MIMAKI CJV300-130 Maintenance manual

1
Inkjet Printer CJV300-130/160, CJV300-130/160 Plus
Requests for Care and Maintenance
This machine is a precision machine equipped with extremely fine mechanisms. Especially, the nozzle sur-
face of the heads from which the ink is discharged is affected even by a slightest attachment of dust or paper
powder and the proper printing results could not be obtained. With a view to using this machine in a better
condition, we would like to recommend performing the following care and maintenance on daily basis.
1. When to care
When to care What to care Reference Page
When the Machine Is Not Used
for a Long Time Perform “Storage Wash” P.2
Once a day
(at the end of the daily work)
Surroundings of the heads P.4
Capping station P.5
Wiper P.6
Media press P.7
Media sensor P.7
Once a week
(at the end of the work on
weekend)
Cleaning the Platen P.8
Exterior P.8
Waste ink tank P.8
Ink Discharge Passage P.9
Replace or clean when it is dirty
Replacing the exhaust BOX filter or exhaust BOX. P.10
Replace the blow down fan filter. P.11
Replace the CP pad set. P.12
Replacing the pen line rubber or pen line sponge. P.13
Cleaning and replacing the pinch roller. P.14
Tools required for maintenance
• Cleaning stick (SPC-0527)
• Maintenance washing liquid kit for solvent (SPC-0369) /
Cleaning solution bottle kit A29 (SPC-0137)
• Cotton swab
• Safety glasses
• Gloves
• Soft fabric

2
2. Safety Precautions
]
3. Installation environment
• Use this printer as much as possible in a dust-free environment. Fans and air-blowers could cause the
dust scattering.
• The using environment of this printer is from 20 to 30°C (68°F to 86°F) in temperature and from 35 to 65 %
in relative humidity. Avoid the use of this printer at a temperature and humidity higher or lower than the
indicated ranges.
4. When the printer is not used for a long period
When the printer is not to be used for a period of one week or above, perform the cleaning of the heads and
nozzles and the ink discharging channel before storing this printer.
When cleaning, be sure to provide adequate ventilation and be sure to wear the supplied protective
glasses and gloves.
When ink is mixed with water or alcohol, aggregates are generated. Do not to allow water or alcohol to
deposit to the nozzle surface, around the head, cap, and wiper.
To ensure ink ejection stability, this machine must periodically eject (flush) a small amount of ink
depending on the ink type when it is not used (output) for a long time.
When not using this machine for an extended period of time, execute the [CUSTODY WASH] function,
("When the Machine Is Not Used for a Long Time (CUSTODY WASH)" Chapter 4 of Operation Man-
ual) and turn off only the power button on the front panel. The main power switch on the right side
should be on (in the state of |) and the outlet should be inserted.
Never disassemble the machine. Failure to do so may cause electric shock, fire or damage.
Make sure that no moisture enters the machine. If the inside gets wet, it may cause electric shock, fire
and damage.
Before cleaning, turn off the power switch and disconnect the power cable. It may cause an unex-
pected accident.
Do not use chemicals containing benzine, thinner or abrasives. The cover surface may be altered or
deformed.
Do not lubricate the machine with lubricating oil.
There is a risk of failure.

3
5. Storage of ink cartridge
Be careful of the followings to store.
• Store the ink cartridge in no direct sunlight, and no high humidity.
• As it's a delicate product, do not drop it.
• IC chip should not be contaminated and discharged static electric-
ity.
• Be sure to store the ink cartridge and the IC chip together.
6. Storage of media
Media should be stored in the little dust area, and not in direct sunlight. Avoid storing the media in the area
with high temperature and high humidity.
The IC chip mounted on the ink cartridge

