TECHNICAL MANUAL
STANDARD INVERTER PACKAGED
AIR-CONDITIONERS
(Split system, air to air heat pump type)
CEILING CASSETTE-4WAY TYPE
FDT100VNP1VF2
CEILING SUSPENDED TYPE
FDE100VNP1VG
DUCT CONNECTED-HIGH STATIC
PRESSURE TYPE
FDU100VNP1VF2
FLOOR STANDING TYPE
FDF100VNP1VD2
WALL MOUNTED TYPE
SRK100VNP1ZR
DUCT CONNECTED-LOW / MIDDLE
STATIC PRESSURE TYPE
FDUM100VNP1VF2
Manual No.'16•PAC-T-240
updated April 26, 2016
TECHNICAL MANUAL

-
1
-
'16 • PAC-T-240
1. SPECIFICATIONS .......................................................................................... 6
CONTENTS
(2) Ceiling suspended type (FDE) ............................................................... 7
(1) Ceiling cassette-4way type (FDT) ......................................................... 6
(2) Ceiling suspended type (FDE) ............................................................... 35
(1) Ceiling cassette-4way type (FDT) ......................................................... 34
(4) Duct connected-Low / Middle static pressure type (FDUM) .................. 9
(3) Duct connected-High static pressure type (FDU) ................................. 8
(2) Duct connected-Low / Middle static pressure type (FDUM) .................. 33
(1) Duct connected-High static pressure type (FDU) ................................. 32
(5) Floor standing type (FDF) ..................................................................... 10
(6) Wall mounted type (SRK) ...................................................................... 11
(2) Ceiling suspended type (FDE) ............................................................... 53
(1) Ceiling cassette-4way type (FDT) ......................................................... 46
(4) Duct connected-Low / Middle static pressure type (FDUM) ................. 62
(3) Duct connected-High static pressure type (FDU) ................................. 57
(3) Floor standing type (FDF) ..................................................................... 36
2. EXTERIOR DIMENSIONS .............................................................................. 12
(1) Indoor units ........................................................................................... 12
(2) Outdoor unit .......................................................................................... 18
(3) Remote control ...................................................................................... 19
3. ELECTRICAL WIRING ................................................................................... 22
4. NOISE LEVEL ................................................................................................ 29
5. CHARACTERISTICS OF FAN ........................................................................ 32
6. TEMPERATURE AND VELOCITY DISTRIBUTION ...................................... 34
7. PIPING SYSTEM ............................................................................................ 37
8. RANGE OF USAGE & LIMITATIONS ............................................................ 38
(1) Indoor units ........................................................................................... 22
(2) Outdoor unit .......................................................................................... 28
(1) Indoor units ........................................................................................... 29
(2) Outdoor unit .......................................................................................... 31
9.2 Correction of cooling and heating capacity in relation to air flow rate control (Fan speed)
9.3 Correction of cooling and heating capacity in relation to one way length of refrigerant piping
9.4 Height difference between the indoor unit and outdoor unit
................ 45
........... 45
............... 45
9. SELECTION CHART
9.1 Capacity tables ......................................................................................... 41
...................................................................................... 41
10. APPLICATION DATA
10.1 Installation of indoor unit ...................................................................... 46
..................................................................................... 46
(5) Floor standing type (FDF) ..................................................................... 67

-
2
-
'16 • PAC-T-240
(6) Wall mounted type (SRK) ....................................................................... 71
(7) Effective range of cool/hot wind (Reference) ........................................ 75
(1) FDT, FDE, FDU, FDUM series ............................................................... 76
(2) FDF series .............................................................................................. 80
10.4 Installation of outdoor unit ..................................................................... 98
10.2 Electric wiring work installation ............................................................. 76
10.3 Installation of wired remote control (Option) ........................................ 84
11. OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER ..................105
11.1 Remote control .........................................................................................105
11.2 Operation control function by the wired remote control
11.3 Operation control function by the indoor control .................................111
11.3.1 FDT, FDE, FDU, FDUM, FDF series ....................................................111
......................108
(1) Auto operation .......................................................................................111
(2) Operations of functional items during cooling/heating ...........................112
(4) Timer operation ......................................................................................113
(5) Remote control display during the operation stop ..................................114
(6) Hot start (Cold draft prevention at heating) ...........................................114
(7) Hot keep ................................................................................................114
(8) Auto swing control ..................................................................................115
........................................................118
(9) Thermostat operation .............................................................................116
(10) Filter sign ...............................................................................................117
.................................................117
(13) Drain pump abnormalities detection
(11) Compressor inching prevention control
(12) Drain pump control .................................................................................118
(3) Dehumidifying operation ........................................................................112
...................................................................119
...........................118
(16) Heating overload protection
(14) Operation check/drain pump test run operation mode
(15) Cooling, dehumidifying frost protection ..................................................119
................................................................................120
............................................................................120
(19) High ceiling control
(17) Anomalous fan motor
(18)
Plural unit control - Control of 16 units group by one remote control ..........120
..........................................121
.......121
(21) External input/output control (CnT or CnTA)
(20) Abnormal temperature thermistor (return air/indoor heat exchanger) wire/short-circuit detection
(22) Operation permission/prohibition ...........................................................123
..............................124(23) Selection of cooling/heating external input function
....................................................125
................................................................125
(26) Return air temperature compensation
(24) Fan control at heating startup
(25)
Room temperature detection temperature compensation during heating .........125
..................................................125(27) High power operation (RC-EX1A only)

