Mission Critical Xantrex Freedom X 1800 User manual

Freedom X 1800 (12VDC) Inverter
Owner’s Guide
Freedom X 1800 (12VDC)
817-1800-02

ii Freedom X 1800 (12VDC) Owner's Guide
Copyright © 2023 Xantrex LLC. All Rights Reserved.
All trademarks are owned by Xantrex LLC and its affiliates.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER
(A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS
MANUALS OR OTHER DOCUMENTATION;
(B) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT,
CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE
ENTIRELY AT THE USER’S RISK; AND
(C) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE
ACCURACY OF THE TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED CONTENT IS CONTAINED WITH THE ENGLISH
LANGUAGE VERSION WHICH IS POSTED AT http://www.xantrex.com/.
NOTE: Visit http://www.xantrex.com/ , click Products, select a Product category, select a Product, and search the Product
Documents panel for a translation of the English guide, if available.
Document Number:975-1169-01-01 Rev A Date: July 2023
Product Name and Part Number
Freedom X 1800 (12VDC) (817-1800-02)
Contact Information
Telephone: (Toll Free USA/Canada) [phone] / (Outside USA/Canada) [phone]
Email: [e-mail],
https://xantrex.com/support/get-customer-support/
Web: http://www.xantrex.com/

975-1169-01-01 iii
Information About Your System
As soon as you open your product, record the following information and be sure to keep your proof of purchase.
Serial Number ____________________________
Product Number ____________________________
Purchased From ____________________________
Purchase Date ____________________________
To view, download, or print the latest revision, visit the website shown under Contact Information.

iv Freedom X 1800 (12VDC) Owner's Guide
Purpose
The purpose of this Owner’s Guide is to provide explanations and
procedures for installing, operating, configuring, maintaining, and
troubleshooting a Freedom X 1800 (12VDC) Inverter for
Commercial and Fleet Vehicle.
Scope
The guide provides safety and operating guidelines as well as
information on installing and configuring the inverter. It also
provides information about troubleshooting the unit. It does not
provide details about particular brands of batteries. You need to
consult individual battery manufacturers for this information.
Audience
The guide is intended for users and operators of the Freedom X
1800 (12VDC) Inverter.The Installation section starting on page
13 is intended for qualified personnel.
Qualified personnel have training, knowledge, and experience in:
lInstalling electrical equipment.
lApplying all applicable installation codes.
lAnalyzing and reducing the hazards involved in performing
electrical work.
lSelecting and using Personal Protective Equipment (PPE).
Abbreviations and Acronyms
A Amperes
AC Alternating Current[V]
ACC Accessory in vehicle ignition system
AGM Absorbed Glass Mat (a battery type)
BTS Battery Temperature Sensor
DC Direct Current[Z]
GFCI Ground Fault Circuit Interrupter
in-lb inch-pound force (a unit of torque)
kW Kilowatts (1000 watts)
LBCO Low Battery Cutout (or Cutoff)
LCD Liquid Crystal Display
LED Light Emitting Diode
LFP LiFePO4(lithium iron phosphate – a battery type)
LIN Vehicle Local Interconnect Network Bus
Communications protocol
N-m Newton-meters (a unit of torque)
PN Product Number
PPE Personal Protective Equipment
PV Photovoltaic (Solar)
V, VAC,
VDC Voltage, Volts AC, Volts DC
W Wattage
Related Information
You can find more information about Xantrex products and
services at http://www.xantrex.com/.

975-1169-01-01 v
IMPORTANT SAFETY
INSTRUCTIONS
READ AND SAVE THIS OWNER’SGUIDE FOR FUTURE
REFERENCE.
This guide contains important safety instructions for the Freedom
X that must be followed during installation, operation,
maintenance, and troubleshooting.
Read these instructions carefully and look at the equipment to
become familiar with the device before installing, operating,
configuring, maintaining, and troubleshooting it. The following
special messages may appear throughout this documentation or
on the equipment to warn of potential hazards or to call attention to
information that clarifies or simplifies a procedure.
The addition of either symbol to a “Danger” or
“Warning” safety label indicates that an electrical
hazard exists which will result in personal injury if the
instructions are not followed.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
IMPORTANT:These notes describe things which are important for you to know,
however, they are not as serious as a caution or warning.
Please Note: No responsibility is assumed by Xantrex for any consequences
arising out of the use of this material.

