MIMAKI CJV300-130 User manual

Mimaki Europe B.V.
Sign Graphics Products
Print&Cut
Imagination to Creation
The information in this document is subject to change without notice.
Product Guide
07-03-2019
V1.61EU

Mimaki Europe B.V.
Sign Graphics Products
Terms of use
•The contents of this presentation are intended only for Mimaki authorized
resellers. Authorized persons are not permitted to distribute, copy or change
this presentation without explicit approval of Mimaki Europe B.V.
•Contents and technical explanations in this presentation are based on the
test results achieved at Mimaki at the time of testing and are not a guarantee
for performance. Substrates should be tested beforehand.
•In addition, the contents in this presentation do not lead to any legal
obligations from Mimaki and Mimaki does not take any responsibility. Please
verify in advance whether your intended prints will result in sufficient
quality.
•Contents of this presentation are subject to change without prior notice for
improvement. Compositors errors reserved.
2

Mimaki Europe B.V.
Sign Graphics Products
Features
3
•Maximum print speed of 105.9 sqm/h with SS21 inks
•High productivity with the staggered dual-heads design and high
densities
•SS21’s silver ink expresses unforeseen high-intensity metallic
•SS21’s silver ink has a 67% higher reflection level, compared to
conventional silver ink
•Easy color matching with the Metallic color collection
includes 756 metallic colors
•High fidelity color reproductions with Orange ink & Light
Black ink
•Wider color gamut printing by orange ink allows printing corporate
colors
•Light black ink produces accurate grayscale printing without color
shifts

Mimaki Europe B.V.
Sign Graphics Products
Features
4
•High quality printing by Mimaki’s original technologies
•Smooth image quality by waveform control and precise dot placing
technology
•Variable dot printing by 3 different drop sizes of small/middle/large
•Mimaki’s proprietary 3-way intelligent heater optimizes dot sizes
•MAPS3 eliminates banding and delivers smooth print densities
•A wide variety of Print&Cut functions
•Continuous crop mark detection for unattended, high quality P&C
operation
•Zero margin crop mark eliminates margins between crop marks,
reducing media waste
•Cut & Print allows for high quality finish, when using thin media such
as heat transfer media
•Over cut and Corner cut functions cut edges sharp even when using
thick media

Mimaki Europe B.V.
Sign Graphics Products
System configuration
Options
MBIS3
Drying fan
Air exhaust unit
Static prevention sheet
Front cover
8x Eco-cartridge for 600ml BS3/BS4 inks
Including Rip software
PC
Works also with:
USB 2 0
5m(15ft) cable is recommended
Connection
Recommended PC configuration
CPU: Core i5 3.5GHz
Memory: 8GB
HDD: 500GB
I/F : USB2.0, 4 ports or more
ODD: DVD-ROM
Network: 1000BASE-T
Compatible OS: Windows Vista(32/64bit)
Windows 7(32/64bit)
Windows 8(32/64bit)
Windows 10(32/64bit)
Monitor: 1366x768
5

Mimaki Europe B.V.
Sign Graphics Products
Ink type
SS21 ES3 BS3 / BS4* Sb53 Sb54
Eco Solvent Eco Solvent
(Low odor) Solvent Sublimation Sublimation
Colors 10C*6C 4C 6C* 4C
Ink Sets
6C+WSi: Silver included 4C: High speed printing 4C: High speed printing 4C: High speed printing 4C: High speed printing
4C: High speed printing 6C: Smooth Result 6C: Smooth Result
8C: Smooth result &
vibrant expression
6C+WW: 6C plus white
printing
Lk/Or/W/Si included
Lk/Or/W 2 included
Ink
Capacity
MCYKLcLmLkOr:
-440ml cartridge
-2L Ink pack (for MBIS3)
WSi: 220ml cartridge
-440ml cartridge -600ml Ink pack
(with Eco-cartridge)
-2L Ink pack (for MBIS3)
-440ml cartridge
-2L Ink pack (for MBIS3) 2L Ink pack (for MBIS3)
**Up to 8 colors can be
set out of 10 colors. *BS4 has low odor *K is also available
M C Y KKY C M
M C Y KLc Lm Lk Or
M C Y KKY C M
M C Y KKY C M
6
Ink Type / Ink Set
MT BLT YT KT KT YT BLT MT
M C Y KLk Or W W
M C Y KLk Or WSi
6