-
3
-
'16 • PAC-T-240
.............................................126(28) Energy-saving operation (RC-EX1A only)
..........................................................126(29) Warm-up control (RC-EX1A only)
.......................................................126(30) Home leave mode (RC-EX1A only)
.............................................126(31) Auto temperature setting (RC-EX1A only)
...............................................126(32) Fan circulator operation (RC-EX1A only)
........126(33)
The operation judgment is executed every 5 minutes (RC-EX1A only)
................................................126(34) Auto fan speed control (RC-EX1A only)
...........................................126(35) Indoor unit overload alarm (RC-EX1A only)
..............................................................127(36) Peak-cut time (RC-EX1A only)
11.4 Operation control function by the outdoor control ...............................138
(1) Compressor command speed ................................................................138
(2) Compressor protection start ...................................................................138
(3) Outdoor unit fan control .........................................................................138
(4) Defrost operation ...................................................................................140
(5) Cooling overload protective control .......................................................141
(6) Cooling high pressure control ................................................................141
(7) Cooling low outdoor temperature protective control ..............................141
(8) Heating high pressure control ................................................................142
(9) Heating overload protective control 䊠....................................................142
...................................................142(10) Heating overload protective control 䊡
..............................143(11) Heating low outdoor temperature protective control
11.3.2 SRK series ............................................................................................128
................................................................................130(7) Economy operation
.............................................................................130(6) High power operation
(5) Selection of the annual cooling function ................................................130
...................................................................134
....................................129
(2) Unit ON/OFF button ...............................................................................129
(1) Operation control function by wireless remote control ...........................128
(4) Installing two air-conditioners in the same room
(3) Auto restart function ..............................................................................129
(14) Outline of heating operation
(8) Flap and louver control ..........................................................................131
(13) Installation location setting .....................................................................134
.........................................................................................133
(12) Night setback
(11) Silent mode ............................................................................................133
(9) 3D auto operation ...................................................................................132
(10) Timer operation ......................................................................................133
(15) Outline of cooling operation ...................................................................135
(16) Outline of dry(dehumidifying) operation .................................................135
(17) Outline of automatic operation ...............................................................136
(18) Protection control function .....................................................................136

-
4
-
'16 • PAC-T-240
............................................................143(12) Compressor overheat protection
...........................................................................................143(13) Current safe
.............................................................................................144(14) Current cut
................................................................................144(15) Outdoor unit failure
............................................144(16) Serial signal transmission error protection
..............................................................................................144(17) Rotor lock
....................................................144(18) Refrigeration cycle system protection
............................................................................................144
(19) Silent mode
.......................................145(20) Broken wire detection on temperature sensor
........................................145(21) Base heater ON/OFF output control (Option)
................................145(22) Reverse operation start for compressor protection
12. MAINTENANCE DATA ...................................................................................146
12.1.1 Diagnosing of microcomputer circuit ................................................146
12.1 FDT, FDE, FDU, FDUM, FDF series .........................................................146
(1) Selfdiagnosis function ............................................................................146
(2) Troubleshooting procedure ....................................................................149
(3) Troubleshooting at the indoor unit .........................................................149
(4) Check of anomalous operation data with the remote control .................156
(5) Outdoor unit control failure diagnosis circuit diagram ............................158
...........................................................................159
(1) List of troubles ........................................................................................159
(2) Troubleshooting .....................................................................................160
12.1.2 Troubleshooting flow
.........................202
(4) Troubleshooting procedure (If the air-conditioner runs)
12.2 SRK series ................................................................................................201
(3) Troubleshooting procedure
(If the air-conditioner does not run at all) ..........201
(1) Cautions .................................................................................................201
(2) Items to check before troubleshooting ...................................................201
(10) How to make sure of wireless remote control ........................................216
(11) Inspection procedure for blown fuse on the indoor control PCB ...........216
(5) Self-diagnosis table ...............................................................................203
(6) Service mode (Trouble mode access function) .....................................204
(8)
Phenomenon observed after shortcircuit, wire breakage on sensor ...........214
(7) Inspection procedures corresponding to detail of trouble ......................212
(9) Checking the indoor electrical equipment ..............................................214
13. OPTION PARTS
13.1 Wireless kit ................................................................................................217
13.3 Filter kit (FDUM series) .............................................................................231
13.2 Simple wired remote control (RCH-E3) ...................................................225
(1) FDT series (RCN-T-36W-E) ....................................................................217
(2) FDE series (RCN-E-E) ..........................................................................219
(3) FDU, FDUM, FDF series (RCN-KIT3-E) .................................................223
..............................................................................................217

