Mitsubishi Heavy Industries FDTC71VNXPVD Product guide

HYPER INVERTER PACKAGED AIR-CONDITIONERS
(Split system, Air to air heat pump type)
Twin type
FDTC71VNXPVD
FDTC100VNXPVD
FDTC100VSXPVD
FDTC125VNXPVD
FDTC125VSXPVD
Triple type
FDTC140VNXTVD
FDTC140VSXTVD
CEILING CASSETTE- 4 WAY COMPACT TYPE
Single type
FDUM71VNXVD
FDUM100VNXVD
FDUM100VSXVD
FDUM125VNXVD
FDUM125VSXVD
FDUM140VNXVD
FDUM140VSXVD
Twin type
FDUM100VNXPVD
FDUM100VSXPVD
FDUM125VNXPVD
FDUM125VSXPVD
FDUM140VNXPVD
FDUM140VSXPVD
Triple type
FDUM140VNXTVD
FDUM140VSXTVD
DUCT CONNECTED-LOW/MIDDLE STATIC PRESSURE TYPE
Single type
FDU71VNXVD
FDU100VNXVD
FDU100VSXVD
FDU125VNXVD
FDU125VSXVD
FDU140VNXVD
FDU140VSXVD
DUCT CONNECTED-HIGH STATIC PRESSURE TYPE
Single type
FDT71VNXVD
FDT100VNXVD
FDT100VSXVD
FDT125VNXVD
FDT125VSXVD
FDT140VNXVD
FDT140VSXVD
Twin type
SRK100VNXPZIX
SRK100VNXPZJX
SRK100VSXPZIX
SRK100VSXPZJX
SRK125VNXPZIX
SRK125VNXPZJX
SRK125VSXPZIX
SRK125VSXPZJX
Triple type
SRK140VNXTZIX
SRK140VNXTZJX
SRK140VSXTZIX
SRK140VSXTZJX
WALL MOUNTED TYPE
Twin type
FDT71VNXPVD
FDT100VNXPVD
FDT100VSXPVD
FDT125VNXPVD
FDT125VSXPVD
FDT140VNXPVD
FDT140VSXPVD
Triple type
FDT140VNXTVD
FDT140VSXTVD
CEILING CASSETTE- 4 WAY TYPE
Single type
FDEN71VNXVD
FDEN100VNXVD
FDEN100VSXVD
FDEN125VNXVD
FDEN125VSXVD
FDEN140VNXVD
FDEN140VSXVD
Twin type
FDEN71VNXPVD
FDEN100VNXPVD
FDEN100VSXPVD
FDEN125VNXPVD
FDEN125VSXPVD
FDEN140VNXPVD
FDEN140VSXPVD
Triple type
FDEN140VNXTVD
FDEN140VSXTVD
CEILING SUSPENDED TYPE
Manual No. '10 • PAC - DB - 136
DATA BOOK
HYPER INVERTER PACKAGED AIR-CONDITIONERS
Air-Conditioning & Refrigeration Systems Headquarters
16-5, 2-chome, Kounan, Minato-ku, Tokyo, 108-8215, Japan
Fax : [phone]
© Copyright MITSUBISHI HEAVY INDUSTRIES, LTD.
Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice.
updated April 27, 2011

-
1
-
'10 • PAC-DB-136
CONTENTS
1. SPECIFICATIONS ........................................................................................... 3
1.1 Ceiling cassette-4way compact type (FDTC) .......................................... 3
1.2 Ceiling cassette-4way type (FDT) ............................................................. 10
1.3 Ceiling suspended type (FDEN) ............................................................... 26
1.4 Duct connected-Low/Middle static pressure type (FDUM) .................... 42
1.5 Duct connected-High static pressure type (FDU) .................................. 57
1.6 Wall mounted type (SRK) ......................................................................... 64
(6) Wall mounted type (SRK) .........................................................................137
6.1 Ceiling cassette-4way compact type (FDTC) ...........................................107
6.2 Ceiling cassette-4way type (FDT) .............................................................108
6.3 Ceiling suspended type (FDEN) ...............................................................111
5.1 Duct connected-Low/Middle static pressure type (FDUM) ....................103
5.2 Duct connected-High static pressure type (FDU) ..................................106
2. EXTERIOR DIMENSIONS ............................................................................... 70
2.1 Indoor units ............................................................................................... 70
2.2 Outdoor units ............................................................................................ 82
4. NOISE LEVEL
5. CHARACTERISTICS OF FAN
7. PIPING SYSTEM
6. TEMPERATURE AND VELOCITY DISTRIBUTION
3. ELECTRICAL WIRING .................................................................................... 86
8. RANGE OF USAGE & LIMITATIONS
3.1 Indoor units ............................................................................................... 86
3.2 Outdoor units ............................................................................................ 95
4.1 Indoor units ............................................................................................... 98
4.2 Outdoor units ............................................................................................102
2.3 Remote controller (Option parts) ............................................................. 84
9. SELECTION CHART
9.1 Capacity tables
9.2
Correction of cooling and heating capacity in relation to air flow rate control (fan speed)
(2) Ceiling cassette-4way type (FDT)
(1) Ceiling cassette-4way compact type (FDTC) ...............................................122
(3) Ceiling suspended type(FDEN)
...............................................................124
(4) Duct connected-Low/Middle static pressure type (FDUM)
...................................................................128
(5) Duct connected-High static pressure type (FDU) .......................................135
........................132
9.3
Correction of cooling and heating capacity in relation to one way length of refrigerant piping
9.4 Height difference between the indoor unit and outdoor unit
........................................................................................122
..........139
.....139
..............139
................................................................................................. 98
........................................................................103
........................................107
.............................................................................................115
............................................................118
.......................................................................................122

