minrray UV570 User manual

HD PTZ Camera
User Manual
（V1.0）
Universal Camera

FHD PTZ Camera User Manual
i
Preface
This manual is to ensure that the user can use the product properly and avoid danger
while operating. Before using this product, please read the user manual carefully and
keep it properly for future reference
Overview
This manual is about PTZ camera operation
Graphic Symbols
Description of graphic symbols used in this manual
Symbols
Description
This symbol indicates that the words are clarification or
supplement to this article.
This symbol indicates that negligence of the instructions may
lead to mishandling that may cause injury or property damage.
This symbol indicates a risk that may result in damage to this
machine or documents.
Follow the instructions to avoid property damage.

FHD PTZ Camera User Manual
ii
Attention
This manual introduces functions, installations and operations for this product in
details. Please read this manual carefully before installation and use.
Precautions:
This product can only be used in the specified conditions in order to avoid any
damage to the camera:
1) Do not expose the product to rain or moisture.
2) To prevent the risk of electric shock, do not open the case. Installation and
maintenance should only be carried out by qualified technicians.
3) Do not use the product beyond the specified temperature, humidity or power
supply specifications.
4) Please use a soft dry cloth to clean the camera. If the camera is very dirty, clean
it with diluted neutral detergent; do not use any type of solvents, which may
damage the surface.
Electrical Safety:
Installation and use of this product must strictly comply with local electrical safety
standards.
Transportation:
Avoid any stress, vibration, or moisture during transportation, storage, installation and
operation
Installation:
1) Do not rotate the camera head violently, otherwise it may cause mechanical
failure;
2) This product should be placed on a stable desktop or other horizontal surface. Do
not install the product obliquely, otherwise it may display inclined image;
3) Ensure there are no obstacles within rotation range of the holder.
4) Do not power on before completely installation.
Do Not Dismantle Camera：
We are not responsible for any unauthorized modification or dismantling.

FHD PTZ Camera User Manual
iii
Magnetic Interference
Electromagnetic fields at specific frequencies may affect the video image. This
product is Class A. It may cause radio interference in household application.
Appropriate measure is required.

FHD PTZ Camera User Manual
iv
Content
Quick Start .........................................................................................................................1
1.1 Interface................................................................................................................1
1.2 Connection Diagram ...............................................................................................2
1.3 Mounting Brackets .................................................................................................3
1.3.1 Wall Mount ...................................................................................................3
1.3.2 Ceiling Mount ................................................................................................4
Product Overview ...............................................................................................................6
2.1 Dimension .............................................................................................................6
2.2 Accessory ..............................................................................................................6
2.3 RS-232...................................................................................................................7
2.4 Rotary Dial...........................................................................................................10
2.5 Product Feature ...................................................................................................10
2.6 Technical Specification ..........................................................................................12
How To Use ......................................................................................................................16
3.1 Remote Control....................................................................................................16
3.2 IR Remote Control ................................................................................................17
3.2.1 Remote Control Usage..................................................................................19
3.3 Menu Setting .......................................................................................................21
3.3.1 Main Menu..................................................................................................21
3.3.2 English Menu...............................................................................................22
Network Connection .........................................................................................................23
4.1 Connection Method..............................................................................................23
4.2 Camera Web Interface ..........................................................................................24
4.3 Streaming............................................................................................................25
4.4 Software Upgrading..............................................................................................27
4.5 Webpage Configuration for Human ..........................................................................28
Serial Port Communication Port..........................................................................................31
5.1 VISCA Protocol List ...............................................................................................31
5.1.1 VISCA Protocol List .......................................................................................31

FHD PTZ Camera User Manual
v
5.1.2 Camera Control Command ............................................................................32
5.1.3 Inquiry Command.........................................................................................40
5.2 Pelco-D Protocol Command List .............................................................................44
5.3 Pelco-P Protocol Command List..............................................................................47
Maintenance and Troubleshooting .....................................................................................50
6.1 Camera Maintenance............................................................................................50
6.2 Unqualified Applications .......................................................................................50
6.3 Troubleshooting...................................................................................................50

FHD PTZ Camera User Manual
1
Quick Start
1.1 Interface
Figure1-1 Interface
Interface Introduction：
1, Lens
7, HDMI Output
13, RS422 Compatible with RS485
Interface
2, Base
8, USB3.0
14. LAN Port
3, Receiving Light
9, Audio Input
Interface(LINE-IN)
15, Power Input Socket(DC12V)
4, Infrared Receiver
10, Rotary Dial
Switch
16, Power Switch
5, Screw Hole for Tripod
11, RS232 Input
6, Hole for Installation
Fixation
12, RS232 Output
When using the camera, please put the plastic pad on the
center bottom of device

FHD PTZ Camera User Manual
2
1.2 Connection Diagram
Figure1-2 Connection Diagram
1) After power on and self-check, the camera will automatically return to the preset 0
position if it’s pre-set.
2) The default address for the IR remote control is 1#.
If the menu restored to factory defaults, the remote control default address will
restore to 1#.

