Minix NEO X39 User manual

4K Ultra HD Industrial Android Player
™
English User Guide
NEO X39
www.minix.com.hk

Specifications
Dual Core Cortex A72 + Quad Core Cortex A53 Processor (64-bit)
Mali-T860MP
DC 12V, 3A adapter (included)
or via USB-C input (DC 12V)
4GB LPDDR4
RJ-45 Gigabit Ethernet, Micro SD card reader,
USB 2.0 port x 3, USB 3.0 port x 1, USB-C port x 1,
Kensington Lock ready, IR receiver (remote included)
GPU
Memory
Peripheral Interface
Power
Processor
Internal Storage
Wireless Connectivity
Digital Audio Output
Video Output
Operating System
Analog Audio Output
Audio Input
32GB eMMC 5.1 (MLC)
802.11ac 2 x 2 MIMO Dual-Band Wi-Fi, Bluetooth 4.1
Android™ 7.1.2 Nougat
HDMI™ 2.0 (4K @ 60Hz), USB-C (Full 1080p HD)
HDMI™ 2.0, Optical S/PDIF
3.5mm audio jack
3.5mm audio jack

Contents
MINIX NEO X39 MINIX
IR-Remote
12V (3A)
Power Adapter
HDMI Cable
Dual-Band
Antenna
USB-C to USB-A
Cable

Overview
Thank you for supporting MINIX,
we hope you enjoy your NEO X39.
MINIX NEO X39 is a 4K Ultra HD Industrial Android Player,
designed exclusively for digital signage and
commercial usage.
MINIX NEO X39 supports the vast majority of video and
audio formats, pioneering the latest technologies to
achieve enhanced picture quality.
For more information visit: www.minix.com.hk
Join the MINIX Forum at: www.theminixforum.com
™

Overview
IR Receiver - Compatible with Logitech Harmony.
Power LED - The LED glows blue when NEO X39 is on, green when
suspended.
Power Button - To power on the NEO X39, press and hold the power
button for 2-3 seconds until the power LED glows. To power off the
NEO X39, press and hold the power button until the display shows
the power off options, select OK to confirm your choice.
Alternatively, hold the power button for 8 seconds to force power
off. [You may also power on/off using the infra-red remote control.]
Micro SD Card Reader - Increase the storage capacity or read files
directly from a micro SD card slot, supports up to 256GB capacity.
3.5mm Audio Jack - Connect external audio input/output device.

Overview
USB 2.0 and USB 3.0 Ports - Connect an external USB device to the
NEO X39 such as webcam, wired mouse or external hard drive.
HDMI Port - Connect the NEO X39 via HDMI to a TV or PC monitor
using included HDMI cable.
USB-C Port - Connect the NEO X39 via USB-C to a TV or PC monitor.
Gigabit Ethernet Port - Connect an Ethernet cable for wired internet
access up to 1000Mbps.
Optical Audio Port - Connect to the optical audio input or an external
sound processing unit, such as an amplifier.
DC 12V Power-in Jack - Connect the included 12V power adapter.

Control
You may control NEO X39 via one of the following input methods:
1. Wired mouse
2. 2.4GHz USB wireless mouse and keyboard set
3. 2.4GHz USB air-mouse/gyro-mouse
4. MINIX IR-Remote [included]
Menu: Call out the options menu from your current screen
Home: Return to the home screen
Power: Power on, enter/wake from sleep mode
Back: Return to the previous screen or cancel current action
Volume Up and Down: Adjust the system volume
Directional Pad: Move up, down, left and right
OK: Confirm a particular action, or as an ‘Enter’ key
Settings: Call out the basic settings menu
IR-Remote Functions

NEO X39 connects to your TV or PC monitor via either a HDMI or
USB-C port.
Step 1: Connect the Cable [HDMI or/and USB-C]
Connect one end of the cable to the corresponding port on your
TV/PC monitor, and the other end to the port on NEO X39.
Step 2: Connect the Power
Connect the supplied 12V power adapter to the power-in jack.
Press and hold the power button for 2-3 seconds to power on,
the blue power LED should then glow.
Step 3: Turn on your TV/PC monitor and select the input
Turn on your TV or PC monitor and select the corresponding port
connected to the NEO X39.
Basic Setup

Language Setup
You may choose the desired system language by following these
steps: Launcher Home Screen > Settings > Language
The default language is English.
Time Zone Setup
You can adjust the time zone according to your current location by
following these steps:
Launcher Home Screen > Settings > Date & Time > Select Time Zone
Wi-Fi Setup
Follow these steps to connect to your wireless network:
Launcher Home Screen > Settings > Wi-Fi Network > Turn On
Select the network you wish to connect to and enter the password
when prompted.
Basic Setup

The USB-C port supports 9V/2A, 12V/5A and 15V/3A
power input. It does not support 20V/3.25A power input.
The USB-C port only supports 5V/3A power output.
LG 27UD88 monitor is fully compatible with NEO X39,
a full list of compatible USB-C equipped monitors can be
found on the MINIX Forum – www.theminixforum.com.
NEO X39 is fully compatible with our range of USB-C
accessories, including USB-C to USB-C cable [NEO C-MUC]
and USB-C to 4K @ 60Hz HDMI cable [NEO C-4K].
USB-C Notes

Copyright 2019 MINIX Technology Limited. All rights reserved.
No part of this guide, including the products and software described
in it, may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language in any form or by
any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of
MINIX Technology Limited.
MINIX and the MINIX logo are trademarks of MINIX Technology
Limited. All other marks and trademarks are properties of their
respective owners.
The content of this guide may differ in some details from the product
or its software.
All information in this documentation is subject to change without
notice.
C

NEO X39 connects to your TV or PC monitor via either a HDMI or
USB-C port.
Step 1: Connect the Cable [HDMI or/and USB-C]
Connect one end of the cable to the corresponding port on your
TV/PC monitor, and the other end to the port on NEO X39.
Step 2: Connect the Power
Connect the supplied 12V power adapter to the power-in jack.
Press and hold the power button for 2-3 seconds to power on,
the blue power LED should then glow.
Step 3: Turn on your TV/PC monitor and select the input
Turn on your TV or PC monitor and select the corresponding port
connected to the NEO X39.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment under FCC rules.

