Milwaukee as12e User manual

AS 12 E
AP 12 E
Original instructions

2 3
START STOP
7
SERVICE
10
9
8
4 5
6
AP 12 E AS 12 E
ENGLISH
Technical Data,Safety Instructions, Specifi ed Conditions of Use,
EC-Declaration of Conformity, Mains connection, Maintenance, Symbols
Please read and save
these instructions!
12

4 5
1
2
3
1
2
3
AS 12 EAP 12 E

6 7
1
2
AS 12 E
AP 12 E AP 12 E

8 9
1
A...................G
STOP
START
1 2
12
3
Switch can be locked

10 11
SERVICE
1
2
4
3
6
7
5
8
!

1312
AP 12 E AS 12 E
..................... 4557 94 04... ............. 4638 48 04...
..................... 4638 25 04... ............. 4638 52 04...
...000001-999999 ...000001-999999
.......................1200 W .........................1200 W
.........................600 W ...........................600 W
................900-2500 min-1 ............1800-4800 min-1
.......................4700 min-1 .....................9000 min-1
.........................150 mm ........................180 mm
.......................M 14 ............................M 14
..........................2,2 kg ............................2,5 kg
...........................79 dB(A) ....................81,5 dB(A)
...........................90 dB(A) ....................92,5 dB(A)
........................2,24 m/s2.............................- m/s2
..........................1,5 m/s2.............................- m/s2
..............................- m/s2.........................2,9 m/s2
..............................- m/s2.........................1,5 m/s2
ENGLISH
k) Position the cord clear of the spinning accessory. If
you lose control, the cord may be cut or snagged and your
hand or arm may be pulled into the spinning accessory.
l) Never lay the power tool down until the accessory has
come to a complete stop. The spinning accessory may
grab the surface and pull the power tool out of your control.
m) Do not run the power tool while carrying it at your
side. Accidental contact with the spinning accessory could
snag your clothing, pulling the accessory into your body.
n) Regularly clean the power tool’s air vents. The motor’s
fan will draw the dust inside the housing and excessive
accumulation of powdered metal may cause electrical
hazards.
o) Do not operate the power tool near fl ammable
materials. Sparks could ignite these materials.
p) Do not use accessories that require liquid coolants.
Using water or other liquid coolants may result in
electrocution or shock.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged
rotating wheel, backing pad, brush or any other accessory.
Pinching or snagging causes rapid stalling of the rotating
accessory which in turn causes the uncontrolled power tool
to be forced in the direction opposite of the accessory’s
rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by
the workpiece, the edge of the wheel that is entering into the
pinch point can dig into the surface of the material causing
the wheel to climb out or kick out. The wheel may either
jump toward or away from the operator, depending on
direction of the wheel’s movement at the point of pinching.
Kickback is the result of power tool misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below.
a) Maintain a fi rm grip on the power tool and position
your body and arm to allow you to resist kickback
forces. Always use auxiliary handle, if provided, for
maximum control over kickback or torque reaction
during start-up. The operator can control torque reactions
or kickback forces, if proper precautions are taken.
b) Never place your hand near the rotating accessory.
Accessory may kickback over your hand.
c) Do not position your body in the area where power
tool will move if kickback occurs. Kickback will propel the
tool in direction opposite to the wheel’s movement at the
point of snagging.
d) Use special care when working corners, sharp edges
etc. Avoid bouncing and snagging the accessory.
Corners, sharp edges or bouncing have a tendency to snag
the rotating accessory and cause loss of control or kickback.
e) Do not attach a saw chain, woodcarving blade or
toothed saw blade. Such blades create frequent kickback
and loss of control.
AS 12 E:
Safety Warnings Specifi c for Sanding Operations:
a) Do not use excessively oversized sanding disc paper.
Follow manufacturers recommendations, when
selecting sanding paper. Larger sanding paper extending
beyond the sanding pad presents a laceration hazard and
may cause snagging, tearing of the disc or kickback.
AP 12 E:
Safety Warnings Specifi c for Polishing Operations:
a) Do not allow any loose portion of the polishing
bonnet or its attachment strings to spin freely. Tuck
away or trim any loose attachment strings. Loose and
spinning attachment strings can entangle your fi ngers or
snag on the workpiece.
Appliances used at many diff erent locations including open
air should be connected via a residual current device of
30 mA or less.
Dust and splinters must not be removed while the machine
is running.
Only plug-in when machine is switched off .
Never reach into the danger area of the tool when it is
running.
Always use the auxiliary handle.
Immediately switch off the machine in case of considerable
vibrations or if other malfunctions occur. Check the machine
in order to fi nd out the cause.
Always use and store the grinding disks according to the
manufacturer's instructions.
When grinding metal, fl ying sparks are produced. Take care
that no persons are endangered. Because of the danger of
fi re, no combustible materials should be located in the
vicinity (spark fl ight zone). Do not use dust extraction.
Due care should be taken that no sparks or sanding dust
fl ying from the workpiece come into contact with you.
The adjusting nut must be tightened before starting to work
with the machine.
The workpiece must be fi xed if it is not heavy enough to be
steady. Never lead the workpiece to the grinding disk with
your hand.
Under extreme conditions (e.g. smooth-grinding metals with
the arbour and vulcanized fi bre grinding wheel), signifi cant
contamination can build up on the inside of the angle
grinder. For safety reasons, in such conditions the inside
