41 LINEAR ENCODER
1.1 Shielding CN2, CN2A, CN2B, and CN2C connectors
1LINEAR ENCODER
Precautions
• While the linear encoder and the linear servo motor should be oil and dust proofed, oil and dust proofing are especially
important for the linear encoder. Contact the manufacturer of the linear encoder being used.
• Use the linear encoder cables specified in this chapter. Using products other than those specified may cause a malfunction.
• Contact the manufacturer of the linear encoder being used for information on specifications, performance and guarantees.
• If the linear encoder is incorrectly installed, an alarm or position mismatch may occur. In such situations, refer to the
following check points and ensure that the linear encoder is installed in a suitable environment.
Check that the gap between the head and scale is correct.
Check that the scale head is not rolling or yawing (i.e., that the scale head is not loose).
Check the surface of the scale for dust and scratches.
Check that the vibration and temperature are within the specified range.
Check that the speed is within the permissible range without overshooting.
• Refer to the following page for combinations of linear encoders and servo amplifiers.
Page 4 Compatible linear encoder list
1.1 Shielding CN2, CN2A, CN2B, and CN2C
connectors
• When using 3M shell kits (36310-3200-008 or 36310-F200-008) or the Molex connector set (54599-1019), ensure the
external conductor of the shielded cable is firmly in contact with the ground plate before attaching the connector shell.
1.2 Compatible linear encoder list
Precautions
For linear encoders that can be used with your servo amplifier, contact your local sales office.
Screw
Cable
Ground plate

1 LINEAR ENCODER
1.2 Compatible linear encoder list 5
1
For information on suitable operating environments and linear encoder specifications such as temperature, vibration
resistance, and IP ratings, contact the product manufacturer.
Linear encoder type Manufacturer Model Resolution Rated
speed
*1
Effective
measurement
length
(Maximum) *2
Communication
method
Absolute
position
detection
system
Compatible
with
Mitsubishi
Electric
serial
interface
Absolute
position
type
Magnescale SR77 0.05 μm/0.01
μm
3.3 m/s 2040 mm Two-wire type 
SR87 3040 mm
SR27A 0.01 µm 3.3 m/s 2040 mm Two-wire type/four-
wire type *5
SR67A 3640 mm
Mitutoyo AT343A 0.05 µm 2.0 m/s 3000 mm Two-wire type
AT543A-SC 2.5 m/s 2200 mm
AT545A-SC 20 µm/4096
(Approx.
0.005 µm)
2.5 m/s 2200 mm
ST743A 0.1 µm 5.0 m/s 6000 mm
ST744A
ST748A
Renishaw RESOLUTE RL40M 1 nm/50 nm 100 m/s 10000 mm Two-wire type
EVOLUTE EL40M 50 nm/100
nm/500 nm
100 m/s 3020 mm Two-wire type
Heidenhain LC 495M 0.001 μm/
0.01 μm
3.0 m/s 2040 mm Four-wire type *5
LC 195M 4240 mm
LIC 4193M 0.005 μm/
0.01 μm
10.0 m/s 3040 mm Two-wire type/four-
wire type *5
LIC 4195M 28440 mm
LIC 4197M 6040 mm
LIC 4199M 1020 mm
LIC 2197M 0.05 μm/0.1
μm
10.0 m/s 6020 mm Two-wire type/four-
wire type *5
LIC 2199M 6020 mm
Incremental
type
Magnescale SR75 0.05 μm/0.01
μm
3.3 m/s 2040 mm Two-wire type 
SR85 3040 mm
SL710 +PL101-RM/
RHM
0.1 µm 10.0 m/s 100000 mm
SQ10 + PQ10 + MQ10 0.1 μm/0.05
μm
10.0 m/s 3800 mm Two-wire type/four-
wire type *5
Heidenhain LIDA 483 + EIB 392M
(/16384)
20 μm/16384
(approx. 1.22
nm)
4.0 m/s 3040 mm Four-wire type *5
LIDA 485 + EIB 392M
(/16384)
30040 mm
LIDA 487 + EIB 392M
(/16384)
6040 mm
LIDA 489 + EIB 392M
(/16384)
1020 mm
LIDA 287 + EIB 392M
(/16384)
200 μm/
16384
(approx. 12.2
nm)
10000 mm
LIDA 289 + EIB 392M
(/16384)
NIDEC
SANKYO
PSLH041 0.1 µm 5.0 m/s 2400 mm Two-wire type
A/B/Z-
phase
differential
output type
Not specified 0.001 μm to 5
μm *3
Depends
on the
linear
encoder
Depends on the
linear encoder
A/B/Z-phase
differential output
method *4

