General Safety Instructions 1 & 2
Warning Decal Placement 3
Assembly Instructions 4, 5
Handle Assembly 6, 7
Blower Assembly HC Series 8
Blower Assembly HT Series 9
Engine Assembly 10, 11, 12
Warranty Back Cover

1
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANTANT
ANTANT
ANT SAFETYSAFETY
SAFETYSAFETY
SAFETY INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
READREAD
READREAD
READ ALLALL
ALLALL
ALL INSTRUCTIONS BEFORE USINGINSTRUCTIONS BEFORE USING
INSTRUCTIONS BEFORE USINGINSTRUCTIONS BEFORE USING
INSTRUCTIONS BEFORE USING
WW
WW
WARNINGARNING
ARNINGARNING
ARNING
• To prevent personal injury or property damage, do not attempt to start engine until all assembly steps are
complete and you have read and understand the safety and operating instructions in this manual.
• Under California, and under laws of several other states, you are not permitted to operation internal
combustion’s engine using hydrocarbon fuels on any forest covered, brush covered, or grass covered
land, or on land with grain, hay, or other flammable agricultural crop, without an engine spark arrester in
continuous effective working order.
• The engine on your power equipment, like most outdoor power equipment, is an internal combustion en-
gine that burns gasoline, a hydrocarbon fuel. Therefore, your power equipment must be equipped with a
spark arrester muffler in continuous effective working order. The spark arrester must be attached to the
engine exhaust system in such a manner that flames or heat from the system will not ignite flammable
material. Failure of the owner/operator of the equipment to comply with this regulation is a misdemeanor
under California law, and may also be a violation of other state and/or federal regulations, laws, ordinances,
or codes. Contact your local fire marshal or forest service for specific information about what regulations
apply in your area.
• Wear approved safety glasses when operating this equipment. The operation of any powered machine can
result in foreign objects being thrown by high-speed rotating parts.
• Wear work gloves, sturdy footwear, and hearing protection when operating this equipment.
• Remove hearing protection and watch for traffic when operating near, or when crossing roadways.
• Before inspecting or servicing any part of equipment, shut off engine, disconnect spark plug wire from
spark plug, and make sure that all moving parts have come to a complete stop. Be aware that rotating
blades slow down gradually after engine is shut off.
• Exercise extreme caution on slopes and avoid excessively steep slopes.
• Never leave equipment unattended when engine is running. Shut off engine and disconnect spark plug wire
from spark plug before leaving equipment.
• Do not blow any burning or smoldering materials such as cigars, cigarettes, ashes or cinders.
• Do not blow areas that have been recently treated with fertilizers, pesticides or herbicides. Follow chemical
manufacturer’s safety instructions regarding contact with treated areas.
• Never allow children or untrained adults to operate this equipment.
• Keep the area of operation clear of all persons, particularly small children, and pets. Keep bystanders at
least 25 feet away from the area of operation.
• Do not run engine in an enclosed area. Engine exhaust contains carbon monoxide gas, a deadly poison
that is odorless, colorless, and tasteless. Do not operate this equipment near buildings, windows, or air
conditioners.
• Do not allow hands or any other part of the body or clothing inside the vacuum inlet.
• Do not start engine or operate this equipment with any safety guards or housing removed.
DANGERDANGER
DANGERDANGER
DANGER
Gasoline is highly flammable and its vapors are explosive. To prevent personal injury or property damage:
• Do not add fuel if engine is running or still hot from recent operation. Allow engine to cool for at least three
minutes.
• Do not fill fuel tank indoors. After filling, wipe up any spills and move away from gasoline fumes before
starting engine.
• Do not allow open flame, matches, or smoking in area.
• Fill fuel tank with fresh, clean unleaded regular automotive gasoline, (leaded regular and unleaded or
leaded premium grades of gasoline are acceptable substitutes).
• Do not mix oil with gasoline.
• Clean the area around the fuel fill cap and remove the cap from the fuel tank. Insert a clean funnel into the
fuel tank.
• Fill the tank to 1/2 inch below the bottom of the filter neck to provide space for any fuel expansion.
• Reinstall the fuel fill cap securely and wipe up any spilled gasoline.
SASA
SASA
SAVEVE
VEVE
VE THESE INSTRUCTIONSTHESE INSTRUCTIONS
THESE INSTRUCTIONSTHESE INSTRUCTIONS
THESE INSTRUCTIONS

