Mitsubishi Electric SD220U User manual

Energy savings considered throughout, including low-maintenance,
filter-free construction and cost-saving operation. Lamp life extended
to as long as 4,000hr when used in the “Low Lamp” mode.
*When used at the low lamp mode. Maximum lamp life at standard mode use is 3,000 hours.
Energy-saving, Cost-saving FeaturesEasy User Interface
Introducing the New Teacher’s Pet
It’s like giving a presentation in a suburban residential area in the
middle of the night! That’s the operating sound level promised by
the SD220U.
SD220U
Mobile SVGA
NEW
Simple, No-nonsense Operation
Quick Menu
Operation doesn’t get any easier than this.
The tool bar is broken down into seven
main menus and one custom menu.
Switch to sub-menus for setting more
specific operations.
The perfect projector for educational environments
Amazingly Quiet OperationUser-friendly Design
Easy Lamp Replacement
The projection lamp is located in the upper
part of the projector, so regardless of
where the unit is sitting—on a table or
suspended from the ceiling—replacement
is quick and easy.
Long-life 4,000hr* Lamp
Stand-by Mode of Less than 1W
Only 26dBA (in low mode)

MOBILE SVGA PROJECTOR
SD220U
SD220U
Screen Size and Projection Distance
As seen from the side
SD220U
Height
Hd
Projection Distance (L)
SD220U
0.55" 1-Chip DMD
800 x 600 (Total 480,000 pixels)
2200lm
2000 : 1
30" - 300"
1.9 - 2.2
Model
Display Technology
Resolution
Brightness
Contrast Ratio
Picture Size
Throw Ratio
Specifications
PC Compatibility 640 x 480 - 1280 x 1024,
True : 800 x 600, Sync on Green available
NTSC / NTSC 4.43 / PAL
(
including PAL-M, N
)
/ SECAM / PAL-60
Component Video ; 480i/p (525i/p), 576i/p (625i/p),
720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz)
Video Compatibility
160W (Shut-off Time 4000hr)with Low Mode,
180W (Shut-off Time 3000hr)with Standard Mode
Source Lamp
RGB ; mini D-sub 15pin x 1
Video ; RCA x 1
Audio ; Stereo mini jack (ø3.5mm)x 1
Input Terminals
Communication Terminal
Audio Speaker
Dimensions (W x H x D)
Weight
Power Requirements
Optional Lamp
RS-232C; mini DIN 8pin x 1
2W Mono
320 x 104 x 236 mm / 12.6 x 4.1 x 9.3 inch
3.0kg / 6.6lbs
AC 100-240V, 50/60Hz
VLT-XD221LP
Screen
Diagonal Size Width (W)Max. Zoom Min. Zoom
Height (H)
inch
24
36
48
60
90
120
150
180
Distance from screen (L)Height projected
image (Hd)
inch
40
60
80
100
150
200
250
300
cm
102
152
203
254
381
508
635
762
inch
32
48
64
80
120
160
200
240
cm
81
122
163
203
305
406
508
610
cm
61
91
122
152
229
305
381
457
inch
61
92
124
155
233
311
389
468
m
1.5
2.3
3.1
3.9
5.9
7.9
9.9
11.9
inch
68
103
138
173
260
347
434
-
m
1.7
2.6
3.5
4.4
6.6
8.8
11.0
-
inch
3.6
5.4
7.2
9.0
13.4
17.9
22.4
26.9
cm
9
14
18
23
34
45
57
68
Screen size chart (4:3 aspect ratio)
The above numbers are approximate, and may be slightly different from the actual measurements.
Screen
Diagonal Size Width (W)Max. Zoom Min. Zoom
Height (H)
inch
20
29
39
49
74
98
123
147
Distance from screen (L)Height projected
image (Hd)
inch
40
60
80
100
150
200
250
300
cm
102
152
203
254
381
508
635
762
inch
35
52
70
87
131
174
218
261
cm
89
133
177
221
332
443
553
664
cm
50
75
100
125
187
249
311
374
inch
66
100
135
169
254
339
424
509
m
1.7
2.6
3.4
4.3
6.4
8.6
10.8
12.9
inch
74
112
150
188
283
378
473
-
m
1.9
2.8
3.8
4.8
7.2
9.6
12.0
-
inch
7.2
10.8
14.3
17.9
26.9
35.9
44.8
53.8
cm
18
27
36
46
68
91
114
137
Screen size chart (16:9 aspect ratio)
The above numbers are approximate, and may be slightly different from the actual measurements.
320
236
116 116
34.5
45.4
113.9135.5
213
14.3
30.6
48
214
48
64.5
90
60.2
14
Top View Bottom View
Front View Side View
• Compliance with ISO21118-2005
• All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
Unit:mm
Input and Output Terminals
1
2
3
4
Audio input
Video
PC/Component
Video input
Serial RS-232C
1 2 3 4
Brilliant
ColorTM
Color
Enhancer
Wall
Screen Splash
Screen
Low
Stand-by
Power
Low
Fan Noise
Top/Side
Loading
Lamp
Page
Up/Down
Instant
Shutdown
Long-life
Lamp
Password
Lock
Picture Performance
Presentation
User Friendly
