Milnor 48040H7K User manual

Published Manual Number/ECN: ME6H7NZ1AE/2021255N
• Publishing System: TPAS2
• Access date: 06/17/2021
• Document ECNs: Latest
Schematic/Electrical Parts
48040H7K, H7R, M7K
68036H5K, M5K
72046M5K
MilTouch-EX™ Controls
PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.

Table of Contents
ME6H7NZ1AE/21255N
Page Description Document
1 Component Parts List W6H3NZPL/2021022N
9 Limited Standard Warranty BMP720097/2019036
10 How to Get the Necessary Repair Components BIUUUD19/20081231
11 How to Use Milnor® Electrical Schematic Diagrams BIUUUK01/20130308
24 Sample Schematic BMP010012/2018343
26 3 Phase Motor Connection Diagram BMP850029/1999362B
27 3P Motor Diagram-Multivolt W80008/2001253A
28 Control Box Layouts W6H3NZTG1/2021022B
30 Control Box Layouts W6H3NZTG2/2018352B
32 Control Box Layouts W6H3NZTG3/2018352B
34 Board to Board Wiring W6H3NZBW/2021034B
36 Flushing Supplies W6H3NZCF/2019063B
38 Liquid Supply-Interpret Relays W6H3NZCP/2014116B
40 Central Liquid Supply W6H3NZCX/2014116B
42 Alternate Drain Valve Air Operated W6H3NZDR/2014116B
44 Extract Commands Satisfied W6H3NZEA/2014116B
46 Electronic Balance W6H3NZEB1/2015225B
48 Balancing Valves W6H3NZEB2/2015225B
50 Extract Speed Limit W6H3NZEC/2015225B
52 Electrical Valves 48040H7R/M7R W6H3NZEV/2015422B
54 Electrical Valves 48040H/M7K, 68036H/M5K, 72046M5K W6H3NZEVA/2019383B
56 Optional LED Signal Light W6H3NZFS/2021162B
58 Hydraulic Door Wiring 48040H7R W6H3NZHD/2014116B
60 Hydraulic Door Wiring 48040H7K/M7K & 68036H5K/M5K W6H3NZHDA/2016333B
62 Microprocessor Inputs W6H3NZI1/2016492B
64 Light Curtain W6H3NZLC/2021022B
66 Control Circuit Transformer W6H3NZLV/2017365B
68 600V to 480V Buck Boost Transformer W6H3NZMT6/2019472B
70 20 Programable Outputs Optional W6H3NZOP/2014116B
72 Raise House - 48040H/M7K, 68036H/M5K, 72046M5K W6H3NZRH/2021255B
74 Start Circuit - 48040H7R W6H3NZS+/2021162B
76 Start Circuit 48040H/M7K, 68036H/M5K, 72046M5K W6H3NZS+A/2021162B
78 Inverter wiring W6H3NZVP/2020476B

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION
>>>CONTROL BOX LAYOUTS
01 DETAIL-LOW VOLTAGE CONTROL BOX W6H3NZTG1 B2T2014006 48040H7R/K LOW VOLT C-BOX SEE FUNCTION 02 DETAIL-HIGH VOLTAGE CONTROL BOX - 68 & 72M5K W6H3NZTG1 B2T2014015 48/68/72 H/M 7/5 R/K HV BOX SEE FUNCTION 03 DETAIL-HIGH VOLTAGE CONTROL BOX - 48M5K W6H3NZTG2 B2T2015005 48M7R/K HV BOX SEE FUNCTION 04 DETAIL-POWER SUPPLIES W6H3NZTG2 B2T2014012 MILTOUCH-EX POWER SUPY SET SEE FUNCTION 05 DETAIL-CONTROL BOARDS INPUTS/OUTPUTS W6H3NZTG3 B2T2014013 MTOUCH-EX W/E BDS IN/OUT LIST SEE FUNCTION 06 DETAIL-VALVE SET W6H3NZTG3 B2T2015003 48M7K, 68-72M5K VALVES SEE FUNCTION ACBA >>>ACCELEROMETERS ACBA BOARD-ACCELEROMETER W6H3NZEB1 EACCLRM5 ASSY:ACCEL 1-5G ADXL 105+TEST DOOR LATCH ACBA BOARD-ACCELEROMETER W6H3NZEC EACCLRM5 ASSY:ACCEL 1-5G ADXL 105+TEST DOOR LATCH BA >>>PRINTED CIRCUIT BOARDS BAD-1 BOARD-ANALOG TO DIGITAL CONVERTER W6H3NZBW 08BSADCT BD: SERIAL A-D CONVERT->TEST CONTROL BOX BAS BOARD-16 SNUBBER CIRCUITS W6H3NZCF 08BNCMBT COIN MACHINE SNUBBER->TESTED CONTROL BOX BAS BOARD-16 SNUBBER CIRCUITS W6H3NZEV 08BNCMBT COIN MACHINE SNUBBER->TESTED CONTROL BOX BAS BOARD-16 SNUBBER CIRCUITS W6H3NZEVA 08BNCMBT COIN MACHINE SNUBBER->TESTED CONTROL BOX BBAD-1 BOARD-BALANCE A-D W6H3NZEB1 08BSBADCTE SR BALANCE A-D BD EXTACTR-TEST CONTROL BOX BBAD-1 BOARD-BALANCE A-D W6H3NZEC 08BSBADCTE SR BALANCE A-D BD EXTACTR-TEST CONTROL BOX BDA-1 BOARD-DIGITAL TO ANALOG CONVERTOR W6H3NZBW 08BSDACHT BD:HI-RES SERIAL D-A->TEST CONTROL BOX BIO-1 BOARD-8OUTPUT/16INPUT #1 W6H3NZBW 08BS816CHT BD 8OUT-16IN HIGH SPD->TEST CONTROL BOX BIO-2 BOARD-8OUTPUT/16INPUT #2 W6H3NZBW 08BS816CHT BD 8OUT-16IN HIGH SPD->TEST CONTROL BOX BLB BOARD-LEVEL TRANSDUCER W6H3NZBW 08BNLTT LEVEL TRANSDUCER BD->TEST CONTROL BOX BMTH-1 BOARD-3 CHANNEL MOTHER W6H3NZBW 08BS3MTHAT BD:SERIAL 3 CARD MOTHER->TEST CONTROL BOX BMTH-1 BOARD-3 CHANNEL MOTHER W6H3NZEB1 08BS3MTHAT BD:SERIAL 3 CARD MOTHER->TEST CONTROL BOX BMTH-2 BOARD-3 CHANNEL MOTHER W6H3NZBW 08BS3MTHAT BD:SERIAL 3 CARD MOTHER->TEST CONTROL BOX BO24-1 BOARD-24 OUTPUT #1 W6H3NZBW 08BSO24AT BD:SERIAL 24 OUTPUT->TEST CONTROL BOX BO24-2 BOARD-24 OUTPUT #2 W6H3NZBW 08BSO24AT BD:SERIAL 24 OUTPUT->TEST CONTROL BOX BO24-3 BOARD-24 OUTPUT #3 W6H3NZBW 08BSO24AT BD:SERIAL 24 OUTPUT->TEST CONTROL BOX BPB BOARD-ARM9 PROCESSOR+TOUCH SCREEN W6H3NZBW 08BHA9D4T ASSY:ARM9 PROC+8.4 OPTREX DSP-TESTED PROCESSOR BX BSP BOARD-SPEED SENSING W6H3NZBW 08BNDSRAT BD DRY SAFETY ROTATION->TEST CONTROL BOX CB >>>CIRCUIT BREAKER CB1 CIRCUIT BREAKER-HYDRAULIC PUMP W6H3NZVP 09FC016CAA IEC MINI CIR.BREAK 16A 480V3P CONTROL BOX CB2 CIRCUIT BREAKER-RECIRCULATION PUMP W6H3NZVP 09FC010CAA IEC MINI CIR.BREAK 10A 480V3P CONTROL BOX CD >>>RELAY DELAY
Page 1 of 8
1