4
7. Daily care
(1) Surroundings of the heads ("Cleaning the Ink Head and the Area around It" Chapter 5
of the Operation Manual)
• Maintenance washing liquid kit for solvent (SPC-0369) / Cleaning solution bottle kit A29 (SPC-0137)
1Move the carriage.
• Refer to the Step 1 to 4 of Chapter 5 “Cleaning the
Ink head and The area around It” of the operation
manual to perform the operation.
2Soak the clean stick or the waste cloth in the maintenance cleaning liquid and wipe
off an accumulated ink on the side of the head and on the bottom surface of the
slider.
• Never rub the nozzles.
• When possible, use the cleaning stick (SPC-0527) for cleaning around the head/ capping station/ wiper.
Using the other cotton bud may attach lint, then it may damage the machine.
• Be sure to perform maintenance for the ink cap and the wiper of capping station every day. If you leave it
dirty, dirt may adhere to the nozzle surface, or, dust and dry ink may be rubbed against the nozzle. It may
cause discharge defect.
• Clean the bottom of carriage every day so that it will not get dirt from inks or dusts. If you leave it dirty, dust
and dry ink may be rubbed against the nozzle at wiping operation when performing head cleaning.
• When you clean the carriage bottom surface, fully be careful not to rub the nozzle surface.
• The heads and their surroundings are the parts most liable to be tainted in this machine and if
tainted, it could cause adverse effects to the functions of the machine and the results of the printings.
Moreover, as the head itself uses very fine mechanisms, sufficient precautions are required for the
care and maintenances.
Maintenance cover
Head
maintenancec
over
Clean the side surface of the head
(shown in deep gray) with a clean stick.
The nozzle part (Never
touch it.)
Clean with a clean stick or a waste cloth.

5
(2) Capping Station ("Cleaning the Wiper and Cap" Chapter 5 of the Operation Manual)
The surrounding area of the cap is also liable to be stained by the dust and ink. It is recommended to clean
the head frequently using the cleaning liquid for maintenance suitable for the ink used to avoid the stains on
the head.
• Maintenance washing liquid kit for solvent (SPC-0369) / Cleaning solution bottle kit A29 (SPC-0137)
1Move the carriage.
• Refer to the Step 1 to 5 of Chapter 5 “Cleaning the
Wiper and Cap” of the operation manual to perform
the operation.
2Clean the cap.
• Dip the clean stick into the cleaning liquid for
maintenance and wipe off the cap. Wipe off so that
cleaning solution for maintenance will not remain.
Carriage
Cap

6
(3) Wiper ("Cleaning the Wiper and Cap” Chapter 5 of the Operation Manual)
On the wiper, the ink, dust and paper powder are liable to accumulate. Check the state of the wiper and if it is
stained, clean it.
• Maintenance washing liquid kit for solvent (SPC-0369) / Cleaning solution bottle kit A29 (SPC-0137)
1Move the carriager.
• Refer to the Step 1 to 2 of Chapter 5 “Cleaning the
Wiper and Cap” of the operation manual to perform
the operation.
2Clean the wiper.
• Remove the wiper by holding the protrusions at its
both ends.
• Wipe off the ink sticking to the wiper and bracket with
a clean stick dipped in cleaning solution for
maintenance. Wipe off so that cleaning solution for
maintenance will not remain.
Further, in the cases as explained below, replace the wiper with the new one (SPA-0134) in accordance with
"Replacing the wiper" on Chapter 4 of the Operation Manual.
• When the wiper is deformed
• When the stuck ink can not be wiped off
• When the warning for wiper replacement is indicated
Carriage
Wiper
Projection
Bracket

7
(4) Media press (“Cleaning the Media Press” Chapter 5 of the Operation Manual)
When the cut dust of the media and other dusts accumulate between the media holder and the platen, it could
cause the risks that the transfer of the media could not be performed properly or such dusts stick to the noz-
zles and this could interfere the proper printings. You are recommended to clean it frequently.
(5) Media sensor ("Cleaning the Media Sensor" Chapter 5 of the Operation Manual)
The media sensors are located on the platen in the backside and the bottom surface of the head.
If the dusts and ink accumulate on the sensor, it could cause false detection of the media or the register mark.
Wipe off the sensors with soft cloth or clean sticks.
• For the cleaning of the media sensors, never use the solvent.
• When the sensor is heavily stained, use a soft cloth soaked in a neutral detergent diluted with water,
wrung out,and then wiped off.
Media sensor Media sensor
The backside of the machine The lower surface of the head

8
8. Periodically care (Once a week)
Users are advised to perform the maintenance works described below once a week so that the printer will
keep its high performance and accuracy over an extended period of its life.
(1) Platen (“Cleaning the Platen” Chapter 5 of the Operation Manual)
Continuing to use the media while it is dirty may cause
media to be fed incorrectly, or rubbing dirt or solid ink
onto the head nozzle surface, resulting in discharge fail-
ure (nozzle clogging, deflection, etc.).
(2) Exterior (“Cleaning the Exterior Surfaces” Chapter 5, Operation Manual)
When the exterior surfaces of the machine are stained,
dampen a soft cloth with water or a neutral detergent
diluted with water, squeeze it, and wipe the surfaces
with the cloth.
(3) Waste ink tank (“If a Waste Ink Tank Confirmation Message Appears” Chapter 5 of
the Operation Manual)
Check whether the waste ink tank is full or not. Take care so that the
waste ink never overflows the tank.
• Turn off the main power and unplug the
power cable before maintenance.
• Do not allow liquids to enter the machine.
There is a risk of equipment failure, electric
shock, or fire.
• If the dirt is noticeable, use a soft cloth
soaked in a neutral detergent diluted with
water, wrung out,and then wiped off.
• Before cleaning the platen, make sure that
the platen has cooled adequately.
• The groove that slides the media press and
the groove that cuts the media are
particularly easy to collect dust. Please
carefully remove the dust.