should be cleaned thoroughly of metal deposits and a motor
circuit-breaker must be connected in series. If the motor
circuit-breaker trips the machine must be sent for repair.
For accessories intended to be fi tted with threaded hole
wheel, ensure that the thread in the wheel is long enough to
accept the spindle length.
SPECIFIED CONDITIONS OF USE
AP 12 E: The polisher can be used for polishing lacquers,
coatings, plastics and other smooth surfaces.
AS 12 E: The sander can be used for sanding wood,
plastics and metal.
Do not use this product in any other way as stated for
normal use.
STARTING CURRENT LIMITER + SMOOTH START
The starting current for the machine is several times greater
than rated current. The starting current limiter reduces the
starting current to such an extent that a fuse (16 A,
slow-blow) is not tripped.
Electronic smooth start for save use prevents jerky run-up of
the machine.
ELECTRONICS
The speed of rotation is adjusted electronically when the
load increases.
In case of a longer overload period the speed is decreased
electronically. The machine continues to run slowly to cool
down the motor coil. After switching off and on the machine
can be used at rated load.
STARTUP PROTECTION
A zero-voltage switch prevents the machine from restarting
after a power failure. On resuming work, switch the machine
off and then back on again.
ENGLISH
TECHNICAL DATA Polisher/Sander
Production code.......................................................................
..............................................................................................
Rated input ..............................................................................
Output ......................................................................................
Rated speed ............................................................................
Max. Rated speed ...................................................................
Grinding disk diameter.............................................................
Thread of work spindle ...........................................................
Weight according EPTA-Procedure 01/2014 ...........................
Noise/Vibration Information
Measured values determined according to EN 60745.
Typically, the A-weighted noise levels of the
tool are:
Sound pressure level (Uncertainty K=3dB(A))......................
Sound power level (Uncertainty K=3dB(A)) ..........................
Wear ear protection!
Total vibration values (vector sum in the three axes)
determined according to EN 60745:
Polishing: vibration emission value ah .....................................
Uncertainty K = ........................................................................
Disk sanding vibration emission value ah ................................
Uncertainty K = ........................................................................
WARNING
WARNING! Read all safety warnings and all
instructions, including those given in the accompanying
brochure. Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
POLISHER/SANDER SAFETY INSTRUCTIONS
Safety warnings that are common for polishing and
sanding:
a) This power tool is intended to function as a polisher
(only AP 12 E) or sander (only AS 12 E). Read all safety
warnings, instructions, illustrations and specifi cations
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, fi re
and/or serious injury.
b) Operations such as sanding (only AP 12 E), polishing
(only AS 12 E), grinding, wire brushing, or cutting-off
are not recommended to be performed with this power
tool. Using the electric tool for purposes other than those for
which it is designed may cause dangers and injuries.
c) Do not use accessories which are not specifi cally
designed and recommended by the tool manufacturer.
Just because the accessory can be attached to your power
tool, it does not assure safe operation.
d) The rated speed of the accessory must be at least
equal to the maximum speed marked on the power tool.
Accessories running faster than their rated speed can break
and fl y apart.
e) The outside diameter and the thickness of your
accessory must be within the capacity rating of your
power tool. Incorrectly sized accessories cannot be
adequately guarded or controlled.
f) The arbour size of wheels, fl anges, backing pads or
any other accessory must properly fi t the spindle of the
power tool. Accessories with arbour holes that do not
match the mounting hardware of the power tool will run out
of balance, vibrate excessively and may cause loss of
control.
g) Do not use a damaged accessory. Before each use
inspect the accessory such as backing pad for cracks,
tear or excess wear. If power tool or accessory is
dropped, inspect for damage or install an undamaged
accessory. After inspecting and installing an accessory,
position yourself and bystanders away from the plane
of the rotating accessory and run the power tool at
maximum no-load speed for one minute. Damaged
accessories will normally break apart during this test time.
h) Wear personal protective equipment. Depending on
application, use face shield, safety goggles or safety
glasses. As appropriate, wear dust mask, hearing
protectors, gloves and shop apron capable of stopping
small abrasive or workpiece fragments. The eye
protection must be capable of stopping fl ying debris
generated by various operations. The dust mask or
respirator must be capable of fi ltrating particles generated
by your operation. Prolonged exposure to high intensity
noise may cause hearing loss.
i) Keep bystanders a safe distance away from work
area.
Anyone entering the work area must wear personal
protective equipment.
Fragments of workpiece or of a broken
accessory may fl y away and cause injury beyond immediate
area of operation.
j) Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring. Cutting accessory contacting
a „live“ wire may make exposed metal parts of the power
tool „live“ and could give the operator an electric shock.
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent
applications, with diff erent accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.

