MILLER-ST.NAZIANZ,INC.
P.O. BOX 127
ST. NAZIANZ, WI 54232
920/773-2121
FAX:[phone]
OPERATOR'S MANUAL
DO NOT OPERATE THIS EQUIPMENT UNTIL THIS
MANUAL HAS BEEN READ AND UNDERSTOOD.
Part Number: 42.0802219B
December 2014
MODEL: LX1214 Professional

SOME PHOTOGRAPHS USED HEREIN MAY SHOW DOORS, GUARDS AND
SHIELDS OPENED OR REMOVED. BE SURE THAT ALL DOORS, GUARDS
AND SHIELDS ARE FASTENED IN THEIR PROPER POSITION BEFORE
MACHINE IS OPERATED!
WARNING
INTRODUCTION
This Operator's Manual is provided to acquaint the operator with the safety and operation of the Miller
Ag-Bag LX1214 Professional Bagger. Complete Assembly, Operation, Lubrication and Maintenance
procedures are provided. Following the recommended procedures will help you achieve many years of
dependable service.
This manual is considered part of your machine and should remain with the machine at all times.
Make sure the operator reads and understands the manual before placing the bagger into operation.
Failure to follow the recommended procedures may result in personal injury or equipment damage, and
could void the warranty.
MACHINE SERIAL NUMBER
The machine serial number is located on the support frame below the engine on the feed table side. For
your convenience refer to this number and your product model number when requiring service or parts
information. Record the machine serial number, model number, date of purchase and dealership name
in the space provided below.
Date Purchased
Model No. Serial No.
Right and Left sides are determined from a position standing at the bag tunnel side looking toward the
feed table.
The Warranty Registration must be completed by the dealer online to validate your warranty protection.
You must read and understand the places where you attest to having received instructions as to care,
adjustments, safe operation and applicable warranty policy.
Dealership

1
Table Of Contents
IMPORTANT REFERENCE NUMBERS............................................................................................. 5
BAGGER CHECK LISTS.................................................................................................................... 6
SAFETY PRECAUTIONS................................................................................................................... 7
General Safety Precautions.......................................................................................................... 8
Maintenance Safety Precautions ................................................................................................ 10
Engine Safety Precautions ......................................................................................................... 11
Electrical Safety Precautions...................................................................................................... 12
Wheels and Tires Safety Precautions......................................................................................... 13
SAFETY SIGN AND DECAL LOCATIONS....................................................................................... 14
Safety Signs................................................................................................................................ 16
Yellow Reflective Decals............................................................................................................. 18
SMV Emblem & Red Reflective Decals ...................................................................................... 18
SPECIFICATIONS ............................................................................................................................ 19
FEATURES AND CONTROLS ......................................................................................................... 20
In Cab Controls........................................................................................................................... 20
Upper Beater Control Switch ...................................................................................................... 21
Signal Light Switch Red-Green .................................................................................................. 21
Signal Light Switch Amber.......................................................................................................... 22
Inoculant Spray Applicator Switch .............................................................................................. 22
Anchor Float Switch.................................................................................................................... 23
Anchor Switch In/Out.................................................................................................................. 23
Engine Throttle Control Switch ................................................................................................... 24
Engine High Idle Switch.............................................................................................................. 24
Tunnel Clean Out Switch ............................................................................................................ 25
Feed Table Lift/Lower Switch ...................................................................................................... 25
Engine End Lift Jack Switch ....................................................................................................... 26
Cab End Lift Jack Switch ............................................................................................................ 26
Power Port For 12 Volt Accessories............................................................................................ 27
Horn Button ................................................................................................................................ 27
Brake Pedal ................................................................................................................................ 27
Direction and Steering Joystick .................................................................................................. 28
Switching Driving Modes ............................................................................................................ 29
Feed Table Belt Control .............................................................................................................. 32
Two Way Radio Coax Cable ....................................................................................................... 32
Antenna ...................................................................................................................................... 33
AM/FM/WX Stereo Radio w/CD Player ...................................................................................... 33
Programming Radio For Use In Other Countries........................................................................ 34
Ignition Switch ............................................................................................................................ 35
Parking Brake ............................................................................................................................. 35
System Air Pressure Gauge ....................................................................................................... 36
Brake Pressure Adjustment Switches (Cab & Engine End)........................................................ 36
Two Wheel Drive/Four Wheel Drive Switch................................................................................. 37
Drive/Align Switch....................................................................................................................... 37
HPTO Clutch Controller .............................................................................................................. 38
Cab Interior Light ........................................................................................................................ 39
Windshield Wiper/Washer Switch ............................................................................................... 39
Heater and Air Conditioner Controls........................................................................................... 40