Product Safety Information
vi Freedom X 1800 (12VDC) Owner's Guide
Product Safety Information
1. Before using the inverter, read all instructions and cautionary
markings on the unit, the batteries, and all appropriate
sections of this guide.
2. Use of accessories not recommended or sold by the
manufacturer may result in a risk of fire, electric shock, or
injury to persons.
3. The inverter is designed to be connected to both DC and AC
electrical systems. The manufacturer recommends that all
wiring be done by a certified technician or electrician to
ensure adherence to the local and national electrical codes
applicable in your jurisdiction.
4. To avoid a risk of fire and electric shock, make sure that
existing wiring is in good condition and that wire is not
undersized. Do not operate the inverter with damaged or
substandard wiring.
5. Do not operate the inverter if it has been damaged in any
way.
6. This unit does not have any user-serviceable parts. Do not
disassemble the inverter except where noted for connecting
wiring and cabling. See your warranty for instructions on
obtaining service. Attempting to service the unit yourself
may result in a risk of electrical shock or fire. Internal
capacitors remain charged after all power is disconnected.
7. To reduce the risk of electrical shock, disconnect both AC
and DC power from the inverter before attempting any
maintenance or cleaning or working on any components
connected to the inverter. Do not disconnect under load.
Turning the inverter to Standby mode using the Power button
on the front panel will not reduce an electrical shock hazard.
8. The inverter must be provided with an equipment-grounding
conductor connected to the AC input ground.
9. Do not expose this unit to rain, snow, or liquids of any type.
This product is designed for dry-locations-use only. Damp
environments will significantly shorten the life of this product
and corrosion caused by dampness will not be covered by
the product warranty.
10. To reduce the chance of short-circuits, always use insulated
tools when installing or working with this equipment.
11. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with electrical
equipment.
DANGER
ELECTRICAL SHOCK AND FIRE HAZARD
Installation must be done by qualified personnel to ensure
compliance with all applicable installation and electrical codes and
regulations. Instructions for installing the Freedom X 1800 (12VDC)
Inverter are provided here for use by qualified personnel only.
Failure to follow these instructions will result in death or serious
injury.

Product Safety Information
975-1169-01-01 vii
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC
FLASH
nApply appropriate personal protective equipment (PPE) and follow safe
electrical work practices. See NFPA 70E or CSA Z462.
nThis equipment must only be installed and serviced by qualified electrical
personnel.
nTurn off all power supplying this equipment before working on or inside
equipment.
nAlways use a properly rated voltage sensing device to confirm power is
off.
nReplace all devices, doors, and covers before turning on power to this
equipment.
nBatteries can present a risk of electric shock, high short-circuit current
and exposure to gases and chemicals.
nThe following precautions must be observed when working with
batteries:
nRemove watches, rings or other metal objects.
nKeep sparks and flames away from batteries.
nUse tools with insulated handles.
nDo not lay tools or other metal parts on top of batteries.
nServicing of batteries must only be performed by qualified personnel
knowledgeable of batteries and the required precautions. Keep
unqualified personnel away from batteries.
nDisconnect the charging source prior to connecting or disconnecting
battery terminals.
nNever attempt to charge a frozen battery.
Failure to follow these instructions will result in death or serious
injury.
WARNING
FIRE AND EXPLOSION HAZARD
nUnit’s components may produce arcs or sparks.
nDo not install near batteries, in machinery space, or in an
area in which ignition-protected equipment is required. For
indoor use only.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.
Areas include any space containing gasoline-powered machinery,
fuel tanks, as well as joints, fittings, or other connections between
components of the fuel system.
WARNING
ELECTRICAL SHOCK HAZARD
nReplace the wiring compartment cover before turning on
power to this equipment.
nUse a torque screwdriver to tighten the captive nut panel
screw to 5 in-lb (0.56 N-m) torque to ensure a proper
ground connection and a required tool access to the wiring
compartment.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.

