exposure.
T prevent electric shock, match wide blade of plug to wide slot,o
fully insert.
Caution:
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK),
NO USER SERVICEABLE PARTS INSIDE,
REFER SERVICING TO QUALIFIED SERVICE PERSONAL.
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
T
I
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. .
RISK OF ELECTRIC SHOCK
DO NOT OPEN
FRONT PANEL
REAR PANEL
REMOTE CONTROL
INTRODUCTION
of uninsulated “dangerous voltage” within the products enclosure that
RS-232 SERIAL INTERFACE 8
RS-232 PROTOCOL COMMANDS 9
INSTALLATIONS 10
FEATURES & SPECIFICATIONS 11
The SB-3866 is a 8:1 Multi-Video Routing Switcher
featuring 8 inputs and pre-emphasized 2 outputs.
> 8 inputs as following :
2 x Composite Video+Audio
2 x S-Video+Audio,
2 x Component Video+Audio,
2 x VGA+Audio,
> 2 same signal outputs as following :
2 x VGA+Audio
Automatic input TV standard system detection :
> NTSC 3.58 / NTSC-EIAJ / NTSC 4.43
> PAL / PALM / PAL-N / PAL-COMB-N/PAL-60
> SECAM
This switcher suppors full data rates and enabling
input HDMI 480p, 720p or 1080i/p formats. PC
resolution (1920 x 1200HD) is ideally suitable for
high Definition LCD Television, HDTV, Plasma
display or Monitor applications.
Control is provided via Front panel buttons with LED
readout, IR remote control, or RS-232..
A RS-232 interface is provided for interfacing with
a third party controller.
OSD FUNCTION SETUP 12~17
LIMITED WARRANTY 18

PAGE 4 SB-3866 INSTRUCTION & OPERATION MANUAL
FRONT PANEL
1
FRONT PANEL
3
3
2
POWER ON SWITCH
SOURCE SELECT BUTTONS
1
3
The power switch turns the unit on and off.
The LED will illuminate red to indicate
that the switcher is ON and is receiving power
INPUT SOURCES DISPLAY
2
Input sources 1 to 8 LED illuminates green to
indicate that a video source is present on that input.
A separate output 1 and 2 source select buttons
are provided for each destination.
IR SENSOR
4
The IR sensor receives IR commands from the
supplied remote controller.
SELECT VGA RESOLUTION BUTTONS
5
VGA output resolutions via selection buttons.
LINE DISPLAY
7
Optional function for unit line to another unit.
ADJUST AUDIO OUTPUT VOLUME
8
Adjust output Audio Volume via LED display.
OSD CONTROL
6
Adjust OSD on display via display screen.
1 2 3 4 5 6 7 8
IRIR
CV-1 CV-2 SV-1 SV-2 YUV-1 YUV-2 VGA-1 VGA-2
POWER
SELECT
ENTER
SVGA XGA SXGA
800 -60 0 1024-768 1280-1024
VGA
640 -48 0
WSX GA
1366-768 1680-1050 1920-1200
WXGA WUXGA
MULTIVIDEO SWITCHER
Video-S-Video-Component-VGA Multiple To WUXG A
SB-3866MRM
Audio Value
8:28:2
Line
VGA OUTPUT RES OLUTION S ELECT
45678
# Input 1 - Composite Video / Stereo Audio
# Input 2 - Composite Video / Stereo Audio
# Input 3 - S-Video / Stereo Audio
# Input 4 - S-Video / Stereo Audio
# Input 5 - Component Video (YPBPR) / Stereo Audio
# Input 6 - Component Video (YPBPR) / Stereo Audio
# Input 7 - VGA (RGBHV) / Stereo Audio
# Input 8 - VGA (RGBHV) / Stereo Audio
# 1 - VGA Resolution : 640 x 480
# 2 - SVGA Resolution : 800 x 600
# 3 - XGA Resolution : 1024 x 768
# 4 - SXGA Resolution : 1280 x 1024
# 5 - WXGA Resolution : 1366 x 768
# 6 - WSXGA Resolution : 1680 x 1050
# 7 - WUXGA Resolution : 1920 x 1200

