Mitsubishi Electric PUY-A36NHA4 Installation and user guide

Job Name: Location: Date:
Purchaser: Engineer:
Submitted to: For Reference Approval Construction
Unit Designation: Schedule No.:
Cooling*
Rated Capacity...............................35,000 Btu/h
Minimum Capacity ............................12,000 Btu/h
SEER ..................................... 15.0 Btu/h/W
EER ....................................... 7.2 Btu/h/W
Total Input .....................................4,850 W
* Rating Conditions (Cooling) - Indoor: 80ºF (27ºC) DB / 67ºF (19ºC) WB.
Outdoor: 95ºF (35ºC) DB / 75ºF (24ºC) WB.
Electrical Requirements
Power Supply ....................208 / 230V, 1-Phase, 60 Hz
Recommended Fuse/Breaker Size.......................30 A
Voltage
Indoor - Outdoor S1-S2 ......................AC 208 / 230V
Indoor - Outdoor S2-S3 ............................DC24V
Indoor - Remote Controller..........................DC12V
OPERATING CONDITIONS
Indoor Intake Air Temp. Outdoor Intake Air Temp.
Cooling Maximum 95ºF (35ºC) DB, 71ºF (22ºC) WB 115ºF (46ºC) DB
Minimum 67ºF (19ºC) DB, 57ºF (14ºC) WB 0ºF** (-18ºC) DB
** With optional wind bafe accessory installed. If not installed, the minimum
temperature will be 23ºF (-5ºC) DB.
Indoor Unit: PEAD-A36AA4
Outdoor Unit: PUY-A36NHA4
SUBMITTAL DATA: PEAD-A36AA4 & PUY-A36NHA4. . . . . . . . . . . . .36,000 BTU/H HORIZONTAL-DUCTED AIR CONDITIONING SYSTEM
GENERAL FEATURES
• Horizontal-ducted indoor unit features medium static pressure
capability
• Thin body: 9-7/8" high
• Built-in drain mechanism for condensate removal; lifts to 27-9/16"
• Air lter is included with indoor unit
• Quiet operation—both indoor and outdoor units
• Automatic fan speed control
• Auto restart following a power outage
• Self-check function—integrated diagnostics
• Knockout for ventilation air
• Limited warranty: ve years on parts and defects and seven years
on compressors
Indoor Unit
MCA ............................................ 3.30 A
Fan Type x Quantity ......................... Sirocco fan x 2
Fan Motor Type ............. Direct-driven DC Brushless Motor
Fan Motor ....................................2.64 F.L.A.
Fan Motor Output ..................................244 W
Airow (Lo - Mid - Hi) ............. 847 - 1,024 - 1,201 Dry CFM
777 - 953 - 1,130 Wet CFM
Air Filter .........................Polypropylene Honeycomb
External Static Pressure...... 0.14 - 0.20 - 0.28 - 0.40 - 0.60"WG
Sound Pressure Level (Lo - Mid - Hi) ..........33 - 38 - 42 dB(A)
SHF ............................................. 0.75
Moisture Removal................................ 7.9 pt./h
DIMENSIONS UNIT INCHES / MM
W 55-1/8 / 1,400
D 28-7/8 / 732
H 9-7/8 / 250
Weight ....................................91 lbs. / 41 kg
External Finish .......................Galvanized-steel Sheet
Field Drainpipe Size O.D...................... 1-1/4"/ 32 mm
Outdoor Unit
Compressor ...................DC Inverter-driven Twin Rotary
MCA ..............................................25 A
MOCP.............................................40 A
Fan Motor .....................................0.75 F.L.A.
Sound Pressure Level (Cooling).....................48 dB(A)
DIMENSIONS INCHES / MM
W 37-3/8 / 950
D 13 + 1-3/16 / 330 + 30
H 37-1/8 / 943
Weight ...................................163 lbs. / 74 kg
External Finish ......................Munsell No. 3Y 7.8 / 1.1
Refrigerant Type ...................................R410A
Refrigerant Pipe Size O.D.
