elsner elektronik Vari KNX 3L-TH-D GPS Guide

Installation and Adjustment
Item number 70390
EN
Elsner Elektronik GmbH Control and AutomationTechnology
Sohlengrund 16
75395 Ostelsheim Phone [phone] / 30 945-0 [e-mail]
Germany Fax [phone] www.elsner-elektronik.de
Vari KNX 3L-TH-D GPS
Combined Outdoor Sensor
Technical support: +49 (0) 70 33 / 30 945-250

1 Contents
Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany
Sensor Vari KNX 3L-TH-D GPS • from ETS programme version 1.0
Version: 22.08.2017 • Technical changes and errors excepted.
1. Description ........................................................................................... 5
1.0.1. Scope of delivery .......................................................................................... 6
1.1. Technical specification ............................................................................................. 6
2. Installation and start-up ....................................................................... 7
2.1. Installation notes ...................................................................................................... 7
2.2. Installation location .................................................................................................. 8
2.3. Device design ........................................................................................................... 9
2.4. Installing the device ............................................................................................... 10
2.4.1. Preparation for installation ........................................................................ 10
2.4.2. Fitting the lower part of the housing with mounting ............................... 10
2.4.3. Connection .................................................................................................. 12
2.4.4. Completing the installation ........................................................................ 13
3. Addressing the device ........................................................................ 13
4. Maintenance ....................................................................................... 14
5. Transfer protocol ............................................................................... 15
5.1. List of all communication objects ......................................................................... 15
6. Parameter setting .............................................................................. 41
6.1. Behaviour on power failure/ restoration of power .............................................. 41
6.1.1. Storage of threshold values ....................................................................... 41
6.1.2. Malfunction objects .................................................................................... 41
6.1.3. General settings .......................................................................................... 41
6.2. GPS .......................................................................................................................... 42
6.3. Location ................................................................................................................... 43
6.4. Temperature Measurement ................................................................................... 45
6.5. Temperature threshold values .............................................................................. 46
6.5.1. Threshold values 1-4 .................................................................................. 46
6.6. Brightness measurement value ............................................................................ 48
6.7. Brightness threshold values sensor 1-3 and total brightness threshold values 49
6.7.1. Threshold values 1-4 .................................................................................. 49
6.8. Twilight brightness threshold values ................................................................... 51
6.8.1. Threshold values 1-4 .................................................................................. 51
6.9. Night ........................................................................................................................ 53
6.10.Sun position ........................................................................................................... 54
6.11.Humidity Measurement ......................................................................................... 55
6.12.Humidity threshold values .................................................................................... 55
6.12.1. Threshold values 1-4 .................................................................................. 55
6.13.Dewpoint measurement ........................................................................................ 58
6.13.1. Cooling medium temperature monitoring ............................................... 58
6.14.Absolute humidity ................................................................................................. 60
6.15.Comfort field .......................................................................................................... 61
6.16.Air pressure measurement ................................................................................... 62
6.17.Wind threshold values ........................................................................................... 63

2 Contents
Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany
Sensor Vari KNX 3L-TH-D GPS • from ETS programme version 1.0
Version: 22.08.2017 • Technical changes and errors excepted.
6.17.1. Wind threshold values 1-4 ......................................................................... 63
6.18.Temperature PI control .......................................................................................... 65
6.18.1. Heating control level 1/2 ............................................................................. 70
6.18.2. Cooling control level 1/2 ............................................................................. 73
6.19.Summer Compensation ........................................................................................ 75
6.20.Humidity PI control ................................................................................................ 76
6.21.Variable comparator .............................................................................................. 78
6.21.1. Control variable comparator 1/2/3/4 .......................................................... 78
6.22.Computer ................................................................................................................ 79
6.22.1. Computers 1-8 ............................................................................................. 79
6.23.Weekly timer .......................................................................................................... 83
6.23.1. Weekly timer period 1-24 ........................................................................... 83
6.24.Calendar timer ........................................................................................................ 84
6.24.1. Calendar clock Period 1-4 ........................................................................... 85
6.25.Logic ........................................................................................................................ 86
6.25.1. AND logic 1-8 and OR logic outputs 1-8 ................................................... 86
6.25.2. AND logic connection inputs ..................................................................... 88
6.25.3. Connection inputs of the OR logic ............................................................. 93