61 LINEAR ENCODER
1.2 Compatible linear encoder list
*1 Values are taken from manufacturer specifications. When the linear encoder is used with MELSERVO-J5 series servo amplifiers, the
rated speed is the lowest value of either the value indicated in the table or the rated speed of the servo motor.
*2 Values are taken from manufacturer specifications. The length of the encoder cable between the linear encoder and the servo amplifier
should not exceed 30 m.
*3 Select a linear encoder that has a resolution within this range.
*4 When using A/B/Z-phase differential output linear encoders, use the MR-J5-_-RJ_.
*5 When using four-wire type linear encoders in a fully closed loop system, use the MR-J5-_-RJ_. When using four-wire type linear
encoders for the scale measurement function, use the MR-J5-_-RJ_.
The following table shows the servo amplifier connectors used to connect the servo amplifier to a linear encoder.
For the MR-J5-_ servo amplifiers
*1 The MR-J4THCBL03M branch cable is required.
*2 Connect a thermistor to CN2.
*3 The MR-J4FCCBL03M branch cable is required.
*4 If the external encoder communication method is the four-wire type, CN2 cannot be used. Use the MR-J5-_-RJ_.
*5 If the external encoder communication method is the four-wire type, the MR-J5W2-_G_ cannot be used. Use the MR-J5-_G-RJ_.
*6 This operation mode can be used by servo amplifiers with a software version of A5 or later.
Operation
mode
External
encoder
communication
method
Connector
MR-J5-_A MR-J5-_A-RJ MR-J5-_G_ MR-J5-_G-RJ_ MR-J5W2-_G_ MR-J5W3-_G_
Linear servo
motor system
Two-wire type CN2 *1 CN2 *1 CN2 *1 CN2 *1 CN2A *1
CN2B *1
CN2A *1
CN2B *1
CN2C *1
Four-wire type
A/B/Z-phase
differential output
method
CN2L *2 CN2L *2 
Fully closed
loop system *6
Two-wire type CN2 *3*4 CN2L CN2 *3*4 CN2L CN2A *3*5
CN2B *3*5

Four-wire type  
A/B/Z-phase
differential output
method
Scale
measurement
function *6
Two-wire type  CN2 *3*4 CN2L CN2A *3*5
CN2B *3*5

Four-wire type 
A/B/Z-phase
differential output
method

1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type) 7
1
1.3 Linear encoder manufactured by Mitutoyo
(absolute type)
The battery for the absolute position is not required when constructing an absolute position detection system.
AT343A
Cable structure
Prepare a cable based on the following configuration diagram.
■For linear servo motors
• MR-J5-_/MR-J5W_-_G_
*1 The connection to CN2C is for the MR-J5W3-_G_. The MR-J5W2-_G_ does not have CN2C.
*2 Supplied by customer
*3 For thermistor signal connectors, change the connection method depending on the system being used.
Conditions Branch cable Encoder cable Output cable
When using an optional encoder
cable
(4) MR-J4THCBL03M
Page 74 MR-J4THCBL03M
branch cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H
encoder cable
(3) Options manufactured by
Mitutoyo *2
Part No.09BAA598A: 0.2 m
Part No.09BAA598B: 2 m
Part No.09BAA598C: 3 m
When fabricating the encoder cable (2) MR-ECNM connector set
Page 9 Encoder cable 1
When not using a branch cable (5) MR-ECNM connector set
Page 10 Encoder cable 2
CN2B
CN2A
CN2
CN2C
*1
MR-J5W_-_G_
MR-J5-_
(2)
(1)
(3)
CN2 (4) SCALE
THM
*3
(5)
AT343A
Linear servo motor thermistor
Branch cable
Linear encoder
Linear servo motor thermistor
Encoder cable 1
or
Encoder cable 2