-
5
-
'16 • PAC-T-240
13.6 Base heater kit (CW-H-E1) ........................................................................239
13.5 Superlink E board (SC-ADNA-E) ..............................................................237
14. TECHNICAL INFORMATION .........................................................................247
(2) Ceiling suspended type (FDE) ..............................................................248
(1) Ceiling cassette-4way type (FDT) ..........................................................247
(4) Duct connected-Low / Middle static pressure type (FDUM) ...................250
(3) Duct connected-High static pressure type (FDU) ..................................249
(5) Floor standing type (FDF) ......................................................................251
(6) Wall mounted type (SRK) .......................................................................252
ڦHow to read the model name
FDT
FDE
FDU
FDUM
FDF
SRK
FDC
Example : FDT 100 VNP1 VF2
Series code
Applicable power source...See the specification
Product capacity
Model name : Ceiling cassette-4way type
: Ceiling suspended type
: Duct connected-High static pressure type
: Duct connected-Low / Middle static pressure type
: Floor standing type
: Wall mounted type
: Outdoor unit
13.4 Interface kit (SC-BIKN-E) ..........................................................................233

-
6
-
'16 • PAC-T-240
1. SPECIFICATIONS
(1) Ceiling cassette-4way type (FDT)
Model
Item
FDT100VNP1VF2
Indoor unit FDT100VF2 Outdoor unit FDC100VNP
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 2.8(Min.)— 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 2.5(Min.)— 12.5(Max.)]
Power consumption Cooling
kW
2.76
Heating 2.84
Max power consumption 4.60
Running current Cooling
A
12.1 / 12.7
Heating 12.5 / 13.0
Inrush current, max current 5, 21
Power factor Cooling %99
Heating 99
EER Cooling 3.62
COP Heating 4.52
Sound power level Cooling
dB(A)
65 70
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 40 Me : 37 Lo : 35 57
Heating 61
Silent mode sound pressure level — Cooling:50 / Heating:49
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster white
(6.8Y8.9/0.2 )near equivalent
Stucco white
(4.2Y7.5/1.1)near equivalent
Net weight kg UNIT 27 PANEL 5.5 70
Compressor type & Q'ty — RMT5126MCE1 ( Twin rotary type )×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.90 MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 2.55kg in outdoor unit (incl. the amount for the piping of : 15m)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling m
3
/min P-Hi : 37 Hi : 27 Me : 24 Lo : 20 75
Heating 79
Available external static pressure Pa 0 0
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater W — —
Operation
control
Remote control (option) wired : RC-EX1A , RC-E5 , RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection( High pressure control ), Cooling overload protection
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") Pipeφ15.88(5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.30m
Vertical height diff. between O.U. and I.U. m Max.20m (Outdoor unit is higher) Max.20m (Outdoor unit is lower)
Drain hose Hose connectable VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in drain pump , 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number 1.5mm2×4 cores (Including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IPX4
Standard accessories Mounting kit, Drain hose
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these values are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
F
PJF000Z314

-
7
-
'16 • PAC-T-240
(2) Ceiling suspended type (FDE)
Model
Item
FDE100VNP1VG
Indoor unit FDE100VG Outdoor unit FDC100VNP
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 2.8(Min.)— 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 2.5(Min.)— 12.5(Max.)]
Power consumption Cooling
kW
2.66
Heating 2.94
Max power consumption 4.28
Running current Cooling
A
11.7 / 12.2
Heating 12.9 / 13.5
Inrush current, max current 5, 21.0
Power factor Cooling %99
Heating 99
EER Cooling 3.76
COP Heating 3.81
Sound power level Cooling
dB(A)
64 70
Heating
Sound pressure level Cooling P-Hi : 48 Hi : 43 Me : 38 Lo : 34 57
Heating 61
Silent mode sound pressure level — Cooling:50 / Heating:49
Exterior dimensions (Height × Width × Depth) mm 250 × 1,620 × 690 845×970×370
Exterior appearance
( Munsell color )
Plaster white
(6.8Y8.9/0.2 )near equivalent
Stucco white
(4.2Y7.5/1.1)near equivalent
Net weight kg 43 70
Compressor type & Q'ty — RMT5126MCE1 ( Twin rotary type )×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.90 MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 2.55kg in outdoor unit (incl. the amount for the piping of : 15m)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Centrifugal fan ×4 Propeller fan ×1
Fan motor (Starting method) W 80 < Direct line start > 86 < Direct line start >
Air flow Cooling m
3
/min P-Hi : 32 Hi : 26 Me : 21 Lo : 16.5 75
Heating 79
Available external static pressure Pa 0 0
Outside air intake Not possible —
Air filter, Quality / Quantity Pocket plastic net ×2(Washable) —
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater W 0 —
Operation
control
Remote control (option) wired : RC-EX1A , RC-E5 , RCH-E3 wireless : RCN-E-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection( High pressure control ), Cooling overload protection
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") Pipeφ15.88(5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.30m
Vertical height diff. between O.U. and I.U. m Max.20m (Outdoor unit is higher) Max.20m (Outdoor unit is lower)
Drain hose Hose connectable VP20 (O.D.26) Holes size φ20 × 3pcs
Drain pump, max lift height mm — —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number 1.5mm2×4 cores (Including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IPX4
Standard accessories Mounting kit, Drain hose Drain elbow, Drain hole grommet
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these values are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PFA004Z024

