MINIMOTO ATV User manual

Important: You must
charge your MINIMOTO™
ATV a minimum
of 12 hou rs before you
can use it.
RECHARGE t he batt ery
EACH TIME you use it.
TO PROTECT THE LIFE
OF THE BATTERY,
rech arge the batt er y
at least on ce a month.
FOLLOW ALL SAFETY
RULES AND SET UP
INSTRUCT IONS IN THIS
MANUAL THOROUGHLY.
FAILURE TO DO SO
MAY VO ID YOUR
WARRANT Y.
DO NOT RETURN THE
MINIMOTO™ ATV
TO THE STORE!
IF YOU NEED REPAIR
PARTS GO TO:
www.ElectricScooterParts.com
OR CALL:
1-800-908-8082
8 AM TO 5 PM PST,
Monday through Friday,
(excluding holidays)
OR contact us by
email at:
[email protected]
23293 1.0(01/07)
23293 1.1(03/02)
23293 1.2(03/11)
23293 1.3(04/01)
23293 1.4(04/09)
23293 1.5(04/29
ATV
ELECTRIC POWERED

Please read this manual and save it with your original sales receipt.
Tools needed for assembly (included): Three Allen Keys, One Wrenches, and one Detachable Screwdriver.
Use only with included: One 36 Volt Lead-Acid Rechargeable Battery,
three Ignition Keys and one Battery Charger.
(Protective equipment not included)
INSTRUCTION
MANUAL
IMPORTAN T!
Read completely before
attempting to ride
ATV
14
5
ELECTRIC POWERED
Owners Manual Courtesy of ElectricScooterParts.com

MINIMOTO
™
ATV
1
Conte nts Page
MINIMINIMOTO™ ATV
Owner’s manual and safety instructions
2
Warnings
3 - 4
Electrical hazard
5
Vehicle set up and a ssembly
6
Battery charging information
7
Steps to charge battery
8
Battery care
9
Riding rules
10
Abuse detection warning buzzer, circuit breaker, and power shut down prote ction
14
How to ride your MINIMOTO™ ATV
12 - 13
Pre-ride checklist / MINIMOTO™ ATV controls and switches
11
Low power LED Indicator / If you lose the key
15
Tire inflation procedure / Tire repair
16
Tire rotation
17
Replacing the battery
18 - 19
Battery disposal
19
Replacing the chain
20
Brake Adjustment
21
Rear disc brake ad justment
21 - 22
Limited warranty and registration policy
25
Trouble shooting
23 - 24
Registration card / V IN location
26
Appendix — spare part list
27 - 28

MINIMOTO
™
ATV
MINIMOTO
™
ATV
MINIMOTO™ ATV
Owner’s manual and safety instructions
Read this manual completely and carefully
before operating your electric MINIMOTO™
ATV. Keep this manual in a safe place for
future reference. Be sure you thoroughly
understand how to operate the compo-
nents of your MINIMOTO™ ATV.
NOTE: Throughout this manual there
are many “WARNINGS”. Be sure to
read and understand all of these “WARN-
INGS”. Please pa y extremely close atten-
tion to these areas as serious injury or
even death may result in failing to do so.
WARNING: This vehicle is a seri-
ous machine and should be treat-
ed with respect when riding it,
working on it, or simply being
near it.
This vehicle can obtain speeds that only
qualified riders of the proper age, size,
and maturity should attempt. That deci-
sion rests entirely on the observation and
discretion of the direct supervising adult.
IMPORTANT!!! Before we begin:
Like any wheeled vehicle, riding the MINI-
MOTO™ ATV can be extremely hazardous.
It is your responsibility to follow this manu-
al for the proper set up, inspection, riding
procedure, protective gear required, and
rules of the road to reduce the risk of seri-
ous injury.
The age recommendation is only an esti-
mate. If the rider is too small, too large,
or too old to comfor tably fit on the MINI -
MOTO™ ATV, he/she should not attempt to
ride it. The minimoto™ ATV is not
designed for or intended to be used b y of
anyone under the age of 10.
Keep away from small children.
2
FOR WEBSITE INFORMATION
www.teamminimoto.com
For Repair Parts and Accessories
Go To
www.ElectricScooterParts.com