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION CDDH DELAY-HDRAULIC DOOR OPEN > 3/6/2019 W6H3NZRH 09CF001071 TDR F1S 2PDT 11PIN 240V60C CONTROL BOX CDDH DELAY-HDRAULIC DOOR OPEN < 3/6/2019 W6H3NZRH 09CA0100A71 ADJUSTABLE TIME DELAY 10S OMRON 200-2
3
CONTROL BOX
CL >>>RELAY-LATCH CLA LATCH-DOOR SEAL W6H3NZS+A 09CL2C-C71 RELAY-LATCH DPDT 240V 2-COIL CONTROL BOX CLA LATCH-DOOR SEAL W6H3NZS+ 09CL2C-C71 RELAY-LATCH DPDT 240V 2-COIL CONTROL BOX CLA-CHOKE CHOKE-DOOR SEAL LATCH W6H3NZS+A 10YCLCHOKE LATCH HARNES: RF CHOKE CONTROL BOX CP >>>PHOTOEYE CPLC LIGHT CURTAIN-EMITTER/RECEIVER W6H3NZLC 09RPE018LBA LITE BEAM EMITTER/RECEIVER 600MM BANN
E
SIDE OF MACH
CPLCC LIGHT CURTAIN-EMITTER/RECEIVER W6H3NZLC 09RPE018LBC LITE BEAM MUTING RELAY MODULE LOW VOLT BOX CPSP PHOTOEYE-SPEED W6H3NZBW 09RPE013Q SENSOR E-Z BEAM QUICK CONN DC MAIN PULLEY CR >>>RELAY-PILOT OR CONTROL CRA RELAY-DOOR SEALED W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRA RELAY-DOOR SEALED W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRAD RELAY-BASE BLOCK ON MILTOUCH POWER UP W6H3NVVP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED LOW VOLT BOX CRBO RELAY-BEAM OK W6H3NZLC 09C024E24 RELAY 4PDT DIFGLD 14PIN 24DC CONTROL BOX CRBO RELAY-GATE IS CLOSED W6H3NZLC 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRBSL RELAY-SPEED IS AT OR ABOVE DRAIN SPEED W6H3NZLC 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRC01 RELAY-INTERPRET RELAY #1 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC02 RELAY-INTERPRET RELAY #2 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC03 RELAY-INTERPRET RELAY #3 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC04 RELAY-INTERPRET RELAY #4 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC05 RELAY-INTERPRET RELAY #5 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC06 RELAY-INTERPRET RELAY #6 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC07 RELAY-INTERPRET RELAY #7 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC08 RELAY-INTERPRET RELAY #8 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC09 RELAY-INTERPRET RELAY #9 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC10 RELAY-INTERPRET RELAY #10 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC11 RELAY-INTERPRET RELAY #11 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC12 RELAY-INTERPRET RELAY #12 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC13 RELAY-INTERPRET RELAY #13 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC14 RELAY-INTERPRET RELAY #14 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC15 RELAY-INTERPRET RELAY #15 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRD RELAY-DOOR UNLATCH W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX
Page 2 of 8
2

