Mitsubishi Electric CC-Link-AnyWire Bitty Bridge User manual

CC-Link-AnyWire Bitty Bridge Module
User's Manual
-NZ2AW1C1BY

1
COPYRIGHT
This document is protected by the law of copyright, whereby all rights established therein remain with the company
Mitsubishi Electric Corporation. Reproduction of this document or parts of this document is only permissible within the
limits of the legal determination of Copyright Law. Alteration or abridgement of the document is not permitted without
the explicit written approval of the company Mitsubishi Electric Corporation.
PRECAUTIONS REGARDING WARRANTY AND
SPECIFICATIONS
The NZ2AW1C2D2 was jointly developed and manufactured by Mitsubishi and Anywire Corporation.
Note that there are some precautions regarding warranty and specifications of this product.
<Warranty>
<Application of the EMC Directive>
*1 The bridge module with a serial number where the sixth digit is "3" or later complies with this standard.
<Application of the UL/cUL standards>
*2 The bridge module with a serial number where the sixth digit is "3" or later complies with this standard.
Item NZ2AW1C1BY
Other programmable controller
products
(e.g.: MELSEC-Q series)
Repair term after discontinuation of
production 1 year 7 years
Item NZ2AW1C1BY
Other programmable controller
products
(e.g.: MELSEC-Q series)
Applicable EMC standard EN61131-2*1 EN61131-2
Item NZ2AW1C1BY
Other programmable controller
products
(e.g.: MELSEC-Q series)
Applicable UL standard/cUL standard UL508*2
CSA22.2*2
UL508
CSA22.2

2
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention
to safety to handle the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of the
programmable controller system, refer to the user's manual for the CPU module used.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to
serious consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future
reference.
[Design Precautions]
[Design Precautions]
WARNING
●An AnyWire Bitty system has no control function for ensuring safety.
●When a communication failure occurs in the network, data in the master module are held. Check the
communication status information and configure an interlock circuit in the sequence program to
ensure that the entire system will operate safely.
CAUTION
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●Configure safety circuits, such as an emergency stop circuit and interlock circuit, external to the
AnyWire Bitty system.
WARNING
CAUTION
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in minor or moderate injury or property damage.

3
[Installation Precautions]
[Wiring Precautions]
CAUTION
●Use the module in an environment that meets the general specifications in this manual. Failure to do
so may result in electric shock, fire, malfunction, or damage to or deterioration of the product.
●Securely fix the module with a DIN rail.
●Do not directly touch any conductive parts and electronic components of the module. Doing so can
cause malfunction or failure of the module.
CAUTION
●Shut off the external power supply (all phases) used in the system before wiring. Failure to do so may
cause the module to fail or malfunction.
●Individually ground the FG and LG terminals of the programmable controller with a ground resistance
of 100 ohms or less. Failure to do so may result in electric shock or malfunction.
●Check the rated voltage and terminal layout before wiring to the module, and connect the cables
correctly. Connecting a power supply with a different voltage rating or incorrect wiring may cause a fire
or failure.
●Tighten the terminal screw within the specified torque range. Undertightening can cause short circuit
or malfunction. Overtightening can damage the screw and/or module, resulting in drop, short circuit,
or malfunction.
●Prevent foreign matter such as dust or wire chips from entering the module. Such foreign matter can
cause a fire, failure, or malfunction.
●Incorrect wiring may damage modules and external devices. Adjust a cable length and a module
position to prevent disconnection of a connector type terminal block or a cable.
●Do not solder stranded wires of a cable when connecting them to the terminal block. Doing so may
cause poor contact.
●The power supply voltage of remote slave modules may be insufficient due to a voltage drop in the
power supply line. Connect an external power supply so that the voltage of remote slave modules is
ensured.
●Do not apply the 24VDC power before wiring the entire AnyWire Bitty system. If the power is applied
before wiring, normal data transmission is not guaranteed.
●Use 24VDC stabilized power supplies for devices in the AnyWire Bitty system.
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Failure to do so may result in malfunction due to noise.
●Place the cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be pulled,
resulting in damage to the module or cables or malfunction due to poor contact.
●When disconnecting the cable from the module, do not pull the cable by the cable part. When
disconnecting a cable connected to a terminal block, loosen the screws on the terminal block first
before removing the cable. If a cable is pulled while being connected to the module, it may cause the
module to malfunction or damage the module and the cable.