-
8
-
'16 • PAC-T-240
(3) Duct connected-High static pressure type (FDU)
Model
Item
FDU100VNP1VF2
Indoor unit FDU100VF2 Outdoor unit FDC100VNP
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 2.8(Min.)— 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 2.5(Min.)— 12.5(Max.)]
Power consumption Cooling
kW
3.00
Heating 2.93
Max power consumption 4.60
Running current Cooling
A
13.2 / 13.8
Heating 12.9 / 13.5
Inrush current, max current 5, 22.0
Power factor Cooling %99
Heating 99
EER Cooling 3.33
COP Heating 3.82
Sound power level Cooling
dB(A)
65 70
Heating
Sound pressure level Cooling P-Hi : 44 Hi : 38 Me : 36 Lo : 30 57
Heating 61
Silent mode sound pressure level — Cooling:50 / Heating:49
Exterior dimensions (Height × Width × Depth) mm 280 × 1,370 × 740 845×970×370
Exterior appearance
( Munsell color ) —Stucco white
(4.2Y7.5/1.1)near equivalent
Net weight kg 54 70
Compressor type & Q'ty — RMT5126MCE1 ( Twin rotary type )×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.90 MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 2.55kg in outdoor unit (incl. the amount for the piping of : 15m)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Centrifugal fan ×3 Propeller fan ×1
Fan motor (Starting method) W 100 + 130 < Direct line start > 86 < Direct line start >
Air flow Cooling m
3
/min P-Hi : 36 Hi : 28 Me : 25 Lo : 19 75
Heating 79
Available external static pressure Pa Standard：60 Max：200 0
Outside air intake Possible —
Air filter, Quality / Quantity Procure locally —
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater W — —
Operation
control
Remote control (option) wired : RC-EX1A , RC-E5 , RCH-E3 wireless : RCN-KIT3-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection( High pressure control ), Cooling overload protection
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") Pipeφ15.88(5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.30m
Vertical height diff. between O.U. and I.U. m Max.20m (Outdoor unit is higher) Max.20m (Outdoor unit is lower)
Drain hose Hose connectable VP25 (I.D.25,O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in drain pump , 600 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number 1.5mm2×4 cores (Including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IPX4
Standard accessories Mounting kit, Drain hose —
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these values are somewhat higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
(7) The factory E.S.P. setting is set within the range of 80 - 150 Pa.If SW8-4 is turned to "ON",
E.S.P. setting range can be changed to 10 - 200 Pa.(For RC-EX1A and RC-E5 only)
Item
Operation
Indoor air temperature Outdoor air temperature External static pressure
of indoor unit Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C 60Pa ISO5151-T1
Heating 20˚C —7˚C 6˚C
G
PJG000Z160