Mimaki Europe B.V.
Sign Graphics Products
Print heads configuration
•Staggered dual-head design
•The 2 print heads, positioned in a staggered configuration, make high speed
printing possible
•Capable of ejecting 7 different drop sizes of 4pl/7pl/8pl/14pl/16pl/24pl/35pl
Approx.
50.8mm
(2 inch)
1 2 3 45 6 7 8
Nozzle row length
Approx.25.4mm
(1 inch)
Nozzle width
Approx.31mm
(1.2 inch)
Approx. 101mm (3.9 inch)
1-head:1440-nozzle
(180-nozzle x 8-lines) Staggered Dual-head design
123 4 5 6 7 8
7

Mimaki Europe B.V.
Sign Graphics Products
Highly versatile printer
•Larger ink drop
•3 different drop sizes are automatically selected from 7drop sizes, depending
on the selected print quality (profile)
•When working with SS21, the 7 drop sizes are 4pl,7pl,8pl,14pl,16pl,24pl, and 35pl
•For high speed printing with high densities, the variable dot technology with a maximum
dot size of 35pl is used for the highest productivity of 105.9m²/h with SS21/BS3/BS4, and
112.5m²/h with SB53/SB54
•This gives the printer a wide coverage, from high resolutions with high qualities to low
resolution printing, with higher densities
Case 1 : Maximum dot size =21pl Case 2 : Maximum dot size =35pl
Large
21ｐｌ
Middle
14ｐｌ
Small
4ｐｌ
1 /360 inch
1 /360
inch
Large
35ｐｌ
Middle
14ｐｌ
Small
4ｐｌ
1 /360 inch
1 /360
inch
Low density due to an gap between the dots
↓
Not suitable for high speed mode (low resolution)
High density with no gap between the dots
↓
Suitable for High speed mode
8

Mimaki Europe B.V.
Sign Graphics Products
Print Speed, SS21/BS3/BS4, 4C ink set
PVC
Banner
m²/hm²/h
3,7
6,9
9,0
13,4
17,6
21,4
28,4
4,3
7,9
10,4
15,4
20,2
24,6
32,7
020 40 60 80
Super Smooth
1440x1440,16P,Bi
High Quality②
720x1440,16P,Bi
High Quality①
720x1440,12P,Bi
Standard②
720x1080,8P,Bi
Standard①
720x1080,6P,Bi
High Speed
540x720,6P,Bi
Draft
540x720,4P,Bi
CJV300-160
CJV300-130 10,9
13,4
17,6
25,7
28,4
39,2
60,2
92,1
12,5
15,4
20,2
29,5
32,7
45
69,2
105,9
050 100 150
Super Smooth
720x1440,10P,Bi
High Quality②
720x1080,8P,Bi
High Quality①
720x1080,6P,Bi
Standard②
720x720,4P,Bi
Standard①
540x720,4P,Bi
High Speed
540x360,3P,Bi
Draft
540x360,2P,Bi
Super Draft
360x360,1P,Bi
CJV300-160
CJV300-130
*
**
**
9
•Ink set: 4C (CMYK)
*
**
*
*
The print modes shown in this document are the performance of the printer itself. The profiles are created selectively depending on the media type. When the
profile is not available, use MPM-3 to create the profile for the media.
* MAPS works with “Quality priority” setting in RasterLink6
** MAPS does not work

Mimaki Europe B.V.
Sign Graphics Products
Print Speed, SS21, 8C/6C ink set
PVC
Banner
m²/hm²/h
1,7
4,6
6,9
9,1
15,1
19,7
1,9
5,3
7,9
10,5
17,4
22,7
0 5 10 15 20 25 30 35 40
Super Smooth
1440x1440,32P,Bi
High Quality
720x1440,24P,Bi
Standard②
720x1080,16P,Bi
Standard①
720x1080,12P,Bi
High Speed
540x720,8P,Bi
Draft
540x360,6P,Bi
CJV300-160
CJV300-130 4,6
6,9
9,1
15,1
19,7
29,5
43,9
5,3
7,9
10,5
17,4
22,7
33,9
50,5
020 40 60
Super Smooth
720x1440,24P,Bi
High Quality
720x1080,16P,Bi
Standard②
720x1080,12P,Bi
Standard①
540x720,8P,Bi
High Speed
540x360,6P,Bi
Draft
540x360,4P,Bi
Super Draft
360x360,2P,Bi
CJV300-160
CJV300-130
**
*
10
•Ink set: -6C(CMYKLcLm+WW/WSi) or (CMYKOrLk+WW/WSi)
-8C(CMYKLcLmLkOr)
* MAPS works with “Quality priority” setting in RasterLink6
** MAPS does not work
**
*
*
*