4
[Startup and Maintenance Precautions]
[Startup and Maintenance Precautions]
[Disposal Precautions]
WARNING
●Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction.
●Shut off the external power supply (all phases) used in the system before cleaning the module or
retightening the terminal screws or module fixing screws. Failure to do so may result in electric shock.
Undertightening the terminal screws can cause short circuit or malfunction. Overtightening can
damage the screw and/or module, resulting in drop, short circuit, or malfunction.
CAUTION
●Do not disassemble or modify the modules. Doing so may cause failure, malfunction, injury, or a fire.
●Shut off the external power supply (all phases) used in the system before mounting or removing a
module. Failure to do so may cause the module to fail or malfunction.
●Before handling the module, touch a grounded metal object to discharge the static electricity from the
human body. Failure to do so may cause the module to fail or malfunction.
CAUTION
●When disposing of this product, treat it as industrial waste.

5
CONDITIONS OF USE FOR THE PRODUCT
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;
and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the
case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL
RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY
INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE
OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR
WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL
BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the
public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality
assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,
Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and
Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or
more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific
applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or
other safety features which exceed the general specifications of the PRODUCTs are required. For details, please
contact the Mitsubishi representative in your region.

6
COMPLIANCE WITH EMC AND LOW VOLTAGE
DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low Voltage Directives when incorporated
into other machinery or equipment, certain measures may be necessary. Please refer to one of the following
manuals.
• User's manual for the CPU module or head module used
• Safety Guidelines (This manual is included with the CPU module, base unit, or head module.)
The CE mark on the side of the programmable controller indicates compliance with EMC and Low Voltage
Directives.
(2) Additional measures
To ensure that this product maintains EMC and Low Voltage Directives, please refer to the following.
Page 63, Appendix 1

7
Memo

CONTENTS
8
CONTENTS
COPYRIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
PRECAUTIONS REGARDING WARRANTY AND SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CHAPTER 1 OVERVIEW 11
CHAPTER 2 SPECIFICATIONS 13
2.1 General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2.1 Performance specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.2.2 Scope of the power supply for the transmission cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2.2.3 Power supply sequence and handling of I/O data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
2.3 Applicable System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.3.1 Applicable master module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
2.3.2 Differences in parameter settings depending on the CC-Link versions . . . . . . . . . . . . . . . . . .20
2.3.3 CC-Link dedicated instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
2.4 External Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.5 Part Names. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.6 Checking Function Version and Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
CHAPTER 3 MODULE MOUNTING 25
CHAPTER 4 CONNECTIONS 27
4.1 CC-Link Side Terminal Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1.1 Connecting a CC-Link dedicated cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
4.1.2 Cable processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
4.2 AnyWire Bitty Side Terminal Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4.2.1 Description of the terminals of an AnyWire Bitty side terminal block . . . . . . . . . . . . . . . . . . . .29
4.2.2 Cable processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
4.3 Terminating Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
CHAPTER 5 SWITCH SETTING 32
5.1 CC-Link Side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.2 AnyWire Bitty Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
CHAPTER 6 MEMORY MAPS 35
6.1 Remote I/O Signal List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.2 Remote Register List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.3 Correspondence Between the Remote Register and Address. . . . . . . . . . . . . . . . . . . . . . . . . 38
6.4 Error Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

9
CHAPTER 7 PREPARATION FOR OPERATION 40
7.1 Setting by the Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.2 Setting on the Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
CHAPTER 8 POWER-ON AND PART INDICATION 45
8.1 LED Indication Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
CHAPTER 9 MONITORING FUNCTION 48
9.1 Automatic Address Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
9.1.1 Performing the automatic address detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
9.2 Monitoring Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
CHAPTER 10 CC-LINK I/O RESPONSE TIME 50
CHAPTER 11 TRANSMISSION TIME 52
11.1 Transmission Cycle Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
11.1.1 Transmission cycle time of the NZ2AW1C1BY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
11.1.2 Effects of the double check system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
11.2 Transmission Delay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
11.2.1 Slave module (input) to bridge module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
11.2.2 Bridge module to slave module (output) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
CHAPTER 12 TROUBLESHOOTING 55
12.1 Troubleshooting Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
12.1.1 When transmission does not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
12.1.2 When the ERR.LED on the CC-Link master station is flashing . . . . . . . . . . . . . . . . . . . . . . . .57
12.1.3 When the LINK LED on the bridge module does not flash. . . . . . . . . . . . . . . . . . . . . . . . . . . .59
12.1.4 When the LINK LED on the slave module does not flash . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
12.1.5 When the slave module does not operate as expected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
12.2 Symptom checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
APPENDICES 63
Appendix 1 EMC and Low Voltage Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Appendix 1.1 Requirements for compliance with the EMC Directive . . . . . . . . . . . . . . . . . . . . . . . . .63
Appendix 1.2 Requirements for compliance with the Low Voltage Directive . . . . . . . . . . . . . . . . . . .66
Appendix 2 Functions Added and Modified with Version Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . 67
REVISIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