Gas Side ................................5/8" / 15.88 mm
Liquid Side................................3/8" / 9.52 mm
Max. Refrigerant Pipe Length..................... 165' / 50 m
Max. Refrigerant Pipe Height Difference ............ 100' / 30 m
Connection Method ................................Flared
OPTIONAL ACCESSORIES
Indoor Unit
□ Filter Box with MERV 13 Filters (FBM2-4)
Outdoor Unit
□ Drain Pan (PAC-SG64DP)
□ Drain Socket (PAC-SG61DS)
□ Three-pole Disconnect Switch (TAZ-MS303)
□ Wind Bafe (WB-PA2)
□ Air Outlet Guide (PAC-SG59SG)
□ Mounting Base (DSD-400N)
□ Mounting Pad (ULTRILITE2)
□ Wall-mounting Brackets (CWMB1)
Controller Options
□ Wall-mounted Wired Remote Controller (PAR-21MAA)
□ M-NET Adapter (PAC-SF81MA)
□ CN51 Connector for Multiple Remote Controller Adapters/Duct Fan
Controller (PAC-725AD)
□ CN32 Connector for Remote On/Off (PAC-715AD)
□ Remote Temperature Sensor (PAC-SE41TS)
□ Remote Operation Adapter - Display and On/Off (PAC-SF40RM)
□ Handheld Wireless Remote Controller (PAR-FL32MA; req.
PAR-SA9CA)
□ Wireless Signal Receiver Module (PAR-SA9CA)
□ Lockdown Bracket for Handheld Controller (RCMKP1CB)
□ Control/Service Tool (PAC-SK52ST)

INDOOR UNIT PEAD-A36AA4 FAN PERFORMANCE AND AIRFLOW RATES
0
[0]
50
[0.201]
100
[0.401]
150
[0.602]
Airflow rate (m3/min)[cfm]
External static pressure (Pa)[in.WG]
0
[0]
50
[0.201]
100
[0.401]
150
[0.602]
Airflow rate (m3/min)[cfm]
External static pressure (Pa)[in.WG]
0
[0]
10
[0.040]
20
[0.080]
30
[0.120]
40
[0.161]
50
[0.201]
60
[0.241]
70
[0.281]
Airflow rate (m3/min)[cfm]
External static pressure (Pa)[in.WG]
10
[353]
15
[530]
20
[706]
25
[883]
30
[1059]
35
[1236]
40
[1412]
45
[1589]
10
[353]
15
[530]
20
[706]
25
[883]
30
[1059]
35
[1236]
40
[1412]
45
[1589]
10
[353]
15
[530]
20
[706]
25
[883]
30
[1059]
35
[1236]
40
[1412]
45
[1589]
10
[353]
15
[530]
20
[706]
25
[883]
30
[1059]
35
[1236]
40
[1412]
45
[1589]
10
[353]
15
[530]
20
[706]
25
[883]
30
[1059]
35
[1236]
40
[1412]
45
[1589]
0
[0]
50
[0.201]
100
[0.401]
150
[0.602]
200
[0.803]
Airflow rate (m3/min)[cfm]
External static pressure (Pa)[in.WG]
0
[0]
10
[0.040]
20
[0.080]
30
[0.120]
40
[0.161]
50
[0.201]
60
[0.241]
70
[0.281]
80
[0.321]
100
[0.401]
90
[0.361]
Airflow rate (m3/min)[cfm]
External static pressure (Pa)[in.WG]
Limit
Low
Middle
High
Rated point
Limit
Low
Middle
High
Rated point
Limit
Low
Middle
High
Rated point
Limit
Low
Middle
High
Rated point
Limit
Low
Middle
High
Rated point
PEAD-A36AA4
(External static pressure 35Pa [0.14 in. WG]) 208-230V 60Hz
PEAD-A36AA4
(External static pressure 50Pa [0.2 in. WG]) 208-230V 60Hz
PEAD-A36AA4
(External static pressure 70Pa [0.3 in. WG]) 208-230V 60Hz
PEAD-A36AA4
(External static pressure 100Pa [0.4 in. WG]) 208-230V 60Hz