81 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type)
• MR-J5-_-RJ_
*1 Supplied by customer
*2 For thermistor signal connectors, change the connection method depending on the system being used.
■For fully closed loop system and scale measurement function
• MR-J5-_/MR-J5W_-_G_
*1 Supplied by customer
Conditions Branch cable Encoder cable Output cable
When using an optional encoder
cable
(4) MR-J4THCBL03M
Page 74 MR-J4THCBL03M
branch cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H
encoder cable
(3) Options manufactured by
Mitutoyo *1
Part No.09BAA598A: 0.2 m
Part No.09BAA598B: 2 m
Part No.09BAA598C: 3 m
When fabricating the encoder cable (2) MR-ECNM connector set
Page 9 Encoder cable 1
When not using a branch cable (5) MR-ECNM connector set
Page 10 Encoder cable 2
Conditions Branch cable Encoder cable Output cable
When using an optional encoder
cable
(4) MR-J4FCCBL03M
Page 75 MR-J4FCCBL03M
branch cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H
encoder cable
(3) Options manufactured by
Mitutoyo *1
Part No.09BAA598A: 0.2 m
Part No.09BAA598B: 2 m
Part No.09BAA598C: 3 m
When fabricating the encoder cable (2) MR-ECNM connector set
Page 9 Encoder cable 1
(2)
(1)
(3)
CN2 (4) SCALE
THM
*2
(5)
AT343A
CN2
CN2L
MR-J5-_-RJ_
Linear servo motor thermistor
Branch cable
Linear encoder
Linear servo motor thermistor
Encoder cable 1
Encoder cable 2
(2)
(1)
(3)
CN2 (4) SCALE
AT343A
CN2
MR-J5-_
CN2B
CN2A
MR-J5W_-_G_
MOTOR
Rotary servo motor encoder
Branch cable
Linear encoder
Encoder cable 1
or

1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type) 9
1
• MR-J5-_-RJ_
*1 Supplied by customer
Fabricating the encoder cable
Fabricate the encoder cable using the MR-ECNM connector set as shown below. The encoder cable may be as long as 30 m.
■Encoder cable 1
*1 Encoder cables that meet the following specifications are recommended.
*2 The signals of pins 3 and 4 of the CN2L connector are as follows.
Pin 3: MR2
Pin 4: MRR2
*3 Do not connect anything to the pins that are marked with a diagonal line. Securely connect the external conductor of the shielded cable
to the ground plate and fix it to the connector shell.
Page 4 Shielding CN2, CN2A, CN2B, and CN2C connectors
Conditions Encoder cable Output cable
When using an optional encoder cable (1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H encoder cable
(3) Options manufactured by Mitutoyo *1
Part No.09BAA598A: 0.2 m
Part No.09BAA598B: 2 m
Part No.09BAA598C: 3 m
When fabricating the encoder cable (2) MR-ECNM connector set
Page 9 Encoder cable 1
Wiring length Number of paired LG and P5 connections
(when the output cable is 3 m or less)
Wire size
Up to 5 m 1 pair AWG 22
Up to 10 m 2 pairs
Up to 20 m 3 pairs
Up to 30 m 5 pairs
MR-J5-_-RJ_
CN2
CN2L
(2)
(1)
(3)
AT343A
Linear encoder
Encoder cable 1
Rotary servo motor encoder
1
P5
379
4
MRR
2
LG
8610
5
4
MRR
2
LG 8
6
1
P5
5
10
37
9
MR
MR
*2
*2
P5
LG
1
2
MR
*2
MRR
*2
3
4
7
SD
1
2
8
9
LG
RQ
/RQ
FG
P5
*1
RQ
123
/RQ
456
P5
789
LG FG
Servo amplifier-side Linear encoder-side
Plate
View from the wiring side.
*3
or
View from the wiring side.
*3
Connector set: 54599-1019
(Molex)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(3M)
View from the wiring side.
Housing: 1-172161-9
Connector pin: 170359-1
(TE Connectivity or equivalent)
Cable clamp: MTI-0002
(Toa Electric Industrial)