10
TERMS
Unless otherwise specified, this manual uses the following terms.
Term Description
AnyWire Bitty
This system provides a high-speed and highly-reliable sensor network. An original transmission
system provided by Anywire Corporation. This module supplies power using a transmission line,
minimizing wiring for machines and equipment.
Buffer memory A memory in an intelligent function module, where data (such as setting values and monitoring values)
exchanged with a CPU module are stored
GX Developer The product name of the software package for the MELSEC programmable controllers
GX Works2
Intelligent function module A Q-series module other than CPU modules, power supply modules, and I/O modules, which is
mounted on a base unit
Master module A module that controls a data link system.
One master module is required for one system.
NZ2AW1C1BY The abbreviation for the CC-Link-AnyWire Bitty bridge module, NZ2AW1C1BY
Programming tool A generic term for GX Works2 and GX Developer
Remote I/O module A remote module that exchanges I/O signals (bit data) with an external device
RWr Remote register (read area for CC-Link).
Information input in 16-bit units from the slave station to the master station.
RWw Remote register (write area for CC-Link).
Information output in 16-bit units from the master station to the slave station.
RX Remote input (for CC-Link).
Information input in bit units from the slave station to the master station.
RY Remote output (for CC-Link).
Information output in bit units from the master station to the slave station.
Slave module A generic term for modules that communicate data with a bridge module
Terminating unit A waveform shaper
Transmission cycle time A data sampling interval

11
CHAPTER 1 OVERVIEW
1
CHAPTER 1 OVERVIEW
This manual describes the specifications, part names, and settings of the NZ2AW1C1BY CC-Link–AnyWire Bitty
bridge module (hereafter abbreviated as the NZ2AW1C1BY) used as a remote device station in the CC-Link system.
This module, a product of the joint development project with Anywire Corporation, allows the AnyWire Bitty system to
be connected with CC-Link.
The AnyWire Bitty system provides a high-speed and highly reliable sensor network system.
(1) Features of the NZ2AW1C1BY
The NZ2AW1C1BY is the bridge module used for the connection between AnyWire Bitty having the DC
transmission cable system and CC-Link.
Disconnections can be detected even when the wiring is branched.
Up to 256 remote input points and 256 remote output points can be connected to one NZ2AW1C1BY module.
(2) Configuration of the AnyWire Bitty system
For the number of connectable slave modules, refer to the following.
Page 14, Section 2.2.1
AnyWire Bitty
MELSEC-Q series
CC-Link
AnyWire Bitty
remote I/O module (output)
*1
AnyWire Bitty
remote I/O module (input)
*1
AnyWire Bitty
terminating unit
*1
*1: Manufactured by Anywire Corporation

12
Memo

13
CHAPTER 2 SPECIFICATIONS
2
2.1 General Specifications
CHAPTER 2 SPECIFICATIONS
2.1 General Specifications
*1 Do not use or store the programmable controller under pressure higher than the atmospheric pressure at sea level.
Doing so may cause malfunction. When using the programmable controller under pressure, please consult your local
Mitsubishi representative.
*2 This indicates the section of the power supply to which the equipment is assumed to be connected between the public
electrical power distribution network and the machinery within premises. Category II applies to equipment for which
electrical power is supplied from fixed facilities. The surge voltage withstand level for up to the rated voltage of 300V is
2500V.
*3 This index indicates the degree to which conductive material is generated in terms of the environment in which the
equipment is used. In pollution degree 2, only non-conductive pollution occurs. A temporary conductivity caused by an
accidental condensation may also occur occasionally.
Item Specifications
Operating ambient
temperature 0 to 55
Storage ambient
temperature -25 to 75
Operating ambient
humidity 10 to 90%RH, non-condensing
Storage ambient
humidity
Vibration resistance
Compliant with
JIS B 3502 and
IEC 61131-2
Frequency Constant
acceleration Half amplitude No. of sweeps
Under
intermittent
vibration
5 to 8.4Hz 3.5mm 10 times each in
X, Y, and Z
directions
8.4 to 150Hz 9.8m/s2
Under
continuous
vibration
5 to 8.4Hz 1.75mm

