Mitsubishi Electric PCA-RP KAQ User manual

Air-Conditioners

PCA-RP•KAQ
English
Deutsch
Français
Nederlands
Español
Italiano
Português
Dansk
Svenska
INSTALLATION MANUAL
For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing
the air-conditioner unit.
INSTALLATIONSHANDBUCH
Aus Sicherheitsgründen und zur richtigen Anwendung vor Installation der Klimaanlage die vorliegende Bedie-
nungsanleitung und das Installationshandbuch gründlich durchlesen.
MANUEL D’INSTALLATION
Avant d’installer le climatiseur, lire attentivement ce manuel, ainsi que le manuel d’installation de l’appareil exté-
rieur pour une utilisation sûre et correct.
INSTALLATIONSMANUAL
Läs bruksanvisningen och utomhusenhetens installationshandbok noga innan luftkonditioneringen installeras så
att den används på ett säkert och korrekt sätt.
INSTALLATIEHANDLEIDING
Lees deze handleiding en de installatiehandleiding van het buitenapparaat zorgvuldig door voordat u met het
installeren van de airconditioner begint.
MANUALE DI INSTALLAZIONE
Per un uso sicuro e corretto, prima di installare il condizionatore d’aria leggere attentamente il presente manuale
ed il manuale d’installazione dell’unità esterna.
MANUAL DE INSTALACIÓN
Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de
aire acondicionado.
MANUAL DE INSTALAÇÃO
Para uma utilização segura e correcta, leia atentamente este manual e o manual de instalação da unidade exte-
rior antes de instalar o aparelho de ar condicionado.
INSTALLATIONSMANUAL
Læs af sikkerhedshensyn denne manual samt manualen til installation af udendørsenheden grundigt, før du
installerer klimaanlægget.
FOR INSTALLER
FÜR INSTALLATEURE
TIL INSTALLATØREN
PARA O INSTALADOR
PARA EL INSTALADOR
PER L’INSTALLATORE
VOOR DE INSTALLATEUR
FÖR INSTALLATÖREN
POUR L’INSTALLATEUR

  
Για σωστή και ασφαλή χρήση, διαβάστε προσεκτικά αυτό το εγχειρίδιο, καθώς και το εγχειρίδιο εγκατάστασης
της εξωτερικής μονάδας, πριν από την εγκατάσταση της μονάδας κλιματιστικού.
     
Türkçe
MONTAJ ELKTABI
Emniyetli ve doğru kullanım için, klima cihazınımonte etmeden önce bu kılavuzu ve dışünite montaj kılavuzunu
tamamıyla okuyun.
MONTÖR ÇN

  
Для обеспечения безопасной инадлежащей эксплуатации внимательно прочтите данное руководство и
руководство по установке наружного прибора перед установкой кондиционера.
 

2
Contents
Before installing the unit, make sure you read all the “Safety precau-
tions”.
Please report to your supply authority or obtain their consent before
connecting this equipment to the power supply system.
Warning:
Describes precautions that must be observed to prevent danger of injury or
death to the user.
Caution:
Describes precautions that must be observed to prevent damage to the unit.
After installation work has been completed, explain the “Safety Precautions,” use,
and maintenance of the unit to the customer according to the information in the
Operation Manual and perform the test run to ensure normal operation. Both the
Installation Manual and Operation Manual must be given to the user for keeping.
These manuals must be passed on to subsequent users.
:Indicates a part which must be grounded.
Warning:
Carefully read the labels affixed to the main unit.
Warning:
• Ask a dealer or an authorized technician to install the unit.
• For installation work, follow the instructions in the Installation Manual and
use tools and pipe components specifically made for use with refrigerant
specified in the outdoor unit installation manual.
• The unit must be installed according to the instructions in order to mini-
mize the risk of damage from earthquakes, typhoons, or strong winds. An
incorrectly installed unit may fall down and cause damage or injuries.
•
The unit must be securely installed on a structure that can sustain its weight.
• If the air conditioner is installed in a small room, measures must be taken
to prevent the refrigerant concentration in the room from exceeding the
safety limit in the event of refrigerant leakage. Should the refrigerant leak
and cause the concentration limit to be exceeded, hazards due to lack of
oxygen in the room may result.
• Ventilate the room if refrigerant leaks during operation. If refrigerant comes
into contact with a flame, poisonous gases will be released.
• All electric work must be performed by a qualified technician according to
local regulations and the instructions given in this manual.
• Use only specified cables for wiring. The wiring connections must be made
securely with no tension applied on the terminal connections. Also, never
splice the cables for wiring (unless otherwise indicated in this document).
Failure to observe these instructions may result in overheating or a fire.
1.1. Before installation (Environment)
Caution:
• D
o not use the unit in an unusual environment. If the air conditioner is in-
stalled in areas exposed to steam, volatile oil (including machine oil), or sulfu-
ric gas, areas exposed to high salt content such as the seaside, the perform-
ance can be significantly reduced and the internal parts can be damaged.
• Do not install the unit where combustible gases may leak, be produced,
flow, or accumulate. If combustible gas accumulates around the unit, fire or
explosion may result.
• Do not keep food, plants, caged pets, artwork, or precision instruments in
the direct airflow of the indoor unit or too close to the unit, as these items
can be damaged by temperature changes or dripping water.
• When the room humidity exceeds 80% or when the drainpipe is clogged,
water may drip from the indoor unit. Do not install the indoor unit where
such dripping can cause damage.
• When installing the unit in a hospital or communications office, be pre-
pared for noise and electronic interference. Inverters, home appliances,
high-frequency medical equipment, and radio communications equipment
can cause the air conditioner to malfunction or breakdown. The air con-
ditioner may also affect medical equipment, disturbing medical care, and
communications equipment, harming the screen display quality.
1.2. Before installation or relocation
Caution:
• Be extremely careful when transporting the units. Two or more persons
are needed to handle the unit, as it weighs 20 kg or more. Do not grasp the
packaging bands. Wear protective gloves as you can injure your hands on
the fins or other parts.
•
Be sure to safely dispose of the packaging materials. Packaging materials, such
as nails and other metal or wooden parts may cause stabs or other injuries.
• Thermal insulation of the refrigerant pipe is necessary to prevent condensation.
If the refrigerant pipe is not properly insulated, condensation will be formed.
1.3. Before electric work
Caution:
• Be sure to install circuit breakers. If not installed, electric shock may result.
• For the power lines, use standard cables of sufficient capacity. Otherwise,
a short circuit, overheating, or fire may result.
• When installing the power lines, do not apply tension to the cables.
• Be sure to ground the unit. If the unit is not properly grounded, electric
shock may result.
1.4. Before starting the test run
Caution:
• Turn on the main power switch more than 12 hours before starting opera-
tion. Starting operation just after turning on the power switch can severely
damage the internal parts.
• Before starting operation, check that all panels, guards and other protec-
tive parts are correctly installed. Rotating, hot, or high voltage parts can
cause injuries.
• Do not operate the air conditioner without the air filter set in place. If the air
filter is not installed, dust may accumulate and breakdown may result.
• Do not touch any switch with wet hands. Electric shock may result.
• Do not touch the refrigerant pipes with bare hands during operation.
• After stopping operation, be sure to wait at least five minutes before turn-
ing off the main power switch. Otherwise, water leakage or breakdown may
result.
Note:
The phrase “Wired remote controller“ in this installation manual refers only to the PAR-31MAA.
If you need any information for the other remote controller, please refer to either the installation manual or initial setting manual which are included in these
boxes.
• The appliance shall be installed in accordance with national wiring regulations.
• The terminal block cover panel of the unit must be firmly attached.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
• Use only accessories authorized by Mitsubishi Electric and ask a dealer or
an authorized technician to install them.
• The user should never attempt to repair the unit or transfer it to another lo-
cation.
• After installation has been completed, check for refrigerant leaks. If refrig-
erant leaks into the room and comes into contact with the flame of a heater
or portable cooking range, poisonous gases will be released.
• When installing or relocating, or servicing the air conditioner, use only the
specified refrigerant (R410A) to charge the refrigerant lines. Do not mix it
with any other refrigerant and do not allow air to remain in the lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other
hazards.
The use of any refrigerant other than that specified for the system will
cause mechanical failure or system malfunction or unit breakdown. In the
worst case, this could lead to a serious impediment to securing product
safety.
• Place thermal insulation on the pipes to prevent condensation. If the drain-
pipe is installed incorrectly, water leakage and damage to the ceiling, floor,
furniture, or other possessions may result.
• Do not clean the air conditioner unit with water. Electric shock may result.
• Tighten all flare nuts to specification using a torque wrench. If tightened too
much, the flare nut can break after an extended period.
• Use circuit breakers (ground fault interrupter, isolating switch (+B fuse),
and molded case circuit breaker) with the specified capacity. If the circuit
breaker capacity is larger than the specified capacity, breakdown or fire
may result.
1. Safety precautions
1. Safety precautions..................................................................................... 2
2. Installation location....................................................................................3
3. Installing the indoor unit ............................................................................3
4. Installing the refrigerant piping ..................................................................5
5. Drainage piping work................................................................................. 6
6. Electrical work ...........................................................................................6
7. Test run....................................................................................................12
8. Easy maintenance function .....................................................................16