PEAD-A36AA4
(External static pressure 150Pa [0.6 in. WG]) 208-230V 60Hz

DIMENSIONS: PEAD-A36AA4
3-ø2.9(1/8) mounting hole
Air filter
Refrigerant piping
flare connection (liquid)
Liquid pipe
Gas pipe
ø9.52
(3/8)
ø15.88
(5/8)
Ventilation air intake ø100(3-15/16) knock out hole
A
Model
1400
1100
PEAD-A24, 30AA4
PEAD-A36, 42AA4
GFBCDE
1000
14
136015001454
1154 1060 11
1200
1300 1358
1058
Suspension bolt hole
4-14x30(9/16X1-3/16) Slot
(O.D.ø32(1-1/4))
Drain pipe
Drain pipe(O.D.ø32(1-1/4))(Spontaneous draining)
Terminal block(Remote controller transmission line)
Terminal block(Indoor/Outdoor connection line)
Control box
Drain pump
Refrigerant piping
flare connection (gas)
1
12
2
Drain pipe(O.D. ø32(1-1/4))
(Emergency draining)
2xE-ø2.9(1/8)
Air inlet
Air outlet
2X2-ø2.9(1/8)
(4-15/16)
ø125
120
120
57(2-1/4)
78(3-1/8)
200(7-7/8)
378(12-7/16)
Unit:mm(in.)
(43-5/16)
(55-1/8) (57-1/4)
(45-7/16) (47-1/4)
(59-1/16)
(53-9/16)
(41-3/4) (39-3/8)
(51-3/16) (53-1/2)
(41-11/16)
21(7/8)
(8-5/16)
(5-3/8)
135
153(6-1/16)
(2-11/16)
(5-3/8)
(Suspension bolt pitch)
21 G
18(3/4) 210
40(1-5/8) 40(1-5/8)
250(9-7/8)
40(1-5/8)
33(1-5/16) 122(4-13/16)
D(Duct)
20(13/16)
100(3-15/16)X(E-1)=F30(1-3/16)
100(3-15/16)
217(8-9/16)
41(1-5/8)
100(3-15/16)
356(1/16)
67136
732(28-7/8)
700(27-9/16)32(1-5/16)
238(9-3/8)
10(7/16)
23(15/16)178(7-1/16)
643(25-3/8)
23(15/16)
C
B(Suspension bolt pitch)
A
10(7/16)
57(2-1/4)
58(2-5/16)
15(5/8)
Note 4
10
12
1280
330 4
49
54 320 5
990
MLKJN
1200
1500
H
N-ø2.9(1/8)
(4-7/16) (4-7/16)
(50-7/16)
(39)
(12-5/8)
(13)(1-15/16)
(2-3/16)(59-1/16)
(47-1/4)
-7/16
0
(2-9/16 )
(11-13/16)
(27-9/16)
(11-13/16)
(9-7/8~11-13/16)
Less than 700
Less than 300
(Actual length)
65
0 -10
JKX(L-1)=MJ6(1/4)
112 112 11(7/16)
K
50(2)
250~300
450(17-3/4)
50(2)
H
777(30-5/8)
450(17-3/4)
More than 300
More than 20(13/16)
More than 10(7/16)
<accessory>
Drain hose (I.D.ø32(1-1/4))
Access door
Note2
Make the access door at the appointed position properly for service maintenance.
Ceiling surface Access door
Required space for service and maintenance
NOTE 1. Use M10 screw for the Suspension bolt (field supply).
2. Keep the service space for the maintenance at the bottom.
3. This chart indicates for PEAD-A24·30·36·42AA4 models,which have 2 fans.
4. In case of the inlet duct is used, remove the air filter (supplied with the unit), then install a filter (field supplied) at suction side.

3400 Lawrenceville Suwanee Rd
Suwanee, GA 30024
Tele: 678-376-2900 • Fax: [phone]
Toll Free: 800-433-4822 (#3)
www.mehvac.com
Specications are subject to change without notice.
C SD - PEAD-A36AA4 - PUY-A36NHA4 - 201011 © MITSUBISHI ELECTRIC / HVAC 2010
DIMENSIONS: PUY-A36NHA4
Clearance Area