Mimaki Europe B.V.
Sign Graphics Products
Print Speed, SS21, silver ink set
•Ink set: 6C (CMYKLcLm+WSi) / (CMYKLcLm+WSi)
1-layer printing
(Silver only)
Metallic color printing
(Silver→Color)
m²/h
m²/h
1,7
3,4
5,5
6,9
1,9
3,9
6,3
7,9
0 5 10 15
Super Smooth
1440x1440,32P,Bi
High Qulaity
720x1440,32P,Bi
Standard
720x1440,20P,Bi
High Speed
720x1080,16P,Bi
CJV300-160
CJV300-130
0,3
0,7
1,4
3,0
0,38
0,78
1,58
3,5
012345
Super Smooth
1440x1440,32P,Bi
High Qulaity
720x1440,32P,Bi
Standard
720x1080,16P,Bi
High Speed
720x1080,12P,Bi
CJV300-160
CJV300-130
11
* MAPS does not work
*

Mimaki Europe B.V.
Sign Graphics Products
Print Speed, SS21, White ink set
㎡/h
1,3
3,4
6,2
9,1
1,5
3,9
7,1
10,5
0 5 10 15
Super Smooth
1440x1440,32P,Uni
High Quality
720x1440,32P,Bi
Standard
720x1080,18P,Bi
High Speed
720x1080,12P,Bi
CJV300-160
CJV300-130 0,4
1,1
2,0
2,7
0,5
1,3
2,3
3,1
0 5 10 15
Super Smooth
1440x1440,32P,Uni
High Quality
720x1440,32P,Bi
Standard
720x1080,18P,Bi
High Speed
720x1080,14P,Bi
CJV300-160
CJV300-130
0,3
0,7
1,1
2,0
0,3
0,8
1,3
2,3
0 5 10 15
Super Smooth
1440x1440,32P,Uni
High Quality
720x1440,32P,Bi
Standard
720x1080,24P,Bi
High Speed
720x1080,18P,Bi
CJV300-160
CJV300-130
1-layer printing
(White only)
2-layer printing
(Color →White / White →Color)
3-layer printing
(Color → White → Color)
m²/h
m²/h
m²/h
12
•Ink set: 6C+WW/WSi (CMYKLcLm/CMYKOrLk+WW/Wsi)
*
* MAPS does not work

Mimaki Europe B.V.
Sign Graphics Products
1,7
3,5
6,0
7,7
10,4
15,5
21.4
1.9
4.0
6,9
8,8
12
17,8
24.6
030 60 90 120
Super Smooth
1440x1440,32P,Bi
High Quality②
720x1440,32P,Bi
High Quality①
720x1440,18P,Bi
Standard②
720x1080,14P,Bi
Standard①
720x1080,10P,Bi
High Speed②
540x720,8P,Bi
High Speed①
540x720,6P,Bi
CJV300-160
CJV300-130
6,7
9,0
10.9
17,6
19,7
29,5
60,2
92,1
7,7
10,4
12.5
20,2
22,7
33,9
69,2
105,9
030 60 90 120
Super Smooth
720x1440,16P,Bi
High Quality
720x1440,12P,Bi
Standard②
720x1080,10P,Bi
Standard①
720x720,6P,Bi
High Speed②
540x720,6P,Bi
High Speed①
540x360,4P,Bi
Billboard
540x360,2P,Bi
Draft
360x360,1P,Bi
CJV300-160
CJV300-130
PVC Banner
Print Speed, ES3: 4C ink set
m²/h m²/h
13
The print modes shown in this document are the performance of the printer itself. The profiles are created selectively depending on the media type. When the
profile is not available, use MPM-3 to create the profile for the media.
* MAPS works with “Quality priority” setting in RasterLink6
*
*

Mimaki Europe B.V.
Sign Graphics Products
1,7
3,5
4,6
6,9
7,7
10,9
15.1
1.9
4
5,3
7,9
8,8
12,5
17.4
020 40 60
Super Smooth
1440x1440,32P,Bi
High Quality②
720x1440,32P,Bi
High Quality①
720x1440,24P,Bi
Standard②
720x1080,16P,Bi
Standard①
720x1080,14P,Bi
High Speed②
540x720,12P,Bi
High Speed①
540x720,8P,Bi
CJV300-160
CJV300-130
1,7
5,8
7,7
12,7
15,1
19,7
43,9
1,9
6,7
8,8
14,6
17,4
22,7
50,5
020 40 60
Super Smooth
1440x1440,32P,Bi
High Quality
720x1440,18P,Bi
Standard②
720x1080,14P,Bi
Standard①
540x720,10P,Bi
High Speed②
540x720,8P,Bi
High Speed①
540x360,6P,Bi
Draft
360x360,2P,Bi
CJV300-160
CJV300-130
PVC Banner
Print Speed, ES3: 6C ink set
m²/h m²/h
14
* MAPS works with “Quality priority” setting in RasterLink6
*
*
*

