Minuteman MC832085 User manual

Pic-A-Vac Model: MC832085
MC833085
MC832105
MC833105
MC832130
MC833130
Revised 7/02
OPERATION SERVICE PARTS CARE

1
FOR COMMERCIAL USE ONLY
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING
WARNING - To reduce the risk of fire, electric shock, or injury:
•Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
•To avoid electrical shock, do not expose to rain, store indoors.
WARNING:
•To reduce the risk of electrical shock - Do not use on wet surfaces. Do not expose to rain. Store
indoors.
•Do not allow to be used as a toy. Close attention is necessary when used by or near children.
•Use only as described in this manual. Use only manufacturer’s recommended attachments.
•Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return it to a service center.
•Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
•Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
•Do not handle plug or appliance with wet hands.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce airflow.
•Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
•Do not use without dust bag and/or filters in place.
•Turn off all controls before unplugging.
•Use extra care when cleaning on stairs.
•Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where
they may be present.
•Connect to a properly grounded outlet only. See grounding instructions.
SAVE THESE INSTRUCTIONS

2
INSPECTION
Carefully unpack and inspect your machine for shipping damage. Each unit is tested and thoroughly
inspected before shipment, and any damage is the responsibility of the delivery carrier who should
be notified immediately.
ELECTRICAL - 115 Volt
This machine is designed to operate on a standard 15 amp. 115 volt, 60 hz, AC circuit. Voltages
below 105 volts AC or above 125 volts AC could cause serious damage to the motor.
ELECTRICAL - 240 Volt
This machine is designed to operate on a standard 10 amp. 230 volt, 50 hz, AC circuit.
WARNING
Electric motors can cause explosions when operated near explosive materials or vapors. Do not
operate this machine near flammable materials such as solvents, thinners, fuels, grain dust, etc.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path
of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped
with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the appliance — if it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
This machine is for use on a nominal 120 volt circuit and has a grounding plug that looks like the plug
illustrated in Sketch A. Make sure that the machine is connected to an outlet having the same
configuration as the plug. No adapter should be used with this appliance.

3
WARNING
This vacuum may contain potentially hazardous dust depending on its appilcation. Special handling
of contaminated disposal bags and filters is recommended. Disposal must be in compliance with
local EPA regulations
USER MAINTENANCE INSTRUCTIONS
All service and repair should be performed by qualified vacuum service representative or electri-
cian. No user serviceable components are employed in the electrical vacuum lid head assembly. No
lubrication of the motor is required.
CLOTH BAG & HOSE ASSEMBLY
Cloth bag and hose assembly are user maintenance items and can be replaced when worn out. For
optimum performance, empty and clean filter bag regularly. A clogged and dirty bag restricts the flow
of air and results in reduced vacuum. The hose assembly can be maintained by wiping off with a
dampened cloth of mild liquid soap and water, then allowed to dry.
CORD STORAGE
While not in use storage can be accomplished by winding cord around motor lid assembly. Cord
should be completely unwound from lid assembly during operation.
•Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return to service center.
•Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
•Do not unplug by pulling cord. To unplug, grasp the plug, not the cord.
•Do not handle plug or appliance with wet hands.
•Always unplug the machine when removing the motor head off the tank. This equipment should be
stored indoors and not exposed to rain.
•Always unplug the machine when removing the motor head off the tank. This equipment should be
stored indoors and not exposed to rain.

4
HEAD AND TANK ASSEMBLY INSTRUCTIONS
Install float and float cage to the head assembly. When installing float, make sure the weighted bolt in the
float faces away from the vacuum head. The float cage snaps on the head assembly and is then secured
using 1/4-20 bolt, washer, and nut provided in the hardware package.
Handle Installation - 16 Gallon Tank Only
Install handle struts to the tank with snap button facing in towards the tank. The screws provided will pass
through struts and screw into the tank’s threaded holes. The washers and nuts, also provided, are fas-
tened on the inside of the tank. When both struts are attached, handle will slide over struts. Make certain
snap buttons lock into holes located on handle.
TO MAKE VACUUM READY FOR USE, FOLLOW THESE STEPS:
1. Set filter bag assembly in tank.
2. Set head on top of assembly installed in Step 1 and clamp onto tank with clamps attached
to tank. Make sure head is positioned and centered correctly on tank.
3. Attach hose to intake connector on front of tank.
4. Check drain plug to make sure it is securely in place. To make plug larger in diameter, turn
lever on it clockwise: to make it smaller, turn lever in opposite direction.
5. Attach vacuum cleaner attachment to loose end of hose.
6. Plug cord into electrical outlet of correct voltage. Push switch to “On” position when ready
to commence work.

