Mistral MWF40R User manual

MWF40R
40cm with Remote Control
Wall Fan

2
When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or injury, these
basic safety precautions should always be followed:
Important Safeguards
FOR YOUR SAFETY
Read all instructions carefully, even if you are familiar
with the appliance.
• The appliance is not intended for use by children
or infirm persons without supervision.
• Children should be prevented from playing with
the appliance.
• Switch off the power outlet and remove the plug
when the appliance is not in use.
• Do not operate any appliance with a damaged
cord or plug; if the appliance malfunctions; or if
it is dropped or damaged in any manner.
• Do not use outdoors.
• Do not use any appliance for anything other than
its intended use. This product is intended for
household use only.
• This appliance is intended to be plugged in a 240V
power outlet only.
• Do not misuse the cord. Never carry the appliance
by the cord or pull to disconnect it from the outlet.
Instead, grasp the plug and pull to disconnect.
• Do not attempt to repair disassemble or modify
the appliance. There are no userserviceable parts.
• Arrange the power cord away from traffic areas
where it will not be tripped over.
• Do not insert or allow foreign objects to enter
the grille openings as this may cause damage to
the appliance and/or injury to the user.
• Ensure that the fan is switched off from the supply
mains before removing the guard.
COMPULSORY WARNING
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent, or a similarly
qualified person, in order to avoid a hazard.
This product has not been designed for any uses
other than those specified in this booklet.
SAVE THESE INSTRUCTIONS

Features of your Wall Fan
3
Child Proof Safety Grille
Blade
Assembly
(inside)
Wall
Mounting
Bracket
Fixed or
Oscillating
Operation
High Velocity
Turbo Blades
Electronic
Panel

Congratulations on the purchase of your new Wall
Fan by Mistral.
Before fist using your new Wall Fan, it is most
important that you read and follow the instructions
in this use and care booklet, even if you feel you are
familiar with this type of appliance.
Your attention is drawn particularly to the section
dealing with IMPORTANT SAFEGUARDS. Find a safe
and convenient place to keep this booklet handy for
future reference.
This appliance has been designed to operate from a
standard domestic power outlet. It is not intended
for industrial or commercial use.
Your Wall Fan is safe and easy to use. It has been
designed to function quietly and safely under normal
circumstances.
Its energy efficient blades circulate cool air while
using less power than a standard light globe. The
heavy-duty motor is rated for continuous use to
combat long hot summers.
4
Your Wall Fan has been boxed unassembled to
minimise packaging waste. Each part is designed to
fit together and be disassembled easily for cleaning
or storage.
Note: Ensure the Wall Fan is disconnected from
the power outlet before commencing assembly.
Getting to know your
Wall Fan
Assembly of your Wall Fan
Orientation Pin 9
Motor Shaft 10
Fanhead 11
Connector 12
Rear Guard8
Install Hole7
Rear Guard
Securing Nut
6
Blade5
Securing Nut4
Fixed Clip3
Front Guard2
Guard Clip1
Install Plate 13
Fixing Screw 14
Hung Hook 15
Powercord 16
Base 17
Stanchion 18

5
Mount the install plate (13) on the wall with three
fixing screws (14) provided (Fig 1).
Hang the motor and base (17) with the hang hook
(15) onto the hanging bracket (Fig 2).
Remove the plastic shaft protector from the motor
shaft (10) .
Loosen the rear guard securing ring (6) from the
motor & housing assembly.
position the rear guard (8) firmly to the motor &
housing assembly and fasten by turning the rear
guard securing ring (6) clockwise tightly.
Push the fan blade (5) along the motor shaft. Fasten
securely using the fan blade securing nut (4) with the
spinner by turning anticlockwise.
Attach the front guard (2).
Always disconnect electrical appliances before
cleaning them.
Wipe them clean with a slightly damp sponge.
Clean the motor housing and body assembly with a
clean, damp cloth and wipe dry.
Never spray the Wall Fan with liquids or submerge
it in water or any other liquid.
Note: If the cordset of this appliance becomes
damaged, discontinue use. Repairs should be
undertaken only by a qualified electrician.
Care and Cleaning
MWF40R
3 Speed, 40cm Wall Fan.
For indoor use only.
230-240V a.c., 50Hz, 55 Watt
Approval No. S/10
Specifications
Operation of Your Wall Fan
Add-up-type timer measure time by the 0.5 hour, the
longest time is 7.5 hours. If you touch the timer once.
That means the fan will run for 0.5 hous, if you touch
the timer twice, that means it will run for 1 hour.
when the time indicator lamp is a light at the 0.5h,
2H, and 4H, that means the fan will run for 0.5 + 2 +
4 = 6.5 hours. You can enjoy the three different, sleep,
rhythmical, and normal wind types. You could choose
the low, medium or high wind speeds for each wind
type.
You remove the cover from the back of the remote
control, and insert the two batteries, aim it at
switchboard when operating.
Wall
Fig 1 Fig 2

6
Notes

7
Notes

8
DO NOT SEND IN THIS WARRANTY
Fill out the following details and file with your purchase
invoice.
RETAIN & FILE WITH YOUR RECEIPT.
Your Purchase Receipt/Invoice is proof of date of
purchase. You must be able to present it at the place
of purchase to obtain a replacement or service under
warranty.
Linda Australia Pty Ltd reserves the right to
discontinue items, modify designs and change
specifications without incurring obligation. Whilst
every effort is made to ensure that descriptions,
specifications and other information in this publication
is correct, no warranty is given in
respect thereof and the company shall not be liable
for any errors therein.
Purchased from:
Co. Name:
Address:
Date of Purchase:
NOTE: Consistent with our continuing product
development policy, improvements may have been
made which render the contents of this package
slightly different to that shown.
Cat. No. MWF40R
July 2004
Warranty
The benefits conferred by this warranty are in addition
to all implied warranties, other rights and remedies
in respect of the product which the consumer has
under the Trade Practices Act and similar State and
Territory Laws.
The original purchaser of this Mistral product is
provided with the following warranty subject to the
following conditions.
Linda Australia Pty Ltd warrant this product for a
period of 2 years from the date of purchase for all
parts defective in workmanship or materials.
This product or defective parts will be replaced free
of charge.
WARRANTY CONDITIONS
1. This warranty is only valid for appliances used
according to the manufacturer's instructions.
2. This appliance must not be modified or changed
in any way.
3. Connection must be to the voltage requirements
as specified in the ratings label located on the
product.
4. The manufacturer does not accept liability for any
direct or consequential damage, loss or other
expense arising from misuse or incorrect
installation and operation of the appliance.
5. Warranty will only be given where proof of
purchase is provided, e.g. original invoice.
6. Not designed or warranted for industrial or
commercial use.
Product of Linda Australia Pty Ltd ABN 60 079 923 130
A member of the Mistral International Pty Ltd group of companies
324 Frankston-Dandenong Road
Dandenong South, Victoria, Australia 3175
RINGGRIP (NZ) Pty Ltd ACN 006 771 922
PO Box 33672, Takapuna, Auckland NZ
Manufactured for Linda Australia
©2004 Linda Australia Pty Ltd
