Mobotix D22M with Vandalism Set User manual
MOBOTIX AG • Security-Vision-Systems • Made in Germany
Current PDF File:
www.mobotix.com > Support > Manuals
3 mm Beschnitt umlaufend
Complete integration for web and security
D22M
Camera Manual
MOBOTIX ... the new face of IP video
Part 1
X
MOBOTIX
Security-Vision-SystemsSecurity-Vision-Systems
.
com
Wall mount
with cable cover
for RJ45 wall outlet
30 Frames/s
VGA (640 x 480)
12 fps Mega
-22°F to +140°F
Weatherproof
-30°C to +60°C, IP65
no heating necessary
IEEE 802.3af
PoE
network power
even in winter
Video SIP Client
IP Telephony
alarm notify,
camera remote control
lip-syncronized audio
Recording
event ring buffer
30 cams each 30 fps
Backlight
safe using CMOS
without mechanical iris
Video motion
multiple windows
precision pixel-based
microphone & speaker
Audio
bi-directional via IP
variable frame rates
Live viewing
30 cams at 30 fps
all on one screen
3 Megapixels
2048 x 1536
8x software zoom
Robust
no moving parts
fiber glass housing
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
D22M Camera Manual Part 1
MOBOTIX Camera Data
Enter the data of your camera here!
Camera Model:
Camera Name:
Factory IP Address:
Current IP Address:
DHCP: activated deactivated
Admin User Name:
Admin Password:
Note: MOBOTIX offers inexpensive seminars that include a workshop and
practical excercises: Basic Seminar 3days, Advanced Seminar
2days. For more information, see www.mobotix.com
.
.
.
.
.
.
D22M Basic
D22M Secure
D22M with Vandalism Set
D22M CAMERA MANUAL PART1
1 INTRODUCTION 6
1.1 MOBOTIX Cost Benefits 12
1.2 MOBOTIX Technical Advantages 13
1.3 MOBOTIX D22M Concept 14
1.4 Lens Options, Hardware and Software Features 20
1.5 Important Notes 24
1.5.1 Weatherproofness 24
1.5.2 Password for the Administration Menu 24
1.5.3 Irreversibly Deactivating the Microphone 24
1.5.4 Starting the Camera Using the Factory IP Address 25
1.5.5 Resetting the Camera to Factory Defaults 25
1.5.6 Activating Event Control for Security Applications 25
1.5.7 Deactivating Text and Logo Options 25
1.5.8 Deactivating the Automatic Daily Reboot of the Camera 26
1.5.9 ISDN Compatibility Notes 26
1.5.10 Using Internet Browsers 26
1.5.11 Cleaning Instructions 26
1.5.12 Safety Notes for Operating MOBOTIX Cameras 26
1.5.13 Additional Information 27
2 MOUNTING THE CAMERA 28
2.1 Preparing the Installation 28
2.1.1 Mounting to a Ceiling or Wall 28
2.1.2 Additional Mounting Options for IT/Secure Models 29
2.1.3 Network Connection and Power Supply, UPS 30
2.1.4 Providing the Camera Connections, Wall Outlets 31
2.1.5 Directions for Mounting 32
2.2 D22M-IT/Secure: Delivered Parts, Components and Dimensions 34
2.2.1 Delivered Parts and Components D22M-IT/Secure 34
2.2.2 Camera Housing and Connectors D22M-IT/Secure 35
2.2.3 Dimensions of the D22M-IT/Secure 36
2.2.4 Drilling Template for the D22M-IT/Secure Mounting Ring 37
2.3 D22M-Basic: Delivered Parts, Components and Dimensions 38
2.3.1 Delivered Parts and Components D22M-Basic 38
2.3.2 Camera Housing and Connectors D22M-Basic 39
2.3.3 Dimensions of the D22M-Basic 40
2.2.4 Drilling Template for the D22M-Basic 41
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
1/108
D22M Camera Manual Part 1
2.4 Camera Accessories: Delivered Parts, Components and Dimensions 42
2.4.1 D22M On-Wall Set 42
2.4.2 D22M In-Ceiling Set 44
2.4.3 D22M Vandalism Set 46
2.4.4 D22M Wall Mount 48
2.4.5 D22M Pole Mount 50
2.5 Mounting the Camera 52
2.5.1 D22M-IT/Secure 52
2.5.2 D22M-Basic 53
2.5.3 Finishing the Mounting Process 56