3
3. Installing the indoor unit
2. Installation location
(mm)
236Min.500
680
Max.250
W
Min.270 Min.300
123
456
78
A








236
B
2
75
80320
680
2
19046
6
233
246 C
D
233
246



 


86 285
138
126
19046
3.1. Check the indoor unit accessories (Fig. 3-1)
The indoor unit should be supplied with the following accessories
(contained in the inside of the intake grille).
Accessory name Q’ty
1Washer 4 pcs
2Pipe cover 1 pc Large size (For gas tubing)
3Pipe cover 1 pc Small size (For liquid tubing)
4Band 4 pcs
5Joint socket 1 pc Marked with “UNIT”
6Socket cover 1 pc
7Drain tubing cover 1 pc
8Flare nut 1 pc ø6.35 (RP60 only)
3.2. Preparation for installation (Fig. 3-2)
3.2.1. Suspension bolt installing spacing
(mm)
Models A B
RP35, 50 917 960
RP60, 71 1237 1280
RP100, 125, 140 1557 1600
3.2.2. Refrigerant and drain tubing location
(mm)
Models C D
RP35, 50 184 203
RP60 179 203
RP71-140 180 200
AFront side outlet FLeft drain tubing
BLeft side outlet GGas tubing
CRight side outlet HLiquid tubing
DIndependent piece (Removable) IRubber plug
ERight drain tubing Jwith Joint socket 5
In case of the rear pipe arrangement, make sure to remove the shaded portions
from the Dindependent piece. Then put the Dindependent piece back in initial
position.
(The heat exchanger might be clogged because of dust)
Fig. 2-1
2.1. Outline dimensions (Indoor unit) (Fig. 2-1)
Select a proper position allowing the following clearances for installation and main-
tenance.
Models W
RP35, 50 960
RP60, 71 1280
RP100, 125, 140 1600
Warning:
Mount the indoor unit on a ceiling strong enough to withstand the weight of
the unit.
2.2. Outline dimensions (Outdoor unit)
Refer to the outdoor unit installation manual.
Fig. 3-1
70+6
Fig. 3-2
(mm)

4
3. Installing the indoor unit











(mm)
/ 5
3
5
3
4
0
10 –20
21
3
5

/
0






125
175
190
70
80 ø65 ø100
7~12









3.3. Installing the indoor unit (Fig. 3-5)
Use a proper suspending method depending on the presence or absence of ceiling
materials as follows.
AIn the presence of ceiling materials cCeiling
BIn the absence of ceiling materials dSuspending bolt
aSuspending bracket eWasher 1
bUnit fWasher (Local procurement)
gDouble nuts
1) Directly suspending the unit
Installing procedures
1. Install the washer 1(supplied with the unit) and the nuts (to be locally procured).
2. Set (hook) the unit through the suspending bolts.
3. Tighten the nuts.
Check the unit installing condition.
• Check that the unit is horizontal between the right and left sides.
• Check that the front and the rear of suspending brackets are horizontal.
(To keep drainage,the unit is inclined to the suspending brackets. The unit slopes
continuously downward from the front to the rear is the right installation position.)
2) Installing the suspending bracket first onto the ceiling (Fig. 3-6)
Installing procedures
1. Remove the suspending brackets and U-shaped washers from the unit.
2. Adjust the suspending bracket holding bolts on the unit.
3. Attach the suspending brackets to the suspending bolts.
4. Check that the suspending brackets are horizontal (front and rear/right and left).
5. Set (hook) the unit to the suspending brackets.
6. Tighten fixed bolts of the suspending brackets.
wBe sure to install the U-shaped washers.
ASuspending bracket holding bolt
BUnit
CU-shaped washer
DSuspending bolt
EWasher 1
FDouble nuts
3.2.3. Selection of suspension bolts and tubing positions (Fig. 3-3)
Using the pattern paper provided for installation, select proper positions for suspen-
sion bolts and tubing and prepare relative holes.
APattern paper
BSuspension bolt hole
CIndoor unit width
Secure the suspension bolts or use angle stock braces or square timbers for bolt
installation.
DUse inserts of 100 kg to 150 kg each.
EUse suspension bolts of W3/8 or M10 in size.
3.2.4. Indoor unit preparation (Fig. 3-4)
1. Install the suspending bolts. (Procure the W3/8 or M10 bolts locally.)
Predetermine the length from the ceiling (1within 100 mm).
ACeiling surface BSuspending bolt CSuspending bracket
2. Remove the intake grille.
Slide the intake grille holding knobs (at 2 or 3 locations) backward to open the
intake grille.
3. Remove the side panel.
Remove the side panel holding screws (one in each side, right and left) then slide
the side panel forward for removal.
DIntake grille JSlide the side panel forward.
EIntake grille holding knob KSide panel
FSlide LRemove the side panel holding screws.
GHinge MRemove the protective vinyl of vane.
HPushing the hinge, pull out the intake grille.
2Forcing open the intake grille or opening it to an angle of more than 120° may
damage the hinges.
Fig. 3-4
Fig. 3-5
Fig. 3-3
Fig. 3-6
(mm)
GRP35, 50 882-887
RP60, 71 1202-1207
RP100-140 1522-1527