9
(4) Ink Discharge Passage
(“Washing the Ink Discharge Passage” Chapter 5 of the Operation Manual)
Wash the ink discharge passage (DISWAY WASH) regularly (about once a week) to prevent the head nozzles
from clogging due to ink coagulation inside the passage.
1Select “MAINTENANCE” menu  “STATION”  “DISWAY WASH”.
• Refer to the Step 1 to 3 of Chapter 5 “Washing the Ink Discharge Passage” of the operation manual to
perform the operation.
• The carriage will move onto the platen.
2Press [ENTER] key.
• Dry suction operation is performed repeatedly until the washing work is completed.
3Fill up the cap with cleaning solution for
maintenance.
• If the cleaning solution cartridge is usable,
maintenance solution is automatically filled. If there is
not enough maintenance solution, press the [FUNC2]
key to add maintenance solution.
4Press the [ENTER] key.
• Before washing the ink discharge passage, make sure that the maintenance washing liquid is set. If
the maintenance washing liquid is not set, washing operation will not be conducted and the passage
could be clogged.
• If the cleaning solution cartridge is not usable, suck
maintenance solution into a dropper and fill up the cap
with it. Fill up the cap with maintenance solution on the
verge of overflow from the cap.

10
9. Replace or clean when it is dirty
(1) Replacing the exhaust BOX filter or exhaust BOX.
Replace the exhaust BOX filter (product number: SPA - 0249) or the exhaust BOX (product number: SPA -
0248) when it is dirty with ink.
1Remove the tabs (2 locations) on the exhaust
BOX.
• There are tabs engaged at the rear of the exhaust box
also.
2Remove the exhaust BOX and exhaust BOX
filter.
3Replace the exhaust BOX filter or the exhaust
BOX with a new one.
4Attach the exhaust BOX filter to the exhaust
BOX.
• Insert the exhaust BOX filter in the exhaust BOX tabs.
5Attach the exhaust BOX to its original location.
• Engage the exhaust box rear tabs into the machine body, then push in the front part of the box.
Exhaust BOX filter
Exhaust BOX
Exhaust BOX filter
Exhaust BOX

11
(2) Replace the blow down fan filter.
Replace the blow down fan filter (SPC-0774) when it is dirty.
1Remove the fan filter cover.
• Push the fan filter cover's tab outward, and pull
the cover out toward you.
2Remove the blow down fan filter.
3Attach a new blow down fan filter and
return the fan filter cover.
• Fit the fan filter cover on firmly, so that it clicks
into place.
Fan filter cover
Tabs
Blow down fan filter

12
(3) Replace the CP pad set.
Replace CP pad set (SPA-0257) when it is dirty.
1Push up the tabs (2places) of CP pad
Assy.
2Remove the CP pad Assy.
3Attach a new CP pad Assy.
• After inserting the tabs of CP pad Assy to the
slit of C slider, fit the whole.
CP pad Assy
CP pad Assy
Tabs
C Slider
Press to lock the tab

13
(4) Replacing the pen line rubber or pen line sponge.
There are two types of pen line, one is rubber type and the other is sponge type.
Use the pen line rubber when writing with a pen or cutting a sheet.
Use the pen line sponge when cutting on the dotted line (half cut).
If the pen line rubber (PN: SPC - 0770 or SPC - 0771) or pen line sponge gets worn, replace it (PN: SPC -
0775 or SPC - 0776).
1Remove a pen line rubber or pen line sponge with tweezers.
• If double-sided tape glue remains in the groove of this
machine, wipe off the glue with alcohol.
2Attach the attached double-sided tape to the groove of this machine.
3Put a new pen line rubber or pen line sponge on double-sided tape.
• Put a new pen line rubber or new pen line sponge flattened
on the two-sided tape.