-
9
-
'16 • PAC-T-240
J
PJG000Z159
(4) Duct connected-Low / Middle static pressure type (FDUM)
Model
Item
FDUM100VNP1VF2
Indoor unit FDUM100VF2 Outdoor unit FDC100VNP
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 2.8(Min.)— 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 2.5(Min.)— 12.5(Max.)]
Power consumption Cooling
kW
3.00
Heating 2.93
Max power consumption 4.60
Running current Cooling
A
13.2 / 13.8
Heating 12.9 / 13.5
Inrush current, max current 5, 22.0
Power factor Cooling %99
Heating 99
EER Cooling 3.33
COP Heating 3.82
Sound power level Cooling
dB(A)
65 70
Heating
Sound pressure level Cooling P-Hi : 44 Hi : 38 Me : 36 Lo : 30 57
Heating 61
Silent mode sound pressure level — Cooling:50 / Heating:49
Exterior dimensions (Height × Width × Depth) mm 280 × 1,370 × 740 845×970×370
Exterior appearance
( Munsell color ) —Stucco white
(4.2Y7.5/1.1)near equivalent
Net weight kg 54 70
Compressor type & Q'ty — RMT5126MCE1 ( Twin rotary type )×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.90 MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 2.55kg in outdoor unit (incl. the amount for the piping of : 15m)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Centrifugal fan ×3 Propeller fan ×1
Fan motor (Starting method) W 100 + 130 < Direct line start > 86 < Direct line start >
Air flow Cooling m
3
/min P-Hi : 36 Hi : 28 Me : 25 Lo : 19 75
Heating 79
Available external static pressure Pa Standard：60 Max：100 0
Outside air intake Possible —
Air filter, Quality / Quantity Procure locally —
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater W — —
Operation
control
Remote control (option) wired : RC-EX1A , RC-E5 , RCH-E3 wireless : RCN-KIT3-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection( High pressure control ), Cooling overload protection
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") Pipeφ15.88(5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.30m
Vertical height diff. between O.U. and I.U. m Max.20m (Outdoor unit is higher) Max.20m (Outdoor unit is lower)
Drain hose Hose connectable VP25 (I.D.25,O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in drain pump , 600 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number 1.5mm2×4 cores (Including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IPX4
Standard accessories Mounting kit, Drain hose —
Option parts UM-FL3EF
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these values are somewhat higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
(7) Static pressure of optional air filter "UM-FL3EF" is 5Pa initially.
(8) The external static pressure setting can be changed to 10-100Pa. (For RC-EX1A and RC-E5 only)
Item
Operation
Indoor air temperature Outdoor air temperature External static pressure
of indoor unit Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C 60Pa ISO5151-T1
Heating 20˚C —7˚C 6˚C

-
10
-
'16 • PAC-T-240
(5) Floor standing type (FDF)
Model
Item
FDF100VNP1VD2
Indoor unit FDF100VD2 Outdoor unit FDC100VNP
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 2.8(Min.)— 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 2.5(Min.)— 12.5(Max.)]
Power consumption Cooling
kW
3.19
Heating 3.09
Max power consumption 4.60
Running current Cooling
A
14.0 / 14.6
Heating 13.6 / 14.2
Inrush current, max current 5, 21.0
Power factor Cooling %99
Heating 99
EER Cooling 3.13
COP Heating 3.62
Sound power level Cooling
dB(A)
65 70
Heating
Sound pressure level Cooling P-Hi : 54 Hi : 50 Me : 48 Lo : 44 57
Heating 61
Silent mode sound pressure level — Cooling:50 / Heating:49
Exterior dimensions (Height × Width × Depth) mm 1,850 × 600 × 320 845×970×370
Exterior appearance
( Munsell color )
Ceramic white
(N8.0 )near equivalent
Stucco white
(4.2Y7.5/1.1)near equivalent
Net weight kg 52 70
Compressor type & Q'ty — RMT5126MCE1 ( Twin rotary type )×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.90 MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 2.55kg in outdoor unit (incl. the amount for the piping of : 15m)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Centrifugal fan ×1 Propeller fan ×1
Fan motor (Starting method) W 157 < Direct line start > 86 < Direct line start >
Air flow Cooling m
3
/min P-Hi : 29 Hi : 26 Me : 23 Lo : 19 75
Heating 79
Available external static pressure Pa 0 0
Outside air intake Not possible —
Air filter, Quality / Quantity Plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater W — —
Operation
control
Remote control RC-E5 (Installed) / wireless : RCN-KIT3-E (option)
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection( High pressure control ), Cooling overload protection
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") Pipeφ15.88(5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.30m
Vertical height diff. between O.U. and I.U. m Max.20m (Outdoor unit is higher) Max.20m (Outdoor unit is lower)
Drain hose Hose connectable with VP20 Holes size φ20 × 3pcs
Drain pump, max lift height mm — —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number 1.5mm2×4 cores (Including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IPX4
Standard accessories Mounting kit Drain elbow, Drain hole grommet
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these values are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V 50Hz or 220V 60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
G
PGA000Z812

