Minuteman E17 User manual

User Manual
E17/E20 Walk-Behind Scrubber
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM1

2
This manual is furnished with each new MINUTEMAN E17/E20. This provides the necessary operating and preventive
maintenance instructions. Operators must read and understand this manual before operating or servicing this machine.
This machine was designed to give you excellent performance and efficiency. For best results and minimal cost,
please follow the general guidelines below:
·Operate the machine with reasonable care.
·Follow the manufacturers suggested maintenance instructions as provided in this booklet.
·Use original Minuteman supplied parts.
Model E17/E20
Model No. E17BD / E17BDCE / E17BDQP / E17BDQPCE
E17BDQPG / E17BDQPGCE
E20BDQP / E20BDQPCE
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM2

3
Technical Specifications
32 amps
24V
105AH @ 20Hr
100AH @ 20Hr
69 dBA
310 lbs (141 kg)
200 lbs (91 kg)
33” (84cm)
2%
2%
Current (Max)
Voltage, Batteries
Battery Capacity (Lead Acid)
Battery Capacity (Gel)
Sound Level
Gross Weight (with Batteries)
Gross Weight (w/o Batteries)
Squeegee Width
Working Grade Transport
Working Grade Cleaning
Working Width E17
Working Width E20
Working Speed
Vacuum Flow
Vacuum Waterlift
Vacuum Power
Brush Speed
Solution Tank Capacity
Recovery Tank Capacity
17” (43cm)
20” (60cm) E20
2.5 mph (4 km/hr)
65 cfm (110 m³/hr)
45 in.H2O (112 mbar)
3/4hp (560W)
180 RPM
12 gal (45 ltr)
13 gal (50 ltr)
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM3

4
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM4

5
Table Of Contents
Battery Compartment 15
HandleAdjustment 16
Angle Adjustment ................................................................16
Horizontal Adjustment ......................................................... 17
Solution Tank Drain Hose / Level Indicator 18
Solution Tank Drain Hose ................................................... 18
Solution Level Indicator....................................................... 18
Solution Fill Filter 19
Brush Load / Unload 20
Loading Brush ..................................................................... 20
Unloading Brush.................................................................. 21
Screened Float 22
Screened Float Removal 23
Rear Squeegee 24
The E17/E20 25
Machine Operation 26
Optional Equipment Operation 27
Hour Meter .......................................................................... 27
Solution Solenoid ................................................................27
After Use 28
Maintenance 29
Troubleshooting 30
Minuteman International Limited Warranty 32
Technical Specifications 3
Safety Instructions 6
DURING OPERATION .......................................................... 6
WHEN SERVICING or MAINTAINING MACHINE ................ 6
Unpacking Instructions 7
INSPECTION ........................................................................ 7
ELECTRICAL ........................................................................ 7
BATTERIES .......................................................................... 7
OPERATOR RESPONSIBILITY............................................ 7
Machine Overview 8
Front ...................................................................................... 8
Rear....................................................................................... 9
Control Panel 10
Bail Handle.......................................................................... 11
Handle Adjustment Knobs................................................... 11
Key Switch .......................................................................... 11
Squeegee Lift Lever ............................................................ 11
Solution Control Lever ........................................................ 11
Battery Gauge ..................................................................... 11
Charge Status Indicator ...................................................... 11
Optional Hour Meter 12
Optional Solution Solenoid 13
Circuit Breakers 14
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:43 PM5