10 1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type)
■Encoder cable 2
*1 Encoder cables that meet the following specifications are recommended.
*2 For information on wiring the linear servo motor thermistor, refer to "Power supply cable wiring diagrams" in the following manual.
Linear Servo Motor User's Manual
*3 Do not connect anything to the pins that are marked with a diagonal line. Securely connect the external conductor of the shielded cable
to the ground plate and fix it to the connector shell.
Page 4 Shielding CN2, CN2A, CN2B, and CN2C connectors
Wiring length Number of paired LG and P5 connections
(when the output cable is 3 m or less)
Wire size
Up to 5 m 1 pair AWG 22
Up to 10 m 2 pairs
Up to 20 m 3 pairs
Up to 30 m 5 pairs
P5
LG
1
2
MR
MRR
3
4
THM1
THM2
5
6
7
1
2
8LG
RQ
/RQ
P5
SD 9 FG
*1
1
P5
379
4
MRR
2
LG
8610
5
4
MRR
2
LG 8
6
1
P5
5
10
37
9
MR
MR RQ
123
/RQ
456
P5
789
LG FG
THM1
THM2
THM1
THM2
View from the wiring side.
*3
or
View from the wiring side.
*3
Connector set: 54599-1019
(Molex)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(3M)
View from the wiring side.
Housing: 1-172161-9
Connector pin: 170359-1
(TE Connectivity or equivalent)
Cable clamp: MTI-0002
(Toa Electric Industrial)
Servo amplifier-side Linear encoder-side
Plate
Linear servo motor
thermistor
*2
AWG 24 to 20

1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type) 11
1
AT543A-SC/AT545A-SC
Cable structure
Prepare a cable based on the following configuration diagram.
■For the linear servo motor
• MR-J5-_/MR-J5W_-_G_
*1 The connection to CN2C is for the MR-J5W3-_G_. The MR-J5W2-_G_ does not have CN2C.
*2 For thermistor signal connectors, change the connection method depending on the system being used.
Conditions Branch cable Encoder cable Output cable Head cable
When using an optional
encoder cable
(3) MR-J4THCBL03M
Page 74 MR-
J4THCBL03M branch cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H
encoder cable
Linear encoder accessory
Cable length: 3 m
Linear encoder accessory
Cable length: 2 m
When fabricating the
encoder cable
(2) MR-ECNM connector set
Page 14 Encoder cable 1
When not using a branch
cable
(4) MR-ECNM connector set
Page 15 Encoder cable 2
CN2C
*1
(2)
(1)
MR-J5-_
CN2B
CN2A
CN2
MR-J5W_-_G_
(4)
AT543A-SC/AT545A-SC
CN2 (3) SCALE
THM
*2
Linear encoder
Output cable Head cable
or
Linear servo motor thermistor
Encoder cable 2
Linear servo motor thermistor
Branch cable
Encoder cable 1

12 1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type)
• MR-J5-_-RJ_
*1 For thermistor signal connectors, change the connection method depending on the system being used.
Conditions Branch cable Encoder cable Output cable Head cable
When using an optional
encoder cable
(3) MR-J4THCBL03M
Page 74 MR-
J4THCBL03M branch cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H
encoder cable
Linear encoder accessory
Cable length: 3 m
Linear encoder accessory
Cable length: 2 m
When fabricating the
encoder cable
(2) MR-ECNM connector set
Page 14 Encoder cable 1
When not using a branch
cable
(4) MR-ECNM connector set
Page 15 Encoder cable 2
MR-J5-_-RJ_
CN2
CN2L
(2)
(1)
(4)
AT543A-SC/AT545A-SC
CN2 (3) SCALE
THM
*1
Linear encoder
Output cable Head cable
Linear servo motor thermistor
Encoder cable 2
Linear servo motor thermistor
Branch cable
Encoder cable 1

1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type) 13
1
■For fully closed loop system and scale measurement function
• MR-J5-_/MR-J5W_-_G_
• MR-J5-_-RJ_
Conditions Branch cable Encoder cable Output cable Head cable
When using an optional
encoder cable
(3) MR-J4FCCBL03M
Page 75 MR-
J4FCCBL03M branch cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H
encoder cable
Linear encoder accessory
Cable length: 3 m
Linear encoder accessory
Cable length: 2 m
When fabricating the
encoder cable
(2) MR-ECNM connector set
Page 14 Encoder cable 1
Conditions Encoder cable Output cable Head cable
When using an optional encoder
cable
(1) MR-EKCBL_M-H
2 m/5 m
Page 72 MR-EKCBL_M-H encoder
cable
Linear encoder accessory
Cable length: 3 m
Linear encoder accessory
Cable length: 2 m
When fabricating the encoder cable (2) MR-ECNM connector set
Page 14 Encoder cable 1
MR-J5-_
CN2B
CN2A
CN2
MR-J5W_-_G_
(2)
(1)
AT543A-SC/AT545A-SC
CN2 (3) SCALE
MOTOR
or
Linear encoder
Output cable Head cable
Rotary servo motor encoder
Branch cable
Encoder cable 1
(2)
(1)
AT543A-SC/AT545A-SC
CN2
MR-J5-_-RJ_
CN2L Linear encoder
Output cable Head cable
Rotary servo motor encoder
Encoder cable 1