MINIMOTO
™
ATV
WARNINGS:
This product is meant for outdoor use only
and only on private property. Never ride
your MINIMOTO™ ATV on public streets,
alleys, or other public roads or through-
fares. It must never be ridden in any area
that could potentially do harm to humans,
animals, or property damage.
Never ride around the vicinity of small chil-
dren who may enter your path.
Special notes for supervising adults of
the rider:
1) The decision to allow a rider to ride the
MINIMOTO™ A TV must be done with the
permission of a directly super vising adult.
The directly supervising adult must read
and follow all of the contents of the owners
manual before making this decision.
2) The rider must ha ve previous experience
in riding electric powered vehicles before
attempting to ride the MINIMOTO™ ATV. It
is the responsibility of the supervising adult
to ensure the rider has the specific talent,
physical ability, and training before allowing
them to attempt to ride the ATV.
3) The MINIMOTO™ ATV is never to be rid-
den indoors. Indoor flooring and carpets
can be damaged from abrasive contact with
the tires. The manufacturer will not be
responsible for an y indoor damage if the
MINIMOTO™ ATV is used in this manner.
4) The MINIMOTO™ ATV is designed to run
on off-road surfaces. Grass, packed dirt,
and moderate off-road ter rain are ideal rid-
ing surfaces by persons over the age of 10.
5) The rider of a MINIMOTO™ A TV should
always wear appropriate footwear. Open-
toed shoes should ne ver be allowed. K eep
shoe laces and pant legs away and clear of
the wheels.
6) The rider must wear a safety helmet,
elbow and kneepads to avoid injury if
falling. Failure to wear a standard
approved helmet may result in serious per-
sonal injury or death.
7) The MINIMOTO™ ATV is never to be rid-
den by more than one person at a time. In
addition, it is not designed to pull or tow
anything behind it as it may result in serious
damage to the motor or internal parts. Do
not exceed the maximum capacity of 200
lbs (90 kg).
8) The MINIMOTO™ ATV cannot be used on
wet surfaces or in wet weather. Never
immerse any part of the MINIMOTO™ A TV in
water. Moisture can damage the motor,
switches, and drive components.
9) The MINIMOTO™ A TV should ne ver be
ridden in mud, water, ice, snow or sand. It is
not designed to be ridden in streets or on
paved surfaces either. Avoid riding on
extreme incline, declines, rocky surfaces,
curbs or jumps.
10) The electric motor can become hot
when in use. Do not touch it at an ytime and
handle it carefully.
11) Never use your MINIMOTO™ ATV while
using personal radios or headphones.
12) Do not use your MINIMOTO™ A TV for
stunt riding , ramp jumping, acrobatics or
similar activities.
3

MINIMOTO
™
ATV
MINIMOTO
™
ATV
13) Never inflate the tires beyond 30 psi.
Inflation of the tires should be performed by
adults only. Serious injury or death may
result in over inflation of the tires. Avoid fill-
ing the tires at a gas station. The greater
pressure of a gas station air pump makes a
blowout of the tire possible. This may
result in serious injury or death. Never use
non-MINIMOTO™ replacement parts.
14) If you need repair parts or accessories
the MINIMOTO ATV please contact
ElectricScooterParts.com toll-free at:
1-800-908-8082
Between the hours of 8 to 5 PST, Monday
through Friday (excluding holidays)
or by email:
[email protected]
Do not return the product to the
store! Contact the Minimoto
Service Center. Authorized serv-
ice is only available through the
official Minimoto Service Center.
Spare tires, inner tubes, batter-
ies, and replacement parts can
be obtained through the
Minimoto Service Center.
15) SB 1918 (CALIFORNIA) DECLARATION:
YOUR INSURANCE POLICIES MAY NOT
PROVIDE COVERAGE FOR ACCIDENTS
INVOLVING THE USE OF THIS PRODUCT.
TO DETERMINE IF COVERAGE IS PROVID-
ED, CONTACT YOUR INSURANCE COMPANY
OR AGENT.
4
TTooyyQQuueesstt
cc//ooMMiinniimmoottooSSeerrvviicceeCCeenntteerr
11880000NN..99tthhSSttrreeeett
IInnddiiaannoollaa,,IIoowwaa5500112255
For Repair Parts and Accessories
Go To
www.ElectricScooterParts.com