-
11
-
'16 • PAC-T-240
(6) Wall mounted type (SRK)
Model
Item
SRK100VNP1ZR
Indoor unit SRK100ZR-S Outdoor unit FDC100VNP
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 2.4(Min.)— 10.5(Max.)]
Nominal heating capacity (range) kW 11.2 [ 3.2(Min.)— 11.5(Max.)]
Heating capacity (H2) kW —
Power consumption
Cooling
kW
3.09 ( 0.6 - 3.2 )
Heating 3.28 ( 0.6 - 3.6 )
Heating (H2) —
Max power consumption 4.6
Running current Cooling
A
14.2 / 13.6 / 13.0 (220/ 230/ 240 V)
Heating 15.1 / 14.4 / 13.8 (220/ 230/ 240 V)
Inrush current, max current 15.1 / 14.4 / 13.8 (220/ 230/ 240 V) Max. 21
Power factor Cooling %99
Heating 99
EER Cooling 3.24
COP Heating 3.41
Heating (H2) —
Sound power level Cooling
dB(A)
63 70
Heating 63 74
Sound pressure level Cooling Hi : 48 Me : 45 Lo : 40 ULo : 27 57
Heating Hi : 48 Me : 43 Lo : 38 ULo : 30 61
Silent mode sound pressure level — Cooling:50 / Heating:49
Exterior dimensions (Height × Width × Depth) mm 339 x 1197 x 262 845×970×370
Exterior appearance
( Munsell color )
Fine snow
( 8.0Y 9.3/0.1 ) near equivalent
Stucco white
(4.2Y7.5/1.1)near equivalent
Net weight kg 16.5 70
Compressor type & Q'ty — RMT5126MCE1 ( Twin rotary type )×1
Compressor motor (Starting method) kW — 4.0 ( Inverter driven )
Refrigerant oil (Amount, type) — 0.90 ( DIAMOND FREEZE MA68 )
Refrigerant (Type, amount, pre-charge length) kg R410A 2.55 in outdoor unit (incl. the amount for the piping of 15m)
Heat exchanger Louver fin & inner grooved tubing M fin & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Tangential fan x 1 Propeller fan ×1
Fan motor (Starting method) W 56 x1 (Direct drive) 86 x1 (Direct drive)
Air flow Cooling m
3
/min
Hi : 24.5 Me : 21.3 Lo : 17.6 ULo : 10.4 75
Heating Hi : 27.5 Me: 23.2 Lo : 19.1 ULo : 13.6 80
Available external static pressure Pa 0 0
Outside air intake Not possible —
Air filter, Quality / Quantity Polypropylene net ( washable ) x 2 —
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater — —
Operation
control
Remote control Wireless-Remote control
Room temperature control Microcomputer thermostat
Operation display RUN: Green, TIMER: Yellow, HI POWER: Green, 3D AUTO: Green
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection( High pressure control ), Cooling overload protection
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: φ9.52 (3/8") Gas line: φ15.88 (5/8")
Connecting method Flare connection Flare connection
Attached length of piping m Liquid line : 0.78 / Gas line : 0.72 —
Insulation for piping Necessary ( Both sides ), independent
Refrigerant line (one way) length m Max.30m
Vertical height diff. between O.U. and I.U. m Max.20 ( Outdoor unit is higher ) / Max.20 ( Outdoor unit is lower )
Drain hose Hose connectable ( VP 16 ) Holes φ20 × 3pcs
Drain pump, max lift height mm — —
Recommended breaker size A 30
L.R.A. (Locked rotor ampere) A 5 / 5 / 5 (220/ 230/ 240 V)
Interconnecting wires Size × Core number 1.5mm2x 4 cores ( Including earth cable ) / Terminal block ( Screw fixing type )
IP number IPX0 IPX4
Standard accessories Mounting kit, Clean filter ( Allergen clear filter x 1, Photocatalytic washable deodorizing filter x 1 )
Option parts Interface kit ( SC-BIKN-E ), Drain Hose
Note (1) The data are measured at the following conditions. The pipe length is 5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these values are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C ISO5151-H1
Heating (H2) 20˚C —2˚C 1˚C ISO5151-H2
D
RWA000Z262

-
12
-
'16 • PAC-T-240
2. EXTERIOR DIMENSIONS (1) Indoor units (a) Ceiling cassette-4way type (FDT)
Model FDT100VF2
Unit:mm
Air supply
Air return grille
B A F
D
H
H
H
H
G
H
Make a space of 5000 or more between
the units when installing more than one.
Obstacle
or more
or more
AGas piping φ15.88(5／8")(Flare)
BLiquid piping
CDrain piping VP25(I.D.25,O.D.32)
DHole for wiring
FSuspension bolts (M10 or M8)
GOutside air opening
Air outlet opening
H
Symbol Content
φ9.52(3／8")(Flare)
for ducting
for ducting
Space for installation and service
(Knock out)
(Knock out)
G
Holes for
tapping screws
Hole
5-φ4
Holes for
tapping screws
6-φ4
Hole
Decorative panel
（Ceiling hole size）
（Suspension bolts pitch）
（Suspension bolts pitch）
C
（Installed on site）
Drain hose piece
suspension bolt
Hanger plate for
Control box
or more
（Max. Drain lift）
or less
box
Control
778
860‑910
725
648
418
420
50
150
207
260
303345
□840
123
173
29835
□630
□950
700
295‑325
140
100
100
60
140
1000
1000
65
105
112
137
40
38 50
37
76 67
13 44
Note（1）The model name label is attached
inside the air return grille.
140
（Accessory）
B
PJF000Z285