2 Clarification of signs
This manual is amended periodically and will be brought into line with new software
releases. The change status (software version and date) can be found in the contents footer.
If you have a device with a later software version, please check
www.elsner-elektronik.de in the menu area "Service" to find out whether a more up-to-
date version of the manual is available.
Clarification of signs used in this manual
Installation, inspection, commissioning and troubleshooting of the device
must only be carried out by a competent electrician.
Safety advice.
Safety advice for working on electrical connections, components,
etc.
DANGER! ... indicates an immediately hazardous situation which will lead to
death or severe injuries if it is not avoided.
WARNING! ... indicates a potentially hazardous situation which may lead to
death or severe injuries if it is not avoided.
CAUTION! ... indicates a potentially hazardous situation which may lead to
trivial or minor injuries if it is not avoided.
ATTENTION! ... indicates a situation which may lead to damage to property if it is
not avoided.
ETS In the ETS tables, the parameter default settings are marked by
underlining.

5 Description
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
1. Description
The Sensor Vari KNX 3L-TH-D GPS for the KNX building bus system records bright-
ness, temperature, air humidity and air pressure outside. The devices also receives the
GPS signal for time and location and uses it to compute the position of the sun (azi-
muth and elevation).
All measurement values can be used for the control of limit-dependent switching out-
puts. States can be linked via AND logic gates and OR logic gates. Multi-function mod-
ules change input data as required by means of calculations, querying a condition, or
converting the data point type. In addition, an integrated control variable comparator
can compare and output variables that were received via communication objects.
Integrated PI-controllers control ventilation (according to humidity) and heating/cool-
ing (according to temperature). The Vari KNX 3L-TH-D GPS can output a warning to
the bus as soon as the comfort field (as per DIN 1946) is exited.
The compact housing of the Vari KNX 3L-TH-D GPS accommodates the sensors,
evaluation circuits and bus-coupling electronics.
Functions:
•Brightness measurement: The current light intensity is measured by three
sensors. Of the three measurement values, the maximum value or a calculated
mixed value can be output optionally.
•GPS receiver, outputting the current time and location coordinates. The
Sensor Vari KNX 3L-TH-D GPS also computes the position of the sun
(azimuth and elevation)
•Temperature and humidity measurement (relative, absolute), in each case
with Mixed value calculation. The share of internal measurement value and
external value can be set as a percentage.
In addition the bus output will indicate whether the values are inside the
comfort field (DIN 1946). The dewpoint will be calculated
•Air pressure measurement: Output of the value as normal pressure and
optionally as barometric pressure
•Switching outputs for all measured and computed values. Threshold values
can be adjusted per parameter or via communication objects
•PI-controller for heating (one or two-stage) and cooling (one or two-stage)
according to temperature. Regulation according to separate setpoints or basic
setpoint temperature
•PI controller for humidity according to humidity: Ventilate/Air (one-stage) or
Ventilate (one or two-stage)
•Weekly and calendar time switch: All time switching outputs can be used
as communication objects.
The weekly time switch has 24 periods. Each period can be configured either
as an output or as an input. If the period is an output, then the switching time
is set per parameter or per communication object.
The calendar time switch has 4 periods. Two on/off switching operations,
which are executed daily, can be set for each period