MINIMOTO
™
ATV MINIMOTO
™
ATV
ELECTRICAL HAZARD:
WARNING
CAUTION!
THIS IS AN ELECTRICALLY OPERATED
PRODUCT AND SHOULD BE OPERATED
WITH CARE. KEEP AWAY FROM SMALL
CHILDREN.
BEFORE RIDING, ALWAYS MAKE SURE
THAT THE BATTERY RETAINER IS FIRMLY IN
PLACE AND HOLDING THE BATTERY
SECURELY.
PREVENTING A FIRE:
a) Never modify the electrical system or
battery charger. Modifications of these
systems can result in fire, serious injury
and damage to the electrical components.
b) To avoid damaging the batteries, do not
use the charger if it has been str uck,
dropped or damaged in any way.
c) Do not expose the batteries to high
temperatures as this may cause the
battery to explode.
d) Never allow the batter y charger to
become wet or placed in w ater.
e) Use of the wrong type of batteries or
charger could cause a fire or explosion
resulting in serious injur y.
f) Never use Minimoto™ parts, batteries,
or components in any other products or
vehicles other than those of Minimoto™.
Replacing or substituting parts with other
vehicles can result in overheating, fire, or
explosion.
g) The battery is to be handled by ADULTS
ONLY. The battery is heavy and contains a
lead-acid electrolyte. Dropping the battery
can result in serious injury.
h) Never allow children to recharge the
battery. Charging the battery must be
done by ADULTS ONLY. A child could be
injured when involved in the operations of
battery charging or use of electrical
devices.
i) Make sure that all battery contacts or
connectors are clean and free of excessive
wear or damage whenever the battery is
charged. If ANY damage is detected, DO
NOT USE the charger or batteries until you
have replaced the worn or damaged part.
j) Always remove the Key when not in use
to ensure the power is off and prevent any
unauthorized riders from attempting to ride
the ATV.
5

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
VEHICLE SET UP AND
ASSEMBLY:
CAUTION: The included tools to set up
and charge the Minimoto™ ATV should be
used by an ADULT ONLY. The package con-
tains some small parts. Keep away from
small children.
1) Completely remove the Minimoto™ ATV
and all
contents
from the
package.
(Fig 1)
Remove
and dis-
card the
protective
cardboard covering from the handlebars.
2) Find and identify
the following tools
and hardware (Fig 2)
3) Take the steering arm and place it in the
clamp (Fig 3)
4) Tighten the steering arm using the
Allen key in the tool kit (Fig 4).
5) Under the seat, remove the rubber band
that holds
the connec-
tors and
snap togeth-
er the two
connectors
(Fig 5).
6) From the left side of the vehicle, locate
the two screws holding the Battery box
together (Fig 6). Using a phillips head
screwdriver, unscrew these screws and
remove the left half of the battery box off
the vehicle (F ig 7).
7) Place the connector assembly inside
the battery
box with only a
wire protruding
from the top
(Fig 9).
8) Place the left half of the battery box
back on the vehicle and retighten the
screws (Fig 10).
6
Fig 1
Fig 2
Fig 3
Fig 4
Fig 6 Fig 7
Fig 9
Fig 5
Fig 10