5
4. Installing the refrigerant piping











B



A
45 2
4.3. Indoor unit (Fig. 4-3)
Installing procedures
1. Slide the supplied pipe cover 2over the gas tubing until it is pressed against the
sheet metal inside the unit.
2. Slide the provided pipe cover 3over the liquid tubing until it is pressed against
the sheet metal inside the unit.
3. Tighten the pipe covers 2and 3at the both ends (20 mm) with the supplied
bands 4.
AGas tubing EPipe cover 3
BLiquid tubing FPress the pipe cover against the sheet metal.
CBand 4GRefrigerant tubing heat insulating material
DPipe cover 2
4.4. For twin/triple combination
Refer to the outdoor unit installation manual.
4.1. Precautions
For devices that use R410A refrigerant
• Use ester oil, ether oil or alkylbenzene oil (small amount) as the refrigera-
tion oil applied to the flared sections.
• Use C1220 copper phosphorus for copper and copper alloy seamless
pipes, to connect the refrigerant pipes. Use refrigerant pipes with the thick-
nesses specified in the table below. Make sure the insides of the pipes are
clean and do not contain any harmful contaminants such as sulfuric com-
pounds, oxidants, debris, or dust.
Warning:
When installing or relocating, or servicing the air conditioner, use only the
specified refrigerant (R410A) to charge the refrigerant lines. Do not mix it
with any other refrigerant and do not allow air to remain in the lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other haz-
ards.
The use of any refrigerant other than that specified for the system will cause
mechanical failure or system malfunction or unit breakdown. In the worst
case, this could lead to a serious impediment to securing product safety.
RP35, 50 RP60-140
Liquid pipe [6.35 thickness 0.8 mm [9.52 thickness 0.8 mm
Gas pipe [12.7 thickness 0.8 mm [15.88 thickness 1.0 mm
• Do not use pipes thinner than those specified above.
4.2. Connecting pipes (Fig. 4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C or
more, thickness of 12 mm or more).
• The indoor parts of the drain pipe should be wrapped with polyethylene foam in-
sulation materials (specific gravity of 0.03, thickness of 9 mm or more).
• Apply thin layer of refrigerant oil to pipe and joint seating surface before tighten-
ing flare nut.
• Use 2 wrenches to tighten piping connections.
• Use refrigerant piping insulation provided to insulate indoor unit connections. In-
sulate carefully.
BFlare nut tightening torque
Copper pipe O.D.
(mm)
Flare nut O.D.
(mm)
Tightening torque
(N·m)
[6.35 17 14-18
[6.35 22 34-42
[9.52 22 34-42
[12.7 26 49-61
[12.7 29 68-82
[15.88 29 68-82
[15.88 36 100-120
[19.05 36 100-120
CApply refrigerating machine oil over the entire flare seat surface.
DUse correct flare nuts meeting the pipe size of the outdoor unit.
Available pipe size
RP35, 50 RP60 RP71-140
Liquid side [6.35 Ο[6.35 —
—[9.52 Ο[9.52 Ο
Gas side [12.7 Ο[15.88 Ο[15.88 Ο
Ο: Factory flare nut attachment to the heat exchanger.
AFlare cutting dimensions
Copper pipe O.D.
(mm)
Flare dimensions
[A dimensions (mm)
[6.35 8.7 - 9.1
[9.52 12.8 - 13.2
[12.7 16.2 - 16.6
[15.88 19.3 - 19.7
[19.05 23.6 - 24.0
Copper pipe O.D.
(mm)
B (mm)
Flare tool for R410A
Clutch type
[6.35 (1/4″) 0 - 0.5
[9.52 (3/8″) 0 - 0.5
[12.7 (1/2″) 0 - 0.5
[15.88 (5/8″) 0 - 0.5
[19.05 (3/4″) 0 - 0.5
Fig. 4-3
Fig. 4-1
Fig. 4-2
90° ± 0.5°
R0.4 - R0.8
EDie
FCopper pipe

6
5. Drainage piping work
6. Electrical work

















7
• For left side tubing, be sure to insert the rubber plug into the right drain port. (Fig.
5-1)
• Use VP-20 (O.D. ø26 (1”) PVC TUBE) for drain piping and provide 1/100 or more
downward slope.
• After completion of work, check that correct drain is available from the outflow
port of the drain tubing.
ADrain pan
BPlug
CInsert the driver etc.in the plug deeply.
Installing procedures (Fig. 5-2)
1. Attach the joint socket 5supplied with the unit to the drain port on the unit with a
vinyl chloride adhesive.
2. Fasten the socket cover 6supplied with the unit to the joint socket 5.
3. Attach the field drain tubing (VP-20) to the joint socket 5with a vinyl chloride
adhesive.
4. Wrap the drain tubing cover 7supplied with the unit. (Seam taping)
ADrain pan
BDrain tubing
CSocket cover 6
DJoint socket 5
EDrain tubing cover 7
FInsertion length 37 mm
5. Check for correct drainage. (Fig. 5-3)
* Fill the drain pan with water of about 1 L from the air outlet.
6.1. Electric wiring (Fig. 6-1)
Wiring procedures
1. Remove the tapping screw Cthen remove the beam.
2. Remove the (2) tapping screws Bthen remove the electric part cover A.
3. Connect the electric wires securely to the corresponding terminals.
4. Replace the removed parts.
5. Tie the electric wires with the local wiring clamp located in the right side of the
junction box.
ACover HGrounding cable connector
BSet screws (2 pcs) ITerminal block for Remote controller
CSet screws (Beam) iSecure with the wiring clamp.
DWiring clamp
EControl board
FWire service entrance
GTerminal block for indoor and outdoor units connection
Fig. 5-1
Fig. 5-2
Fig. 5-3
Fig. 6-1

7
6.1.1. Indoor unit power supplied from outdoor unit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.1 System
S1
S2
L
N
1
2
S1
S2
S3
S3
AB C
D
E
F
G
S1
S2
L
N
1
2
S1
S2
S3
1
2
S1
S2
S3
S3
1
2
S1
S2
S3
1
2
S1
S2
S3
ABC
D
E
F
GGGG
HHH
* Affix label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
* Affix label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
Indoor unit model PCA
Wiring
Wire No. × size
(mm²)
Indoor unit-Outdoor unit *1 3 × 1.5 (polar)
Indoor unit-Outdoor unit earth *1 1 × Min.1.5
Indoor unit earth 1 × Min.1.5
Remote controller-Indoor unit *2 2 × 0.3 (Non-polar)
Circuit rating
Indoor unit (Heater) L-N *3 -
Indoor unit-Outdoor unit S1-S2 *3 AC 230 V
Indoor unit-Outdoor unit S2-S3 *3 DC24 V
Remote controller-Indoor unit *3 DC12 V
*1. <For 50-140 outdoor unit application>
Max. 45 m
If 2.5 mm2used, Max. 50 m
If 2.5 mm2used and S3 separated, Max. 80 m
<For 200/250 outdoor unit application>
Max. 18 m
If 2.5 mm2used, Max. 30 m
If 4 mm2used and S3 separated, Max. 50 m
If 6 mm2used and S3 separated, Max. 80 m
*2. The 10 m wire is attached in the remote controller accessory. Max. 500 m
*3. The figures are NOT always against the ground.
S3 terminal has DC 24 V against S2 terminal. However between S3 and S1, these terminals are not electrically insulated by the transformer or other device.
Notes: 1. Wiring size must comply with the applicable local and national code.
2.
Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed flexible cord.
(Design 60245 IEC 57)
3. Install an earth longer than other cables.
Simultaneous twin/triple/quadruple system
1:1 System
6.1.2. Separate indoor unit/outdoor unit power supplies (For PUHZ application only)
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
1:1 System
6. Electrical work
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Indoor unit earth
S1
S2
L
N
1
2
L
N
S1
S2
S3
S3
ACB
D
J
E
BC
F
G
H
* The indoor power supply terminal kit is required. A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
* Affix label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.