8.4 to 150Hz 4.9m/s2
Shock resistance Compliant with JIS B 3502 and IEC 61131-2 (147m/s2, 3 times each in X, Y, and Z directions)
Operating
atmosphere No corrosive gas
Operating altitude*1 0 to 2000m
Installation location Inside the control panel
Overvoltage
category*2 II or less
Pollution degree*3 2 or less

14
2.2 Performance Specifications
2.2.1 Performance specifications
Classification Item Specifications
CC-Link side
Station type Remote device station
CC-Link version Ver. 1.10
Communication speed 10M/5M/2.5M/625K/156Kbps (switching by transmission speed setting switch)
Number of occupied stations
Remote device stations 1 to 4 are occupied according to the setting of the specification
selection switch.
1 station (RX/RY number of occupied points: 32 points) (RWr/RWw 4/4)
2 stations (RX/RY number of occupied points: 64 points) (RWr/RWw 8/8)
3 stations (RX/RY number of occupied points: 96 points) (RWr/RWw 12/12)
4 stations (RX/RY number of occupied points: 128 points) (RWr/RWw 16/16)
Number of connectable
modules Up to 42
Connection location of
NZ2AW1C1BY No restriction
Connection cable*1 CC-Link dedicated cable/High-performance CC-Link dedicated cable/
Ver.1.10- compatible CC-Link dedicated cable
AnyWire Bitty side
Transmission clock 27.0kHz
Maximum transmission
distance (total length)*2 100m
Number of connectable
slave modules Up to 128 (varies depending on the current consumption of each slave module)
Transmission system DC power supply transmission total frame cyclic system
Connection type Bus topology (multidrop system, T-branch system, tree branch system)
Transmission protocol Dedicated protocol (AnyWire Bitty)
Error control Double-check system
Number of connected I/O
points Up to 512 points (256 input points/256 output points)
RAS function Disconnected transmission cable location detection function, transmission cable short
detection function, transmission cable voltage drop detection function
Transmission cable (DP,
DN)*2
• UL-compliant general-purpose 2-wire cable (VCTF, VCF 1.25, 0.75,
temperature rating 70or higher)
• UL-compliant general-purpose wire (1.25, 0.75, temperature rating 70or
higher)
Power cable (24V, 0V)
• UL-compliant general-purpose 2-wire cable (VCTF, VCT 0.75to 2.0,
temperature rating 70or higher)
• UL-compliant general-purpose wire (0.75to 2.0, temperature rating 70or
higher)
Maximum number of writes
to EEPROM Up to 100000 times
Common
Power supply
Voltage 21.6 to 27.6VDC (24VDC -10 to +15%), ripple voltage 0.5Vp-p or lower
Recommended voltage 26.4V (24VDC +10%)
Current
Module current consumption: 0.2[A] (When 128 slave modules are connected, the
load current is not included.)
Transmission cable supply current: Up to 2[A]*2
External dimensions 100mm (H) 40mm (W) 66mm (D)
Weight 0.16kg

15
CHAPTER 2 SPECIFICATIONS
2
2.2 Performance Specifications 2.2.1 Performance specifications
*1 Ver.1.10- compatible CC-Link dedicated cable, CC-Link dedicated cable (Ver.1.00), and high-performance CC-Link
dedicated cable cannot be used at the same time. If those cables are used at the same time, normal transmission is not
guaranteed. In addition, use the terminating resistor according to the type of cable used.
*2 Refer to the table below for the relationship between the total length, the diameter of transmission cable (DP, DN), and
the transmission cable supply current.
When a total length exceeds 50m, use isolated slave modules. For some slave modules with cables, the wire diameter
of module-integrated transmission cable (DP, DN) may be 0.75or less. However, they can be used without any
problem, provided that the diameter of transmission cable (DP, DN) meets the following requirements.
Diameter of transmission
cable (DP, DN)
Supply current for transmission cable
Total length of 50m or less Total length of 50m to 100m
1.25Up to 2A Up to 0.7A
Non-isolated slave modules cannot be used.
0.75Up to 1A Only a fool-proof terminal can be connected (manufactured by
Anywire Corporation).