2
SAFETY DECALSSAFETY DECALS
SAFETY DECALSSAFETY DECALS
SAFETY DECALS

3
ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
YINSTRUCTIONSINSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
UNPUNP
UNPUNP
UNPACKINGACKING
ACKINGACKING
ACKING
1. Remove all loose items from the carton.
2. Do not discard the carton or inserts until the unit is completely assembled.
ASSEMBLING WHEELSASSEMBLING WHEELS
ASSEMBLING WHEELSASSEMBLING WHEELS
ASSEMBLING WHEELS
1. Remove the cotter pin from each end of axle. Also remove one
flatwasher from each side.
2. Lift unit and assemble wheels to axles. Replace flatwashers and
cotter pins.
NOTE: Wheels must be assembled with grease fitting in hub to
the outside. Apply a good grade of grease to wheels before
operating unit.
NOTE: See Handle Assembly on Page 7 of this owner’s guide
for reference to number used in the following instructions.
HANDLEHANDLE
HANDLEHANDLE
HANDLE ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
Y
1. Remove hex head bolts (20) and hex lock nuts (29) from
the bottoms of the upper handles (1) and (2).
2. Place upper handles (1) and (2) over the ends of the
middle handles (3).
3. Align the lower holes in both upper and middle handles.
Replace hex head bolts (20), removed in Step 1, to each
of the lower holes.
4. Lift handles until the back braces (4) can be assembled
to bolts (20) assembled in Step 3. Assemble hex lock
nuts (29). DO NOT TIGHTEN.
5. Align the upper holes in both upper and middle handles.
Assemble the remaining two hex head bolts (20) and hex
lock nuts (29). DO NOT TIGHTEN.
NOTE: Check alignment of handle. The hex lock nuts have
been left loose to allow movement between the holes and
the bolts. Do not bend tubing to accomplish proper
alignment.
6. Once handles are aligned, tighten all hex lock nuts (29).
NOTE: Nuts should be tightened enough that at least two of the bolt threads extend through the nut. It
may be necessary to collapse the tubing SLIGHTLY to accomplish this.
THROTTLE HOOKUPTHROTTLE HOOKUP
THROTTLE HOOKUPTHROTTLE HOOKUP
THROTTLE HOOKUP
1. Remove throttle control assembly from shipping
position.
2. Straighten the throttle cable out and run it up the left
hand handles (2) and (3).
3. Attach the throttle control (8) to the upper left hand
handle (2) with the two oval head screws (25) and
hex nuts (28) furnished.
4. Attach snap-on clamps (17) to handle to secure
throttle cable.
5. Make sure no bends are less than 8" radius.
3. Whenever the terms left or right hand, or “L” and “R”,
are used, it means from a position standing behind
the unit facing forward. All hardware is on the unit in
its proper location.

4
ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
YINSTRUCTIONSINSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
ASSEMBLING DEFLECTOR CONTROL ROD HC MODELASSEMBLING DEFLECTOR CONTROL ROD HC MODEL
ASSEMBLING DEFLECTOR CONTROL ROD HC MODELASSEMBLING DEFLECTOR CONTROL ROD HC MODEL
ASSEMBLING DEFLECTOR CONTROL ROD HC MODEL
1. Remove the contour head bolt (23) lockwasher (26)
and hex nut (27) from lower end of upper control
rod (10).
2. Place lower end of upper control rod (10) down
through hole in bracket (9) on upper cross bar (5).
3. Lift free end of lower control rod (11) and place inside
lower end of upper control rod (10). Align holes and
reassemble hardware from Step 1.
OPERAOPERA
OPERAOPERA
OPERATIONTION
TIONTION
TION AND MAINTENANCE INSTRUCTIONSAND MAINTENANCE INSTRUCTIONS
AND MAINTENANCE INSTRUCTIONSAND MAINTENANCE INSTRUCTIONS
AND MAINTENANCE INSTRUCTIONS
WARNING: The engine contains no oil when shipped. Read the Engine Instruction Manual and add the
proper type and amount of oil and gas before starting engine.
1. Read engine manual carefully. Be sure to know how to start
and stop engine operating unit.
2. The unit is designed to operate at full throttle, and will work
effectively by either pushing or pulling.
3. To clean an area, start at the outer perimeter and blow the
material toward the center.
4. When cleaning large areas or if debris is very dense, it may
be best to split the area into smaller plots and blow the material
into several small piles rather than one large one. As the area
being cleaned becomes smaller, reduce the engine speed to
prevent blowing the collected debris into the area already
cleaned.
HC MODELS ONLHC MODELS ONL
HC MODELS ONLHC MODELS ONL
HC MODELS ONLYY
YY
Y
5. The blower housing can be adjusted to the “Hi” or “Low”
blowing position depending on the job being performed.
6. Place the blower housing in the “Low Blow” position with the
exhaust deflector straight out from side of unit for blowing dry
leaves and other light debris.
7. For blowing heavier debris such as wet leaves, twigs and
small sticks, place blower housing in “Low Blow” position with
exhaust deflector aimed downward.
8. Place the blower housing in the “Hi Blow” position for stacking
leaves in piles or windrows. The exhaust deflector should be
adjusted to achieve desired effect.
ADJUSTING BLOWER HOUSING “HI or LOW”ADJUSTING BLOWER HOUSING “HI or LOW”
ADJUSTING BLOWER HOUSING “HI or LOW”ADJUSTING BLOWER HOUSING “HI or LOW”
ADJUSTING BLOWER HOUSING “HI or LOW”
CAUTION: When adjusting blower housing, engine
must be shut off and spark plug wire disconnected.
1. Loosen adjusting knob, do not remove, that holds
clamp against pivot ring of blower housing.
2. Pivot blower housing to desired position and tighten
adjusting knob.
NOTE: It is not necessary to detach the deflector
control rod assembly.
3. It is possible to control the air flow from the
operating position. Turn exhaust control lever to
change deflection on angle of exhaust deflector.