-
2
-
'10 • PAC-DB-136
10.3 Installation of outdoor unit .....................................................................174
(1) Model FDC71VNX ....................................................................................174
(2) Models FDC100～140VNX,100～140VSX ...............................................182
10.4 Electric wiring work installation .............................................................190
11.2 Simple wired remote controller (RCH-E3) .............................................206
11.3 Base heater kit (CW-H-E) ........................................................................212
11.4 Interface kit (SC-BIKN-E) ........................................................................216
11.5 Superlink E board (SC-ADNA-E) ...........................................................220
10.5 Instructions for branching pipe set (DIS-WA1,WB1,TA1,TB1) .............193
How to read the model name
FDTC : Ceiling cassette-4way compact type
FDT : Ceiling cassette-4way type
FDEN : Ceiling suspended type
FDUM : Duct connected-Low/Middle static pressure
type
FDU : Duct connected-High static pressuret type
Example: FDTC 100 VNX P VD
Series code
P : Twin type
: Single type
T : Triple type
Applicable power source...See the specification
Product capacity
Model name
FDC : Outdoor unit
(blank)
10. APPLICATION DATA
10.1 Installation of indoor unit
(1) Ceiling cassette-4way compact type (FDTC)
.......................................................................141
11.1 Wireles kit ...............................................................................................196
11.1.1 FDTC Series (RCN-TC-24W-ER) .........................................................196
11.1.2 FDT Series (RCN-T-36W-E) ................................................................198
...................................................................................141
11. OPTION PARTS ...........................................................................................196
(2) Ceiling cassette-4way type (FDT) ..............................................................147
(3) Ceiling suspended type(FDEN) .................................................................153
(4) Duct connected-Low/Middle static pressure type (FDUM) ........................157
(5) Duct connected-High static pressure type (FDU) .......................................161
(6) Wall mounted type (SRK) ..........................................................................165
10.2 Installation of wired remote controller ..................................................169
..............................................141
11.1.3 FDEN Series (RCN-E1R) ....................................................................200
11.1.4 FDUM,FDU Series (RCN-KIT3-E) ........................................................204
Example: SRK 125 VNX P ZIX
Series code
P : Twin type
T : Triple type
Applicable power source...See the specification
Product capacity
Model name〔Wall mounted type 〕

-
3
-
'10 • PAC-DB-136
Model
Item
FDTC71VNXPVD
Indoor unit FDTC40VD (2 units) Outdoor unit FDC71VNX
Panel TC-PSA-25W-E
Power source 220-240V
~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 7.1 [ 3.2 (Min.)
~ 8.0 (Max.)] 8.0 [ 3.6 (Min.) ~ 9.0 (Max.)]
Power consumption kW 1.99 2.18
Running current A 8.9 / 9.3 9.7 / 10.2
Power factor % 98 98
Inrush current A 5 < Max.running current 17 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 Cooling : 51 Heating : 48
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 750×880 (+88) × 340
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 60
Refrigerant equipment
Compressor type & Q'ty — RMT5118MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.675 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 Cooling : 60 Heating : 50
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") × 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 120
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 2.95kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose —
1. SPECIFICATIONS
1.1 Ceiling cassette-4way compact type (FDTC)
(1) Twin type Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ①: Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379

-
4
-
'10 • PAC-DB-136
Model
Item
FDTC100VNXPVD
Indoor unit FDTC50VD (2 units) Outdoor unit FDC100VNX
Panel TC-PSA-25W-E
Power source 220-240V—50Hz / 220V—60Hz
Operation data Cooling Heating
Nominal capacity kW 10.0 [ 4.0 (Min.)
~ 11.2 (Max.)] 11.2 [ 4.0 (Min.) ~ 12.5 (Max.)]
Power consumption kW 2.78 3.02
Running current A 12.3 / 12.9 13.4 / 14.0
Power factor % 98 98
Inrush current A 5 < Max.running current 24 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo：32 Cooling : 48 Heating : 50
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 105
Refrigerant equipment
Compressor type & Q'ty — RMT5134MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 2
Motor <Starting method> W 33 < Direct line start > 86 x 2 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo：8100
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") × 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 120
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ①: Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379

