MinimumRC DH-88 Comet User manual

DH-88 Comet
Assembly Instructions
Important notification
1.The model is supplied with UFO and 502 glue. UFO is for bonding foam parts, and 502 for
bonding wood, carbon fiber and metal parts. 502 glue will cause serious corrosion to foam parts.
2.Please wait for the glue to dry and solidify in each installation step before the next installation.
3.Please avoid using flame to heat the heat shrinkable tube on the model. Electric iron shall be
used for heating.
4.Please use razor blade to remove the parts from the plate. Do not tear the parts by force.

1. Wooden frame components of the fuselage.
2. Assemble the wooden frame of the fuselage.

3. Connect the receiver to the servos, power it on, and bind the receiver with the tansmitter to
ensure that the servo arm returns to its neutral position.
Test the servos to ensure they are functioning correctly and install the servos and servo arms
according to the diagram.
Note: This step is crucial. Please ensure that the servos are powered on, the servo arm is in the
neutral position, and follow the diagram precisely. Once the model is assembled, adjustments
cannot be made.
4. (Bottom view) Install and secure all three servos from underneath the wooden board.

5. Use adhesive Velcro to secure the receiver.
6. Connect the receiver to the servos. Turn on the transmitter and test the correspondence
between the three servos and the channels on the transmitter.
After testing, use adhesive Velcro to secure the receiver and secure the cables with zip ties.
7. Bend the front ends of the two side panels of the fuselage inward as shown in the diagram.

8. Method for bending foam board pieces: Press the part that needs to be bent against the palm
of your hand.
9. Press the part that needs to be bent against the edge of a table, ensuring that the palm is in
close contact with the part, and slide downward.
10. Completed bent parts.

11. Use glue to secure the wooden frame.
12. Press the top and bottom plates of the fuselage and bend them into the corresponding shape
of the fuselage contour.
13. Use glue to secure the rear top plate of the fuselage. Note that the front end of the rear top
plate should align with the cockpit position on the fuselage.

14. Use glue to secure the front top plate of the fuselage.
15. Use glue to secure the bottom plate of the fuselage. Note: Do not apply glue to the indicated
position on the front bottom plate (yellow contour) in the diagram.
16.

17. Close the fuselage.
18. Apply decals to the fuselage.
19. The front bottom plate of the fuselage can be opened forward as a battery compartment
cover. When the cover is closed, it should be secured using the end of the decal.

20. Use a sharp tool (screwdriver) to score through the marked lines on the bottom of the
horizontal stabilizer, allowing the elevator to move freely along the lines on both sides.
21. Use a sharp tool (screwdriver) to score through the marked lines on the bottom of the vertical
stabilizer, allowing the rudder to move freely along the lines on both sides.
22. Install vertical stabilizer reinforcement.

23. Insert the horizontal stabilizer into the pre -cut slot on the fuselage and secure it. Ensure that
the horizontal stabilizer is parallel to the wing spar.
24. Install the vertical stabilizer.
25. The two motor compartments are designed to be mirror symmetrical. Please assemble both
motor compartments simultaneously to avoid confusion.

26. Assembled framework of the two motor compartments. The side with the circular holes should
face the fuselage.
27. Wheel axle sleeves, wheel hubs, and tires.
28. Assemble the wheel axle sleeves and wheel hubs and use glue to secure them.

29. Assemble the wheel hubs and tires and use glue to secure them.
30. Install the wheels on the wire landing gear. Bend the wire at the end upward using needle -
nose pliers to prevent the wheels from coming off.
Alternatively, insert a short piece of heat shrink tubing at the end of the wire, hea t it to shrink,
and use glue for additional fixation to prevent the wheels from coming off.
Secure the wire landing gear to the motor compartment frame using screws.

31. Install the landing gear on both sides in a mirrored symmetrical manner.
32. Differentiate the parts of the motor compartment. The parts with circular holes should face
the fuselage.
33.

34. Pass the motor wires through the circular holes.
35. Press the top and bottom plates of the motor compartment and bend them into the
corresponding shape of the motor compartment contour.
36. Use glue to secure the bottom plate of the motor compartment.

37. Use glue to secure the top plate of the motor compartment.
38. Install the completed motor compartments on both sides in a mirrored symmetrical manner.
39. Install the motor compartments on both sides.

40. Install the tail brace at the tail of the fuselage.
41. Use a sharp tool (screwdriver) to score along the wing's marked line, allowing the wing to fold
downward along the center longitudinal line to form the airfoil.
42. Use a sharp tool (screwdriver) to score along the aileron's marked line, allowing the aileron to
move up and down along the line.

43. Paste carbon fiber rods on the bottom of the wing along the marked line to increase strength.
44. Install the wing.
45. Install the wing root.

46. Apply decals to the motor compartments.
47. Install the elevator control horn.
48. Install the rudder control horn.

49. Cut four pieces of heat shrink tubing, each 5mm in length, for connecting the tail control rods
and steel wire clips.
50. Use heat shrink tubing to connect the control rods to the steel wire clips and secure them with
epoxy adhesive.
51. Install connecting hooks on the tail control horns.

52. Attach the control rod clips onto the servo arms.
53. Trim the carbon fiber rod to an appropriate length. Use heat shrink tubing to connect the
carbon fiber rod to the connecting hook and secure it with epoxy adhesive.
54. Install the aileron control horns on both sides.