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION CRD RELAY-DOOR UNLATCH W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRDB RELAY-RESISTOR TEMP HIGH W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRDB RELAY-DOOR UNLATCH HIGH W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRDOA RELAY-DOOR FULL OPEN W6H3NZRH 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CREI RELAY-DOOR OPEN AND UNLATCHED W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CREI RELAY-OK TO JOG W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRLPB RELAY-LIGHT BEAM BY PASS W6H3NZLC 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+ RELAY-START 3-WIRE W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+ RELAY-START 3-WIRE W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+A RELAY-START 3-WIRE (SLAVE) W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+B RELAY-START 3-WIRE (SLAVE) W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRSG RELAY-SIGNAL FOR ROTATION LED BEACON W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRWJ RELAY-JOG W6H3NZHDA 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CS >>>CONTACTOR-MOTOR STARTER CSDO CONTACTOR-HYDRAULIC PUMP W6H3NZHD 09MC08C371 16A 3P MCS CONT NR 240V5/6 CONTROL BOX
CSDO CONTACTOR-HYDRAULIC PUMP W6H3NZRH 09MC08C371 16A 3P MCS CONT NR 240V5/6 CONTROL BOX
CSR CONTACTOR-RECIRCULATE W6H3NZEV 09MC04E371 32A 3P CONT.NR 240V5/6 IEC CONTROL BOX CSR CONTACTOR-RECIRCULATE W6H3NZEVA 09MC04E371 32A 3P CONT.NR 240V5/6 IEC CONTROL BOX CSVP CONTACTOR-INVERTER 48040 LOW VOLTAGE W6H3NZS+A 09MC08N371 72A 3P MCS CONT NR 240V5/6 CONTROL BOX CSVP CONTACTOR-INVERTER 68036 LOW VOLTAGE W6H3NZS+A 09MC08T371 115A 3P MCS CONT. NR 240V5/6 CONTROL BOX CSVP CONTACTOR-INVERTER 48040 LOW VOLTAGE W6H3NZS+ 09MC08N371 72A 3P MCS CONT NR 240V5/6 CONTROL BOX
CSVS CONTACTOR-INVERTER 48040 HIGH VOLTAGE W6H3NZS+A 09MC08G371 37A 3P MCS CONT NR 240V5/6 CONTROL BOX CSVS CONTACTOR-INVERTER 68036 HIGH VOLTAGE W6H3NZS+A 09MC08N371 72A 3P MCS CONT NR 240V5/6 CONTROL BOX CSVS CONTACTOR-INVERTER 48040 HIGH VOLTAGE W6H3NZS+ 09MC08G371 37A 3P MCS CONT NR 240V5/6 CONTROL BOX EB >>>BUZZER OR AUDIBLE SIGNAL EBSG BUZZER-SIGNAL AUDIBLE W6H3NZS+A 09H016 BUZZ. 230V W/6-32 CTR+6" LEADS SWITCH PANEL EBSG BUZZER-SIGNAL AUDIBLE W6H3NZS+ 09H016 BUZZ. 230V W/6-32 CTR+6" LEADS SWITCH PANEL
EF >>>FUSE OR FUSE HOLDER EF01 FUSE-CONTROL CIRCUIT W6H3NZLV 09FF006AMA FUSE BK/ABC 6 AMP 250V BUSS CONTROL BOX EF02 FUSE-CONTROL CIRCUIT W6H3NZLV 09FF006AMA FUSE BK/ABC 6 AMP 250V BUSS CONTROL BOX EF1 FUSE-PRIMARY INCOMING VOLTAGE W6H3NZLV 09FF005AWN BUSE BUSS KTK 5AMP 600V=HPS HOLDER CONTROL BOX EF2 FUSE-PRIMARY INCOMING VOLTAGE W6H3NZLV 09FF005AWN BUSE BUSS KTK 5AMP 600V=HPS HOLDER CONTROL BOX EL >>>LIGHT-PILOT OR INDICATOR
Page 3 of 8
3