5
ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
YINSTRUCTIONSINSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
SHIFT LEVER CONNECTIONSHIFT LEVER CONNECTION
SHIFT LEVER CONNECTIONSHIFT LEVER CONNECTION
SHIFT LEVER CONNECTION
1. Remove cotter pin (18) from upper end of shifter rod (19).
2. Place end of rod thru upper hole in shift lever (13). Small pin in rod will act as a stop.
3. Replace cotter pin (18). Shifter rod (19) should pivot freely in shift lever (13).
4. Secure lower end of shifter rod (19) to shifter plate (20) as outlined above.
5. Pulling shift lever fully to the rear is reverse gear. Moving lever progressively from reverse is
neutral, 1st, 2nd, 3rd, 4th and 5th gears. Securing bracket (12) is slotted on bottom for adjustment
if necessary.
NOTE: Unit will roll freely forward and backwards with the transmission in neutral.
CLUTCHCLUTCH
CLUTCHCLUTCH
CLUTCH ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
Y ANDAND
ANDAND
AND ADJUSTMENTADJUSTMENT
ADJUSTMENTADJUSTMENT
ADJUSTMENT
1. Remove the snap clamp (26) securing the clutch cable (37) to the left middle handle (12).
2. Run the clutch cable (37) up the right hand upper handle (10) and assemble open loop of spring
(37) through hole in tab of clutch grip (35).
3. Check to make sure the lower end of clutch cable is seated in the nylon pulley (78).
NOTE: Proper assembly of the clutch cable is important as it determines the adjustment of the
clutch. Follow these instructions carefully to adjust clutch.
4. Loosen the fasteners on wire clamp (40) securing clutch cable (37) to the right middle handle
(12).
5. Slide the black outer sheath of clutch cable (37) up or down so that the metal collar on top of
sheath is 2 1/4 inches down from the center of the hex head bolt (2) securing upper cross brace
(1) to handles.
6. Measure down 6 inches from that same bolt and assemble snap clamp (26), removed in Step 1,
to upper handle and clutch cable.
7. Measure up from the bottom of the middle handle (12) to the lowest edge of the wire clamp (40).
This should be 5 1/2 inches.
NOTE: If adjustment is needed wire clamp (40) should be loosened enough to allow free movement
over cable and handle without pulling or stretching black sheath.
8. Once clamp is properly set, hold in place and tighten fasteners.
9. This should be the correct setting and no further adjustment needed. To check, depress clutch
grip (35), engaging clutch, the cable spring should be, almost or just touching nylon pulley (78).
10. If after inspection or operation the clutch would need adjustment, loosen the fasteners on the wire
clamp (40). Moving the clamp upward on handle and cable will loosen the tension of clutch.
Moving the clamp down will tighten clutch.