14
(5) Cleaning and replacing the pinch roller.
Clean the pinch roller (product number: SPA-0166 or SPA-0167) when it is dirty.
Also, when the pinch roller wears out or the dirt of the pinch roller does not fall, replace the pinch roller.
1Raise the clamp lever.
2Remove the O-ring retaining the pinch roller.
3Pull out the Pinch Roller shaft with care not to
drop the pinch roller.
4Remove the pinch roller.
5Clean or replace the O-ring and pinch roller.
• Wipe off the ink sticking to the O-ring and pinch roller with a
clean stick dipped in cleaning solution for maintenance. Wipe
off so that cleaning solution for maintenance will not remain.
• If it does not become clean even after cleaning, replace the
pinch roller with the following procedure.
(1) Install a new pinch roller.
(2) Insert the PR axis and fit O ring.
• Be careful not to drop the parts in the gap of
the machine as they are small.
O-ring
Pinch roller
PR shaft

15
10. The examples of defective printing
These following examples indicate improper head (nozzle) firing by dust, which effect printing.
Confirm the nozzle condition periodically before or during outputting not to use in such as this condition.
The nozzle condition can be confirmed with [test printing] in this plotter. (Operation manual Chapter 2 “Test
Printing”)
1
10
21
30
41
50
61
70
81
90
101
110
121
130
141
150
161
170
181
190
201
210
221
230
1
10
21
30
41
50
61
70
81
90
101
110
121
130
141
150
161
170
181
190
201
210
221
230
1.Deflection 2.Nozzle out 3.Ink dropping
4.Satellite 5.Mixing in air

16
11. Recovery method of defective nozzle discharge
When this printer has not been used for an extended period of time, or depending on the environmental tem-
perature, the discharge at the nozzles could become unstable. In such a case, the following methods may be
taken to recover the status of the nozzles.
For symptoms 1 to 4 in P.15 “The examples of defective printing”
12. Supplies
1.Daily maintenance and care
Perform the cleaning of the parts described in this document.
2. Performing Head Cleaning (normal). Refer to Chapter 2 of
Operation Manual.
After having performed the care and maintenance stated in step 1, perform
the cleaning of the heads in accordance with the procedures stated in
Operation Manual.
Perform test printing and
check
(Chapter 2 of Operation Manual)
In the event nozzle missing etc. have not been improved
3. Performing Head Cleaning (hard). Refer to Chapter 2 of
Operation Manual.
If the nozzle missing does not disappear even after repeating the head
cleaning (normal) several times, reset the cleaning mode to "hard" and
perform the cleaning again.
Perform test printing and
check
(Chapter 2 of Operation Manual)
In the event nozzle missing etc. have not been improved
4. Perform the cleaning of the head nozzles. Refer to Chapter
5 of Operation Manual.
Perform the cleaning of the head nozzles. In this case, leaving time of the
cleaning liquid for maintenance shall be made [1 minute].
Perform test printing and
check
(Chapter 2 of Operation Manual)
In the event nozzle missing etc. have not been improved
5. Perform the cleaning of the head nozzles again. Refer to
Chapter 5 of Operation Manual
Reset the leaving time of the cleaning liquid for maintenance to [10
minutes], and perform the cleaning of the head nozzles again.
Perform test printing and
check
(Chapter 2 of Operation Manual)
• If the nozzle clogging does not recover after the above operations, contact your local distributor, our
sales office, or our call center.
Product Name Product No. Product Name Product No.
Cleaning solution bottle kit A29 SPC-0137 Wiper kit 33S SPA-0134
Maintenance washing liquid kit for solvent SPC-0369 Pinch Roller Set 4pcs SPA-0166
Cleaning Stick for Head Surrounding (50 sticks) SPC-0527 Pinch Roller Set 3pcs SPA-0167
Pen Line Rubber for 300/150-160 SPC-0770 Wiper cleaner SPA-0243
Pen Line Rubber for 300/150-130 SPC-0771 Square waste ink tank 2L SPA-0246
300 Fan Filter SPC-0774 Exhaust BOX SPA-0248
Pen Line Sponge for 300/150-160 SPC-0775 Exhaust BOX filter SPA-0249
Pen Line Sponge for 300/150-130 SPC-0776 CP pad set 2 SPA-0257
Cutter blades ASSY SPA-0107

17
Memo

18

19

You can also download the latest manual from our website.
 2014 MIMAKI ENGINEERING CO., LTD.
D202748-32-16102019 MM
FW : 2.80 (CJV300)
1.10 (CJV300 Plus)