8
6. Electrical work
Simultaneous twin/triple/quadruple system
S1
S2
L
N
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
S3
AB C
D
E
JBC
F
H
GGGG
K
K
K
HHH
ON
OFF 1 2 (SW8)
3
S1
S2
S3
L
N
BLUE BLUE
YELLOW YELLOW
CN01
CN01
BLACK
CN01
BLACK
S1
S2
S3
L
N
YELLOW
BLUE
BLUE
YELLOW
CN01
* Affix label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
If the indoor and outdoor units have separate power supplies, refer to the table
below. If the indoor power supply terminal kit is used, change the indoor unit elec-
trical box wiring refering to the figure in the right and the DIP switch settings of the
outdoor unit control board.
Indoor unit specifications
Indoor power supply terminal kit (option) Required
Indoor unit electrical box connector connec-
tion change
Required
Label affixed near each wiring diagram for
the indoor and outdoor units
Required
Outdoor unit DIP switch settings (when us-
ing separate indoor unit/outdoor unit power
supplies only)
* There are 3 types of labels (labels A, B and C). Affix the appropriate labels to the
units according to the wiring method.
Indoor unit model PCA
*1. A breaker with at least 3.0 mm contact separation in each pole shall be pro-
vided. Use earth leakage breaker (NV).
The breaker shall be provided to ensure disconnection of all active phase
conductors of the supply.
*2. Max. 120 m
*3. The 10 m wire is attached in the remote controller accessory. Max. 500 m
*4. The figures are NOT always against the ground.
Indoor unit power supply ~/N (single), 50 Hz, 230 V
Indoor unit input capacity
Main switch (Breaker) *1 16 A
Wiring
Wire No. ×
size (mm²)
Indoor unit power supply & earth 3 × Min. 1.5
Indoor unit-Outdoor unit *2 2 × Min. 0.3
Indoor unit-Outdoor unit earth –
Remote controller-Indoor unit *3 2 × 0.3 (Non-polar)
Circuit
rating
Indoor unit L-N *4 AC 230 V
Indoor unit-Outdoor unit S1-S2 *4 –
Indoor unit-Outdoor unit S2-S3 *4 DC24 V
Remote controller-Indoor unit *4 DC12 V
Notes: 1. Wiring size must comply with the applicable local and national code.
2.
Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed flexible cord. (Design 60245 IEC 57)
3. Install an earth longer than other cables.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
K Indoor unit earth
Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a fire or communication failure.
Warning:
* The indoor power supply terminal kits are required.
Set the SW8-3 to ON.
Option
Option
Indoor unit power supplied from outdoor unit
(initial setting)
Separate indoor unit/outdoor unit power supplies
Connectors (connections of initial setting
are for indoor unit power supplied from
outdoor unit)
If the indoor and
outdoor units have
separate power
supplies, change the
connections of the
connectors as shown
in the following
figure.
Connectors
Indoor unit
control board
Indoor unit
control board

9
6. Electrical work
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT










ON/OFF TEMP
RESETSET CLOCK
MODEL SELECT
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK



6.2. Remote controller
6.2.1. For wired remote controller
1) 2 remote controllers setting
If 2 remote controllers are connected, set one to “Main” and the other to “Sub”. For
setting procedures, refer to “Function selection of remote controller” in the opera-
tion manual for the indoor unit.
6.2.2. For wireless remote controller
1) Installation area
• Area in which the remote controller is not exposed to direct sunshine.
• Area in which there is no nearby heating source.
• Area in which the remote controller is not exposed to cold (or hot) winds.
• Area in which the remote controller can be operated easily.
• Area in which the remote controller is beyond the reach of children.
2) Installation method (Fig. 6-2)
1
Attach the remote controller holder to the desired location using 2 tapping screws.
2Place the lower end of the controller into the holder.
ARemote controller BWall CDisplay panel DReceiver
• The signal can travel up to approximately 7 meters (in a straight line) within 45
degrees to both right and left of the center line of the receiver.
3) Setting (Fig. 6-3)
1Insert batteries.
2Press the SET button with something sharp at the end.
MODEL SELECT
blinks and Model No. is lighted.
3Press the temp buttons to set the Model No.
If you mistook the operation, press the ON/OFF button and operate again
from procedure 3.
4Press the SET button with something sharp at the end.
MODEL SELECT
and Model No. are lighted for 3 seconds, then turned off.
Indoor Outdoor AModel No.
PCA PUH, PUHZ, SUZ 001
PU 033
4)Assigning a remote controller to each unit (Fig. 6-4)
Each unit can be operated only by the assigned remote controller.
Make sure each pair of an indoor unit PC board and a remote controller is assigned
to the same pair No.
5) Wireless remote controller pair number setting operation
1Press the SET button with something sharp at the end.
Start this operation from the status of remote controller display turned off.
MODEL SELECT
blinks and Model No. is lighted.
2Press the
min
button twice continuously. Pair No. “0” blinks.
3Press the temp buttons to set the pair number you want to set.
If you mistook the operation, press the ON/OFF button and operate again
from procedure 2.
4Press the SET button with something sharp at the end.
Set pair number is lighted for 3 seconds then turned off.
APair No. of wireless remote controller Indoor PC board
0 Initial setting
1 Cut J41
2 Cut J42
3-9 Cut J41, J42
Fig. 6-2 Fig. 6-3
Fig. 6-4