FHD PTZ Camera User Manual
3
1.3 Mounting Brackets
Ceiling or wall mounting brackets can only be mounted on template and concrete
wall. For safety reason, plasterboard is not recommended.
1.3.1 Wall Mount

FHD PTZ Camera User Manual
4
1.3.2 Ceiling Mount

FHD PTZ Camera User Manual
5

FHD PTZ Camera User Manual
6
Product Overview
2.1 Dimension
Figure1-3 Product Dimension
2.2 Accessory
When you unpack your package, check that all the supplied accessories are
included:
Table1-1 SuppliedAccessory
Supplied
Power adapter
USB3.0 Cable
RS232 cable
User manual

FHD PTZ Camera User Manual
7
Plastic pad
Optional
Wireless remote control
IR Remote Control
Brackets for wall mounting
Brackets for ceiling mount
Cascading Cable
2.3 RS-232
1）RS-232 Jack
Connection method of camera to PC or
Controller.
Camera
WindowsDB-9
1.DTR
1.DCD
2.DSR
2.RXD
3.TXD
3.TXD
4.GND
4.DTR
5.RXD
5.GND
6.GND
6.DSR
7.IR OUT
7.RTS
8.NC
8.CTS
9.RI
Figure1-4 diagram of RS232 Connection

FHD PTZ Camera User Manual
8
2）RS-232 Mini-DIN 8-pin Terminal Definition
Table 1-8 RS-232 Mini-DIN 8-pin Port Definitions
3）RS232(DB9) Port Definition
NO.
Port
Definition
1
DTR
Data Terminal
Ready
2
DSR
Data Set
Ready
3
TXD
Transmit Data
4
GND
Signal Ground
5
RXD
Receive Data
6
GND
Signal Ground
7
IR OUT
IR
Commander
Signal
8
NC
No Connection
Table 1-9 RS232(DB9) Port Definition
NO.
Port
Definition
1
DCD
Data Carrier Detect
2
RXD
Receive Data
3
TXD
Transmit Data
4
DTR
Data Terminal Ready
5
GND
System Ground
6
DSR
Data Set Ready

FHD PTZ Camera User Manual
9
4）VISCA Networking Method
Networking Method
Device 1
Device2
1.DTR
1.DTR
2.DSR
2.DSR
3.TXD
3.TXD
4.GND
4.GND
5.RXD
5.RXD
6.GND
6.GND
7.IR OUT
7.OPEN
8. NC
8.OPEN
Figure1-5 Diagram of Networking Method
The product has RS232 input and output interfaces and can be cascaded in the
above manner.
7
RTS
Request to Send
8
CTS
Clear to Send
9
RI
Ring Indicator

FHD PTZ Camera User Manual
10
2.4 Rotary Dial
Figure1-6 Rotary dial corresponding to video format
Dial
Video Format
Dial
Video Format
0
1080P60
8
720P59.94
1
1080P50
9
-----
2
1080P30
A
-----
3
1080P30
B
-----
4
720P60
C
-----
5
720P50
D
-----
6
1080P59.94
E
-----
7
1080P29.97
F
-----
After switching the mode and dialing the code, you need to restart the camera to
take effect;
When the rotary dial is 5-F, the video format item will be displayed in the menu;
2.5 Product Feature
This series camera has perfect functions, superior performance and rich video output
interfaces; Featuring with advanced ISP processing algorithms, offering vivid and
high resolution video with a strong sense of depth and fantastic color rendition. It
supports H.264/H.265 encoding which makes motion video more fluent and clear
under low bandwidth conditions.
Full HD Resolution: 1/2.8 inch high quality CMOS sensor. Resolution is up to
1920x1080 with frame rate up to 60 fps.
Multiple Optical Zoom Lens: 12X/20X optical zoom lens.
Leading Auto Focus Technology: Fast, accurate and stable auto focusing
technology.

FHD PTZ Camera User Manual
11
Low Noise and High SNR: Super high SNR image is achieved with low noise
CMOS. Advanced 2D/3D noise reduction technology further reduces the noise
while ensuring high image clarity.
Multiple video output interfaces: HDMI, USB3.0, LAN. Simultaneously output
audio and video signal via HDMI, LAN interface support POE, USB 3.0 support
dual code stream,
USB3.0 Support Dual Coding Stream: Support main stream and sub –stream,
and simultaneous output; support YUY2, MJPEG, H.264, NV12, H.265 video
coding format
Built-in Gravity Sensor: Support PTZ auto-flip function and easy installation.
Multiple Network Protocol: Support ONVIF,GB/T28181,RTSP,RTMP,VISCA
OVER IP,IP VISCA,RTMPS,SRT protocols; Support RTMP push mode,easy to
be connected to streaming server (Wowza,FMS); Support RTP multicast mode;
Control Interface: RS422 is compatible with RS485, RS232-IN, RS232-OUT,
and the RS232 interface supports cascading.
Multiple Control Protocol: Support VISCA, PELCO-D,PELCO-P protocols;
Support automatic identification protocols.
Quiet Pan / Tilt Movement: With high accuracy step driving motor, camera can
pan / tilt extremely quiet and smooth.
Various Remote Controls: Users can choose infrared remote control or wireless
remote control according to the environmental conditions used. The 2.4G
wireless remote control is not affected by angle, distance, and infrared
interference. Support the remote control signal transparent transmission function,
which is convenient for back-end equipment to use.
AI Human Detection: Built-in high-speed processor and advanced image
processing and analysis algorithms, users can choose real-time tracking and
regional tracking according to the environment.
Multiple Application: Online-education, Lecture Capture, Webcasting, Video
conferencing, Tele-medicine, Unified Communication, Emergency command and
control systems, etc.