IN PUT- 1
INPUT- 2
INPUT- 3
INPUT- 4
VI DEOALAR
VIDEO
ALAR
ALAR
ALAR
ALAR
ALAR
SV
SV
IN PUT- 5
INPUT- 6
PR
PR
ALAR
ALAR
PB
PB
Y
Y
RS 232
IN PUT- 7
INPUT- 8
OUTPUT- 1
OUTPUT- 2
ALAR
ALAR
ALAR
ALAR VGA
VGA
AUDIO
AUDIO VGA
VGA
INPUT
AU DIO
AUDIO
MULTIVIDEO SWITCHER
SB-3866 RoHS/95/EC
DC 12V
IR EXT.
PAGE 5SB-3866 INSTRUCTION & OPERATION MANUAL
1
REAR PANEL
REAR PANEL
678 9 10
2x VGA-AUDIO OUTPUTS
2x OD3.5mm AUDIO OUTPUTS
INPUT 7& 8 VGA-AUDIO INPUTS
1
2
Two VGA-Audio outputs are same picture
via RCA connector is provided for Audio ouput
via DB-15p connector for VGA output
Provided 2x same Stereo Audio outputs. Audio
Source from VGA series ports input 7&8 only.
INPUT 7& 8 AUDIO with OD3.5mm Jack
3
4
Input 7 is a stereo audio(AR/AL) via OD3.5mm phone jack
INPUT 5& 6 COMPONENT-AUDIO INPUTS
5
INPUT- 3&4 S-VIDEO INPUTS
RS 232 CONTROL
6
INPUT- 1&2 COMPOSITE-AUDIO INPUTS
7
8
RS 232 control port to allow for interfacing to a
PC.
IR EXTENDER CONTROL
9
DC POWER INLET
10
The SB-3866 is fitted with a DC power plug-park
input connector. Please ensure that the plug-park
used is of an approved type and is of sufficient
current carrying capacity with the correct voltage
and connector polarity. 12Volt DC power supply
2A Max.
Support VGA(RGBHV) & Stereo Audio Inputs
Support input 5 & input 6 Component(YP BPR)/Stereo Audio.
Support S-Video / Audio via Input 3 and input 4
IR Extender for 300M extend distance.
2 53 4
4
# Output 1 - VGA-RGBHV / Stereo Audio
# Output 2 - VGA-RGBHV / Stereo Audio
# Input 7 - VGA-RGBHV via 1x DB-15p connector
- Stereo Audio via 2x RCA connectors
# Input 8 - VGA-RGBHV via 1x DB-15p connector
- Stereo Audio via 2x RCA connectors
Input 8 is a stereo audio(AR/AL) via OD3.5mm phone jack
Support 2x Audio via OD3.5mm Jack input 7&8 to Output port.
# Input 5 - Component(YPBPR)via 1x RCA connectors
- Stereo Audio via 2x RCA connectors
# Input 6 - Component(YPBPR)via 1x RCA connectors
- Stereo Audio via 2x RCA connectors
# Input 3 - S-Video (Y/C) via 1x Mini din-4 Female connector
- Stereo Audio via 2x RCA connectors
# Input 4 - S-Video (Y/C) via 1x Mini din-4 Female connector
- Stereo Audio via 2x RCA connectors
Support Composite Video / Stereo Audio via Input 1 and input 2
# Input 1 - Composite Video via 1x RCA connectors
- Stereo Audio via 2x RCA connectors
# Input 2 - Composite Video via 1x RCA connectors
- Stereo Audio via 2x RCA connectors

1
MULTIVIDEO SWITCHER
SW-3866
POWE R
2
3
4
5
6
7
8
Menu
Exit
ENTERENTER
1280x1024
1366x768
1680x1050
1920x1200
Audi o Vol ume
PAGE 6 SB-3866 INSTRUCTION & OPERATION MANUAL
Before making any connections to the SB-3866. Observe the following:
> Ensure the mains voltage supply matches the label on the supplied plug-
Pack (+/- 10%)
> Ensure that the power switch is OFF
> Ensure that all system grounds (earth) are connected to a common point.
> Avoid powering equipment within a system from multiple power sources
that may be separated by large distances
REMOTE CONTROL
REMOTE CONTROL
> Connect all audio video sources and destination equipment
> power up all source and destination audio-visual sources
> For each destination output select the appropriate input source by using
> Upon power up the switcher will return to its last used setting before
The front panel input select buttons. The supplied IR remote control.
Or through the RS 232 serial communications port.
Powered down.
1
2
SWITCH POWER ON or OFF
1
Controller with a power ON and OFF
SELECT VGA OUTPUT RESOLUTIONS
Select VGA output resolutions as following :
- SXGA 1280 x1024
- WXGA 1366 x 768
- WSXGA+1680 x1050
- WUXGA 1920 x1200
3
MEMU - OSD
OSD to setup or Adjust output resolutions and color.
4
AUDIO VALUE ADJUSTMENT
OSD to setup or Adjust Audio output Volume
6
INPUT 1 To 8 SOURCES SELECT
The Input 1 to 8 Audio and Video source selections
2
4
3
6
5
EXIT - OSD
OSD to EXIT
5
Input- # 1 Composite Video / Stereo Audio
Input- # 2 Composite Video / Stereo Audio
Input- # 3 S-Video / Stereo Audio
Input- # 4 S-Video / Stereo Audio
Input- # 5 Component Video (YP BPR) / Stereo Audio
Input- # 6 Component Video (YP BPR) / Stereo Audio
Input- # 7 VGA-RGBHV / Stereo Audio
Input- # 8 VGA-RGBHV / Stereo Audio