6 Description
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
•8 AND and 8 OR logic gates, each with 4 inputs. All switching events as well
as 16 logic inputs (in the form of communications objects) can be used as
inputs for the logic gates. The output of each gate can be configured optionally
as 1-bit or 2 x 8-bit
•8 multi-function modules (computers) for changing the input data by
calculations, by querying a condition or by converting the data point type
•4 control variable comparators to output minimum, maximum or average
values. 5 inputs each for values received via communication objects
•Summer compensation for cooling systems. A characteristic curve matches
the target temperature in the room to the external temperature and sets the
minimum and maximum target temperature values
Configuration is made using the KNX software ETS. The product file can be down-
loaded from the Elsner Elektronik website on www.elsner-elektronik.de in the “Ser-
vice” menu.
1.0.1. Scope of delivery
•Sensor
• Stainless steel installation band for pole installation
• 4×50 mm stainless steel Roundhead screws and 6×30 mm dowels for wall
mounting. Use fixing materials that are suitable for the base!
1.1. Technical specification
Housing Plastic
Colour White / Translucent
Assembly Surface mount
Protection category IP 44
Dimensions approx. 65 × 80 × 30 (W × H × D, mm)
Weight approx. 60 g
Ambient temperature Operation -25…+80°C, Storage -40…+85°C,
avoid condensation
Operating voltage KNX bus voltage
Bus current max. 20 mA
Data output KNX +/- bus connector terminal
BCU type Integrated micro controller
PEI type 0
Group addresses max. 2000
Assignments max. 2000
Communication objects: 603
Temperature sensor:
Measurement range -25°C … +80°C
Resolution 0.1°C

7 Installation and start-up
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
The product conforms with the provisions of EU directives.
2. Installation and start-up
2.1. Installation notes
Installation, testing, operational start-up and troubleshooting should
only be performed by an electrician.
CAUTION!
Live voltage!
There are unprotected live components inside the device.
• National legal regulations are to be followed.
• Ensure that all lines to be assembled are free of voltage and take
precautions against accidental switching on.
• Do not use the device if it is damaged.
• Take the device or system out of service and secure it against
unintentional use, if it can be assumed, that risk-free operation is no
longer guaranteed.
Accuracy ±0,8°C at -25...-10°C
±0,5°C at -10...+65°C
±0,6°C at +65...+80°C
Humidity sensor:
Measurement range 0% RH … 100% RH
Resolution 0.1% RH
Accuracy ±7,5% RH at 0...10% RH
±4,5% RH at 10...90% RH
±7,5% RH at 90...100% RH
Pressure sensor:
Measurement range 300 mbar … 1100 mbar
Resolution 0.1 mbar
Accuracy ±4 mbar
Brightness sensor:
Measurement range 0 lux … 150,000 lux
Resolution 1 lux at 0…255 lux
6 lux at 256…2,645 lux
96 lux at 2,646…128,256 lux
762 lux at 128,257…150,000 lux
Accuracy ±15% of the measurement value at 35 lux … 150,000
lux

8 Installation and start-up
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
The device is only to be used for its intended purpose. Any improper modification or
failure to follow the operating instructions voids any and all warranty and guarantee
claims.
After unpacking the device, check it immediately for possible mechanical damage. If it
has been damaged in transport, inform the supplier immediately.
The device may only be used as a fixed-site installation; that means only when assem-
bled and after conclusion of all installation and operational start-up tasks and only in
the surroundings designated for it.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
2.2. Installation location
Due to the GPS receiver, the Sensor Vari KNX 3L-TH-D GPS must be installed out-
side.
The device should be protected from condensation. For critical applications in which
the formation of condensation is expected, please consult Elsner Elektronik about spe-
cial solutions.
Select an installation position on the building where the sensors can measure sunshine
without any obstructions. The weather station should not be shaded by structures or,
for example, trees. Ensure no shadow is thrown on the device by an extended awning.
Fig. 1
The device must be attached to a vertical wall
(or a pole).
wall
or
pole
90°
Fig. 2
The device must be mounted in the horizontal
(transverse) direction.
Horizontal

9 Installation and start-up
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
Temperature measurements can also be distorted by external influences such as
warming or cooling of the building structure on which the sensor is mounted (sunlight,
heating or cold water pipes). Temperature variations from such sources of interference
must be corrected in the ETS in order to ensure the specified accuracy of the sensor
(temperature offset).
Magnetic fields, transmitters and interference fields from electrical consumers (e.g. flu-
orescent lamps, neon signs, switch mode power supplies etc.) can block or interfere
with the reception of the GPS signal.
2.3. Device design
Fig. 3
For installation in the northern hemisphere,
the device must be aligned to face south.
For installation in the southern hemisphere,
the device must be aligned to face north.
North
South
Wall/Pole
3
Fig. 4
1 Position of the brightness sen-
sors 1-3. With alignment of the
device to the south
Sensor 1 = East
Sensor 2 = South
Sensor 3 = West
2 Semi-transparent cover
(GPS receiver and pressure sen-
sor below)
3 Position of the Signal LED (un-
der the cover). LED is freely con-
trolled via two objects
4 Position of the programming
LED (under the cover)
5 Lower part of housing
6 Temperature and humidity sen-
sor
7 Programming key on the bottom
of the housing (recessed), see
Addressing the device, page 13
8 Wall/Pole holder
4
8
7
1
5
2
6
3
1
2