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION ELLB-E/R LIGHT CURTAIN-EMITTER/RECEIVER W6H3NZLC 09RPE018LBA LITE BEAM EMITTER/RECEIVER 600MM BANN
E
CONTROL BOX
ELLB-PS LIGHT CURTAIN POWER SUPPLY W6H3NZLC 09RPE018LBD LITE BEAM SAFETY RATING 24VDC PWR SPL
Y
CONTROL BOX
ELLB-RM LIGHT CURTAIN RELAY MODULE W6H3NZLC 09RPE018LBC LITE BEAM MUTING RELAY MODULE CONTROL BOX ELLPB LIGHT-LIGHT BEAM BY PASSED BEACON W6H3NZLC 09H025V71 BEACON ROTARY 8.5"DIA AMBER TOP OF CNTR BX ELLPB LIGHT-LIGHT BEAM BY PASSED LED BEACON W6H3NZFS 09H025V12 BEACON ROTARY AMBER LED 12VDC TOP OF CNTR BX ELSG LIGHT-SIGNAL VISUAL W6H3NZS+A 09J060A71 LAMP 1/2" AMB 250V IDI 1051QC3 SWITCH PANEL ELSG LIGHT-SIGNAL VISUAL W6H3NZS+ 09J060A71 LAMP 1/2" AMB 250V IDI 1051QC3 SWITCH PANEL ELSG LIGHT-OPTIONAL ROTATION LED BEACON W6H3NZFS 09H025V12 BEACON ROTARY AMBER LED 12VDC TOP OF CNTR BX EM >>>METERS EMHR METER-RUN TIME IN HOURS W6H3NZFS 38C203 HOUR METER 3.8IN 3 HOLE MTG 230V/60C CONTROL BOX ES >>>POWER SUPPLY-ELECTRONIC ESLC POWER SUPPLY-LIGHT CURTAIN W6H3NZLC 09RPE018LBD LITE BEAM SAFETY RATING 24VDC POWER S
U
LOW VOLT BOX
ESPS POWER SUPPLY-CARD CAGE W6H3NZBW 08PSS3401T 40 WATT POWER SUPPLY TESTED CONTROL BOX ESPS-2 POWER SUPPLY-MICROPROCESSOR W6H3NZBW 08PSS2401T PRW SUPY 40WATT 120/240V TO 12V TESTED CONTROL BOX ESPS-2 POWER SUPPLY-OPTIONAL BEACON LIGHT W6H3NZFS 08PSS2401T PRW SUPY 40WATT 120/240V TO 12V TESTED CONTROL BOX ET >>>THERMAL OVERLOAD DEVICES ETDO OVERLOAD-HYDRAULIC PUMP MOTOR W6H3NZHD 09FTD0037T MCS OL RELAY ADJ. RANGE 3.7-12 CONTROL BOX ETDO OVERLOAD-HYDRAULIC PUMP MOTOR W6H3NZRH 09FTD0037T E1 PLUS OL RELAY 3.2-16A CONTROL BOX ETVS OVERLOAD-VARIABLE SPEED INVERTER W6H3NZVP 09FTD0230T MCS OL RELAY ADJ. RANGE 23-75 CONTROL BOX EX >>>TRANSFORMERS EX37-1 TRANSFORMER-208 TO 240V W6H3NZLV 09UB25AU71 AUTOXFMR 208V/230V 250VA UL/CSA CONTROL BOX EX37-2 TRANSFORMER-380/480 TO 240VAC W6H3NZLV 09UA025AAB XFMR 380-480PRI/120-240SEC250V CONTROL BOX EX96A TRANSFORMER-600V TO 480V -48040H7 W6H3NZMT6 09US050A96 XFMR 1PH 5KVA 240/480X120/240 SIDE OF MACH EX96A TRANSFORMER-600V TO 480V -68036H5 W6H3NZMT6 09US100A96 XFMR 1PH 10KVA 240/480X120/240 SIDE OF MACH EX96A TRANSFORMER-600V TO 480V -72044H5 W6H3NZMT6 09US250A96 XFMR 1PH 25KVA 240/480X120/240 SIDE OF MACH EX96B TRANSFORMER-600V TO 480V -48040H7 W6H3NZMT6 09US050A96 XFMR 1PH 5KVA 240/480X120/240 SIDE OF MACH EX96B TRANSFORMER-600V TO 480V -68036H5 W6H3NZMT6 09US100A96 XFMR 1PH 10KVA 240/480X120/240 SIDE OF MACH EX96B TRANSFORMER-600V TO 480V -72044H5 W6H3NZMT6 09US250A96 XFMR 1PH 25KVA 240/480X120/240 SIDE OF MACH INVD1-H BRAKING UNIT-68036H5K 380-480VOLTS W6H3NZVP 09MVBT25HC BRAKE MODULE-OPEN CHASSIS CONTROL BOX INVD1-L BRAKING UNIT-68036H5K 200-240VOLTS W6H3NZVP 09MVBT25LC BRAKEMODULE OPEN CHASIS INVERT CONTROL BOX MT >>>MOTORS MTD MOTOR-DRIVE W6H3NZVP MESSAGE SO SEE SPECIFIC COMPONENT+NAMEPLATE MACHINE TOP MTDO MOTOR-HYDRAULIC PUMP W6H3NZHD MESSAGE SO SEE SPECIFIC COMPONENT+NAMEPLATE MACHINE REAR
Page 4 of 8
4

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION MTDO MOTOR-HYDRAULIC PUMP W6H3NZRH 39T050CAN 5HP 4P TEFC 208-230/460 60C MACHINE REAR
MTLF FILTER-INVERTER/MOTOR POWER W6H3NZS+A 09MVFILTR1 INCOME POWER FILTER CAP CONTROL BOX MTLF FILTER-INVERTER/MOTOR POWER W6H3NZS+ 09MVFILTR1 INCOME POWER FILTER CAP CONTROL BOX MTVS FAN-INVERTER COOLING W6H3NZS+A 13AF235A71 FAN 235CFM 230V 50/60 BACK C-BOX MTVS FAN-INVERTER COOLING W6H3NZS+ 13AF235A71 FAN 235CFM 230V 50/60 BACK C-BOX MVB >>>INVERTER BRAKING UNIT MVDBR RESISTOR-DYNAMIC BRAKE W6H3NZVP 09MV100RES RESIST 100 OHM 225WATT ADJ BELOW C-BX MVFLT INV FILTER-DRIVE W6H3NZVP 09MVFILTR1 INCOME POWER FILTER CAP CONTROL BOX MVI >>>MOTOR POWER INVERTERS MVINV-H INVERTER-4840H7K/H7R 380-460 VOLTS W6H3NZVP 09MWA03996 INVERTER 39AMPS 480V F7 CONTROL BOX
MVINV-H INVERTER-6836H5K 380-460 VOLTS W6H3NZVP 09MWC07596 A1000 INVERTER 75 AMP CONTROL BOX MVINV-L INVERTER-4840H7K/F7R 200-240VOLTS W6H3NZVP 09MWA07174 F7 INVERTER 71AMP CONTROL BOX MVINV-L INVERTER-6836H5K 200-240VOLTS W6H3NZVP 09MWC14574 A1000 INVERTER 145AMPS CONTROL BOX
PX >>>PROXIMITY SWITCHES PXDO PROX SWITCH-DOOR FULL OPEN W6H3NZRH 09RPS30CAS PROXSW QK CONN 30M NO-AC SHLD DOOR
PXRTD PROX SW-REAR FULL DOWN W6H3NZRH 09RPS30CAS PROXSW QK CONN 30M NO-AC SHLD SIDE OF MACH PXRTU PROX SW-REAR FULL UP W6H3NZRH 09RPS30DAS PRXSW QK CONN 30M NC-AC SHLD SIDE OF MACH PXWP PROX SW-AT WASH LEVEL W6H5KZ1A 09RPS30ADS PROX SW QK CONN 30M NO-DC SHLD SIDE OF MACH
RS >>RESISTORS RS01 RESISTOR 16 OHM 25W W6H3NZBW ECEUV8R LOAD RESISTOR ASSY MILTOUCH LOW VOLT BOX RS02 RESISTOR 40 OHM 25W W6H3NZBW ECEUMTRES LOAD RESISTOR ASSY MILTOUCH EX LOW VOLT BOX SH >>>SWITCH-HAND OPERATED SH01 SWITCH-208-240V SELECT W6H3NZLV 09N050 TOGSW SPDT NO OFF 10A250V CONTROL BOX SHD SWITCH-ALTERNATE DRAIN W6H3NZDR 09N400CBNO CONTACT BLK ONLY 1-NO SQD#ZB2BE101 ALT DRAIN BX SHDO SWITCH-OPEN DOOR W6H3NZRH 09N405PB12 SWASS PB BLUE 1NO/2NC SWITCH PANEL
SHDOH SWITCH-DOOR OPEN W6H3NZS+A 09N405S320 SWASS S3W 2NO SWITCH PANEL SHDOH SWITCH-DOOR OPEN W6H3NZS+ 09N405S320 SWASS S3W 2NO SWITCH PANEL
SHDOJ SWITCH-DOOR OPEN JOG W6H3NZHDA 09N405PB10 SWASS PBBK 1NO SWITCH PANEL SHDOJ SWITCH-DOOR OPEN JOG W6H3NZRH 09N405PB10 SWASS PBBK 1NO SWITCH PANEL SHMD SWITCH-MILDATA LOCAL/REMOTE W6H3NZEVA 09N405M210 SWASS M2W 1NO PROCESSOR BX SHRM SWITCH-MOVE W6H3NZRH 09N405S320 SWASS S3W 2NO SWITCH PANEL SHSAD SWITCH-SAMPLE DESIRED W6H3NZDR 09N400CBNO CONTACT BLK ONLY 1-NO SQD#ZB2BE101 SAMPLE SWPL SHSMA SWITCH-MASTER W6H3NZS+A 09N405M210 SWASS M2W 1NO SWITCH PANEL
Page 5 of 8
5