MINIMOTO
™
ATV MINIMOTO
™
ATV
7
BATTERY CHARGING
INFORMATION:
IMPORTANT! The new battery provided
in the Minimoto™ ATV MUST BE charged
for at least 12 hours before using for the
first time.
The charger MUST be used only in a clean,
dry area. In addition:
--Battery charging must be done by ADULTS
only.
--The battery must be upright when charging.
--The charger is not a to y.
--Do not shor t-circuit the battery.
--Do not charge the battery on any delicate
surfaces (such as a counter top).
--Only use the provided charger to charge the
battery.
--Only use a Minimoto™ ATV battery or bat-
teries when operating.
--Remove old or dead battery from the
Minimoto™ ATV if they do not accept a
charge.
--Never use the charger in an enclosed
space. Alw ays ensure adequate ventilation.
--Never cover the Minimoto™ ATV or the
charger during charging.
--Should anything abnormal happen to the
Minimoto™ ATV or charger, switch off the
mains supply immediately and contact
Minimoto™ Ser vice Center.
IMPORTANT!
Under normal conditions, the battery will
reach full charge in 8 to 12 hours of charg-
ing time. The difference in time depends
on the local power output in your area, the
type of outlet you use, and the condition of
the battery.
NOTE: Do not connect the charger to a
surge protector. You should only plug the
charger directly into a standard electric
wall outlet. Surge protectors can slow
down the charging process.

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
STEPS TO CHARGE BATTERY:
1) IMPORTANT: BEFORE YOU ATTEMPT
TO CHARGE THE MINIMOTO™ ATV,
REMOVE THE KEY FROM THE LOCK.
2) Lift up the rubber protective cover of
the charger receptacle (Fig 11)
3) Note that the charging port has a
“groove” inside (Fig 12). This allows the
plug to be inser ted in the proper orienta-
tion to the port. Plug the charger into the
port.
4) Plug in the charger into an electrical
outlet.
5) Inspect that the RED or GREEN LED is
On. If the RED LED is ON, the battery is
charging. When properly charging the LED
on the charger will change to red. After
the battery is fully charged the LED will
return to GREEN. If there is no GREEN or
RED LED on at all, check that the power is
on from the outlet and that the charger is
properly plugged into the charging port.
NOTE: When properly charging, the RED
indicator light on the charger will be ON.
You may hear a clicking sound. This is
normal. MAKE SURE ANY SWITCHES
CONNECTING THE ELECTRICAL OUTLET
ARE SET TO THE ON POSITION.
When the battery is fully charged, a
Green light will be indicated on the
charger.
6) Before using the Minimoto™ ATV for the
first time, charge the battery for at least
12 hours. Never charge the battery for
more than 30 hours.
7) It is recommended that you alw ays
recharge the battery for a period of 8
hours. However, 80% of the power will be
charged into the batter y in 4 hour s. It is
possible to use the Minimoto™ ATV after
this period but the total running time will
be reduced.
8) Remove the charger plug from the
charging port. Replace the r ubber protec-
tive cover over the charging port.
8
Fig 11
Fig 12

MINIMOTO
™
ATV MINIMOTO
™
ATV
9
BATTERY CARE:
If a battery appears to be leaking, avoid
contact with the leaking materials. Place
the battery in a plastic bag.
WARNING: This liquid and contents of the
battery are highly acidic. Wash your hands
immediately and thoroughly for a minimum
of 15 minutes. Call a ph ysician. Do not
touch your face or e yes. If acid is inter-
nally ingested, IMMEDIATELY give water,
milk, egg whites, or milk of magnesia.
Never give emetics or induce vomiting.
CALL A PHYSICIAN IMMEDIATELY.
.Use ONLY a Minimoto™ 36 volt
replacement battery.
.Never charge the battery for more than
30 hours.
.Charge the battery after each use.
.Avoid running the battery completely
as this will greatly shorten their use-
able life.
.Never leave the batter y in an
uncharged condition. This will per ma-
nently damage it and prevent it from
being able to hold any charge.
.Disconnect the battery from the wiring
if the Minimoto™ ATV is to be stored
for more than 2 months.
.Do not store the batteries in tempera-
tures above 122 degrees F or lower
than 32 degrees F.
.Check to make sure the battery are
securing in place before riding the ATV.
Tighten the battery retainer if neces-
sary.
Country Input Output P olarity Shape
A.C. 100-120V
60Hz
d.c. 36V 2000mA
U.S./Canada
Taiwan/Japan
A.C. 220-240V
50Hz
d.c. 36V 2000mA
U.K./Hong Kong/
Singapore/Malaysia/
Africa
A.C. 220-230V
50Hz
d.c. 36V 2000mA
Europe/Germany/
Israel
A.C. 240V 50Hz d.c. 36V 2000mA
Australia/
New Zealand/China
Bare
Bare
Bare
Bare
Battery Charger specifications for world-wide standard:

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
RIDING RULES:
STRONGLY RECOMMEND RIDERS NOT TO
RIDE THE MINIMOTO™ ATV UNDER 32
DEGREES F TO PREVENT COLD TEPERA-
TURE DAMAGING THE ATV.
DIRECT ADULT SUPERVISION IS REQUIRED
WHEN RIDING.
Adults should teach the appropriate safety
rules and methods before allowing anyone
to ride the Minimoto™ ATV. The rules
should be reviewed with any children in the
vicinity that may want to ride the ATV.
1) The following areas are to be avoided
when riding the Minimoto™ ATV :
a. Cars or traffic
b. Streets or alle ys
c. Steps, curbs or steep inclines
d. Swimming pools, puddles, ice, or
bodies of w ater
e. Any area that could potentially
cause har m to humans, animals, or
property. Ride only in areas where
permission has been granted.
2) Do not use on roads or public streets,
as this is illegal and dangerous.
3) Never ride the Minimoto™ A TV at night.
4) Never ride with more than one rider .
Maximum allowable weight of the rider
should not exceed 200 lbs (90kg).
5) Always wear appropriate shoes, cloth-
ing, and protective gear. Protective gear
includes the use of a helmet, knee pads,
and elbow pads (not included).
6) Do not use the Minimoto™ ATV for
jumping, stunts or tricks. This product has
not been designed for such use
7) Do not touch the motor or wheels while
they are rotating.
8) Keep hands, face, feet, and hair away
from all moving parts.
9) Do not ride down or across steep
inclines. The Minimoto™ ATV just like a
professional ATV can reach unsafe
speeds, lose traction, or slide or collide
with other objects. Ride only on level
ground
10) Never ride near flammable liquids or
vapors such as gasoline acetone or paint
thinner. Keep all flammable materials away
from the Minimoto™ ATV.
11) Never wear headphones or use a cell
phone when operating.
12) Ride defensively. Remember that oth-
ers around you may not see you or may be
to involved in their own actions
13) Learn about and observe your local
laws regarding use.
14) Riders must be over the age of 10
yrs. Keep away from small children.
10

MINIMOTO
™
ATV MINIMOTO
™
ATV
11
PRE-RIDE CHECKLIST
YOUR MINIMOTO™ ATV IS JUST LIKE ANY
VEHICLE. IT REQUIRES ROUTINE MAINTE-
NANCE, SERVICE, AND INSPECTION TO
OPERATE RELIABLY AND SAFELY.
.LOOK OVER THE ENTIRE VEHICLE TO
ENSURE THAT THERE ARE NO VISIBLE
PROBLEMS WITH THE MINIMOTO™
ATV.
.CHECK THAT THE HANDLEBAR CLAMP
IS TIGHT AND PROPERLY ALIGNED.
.CHECK THE TIRES, ENSURING THERE
ARE NO CUTS OR EXPOSED CORDS
OR THE TIRES ARE DEFLATED.
.CHECK THAT THE TIRE WHEEL NUTS
ARE TIGHT AND THE WHEELS TURN
PROPERLY.
.CHECK THAT ALL CABLES AND WIRES
ARE NOT FRAYED, CUT OR BR OKEN.
- CHECK ALL STEERING LINKAGES,
RETAINER NUTS, AND ROD ENDS ARE
NOT LOOSE AND ARE IN GOOD WORK-
ING ORDER.
.PRESS THE BRAKE LEVER TO MAKE
SURE THAT:
1. THE BRAKE RELEASES AUTOMATI
CALLY.
2. THE BRAKE HOLDS THE ELECTRIC
ATV FROM BEING PUSHED FORWARD
AND BACKWARD.
. CHECK THAT THE THROTTLE IS TIGHT
ON THE HANDLE BAR.
MINIMOTO™ ATV CONTROLS
AND SWITCHES:
The switches and controls (Fig 13):
Fig 13