10 Installation and start-up
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
2.4. Installing the device
ATTENTION!
Even a few drops of water can damage the device electronics.
• Do not open the device if water (e.g. rain) can get into it.
2.4.1. Preparation for installation
2.4.2. Fitting the lower part of the housing with mounting
Now, first of all, assemble the lower part of the housing with the integrated mounting
for wall or pole installation.
Wall installation
Use fixing materials (dowels, screws) that are suitable for the base.
Fig. 5
The cover and lower part of the housing are
connected together. Pull both parts apart in a
straight line.
Fig. 6
The device is installed with two screws. Break
off the two longitudinal holes in the housing.
Longitudinal holes
Fig. 7 a+b
a) If the power lead is to be hidden when in-
stalled, it must emerge from the wall in
the vicinity of the rear of the housing
(marked area).

11 Installation and start-up
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
Drilling plan
ATTENTION! The print out of the data sheet doesn‘t have original size!
A separate, dimensionally correct drilling plan is included ex works and this can be
used as a template.
b) If the power lead is to be surface-mount-
ed, the cable guide is broken off. The lead
is then fed into the device from the bot-
tom of the housing.
Cable guide
Fig. 8
Feed the power lead through the rubber gas-
ket.
Rubber
gasket
Fig. 9
Dimensions in mm. Varia-
tions are possible for tech-
nical reasons
A/B2× longitudinal holes
8 mm × 5 mm
C Position of the cable
outlet (rubber gasket)
in the housing
AB
C

12 Installation and start-up
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
Pole installation
The device is installed on the pole with the enclosed stainless steel mounting band.
2.4.3. Connection
The connector is in the lower part of the housing.
Fig. 10
Feed the mounting band through the eyelets
in the lower part of the housing.
Fig. 11
Break the cable guide off.
Feed the power lead through the rubber gas-
ket.
Rubber
gasket Cable guide
Fig. 12
Connect the device to the KNX bus via
the pluggable terminal (+|-).
-
+
-
+
KNX

13 Addressing the device
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
2.4.4. Completing the installation
3. Addressing the device
The device is delivered ex works with the bus address 15.15.250. You can program a
different address in the ETS by overwriting the address 15.15.250 or by teaching the
device via the programming button.
The programming button can be reached through the opening on the underside of the
housing; it is recessed by approx. 8 mm. Use a thin object to reach the button, e.g. a
1.5 mm² wire.
Fig. 13
Put the cover on the lower part. This also
makes the plug-in connection between the
board in the cover and the socket in the lower
part.
Fig. 14 a+b
1 Programming LED (under the semi-
transparent cover)
2 Programming button for teaching
the device
12
2Housing from below

14 Maintenance
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
4. Maintenance
WARNING!
Risk of injury due to automatically moved components!
The automatic control may cause parts of the system to start up and
pose a danger to humans.
• Always disconnect the system from the mains power before
maintenance or cleaning.
The device should be regularly checked twice a year for soiling and cleaned if required.
If there is major soiling, the function of the sensor may be compromised.
ATTENTION
The device may be damaged if water penetrates the housing.
• Do not clean with high pressure cleaners or steam jets.