10
6. Electrical work
6.3. Function settings
6.3.1. Function setting on the unit (Selecting the unit functions)
1) For wired remote controller
1(Fig. 6-5)
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Function settings” with the [F1] or [F2] button, and press the [SELECT]
button.
2(Fig. 6-6)
• Set the indoor unit refrigerant addresses and unit numbers with the [F1]
through [F4] buttons, and then press the [SELECT] button to confirm the cur-
rent setting.
<Checking the Indoor unit No.>
When the [SELECT] button is pressed, the target indoor unit will start fan opera-
tion. If the unit is common or when running all units, all indoor units for the se-
lected refrigerant address will start fan operation.
3(Fig. 6-7)
• When data collection from the indoor units is completed, the current settings
appears highlighted. Non-highlighted items indicate that no function settings
are made. Screen appearance varies depending on the “Unit No.” setting.
4 (Fig. 6-8)
• Use the [F1] or [F2] button to move the cursor to select the mode number, and
change the setting number with the [F3] or [F4] button.
5 (Fig. 6-9)
• When the settings are completed, press the [SELECT] button to send the set-
ting data from the remote controller to the indoor units.
• When the transmission is successfully completed, the screen will return to the
Function setting screen.
F1 F2 F3 F4
Service menu
Cursor
Main menu:
Test run
Input maintenance info.
Function setting
Check
Self check
F1 F2 F3 F4
Function setting
Cursor Address
Monitor:
Ref. address
Unit No. Grp./1/2/3/4/All
Fig. 6-5 Fig. 6-6
F1 F2 F3 F4
Function setting
Cursor Cursor
Request:
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
F1 F2 F3 F4
Function setting
Cursor Cursor
Request:
Ref. address
Mode 7
Mode 8
Mode 9
Mode10
Unit # 1
Fig. 6-7 Fig. 6-8
F1 F2 F3 F4
Function setting
Ref. address
Sending data
Grp.
Fig. 6-9

11
2) For wireless remote controller (Fig. 6-10)
Changing the power voltage setting
• Be sure to change the power voltage setting depending on the voltage used.
1Going to the function select mode
Press the
CHECK
button Ftwice continuously.
(Start this operation from the status of remote controller display turned off.)
CHECK
is lighted and “00” blinks.
Press the temp button Conce to set “50”. Direct the wireless remote control-
ler toward the receiver of the indoor unit and press the
h
button A.
2Setting the unit number
Press the temp buttons Cand Dto set the unit number “00”. Direct the
wireless remote controller toward the receiver of the indoor unit and press the
min
button B.
3Selecting a mode
Enter 04 to change the power voltage setting using the temp buttons C
and D. Direct the wireless remote controller toward the receiver of the indoor
unit and press the
h
button A.
Current setting number: 1 = 1 beep (1 second)
2 = 2 beeps (1 second each)
3 = 3 beeps (1 second each)
4Selecting the setting number
Use the temp buttons Cand Dto change the power voltage setting to
01 (240 V). Direct the wireless remote controller toward the sensor of the indoor
unit and press the
h
button A.
5To select multiple functions continuously
Repeat steps
3and 4to change multiple function settings continuously.
6Complete function selection
Direct the wireless remote controller toward the sensor of the indoor unit and
press the button E.
Note: Whenever changes are made to the function settings after installation
or maintenance, be sure to record the changes with a mark in the “Setting”
column of the Function table.
6.3.2. Function setting on the remote controller
Refer to the indoor unit operation manual.
6. Electrical work
Function table
Select unit number 00
Mode Settings Mode no. Setting no. Initial setting setting
Power failure automatic recovery Not available 01 1
Available w2Ο
Indoor temperature detecting Indoor unit operating average
02
1Ο
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported
03
1Ο
Supported (indoor unit is not equipped with outdoor-air intake) 2
Supported (indoor unit is equipped with outdoor-air intake) 3
Power voltage 240 V 04 1
220 V, 230 V 2 Ο
CHECK CHECK
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
CHECK
CHECKCHECK







Fig. 6-10
Select unit numbers 01 to 03 or all units (AL [wired remote controller]/07 [wireless remote controller])
Mode Settings Mode no. Setting no. Initial setting setting
Filter sign 100Hr
07
1
2500Hr 2 Ο
No filter sign indicator 3
Fan speed Silent
08
1
Standard 2 Ο
High ceiling 3
Up/down vane setting No vanes
11
1
Equipped with vanes (vanes angle setup 1)2Ο
Equipped with vanes (vanes angle setup 2)3
wWhen the power supply returns, the air conditioner will start 3 minutes later.

12
7. Test run
7.1. Before test run
After completing installation and the wiring and piping of the indoor and
outdoor units, check for refrigerant leakage, looseness in the power sup-
ply or control wiring, wrong polarity, and no disconnection of one phase
in the supply.
Use a 500-volt megohmmeter to check that the resistance between the
power supply terminals and ground is at least 1 M .
Do not carry out this test on the control wiring (low voltage circuit) termi-
nals.
Warning:
Do not use the air conditioner if the insulation resistance is less than 1 M .
7.2. Test run
7.2.1. Using wired remote controller.
■Make sure to read operation manual before test run. (Especially items to secure safety)
Step 1 Turn on the power.
●Remote controller: The system will go into startup mode, and the remote controller power lamp (green) and “PLEASE WAIT” will blink. While the lamp and message
are blinking, the remote controller cannot be operated. Wait until “PLEASE WAIT” is not displayed before operating the remote controller. After the power is turned on,
“PLEASE WAIT” will be displayed for approximately 2 minutes.
●Indoor controller board: LED 1 will be lit up, LED 2 will be lit up (if the address is 0) or off (if the address is not 0), and LED 3 will blink.
●Outdoor controller board: LED 1 (green) and LED 2 (red) will be lit up. (After the startup mode of the system finishes, LED 2 will be turned off.) If the outdoor controller
board uses a digital display, [- ] and [ -] will be displayed alternately every second.
If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they
are found.
(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)
Symptoms in test run mode
Cause
Remote Controller Display OUTDOOR BOARD LED Display
< > indicates digital display.
Remote controller displays “PLEASE WAIT”,
and cannot be operated. After “startup” is displayed, only green lights up. <00> • After power is turned on, “PLEASE WAIT” is displayed for 2 minutes during system startup. (Normal)
After power is turned on, “PLEASE WAIT” is
displayed for 3 minutes, then error code is dis-
played.
After “startup” is displayed, green (once) and red
(once) blink alternately. <F1> • Incorrect connection of outdoor terminal block (R, S, T and S1,
S2, S3.)
After “startup” is displayed, green (once) and red
(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.
No display appears even when remote control-
ler operation switch is turned on. (Operation
lamp does not light up.)
After “startup” is displayed, green (twice) and
red (once) blink alternately. <EA. Eb>
• Incorrect wiring between the indoor and outdoor unit (Polarity
is wrong for S1, S2, S3.)
• Remote controller transmission wire short.
After “startup” is displayed, only green lights up.
<00> • There is no outdoor unit of address 0. (Address is other than 0.) • Remote controller transmission wire open.
Display appears but soon disappears even
when remote controller is operated. After “startup” is displayed, only green lights up. <00> • After canceling function selection, operation is not possible for about 30 seconds. (Normal)
Step 2 Switch the remote controller to “Test run”.
1Select “Test run” from the Service menu, and press the [SELECT] button. (Fig. 7-1)
2Select “Test run” from the Test run menu, and press the [SELECT] button. (Fig. 7-2)
3The test run operation starts, and the Test run operation screen is displayed.
F1 F2 F3 F4
unemecivreS
rosruC
:unemniaM
Test run
Input maintenance info.
Function setting
Check
Self check
Fig. 7-1
F1 F2 F3 F4
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
Fig. 7-2
F1 F2 F3 F4
Cool
Pipe
Auto
Switch disp.
Mode Fan
RemainTest run
Fig. 7-3
F1 F2 F3 F4
Remain
Vane
Fig. 7-4
Step 3 Perform the test run and check the airflow temperature and auto vane.
1Press the [F1] button to change the operation mode. (Fig. 7-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2Press the [SELECT] button to display the Vane operation screen, and then press
the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)
Press the [RETURN] button to return to the Test run operation screen.
Step 4 Confirm the operation of the outdoor unit fan.
The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will
keep rotating at that speed unless the performance is insufficient. Therefore, the outdoor wind may cause the fan to stop rotating or to rotate in the opposite direction, but
this is not a problem.

