Mira L14A User manual

Introduction
Thank you for purchasing a quality Mira product. To
enjoy the full potential of your new product, please
take time to read this guide thoroughly, having
done so, keep it handy for future reference.
Mira shower fittings are designed to give a
satisfactory shower over a range of pressures.
These ttings are suitable for pressures between
0.1 and 5.0 bar.
General
1. Make sure that the shower ttings are installed
by a competent installer.
2. InstallationsmustcomplywithWaterRegulations
(Bye-Laws, Scotland), and any other Local
Regulations and Building Regulations in force
at the time of installation.
3. Before installation carefully inspect the new
xture for any signs of damage.
4. The shower ttings should be positioned at a
convenient height for all the family. Position
the ttings to spray across rather then towards
the opening of the cubicle and also away from
the shower control. Avoid layouts where the
shower hose will be sharply kinked. This may
reduce the life of the hose.
5. A hose retaining ring is supplied to prevent
the handset from dropping below the spill
over level of the bath or shower, which could
lead to contamination from backsiphonage.
The supplied hose retaining ring should meet
the great majority of user requirements for
shower installations with exible outlet ttings.
However, there will be occasions when the
hose retaining ring will not provide a suitable
solution. In these instances an outlet double
check valve, e.g. the Mira DCV-H, must be
tted. The inclusion of the Mira DCV-H will
increase the required supply pressure typically
by 0.1 bar.
6. Do not t any form of ow control in the outlet
pipe work if the shower ttings are installed
in conjunction with a product that requires
the ttings to act as a vent (e.g. an electric
shower).
7. Special consideration should be given to the
xing arrangements when installing onto a
dry lined, stud partition, shower cubicle or
laminated panel wall structures. Installers may
wish to obtain alternative proprietary cavity
xings, or choose other options, however,
these methods of xing are beyond the scope
of this guide.
Cleaning
Many household cleaners contain abrasives and
chemical substances, and should not be used for
cleaning plated or plastic ttings.
These nishes should be cleaned with a mild
washing up detergent or soap solution, and then
wiped dry using a soft cloth.
Use your thumb or a soft cloth to wipe any
limescale from the soft nozzles and the front
surface of the handset spray plate.
Spare Parts
Spare part numbers are indicated in bold and are
available from authorised stockists or merchants
(locations on request) or direct from Mira
Customer Services, our contact details can be
found on the back cover of this guide.
MIRA L14A SHOWER FITTINGS
1086264-W2-B © Kohler Mira Limited, November 2007
CUSTOMER SERVICE
Guarantee of Quality
Mira Showers guarantee your shower fi ttings against any
defect in materials or workmanship for a period of one year
from the date of purchase.
Alternatively, to confirm the applicable guarantee period
please contact Customer Services.
To validate the guarantee, please return your completed
registration card.
Within the guarantee period we will resolve defects, free
of charge, by repairing or replacing parts or modules as
we may choose.
To be free of charge, service work must only be undertaken
by Mira Showers or our approved agents.
Service under this guarantee does not affect the expiry
date.
The guarantee on any exchanged parts or product ends
when the normal product guarantee period expires.
Not covered by this guarantee:
Damage or defects arising from incorrect installation,
improper use or lack of maintenance, including build-up
of limescale.
Damage or defects if the product is taken apart, repaired or
modified by any persons not authorised by Mira Showers
or our approved agents.
This guarantee is in addition to your statutory and other
legal rights.
What to do if something goes wrong
If when you first use your shower, it doesn’t function
correctly, first contact your installer to check that installation
and commissioning are satisfactory and in accordance with
the instructions in this manual. We are on hand to offer you
or your installer any advice you may need.
Should this not resolve the diffi culty, simply contact our
Customer Services Team who will give every assistance
and, if necessary, arrange for our service engineer to
visit. If the performance of your shower declines, consult
this manual to see whether simple home maintenance is
required. Please call our Customer Services Team to talk
the diffi culty through, request a service under guarantee
if applicable, or take advantage of our comprehensive
After-Sales service.
As part of our quality and training programme calls may be
recorded or monitored.
Our Customer Services Team is comprehensively trained to
provide every assistance you may need: help and advice,
spare parts or a service visit.
Spare Parts
We maintain an extensive stock of spares and aim to provide
support throughout the product’s expected life.
Spares can be purchased from approved stockists or
merchants (locations on request) or direct from Customer
Services.
Spares direct will normally be despatched within two working
days. Payment can be made by Visa or MasterCard at the
time of ordering. Should payment by cheque be preferred,
a pro-forma invoice will be sent.
All spares are guaranteed for 12 months from date of
purchase. Spares that have been supplied directly from us
can be returned within one month from date of purchase,
providing that they are in good order and the packaging
is unopened.
Note! Returned spares will be subject to a 15% restocking
charge and authorisation must be obtained before return.
Please contact our Customer Services Team.
Note! In the interests of safety, spares requiring exposure
to mains voltages can only be sent to competent persons.
Service
Our Service Force is available to provide a quality service
at a reasonable cost. You will have the assurance of a Mira
trained engineer/agent, genuine Mira spare parts and a
12 month guarantee on the repair.
Payment should be made directly to the engineer/agent
using Visa, MasterCard or a cheque supported by a
banker’s card.
To Contact Us
England, Scotland, Wales and Northern Ireland
Mira Showers Customer Services
Telephone: 0870 241 0888, Mon to Fri 8:00 am - 5:30 pm
Sat 8:30 am - 3:30 pm
E-mail: [email protected]
Fax: 01242 282595
By Post: Cromwell Road, Cheltenham,
Gloucestershire, GL52 5EP
Eire
Modern Plant Ltd (Dublin)
Telephone: 01 459 1344, Mon to Fri 9:00 am - 5:00 pm
E-mail: [email protected]
Fax: Dublin 01 459 2329
Post: Otter House, Naas Road,
Clondalkin, Dublin 22
Modern Plant (Cork)
Telephone: 021 496 8755, Mon to Fri 9:00 am - 5:00 pm
E-mail: [email protected]
Fax: 021 496 8607
Post: Tramore Road, Cork
Mira is a registered trade mark of
Kohler Mira Limited.
The company reserves the right to alter
product specifications without notice.
www.mirashowers.com
5
+
!
3
Assemble the slide bar, slide bar supports and backplates and measure the distance between the wall xing hole centres.
Important! Make sure that the cut outs in the slide bar are located correctly. Note! Slots in the backplates allow for a small
amount of horizontal or vertical adjustment. Mark the wall xing hole positions and drill 2 holes to suit the wall xings.
1663.190 (Single Mode - Chrome)
1663.191 (Single Mode - White)
1663.192 (Multi Mode - Chrome)
1663.193 (Multi Mode - White)
Shower Handset
1603.104 (Metal)
1603.137 (Plastic)
Shower Hose (1.25 m)
1642.006 (Chrome)
1663.121 (White)
Clamp Bracket
1642.008
Hose Retaining Ring
(some models)
1663.120 (White)
1663.122 (Chrome)
Slide Bar Support & Backplate (x2)
(includes grubscrews)
1663.123
Screw Pack (x2)
632.73
Hose Seal
Wall Fixing
Hole
Wall Fixing
Hole
1663.119
Soap Dish (some models)
3 mm Hexagonal Key
1663.124 (Long)
1663.129 (Short - Power Showers Only)
Slide Bar
MIRA L14A SHOWER FITTINGS
Important! Make sure that the cut outs
in the slide bar are located correctly.