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION SHSMA SWITCH-MASTER W6H3NZS+ 09N405M210 SWASS M2W 1NO SWITCH PANEL
SHSOE SWITCH-EMERGENCY STOP W6H3NZS+A 09N505 SW ASSY EMER STOP SWITCH PANEL
SHSOE SWITCH-EMERGENCY STOP W6H3NZS+ 09N505 SW ASSY EMER STOP SWITCH PANEL SHSOE SWITCH-EMERGENCY STOP ILLUMINATED W6H3NSFS 09N507B ESTOP ILLUMINATED 240VAC 1-NC CONTACT SWITCH PANEL SHWDO SWITCH-DOOR OPEN/CLOSE W6H3NZHDA 09N405S320 SWASS S3W 2NO SWITCH PANEL SHWDO SWITCH-DOOR OPEN/CLOSE W6H3NZRH 09N405S320 SWASS S3W 2NO SWITCH PANEL SHWJ SWITCH-JOG W6H3NZHDA 09N405PB11 SWASS PBBK 1NO/1NC SWITCH PANEL SHWJ SWITCH-JOG W6H3NZVP 09N405S310 SWASS S3W 1NO SWITCH PANEL SK >>>SWITCH-KEY OPERATED SKLPB SWITCH-LIGHT CURTAIN BY PASS W6H3NZLC 09N127C KEYSW SPST 7A120VAC SCREW TERM CONTROL BOX SM >>>SWITCH-MECHANICAL OPERATED SMEB SWITCH-EXCURSION W6H3NZI1 09R008A MICSW SPDT BZE6-2RN183 UNDER SHELL
SMPLL SWITCH-DOOR CLOSED W6H3NZS+A 09R014A MINI-SW SPDT STAKON #V15G1C26 DOOR LATCH SMPLL SWITCH-DOOR CLOSED W6H3NZS+ 09R014A MINI-SW SPDT STAKON #V15G1C26 DOOR LATCH SMWVB SWITCH-VIBRATION W6H3NZS+A 09R020 SWITCH NC VIBR#WZ-2RW84429-P52 CONTROL BOX SMWVB SWITCH-VIBRATION W6H3NZS+ 09R020 SWITCH NC VIBR#WZ-2RW84429-P52 CONTROL BOX SP >>>SWITCH-PRESSURE OPERATED SPBP PRESSURE SW-BEARING SEAL W6H3NZI1 09N082B05 PRESSW NASON CLOSE @ 5 LB AIR VALVE BX
SPD PRESSURE SW-LEVEL OK TO OPEN DOOR W6H3NZS+A 09N086A PRESS SWITCH EATON #738-761 CONTROL BOX SPD PRESSURE SW-LEVEL OK TO OPEN DOOR W6H3NZS+ 09N086A PRESS SWITCH EATON #738-761 CONTROL BOX SPOF PRESSURE SW-OVERFLOW W6H3NZEV 09N069 PRESS SW 4"WC INVENSYS 738-719 LEVEL SW BOX SPOF PRESSURE SW-OVERFLOW W6H3NZEVA 09N069 PRESS SW 4"WC INVENSYS 738-719 LEVEL SW BOX ST >>>SWITCH-TEMPERATURE OPERATED STDB SWITCH-THERMOSTAT W6H3NZS+A 30RA175T THERMOSTAT OPEN AT 175F CONTROL BOX VE >>>VALVE-ELECTRIC OPERATED VEAD VALVE-ALTERNATE DRAIN W6H3NZDR 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 ALT DRAIN BX VEBP VALVE-BEARING PRESSURE W6H3NZEV 96TBC2BA71 1/4" N/C 2WAY 220V50/60C VALVE AIR VALVE BX VEBP VALVE-BEARING PRESSURE W6H3NZEVA 96TBC2BA71 1/4" N/C 2WAY 220V50/60C VALVE AIR VALVE BX VEC01 VALVE-CHEMICAL #1 FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC VEC02 VALVE-CHEMICAL #2 FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC VEC03 VALVE-CHEMICAL #3 FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC VEC04 VALVE-CHEMICAL #4 FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC VEC05 VALVE-CHEMICAL #5 FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC
Page 6 of 8
6

