Mobile Warming DUAL POWER PANTS User manual

WWW.MOBILEWARMING.COM
FOLLOW US
DUAL POWER
PANTS
USER MANUAL

Welcome to Warmth.
Stay Warm, Stay Comfortable
Thank you for purchasing our Dual Power Performance Heated Jacket or Vest.
To ensure proper use and care of your garment and our Mobile Warming
batteries please read this user manual prior to use.
•One - Dual Power Heated Pant
•One - Power Lead Connector
•One - 12v 5200 mAh Lithium-Ion batteries (Model#MWV52)
•One - 12v Single AC battery charger (Model# ASA16U17
Includes
Introduction
Patented Mobile Warming® technology is
specially engineered for cold environmental
conditions. Mobile Warming® comprehensive
heating solutions keep you warm and
comfortable. The exclusive Mobile Warming®
heating system utilizes F.I.R. (Far-Infrared) heat
and ultra-fine metal fiber heating elements
powered by lightweight, rechargeable, and
powerful Lithium-Ion batteries. As heat builds
Mobile Warming® advanced materials reflect
and direct heat back towards the body
ensuring that you stay warm. The combination of
unique materials, construction techniques, and
innovative design results in the most advanced
heated gear available.
REFLECTIVE LAYER
INSULATION LAYER
HEATED LAYER
F.I.R Technology
WWW.MOBILEWARMING.COM
WARNING

Power Ratings Based on Fully Charged Battery and Ambient Temperature of 72°
135°F
(57.2°C)
2.8Hrs.
100%
120°F
(48.8°C)
3.5Hrs.
75%
105°F
(40.5°C)
5.5Hrs.
50%
90°F
(32.3°C)
11.0Hrs.
25%
WWW.MOBILEWARMING.COM
Battery Installation
Dual Power: Battery Heat Ratings
Use only
MWV52
Battery
3
2
Quick Start Guide (Battery)
Do not use battery if you notice a
change of shape (lumps),
over-heating when charging or if
rust or corrosion on the battery
connectors is found.
Fully Charge battery to 100%.
Press and hold the power button on the battery for a few seconds. Once it’s
powered on LED will be Blue/100% heat.
Plug battery into the pants wire harness. Wire harness is located on the right side front
pocket. (See drawing 1)
Slide battery into wire harness pocket. (See drawing 2)
Now that the battery is connected to jacket or vest, press and hold the touch control
button on for a few seconds. Once it’s powered on LED will be Red/100% heat.
After the pants are on, push the control button to reach your desired settings.
To power off pants, press and hold the touch control button until light turns off. If you
plan to not use the jacket or vest for more than a few days, unplug battery from the
pants.
1-
2-
3-
4-
5-
6-
7-
1
Y-Harness
To connect pants to a Mobile Warming
Jacket or vest you must purchase
temperately the Dual Power 12volt Y-Split
Connector (Part #ASA16U1). This is
required if multiple Dual Power garments
are to be connected and powered
together.
Y-Split
Connector
ASA16U1
Power Lead
Connector

149°F
(65.0°C)
100%
132°F
(55.5°C)
75%
118°F
(47.7°C)
50%
100°F
(37.7°C)
25%
Power Ratings Based on Ambient Temperature of 72°
WWW.MOBILEWARMING.COM
Dual Power: Power Lead Heat Ratings
A
Quick Start Guide (Vehicle)
Before connecting your Dual Power garment
to the Mobile Warming Power Lead
Connector; always make sure the vehicle is
running prior to connecting. Failure to do so
can damage garment’s heating elements
voiding warranty.
Turn off vehicle and remove key from ignition.
Locate and access vehicle’s 12volt battery.
Disconnect the vehicles Negative(-) Cable and remove from battery terminal.
Connect the Negative(-) wire from the supplied Mobile Warming Power Lead
Connector to the battery terminal and re-connect vehicle’s Negative(-) Cable. (See
Drawing A)
Disconnect the vehicles Positive(+) Cable and remove from battery terminal then
connect the Positive(+) wire from the supplied Mobile Warming Power Lead Connec-
tor to the battery terminal and re-connect vehicle’s Positive(+) Cable. (See Drawing
A)
Route Mobile Warming Power Lead Connector the right side of vehicle Seat with a
minimum of 2in (5cm) of the Mobile Warming Power Lead Connector exposed.
Start Vehicle and connect Jacket or Vest to Power Lead Connector. Power Lead is
1-
2-
3-
4-
5-
6-
located in the interior pocket.(See Drawing B)
Now that the battery is connected to jacket
or vest, press and hold the touch control
button for a few seconds. Once it’s powered
on LED will be Red/100% heat.
After the jacket or vest is on, push the control
button to reach your desired settings.
To power off jacket or vest, press and hold
the touch control button until light turns off.
Always remember to disconnect the Jacket or
Vest from the power lead harness before
leaving vehicle.
7-
8-
9-
B