2
Contents - continued
Manual Storage .......................................................................................................................... 40
Cup Holder ................................................................................................................................. 40
Armrest Storage Box .................................................................................................................. 40
Lighting Operation ...................................................................................................................... 41
Light Locations On Vehicle ......................................................................................................... 42
Storage Tray/Recirculation Filter................................................................................................. 43
Cab Pressurization Filter (Charcoal) .......................................................................................... 43
Cab Door Lock and Handles....................................................................................................... 44
Seat Adjustments ....................................................................................................................... 44
Seat Belts ................................................................................................................................... 44
Engine Data Link Connector....................................................................................................... 45
System Monitor Programming Port............................................................................................. 45
Outside Controls - Manual.......................................................................................................... 46
Outside Controls - Remote Control ............................................................................................ 47
Outside Cab End Up-Down Switch............................................................................................. 48
Battery Disconnect Switch.......................................................................................................... 49
Remote Battery Terminals .......................................................................................................... 49
Power Strip Electrical Outlets ..................................................................................................... 50
Auxiliary Power Outlet................................................................................................................. 50
Emergency Exit .......................................................................................................................... 50
Re-Fueling .................................................................................................................................. 51
Drain Water From Fuel Filter/Water Separator ........................................................................... 52
Engine Coolant Conditioner Filter (Extended Life Coolant Only)................................................ 52
Engine Coolant Filter (Organic Acid Technology OAT Coolant Only) ......................................... 52
CHANGING TUNNELS..................................................................................................................... 53
OPERATION..................................................................................................................................... 61
General....................................................................................................................................... 61
Engine Cold Starting................................................................................................................... 62
To Start ....................................................................................................................................... 62
Inoculant Applicator Operation ................................................................................................... 62
Cleaning The Inoculant System.................................................................................................. 63
Spray Tip Selection & Pressure Settings Guide ......................................................................... 63
SETUP BAGGER FOR BAGGING OPERATION ............................................................................. 64
Pintle Hitch ................................................................................................................................. 64
Position Bagger At Bagging Site................................................................................................. 64
Install Tunnel Extension On To Tunnel ........................................................................................ 66
Lower and Setup Feed Table ...................................................................................................... 67
Bag Identification ........................................................................................................................ 68
Remove Anchors From Storage Hooks ...................................................................................... 68
Install The Bag On To The Tunnel ............................................................................................... 69
Seal Beginning End Of Bag........................................................................................................ 72
BAGGING PROCEDURE................................................................................................................. 73
Before Starting The Bagger........................................................................................................ 73
Bagger Start-Up Procedure........................................................................................................ 73
Filling The Bag............................................................................................................................ 75
Removing The Bag ..................................................................................................................... 76
Venting The Bag ......................................................................................................................... 77

3
Contents - continued
PREPARE THE BAGGER FOR TRANSPORT................................................................................. 78
Feed Table .................................................................................................................................. 78
Bag Cradle.................................................................................................................................. 78
Tunnel Extension ........................................................................................................................ 79
Anchors In Storage Position ....................................................................................................... 80
Place Wheels Into Transport Position ......................................................................................... 80
Transport Lock ............................................................................................................................ 82
Pintle Hitch ................................................................................................................................. 83
TRANSPORTING ............................................................................................................................. 84
Transporting Bagger On A Equipment Trailer ............................................................................. 84
Transporting With A Tow Vehicle................................................................................................. 85
BAGGING INSTRUCTIONS ............................................................................................................. 87
Bag Information .......................................................................................................................... 87
STORAGE ........................................................................................................................................ 90
TROUBLE SHOOTING..................................................................................................................... 91
Hydraulic System........................................................................................................................ 91
Engine ........................................................................................................................................ 91
Engine Trouble Shooting............................................................................................................. 92
Engine Fault Codes .................................................................................................................... 92
Engine Fault Codes - QSX Engines ........................................................................................... 94
Trouble Shooting....................................................................................................................... 102
FUSE & RELAY LOCATIONS......................................................................................................... 104
LUBRICATION................................................................................................................................ 105
Rotor Bearing ........................................................................................................................... 105
Feed Table Drive and Idler Rollers............................................................................................ 105
Lower Beater Bar Bearings ...................................................................................................... 106
Upper Beater Bar Bearings ...................................................................................................... 106
Bag Boom................................................................................................................................. 107
Anchor Cable Guide Rollers ..................................................................................................... 108
Brake Pivot Arms ...................................................................................................................... 109
Hydraulic Lift Jack Slide Tubes ................................................................................................. 109
Wheel Column Posts ................................................................................................................ 110
Steering Tie Rod....................................................................................................................... 110
Beater Bar Drive Chain............................................................................................................. 111
Feed Table Drive Chain ............................................................................................................ 111
ADJUSTMENTS............................................................................................................................. 112
Feed Table Drive Chain ............................................................................................................ 112
Feed Table Belt ......................................................................................................................... 112
Lower Beater Bar Drive Chain .................................................................................................. 113
Planetary Drive Belt.................................................................................................................. 113
Bag Pan Clearance Gap........................................................................................................... 115
Brake Slack Adjusters............................................................................................................... 115
Setting High Idle Speed............................................................................................................ 116
Setting Reversing Fan Parameters ........................................................................................... 117
Resetting Steering Sensors...................................................................................................... 119

