Mobiak ROM AIR WALKER User manual

INDICATIONS:
Grade 2 and 3 ankle sprains
Stress fractures of the lower leg
Post-operative use,trauma, Rehabilitation
Stable delayed union or non-union fractures of the distal tibia and fibula
Achilles tendon repairs
CONTRAINDICATIONS:
Application of this device is recommended only when the fracture is demonstrably stable and
there are acceptable limits of angular and rotational deformity. The determination of when to
apply the braces rests strictly at the discretion of the treating physician.
This products was designed to complement the variety of medical treatments common to the
above afflictions. The frequency and duration of use should be determined by your prescribing
healthcare professional .
For first time application, loosen straps and remove liner from boot.
Place foot in liner and secure with contact closure.Fasten the foot flaps on
the liner first,making sure they are snug. Wrap and fasten the leg portion
of the liner,again making sure that it is snug from the bottom to top.
Some trimming of the liner may be necessary to accomplish optimum fit
ROM AIR WALKER INSTRUCTION
Before appling the
brace, please read these instructions completely and carefully.
.
Correct application is vital to the proper function of the braces .

Spread the uprights using both hands and step into boot,
aligning uprights with midline of the ankle.
If uprights have plastic tube liner, remove them now and affix upright to liner.
Secure boot straps at the toes and working up the leg.
To adjust range of motion, press the flexion or extension button
and rotate untill the desired degree of flexion or extension is
achieved through the corresponding windows.The"0" lock setting
are used to lock the brace in full extension .
INFLATE
KNOB
DEFLATE
KNOB
To DEFLATE the air bladder,rotate the valve and loosen
until the air chambers reach a comfortable level.
Slight air loss may be experienced during periods of wear and air can easily be added.
Foam pads are provides to alleviate the problem of excess rubbing and pads can be placed
either inside the liner or between the liner and the uprights .
Warranty:
The product has a warranty period of one (1) year.
The warranty covers factory defects and not damages from misuse/maintenance product.
ΚΑΤΑΣΚΕΥΑΣΤΗΣ:ΜΟΒΙΑΚ Α.Ε/MOBIAK S.A
Μ.ΜΠΟΤΣΑΡΗ 96-98 ΤΚ. 73136- ΤΗΛ: 28210 63222,ΧΑΝΙΑ-ΚΡΗΤΗΣ
M.Mpotsari 96-98, 73136 Chania-Crete, Greece
Web site: http://www.mobiakcare.gr, e-mail: [email protected]
To INFLATE the air bladder,first please make sure the deflate knob is screwed, press the Inflate
Knob repeatedly until the air chambers are inflated to a comfortable level.