13
7.2.2. Using wireless remote controller (Fig. 7-5)
1Turn on the power to the unit at least 12 hours before the test run.
2Press the
TEST RUN
button twice continuously.
(Start this operation from the status of remote controller display turned off.)
A
TEST RUN
and current operation mode are displayed.
3Press the MODE button to activate mode, then check whether
cool air is blown out from the unit.
4Press the MODE button to activate mode, then check whether
warm air is blown out from the unit.
5Press the FAN button and check whether fan speed changes.
6Press the VANE button and check whether the auto vane operates properly.
7Press the ON/OFF button to stop the test run.
Note:
•Point the remote controller towards the indoor unit receiver while following
steps 2to 7.
• It is not possible to run the TEST RUN in FAN, DRY or AUTO mode.
7.2.3. Using SW4 in outdoor unit
Refer to the outdoor unit installation manual.
7.3. Self-check
7.3.1. Wired remote controller
■Refer to the installation manual that comes with each remote controller for details.
1Press the [CHECK] button twice.
2Set refrigerant address with [TEMP] button if system control is used.
3Press the [ON/OFF] button to stop the self-check.
ACHECK button
BRefrigerant address
CTEMP. button
DIC: Indoor unit
OC: Outdoor unit
ECheck code
FUnit address
7.3.2. Wireless remote controller (Fig. 7-6)
1Turn on the power.
2Press the
CHECK button twice.
(Start this operation from the status of remote controller display turned off.)
Abegins to light.
B“00” begins to blink.
3While pointing the remote controller toward the unit’s receiver, press the h
button. The check code will be indicated by the number of times that the buzzer
sounds from the receiver section and the number of blinks of the operation
lamp.
4Press the ON/OFF button to stop the self-check.
7. Test run
Step 5 Stop the test run.
1Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)
Note: If an error is displayed on the remote controller, see the table below.
LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction
P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)
E0 ~ E5 Communication error between the
remote controller and the indoor unit
P2 Pipe sensor error (liquid pipe) PA Leakage error (refrigerant system)
P4 Drain float switch connector disconnected
(CN4F) PL Refrigerant circuit abnormal
P5 Drain overflow protection operation FB Indoor controller board error
E6 ~ EF Communication error between the
indoor unit and the outdoor unit
P6 Freezing/overheating protection
operation
U*, F*
(* indicates an
alphanumeric
character
excluding FB.)
Outdoor unit malfunction
Refer to the wiring diagram for the
outdoor unit.
P8 Pipe temperature error
See the table below for the details of the LED display (LED 1, 2, and 3) on the indoor controller board.
LED1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is con-
nected to the outdoor unit that has an address of 0.
LED3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
CHECK





ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
TEST RUN






Fig. 7-5
Fig. 7-6

14
7. Test run
• Refer to the following tables for details on the check codes. (Wireless remote controller)
[Output pattern A]
[Output pattern A] Errors detected by indoor unit
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1 P1 Intake sensor error
2P2 Pipe (TH2) sensor error
P9 Pipe (TH5) sensor error
3 E6, E7 Indoor/outdoor unit communication error
4 P4 Float switch connector open
5P5 Drain pump error
PA Forced compressor stop (due to water leakage abnormality)
6 P6 Freezing/Overheating protection operation
7 EE Communication error between indoor and outdoor units
8 P8 Pipe temperature error
9 E4 Remote controller signal receiving error
10 — —
11 — —
12 Fb Indoor unit control system error (memory error, etc.)
14 PL Refrigerant circuit abnormal
No sound E0, E3 Remote controller transmission error
No sound E1, E2 Remote controller control board error
No sound – – – – No corresponding
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “U2”) Number of blinks/beeps in pattern
indicates the check code in the
following table
nth 1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
[Output pattern B]
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec. On
0.5 sec.
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “P5”)
Number of blinks/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds

15
7. Test run
[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1 E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)
For details, check the LED
display of the outdoor controller
board.
2 UP Compressor overcurrent interruption
3 U3, U4 Open/short of outdoor unit thermistors
4 UF Compressor overcurrent interruption (When compressor locked)
5 U2 Abnormal high discharging temperature/49C worked/insufficient refrigerant
6 U1, Ud Abnormal high pressure (63H worked)/Overheating protection operation
7 U5 Abnormal temperature of heat sink
8 U8 Outdoor unit fan protection stop
9 U6 Compressor overcurrent interruption/Abnormal of power module
10 U7 Abnormality of super heat due to low discharge temperature
11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal
synchronous signal to main circuit/Current sensor error
12 — —
13 — —
14 Others Other errors (Refer to the technical manual for the outdoor unit.)
*1. If the beeper does not sound again after the initial 2 beeps to confirm the self-check start signal was received and the OPERATION INDICATOR lamp does
not come on, there are no error records.
*2. If the beeper sounds 3 times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” after the initial 2 beeps to confirm the self-check start signal was re-
ceived, the specified refrigerant address is incorrect.
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
• If the unit cannot be operated properly after test run, refer to the following table to find the cause.
Symptom Cause
Wired remote controller LED 1, 2 (PCB in outdoor unit
PLEASE WAIT For about 2 minutes
after power-on
After LED 1, 2 are lighted, LED 2 is turned
off, then only LED 1 is lighted. (Correct
operation)
•For about 2 minutes after power-on, operation of the remote
controller is not possible due to system start-up. (Correct
operation)
PLEASE WAIT →Error code
Subsequent to about
2 minutes after
power-on
Only LED 1 is lighted. LED 1, 2 blink.
•Connector for the outdoor unit’s protection device is not con-
nected.
Reverse or open phase wiring for the outdoor unit’s power
terminal block (L1, L2, L3)
Display messages do not appear
even when operation switch is
turned ON
(operation lamp does not light up).
Only LED 1 is lighted. LED 1 blinks
twice, LED 2 blinks once.
•Incorrect wiring between indoor and outdoor units (incorrect
polarity of S1, S2, S3)
•Remote controller wire short
On the wireless remote controller with condition above, following phenomena take place.
• No signals from the remote controller are accepted.
• Operation lamp is blinking.
• The buzzer makes a short ping sound.
Note:
Operation is not possible for about 30 seconds after cancellation of function selection. (Correct operation)
For description of each LED (LED1, 2, 3) provided on the indoor controller, refer to the following table.
LED 1 (power for microcomputer) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (power for remote controller) Indicates whether power is supplied to the remote controller. This LED lights only in the case of
the indoor unit which is connected to the outdoor unit refrigerant address “0”.
LED 3 (communication between indoor and outdoor units) Indicates state of communication between the indoor and outdoor units. Make sure that this LED
is always blinking.

