MINOURA V150-2 - SCHEMATICS User manual

UF-6: Right Side Coupling & Clamp Lever GM-6: Drive Roller, Axle & Bearing
UF-7: Clamp Lever Guide GM-7: Drive Roller Holder
UF-8: Left Side Coupling GM-9: Axle End Cap
UF-9: Coupling Lock Ring (Red) GM-10: Mag Unit Fitting Bracket
UF-13: Rubber Cap (45mm) GM-11: Rubber Shim
UF-17: V150-2 Main Frame (White) GM-12: Mount Base
M8-4: Rubber Foot Cap (35mm) GM-13: Rubber Washer & Bolt Set
GM-2: Alloy Rotor GM-14: Foot Pedal
GM-3: Housing Cover GM-15: Micro Adjust Knob
GM-4: Neodymium Magnet (for V130/150/270) GM-16: Flywheel (1.5 kgs for V130/150)
GM-5: Main Housing GM-20: Remote Shifter (Chrome Plated)
UF-9
UF-8
UF-6
UF-7
M8-4
UF-13
UF-13
UF-17
V150-2 Schematics
- Page 3 -
GM-20
GM-9
GM-7
GM-10
GM-11
GM-12
GM-13
GM-14 GM-15
GM-6
GM-5
GM-4
GM-3
GM-2
GM-16
{