6
Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
Operators must read and understand this manual before operating or maintaining this machine.
Do not operate this machine in flammable or explosive areas.
This machine is designed solely for scrubbing dirt and dust in an indoor environment. Minuteman does not recommend using this machine
in any other capacity.
The following information below may cause a potential hazard to the operator and equipment. Read this manual carefully and be aware
when these conditions can exist. Take necessary steps to locate all safety devices on the machine and train the personnel operating the
machine. Report any machine damage or faulty operation immediately. Do not use machine if it is not in proper operating condition.
FOR SAFETY DURING OPERATION
Keep hands and feet clear of moving parts while machine is in operation.
Make sure all safety devices are in place and operate properly.All covers, doors and latches must be closed and fastened before use.
During operation, attention should be paid to other persons in the work area and especially if small children are present.
Electric motors and components can cause an explosion when operated near explosive materials or vapor. Do not operate this machine
near flammable materials such as solvents, thinners, fuels, grain dust, etc.
Store or park this machine on a level surface only.To prevent unauthorized use, machine should be stored or parked with the key removed.
This machine is designed for level operation only. Do not operate on ramps or inclines greater than 2%.
This machine is not suitable for picking up hazardous dusts.
Use caution when moving this machine into areas that are below freezing temperatures.Any water in the tanks or hoses can cause damage
to the machine.
FOR SAFETY WHEN SERVICING or MAINTAINING MACHINE
Stop on level surface.
Disconnect the power to the machine by pressing the red Battery Plug located under the recovery tank near the batteries.
Avoid moving parts. Do not wear loose jackets, shirts, or sleeves when working on machine.
Avoid contact with battery acid. Battery acid can cause burns. When working on or around batteries, wear protective clothing and safety
glasses. Remove metal jewelry. Do not lay tools or metal objects on top of batteries.
Charging batteries generates explosive gasses.
Do not charge batteries when open flames or sparks are present. Do not smoke.
Make sure the charger is turned off before disconnecting it from the machine.
Charge the batteries in a well-ventilated area with the battery cover removed completely.
Do not clean machine with a pressure washer.
Authorized personnel must perform repairs and maintenance. Use Minuteman supplied replacement parts.
SAVE THESE INSTRUCTIONS
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM6

7
INSPECTION
Carefully unpack and inspect your E17/E20 Walk-BehindScrubber for shipping damage. Follow unpacking instructions on
shipping pallet. Each unit has been tested and thoroughly inspected before shipment.Any damage is the responsibility of the
delivery carrier who should be notified immediately.
ELECTRICAL
This machine is battery operated and designed to operate on 24 volts DC (2) 12-volt batteries.
BATTERIES
The recommended batteries are rated 105Ah (Minuteman P/N 956712) or 100Ah (Minuteman P/N 956100). We do not
recommend mixingAMP hour capacities.Alternate battery sets can be used if they equal physical size and capacity.
OPERATOR RESPONSIBILITY
Read this manual carefully before operating this machine.
The operator is responsible in taking care of the daily maintenance and check ups of the machine to keep it in good
working condition. The operator must inform the service mechanic or supervisor when the scheduled maintenance intervals
are required as stated in the MAINTENANCE section of this manual.
Before starting familiarize yourself with the machine and its controls (see “Machine Overview, Front”, “Machine Overview,
Rear”, “Control Console” diagrams).
Unpacking Instructions
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM7

8
Machine Overview
Machine Overview - Front A
B
C
D
E
F
G
H
A CUP HOLDER
B SOLUTION FILL PORT
C RECOVERY TANK LID
D RECOVERYTANK
E BRUSH DECK
F FRONT WHEEL
G REAR CASTER
H SOLUTION TANK
K
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM8

9
Machine Overview
Machine Overview - Rear A
B
C
D
G
H
F
E
A BAIL HANDLE
B SQUEEGEE LIFT LEVER
C SOLUTION CONTROL LEVER
D RECOVERY TANK DRAIN HOSE
E ONBOARD CHARGER CORD
F CIRCUIT BREAKERS
G RECOVERY HOSE
H CONTROLPANEL
I SOLUTION TANK DRAIN HOSE / LEVELINDICATOR
J BRUSH LIFT PEDAL
K REAR SQUEEGEE
I
J
K
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM9

10
Control Panel
A
B
C
D
F
E
G
A BAIL HANDLE
B HANDLE ADJUSTMENT KNOB
C KEY SWITCH
D SQUEEGEE LIFT LEVER
E SOLUTION CONTROL LEVER
F BATTERY GAUGE
G CHARGE STATUS INDICATOR
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM10