EMAIL: [email protected]
WEBSITE: www.minix.com.hk
MINIX FORUM: www.theminixforum.com
FACEBOOK: www.facebook.com/minixtech
Contact Us
www.minix.com.hk

4K Ultra HD Industrial Android Player
™
Benutzerhandbuch
NEO X39
www.minix.com.hk

Mali-T860MP
12V, 3A Adapter (im Lieferumfang)
oder via USB-C Eingang (12V DC)
4GB LPDDR4
RJ-45 Gigabit Ethernet, microSD Kartenleser,
3x USB 2.0 Anschluss, 1x USB 3.0 Anschluss,
1x USB-C Anschluss, Kensington Lock Vorbereitung
GPU
Arbeitsspeicher
weitere Anschlüsse
Stromversorgung
Prozessor
Speicher
Funkverbindung
Digital Audio Ausgänge
Video Anschlüsse
Betriebssystem
Analoge Audio Ausgänge
Audio Eingang
32GB eMMC 5.1 (MLC)
Dual-Band WLAN 802.11ac 2 x 2 MIMO, Bluetooth 4.1
Android™ 7.1.2 Nougat
HDMI™ 2.0 (4K @ 60Hz), USB-C (Full 1080p HD)
HDMI™2.0, Optischer S/PDIF
3,5mm Kopfhöreranschluss
3,5mm Kopfhöreranschluss
Ausstattung
Dual Core Cortex A72 + Quad Core Cortex A53 Processor (64-bit)

MINIX NEO X39 MINIX
IR-Fernbedienung
12V (3A)
Stromversorgung
HDMI Kabel
Dual-Band
Antenne
USB-C/USB-A
Kabel
Beinhaltet

Kurzüberblick
Danke, dass Sie sich für die MINIX NEO X39 entschieden
haben.
Die NEO X39 unterstützt den Großteil aller Video und Audio
Formate und ist Vorreiter bei bahnbrechenden Technologien
um eine verbesserte Bild und Tonqualität zu liefern.
Für weitere Hinweise, Tipps und nützliche Informationen
besuchen Sie uns auf: www.theminixforum.com

Kurzüberblick
IR Empfänger - Kompatibel zu Logitech Harmony.
Power LED - Leuchtet blau, wenn die NEO X39 in Betrieb ist und grün
im Standby.
Power Knopf - Um die NEO X39 zu starten, drücken Sie den Knopf für
1-2 Sek. bis die LED leuchtet. Zum Ausschalten drücken Sie den
Knopf bis auf dem Display die Ausschaltoption erscheint und wählen
Sie OK. Alternativ halten die den Knopf für 8 Sekunden gedrückt.
(Das Ein-/Ausschalten ist auch über IR Fernbedienung möglich.)
microSD Kartenleser - Erweitern Sie den Speicher oder lesen Sie
Dateien von einer Karte direkt ein. Unterstützt bis zu 256GB.
3,5mm Klinkenstecker - Ein- und Ausgang für externe Audiogeräte.
USB 2.0 und USB 3.0 Anschlüsse - Schließen Sie externe Geräte mittels
dieser Anschlüsse an.

Kurzüberblick
HDMI Port - Schließen Sie einen Fernseher oder Monitor mittels des
beiliegenden HDMI Kabel an.
USB-C Port - Schließen Sie die NEO X39 mittels USB-C an einen Fernseher
oder Monitor an.
1GBit Netzwerk Anschluss - Für Hochgeschwindigkeitsnetzwerke bis
zu 1000Mbps.
Optischer Audio Anschluss - Schließen Sie optische Audio Geräte
hier an. Sowohl als Ein- und Ausgang nutzbar.
Gleichspannung 12V Stromversorgung - Nutzen Sie das beiliegende
Netzteil.

Steuern Sie die NEO X39 mittels einer der folgenden Methoden:
1. Kabelgebundene Maus
2. 2,4GHz kabellose USB Maus und Keyboards
3. 2,4GHz kabellose USB Air-Mouse/ Gyro-Mouse
4. MINIX IR-Fernbedienung (beiliegend)
Menue: Ruft das Einstellungsmenue aus dem aktuellen Bildschirm auf
Home: Auf den Startbildschirm zurückkehren
Power: Einschalten, Aufwecken aus dem Schlafmodus
Zurück: Zum vorherigen Bildschirm zurückkehren
Lautstärke hoch/ runter: Einstellen der Lautstärke
Richtungstasten: Hoch/ Runter, Rechts/ Links
OK: Bestätigt die aktuellen Aktion oder als Eingabe
Einstellungen: Ruft die Grundeinstellungen auf
IR-Fernbedienungsfunktionen
Bedienung