1514 ENGLISH
EC-DECLARATION OF CONFORMITY
We declare as the manufacturer under our sole
responsibility that the product described under “Technical
Data” fulfi lls all the relevant regulations and the directives
2011/65/EU (RoHS), 2014/30/EU, 2006/42/EC, and the
following harmonized standards have been used:
EN 60745-1:2009+A11:2010
EN 60745-2-3:2011+A2:2013
EN 55014-1:2017+A11:2020
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN IEC 63000:2018
Winnenden, 2021-01-22
Alexander Krug
Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
GB-DECLARATION OF CONFORMITY
We declare as the manufacturer under our sole responsibility
that the product described under “Technical Data” fulfi lls all
the relevant provisions of the following Regulations S.I.
2008/1597 (as amended), S.I. 2016/1091 (as amended), S.I.
2012/3032 (as amended) and that the following designated
standards have been used:
BS EN 60745-1:2009+A11:2010
BS
EN 60745-2-3:2011+A13:2015
BS EN 55014-1:2017+A11:2020
BS EN 55014-2:2015
BS EN 61000-3-2:2014
BS EN 61000-3-3:2013
BS EN IEC 63000:2018
Winnenden, 2021-01-22
Alexander Krug
Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all
times.
Use only Milwaukee accessories and spare parts. Should
components need to be exchanged which have not been
described, please contact one of our Milwaukee service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the machine type printed as well as the six-digit
No. on the label and order the drawing at your local service
agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany.
SYMBOLS
CAUTION! WARNING! DANGER!
Always disconnect the plug from the socket
before carrying out any work on the machine.
Please read the instructions carefully before
starting the machine.
Always wear goggles when using the
machine.
Wear gloves!
Do not use force.
Accessory - Not included in standard
equipment, available as an accessory.
Do not dispose electric tools, batteries/
rechargeable batteries together with
household waste material.
Electric tools and batteries that have reached
the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
Check with your local authority or retailer for
recycling advice and collection point.
Class II tool, tool in which protection against
electric shock does not rely on basic
insulation only, but in which additional safety
precautions, such as double insulation or
reinforced insulation, are provided.
There being no provision for protective
earthing or reliance upon installation
conditions.
European Conformity Mark
British Confomity Mark
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Ukraine Conformity Mark
EurAsian Conformity Mark

(01.21)
4931 4705 49
Copyright 2021
Techtronic Industries GmbH
Max-Eyth-Str. 10
71364 Winnenden
Germany
[phone]
www.milwaukeetool.eu
Techtronic Industries (UK) Ltd
Fieldhouse Lane
Marlow Bucks SL7 1HZ
UK
