Technical Data
MAXIMUM RECOMMENDED MOUNTING HEIGHT: 3.0m
RANGE: Cone-shaped detection pattern, diameter (at floor level)= 2.4 x mounting height
OFFDELAY:20minutes(fixed)
OPERATING VOLTAGE: 230V50Hz (UK & Europe)
MAXIMUM RECOMMENDED LOAD: 6Amps resistive or fluorescent
WEIGHT: 200gapprox
PRODUCTRATING &RECOMMENDED CIRCUITPROTECTION: 10Amps
TERMINALCAPACITY: 2 x 2.5mm
COLOUR:White
MATERIAL:FlameretardantABS
IPRATING: 530
2
Flange
15mm deep
50843PL Ed. 1
Installation and Commissioning
Instructions
K4050 or K4053 required for Commissioning
Standard PIR with Photocell
Surface
At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
Dimensions
72mm
deep
100mm
6.0m
2.4m
SENSORS
K4011
MK Electric
The Arnold Centre, Paycocke Road, Basildon,
Essex, SS14 3EA. UK
Tel: +44 (0)1268 563720
Fax: +44 (0)1268 563064
email: mktechnical@honeywell.com
Tel: +44 (0)1268 563000
Fax: 01268 563404
Fax: +44 (0)1268 563365 (International)
email: mkorderenquiries@honeywell.com
web site: www.mkelectric.co.uk
Novar ED&S Ltd (A Honeywell Company),
Arlington Business Park, Bracknell, Berkshire, RG12 1EB
All marks in this document identified with a R or TM symbol
adjacent to the mark are Trade Marks of Novar ED&S Ltd.
Technical Help
Customer Service
______________________________________________________
K4011-StandardPIRwithPhotocell-Surface
Onlysuitablyqualifiedpersonnelshouldinstallthisequipment.
Note:
The K4011 is a high performance presence detector with photocell. Thephotocell is designedto hold lightsoff
whenareasbecomeoccupiedifthedaylightlevelishighandtoswitchlightsoninoccupiedareasasthedaylight
level falls. Pleasenotethatthephotocellwillnotswitchlightsoffinareasthatareoccupied.
The housing may be secured to a hard surface or a BESA box. The K4011 fits into the housing with a simple
bayonetaction.
Donotpositionwithin25cmofaluminaire.
Fixing
Connection
LOAD
(Max6Amps)
N
E
LPermanent
or switched
supply
N
E
LPermanent
or switched
supply
K4011
K4011 K4011
VOLT-
FREE
OUTPUT
VOLT-
FREE
OUTPUT
VOLT-
FREE
OUTPUT
NOCONNECTION
NOCONNECTION NOCONNECTION
LIVE IN
LIVE IN LIVE IN
NEUTRAL
NEUTRAL NEUTRAL
EARTH
EARTH EARTH
Multiple Detectors
Single Detector
LOAD
(Max6Amps)
Commissioning
The K4011 has a fixed 20 minute off-delay and is designed not to be re-programmed. It is possible, however, to
settheunitintowalk-testmodeandtosetthephotocellswitchinglevel,forwhichaninfraredprogrammer(K4050
orK4053)maybeused
Walk-test Mode
Setting the Photocell
Multiple K4011
Walk-test mode is used to check that the range of the presence detector is appropriate for the application. The
short off-delay enables the installer to check that lights areswitching on when movements are made at the edge
ofthedetectionzone. Itiseasiertocarryoutawalk-testwhenthephotocellisnotholdingthelightsoff.
1. Using an K4050BasicProgrammer, point the unit atthedetector and briefly press ButtonA.Alternatively, set
a 10 second off-delay using the K4053: From the utilities menu, select ‘Walk Test’ and whilst pointing the
programmeratthedetector,brieflypresstheOKbuttontoenterwalk-testmode.
2. Move aroundtheareathatisbeingcontrolled, stoppingfor10secondstoallowthelightstoswitchoff, before
movingandtriggeringthelightsbackon.
3. After5minutes,oraninterruptioninthemainspowersupply,theoff-delayreturns to20minutes.Alternatively
theoff-delaycanbereprogrammedto20minutesusingtheK4053.
The photocell is ideally commissioned at a time when ambient conditions are just insufficient for user
requirementsandassuch,artificiallightingwouldberequired.
With an K4050, point the programmer at the detector and briefly press the ‘Store’ button to set the current light
level as the photocell switching point. This ensures that whenever the controlled area is brighter than this level,
the lights will switch on when entering the area. Note that the lights will not turn OFF if an area is occupied,
regardlessofnaturallightlevels
With a K4053, from the Utilities menu, select Set Light Level and press the OK button to store the current
perceivedlevel.TheprocedureisthesameaswiththeK4050programmer.
A numerical value (0-254) is stored in the Threshold parameter (viewable with an K4053) and can be edited if
necessary.Alower value indicates that the area must be progressively darker before the controlled lighting will
switchON.
Largerareascanbecoveredbyconnectingmultipledetectorsinparallel. Thetotalloadcurrentmustnotexceed
6Ampsincaseonlyoneunitisactivated.
ImportantAdditionalNotes
1. Allterminalsonthisproductare providedforfinalconnections. Itisnotintendedthattheproductbeusedasajunctionbox
forloopingcables.
2. Ameansfordisconnectionmustbeincorporatedinthefixedwiringinaccordancewiththecurrentwiringregulations.
3. Thisequipmentswitcheslightsnomorefrequentlythanwouldaresponsiblehumanoccupant. However,manufacturersof
some lighting types (e.g. ‘2D’ luminaires) may specify a maximum number of switching cycles in order to achieve a
predicted lamp life. Please check with the manufacturer of the luminaires to ensure that they are compatible with
automaticcontrolsinthisrespect.
50843PL Ed. 1