14 1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type)
Fabricating the encoder cable
Fabricate the encoder cable using the MR-ECNM connector set as shown below. The encoder cable may be as long as 30 m.
■Encoder cable 1
*1 Encoder cables that meet the following specifications are recommended.
*2 The signals of pins 3 and 4 of the CN2L connector are as follows.
Pin 3: MR2
Pin 4: MRR2
*3 Do not connect anything to the pins that are marked with a diagonal line. Securely connect the external conductor of the shielded cable
to the ground plate and fix it to the connector shell.
Page 4 Shielding CN2, CN2A, CN2B, and CN2C connectors
Wiring length Number of paired LG and P5 connections
(when the output cable is 3 m or less)
Wire size
Up to 5 m 1 pair AWG 22
Up to 10 m 2 pairs
Up to 20 m 4 pairs
Up to 30 m 5 pairs
1
P5
379
4
MRR
2
LG
8610
5
4
MRR
2
LG 8
6
1
P5
5
10
37
9
MR
MR
*2
*2
P5
LG
1
2
MR
*2
MRR
*2
3
4
7
SD
1
2
8
9
RQ
/RQ
FG
*1
RQ
123
/RQ
456
789
FG
P5
(+5 V)
LG
(0 V)
Servo amplifier-side Linear encoder-side
Plate
View from the wiring side.
*3
or
View from the wiring side.
*3
Connector set: 54599-1019
(Molex)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(3M)
View from the wiring side.
Housing: 1-172161-9
Connector pin: 170359-1
(TE Connectivity or equivalent)
Cable clamp: MTI-0002
(Toa Electric Industrial)
LG (0 V)
P5 (+5 V)

1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type) 15
1
■Encoder cable 2
*1 Encoder cables that meet the following specifications are recommended.
*2 For information on wiring the linear servo motor thermistor, refer to "Power supply cable wiring diagrams" in the following manual.
Linear Servo Motor User's Manual
*3 Do not connect anything to the pins that are marked with a diagonal line. Securely connect the external conductor of the shielded cable
to the ground plate and fix it to the connector shell.
Page 4 Shielding CN2, CN2A, CN2B, and CN2C connectors
Wiring length Number of paired LG and P5 connections
(when the output cable is 3 m or less)
Wire size
Up to 5 m 1 pair AWG 22
Up to 10 m 2 pairs
Up to 20 m 4 pairs
Up to 30 m 5 pairs
RQ
123
/RQ
456
789
FG
P5
(+5 V)
LG
(0 V)
P5
LG
1
2
MR
MRR
3
4
THM1
THM2
5
6
7
1
2
8
RQ
/RQ
SD 9 FG
*1
1
P5
379
4
MRR
2
LG
8610
5
4
MRR
2
LG 8
6
1
P5
5
10
37
9
MR
MR
THM1
THM2
THM1
THM2
View from the wiring side.
Housing: 1-172161-9
Connector pin: 170359-1
(TE Connectivity or equivalent)
Cable clamp: MTI-0002
(Toa Electric Industrial)
View from the wiring side.
*3
or
View from the wiring side.
*3
Connector set: 54599-1019
(Molex)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(3M)
Servo amplifier-side Linear encoder-side
Plate
Linear servo motor
thermistor
*2
AWG 24 to 20
LG (0 V)
P5 (+5 V)

