INSTALLATION MANUAL
JS-601
for Product Code 4036
Job Separator
NOTES
•Before installing, be sure to unplug the power cord of the machine.
•Keep all packing materials out of the reach of children.
4655-7761-02E.fm 0 ページ ２００４年２月１２日 木曜日 午前９時３１分

JS-601
– 1 –
■Unpacking the Job Separator
1. Check that the following accessories are available in the box.
2. Remove tape and other fixing brackets.
■Installing the Job Separator
3. Secure the Job Separator and connect the Hookup Cord to the Finisher (two screws
furnished with the Job Separator).
1 Job Separator ........................................................................................ 1
2 Exit Tray................................................................................................. 1
3 Front Cover............................................................................................ 1
4 Rear Cover ............................................................................................ 1
5 Screw (4x10) ......................................................................................... 2
6 Installation Manual (this manual) ........................................................... 1
4655U001AA 4655U002AA
4655U003AA
4655U004AB
4655U012AA
23
4
5
1
6
4655U005AB
1. Open the Upper Door of the Finisher.
4655U006AA
2. Remove the Dummy Cover (one screw).
4655U007AA
4655U018AB
4655-7761-02E.fm 1 ページ ２００４年２月１２日 木曜日 午前９時３１分

JS-601
– 2 –
4. Install the Front Cover.
NOTE
First insert the hook ➀ and then insert the hook ➁ in order into the holes.
5. Install the Rear Cover.
NOTE
First insert the hook ➀ and then insert the hook ➁ in order into the holes.
➀
➁
4655U014AC
➀
➁
4655U013AC
6. Fit the Exit Tray.
7. Close the Upper Door.
4655U011AA
4655-7761-02E.fm 2 ページ ２００４年２月１２日 木曜日 午前９時３１分