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
12
HOW TO RIDE YOUR
MINIMOTO TM ATV:
NOTE: It will take a little practice to get
used to driving. Take it slowly and start in
a location that is very open and away from
obstacles or obstructions. Take steps to
learn the proper way to use your left hand
for braking purposes.
WE HIGHLY RECOMMEND THAT YOU START
IN “TRAINING MODE” BEFORE USING
“NORMAL MODE”. THIS WILL GIVE THE
RIDER A CHANCE TO BECOME COMFORT-
ABLE WITH THE VEHICLE’S CONTROLS
BEFORE PROCEEDING TO THE TOP SPEED.
WARNING: BEFORE DOING ANYTHING,
REMOVE THE KEY FROM THE VEHICLE
BEFORE ATTEMPTING ENTRY ONTO THE
VEHICLE (Fig 14). THIS WILL PREVENT
ACCIDENTAL ACCELERATION WHEN LOAD-
ING.
1) Check the “FWD/REV” switch is in the
“FWD” (forward) position (Fig 15).
2) Step in the vehicle and carefully sit on
the seat (Fig 16).
3) Place your feet on the foot pads on
either side of the vehicle (Fig 17).
4) Move the Control switch to either
Training Mode or Normal (Full Power) Mode
(Fig 18).
5) Insert the Key
and switch it to
the ON position
(Fig 19).
Fig 14
Fig 15
Fig 16
Fig 17
Fig 18
Fig 19

MINIMOTO
™
ATV MINIMOTO
™
ATV
13
6) Put both hands on the handlebars with-
out pressing the brake lever, SLOWLY
rotate the accelerator handle on the
driver’s right side (Fig 20). The ATV should
move forward. The more you rotate the
handle, the faster the ATV will go.
7) To stop, pull the brake lever on the
handle to the driver’s left side (Fig 21).
Reversing the vehicle
If you need to re verse the vehicle for an y
reason, go to a COMPLETE STOP first.
Next, move the FWD/REV switch to the
“REV” position. Rotate the accelerator
slowly and the vehicle will begin to move
backward. [NOTE: Reverse speed is limit-
ed to a fe w miles per hour. You cannot
run at top speed in reverse.] When fin-
ished reversing, go to another COMPLETE
STOP and move the switch to the FWD
position for forward motion.
TIP: You do not need to let off of the
accelerator when you press on the brake.
The power to the motor is automatically
cut off when the brake pedal is pressed.
This will help you conserve power and
speed when driving.
BE CAREFUL: The Minimoto ATV™ can
reach speeds up to 14 MPH on a level sur-
face (depending on the surface terrain and
the weight of the rider).
SPECIAL SAFETY WARNINGS
1) When accelerating please ensure that
you start slowly & precisely.
2) The brake is designed to control speed
as well as stop the vehicle. Practice brak-
ing for slow-down and smooth stopping .
3) Never operate the accelerator handle
when the rear wheels are off the ground or
the ATV in an upside down position.
4) Do not attempt to make shar p turns.
The Minimoto™ ATV is not designed to do
high speed cornerings. Attempting to do
so may result in serious injur y.
Fig 20
Fig 21