16 1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type)
ST743A/ST744A/ST748A
Cable structure
Prepare a cable based on the following configuration diagram.
■For linear servo motors
• MR-J5-_/MR-J5W_-_G_
*1 The connection to CN2C is for the MR-J5W3-_G_. The MR-J5W2-_G_ does not have CN2C.
*2 Supplied by customer
*3 In order to adjust and check signals when installing the ST743A, ST744A, or ST748A, a personal computer, signal adjustment software,
and a converter unit are required. For further details contact Mitutoyo Corp.
*4 For thermistor signal connectors, change the connection method depending on the system being used.
Conditions Branch cable Encoder cable Head cable
When using an optional
encoder cable
(4) MR-J4THCBL03M
Page 74 MR-
J4THCBL03M branch cable
(1) Options manufactured by Mitutoyo *2
Part No.06ACF117A: 5 m
Part No.06ACF117B: 10 m
Linear encoder accessory
Cable length: 1 m
When fabricating the
encoder cable
(2) MR-J3CN2 connector set
Page 20 Encoder cable 1
(3) Junction connector *2
15-pin D-SUB (female)
Shell: HDAB-15S
Plug case: HDA-CTH (Hirose
Electric)
When not using a branch
cable
(5) MR-J3CN2 connector set
Page 21 Encoder cable 2
(2)
(3)(5)
ST743A/ST744A/ST748A
CN2B
CN2A
CN2
CN2C *1
MR-J5W_-_G_
MR-J5-_
(1)
(3)
CN2 (4) SCALE
THM *4
Personal
computer
Software for
signal adjustment Conversion unit
Equipment required to adjust and check signals *3
Head cable
Linear encoder
Linear servo motor thermistor
Branch cable
Linear servo motor thermistor
Encoder cable 1
or
Encoder cable 2

1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type) 17
1
• MR-J5-_-RJ_
*1 Supplied by customer
*2 In order to adjust and check signals when installing the ST743A, ST744A, or ST748A, a personal computer, signal adjustment software,
and a converter unit are required. For further details contact Mitutoyo Corp.
*3 For thermistor signal connectors, change the connection method depending on the system being used.
Conditions Branch cable Encoder cable Head cable
When using an optional
encoder cable
(4) MR-J4THCBL03M
Page 74 MR-
J4THCBL03M branch cable
(1) Options manufactured by Mitutoyo *1
Part No.06ACF117A: 5 m
Part No.06ACF117B: 10 m
Linear encoder accessory
Cable length: 1 m
When fabricating the
encoder cable
(2) MR-J3CN2 connector set
Page 20 Encoder cable 1
(3) Junction connector *1
15-pin D-SUB (female)
Shell: HDAB-15S
Plug case: HDA-CTH (Hirose
Electric)
When not using a branch
cable
(5) MR-J3CN2 connector set
Page 21 Encoder cable 2
(2)
(3)(5)
ST743A/ST744A/ST748A
CN2
CN2L
(1)
(3)
CN2 (4) SCALE
THM *3
MR-J5-_-RJ_
Personal
computer
Software for
signal adjustment Conversion unit
Equipment required to adjust and check signals *2
Head cable
Linear encoder
Linear servo motor thermistor
Branch cable
Linear servo motor thermistor
Encoder cable 1
Encoder cable 2

18 1 LINEAR ENCODER
1.3 Linear encoder manufactured by Mitutoyo (absolute type)
■For fully closed loop system and scale measurement function
• MR-J5-_/MR-J5W_-_G_
*1 Supplied by customer
*2 In order to adjust and check signals when installing the ST743A, ST744A, or ST748A, a personal computer, signal adjustment software,
and a converter unit are required. For further details contact Mitutoyo Corp.
Conditions Branch cable Encoder cable Head cable
When using an optional
encoder cable
(4) MR-J4FCCBL03M
Page 75 MR-
J4FCCBL03M branch cable
(1) Options manufactured by Mitutoyo *1
Part No.06ACF117A: 5 m
Part No.06ACF117B: 10 m
Linear encoder accessory
Cable length: 1 m
When fabricating the
encoder cable
(2) MR-J3CN2 connector set
Page 20 Encoder cable 1
(3) Junction connector *1
15-pin D-SUB (female)
Shell: HDAB-15S
Plug case: HDA-CTH (Hirose
Electric)
(2)
ST743A/ST744A/ST748A
CN2B
CN2A
CN2
MR-J5W_-_G_
MR-J5-_
(1)
(3)
CN2 (4) SCALE
MOTOR
Personal
computer
Signal
adjustment
software Converter unit
Equipment required to adjust and check signals
*2
Head cable
Linear encoder
Rotary servo motor encoder
Branch cable
Encoder cable 1
or