6

7
PP
PP
PARAR
ARAR
ARTS LISTTS LIST
TS LISTTS LIST
TS LIST
ItemItem
ItemItem
Item Part No.Part No.
Part No.Part No.
Part No. QtyQty
QtyQty
Qty..
..
.DescriptionDescription
DescriptionDescription
Description
1 350186 1 Rope Guide 396526
2 363-816 1 Nut-Nyloc 1/2-20
3 380-432-20 2 Cotter Pin
4 66-436-A 1 Roller
5 67-521-A 2 Rollpin
6 69-416-24 1 BLT-Cont HD 1/4-20 x 1.5
7 711316 2 Nut-Hex 1/4-20 ST PL
8 711373 10 Nut-Nyloc 1/4-20
9 711374 2 Nut-Nyloc 5/16-18
10 711506 8 WSR-Flat 5/16 ST PL
11 711544 2 WSR-Helical 1/4
12 712638 2 Nut-Hex 10/24 SS Nyloc
13 69-416-16 1 BLT-Cont HD 1/4-20 x 1
14 712821 2 SCR-THMS 10-24 x 1.25 STPL
15 713005 7 BLT-HH 1/4-20 x 1 1/2 #5
16 713008 1 BLT-HH 1/4-20 x 2 1/4 #5
17 713030 2 BLT-HH 5/16-18 X 1 3/4 #5
18 713031 2 BLT-HH 5/16-18 X 2 #5
19 713069 1 BLT-HH 1/2-20 X 5.5 #5
20 74-135-A 1 Spring
21 80-238-A 4 Insert Bushing Handle
22 80-276-A 2 Snap Mount
23 80-321-C 1 Handle Upper Drilled & FO
24 81-164-A 1 Nylon Washer HC
25 55-161-A 1 WSR-Special
26 81-58-B 1 Crossbar Brace
27 82-149-B 2 Middle Handle HC
28 82-249-B 1 Crossbar Upper HC
29 82-252-A 1 Bracket HC
30 83-18-C 1 Handle Upper
31 83-25-B-36 1 Throttle Cable Assembly
32 88-91-C 1 Chassis Weldment
33 88-94-C 2 Handle Back Brace
34 92-30 1 Decal Trottle
35 945-1216 2 Special Washer
36 713002 4 BLT-HH 1/4-20 x 3/4 #5
37 SA-1581-A 1 Lower Control Rod Assembly
38 SA-231-B 2 Wheel Assembly
39 SA-909-B 1 Upper Control Rod Assembly
40 82-147-B 2 Roller Support Assembly
41 84-259-A 1 Bushing
42 80-232-A 2 Handle Grip Red
43 711512 2 WSR-Flat .75 x 1.37 x .08
44 81-120-A 2 Spacer

8
ItemItem
ItemItem
Item Part No.Part No.
Part No.Part No.
Part No. QtyQty
QtyQty
Qty..
..
.DescriptionDescription
DescriptionDescription
Description
1 350177 3 Finger Guard Rod Plated
2 350242 1 Belleville Washer 7/16
3 80-316-C 1 Back Plate Weldment
3A 350420 1 Back Plate Assembly HC-Honda
4 79-51-A 1 Clamp
4A 350422 1 Clamp Bracket
5 370074 6 Hubcap Upright
6 505-416-24 8 Flat Head Screw
7 60-716-24 1 BLT-HH 7/16-20 x 1.5 #5
8 711374 3 Nut-Nyloc 5/16-18
9 711377 4 Nut-Lock 1/4-20
10 711505 12 WSR-Flat 1/4
11 711506 3 WSR-Flat 5/16 STPL
12 711615 3 Rollpin .12 x .75
13 713002 7 BLT-HH 1/4-20 x 3/4 #5
14 713003 1 BLT-HH 1/4-20 x 1 #5
15 713028 2 BLT-HH 5/16-18 x 1 1/4 #5
16 73-123-C 4 Anti-Wrap Segment
17 73-124-B 2 Exhaust Side Plate
18 73-125-B 2 Exhaust Def Weldment HC
ItemItem
ItemItem
Item Part No.Part No.
Part No.Part No.
Part No. QtyQty
QtyQty
Qty..
..
.DescriptionDescription
DescriptionDescription
Description
19 73-126-A 1 Link Exhaust Def
20 73-372-A 1 Spring
21 75-79-A 1 Knob
22 75-80-A 2 Shaft Retainer
23 79-129-C 1 Pivot Ring HC
24 79-67-A 2 Spacer for Kohler
24A 83-193-A 1 Spacer Briggs - Honda
25 79-94-A 1 Fluted Knob for Kohler
25A 350139 1 Knob Briggs - Honda
26 80-101-A 2 Bushing
27 81-120-A 2 Spacer for Kohler
28 82-118-D 1 Blower Housing HC
29 82-121-C 1 Grille HC
30 82-124-A 1 Decal Parker Circle HC
31 82-138-B-3 2 Special Washer
32 82-251-A 1 Universal Joint Assembly
33 SA-1581-A 1 Lower Control Rod Assembly
34 80-144-A 2 Roller Guide
35 73-118-D 1 Fan Assembly HC
36 711373 4 Nut-Nyloc 1/4-20
PP
PP
PARAR
ARAR
ARTS LISTTS LIST
TS LISTTS LIST
TS LIST

