Stainless steel riser rail
QIntended use
Suitable for use with all pressure-resistant hot water
systems such as central heating, continuous-flow
water heater, pressure boiler etc. It is not suitable
for low-pressure water heaters such as wood-fired
or coal-fired hot-water heaters, oil-fired or gas-fired
heaters, open electrical storage heaters. If in doubt,
please consult a plumber or specialist. The product
is intended for personal use only and not for medi-
cal or commercial use.The manufacturer does not
accept any liability for any damage caused by
improper use.
QDescription of parts
1Hand shower
2Gaskets
3Shower hose
4Water-saving insert
5Upper wall bracket
6Lower wall bracket
7Screws (approx. ø4.8 x 73 mm)
8Covering caps
9Shower rod
10 Hand shower holder
11 Dowels (approx. ø8 mm)
12 Soap dish
13 Covering cap
14 Spray plate
15 Hand shower lever
16 Adjustment Knob
QTechnical data
Hand shower: approx. 30 x 15 cm (H x ø),
5 adjustable positions
Shower rod: approx. 70 cm, metal
Shower hose: approx. 150 cm, metal,
G1/2" (approx. 21 mm)
standard connection
Safety advice
Avoid the risk of injury!
CAUTION! DANGER OF INJURY! Please
ensure that no parts are damaged and that all
parts are correctly assembled. Incorrect assem-
bly or fitting may lead to injury. Damaged parts
can adversely affect safety and proper function.
CAUTION! RISK OF SCALDING! When
making the hot water setting please ensure that
the temperature of the water is not too high.
JThe shower rod 9should not be used to
attach or support anything, as the fixings and
the rod 9are designed to support only their
own weight.
CAUTION! RISK OF SCALDING! Adjusting
the hand shower 1may change the tempera-
ture of the water coming out. Check the water
temperature before stepping into the shower.
Avoid damage to property!
JAssembly should only be carried out by an
experienced person!
JBefore wall mounting, check that the wall can
take the weight of the shower rod set. If in doubt,
ask in a specialist shop.
JCAUTION! WATER DAMAGE! Before drill-
ing, ensure that there are no water pipes where
you intend to drill.
JEnsure that all gaskets 2are correctly seated.
JPlease note that gaskets 2are wear parts
and therefore will require to be replaced from
time to time.
JExamine the wall before installation and
choose suitable installation fixings. We have
supplied fixings suitable for an ordinary solid
masonry wall.
96297 GB.indd 3 11/29/2013 4:42:02 PM

4 GB/IE
QMounting
Tip: For fittings with 26.4mm (3/4”) connection,
use an adaptor with 26.4mm (3/4”) inner thread
and 21mm (1/2”) outer thread, available in DIY
store or bathroom shops.
Tip: A water-saving insert 4is included in your
shower rod set.
QOperation
QHow to adjust the hand shower
jAdjust the height of the hand shower holder 10
by using the adjustment knob 16 .
jAdjust the angle at which the hand shower 1
is tilted by using the hand shower holder 10 .
QShower functions
jTurn the hand shower lever 15 to set the hand
shower 1function you wish to have (see Fig. E).
The hand shower 1has the following
functions:
Massage
Spray + Massage
Spray
Spray + Bubbling
Bubbling
QWater-saving insert
The water-saving insert 4reduces the flow of water.
This may have an effect on how your continuous-flow
water heater works. If the flow of water is too low,
your continuous-flow water heater will automatically
switch off.
QCleaning and care
jClean the product with a soft, damp cloth and
use a mild cleaning agent if necessary.
jRemove the limescale on the shower rod set
by using a commercially available limescale
remover. Please follow the directions for using
your cleaning agent.
QDisposal
The packaging is made entirely of
recyclable materials, which you may dis-
pose of at local recycling facilities.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.
96297 GB.indd 4 11/29/2013 4:42:03 PM

5GB/IE
Warranty
The device has been manufactured to strict quality
guidelines and meticulously examined before
delivery. In the event of product defects you have
legal rights against the retailer of this product. Your
legal rights are not limited in any way by our
warranty detailed below.
The warranty for this device is 3 years from the
date of purchase. Should this device show any fault
in materials or manufacture within three years from
the date of purchase, we will repair or replace it -
at our choice - free of charge to you.
The warranty period begins on the date of
purchase. Please keep the original sales receipt in
a safe location. This document is required as your
proof of purchase. This warranty becomes void if
the device has been damaged or improperly used
or maintained.
The warranty applies to faults in material or
manufacture. This warranty does not cover product
parts subject to normal wear, thus possibly
considered consumables (e.g. batteries) or for
damage to fragile parts, e.g. switches,
rechargeable batteries or glass parts.
96297 GB.indd 5 11/29/2013 4:42:03 PM

6
You need:
1
1 x
5
1 x 6 1 x 7 2 x 8 2 x 9 1 x
13
1 x
12
1 x
11
2 x
10
1 x
2
2 x 3 1 x 4 1 x
1
ø 8 mm
96297 GB.indd 6 11/29/2013 4:42:04 PM

7
8
5 6
16
13
11
87
611 7 8
9
12
9
10
3
1
5
A
B
96297 GB.indd 7 11/29/2013 4:42:05 PM

8
2
1
2
3
1
3
11
14
C
E
5 7 8
D1
D2
4
2
15
96297 GB.indd 8 11/29/2013 4:42:06 PM