11
Control Panel
For operator ergonomics, the control panel houses all the primary functions. Controls are grouped in a central area at
the rear of the machine.
Bail Handle
(A) When the scrubdeck is lowered to the floor, The Bail Handle Enables the brush motor and moves the machine
forward once depressed. This also allows the operator to automatically load the brush when the scrubdeck is lowered.
Handle Adjustment Knobs
(B) Allows the handle position to be raised or lowered.
Key Switch
(C) Controls the machine’s power (Brush Unload/Off/On) with a key for safety. This switch, when turned counter clock-
wise, operates the auto brush unload when scrubdeck is in the raised position. When it is turned to the on position, the
machine will operate.
Squeegee Lift Lever
(D) When actuated to the top position, the squeegee is lowered and the vacuum motor is turned on. When locked in
the bottom position, the squeegee is raised and the vacumm motor shuts off.
Solution Control Lever
(E) This lever controls the rate at which solution is put down. Moving the lever up will increase the amount of solution.
Moving the lever down will decrease the solution rate. Moving the lever all the way down shuts off solution flow.
Battery Gauge
(F) This gauge displays the remaining battery charge.
Charge Status Indicator
(G) This gauge displays the status of the batteries during charging. The gauge has a readout of 3 LEDs. 1 Green, 1
yellow, 1 Red. Green indicating a full charge, Red indicating the batteries are charging.
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM11

12
Optional Hour Meter
Minuteman offers an optional hour meter for the
E17/E20. Theoptionalkit replaces the powercord
mounting bracket at the rear of the machine with
one that contains an hour meter.
Kit# K-E1720HM
Optional Hour Meter
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM12

13
Optional Solution Solenoid
Optional Solution Solenoid
Minuteman offers an optional solution solenoid for the
E17/E20. The optional solenoid automatically turns off
the solution flow when the brush motor is not active.
Kit# K-E1720S
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM13

14
Circuit Breakers
A Main Control Breaker
B Brush Motor Breaker
C Vacuum Motor Breaker
The circuit breaker is located at the bottom of the back panel of the
machine.The 4-amp breaker (A) protects the main controls circuit,
The 30-amp breaker (B) protects the brush motor circuit, and the
20-amp breaker (C) protects the vacuum motor circuit.
Circuit Breakers
BC A
If any of the functions above are not operating, check if the
circuit breaker buttons have tripped. Press to reset.
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM14

15
Battery Compartment
The battery compartment is located under the recovery tank.The
Battery compartment can be accessed for servicing and mainte-
nance by tilting the recovery tank (make sure recovery tank has
been drained before tilting). The battery compartment contains
two 12-volt batteries connected in series. Connect the batteries
according to the battery connection diagram (see diagram). The
recommended batteries are 105Ah (Minuteman P/N 956712) or
100Ah (minuteman P/N 956100) Gel. The battery tray may be
drained if neccessary using the orange drain hose located above
the rear caster on the right side of the machine.
Battery Compartment
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM15

16
Handle Adjustment
The E17/E20 handle was designed with operator comfort in
mind. The angle and horizontal position of the handle can be
adjusted to suit the needs of the operator.
The handle angle can be adjusted without tools by loosening the
AngleAdjustment Knob (A) on each side and rotating the handle
to the desired position. There are 5 angular positions 11.25° apart
for a total of 45° between the minimum and maximum position.
Angle Adjustment
A
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM16

17
Handle Adjustment
12
3
Plate Position 1
(Shipping Position)
Plate Position 2
Plate Position 3
(Fully Extended)
Horizontal Adjustment
Thehorizontalpositioncanbeadjusted by removing the4 Mounting
Bolts(B) (2 each side) with a 9/16” socket andsliding the Mounting
Plate (P) toone ofthe 3availablepositions. Themachine is shipped
from the factory in position 1.
PB
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM17

18
Solution Tank Drain Hose / Level Indicator
The solution tank may be drained by removing the Solution Tank Drain
Hose (A) from the Hose Barb (B) and routing the hose to a floor drain.
AB
The SolutionTank Drain Hose also serves as a water level indicator for
the solution tank. The amount of water remaining in the solution tank
can be seen through the clear drain hose. Level markers molded into
the solution tank are positioned at 1/4, 1/2, 3/4, and full levels.
Solution Tank Drain Hose
Solution Level Indicator
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM18

19
The Solution Fill Filter (B) should be cleaned regularly.
To remove, simply open the Solution Tank Lid (A) and
pull the filter out.
Solution Fill Filter A
B
Solution Fill Filter
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM19

20
Brush Load / Unload
To load the brush, first center the
E17/E20 brush deck over the scrub
brush.
Lower the scrub deck by releasing
the deck lift pedal. With the key turned on, pull the bail
handle to spin the scrub brush onto
the scrubdeck.
Loading Brush
988720UM - ES 1720 User Manual - REV STAR 0707.pmd 7/19/2007, 4:20 PM20