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION VEC06 VALVE-CHEMICAL #6 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC07 VALVE-CHEMICAL #7 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC08 VALVE-CHEMICAL #8 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC09 VALVE-CHEMICAL #9 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC10 VALVE-CHEMICAL #10 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC11 VALVE-CHEMICAL #11 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC12 VALVE-CHEMICAL #12 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC13 VALVE-CHEMICAL #13 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC14 VALVE-CHEMICAL #14 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC15 VALVE-CHEMICAL #15 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEDL VALVE-DOOR UNLATCH W6H3NZS+A 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BOX
VEDL VALVE-DOOR UNLATCH W6H3NZS+ 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BOX
VEDRR VALVE-REUSE DRAIN W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEDRR VALVE-REUSE DRAIN W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEDRS VALVE-DRAIN W6H3NZEV 96D350A71 DRINVAL 3"MTRDR 240V 50/60C REAR OF MACH VEDRS VALVE-DRAIN W6H3NZEVA 96D350A71 DRINVAL 3"MTRDR 240V 50/60C REAR OF MACH VEEB1 VALVE-BALANCE RIB 1 W6H3NZEB2 96P053A71 3/4"VALVE 240V HAYS#6-2110IS-240 REAR OF MACH VEEB2 VALVE-BALANCE RIB 2 W6H3NZEB2 96P053A71 3/4"VALVE 240V HAYS#6-2110IS-240 REAR OF MACH VEEB3 VALVE-BALANCE RIB 3 W6H3NZEB2 96P053A71 3/4"VALVE 240V HAYS#6-2110IS-240 REAR OF MACH VEFL VALVE-FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC VEHDC VALVE-HYDRAULIC DOOR CLOSED W6H3NZHD 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR VEHDC VALVE-HYDRAULIC DOOR CLOSED W6H3NZHDA 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR VEHDO VALVE-HYDRAULIC DOOR OPEN W6H3NZHD 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR
VEHDO VALVE-HYDRAULIC DOOR OPEN W6H3NZHDA 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR
VEHTD VALVE-HYDRAULIC TILT DOWN W6H3NZRH 96RH711E71 DIRECTIONAL CNT VLV D05NG10 230V MACHINE REAR VEHTU VALVE-HYDRAULIC TILT UP W6H3NZRH 96RH711E71 DIRECTIONAL CNT VLV D05NG10 230V MACHINE REAR VEMTM VALVE-MACHINE TO MACHINE W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEMTM VALVE-MACHINE TO MACHINE W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEMTT VALVE-MACHINE TO TANK W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEMTT VALVE-MACHINE TO TANK W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEPPO VALVE-DOOR SEAL W6H3NZS+A 96R302A71 1/8" AIRPILOT 3W NO 240V50/60 AIR VALVE BOX
VEPPO VALVE-DOOR SEAL W6H3NZS+ 96R302A71 1/8" AIRPILOT 3W NO 240V50/60 AIR VALVE BOX VESTM VALVE-STEAM W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
Page 7 of 8
7

C O M P O N E N T P A R T S L I S T W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION VESTM VALVE-STEAM W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEWC VALVE-COLD WATER W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEWC VALVE-COLD WATER W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEWH VALVE-HOT WATER W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEWH VALVE-HOT WATER W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEWVX VALVE-EXTRA WATER W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEWVX VALVE-EXTRA WATER W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX WF >>>FLOW METER WFM METER-WATER W6H3NZBW 30F515 FLOW SENSOR SIGNET #P51530-PO INLET PIPING
Page 8 of 8
8

BMP720097/19036
PELLERIN MILNOR CORPORATION
LIMITED STANDARD WARRANTY
We warrant to the original purchaser that MILNOR machines including electronic hardware/software
(hereafter referred to as “equipment”), will be free from defects in material and workmanship for a
period of one year from the date of shipment (unless the time period is specifically extended for
certain parts pursuant to a specific MILNOR published extended warranty) from our factory with no
operating hour limitation. This warranty is contingent upon the equipment being installed, operated
and serviced as specified in the operating manual supplied with the equipment, and operated under
normal conditions by competent operators.
Providing we receive written notification of a warranted defect within 30 days of its discovery, we
will—at our option—repair or replace the defective part or parts, EX Factory (labor and freight
specifically NOT included). We retain the right to require inspection of the parts claimed defective in
our factory prior to repairing or replacing same. We will not be responsible, or in any way liable, for
unauthorized repairs or service to our equipment, and this warranty shall be void if the equipment is
tampered with, modified, or abused, used for purposes not intended in the design and construction
of the machine, or is repaired or altered in any way without MILNOR's written consent.
Parts damaged by exposure to weather, to aggressive water, or to chemical attack are not covered
by this warranty. For parts which require routine replacement due to normal wear—such as gaskets,
contact points, brake and clutch linings, belts, hoses, and similar parts—the warranty time period is
90 days.
We reserve the right to make changes in the design and/or construction of our equipment (including
purchased components) without obligation to change any equipment previously supplied.
ANY SALE OR FURNISHING OF ANY EQUIPMENT BY MILNOR IS MADE ONLY UPON THE EXPRESS
UNDERSTANDING THAT MILNOR MAKES NO EXPRESSED OR IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE OR PURPOSE OR ANY OTHER
WARRANTY IMPLIED BY LAW INCLUDING BUT NOT LIMITED TO REDHIBITION. MILNOR WILL NOT
BE RESPONSIBLE FOR ANY COSTS OR DAMAGES ACTUALLY INCURRED OR REQUIRED AS A RESULT
OF: THE FAILURE OF ANY OTHER PERSON OR ENTITY TO PERFORM ITS RESPONSIBILITIES, FIRE
OR OTHER HAZARD, ACCIDENT, IMPROPER STORAGE, MIS-USE, NEGLECT, POWER OR
ENVIRONMENTAL CONTROL MALFUNCTIONS, DAMAGE FROM LIQUIDS, OR ANY OTHER CAUSE
BEYOND THE NORMAL RANGE OF USE. REGARDLESS OF HOW CAUSED, IN NO EVENT SHALL
MILNOR BE LIABLE FOR SPECIAL, INDIRECT, PUNITIVE, LIQUIDATED, OR CONSEQUENTIAL COSTS
OR DAMAGES, OR ANY COSTS OR DAMAGES WHATSOEVER WHICH EXCEED THE PRICE PAID TO
MILNOR FOR THE EQUIPMENT IT SELLS OR FURNISHES.
THE PROVISIONS ON THIS PAGE REPRESENT THE ONLY WARRANTY FROM MILNOR AND NO OTHER
WARRANTY OR CONDITIONS, STATUTORY OR OTHERWISE, SHALL BE IMPLIED.
WE NEITHER ASSUME, NOR AUTHORIZE ANY EMPLOYEE OR OTHER PERSON TO ASSUME FOR US,
ANY OTHER RESPONSIBILITY AND/OR LIABILITY IN CONNECTION WITH THE SALE OR FURNISHING
OF OUR EQUIPMENT TO ANY BUYER.
9