FHD PTZ Camera User Manual
12
2.6 Technical Specification
Table1-2 Camera Lens Parameter
Camera Parameter
Parameter/Model
12X
20X
Focus
3.9～46.8mm
5.2～98mm
Fov
6.3°（N）72.5°（W）
3.2°（N）56°（W）
Aperture Value
F1.8 ～F2.4
F1.5 ～F3.0
Effective Pixels
2.07, 1/2.8-inch high-quality CMOS sensor
Video Format
HDMI Output:
1080P60,1080P50,1080P30,1080P25,720P60,720P50,
1080P59.94,1080P29.97,720P59.94；
USB3.0 Output
Mainstream：YUY2/NV12:
1920×1080/1280×720/1024×576/800×600/800×448/640×3
60/640×480/480×270/320×180@30/25/20/15/10/5fps;
MJPG/H264:
1920×1080/1600×896/1280×720/1024×576/960×540/800×
600/800×448/720×576/720×480/640×360/640×480/480×27
0/352×288/320×240@30/25/20/15/10/5fps;
Substream：YUY2/NV12:
1920×1080/1280×720/1024×576/800×600/800×448/640×3
60/640×480/480×270/320×180@30/25/20/15/10/5fps;
MJPG/H264:
1920×1080/1600×896/1280×720/1024×576/960×540/800×
600/800×448/720×576/720×480/640×360/640×480/480×27
0/352×288/320×240@30/25/20/15/10/5fps
Minimum
Illumination
0.5Lux(F1.8, AGC ON)
DNR
2D﹠3D

FHD PTZ Camera User Manual
13
AWB
Automatic, manual, one-key white balance, specified color
temperature
Focus Mode
Automatic, manual, one-key focus
Exposure Mode
Auto, manual, shutter priority, aperture priority, brightness priority
Iris Value
F1.8 -- F11,CLOSE
Shutter Speed
1/25 -- 1/10000
BLC
On/off
Dynamic Range
Off, 1-8
Image Adjustment
Brightness, chroma, saturation, contrast, sharpness, black and white
mode, gamma curve
SNR
≥50dB
AI Function & Performance
Real-Time Tracking
Maximum Tracking Range: 6-7 meters. Support speakers to walk at
a speed of 3-4 meters
Regional Tracking
Maximum Tracking Region: 4. Support set the region within
horizontal -170°～+170°and vertical -30°～+90°
Interface
Input/Output
Interface
HDMI, LAN(POE),USB3.0（TypeB compatible withUSB2.0）, A-
IN,RS232-IN, RS232-OUT,RS422（compatible with RS485）,rotary
switch,DC12V Power,Power Switch
Video Encoding
Format
LAN Interface：Support main stream and sub-stream H.265,H.264
USB3.0 Interface：main stream support YUY2,MJPEG,H.264,NV12
Audio Input
Interface
Dual channel 3.5mm linear input
Audio Output
Interface
HDMI ,LAN,USB3.0
Audio Compression
AAC,MP3,G.711A

FHD PTZ Camera User Manual
14
LAN Interface
10M/100M/1000M adaptive Ethernet port, support POE power
supply, support audio and video output
Network Protocol
RTSP,RTMP,ONVIF,GB/T28181,VISCA OVER IP,IP
VISCA,RTMPS,SRT Support remote upgrade, remote restart,
remote reset
Control Interface
RS232-IN,RS232-OUT,RS422 compatible with RS485
Serial
Communication
Protocol
VISCA/Pelco-D/Pelco-P; support baud rate
115200/38400/9600/4800/2400
USB
Communication
Protocol
UVC（video communication protocol）,UAC（audio communication
protocol）
Power Interface
HEC3800 Power socket (DC12V)
Power Adapter
Input AC110V-AC220V；output DC12V/2.5A
Input Voltage
DC12V±10%
Input Currency
<1A
Consumption
<12W
PTZ
Pan Rotation
-170°-- +170°
Tilt Rotation
-30°-- +90°
Pan Speed
0.1°/s -- 100°/s
Tilt Speed
0.1°/s -- 45°/s
Preset Speed
Pan：100°/s,Tilt：45°/s
Preset Quantity
Maximum 255 preset positions can be set(10 via remote controls)