-
13
-
'16 • PAC-T-240
C
1
,C
2
C
1
,C
2
C
2
C
1
A
E
G
F
A
B
B
D
(b) Ceiling suspended type (FDE)
Model FDE100VG
PFA004Z027

-
14
-
'16 • PAC-T-240
（Duct dimension）
（Duct dimension）
Pipe（c）
Fan unit
View M
tapping screws
Holes for
Return air duct
Hole
AGas piping
BLiquid piping
DHole for wiring
ESuspension bolts （M10）
FOutside air opening
Air outlet opening
G
Symbol Content
φ9.52（3／8"）（Flare）
for ducting
for ducting
Drain piping
C2 （Gravity drainage）
φ15.88（5／8"）（Flare）
（Knock out）
（Knock out）
Drain hose piece
（Accessory）
（Installed on site）
HInspection hole （450X450）
φ170
φ124
φ170
tapping screws
Holes for
Space for installation and service
or more or more
or more
or more
（Case 1）From side of unit
Select either of two cases to keep space for installation and services.
or more
or more
（Case 2）From bottom of unit
Notes（a）There must not be obstacle to draw
out 2 fan units. For fan units maintenance,
refer to page 61.
（b）Install refrigerant pipes,
drain pipe, and wiring so as
not to cross marked area.
（c）The case that pipes are installed to upper（bottom）of fan unit,
keep space of 60mm or more to upper（bottom）of unit.
C1 Drain piping VP25（I.D.25,O.D.32）
VP20（I.D.20,O.D.26）
Unit:mm
4－φ4
（Suspension bolts pitch）
Air supply duct
Control box
（Duct dimension）
（Duct dimension）
18 1368 18
1404
suspension bolt
Hanger plate for
104 1200 104
92
250
184.5
134.5
467
405
468
635
73830 30
280
71
59
82
284
152 285
23.5
23521.5
64 1280 64
139
□90
600
（Max. drain lift）
（Suspension bolts pitch）
28
530180
or less
113
69
295�325
43
170
4－φ4
1000
150─
200
100―200
100
Slab
20 20
Note（a）
370
Ceiling
Note（b）
600
1720
100
Inspection
hole
725
Note（a）
15
50
FG
M
C
2
D
A
C 1
B
G
F
E
H
Notes（1）The model name label
is attached on the lid
of the control box.
B
PJG000Z048
(c) Duct connected-High static pressure type (FDU)
Model FDU100VF2

-
15
-
'16 • PAC-T-240
B
PJG000Z004
Pipe (c)
Fan unit
View M
Holes for
tapping screws
Return air duct
Hole
tapping screw
Holes for
AGas piping
BLiquid piping
DHole for wiring
ESuspension bolts (M10)
FOutside air opening
Air outlet opening
G
Symbol Content
φ9.52(3／8")(Flare)
for ducting
for ducting
Drain piping
C2 (Gravity drainage)
φ15.88(5／8")(Flare)
(φ150)(Knock out)
(φ125)( Knock out)
Drain hose piece
(Accessory)
(Installed on site)
HInspection hole (450X450)
φ 170
φ 124
φ 170
Holes for
tapping screws
Space for installation and service
or more or more
or more
or more
(Case 1)From side of unit
Select either of two cases to keep space for installation and services.
or more
or more
(Case 2)From bottom of unit
Note(1) The model name label
is attached on the lid
of the control box.
Notes (a) There must not be obstacle to draw
out 2 fan units. For fan units maintenance,
refer to page 66.
(b)Install refrigerant pipes,
drain pipe,and wiring so as
not to cross marked area.
(c)The case that pipes are installed to upper (bottom)of fan unit,
keep space of 60mm or more to upper (bottom)of unit.
C1 Drain piping
VP25(I.D.25,O.D.32)
VP20(I.D.20,O.D.26)
Unit:mm
4－φ4
（Suspension bolts pitch）
Air supply duct
Control box
（Duct dimension）
（Duct dimension）
18 1368 18
1404
Hanger plate for
suspension bolt
104 1200 104
92
250
184.5 134.5
467
405
468
635
73830 30
280
71
59
86
284
152 285
23.5
23521.5
64 1280 64
139
□90
100 100
24.5205
24.5
14－φ4
600
（Max. drain lift）
（Suspension bolts pitch）
28530
180
or less
4×280=1120
113
69
295―325
43
170
（Duct dimension）
（Duct dimension）
280
4－φ4
1000
150―
200
100―200
100
Slab
20 20
Note (a)
370
Ceiling
Note (b)
600
1720
100
Inspection
hole
725
Note (a)
15
45
FG
M
C 2
D
A
C1
B
G
F
E
H
(d) Duct connected-Low / Middle static pressure type (FDUM)
Model FDUM100VF2