How to Get the Necessary Repair Components
PELLERIN MILNOR CORPORATION
BIUUUD19 (Published) Book specs- Dates: 20081231 / 20081231 / 20081231 Lang: ENG01 Applic: UUU
How to Get the Necessary Repair Components
This document uses Simplified Technical English.
Learn more at http://www.asd-ste100.org.
You can get components to repair your machine from the approved supplier where you got this
machine. Your supplier will usually have the necessary components in stock. You can also get
components from the Milnor®factory.
Tell the supplier the machine model and serial number and this data for each necessary component:
• The component number from this manual
• The component name if known
• The necessary quantity
• The necessary transportation requirements
• If the component is an electrical component, give the schematic number if known.
• If the component is a motor or an electrical control, give the nameplate data from the used
component.
To write to the Milnor factory:
Pellerin Milnor Corporation
Post Office Box 400
Kenner, LA 70063-0400
UNITED STATES
Telephone: [phone]
Fax: [phone]
Email: [email protected]
— End of BIUUUD19 —
10

How to Use Milnor®Electrical Schematic Diagrams
PELLERIN MILNOR CORPORATION
BIUUUK01 (Published) Book specs- Dates: 20130308 / 20130308 / 20130308 Lang: ENG01 Applic: PCR UUU
How to Use Milnor®Electrical Schematic Diagrams
Milnor®electrical schematic manuals contain a table of contents/component list and a set of
schematic drawings. These documents are cross referenced and must be used together.
The table of contents/components list shows, for every component on every schematic in the
manual, the component item number (explained in detail below), statement of function, parent
schematic number, part number, description and electric box location. In older manuals, two
component lists are provided: List 1 sorts the components by function, and List 2 by type of
component. Newer schematic manuals include only the list sorted by component number.
The schematic drawings use symbols for each electromechanical component, and indicate the
function of each. Integrated circuits are not shown, but the function of each microprocessor input
and output is stated. Certain electrical components not pertinent to circuit logic, such as wire
connectors, are not represented on the schematic.
Most machines require several schematics to describe the complete control system and all the
options available on the included models. In most manuals there are some schematic pages that
don't apply to your specific machine because certain options and configurations are mutually
exclusive or are not necessary in all markets. You may find it helpful to mark or remove such
pages. A schematic page that only applies to a subset of machines will normally state, in the title,
which models and/or options it covers. Compare this with the nameplate on your machine and
with your purchase records.
Each schematic is devoted to circuits with common functions (e.g., microprocessor inputs, motor
contactors). Schematics appear in the manual in alphanumeric order.
1. Component Prefix Classifications and Descriptions
Component item numbers consist of up to six characters and appear as part of a component's
symbol on the schematic. The first two characters indicate the general class of component, and
the remaining characters are a mnemonic for the function. For example, “CD” is the code for all
time delay relays, and “SR” stands for safety reset. Thus, CDSR is a time delay relay that serves
as a safety reset.
The following are descriptions of electrical components used in Milnor®machines. Descriptions
are in alphabetical order by the component class code (two character prefix).
Note 1: Some component class codes do not have a corresponding symbol, but are represented by a box
and an accompanying note describing the component. Examples of such codes are BA (printed circuit
board), ED (electronic display), and ES (electronic power supply).
BA=Printed Circuit Board—Insulating substrate on which a thin pattern of copper conductors
has been formed to connect discrete electronic components also mounted on the board.
CB=Circuit Breaker (Figure 1)—Automatic switch that opens an electric circuit in abnormal
current conditions (e.g., an overload).
Figure 1: Circuit Breaker (CB)
CD=Control, Time Delay Relay (Figure 2)—A relay whose contacts switch only after a fixed
or adjustable delay, once voltage has been applied to its coil. The contacts switch back to
normal (de-energized state) immediately when the voltage is removed.
11

How to Use Milnor®Electrical Schematic Diagrams
PELLERIN MILNOR CORPORATION
Figure 2: Time Delay Relay (CD)
Coil and Contacts Legend
.
A. Coil
B. Contacts
CL=Control, Latch Relay (Figure 3)—A relay which latches in an energized or set position
when operated by one coil (the latch/set coil). The relay stays latched even though coil voltage
is removed. The relay releases or unlatches when voltage is applied to a second coil (the
unlatch/reset coil).
Figure 3: Latch Relay (CL)
Coils and Contacts Legend
.
A. Coils
B. Contacts
CR=Control, Relay (Figure 4)—A relay whose contacts switch immediately when voltage is
applied to its coil and revert to normal when the voltage is removed.
Figure 4: Standard Relay (CR)
Coils and Contacts Legend
.
A. Coil
B. Contacts
CP=Control, Photo-Eye (Figure 5)—Photo-eyes sense the presence of an object without direct
physical contact. Photo-eyes consist of a transmitter, receiver, and output module. These
components may be housed in one assembly with the transmitter bouncing light off of a
reflector to the receiver, or these components can be housed in two separate assemblies with
the transmitter pointed directly at the receiver. The photo-eye can be set to turn on its output
either when the light beam becomes blocked (dark operate) or when it becomes un-blocked
(light operate).
12