5

6
Parts List
Item Part # Qty Description
1 827743 1 Handle
2 831480 1 Motor Cap
3 831518 1 Cove, Motor
4 831492 1 Shroud, Motor
5 831482 1 Pan, Motor
6 809754 1 Switch, Motor
6A 809755 1 Switch
7 450088 1 Spacer, Switch
8 381020 1 Gray Cord Set 16-3 50'
9 833237 1 Strain Relief
10 712810 2 SCR-MC 10-24 x .37 STPL
11 711553 2 WSR-Internal Lock #10
12 712638 3 Nut-Hex 10-24 SS Nyloc
13 712823 3 SCR-THMS 10-24 x 1.00 STPL
14 711126 6 SCR-ST-B 10 x .75 STPL
15 715105 1 Decal, P/V 105
15A 715085 1 Decal, P/V 85
15B 715130 1 Decal, P/V 130
16 828817 1 Decal, Warning Label
17 831478 1 Gasket, Neop 6 x 7.5 x .37
18 740116 1 Ground Wire
19 831484 1 Gasket, 3.5 x 4.5 x .31
20 380001 1 Vac Motor, Bypass 115V-85
20A 380054 1 Vac Motor, Bypass 240V-85
21 380028 2 Brush, Carbon - 85
22 255039 1 Vac Motor, Bypass 115V-105
22A 255040 1 Vac Motor, Bypass 240V-105
23 255008 2 Brush, Carbon - 105
24 831524 1 Vac Motor, 3 Stage 115V-130
24A 831526 1 Vac Motor, 3 Stage 240V-130
25 711124 1 SCR-ST-B 10 x .37
26 828995 2 Gasket, Neop 2.5 x 6 x .62
27 831626 1 Gasket 4 x 7.37 x .250
28 831576 1 Decal Warning Check Screen
29 712908 3 Nut-Flanged Wizz 10-24
30 831652 3 Spacer
31 833794 1 Gasket Seal 11.16 x 13.16
32 807051 1 Screen Filter SS 85/105
32A 832317 1 Screen Filter SS 130
33 831801 1 Receptacle
34 831801-1 1 Receptacle Clip
35 711505 2 WSR-Flat 1/4
36 711803 1 Cotter Pin

7

8
Parts List
Item Part # Qty Description
1 390035 2 Latch
2 390087 1 Gasket Diecut
3 390110 1 Intake Assy Aluminum
4 711713 2 Retaining Ring-E Ext .50
5 711524 2 WSR-Wave .52 x .87 x .01
6 712569 2 SCR-MC 1/4-20 x 1.50 SS
7 No Longer Used
8 711591 2 WSR-Rubber
9
10 Included in Item 25
11 712532 2 SCR-MC 10-24 x 1.00 SS
12 712819 1 SCR-MC 10-24 x .75 NIPL
13 712569 1 SCR-MC 1/4-20 x 1.50 SS
14 712638 3 Nut-Hex 10-24 SS Nyloc
15 711425 2 Nut-Flanged Wizz 1/4-20
16 711274 3 WSR SS #10
17 715382 1 Decal “Minuteman”
18 800317 1 Hose Assy 1.5 x 10 (16 Gal)
19 900008 2 Wheel, 8.00 Dia
20 804457 2 Caster 3”
21 833316 1 Drain Plug
22 828894 4 Pop Rivet
23 829837 1 Axle
24 833945 1 Tank w/Sockets, 5 Gal
24A 833950 1 Tank w/Sockets, 10 Gal
24B 833956 1 Tank w/Sockets, 16 Gal
25 830987 1 Float Assy
26 833454 1 Float Cage
27 833795 1 Filter Bag Assy
28 833831 2 Clamp Back Plate
29 900035 1 Deflector, Intake
30 710399 4 SCR-MC 3/8-16 x 1.00 STPL
31 711439 4 Nut-Flanged Wizz 3/8-16
32 No Longer Used
33 831121 2 Handle Support
34 831614 1 Handle
35 831629 2 Snap Button
*** 832005 xxx 5 Gal Tank Assy Complete
*** 832010 xxx 10 Gal Tank Assy Complete
*** 832016 xxx 16 Gal Tank Assy Complete

9
Parts List
Item Part # Qty Description
1 830626 1 Filter Ring
2 830634 1 Gasket
3 833797 1 Wet/Dry Filter Bag
833795 xx Wet/Dry Filter Bag Assy
833785 xx Wet Filter Bag Assy
700042 xx Paper Filter Bag 6/Pkg
833798 xx Wet Filter Bag Only