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
14
Abuse Detection Warning
buzzer, Circuit breaker and
Power shut down protection
Your Minimoto™ ATV has automatic protec-
tion systems built into it to prevent perma-
nent damage to the electronic circuits.
Abuse Detection Warning Buzzer: Your
ATV is equipped with a temperature and
overloading current sensor to detect possi-
ble overheating and overloading of the
electronic control box. Overheating or
Overloading may occur if you run your ATV
with too heavy a load, in too rough a ter-
rain, or up too steep an incline.
1) If the temperature in the electronics is
too high, the sensor will shut the vehicle
down and a warning buzzer with a high
pitch noise will last for 10 seconds.
If this happens, you must wait for the sen-
sor to detect a lower temperature. This
may take at least 5 to 10 minutes,
depending on the outside air temperature
during the ride. The ATV should work as
normal again, after the reset.
2) If a overloading current occurs, the
buzzer will beep for 2-3 seconds and shut
the vehicle down at the same time.
Release the accelerator to reset the ATV.
Rotate the accelerator again to resume rid-
ing.
When a overloading current occurs causing
the vehicle to stop operating and NO
buzzer is heard, refer to Circuit Breaker
Protection and Reset section.
Circuit Breaker Protection and Reset: If
the ATV stops working and you hear NO
BUZZER, check to see if the Circuit
Breaker button has “popped up” (Fig 22).
WAIT ten seconds and press the black but-
ton in the center of the Circuit Breaker
down. If the button stays down, the Circuit
Breaker is reset. If not, wait longer until it
has cooled down enough before pressing
the button.
Fig 22

MINIMOTO
™
ATV MINIMOTO
™
ATV
15
Low Power LED Indicator:
When the battery is low and almost com-
pletely drained of power, the Low Power
LED on the front console (Fig 23) will light
up and the vehicle will start to noticeably
slow down. This will help you conserve
power to get your ATV back to the charging
area as soon as possible.
If you continue to run the ATV too long
without recharging the battery, the ATV will
automatically shut down. You will see that
the RED LED is ‘ON’ but the vehicle will
not move. At this point, YOU MUST
RECHARGE the ATV to get it to run again.
IF YOU LOSE THE KEY:
Spare Keys can be obtained by calling the
Minimoto™ Service Center for a fee. You
can also have your key duplicated at any
key shop or kiosk. It is a good idea to
store the extra keys provided in a safe
place.
Fig 23

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
16
TIRE INFLATION PROCEDURE :
IMPORTANT:
Before inflating any tire, make sure
the KEY is removed from the vehicle.
To inflate a tire, unscrew the protective cap
from the valve stem and attach the bicycle
pump as you would with any bicycle.
WARNING: Tire inflation must be done
ONLY BY AN ADULT ONLY. NEVER inflate
the tires above 30 PSI. Tires should be
inflated with a standard “bicycle” type
pump. Inflation at an Automobile service
station can easily result in over inflation
of the tires. Over inflation of the tires
can result in serious injur y or even death.
Tires MUST be at the proper inflation
in order to achieve good handling
characteristics and control. Over
inflation will make the tires “bulge”
outward. This will cause premature
wear of the tire. Under inflation will
cause the tire to look flat on the
ground. This will result in poor run-
ning speeds and handling. Make
sure that your tires are properly
inflated to get the most out of your
vehicle.
TIRE REPAIR:
In the event that a tire should consistently
loose air pressure, the tires can be
repaired at a local bicycle repair shop.
The tires have an inner tube construction.
WARNING: Inspect tires regularly.
1) If the tire tread is worn to the point
where the grooves are difficult to see,
replace the tire(s) immediately.
2) If the tire tread shows uneven wear,
check the axle to make sure the wheel is
loaded evenly and correctly. Uneven wear
may be a sign of uneven loading.
3) If the rims (wheels) are bent or cracked,
they must be replaced.