9
ItemItem
ItemItem
Item Part No.Part No.
Part No.Part No.
Part No. QtyQty
QtyQty
Qty..
..
.DescriptionDescription
DescriptionDescription
Description
1 350177 3 Finger Guard Rod Plated
2 350242 1 Belleville Washer 7/16
3 351-416-18 1 Wing Nut
4 370074 6 Hubcap Upright
5 60-716-20 1 BLT-HH 7/16 x 1 1/4 #5
6 70-416-12 1 Carriage Bolt
7 711377 4 Nut-Lock 1/4-20
8 711505 10 WSR-Flat 1/4
9 711544 9 WSR-Helical 1/4
10 713002 5 BLT-HH 1/4-20 x 3/4 #5
11 713003 8 BLT-HH 1/4-20 x 1 #5
12 73-118-D 1 Fan Assembly HC
13 73-123-C 4 Anti-Wrap Segment
14 82-117-D 1 Blower Housing HT
15 82-121-C 1 Grille HC
16 82-124-A 1 Decal Parker Circle HC
17 82-130-C 1 Exhaust Deflector
18 82-138-B-3 2 Special Washer
19 83-52-C 1 Back Plate
20 711373 1 Nut-Nyloc 1/4-20
PP
PP
PARAR
ARAR
ARTS LISTTS LIST
TS LISTTS LIST
TS LIST

10

11

12

LIMITED WLIMITED W
LIMITED WLIMITED W
LIMITED WARRANTYARRANTY
ARRANTYARRANTY
ARRANTY
The Parker Sweeper Company warrants to the original purchaser/user that this product is free from defects in workmanship
and materials under normal use and service for a period of two years from date of purchase. In addition, Parker Sweeper
Company will, at its option, honor labor warranty claims for the first 12 months from date of sale, provided such claims are
submitted through and approved by factory authorized repair stations. Parker Sweeper Company will, at its option, repair or
replace without charge, except for transportation costs, parts that fail under normal use and service when operated and
maintained in accordance with the applicable operation and instruction manuals.
This warranty does not apply to normal wear, or to items whose life is dependent on their use and care, such as belts, cords,
switches, hoses, rubber parts, electrical motor components or adjustments. Parts not manufactured by Parker Sweeper
Company such as engines, batteries, battery chargers, hydraulic pumps, and tires are covered by and subject to the warranties
and/or guarantees of their manufacturers. Please contact Parker Sweeper Company for procedures in warranty claims against
these manufacturers.
Special warning to purchaserSpecial warning to purchaser
Special warning to purchaserSpecial warning to purchaser
Special warning to purchaser — Use of replacement filters and/or prefilters not manufactured by Parker Sweeper Company
or its designated licensees, will void all warranties expressed or implied.
A potential health hazard exists without exact original equipment replacement.
All warranteed items become the sole property of Parker Sweeper Company or its original manufacturer, whichever the case
may be.
Parker Sweeper Company disclaims any implied warranty, including the warranty of merchantability and the warranty of fitness
for a particular purpose. Parker Sweeper Company assumes no responsibility for any special, incidental or consequential
damages.
This limited warranty is applicable only in the U.S.A. and Canada, and is extended only to the original user/purchaser of this
product. Customers outside the U.S.A. and Canada should contact their local distributor for export warranty policies. Parker
Sweeper Company is not responsible for costs or repairs performed by persons other than those specifically authorized by
Parker Sweeper Company. This warranty does not apply to damage from transportation, alterations by unauthorized persons,
misuse or abuse of the equipment, use of non-compatible chemicals, or damage to property, or loss of income due to
malfunctions of the product.
If a difficulty develops with this machine, you should contact the dealer from whom it was purchased.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state. Some states do not
allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long an implied warranty
lasts, so the above exclusions and limitations may not apply to you.
988225
Printed in U.S.A.
A Member of the Hako Group of Companies
World HeadquartersWorld Headquarters
World HeadquartersWorld Headquarters
World Headquarters Minuteman Canada, Inc.
Minuteman International, Inc. 2210 Drew Road
111 South Rohlwing Road Mississauga, Ontario
Addison, Illinois 60101 L5S 1B1
Phone [phone] Phone [phone]
Fax [phone] Fax [phone]
www.minutemanintl.com