4
Contents - continued
MAINTENANCE ............................................................................................................................. 120
Maintenance Schedule ............................................................................................................. 120
Maintenance Record ................................................................................................................ 122
Engine Maintenance................................................................................................................. 125
Fuel Filter/Water Separator ...................................................................................................... 126
Chassis & Engine Compartment Inspection & Cleaning .......................................................... 126
Radiator, Oil Cooler, Charge Air Cooler and Air Conditioning Condenser Heat Exchangers ... 127
Engine Coolant ......................................................................................................................... 128
Engine Coolant Conditioner Filter (Extended Life Coolant Only).............................................. 129
Engine Coolant Filter (OAT Coolant Only) ................................................................................ 129
Organic Acid Technology (OAT) Coolant .................................................................................. 130
Changing Coolant Types........................................................................................................... 130
Definitions Of Coolant Types .................................................................................................... 130
Engine Air Cleaner Filters......................................................................................................... 131
Engine Serpentine Belts........................................................................................................... 132
Air Storage Tank ....................................................................................................................... 133
Bag Boom Winch Oil................................................................................................................. 134
HYDRAULIC SYSTEMS................................................................................................................. 135
Hydraulic System Cleanliness .................................................................................................. 135
Main Hydraulic System Oil........................................................................................................ 136
Clutch Oil and Filter .................................................................................................................. 140
Rotor Planetary Oil and Filter ................................................................................................... 141
Feed Table Planetary Oil........................................................................................................... 142
Cab Pressurization Filter (Charcoal) ........................................................................................ 144
Tine Cap Replacement............................................................................................................. 145
Tire Air Pressure....................................................................................................................... 145
Wheel Lug Nut Torque .............................................................................................................. 145
Feed Table Wheel Bearings...................................................................................................... 146
ANCHOR CABLES......................................................................................................................... 147
Anchor Cable Replacement...................................................................................................... 147
Anchor Cable Adjustment......................................................................................................... 148
TORQUE SPECIFICATIONS.......................................................................................................... 149
WARRANTY ..................................................................................................... INSIDE BACK COVER

5
Important Reference Numbers
Fill in the important serial numbers and model numbers in the spaces below. These will be helpful
when service or maintenance is required. Also listed below are the part numbers and quantities of
the filters and belts for this unit.
Model and Serial Numbers
Bagger Model Number: __LX1214 Professional__
Bagger Serial Number: ____________________
Engine Model Number: ____Cummins QSX____
Engine Serial Number: ____________________
Filters
Description Part Number Qty.
Primary Air Filter Element 42.0800816 1
Secondary Air Filter Element 42.0800817 1
Fuel Filter/Water Separator 42.0801373 1
Engine Oil Filter 42.0801370 1
Engine Coolant Conditioner Filter 42.0801371 1
(S/N 4220003 & Before, 4220005
thru 4220009) Extended Life
Engine Coolant Filter (S/N 4220004, 42.0802369 1
4220010 & After) OAT Coolant
Cab Air Filter - Charcoal 21.00955 1
Recirculation Filter - In Cab 21.21623 1
Main Hydraulic Oil Return 21.42585 2
Case Drain 21.21112 1
Clutch 42.1541961 1
Rotor Planetary 42.1540167 1
Hydraulic Oil Reservoir Breather 21.20848 1
Belts
Description Part Number Qty.
Serpentine 42.0801377 1
Water Pump 42.0801372 1

6
Delivery and Pre-Delivery Check Lists (customer and dealer copies) follow this page.
Customer copies can remain with this manual.
Dealer copies can be removed along perforation and remain with dealer.
Bagger Check Lists

Delivery Check List - Customer Copy
The following list is an important reminder of valuable information, which must be passed on to the
customer at the time the unit is delivered. Check off each item as you explain it to the customer.
 Give the customer this operator’s manual. Instruct them to be sure to read and completely
understand its contents before attempting to operate the unit.
 Review the warranty.
 Explain and review the safety section of this manual with the customer.
 Explain that regular lubrication and proper adjustments are required for continued proper op-
eration and long life. Review the maintenance section of this manual with the customer.
 Have the dealer complete the warranty registration online.
Dealer’s Signature:_____________________________ Date:_______________
 I acknowledge that the above points were reviewed with me at the time of delivery.
Customer’s Signature:__________________________ Date:_______________

Pre-Delivery Check List - Customer Copy
After the Miller Ag-Bag has been completely set up, check that it is in correct working order before
delivery to the customer. The following is a list of points to inspect. Check off each item to verify
the proper adjustments have been made and the item(s) is (are) operating satisfactorily. Any adjust-
ment must be made according to specifications defined in this manual.
 Verify that all of the options are installed.
 Verify that all accessories function correctly.
 Check tire inflation.
 Check and tighten wheel nuts to correct torque.
 Make sure all bolts and other fasteners are tightened or properly adjusted.
 Make sure hoses are secured and not in contact with any moving parts.
 Check that the feed table raises and lowers properly.
 Check all fluid levels.
 Lubricate all grease fittings.
 Check that all safety signs are in place.
 Check that all safety systems, including guards and shields are in place and functional.
Dealer’s Name:_____________________________
Signature of Pre-Delivery Inspector:___________________________________
Date Of Inspection:________________