16
8. Easy maintenance function
Maintenance data, such as the indoor/outdoor unit’s heat exchanger temperature and compressor operation current can be displayed with “Smooth maintenance”.
* This cannot be executed during test operation.
* Depending on the combination with the outdoor unit, this may not be supported by some models.
F1 F2 F3 F4
Check menu
Cursor
Service menu:
Error history
Refrigerant volume check
Refrigerant leak check
Smooth maintenance
Request code
Smooth maintenance
Begin:
Smooth maintenance
Exit:
Ref.address
Stable mode
Cursor
Ref.address
Stable mode
Stabilization→Collecting
Cool / Heat/ Normal
Cool / Heat/ Normal
Address
Smooth maintenance
Return:
Smooth maintenance
Return:
Smooth maintenance
Return:
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
A
Hz
Hr
times
Hr
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
IU air temp.
IU HEX temp.
IU filter time
1
2
3
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Check” with the [F1] or [F2] button, and press the [SELECT] button.
• Select “Smooth maintenance” with the [F1] or [F2] button, and press the [SELECT]
button.
Select each item.
• Select the item to be changed with the [F1] or [F2] button.
• Select the required setting with the [F3] or [F4] button.
“Ref. address” setting ………. “0” - “15”
“Stable mode” setting……….. “Cool” / “Heat” / “Normal”
• Press the [SELECT] button, fixed operation will start.
* Stable mode will take approx. 20 minutes.
The operation data will appear.
The Compressor-Accumulated operating (COMP. run) time is 10-hour unit, and the
Compressor-Number of operation times (COMP. On/Off) is a 100-time unit (fractions
discarded)
Navigating through the screens
• To go back to the Main menu....................[MENU] button
• To return to the previous screen .......... [RETURN] button

167
   ,     “ -
”.
,      , -
         .
:
  ,    -
    .
:
  ,    -
 .
1.2.    
:
•      . 
     ,     
20 .      .  
,        -
  .
•     . 
, ,       -
,      .
•      
 .       -
,      .

:
•        -
  .
•        -
    , 
   ,  -
    .
•      ,   -
    ,    -
 .      
   .
•      ,    .
•     , 
       -
    .   
    -   
    .
•        , 
.       .
•      -
     ,
  .
•     . ,   -
 ,    .   
  (     ). -
       .
•      -
 .
•        .
•         
 ,    , -
  .
•     ,   -
   Mitsubishi Electric;     -
    .
•        
   .
•       . 
      
    ,  -
 .
•    ,    
    (R410A)   -
 .        
   .
      , -
       .
  ,      -
,   ,   ,  
  .  ,    
     .
1.1.   ( )
:
•      . 
 ,   ,  
(  )   ,  -
   (,   ),   -
       
 .
•    ,   , ,
    .     -
  ,       .
•    , ,   ,
       
     ,   
       .
•      80%   
      .   -
  ,      - -
.
•          
  .   ,  -
,  ,    
       
 .       
  ,  
,     .
•      
.     ,  
    , ,    -
.
•    .     -
 .
•        , -
   .    
      .
1.3.   
:
•    .  
   .
•     ,  
 .     -
 ,   .
•        .
•   .    
   .
•    (    -
,  (  +B)  ) 
  .     -
 ,  ,     .
1.4.   
:
•      ,   12  
 .      
     .
•    ,   ,  
   . ,   -
      .
•       . 
   ,    , 
   .
•       .  
   .
•
         .
•         
     . 
      .
После окончания установочных работ проинструктируйте пользователя относитель-
но правил эксплуатации иобслуживания аппарата, атакже ознакомьте сразделом
“Меры предосторожности” всоответствии синформацией, приведенной вРуководс-
тве по использованию аппарата, ивыполните тестовый прогон аппарата для того,
чтобы убедиться, что он работает нормально. Обязательно передайте пользователю
на хранение экземпляры Руководства по установке иРуководства по эксплуатации.
Эти Руководства должны быть переданы ипоследующим пользователям данного
прибора.
:Указывает, что данная часть должна быть заземлена.
:
       .
:
      “   ”     PAR-
31MAA.
             ,  
 .
1.  
1. Меры предосторожности.....................................................................167
2. Место установки ..................................................................................168
3. Установка внутреннего прибора.........................................................168
4. Прокладка труб хладагента................................................................ 170
5. Дренажные трубы................................................................................171
6. Электрические работы ........................................................................171
7. Выполнение испытания.......................................................................177
8. Функция простого техобслуживания ..................................................181

168
(мм)
3.   
2.  
3.1.   
   (Fig. 3-1)
Вкомплект поставки внутреннего прибора должны входить следующие
дополнительные принадлежности (находящиеся внутри впускной решетки).
Наименование принадлежности Кол-во
1Прокладка 4 шт.
2Изоляция для труб
1 шт. Большой размер (для газового трубопровода)
3Изоляция для труб
1 шт. Небольшой размер (для жидкостного трубопровода)
4Лента 4 шт.
5
Соединительная муфта 1 шт. Сотметкой “UNIT”
6Изоляция для муфты 1 шт.
7
Изоляция для дренажного
трубопровода
1 шт.
8Гайка раструбного стыка 1 шт. ø6,35 (Только RP60)
3.2.   (Fig. 3-2)
3.2.1.    
(мм)
Модели A B
RP35, 50 917 960
RP60, 71 1237 1280
RP100, 125, 140 1557 1600
3.2.2.     
(мм)
Модели CD
RP35, 50 184 203
RP60 179 203
RP71-140 180 200
A
Переднее боковое выходное отверстие
FЛевый дренажный трубопровод
BЛевое боковое выходное отверстие GГазовый трубопровод
CПравое боковое выходное отверстие HЖидкостный трубопровод
DНезависимая деталь (Съемная)IРезиновая пробка
EПравый дренажный трубопровод Jссоединительной муфтой 5
Вслучае расположения трубы сзадней стороны обязательно удалите
заштрихованные участки сDнезависимой детали. Затем верните D
независимую деталь висходное положение.
(Возможно, теплообменник засорен пылью)
236Min.500
680
Max.250
W
Min.270 Min.300
123
456
78
A








236
B
2
75
80320
680
2
19046
6
233
246 C
D
233
246



 


86 285
138
126
19046
Fig. 2-1
2.1.
  ( ) (Fig. 2-1)
Выберите надлежащее место, сучетом наличия следующего свободного
пространства для установки ипроведения техобслуживания.
Модели W
RP35, 50 960
RP60, 71 1280
RP100, 125, 140 1600
:
Подвешивайте внутренний прибор на потолок, способный выдержать вес прибора.
2.2.   ( )
Смотрите руководство по установке наружного прибора.
Fig. 3-1
70+6
Fig. 3-2
(мм)