Mimaki Europe B.V.
Sign Graphics Products
Outstanding Speed, Sb53 inks
BMYDk(K) BMYDk(K)LbLm
m²/h m²/h
10,9
13,4
17,6
25,7
28,4
42,3
62,6
97,9
12,5
15,4
20,2
29,5
32,7
48,6
72
112,5
050 100 150
Super Smooth
720x1440,10P,Bi
High Qulaity
720x1080,8P,Bi
Standard②
720x1080,6P,Bi
Standard①
720x720,4P,Bi
High Speed②
540x720,4P,Bi
High Speed①
540x360,3P,Bi
Draft
540x360,2P,Bi
Super Draft
360x360,1P,Bi
JV300-160
JV300-130
**
4,6
6,9
9,1
15,1
21,1
31,9
50,5
5,3
7,9
10,5
17,4
24,3
36,7
58
020 40 60 80
Super Smooth
720x1440,24P,Bi
High Quality
720x1080,16P,Bi
Standard②
720x1080,12P,Bi
Standard①
540x720,8P,Bi
High Speed②
540x360,6P,Bi
High Speed①
540x360,4P,Bi
Draft
360x360,2P,Bi
JV300-160
JV300-130
*
15
•Sb53 4C and 6C printing speeds
The print modes shown in this document are the performance of the printer itself. The profiles are created selectively depending on the media type.
When the profile is not available, use MPM-3 to create the profile for the media.
* MAPS works with “Quality priority” setting in RasterLink6
** MAPS does not work
*
*
*
*
*
**

Mimaki Europe B.V.
Sign Graphics Products
Sb53 inks
Type Advantage Disadvantage
Sb53-K
•Less smoke generation during heat
transfer
•Less grainy results can be seen at
the low gradation areas
•When printing with 100%, the density is
the same as Dk ink, but the density is
lower in the areas with low gradations
Sb53-DK •Reflection density is higher at the
low gradation part
•Grainy results can be seen at the low
gradation areas
•More smoke generation during heat
transfer, compared to the K ink
16
•2 different types of black ink
•2 types of black ink are offered to meet customer's demand

Mimaki Europe B.V.
Sign Graphics Products
Outstanding Speed with Sb54 inks
KT,BLT,MT,YT
m²/h
10,9
13,4
17,6
25,7
28,4
42,3
62,6
97,9
12,5
15,4
20,2
29,5
32,7
48,6
72
112,5
050 100 150
Super Smooth
720x1440,10P,Bi
High Qulaity
720x1080,8P,Bi
Standard②
720x1080,6P,Bi
Standard①
720x720,4P,Bi
High Speed②
540x720,4P,Bi
High Speed①
540x360,3P,Bi
Draft
540x360,2P,Bi
Super Draft
360x360,1P,Bi
JV300-160
JV300-130
17
•Sb54 4C printing speeds

Mimaki Europe B.V.
Sign Graphics Products
High-intensity silver ink (SS21)
•The SS21 silver ink expresses shiny finish
•Brightness does not become lower even after laminate film is applied*
•Brightness even after 3-year acceleration test is better than ES3
①ES3: Metallic gloss level gets lower when laminated
②SS21: Gloss level is maintained even with laminate
Media: Avery MPI 2000
Laminate Film Avery DOL2060 •Initial brightness of SS21 is 67% higher than ES3
•Brightness of SS21 after 3-year acceleration test is still 5%
higher than ES3’s initial value
Outdoor resistance comparisonBrightness comparison
①Laminated
②Initial brightness of ES3 is set as 100%.
167%
137%
123%
105%
100%
65%
50%
39%
0%
50%
100%
150%
200%
初期 1年相当 2年相当 3年相当
SS21
ES3
*1The scratch resistance of SS21 silver ink is poor, laminate is advised
Initial 1-year 2-year 3-year
ES3 w/laminate SS21w/laminate SS21w/o laminate
18

Mimaki Europe B.V.
Sign Graphics Products
3-type metallic color collection
•Metallic color is expressed by printing color on silver
•648 metallic colors designed for easy color matching
•Target metallic color can be selected from swatch library
•3-type metallic color collection
Type A: Chart
Type B: Booklet
Type C: Patch
*Each type of metallic color collection has the same colors.
3-type metallic color collections are available in RL6
19

Mimaki Europe B.V.
Sign Graphics Products
Metallic color collection: Orange edition (SS21)
•Orange ink edition is added to SS21 metallic color
collection’s ink set CMYKOrLk+Wsi,
•For printing brighter metallic colors
Metallic Color Collection incl. Or ink edition
•SS21 C,M,Y,K,Or,Lk+W,Si Ink set
•108 colors added!
Red/Orange colors are added
•There are total 756 colors including the regular metallic colors
Type B and C
20