How to Use Milnor®Electrical Schematic Diagrams
PELLERIN MILNOR CORPORATION
Figure 5: Photo-eye (CP)
Symbols Legend
.
A. Example of single
assembly
B. Example of two separate
assemblies
CS=Control, Contactor/Motor Starter (Figure 6)—A relay capable of handling heavier
electrical loads, usually a motor.
Figure 6: Other Control Symbols
EB=Electric Buzzer (Figure 6)—An audible signaling device.
EC=Electric Clutch (Figure 6)—A clutch consists of a coil and a rotor. The rotor has two
separate rotating plates. These plates are free to rotate independent of each other until the coil
is energized. Once energized the two plates turn as one.
ED=Electronic Display—A visual presentation of data, such as an LCD (liquid crystal display),
LED (light emitting diode) display, or VFD (vacuum florescent display).
EF=Electric Fuse (Figure 6)—A fuse is an over-current safety device with a circuit opening
fusible member which is heated and severed by the passage of over-current through it.
EL=Electric Light (Figure 6)—Indicator lights may be either incandescent or fluorescent.
EM=Electro Magnet Solenoid—A device consisting of a core surrounded by a wire coil through
which an electric current is passed. While current is flowing, iron is attracted to the core (e.g.,
a pinch tube drain valve solenoid).
ES=Electronic Power Supply—A device that converts AC (alternating current) to filtered and
regulated DC (direct current). The input voltage to the power supply is usually 120 or 240
VAC. The output is +5, +12, and -12 VDC.
ET=Thermal Overload (Figure 7)—A safety device designed to protect a motor. A thermal
overload consists of an overload block, heaters, and an auxiliary contact. The auxiliary contact
is normally installed in a safety (three-wire) circuit that stops power to the motor contactor
coil when a motor overload occurs.
13

How to Use Milnor®Electrical Schematic Diagrams
PELLERIN MILNOR CORPORATION
Figure 7: Thermal Overload (ET)
Schematic Symbol Legend
.
A. Heater (one per phase)
B. Overload relay; contacts open if overload
condition exists
EX=Electrical Transformer (Figure 8)—A device that transfers electrical energy from one
isolated circuit to another, often raising or lowering the voltage in the process.
KB=Keyboard—Device similar to a typewriter for making entries to a computer.
MN=Electronic Monitor (CRT)—A cathode ray tube used for visual presentation of data.
MR=Motors (Figure 9)—Electromechanical device that converts electrical energy into
mechanical energy.
Figure 8: Transformer (EX) Figure 9: Electric Motor (MR)
MV=Motor (Variable Speed) Inverter—To vary the speed of an AC motor, the volts to
frequency ratio must be kept constant. The motor will overheat if this ratio is not maintained.
The motor variable speed inverter converts three phase AC to DC. The inverter then uses this
DC voltage to generate AC at the proper voltage and frequency for the commanded speed.
Note 2: Switch symbols used in the schematics and described below always depict the switch in its un-
actuated state.
PX=Proximity Switch (Figure 10)—A device which reacts to the proximity of an target without
physical contact or connection. The actuator or target causes a change in the inductance of the
proximity switch which causes the switch to operate. Proximity switches can be two-wire
(AC) or three-wire (DC) devices.
14

How to Use Milnor®Electrical Schematic Diagrams
PELLERIN MILNOR CORPORATION
Figure 10: Proximity Switches (PX)
Switch Symbols Legend
.
A. Alternating current
proximity switch
B. Direct current proximity
switch
SC=Switch, Cam Operated (Figure 11)—A switch in which the electrical contacts are opened
and/or closed by the mechanical action of a cam(s). Applications include 35-50 pound timer
operated machines, Autospot, timer reversing motor assembly, and some balancing systems.
SH=Switch, Hand Operated (Figure 12)—A switch that is manually operated (e.g., Start
button, Master switch, etc.).
Figure 11: Cam Switch (SC) Figure 12: Hand Operated Switch
(SH)
SK=Switch, Key Lock (Figure 13)—A switch that requires a key to operate. This prevents
unauthorized personnel from gaining access to certain functions (e.g., the Program menu).
SL=Switch, Level Operated (Figure 14)—A switch connected to a float that causes the switch
to open and close as the level changes.
Figure 13: Key Switch (SK) Figure 14: Level Switch (SL)
SM=Switch, Mechanically Operated (Figure 15)—A switch that is mechanically operated by a
part of or the motion of the machine (e.g., door closed switch, tilt limit switches, etc.)
SP=Switch, Pressure Operated (Figure 16)—A switch in which a diaphragm presses against a
switch actuator.
15

How to Use Milnor®Electrical Schematic Diagrams
PELLERIN MILNOR CORPORATION
Figure 15: Mechanical Switch (SM) Figure 16: Pressure Switch (SP)
ST=Switch, Temperature Operated (Figure 17)—A switch that is actuated at a preset
temperature (e.g., dryer safety probes) or has adjustable set points (e.g., Motometers or
Combistats).
TB=Terminal Board (Figure 18)—A strip or block for attaching or terminating wires.
Figure 17: Temperature Switch
(ST) Figure 18: Terminal Board (TB)
VE=Valve, Electric Operated (Figure 19)—A valve operated by an electric coil to control the
flow of fluid. The fluid can be air, water or hydraulic.
Figure 19: Electrically Operated
Valve (VE)
ZF=Rectifier (Figure 20)—A solid state device that converts alternating current to direct
current.
16