Step 1Step 1
Step 2Step 2
Step 3Step 3
PAGE 7SB-3866 INSTRUCTION & OPERATION MANUAL
IR EXTENDER PACKAGE :
IR EXTENDER
INPUT
DC 12V
IR EXT.
RS-232
REAR PANEL IR EXTENDER PORTS
An IR Extender for Room
IR EXTENDER CONTROL
HOW TO SETUP THE IR EXTENDER COMPONENTS
SB-100
SB-100
1
IR
ROOM
EXTEND TO 300 M
MULTIVIDEO SWITCHER
RoHS/95/EC
1
MULTIVI DEO SWITC HER
SW-3866
POWER
2
3
4
5
6
7
8
Menu
Exit
ENTERENTER
1280x1024
1440x900
1680x1050
1920x1200
AudioVolume
SB-3866

PAGE 8 SB-3866 INSTRUCTION & OPERATION MANUAL
RS-232 SERIAL INTERFACE
RS232
The Shinybow switcher can be controlled via the RS-232
serial control port to allow for interfacing to a PC,
The serial communication parameters are 9600 baud, 8 bit,
No Parity and 1 stop bit - this is often referred to as 9600 8N1.
When the unit recognises a complete command it will perform
the requested action - there is no delimiter character required.
The unit does not send out a message when a value is changed
from the front panel or by IR control. If the unit needs to be
controlled via the front panel in addition to the RS232 control, you should
regularly poll the unit status to ensure the control system
accurately reflectes the current settings.
COMMANDS
To Switch Inputs to Outputs
- Where X is Output Number (1-1) and Y is
Input Number (1-8)
Unit will respond with
SBUD0XOY - Where X is Output Number (1-1) and Y is
Input Number (1-8)
Example : Send Input 6 to Output 1
-Send
SBUD06O1 -Rcvd
or similar third party control system.
SBI06O01
SBI0XO0Y
RS-232 SERIAL INTERFACE CONNECT a PC or CONTROL SYSTEM
1 5
6 9
RS-232 SERIAL INTERFACE
Pin RS-232 Definition
1 ------ Not used
2 TX Transmitter
3 RX Receiver
4 ------ Not used
5 GND Ground
6 ------ Not used
7 ------ Not used
8 ------ Not used
9 ------ Not used

PAGE 9SB-3866 INSTRUCTION & OPERATION MANUAL
RS-232 SERIAL COMMANDS
FRONT PANEL LOCK
Note : Hard resetting the unit will unlock the Front Panel controls.
SBSYSMLK
- When front panel is locked, changes can only be
made by RS232
SBSYSMUK
- Front Panel Unlock
Unit will respond with
SBSYSLOK
- Front Panel has been Locked
SBSYSULK
- Front Panel has been Unlocked
Example : Lock Front Panel Buttons
SBSYSMLK -Send
SBSYSLOK -Rcvd
UNIT RESET
SBALLRST
- Reset every output to Input 1
Unit will respond with
SBRSTACK
- Unit has reset each Output to Input 1
Example : Reset all outputs to Input 1
SBALLRST
-Send
SBRSTACK
-Rcvd
Power Off mode.
- Put system into Standby (Soft Power Off)
- Bring unit out of Standby (Soft Power On)
Unit will respond with
- Unit is in Standby
SBALONAK
- Unit is no longer in Standby
Example : Put Unit in Standby (Soft Power)
SBSYSMOF -Send
SBALOFAK
-Rcvd
SBALOFAK
SBSYSMON
SBSYSMOF
MORE STUFF FOR SB-3866
Note:
Turning the unit System Power Off over RS232 will extinguish the LED channel display leaving only the
Power switch LED on. The Video and Audio outputs will also mute. While the unit is turned off by RS232
it will continue to accept and act upon switching commands. For example, if the unit is in the off mode
(via RS232) and you send a command to switch an input to an output, that route will complete and the
video and audio will now appear on that channel only. The front panel LED channel display for that
particular output will also show the input selected (for that single output channel only). The remaining
LED’s will remain off and video and audio outputs muted. The unit will still return status and change
messages in response to commands sent while in Power Off state. A hard reset command (SBALLRST)
will return the unit to normal operation and also unlock the front panel.