Product Safety Information
viii Freedom X 1800 (12VDC) Owner's Guide
CAUTION
ELECTRICAL SHOCK AND FIRE HAZARD
nDo not open. No serviceable parts inside. Provided with
integral protection against overloads. Bonding between
conduit connections is not automatic and must be
provided as part of the installation.
nRead guide before installing or using.
nDo not cover or obstruct ventilation openings.
nDo not mount in zero-clearance compartment –
overheating may result.
nDo not expose to rain or spray. Indoor use only.
nDo not connect AC OUT to any other source of power.
Damage to unit may occur.
nFor AC IN and AC OUT, use wires suitable for at least
90°C.
Failure to follow these instructions can result in injury or
equipment damage.
NOTES:
nFollow these instructions and those published by the
battery manufacturer and the manufacturer of any
equipment you intend to use in the vicinity of the battery.
Review cautionary markings on these products and on the
engine.
nFreedom X 1800 (12VDC) Inverter products are designed
for deep cycle lead-acid batteries. See warning below when
connecting to lithium ion batteries.
nDo not use transformerless battery chargers in conjunction
with the inverter due to overheating.
CAUTION
LITHIUM ION BATTERY TYPE HAZARD
nMake sure to use a lithium ion battery pack that includes a
certified Battery Management System (BMS) with built-in
safety protocols. Follow the instructions published by the
battery manufacturer.
nConnect the inverter to a 12-volt battery or battery system
ONLY.
Failure to follow these instructions can result in serious injury or
equipment damage.

Precautions When Working With Batteries
975-1169-01-01 ix
CAUTION
PHYSICAL INJURY HAZARD
This Freedom X 1800 (12VDC) Inverter is not intended for use by
persons (including children) with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
Failure to follow these instructions can result in injury or
equipment damage.
Precautions When Working With
Batteries
IMPORTANT: Battery work and maintenance must be done by
qualified personnel knowledgeable about batteries to ensure
compliance with battery handling and maintenance safety
precautions.
WARNING
BURN FROM HIGH SHORT-CIRCUIT CURRENT, FIRE
AND EXPLOSION FROM VENTED GASES HAZARDS
lAlways wear proper, non-absorbent gloves, complete eye
protection, and clothing protection. Avoid touching your
eyes and wiping your forehead while working near
batteries. See the following note #4.
lRemove all personal metal items, like rings, bracelets, and
watches when working with batteries. See notes #5 and #6
below.
lNever smoke or allow a spark or flame near the engine or
batteries.
lNever charge a frozen battery.
lNever charge a Lithium Ion type battery with an ambient of
0°C (-32°F) or colder.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.

Precautions When Placing the Unit
x Freedom X 1800 (12VDC) Owner's Guide
NOTES:
1. Mount and place the Freedom X 1800 (12VDC) Inverter unit
away from batteries in a well ventilated compartment.
2. Always have someone within range of your voice or close
enough to come to your aid when you work near a lead-acid
battery.
3. Always have plenty of fresh water and soap nearby in case
battery acid contacts skin, clothing, or eyes.
4. Keep battery terminals clean from corrosion. If battery acid
or corrosion deposit contacts skin or clothing, wash
immediately with soap and water. If battery acid or corrosion
deposit enters your eye, immediately flood it with running
cold water for at least twenty minutes and have someone
within range of your voice or close enough to get medical
attention immediately.
5. Use extra caution to reduce the risk of dropping a metal tool
on the battery. It could spark or short circuit the battery or
other electrical parts and could cause an explosion. Use
tools with insulated handles only.
6. Batteries can produce a short circuit current high enough to
weld a ring or metal bracelet or the like to the battery
terminal, causing a severe burn.
7. When removing a battery, always remove the negative
terminal from the battery first for systems with grounded
negative. If it is grounded positive, remove the positive
terminal first. Make sure all loads connected to the battery
and all accessories are off so you don’t cause an arc.
Precautions When Placing the
Unit
WARNING
FIRE HAZARD
nDo not install the inverter or any part of its supplied wiring in
engine compartments.
nFor marine installation, always locate the inverter away from
the battery and mounted separately in a well-ventilated
compartment with adequate space.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.
CAUTION
BURN HAZARD
Avoid touching the external surfaces - heatsink may be hot.
Failure to follow these instructions can result in injury or
equipment damage.

Regulatory
975-1169-01-01 xi
NOTICE
RISK OF INVERTER DAMAGE
nNever allow battery acid to drip on the inverter when
reading gravity, or filling battery.
nNever place the Freedom X unit directly above batteries;
gases from a battery will corrode and damage the inverter.
nDo not place a battery on top of the inverter.
Failure to follow these instructions can result in equipment
damage.
Regulatory
The Freedom X inverter is certified to appropriate US and
Canadian standards.
The Freedom Xinverter is intended to be used for vehicle and fleet
vehicles. See the section on Specifications for information.
The Freedom X inverter is intended to be used for mobile or
commercial applications. This inverter is designed for marine
applications only when additional drip protection is installed in
certain orientations. See the section on Specifications for
information.
EMI Information to the User
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC/ISEDCAN ICES-003 Class B Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
nReorient or relocate the receiving antenna.
nIncrease the separation between the equipment and
receiver.
nConnect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
nConsult the dealer or an experienced radio/TV technician for
help.
CAUTION
Unauthorized changes or modifications to the equipment could
void the user’s authority to operate the equipment.