15 Transfer protocol
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
5. Transfer protocol
Units:
Temperatures in degrees Celsius
Brightness in Lux
Air pressure in Pascal
Azimuth and elevation in degrees
Air humidity in %
Absolute air humidity in g/kg and/or g/m3
Variables in %
5.1. List of all communication objects
Abbreviation flags:
C Communication
R Read
WWrite
T Transfer
UUpdate
No. Text Func-
tion
Flags DPT type Size
1 Software version Output R-CT [217.1] DPT_Ver-
sion
2 bytes
21 Signal LED object 1s cycle Input -WC- [1.1] DPT_Switch 1 bit
22 Signal LED object 4s cycle Input -WC- [1.1] DPT_Switch 1 bit
24 GPS malfunction (0 : OK | 1: NOK) Output R-CT [1.2] DPT_Bool 1 bit
25 Date / time Output RWCT [19.1] DPT_Date-
Time
8 bytes
26 Date Output RWCT [11.1] DPT_Date 3 bytes
27 Time Output RWCT [10.1] DPT_-
TimeOfDay
3 bytes
28 Date and time query Input -WC- [1.017] DPT_Trig-
ger
1 bit
30 Location: Northern latitude [°] Output R-CT [14.7] DPT_Val-
ue_AngleDeg
4 bytes
31 Location: Eastern longitude [°] Output R-CT [14.7] DPT_Val-
ue_AngleDeg
4 bytes
41 Temperature sensor: Malfunction Output R-CT [1.1] DPT_Switch 1 bit
42 Temperature sensor: External
measurement
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
43 Temperature sensor: Measured value Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes

16 Transfer protocol
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
44 Temperature sensor: Total
measurement
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
45 Temperature sensor: Min./Max.
measurement query
Input -WC- [1.017] DPT_Trig-
ger
1 bit
46 Temperature sensor: Minimum
measurement
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
47 Temperature sensor: Maximum
measurement
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
48 Temperature sensor: Min./Max.
measurement reset
Input -WC- [1.017] DPT_Trig-
ger
1 bit
51 Temp. threshold value 1: Absolute
value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
52 Temp. threshold value 1: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
53 Temp. threshold value 1: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
54 Temp. threshold value 1: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
55 Temp. threshold value 1: Switching
output
Output R-CT [1.1] DPT_Switch 1 bit
56 Temp. threshold value 1: Switching
output block
Input -WC- [1.1] DPT_Switch 1 bit
58 Temp. threshold value 2: Absolute
value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
59 Temp. threshold value 2: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
60 Temp. threshold value 2: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
61 Temp. threshold value 2: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
62 Temp. threshold value 2: Switching
output
Output R-CT [1.1] DPT_Switch 1 bit
63 Temp. threshold value 2: Switching
output block
Input -WC- [1.1] DPT_Switch 1 bit
65 Temp. threshold value 3: Absolute
value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
66 Temp. threshold value 3: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
67 Temp. threshold value 3: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
68 Temp. threshold value 3: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
69 Temp. threshold value 3: Switching
output
Output R-CT [1.1] DPT_Switch 1 bit
70 Temp. threshold value 3: Switching
output block
Input -WC- [1.1] DPT_Switch 1 bit
No. Text Func-
tion
Flags DPT type Size

17 Transfer protocol
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
72 Temp. threshold value 4: Absolute
value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
73 Temp. threshold value 4: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
74 Temp. threshold value 4: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
75 Temp. threshold value 4: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
76 Temp. threshold value 4: Switching
output
Output R-CT [1.1] DPT_Switch 1 bit
77 Temp. threshold value 4: Switching
output block
Input -WC- [1.1] DPT_Switch 1 bit
95 Brightness measured value sensor 1 Output R-CT [9.4] DPT_Val-
ue_Lux
2 bytes
96 Brightness measured value sensor 2 Output R-CT [9.4] DPT_Val-
ue_Lux
2 bytes
97 Brightness measured value sensor 3 Output R-CT [9.4] DPT_Val-
ue_Lux
2 bytes
98 Total brightness measured value Output R-CT [9.4] DPT_Val-
ue_Lux
2 bytes
101 Brightness sensor 1 threshold
value 1: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
102 Brightness sensor 1 threshold
value 1: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
103 Brightness sensor 1 threshold
value 1: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
104 Brightness sensor 1 threshold
value 1: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
105 Brightness sensor 1 threshold
value 1: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
106 Brightness sensor 1 threshold
value 1: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
108 Brightness sensor 1 threshold
value 2: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
109 Brightness sensor 1 threshold
value 2: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
110 Brightness sensor 1 threshold
value 2: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
111 Brightness sensor 1 threshold
value 2: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
112 Brightness sensor 1 threshold
value 2: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
No. Text Func-
tion
Flags DPT type Size