169
3.   
3.3.    (Fig. 3-5)
Применяйте правильный метод подвешивания прибора всоответствии стем,
какой материал укреплен на потолке.
A
Если на потолке укреплен специальный
материал для закрепления прибора
cПотолок
dПодвесной болт
Bт.е. если на потолке не имеется
специального материала
eПрокладка 1
f
Прокладка (приобретается на месте)
aСкоба для подвешивания gДвойные гайки
bПрибор
1)    ( 
)
Порядок установки
1.
Установите шайбу 1(входит вкомплект поставки прибора) игайки (приобретается на месте).
2. Навесьте прибор на подвесные болты.
3. Затяните гайки.
Проверьте, насколько хорошо подвешен прибор.
• Проверьте, что прибор находится вгоризонтальном положении между его
правой илевой стороной.
• Убедитесь, что передняя изадняя части навесных скоб расположены
горизонтально.
(Для сохранения дренажа прибор располагается снаклоном всторону
навесных скоб. Правильным положением установки является такое, при
котором прибор имеет уклон вниз от передней части кзадней.)
2)     (Fig. 3-6)
Процедуры установки
1. Выньте из прибора навесные скобы иU-образные прокладки.
2. Отрегулируйте болты крепления навесных скоб на приборе.
3. Прикрепите навесные скобы кнавесным болтам.
4. Убедитесь, что навесные скобы расположены горизонтально (спереди исзади
/справа ислева).
5. Наденьте (нацепите) прибор на навесные скобы.
6. Затяните Болт крепления навесных скоб.
wОбязательно установите U-образные прокладки.
AБолт крепления навесных скоб
BПрибор
CU-образная прокладка
DПодвесной болт
EПрокладка 1
FДвойные гайки











(mm)
/ 5
3
5
3
4
0
10 –20
21
3
5

/
0






125
175
190
70
80 ø65 ø100
7~12









3.2.3.      (Fig. 3-3)
Используя бумажный шаблон для монтажа, выберите надлежащие места для
навесных болтов итрубопроводов иподготовьте соответствующие отверстия.
AБумажный шаблон
BОтверстие для навесного болта
CШирина внутреннего прибора
Закрепите навесные болты или используйте угловые скобы или квадратные
брусья для монтажа болтов.
DИспользуйте вставки сноминалом от 100 до 150 кг каждая.
EИспользуйте навесные болты размером W3/8 или M10
3.2.4.    (Fig. 3-4)
1. Установите подвесные болты (Приобретите на месте болты размера W3/8
или М10)
Предусмотрите расстояние от потолка вниз (1впределах 100 мм).
AПоверхность потолка BПодвесной болт CПодвесная скоба
2. Снятие воздухозаборной решетки.
Продвиньте рукоятки, удерживающие водозаборную решетку (при
расположении 2 или 3) назад, чтобы открыть воздухозаборную решетку.
3. Снятие боковой панели.
Удалите винты, удерживающие боковую панель (один винт скаждой
стороны, справа ислева), затем продвиньте боковую панель вперед, чтобы
удалить ее.
DВоздухозаборная решетка JПродвиньте боковую панель вперед.
EРукоятка, удерживающая
воздухозаборную решетку
KБоковая панель
FНаправляющая
L
Удалите винты, удерживающие боковую панель.
GПетля
MСнимите защитный винил сзаслонки
HНажимая на петлю, вытяните воздухозаборную решетку.
2Приложение силы для открытия воздухозаборной решетки или открытие
ее под углом больше 120° может повредить петли.
Fig. 3-4
Fig. 3-5
Fig. 3-3
Fig. 3-6 (мм)
GRP35, 50 882-887
RP60, 71 1202-1207
RP100-140 1522-1527
(мм)

170
4.   
4.1.  
 ,    R410A
•       -
        
( ).
•       , -
  ,    C1220.
      
 ;     . -
,        
, ,   , ,  
 .
:
   ,    -
     (R410A)  
 .       -
     .
      , 
       .
  ,     
,   ,   ,
    .  ,   -
       -
.
RP35, 50 RP60-140
Труба для жидкости ø6,35 толщина 0,8 мм ø9,52 толщина 0,8 мм
Труба для газа ø12,7 толщина 0,8 мм ø15,88 толщина 1,0 мм
•     ,   .
4.2.   (Fig. 4-1)
• При использовании медных труб, имеющихся впродаже, оберните трубы
для жидкости игаза имеющимися впродаже изоляционными материалами (с
теплозащитой от 100 °Сили выше, толщиной не менее 12 мм).
•
Внутренняя часть дренажной трубы должна быть обернута впенополиэтиленовый
изолирующий материал (удельный вес 0,03; толщина 9 мм или более).
• Нанесите тонкий слой масла хладагента на контактную поверхность труб и
соединений перед тем, как затягивать гайку сфланцем.
• Для затягивания трубных соединений используйте два гаечных ключа.
• Используйте прилагаемое трубное изоляционное покрытие для изоляции
соединений внутреннего блока. Тщательно крепите изоляцию.
BМомент затяжки гайки раструбного стыка
Медная труба O.D.
(мм)
Гайка раструбного
затяжки (мм)
Момент затяжки
(Н·м)
ø6,35 17 14-18
ø6,35 22 34-42
ø9,52 22 34-42
ø12,7 26 49-61
ø12,7 29 68-82
ø15,88 29 68-82
ø15,88 36 100-120
ø19,05 36 100-120
CНанесите машинное масло охлаждения на всю поверхность области присоединения
муфты.
DИспользуйте надлежащие гайки раструбного стыка, подходящие кразмеру трубы наруж-
ного прибора.
  
RP35, 50 RP60 RP71-140
Сторона
жидкости
ø6,35 Οø6,35 —
— ø9,52 Οø9,52 Ο
Сторона газа ø12,7 Οø15,88 Οø15,88 Ο
Ο: Крепление гайки раструбного стыка ктеплообменнику, выполненное на
предприятии-изготовителе.
4.3.   (Fig. 4-3)
 
1. Наденьте поставляемую вкомплекте изоляцию для трубы 2на газовый тру-
бопровод, чтобы она соприкасалась слистовым металлом внутри прибора.
2. Наденьте поставляемую вкомплекте изоляцию для трубы 3на жидкостный
трубопровод, чтобы она соприкасалась слистовым металлом внутри прибора.
3. Затяните всю изоляцию трубопроводов 2и3собоих концов (20 мм) спо-
мощью входящих вкомплект лент 4.
A
Газовый трубопровод
EИзоляция для труб 3
B
Жидкостный трубопровод
F
Надавите на изоляцию для труб до листового металла.
CЛента 4G
Теплоизоляционный материал трубопровода для хладагента
D
Изоляция для труб
2
4.4.    / 
Смотрите руководство по установке наружного прибора.











B



A
45 2
AРаструбный стык - размеры
Медная труба O.D.
(мм)
Размеры раструба,
диаметр А(мм)
[6,35 8,7 - 9,1
[9,52 12,8 - 13,2
[12,7 16,2 - 16,6
[15,88 19,3 - 19,7
[19,05 23,6 - 24,0
Kupferrohr O,D,
(мм)
B (мм)
стыка для R410A
Инструмент раструбного
[6,35 (1/4″) 0 - 0,5
[9,52 (3/8″) 0 - 0,5
[12,7 (1/2″) 0 - 0,5
[15,88 (5/8″) 0 - 0,5
[19,05 (3/4″) 0 - 0,5
Fig. 4-1
Fig. 4-2
90° ± 0,5°
R0,4 - R0,8
EПатрубок
FМедная труба
Fig. 4-3