End of Life Disposal
xii Freedom X 1800 (12VDC) Owner's Guide
End of Life Disposal
The Freedom X 1800 (12VDC) Inverter is designed with
environmental awareness and sustainability in mind. At the end of
its useful life, the Freedom X can be decommissioned and
disassembled. Components which can be recycled must be
recycled and those that cannot be recycled must be disposed of
according to local, regional, or national environmental regulations.
Many of the electrical components used in the Freedom X 1800
(12VDC) Inverter are made of recyclable material like steel,
copper, aluminum, and other alloys. These materials can be
auctioned off to traditional scrap metal recycling companies who
resell reusable scraps.
Electronic equipment such as the circuit boards, connectors, and
fuses can be broken down and recycled by specialized recycling
companies whose goal is to avoid having these components end
up in the landfill.
For more information on disposal, contact Xantrex.

CONTENTS
Important Safety Instructions v
Product Safety Information vi
Precautions When Working With Batteries ix
Precautions When Placing the Unit x
Regulatory xi
EMI Information to the User xi
End of Life Disposal xii
Introduction 1
Materials List 2
Key Features 2
Features 5
Default Settings 6
AC/DC and GFCI Panel 7
Display Panel 9
Side Panel 10
Installation 11
Before You Begin the Installation 12
Installation Codes 12
Basic Installation Procedures 13
Installation Tools and Materials 13
Step 1: Designing the Installation 14
Step 2: Choosing a Location for the Unit 20
Step 3: Mounting the Unit 21
Step 4: Connecting the AC Input Cables 23
Step 5: Connecting AC Output Cables to an Existing AC
Circuit 27
Step 6: Connecting the DC Cables 30
Step 7: Connecting to Port(s) on the Freedom X 35
Step 8: Testing Your Installation 37
Marine Installation 39
Drip Shield Installation 40
Operation 41
Freedom XDisplay Panel 42
Status LED Indicators 42
Function Buttons 43
975-1169-01-01 xiii

xiv Freedom X 1800 (12VDC) Owner's Guide
LCD Screen 43
LCD Screen Icons 44
Viewing Information During Battery Mode 45
Viewing Information During Grid Mode 47
Adjusting Feature Settings in Configuration Mode 49
Settings 50
Operating in Battery Mode 53
Turning Inverter Operation ON and OFF 53
Power Save Timer 54
Power Save Mode 54
Checking Battery Status 54
Checking Output Power 54
Operating Several Loads at Once 54
Turning the Audible Alarm ON or OFF 55
Operating During Transition Between Grid Mode and Battery
Mode 56
Transitioning from Grid Mode to Battery Mode 56
Transitioning from Battery Mode to Grid Mode 56
Operating Limits 57
Power Output 57
Input Voltage 57
Overload Conditions 58
High Surge Loads 58
Over-temperature Conditions 58
Routine Maintenance 59
Maintaining the Freedom X Unit 60
Troubleshooting 61
Pre-service Checklist 62
Warning Messages 63
Troubleshooting Reference 66
Inverter Applications 70
Resistive Loads 70
Motor Loads 70
Specifications 71
Physical Specifications 72
Environmental Specifications 72
System Specifications 73
Regulatory Approvals 74

975-1169-01-01 1
1 INTRODUCTION
The Freedom X 1800 (12VDC) Inverter is designed with integrated
inverting functions and power management features suitable for
commercial/fleet vehicle installations.
Please read this section to familiarize yourself with the main
performance and protection features of the Freedom X.
This section includes:
Materials List 2
Key Features 2

Materials List
2 Freedom X 1800 (12VDC) Owner's Guide
Materials List
The Freedom X 1800 (12VDC) Inverter base package includes the
following items:
none Freedom X unit
none Product Notice and extra safety labels
none pre-installed DC ground enclosure lug (not shown)
none set of plastic bushings for large DC cables (not shown)
ntwo AC knockout hole plugs (not shown)
Figure 1 What’s In The Box
NOTE: If any of the items are missing, contact Xantrex or any
authorized Xantrex dealer for replacement. See Contact
Information on page ii.
Key Features
Power for Most
Appliances
The Freedom X inverter provides up to
1800watts of continuous utility grade, sine
wave power derived from a battery bank. It is
designed to handle loads such as microwave
ovens, TVs, DVD/Blu-ray players, and power
tools. In addition, the Freedom X’s high-surge
capability lets you handle many hard-to-start
loads, including full size residential
refrigerators.
The built-in transfer switch automatically
transfers between inverter power and shore
power from recreational facilities such as boat
docks or campsites to ensure power is
always available.
Back-up
Capability
If incoming shore power is interrupted by
external events like brownouts, the Freedom
X automatically becomes an independent
power source1that supplies utility grade AC
power to your loads.
1Assuming the inverter is connected to a battery source with an adequate charge at the time of the power
interruption.