-
5
-
'10 • PAC-DB-136
Model
Item
FDTC100VSXPVD
Indoor unit FDTC50VD (2 units) Outdoor unit FDC100VSX
Panel TC-PSA-25W-E
Power source 380-415V 3N
~ 50Hz / 380V 3N ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 10.0 [ 4.0 (Min.)
~ 11.2 (Max.)] 11.2 [ 4.0 (Min.) ~ 16.0 (Max.)]
Power consumption kW 2.78 3.02
Running current A 4.1 / 4.3 4.4 / 4.7
Power factor % 98 99 / 98
Inrush current A 5 < Max.running current 15 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 Cooling : 48 Heating : 50
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 105
Refrigerant equipment
Compressor type & Q'ty — RMT5134MDE3 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 2
Motor <Starting method> W 33 < Direct line start > 86 x 2 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 100
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") × 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 120
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ①: Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379

-
6
-
'10 • PAC-DB-136
Model
Item
FDTC125VNXPVD
Indoor unit FDTC60VD (2 units) Outdoor unit FDC125VNX
Panel TC-PSA-25W-E
Power source 220-240V
~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 12.5 [ 5.0 (Min.)
~ 14.0 (Max.)] 14.0 [ 4.0 (Min.) ~ 17.0 (Max.)]
Power consumption kW 4.10 4.10
Running current A 18.2 / 19.0 18.2 / 19.0
Power factor % 98 98
Inrush current A 5 < Max.running current 26 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 46 Me : 39 Lo : 30
Heating P-Hi : 47 Hi : 46 Me : 39 Lo : 32 Cooling : 48 Heating : 50
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 105
Refrigerant equipment
Compressor type & Q'ty — RMT5134MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 2
Motor <Starting method> W 33 < Direct line start > 86 × 2 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 7.5
Heating P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 8 100
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") × 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 120
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ①: Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379

-
7
-
'10 • PAC-DB-136
Model
Item
FDTC125VSXPVD
Indoor unit FDTC60VD (2 units) Outdoor unit FDC125VSX
Panel TC-PSA-25W-E
Power source 380-415V 3N
~ 50Hz / 380V 3N ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 12.5 [ 5.0 (Min.)
~ 14.0 (Max.)] 14.0 [ 4.0 (Min.) ~ 18.0 (Max.)]
Power consumption kW 4.10 4.10
Running current A 6.0 / 6.4 6.0 / 6.4
Power factor % 99 / 97 99 / 97
Inrush current A 5 < Max.running current 15 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 46 Me : 39 Lo : 30
Heating P-Hi : 47 Hi : 46 Me : 39 Lo : 32 Cooling : 48 Heating : 50
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 105
Refrigerant equipment
Compressor type & Q'ty — RMT5134MDE3 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 2
Motor <Starting method> W 33 < Direct line start > 86 × 2 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 7
Heating P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 8 100
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/U φ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/Uφ9.52 (3/8")
Gas line
: I/U φ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") × 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 120
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379

-
8
-
'10 • PAC-DB-136
Model
Item
FDTC140VNXTVD
Indoor unit FDTC50VD (3 units) Outdoor unit FDC140VNX
Panel TC-PSA-25W-E
Power source 220-240V
~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 14.0 [ 5.0 (Min.)
~ 16.0 (Max.)] 16.0 [ 4.0 (Min.) ~ 18.0 (Max.)]
Power consumption kW 4.34 4.34
Running current A 19.3 / 20.1 19.3 / 20.1
Power factor % 98 98
Inrush current A 5 < Max.running current 26 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 Cooling : 49 Heating : 52
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 105
Refrigerant equipment
Compressor type & Q'ty — RMT5134MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 2
Motor <Starting method> W 33 < Direct line start > 86 × 2 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 100
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/U φ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/Uφ9.52 (3/8")
Gas line : I/U φ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") × 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 121
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
(2) Triple type
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is three indoor units are combined and run together.
(6) Branching pipe set "DIS-TA1"×1(option). ① : Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379

-
9
-
'10 • PAC-DB-136
Model
Item
FDTC140VSXTVD
Indoor unit FDTC50VD (3 units) Outdoor unit FDC140VSX
Panel TC-PSA-25W-E
Power source 380-415V 3N
~ 50Hz / 380V 3N ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 14.0 [ 5.0 (Min.)
~ 16.0 (Max.)] 16.0 [ 4.0 (Min.) ~ 20.0 (Max.)]
Power consumption kW 4.34 4.34
Running current A 6.4 / 6.7 6.4 / 6.7
Power factor % 98 98
Inrush current A 5 < Max.running current 15 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 Cooling : 49 Heating : 52
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 105
Refrigerant equipment
Compressor type & Q'ty — RMT5134MDE3 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 2
Motor <Starting method> W 33 < Direct line start > 86 × 2 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 100
External static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/U φ6.35 (1/4") ②φ9.52 (3/8") × 0.8 ①φ9.52 (3/8") × 0.8 O/U φ9.52 (3/8")
Gas line : I/U φ12.7 (1/2") ②φ12.7 (1/2") × 0.8 ①φ15.88 (5/8") ×1.0 O/U φ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 121
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is three indoor units are combined and run together.
(6) Branching pipe set "DIS-TA1"×1(option). ① : Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) If wireless remote controller is used, only 3-speed fan setting (Hi-Me-Lo) is available.
PJA003Z379