18 Transfer protocol
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
113 Brightness sensor 1 threshold
value 2: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
115 Brightness sensor 1 threshold
value 3: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
116 Brightness sensor 1 threshold
value 3: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
117 Brightness sensor 1 threshold
value 3: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
118 Brightness sensor 1 threshold
value 3: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
119 Brightness sensor 1 threshold
value 3: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
120 Brightness sensor 1 threshold
value 3: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
122 Brightness sensor 1 threshold
value 4: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
123 Brightness sensor 1 threshold
value 4: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
124 Brightness sensor 1 threshold
value 4: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
125 Brightness sensor 1 threshold
value 4: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
126 Brightness sensor 1 threshold
value 4: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
127 Brightness sensor 1 threshold
value 4: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
129 Brightness sensor 2 threshold
value 1: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
130 Brightness sensor 2 threshold
value 1: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
131 Brightness sensor 2 threshold
value 1: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
132 Brightness sensor 2 threshold
value 1: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
133 Brightness sensor 2 threshold
value 1: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
134 Brightness sensor 2 threshold
value 1: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
136 Brightness sensor 2 threshold
value 2: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
137 Brightness sensor 2 threshold
value 2: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
No. Text Func-
tion
Flags DPT type Size

19 Transfer protocol
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
138 Brightness sensor 2 threshold
value 2: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
139 Brightness sensor 2 threshold
value 2: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
140 Brightness sensor 2 threshold
value 2: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
141 Brightness sensor 2 threshold
value 2: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
143 Brightness sensor 2 threshold
value 3: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
144 Brightness sensor 2 threshold
value 3: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
145 Brightness sensor 2 threshold
value 3: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
146 Brightness sensor 2 threshold
value 3: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
147 Brightness sensor 2 threshold
value 3: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
148 Brightness sensor 2 threshold
value 3: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
150 Brightness sensor 2 threshold
value 4: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
151 Brightness sensor 2 threshold
value 4: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
152 Brightness sensor 2 threshold
value 4: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
153 Brightness sensor 2 threshold
value 4: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
154 Brightness sensor 2 threshold
value 4: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
155 Brightness sensor 2 threshold
value 4: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
157 Brightness sensor 3 threshold
value 1: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
158 Brightness sensor 3 threshold
value 1: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
159 Brightness sensor 3 threshold
value 1: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
160 Brightness sensor 3 threshold
value 1: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
161 Brightness sensor 3 threshold
value 1: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
No. Text Func-
tion
Flags DPT type Size

20 Transfer protocol
Sensor Vari KNX 3L-TH-D GPS • Version: 22.08.2017 • Technical changes and errors excepted.
162 Brightness sensor 3 threshold
value 1: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
164 Brightness sensor 3 threshold
value 2: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
165 Brightness sensor 3 threshold
value 2: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
166 Brightness sensor 3 threshold
value 2: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
167 Brightness sensor 3 threshold
value 2: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
168 Brightness sensor 3 threshold
value 2: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
169 Brightness sensor 3 threshold
value 2: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
171 Brightness sensor 3 threshold
value 3: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
172 Brightness sensor 3 threshold
value 3: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
173 Brightness sensor 3 threshold
value 3: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
174 Brightness sensor 3 threshold
value 3: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
175 Brightness sensor 3 threshold
value 3: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
176 Brightness sensor 3 threshold
value 3: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
178 Brightness sensor 3 threshold
value 4: Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
179 Brightness sensor 3 threshold
value 4: (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
180 Brightness sensor 3 threshold
value 4: Delay from 0 to 1
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
181 Brightness sensor 3 threshold
value 4: Delay from 1 to 0
Input -WC- [7.5] DPT_Time-
PeriodSec
2 bytes
182 Brightness sensor 3 threshold
value 4: Switching output
Output R-CT [1.1] DPT_Switch 1 bit
183 Brightness sensor 3 threshold
value 4: Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
185 Total brightness threshold value 1:
Absolute value
Input/
Output
RWCT [9.4] DPT_Val-
ue_Lux
2 bytes
186 Total brightness threshold value 1:
(1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 bit
No. Text Func-
tion
Flags DPT type Size