Materials List
975-1169-01-01 3
Comprehensive
Protection
The Freedom X’s built-in protection features
safeguard your batteries (from unnecessary
drain) such as the low battery voltage alarm
and shutdown and protect equipment such as
a configurable AC transfer speed.
nSelectable Low Battery Shutdown:
The low battery shutdown for the
inverter can be manually selected by the
user from 10.1 to 12.8VDC.
nVoltage Shutdown Delay Timer:
Configurable from 1 to 300s to reduce
an unnecessary shutdown of inverter
operation such as during cranking or
other brief but heavy discharge of
battery.
nInverter Power Save: The Freedom X
can be programmed to automatically
turn off after 1 to 25 hours of continued
operation of loads that are under 50
watts. It is designed, with LBCO (low
battery cut off), to prevent the battery
from deep discharge.
Configurable AC
Transfer Speed
The Freedom X allows two speed settings for
the AC transfer from AC Mode to Battery
Mode and vice versa which avoids nuisance
resetting of appliances. The normal transfer
rate is for common appliances and the faster
transfer rate is designed for more sensitive
digital equipment like a desktop computer.
Overload Alarm
and Shutdown
During Battery Mode (also called Inverter
Mode), the Freedom X automatically alerts
you if the loads that are connected and
drawing power from the unit are close to
approaching the maximum operating limit. If
so, the Freedom X automatically shuts down
when the maximum operating limit is
exceeded. See Troubleshooting Reference on
page 66 for precautions.
Over temperature
Alarm and
Shutdown
During Battery Mode, the Freedom X
automatically alerts you if it is overheating
and approaching the over-temperature
shutdown limit. The Freedom X automatically
shuts down when the limit is exceeded. See
Troubleshooting Reference on page 66 for
precautions.

Materials List
4 Freedom X 1800 (12VDC) Owner's Guide
Ignition Control The Freedom X provides two user-selectable
options for ignition control:
nIgnition Auto-on: The Freedom X can
automatically turn the inverter on and off
in tandem with the vehicle's ignition
circuit or a manually operated remote
switch.
nIgnition Lockout: The Freedom X
features the ability to inhibit the inverter
from operating in the absence of a
voltage signal from a vehicle's ignition
circuit. This is particularly useful if the
inverter is required to operate only when
a vehicle's engine is running.
Configurable AC
Output Frequency
and Voltage
The Freedom X is factory set to 60Hz AC
output frequency and 120V AC output
voltage. It can be configured to 50Hz for use
in regions outside the USA and Canada. The
AC voltage setting can also be configured to
either of three settings: 108, 110, or 120volts.

975-1169-01-01 5
2 FEATURES
This section identifies the default settings and the hardware
features of the Freedom X 1800 (12VDC) Inverter.
This section includes:
Default Settings 6
AC/DC and GFCI Panel 7
Display Panel 9
Side Panel 10

Default Settings
6 Freedom X 1800 (12VDC) Owner's Guide
Default Settings
Table 1 lists the default settings for the Freedom X system.
You may record your settings in the right-hand column after you have configured the Freedom X.
Program Item Default Setting Setting
01 Inverter ignition control Off Off
02 Low battery cutoff (LBCO) voltage 10.5voltsDC 10.5
03 LBCO shutdown delay timer 300seconds 300
04 LBCO recovery voltage 13.1 volts DC 13.1
05 Power save time 25 hours 25
06 Load sensing Disabled dis
07 Inverter output frequency 60Hz 60
08 Inverter output voltage 120 volts AC 120
09 Inverter power limit 1.8 kW 1
10 Inverter power limit timer 1 second 1
11 Transfer mode Appliance APL
12 Utility AC under-voltage level 90 volts AC 90
13 Inverter fault recovery Manual man
14 Audible alarm On On
Table 1Freedom X Default Values