WWW.MOBILEWARMING.COM
Charging Instructions
To ensure the best battery performance and a
long battery life follow these steps. Battery Port
Charger Port
MWV52
12volt 5200mAh
Lithium-Ion
ASA16U17
• Output: 12.6v, 1.6A
• Input : AC 100v-240v
Replacement or additional batteries and chargers available at
www.mobilewarming.com
Plug Mobile Warming charger into AC wall
socket and connect battery(s) to AC charger
connectors.
When indicator light(s) are “Red” battery(s) are
charging.
When indicator light(s) turn “Green” battery(s)
are fully charged and ready for use or storage.
Always charge batteries indoors.
Always use Mobile Warming Chargers to charge
batteries. Failure to do so could result in bodily
injury, fire, or damaged batteries.
•
•
•
•
•
Always disconnect and remove MW battery(s) from the garment(s) power
lead wiring harness.
Do not machine tumble dry, iron, or dry clean.
Do not wring out the garment(s) as this may cause damage to the heating
elements and or wire harness.
Do not fully submerse in water or other liquids.
Please charge the battery fully before use.
If problems with the battery occurs refer to caution label marked on battery
case or contact us at www.mobilewarming.com
Care Instructions
•
•
•
•
•
•
CAUTION
•
•
•
Only charge your battery with included compatible wall charger. Go to
www.mobilewarming.com/pages/battery-care for more information.
It is important to maintain at least 25% of your battery power when not in use.
Failure to do so will result in performance issues and reduced battery life. We
recommend to charge your batteries every 3 months.
Recommended power settings of 50% is sufficient for temperatures between
50°-64°F (10°-17.7°C) while at lower temperatures setting the power at 75%
or 100% is sufficient. It is not recommended to use 100% power setting for a
long time as it may cause overheating and /or bodily discomfort.
INPUT12.6V1.6A
OUTPUT9-12.6V MAX5A
USBOUTPUT
DC5VMAX2.1A

WWW.MOBILEWARMING.COM
Wash Instructions
Warranty Terms
*Our warranty applies only to the original purchaser and only for items purchased from an authorized
Mobile Warming Dealer or Authorized distributor retail partner.
Limited Two Year Warranty (Garment)
When you purchase a Mobile Warming brand product from an authorized Mobile Warming retailer
within the United States or Canada both the construction and electrical heating components of the
product are warranted to be completely free from factory defects in materials and workmanship for
two (2) year from the date of purchase. If any failure in the construction or the heating function of any
Mobile Warming product purchased from an authorized Mobile Warming dealer within the United
States and Canada occurs due to the manufacturer’s defect within two years of the purchase of the
product, the product will be repaired at no charge.*
90 Day Rechargeable Battery & Charger Warranty
Mobile Warming Gear rechargeable Lithium-ion battery packs and chargers are under warranty from
factory defect for 90 days from the initial purchase date. Mobile Warming will repair or replace any
battery or charger found to be defective under normal use within the 90 day warranty period.
*Costs associated with shipping the item in under warranty is the responsibility of the purchaser.
Warranty Exclusions
Any damage caused to any Mobile Warming products by misuse, abuse, improper care, accident,
normal wear and tear, use of non-mobile warming battery systems, and or the natural breakdown of
materials over an extended period of time and use are not covered in this warranty. Any alterations or
repairs (attempted or otherwise) performed on any Mobile Warming product voids any and all
warranties offered by Mobile Warming for that particular item. Mobile Warming products are technical
athletic apparel and is not intended for use as work wear or for use in strenuous or demanding
circumstances or extreme conditions.
How to initiate a Warranty Claim
First, please ensure that your product is covered under warranty according to the terms above. Then
simply have a digital copy of your dated proof of purchase ready and contact our friendly customer
service team at [e-mail], informing us that you would like to initiate a warranty claim
for repair, briefly explaining the nature of your claim, with your dated proof of purchase attached. Our
customer service team will then follow up with you within two business days of receiving all of the
necessary information with an email containing a Return Authorization number, return instructions and
the return shipping address in order to return with your defective item.
•
•
•
Hand Wash Only
Drip dry only. Do not machine dry.
Do Not Bleach. Do Not Iron, Do Not Dry Clean, Do Not Tumble Dry, Do
Not Wring.
To wash, disconnect the battery(s) from the power lead/wire harness, and
remove battery from garment(s).