PAGE 11SB-3866 INSTRUCTION & OPERATION MANUAL
FEATURES & SPECIFICATIONS
FEATURES
SPECIFICATIONS
1. Video Scaling outputs
2x via HD-15 Female connectors, (Audio : 4x RCA & 2x OD3.5 connectors )
2 . Video Input Signals
TV standards : NTSC-M 3.58, NTSC-J 4. 43, PA L-B-D-I-G-H-K , PAL-M, PAL-N
PAL-N COMB-N, SECAM (Impedance:75 ohms)
Composite Video : 2 x via RCA connectors
S-Video(Y/C) : 2 x via 4 pin Mini-Din connectors
Component Video(YPBPR) : 6x via RCA connectors
PC-VGA(RGBHV) : 2x via HD-15 Female connectors
3. OSD menu selections & Adjustments
Input sources : 1 & 2 AV, 3 & 4 S-Video, 5 & 6 Component Video, 7 & 8 VGA
Color : Contrast, Brightness, Sharpness, Level and TINT
VGA output resolutions: VGA, SVGA, XGA, SXGA, WXGA, WSXGA+, WUXGA
4. Video bandwidth : 400MHz, (-3 dB), Audio Bandwidth: 60MHz, (-3 dB)
5. Audio Frequency Respond:20Hz~20KHz
6. Safety Approvals: CE, FCC, RoHS(2002/95/EC)
7. Dimension(LWH): 19”x 7.87”x 1.75”(482mm x 200mm x 44mm)
8. Power Supply: 12VDC, Universal type 50/60Hz 100~230 VAC
1. Support 8 inputs to 2 outputs Routing Switcher
Multivideo signal as VGA/S-Video/Composite Video/Component Video/Audio
2. Inputs : 8x Group as 2x AV, 2x S-Video/Audio, 2x Component/Audio & 2x VGA/Audio
Outputs: 2x (VGA+Stereo Audio)
3. Automatically input TV standard composite video/S-Video and HDTV Component
Video 50/60Hz, 480p,720p and 1080i/p system detection
4. Automatically scan 8 input video sources display by LED on front panel
5. Direct video input selection by front panel buttons with LED readout
6. Direct VGA output resolution selection.
7. Auto Scaling Video picture up to high HD resolution output.
8. Adjust Stereo Audio Value on front panel
9. OSD (on screen display) for menu color, resolution and input source selections
10. Two VGA(RGBHV) outputs resolution scaling up to 1920x1200 HD
11. Support RS232 interface control driver for win 95/98/2000/xp
12. An IR transceiver on the front panel by infrared remote control and an IR
External port on the rear panel support extend distance about 300Mt.
13. Support desktop with Ear mount and 19 inch Rack mountable type panel

Content
Brightness
Adjusts back ground BRIGHTNESS black level of the
screen image,low enough that ablack area of the
picture emits no light,but high enough that setting
the control any higher would cause the area to
become adark gray.
Adjusts the foreground white level of the screen image.
can be adjusted so that the colors you are seeing
match that of the original object.This adjustment
affects color saturation.
CONTRAST
COLOR
TINT
SHARPNESS
BRIGHTNESS 50
50
50
50
50
COLOR
TINT
SHARPNESS
BRIGHTNESS 50
CONTRAST 50
50
50
50
BRIGHTNESS 50
CONTRAST 50
TINT
SHARPNESS
BRIGHTNESS 50
CONTRAST 50
COLOR 50
50
50
COLOR 50
Contrast
Color Adjustment
OSD PICTURE ADJUSTMENT
PAGE 12 SB-3866 INSTALLATION & OPERATION MANUAL

Content
CONTRAST
COLOR
TINT
SHARPNESS
BRIGHTNESS 50
50
50
50
50
TINT 50
CONTRAST
COLOR
SHARPNESS
BRIGHTNESS 50
50
50
TINT 50
50
SHARPNESS 50
Allows adjustment to increase or decrease Tint.
Allows adjustment to increase or decrease the
Sharpness of the image.This function does not
change Resolution.
Tint
Sharpness
PAGE 13SB-3866 INSTRUCTION & OPERATION MANUAL
OSD PICTURE ADJUSTMENT