MINIMOTO
™
ATV MINIMOTO
™
ATV
17
TIRE ROTATION:
The rear tires will wear unevenly as the
forces placed on them are different. The
Right Rear tire does all the braking and
delivers all the power to the ground.
Replacement tires can be obtained from
the Minimoto Service Center. Email your
request at
customer ser [email protected]
WARNING: Disconnect the battery before
removing the tires. This will ensure no pos-
sibility of the motor or wheel running acci-
dentally while working in this area. Refer
to page 18 steps 1-3 “Replacing the bat-
tery” in this instruction manual for this
operation.
To ensure that your tires last as long as
possible, it is recommended that you
rotate the tires as the tread patter n wears
down. Most likely, the RIGHT REAR tire will
wear heavier than the left (depending on
your driving habits). When the Right Rear
tire appears to show some wear, rotate the
tires between the left and right. This way
you can stretch the useable life of the
tires out over a longer period of time.
1) Raise the ATV and lay it on its side
(Fig. A) Make sure that the ATV will not
fall to its side and injure anyone. Use a
work bench if possible.
2) Open the valve cap on the valve stem
of the tire.
Deflate the tire
by pushing the
valve pin inside
the valve stem.
(Fig. B)
3) Using the wrench (not provided) and
allen key remove the five bolts and nuts
on the hub of the wheel. (Fig. C)
4) Lift and remove the top hub from the
axle. Remove the tire and place aside.
(Fig. D & Fig. E)
5) Place the ne w tire (or from another
wheel) onto the bottom hub on the axle.
Reconnect the two hubs with the tire in
between and align the scre w holes. Mak e
sure the valve stem is also inser ted to the
hole in the top hub. Tighten the bolt and
nuts in re verse order. (F ig. F & F ig. G)
6) Inflate the tire with a foot pump until
30Psi.
7) Reconnect the battery and ride as nor-
mal.
IMPORT ANT: Make sure the wheel nuts
and bolts are properly tightened before
driving.
Fig A
Fig B
Fig C
Fig D Fig E
Fig F Fig G

MINIMOTO
™
ATV MINIMOTO
™
ATV
MINIMOTO
™
ATV MINIMOTO
™
ATV
18
REPLACING THE BATTERY:
1) Check to make sure the Key is removed
from the vehicle.
2) Using a Phillips screwdriver, to remove
the screws on the Left Side of the battery
box beside the left foot pedal (Fig 24).
3) Remove the battery box from the vehi-
cle and disconnect the battery wire (Fig
25).
4) Use the Allen Key and Wrench at the
same time to remove the bolt (as shown)
and nut (under the battery box) that
secures the Battery Retainer until the
Battery Retainer has some slack. (Fig 26)
.
TIP: You don’t need to remove the bolts
and nuts entirely. You only need enough
space between the Battery Retainer and
the Battery to slide the Battery out. This
will help with reassembly.
6) Carefully lift and slide the battery out
from the opened side of the battery box.
NOTE: THE BATTERY IS VERY HEAVY. USE
CAUTION SO THAT YOU DO NOT STRAIN
YOUR BACK OR MUSCLES.
7) Replace the battery with a new one and
reconnect the plug.
8) Re-tighten the nuts from underneath
the battery box and the battery retainer
using the Allen K ey and wrench in reverse
order.
IMPORT ANT: Make sure the batter y does
not move and the retainer is tightly fas-
tened. If the battery is allowed to move,
damage may occur to the batter y, battery
box, or connectors.
9) Replace the batter y box in re verse
order
10) Charge the ne w battery before
attempting to drive the vehicle again.
(See page.8 for details, steps 1-6)
NOTE:
• Use only ElectricScooterParts.com
replacement batteries.
• Battery is to be inserted with the correct
polarity
• Do not short circuit the battery and con-
nectors.
• Rechargeable battery must be recharged
after every ride and every 30 days when not
in use.
Fig 24
Fig 25
Fig 26