-
16
-
'16 • PAC-T-240
Space for installation and service
A
E
C
B
A
D
F
H
G
A
or more
or more
or more
or more
or more
490
197.5
80
600
240120
1850
650 270
537
78
95
1827
50
50
50
185
30648
93
400.5
474
45
196
89040
120
852
150
98
329
600
1000
100
50
Air return
Air supply
125
(Range that
262(Gas)
264(Liquid)
238.5(Drain)
125
H can be installed left
Terminal block
(Power source)
Air supply
812.5
50
φ100(Knock out)
Hole on wall for rear piping
4-7×25(Slot)
Fresh air intake(Both left and right)
Hole on wall for side piping／
M8(2 places)
φ100(Knock out)
φ100(Resin cap having)
VP20(I.D.20,O.D.26)
Fall prevention metal fittings
Metal fittings to fix to floor face
Hole on wall for bottom piping
Drain piping
Liquid piping
Gas piping
H
G
F
E
D
C
B
A
ContentSymbol
φ9.52(3／8")(Flare)
φ15.88(5／8")(Flare)
143
82
15 622.5 15
17.5
35
25-50
Unit:mm
(Center of
terminal block)
(Center of
terminal block)
can be adjusted)
Remote
control
Air return
grille
Note(1) The model name label is attached on the
left lower side panel inside the air return grille.
(e) Floor standing type (FDF)
Model FDF100VD2
A
PGA000Z801

-
17
-
'16 • PAC-T-240
RLD000Z002
Hole on wall for right rear piping
Hole on wall for left rear piping
Gas piping
Outlet for wiring（on both side）
Drain hose
Liquid piping
F
E
C
D
B
Symbol
A
（φ65）
VP16
Content
（φ65）
Outlet for piping（on both side）
G
φ15.88（5／8"）（Flare）
φ9.52（3／8"）（Flare）
（Service space）
Unit
Space for installation and service when viewing from the front
768
157
48
240
6.7 322.4
214.5 214.5
883 157
10
3262
19 43.56464
55
47
53 77
47
1197
339 55
150
50
（Service space）
（Service space）
（Service space）
15 100
780
759
715
55
Installation plate
Unit:mm
Note（1）The model name label is attached
on the underside of the indoor unit.
Outlet for down piping
（Refer to the above view）
Terminal block
60
240 43
470 363.5363.5
568.5 568.5
11 60
D E CAB
G
G
G
F
(f) Wall mounted type (SRK)
Model SRK100ZR-S

-
18
-
'16 • PAC-T-240
51
40
41
103
10
11050
195
280
240
970
50 15
55
370 3939
410 1919
56
325263
39
76
190 580 200
60 16
103 16
5027
52
110
50
195
688
7050
150
41
Terminal block
Notes
（1）It must not be surrounded by walls on the four sides.
（2）The unit must be fixed with anchor bolts. An anchor bolt must not
protrude more than 15mm.
（3）Where the unit is subject to strong winds, lay it in such
a direction that the blower outlet face is perpendicular
to the dominant wind direction.
（4）Leave 1m or more space above the unit.
（5）A wall in front of the blower outlet must not exceed the units height.
（6）The model name label is attached on the service panel.
φ15.88（5／8"）（Flare）
Content
C Pipe／cable draw-out hole
D
E Anchor bolt hole
Drain discharge hole
Symbol
B
A Service valve connection（gas side）
M10×4 places
φ20×3 places
Service valve connection（liquid side）φ9.52（3／8"）（Flare）
F Cable draw-out hole φ30×3 places
Unit:mm
846
60
15
2-R
2-φ15
L2
L3
L4
L1
300
100
250
Open
Ⅰ Ⅱ
Open
250
100
500
Ⅲ
Open
250
150
250
Examples of
Dimensions
installation
Service panel
Minimum installation space
L3
Air intake
L2
Air intake
Air outlet （Service space
for electrical
parts）
L1
L4
The height of a wall is 1200mm or less
C
E
C
D
A
B
F
F
B
A
C C
F
(2) Outdoor unit
Model FDC100VNP
PCA001Z787

-
19
-
'16 • PAC-T-240
Installation space
R/C cable：0.3mm2 × 2-core
A
dapted to RoHSdirective
Exterior appearance
(Munsell color)
Pearl white
(N8.5) near equivalent
-
PJZ000Z297
(3) Remote control
(a) Wired remote control (Option parts)
Model:RC-EX1A
Interface kit (SC-BIKN-E) is required to use the wired remote control. (SRK series only)