Content
RESOLUTION
640x480
1024x768
1280x1024
1366x768
1680x1050
1920x1200
800x600
Changes the output resolution to one of the pre-set
values.Note that after you make this change,your
display device might need to re-clock to the signal.
You can do this by changing your source input and
then back again to the SB-3866 input.For example:
If you have the SB-3866 connected to the VGA input
on your projector.After you change resolution,you
need to set the projector to switch to video input and
then change back to VGA.
Resolution Adjustment
OSD SETUP VGA OUTPUT RESOLUTIONS
PAGE 14 SB-3866 INSTALLATION & OPERATION MANUAL

Content
INPUT SOURCE
CVBS1
S-VIDEO1
S-VIDEO2
YPBPR1
YPBPR2
VGA1
CVBS2
VGA2
Changes the Input Signal Source to one of pre-set
values.The front panel LED will also display the
Input Signal Source selected.
As product improvements continues,specifications
and procedures are subject to change and without
notice.
Input Source
PAGE 15SB-3866 INSTRUCTION & OPERATION MANUAL
OSD VIDEO SOURCES SELECTIONS

Content
Language
Follow you to cheese from English or Chinese.
Visibility
Changing this value sets the transparency ration
between the OSD and the background image.
Information
Display the software version.
INFORMATION
VER-001
SLEEP
RESET
OSD SETTING
VISIBILTTY 50
LANGUAGE
ENGLISH
INFORMATION
VER-001
SLEEP
RESET
OSD SETTING
VISIBILTTY 50
LANGUAGE
ENGLISH
SLEEP
RESET
OSD SETTING
VISIBILTTY 50
LANGUAGE
ENGLISH
INFORMATION
VER-001
OSD FUNCTION SETTING
PAGE 16 SB-3866 INSTALLATION & OPERATION MANUAL

Content
LANGUAGE
ENGLISH
INFORMATION
VER-001
SLEEP
RESET
OSD SETTING
VISIBILTTY 50
Sleep
The Sleep Timer will automatically shutdown the
SB-3866 at apre-determined amount of time.The
preset values start at 10 minutes and goes to 120
minutes,in increments of 10 minutes each
Reset
Selecting Reset will restore the unit to factory
default conditions.The input will default to CVBS-1
at its lowest resolution.
Exit
When finished with any menu,selecting Exit will
take you out of the On Screen Menu (OSD).
LANGUAGE
ENGLISH
INFORMATION
VER-001
SLEEP
RESET
OSD SETTING
VISIBILTTY 50
PAGE 17SB-3866 INSTRUCTION & OPERATION MANUAL
OSD FUNCTION SETTING
EXIT

LIMITED WARRANTY
SHINYBOW WARRANTY
SHINYBOW Technology warrants this product against defects in materials and workman
ship for a period of 1 year from the date of purchase.
Should this product, in SHINYBOW Technology's opinion, prove defective within this
warranty period, SHINYBOW Technology, at its option, repair this product without charge,
to whatever extent it shall deem necessary to restore said product to proper operation
condition.
This warranty does not apply if the fault has been caused by misuse, improper handling
care, electrical or mechanical abuse, and abnormal operating condition or non-SHINYBOW
Technology authorized modification to the product.
If repairs are necessary under the warranty policy, the original purchaser must return the
product to local distributor, freight prepaid.
After repairs are complete, the product will be returned.
REGULATORY COMPLIANCE
The product complies with the relevant standards for CE, FCC and RoHS approval.
The power Adaptor/Supply has been tested for compliance with UL.CSA and CE standards.
TROUBLESHOOTING
If you experience a <no signal> with this switcher or distributor outputs, first make certain that
the signal being fed to its inputs is acceptable.
Disconnect the cables from the this switcher or distributor inputs and connect them directly to
an appropriate monitoring device, if you do not see or hear a signal the problem may well be
the signal source itself. Also check that the AC outlet you have used to power the switcher or
distributor is actually providing power as a wall switch often controls an AC outlet.
The second most common problem with this switcher or distributor revolves around the cables,
Inspect the cables for loose connectors or cable damage such as crushed cable or cables with
cuts or nicks. Replace any cable exhibiting these problem.
You also must use the highest quality cables if you want to achieve the best results. Poor quality
cables provide will poor quality signals.
PAGE 18 SB-3866 INSTRUCTION & OPERATION MANUAL

M U L T I M E D I A A U D I O A N D V I S U A L
1399 Wildfire Lane | Frisco, TX 75034
1-877-SHINY-USA 1-877-744-6987 1-972-377-2508
[e-mail]
www.shinybowusa.com