16
2.2.2 Scope of the power supply for the transmission cable
To implement the AnyWire Bitty system, all conditions specified by the following calculation formulas 1) to 3) have to
be met.
(1) Description of calculation formula 1)
(a) Related constant of non-isolated slave modules (Ihin, Iho)
For non-isolated slave modules, current required for the internal control circuit and connected load is supplied
through the transmission cable (DP, DN).
Ihin(A)
= Current consumption of non-isolated input slave module/I/O combined slave module
= Current consumption of non-isolated input slave module/I/O combined slave module + Current consumption
of connected load (three-wire sensor) Number of points
Iho(A)
= Current consumption of non-isolated output slave module
= Current consumption of non-isolated output slave module + Current consumption of connected load 
Number of points
●The 24VL and 0VL terminals of a slave module are used to supply the power to the connected load. For details, refer to
the manual for the slave module used.
●For the current consumption of non-isolated slave modules, refer to the manual for the slave module used.
Item Description
Calculation formula 1) I(A) = (Ihin m) + (Iho n) + (Izdin p) + (Izdo q) The maximum value of the transmission cable supply current
The number of connected modules by type: m, n, p, q
Calculation formula 2) Vm(V) - V(V) 20V
Calculation formula 3) Vm(V) - V(V) The lowest limit of the allowable voltage range for connected load
Non-isolated slave module
Control circuit
Power supply
generation
Connected load
24VDC external
power supply
24V 0V
24V 0V
24VL 0VL 0 1 n
DN DP
DN DP
NZ2AW1C1BY

17
CHAPTER 2 SPECIFICATIONS
2
2.2 Performance Specifications 2.2.2 Scope of the power supply for the transmission cable
(b) Related constant of isolated slave modules (Izdin, Izdo)
For isolated slave modules, only the current required for the internal control circuit is supplied through the
transmission cable (DP, DN), whereas that for the connected load is supplied from a 24VDC external power
supply.
Izdin(A) = Internal current consumption of isolated input slave module/I/O combined slave module
Izdo(A) = Internal current consumption of isolated output slave module
●In isolated slave modules, current consumption of the connected load is not subject to the current restriction condition for
the AnyWire Bitty system.
●For the current consumption of isolated slave modules, refer to the manual for the slave module used.
(c) Supply current for transmission cable (I (A))
The supply current for the transmission cable of the AnyWire Bitty system is determined by the following
formula.
I(A) = (Ihin m) + (Iho n) + (Izdin p) + (Izdo q)
Number of connectable modules: m, n, p, q
(d) Maximum value of transmission cable supply current
For the maximum value of transmission cable supply current, refer to the following.
Page 14, Section 2.2.1
Isolated slave module
Control circuit
Load driver circuit (photocoupler isolation)
Connected load
24VDC external
power supply
24VDC external
power supply
24V 0V
24V 0V
24V 0V
24V 0V
01 n
DN DP
DN DP
NZ2AW1C1BY

18
(2) Description of calculation formulas 2) and 3)
(a) Vm: Supply voltage to bridge module
Voltage: 24VDC -10 to +15% (21.6 to 27.6VDC), Ripple 0.5Vp-p or less
Recommended voltage: 26.4V
(b) V(V): Voltage drop between lines
V(V) = Transmission cable supply current I (A) Line resistance R ()
Line resistance R() = Line length (m) Conductor resistance (/m) 2
• Line diameter 1.25Conductor resistance 0.015/m
• Line diameter 0.75Conductor resistance 0.025/m
(3) Calculation example
The example shows how to check whether the total length of 50m is sufficient for configuring the system with the
following conditions.
(a) Condition
(b) Calculation result
Based on the above calculation results of calculation formulas 1) through 3), system configuration is found
impossible.
However, changing the diameter of the connection cable and the power supply for the NZ2AW1C1BY enables
the system to be configured.
Item Condition
Non-isolated remote I/O module (input)
• Number of I/O points: 4 points
• Module current consumption: 29mA
• Number of modules: 12
Connected load (three-wire sensor)
• Three-wire sensor current consumption: 13mA
• Number of sensors: 4
• Power voltage: 24V 10%
Diameter of transmission cable (DP, DN) Cable diameter: 0.75
Power supply for the NZ2AW1C1BY Power voltage: 24V
Item Condition
Calculation formula 1)
(Ihin(A) m) = I(A) Maximum value of transmission cable supply current
(0.029 + (0.013 4)) 12 = 0.972A 1A
Satisfied
Calculation formula 2)
Vm(V) - V(V) 20V
24 - (0.972 50 0.025 2) = 24 - 2.43 = 21.57V 20V
Satisfied
Calculation formula 3)
Vm(V) - V(V) The lowest limit of the allowable voltage range for connected load
The lowest limit of the allowable voltage range for connected load = 24 - 24 0.1 = 21.6V
21.57V < 21.6V
Not satisfied