2.5.4 Notes on Mounting the Camera to a Wall Without the Wall Mount 58
2.6 Mounting the D22M to a Ceiling Using the On-Wall Set 60
2.7 Mounting the D22M to a Ceiling Using the In-Ceiling Set 62
2.8 Mounting the D22M Vandalism Set 64
2.9 Mounting the D22M to a Wall Using the Wall Mount 66
2.10 Notes 68
2.10.1 Cleaning Instructions 68
2.10.2Wiring, Fire Prevention, Lightning and Surge Protection 68
2.11 Camera Accessories 70
3 OPERATING THE CAMERA 74
3.1 General Procedure 74
3.1.1 Establishing the Power Supply to the Camera 74
3.1.2 Connecting the Camera 74
3.2 Overview of the Configuration Settings 76
3.3 Connecting the Camera, Power Supply 78
3.3.1 Notes on Cable Lengths and Power Supply 78
3.3.2 Camera Startup Sequence 79
3.3.3 Power Supply (MxPoE) Using a Switch 80
3.3.4 Power Supply (MxPoE) When Connected Directly to a Computer 80
3.3.5 Power Supply (MxPoE) Using a Network Power Rack or Network
Power Box 81
3.3.6 Power Supply (PoE IEEE 802.3af) Using Power-over-Ethernet Products 81
3.4 The First Image from the Camera 82
3.4.1 Preparing the Ethernet Connection 82
3.4.2 The First Image in the Browser 84
3.4.3 Camera Screens in the Browser 86
3.4.4 Access Using Zeroconf/Bonjour 88
3.4.5 Browser Settings 92
3.4.6 The First Image in MxControlCenter 94
3.5 Starting the Camera With an Automatic IP Address (DHCP) 100
3.6 Starting the Camera Using the Factory IP Address 101
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
2/108 D22M Camera Manual Part 1
APPENDIX: IP65/IP54 CERTIFICATE, DECLARATION OF CONFORMITY
DRILLING TEMPLATES (SCALE 1:1)
SOFTWARE MANUAL PART2
4 CAMERA USER INTERFACE
4.1 The First Image in the Browser
4.2 The First Image in MxControlCenter
4.3 The Live Screen in the Browser
4.4 The Playback Screen in the Browser
4.5 The MultiView Screen in the Browser
4.6 PDA Screen
4.7 Guest Screen
4.8 Browser Settings
4.9 Configuring the Softbuttons
4.10 Fast Video Streaming
4.11 Operating Multiple Cameras
5 GENERAL CAMERA CONFIGURATION
5.1 Overview
5.2 Quick Installation
5.3 Connection Test
5.4 Basic Settings
5.5 Image Controls
5.6 Logos
5.7 Exposure Settings
5.8 Day & Night Modes
5.9 Managing Settings
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
3/108
D22M Camera Manual Part 1
Download the latest ver-
sion of this document as a
PDF file from
www.mobotix.com,
Support> Manuals
Note
Chapters 4 and above are part of the Camera Software Manual (
Soft-
ware Manual
in short). The main headings are listed below to give you
an overview of the
Software Manual
contents.
6 SOFTWARE UPDATES
6.1 Overview
6.2 Preparatory Steps
6.3 Updating the Camera Software
6.4 Update Checklist
7 EVENTS, ACTIONS AND MESSAGES
7.1 Overview
7.2 Functional Overview
7.3 General Procedure
7.4 Screen Display of Event Settings in Live Image
7.5 Arming
7.6 Events
7.7 Actions and Messaging, Action and Messaging Profiles
7.8 Working with Profiles
7.9 Time Tasks
8 RECORDING
8.1 Overview
8.2 Recording Modes
8.3 Recording Types
9 TELEPHONY FEATURES
9.1 Overview
9.2 VoIP Settings for IP Telephony
9.3 Camera Phone (Listen, Speak and Intercom Modes)
9.4 Phone Profiles: Outbound Phone Calls
9.5 Phone Call-In: Inbound Phone Calls
9.6 Remotely Controlling the Camera Using a Phone
9.7 Sample Configurations for IP Telephony via Internet
9.8 Sample Configurations for IP Telephony on a LAN
9.9 Video Telephony
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
4/108 D22M Camera Manual Part 1
10 MOBOTIX CAMERAS ON THE WEB
10.1 Overview
10.2 Indirectly Accessing MOBOTIX Cameras via the Web
10.3 Directly Accessing MOBOTIX Cameras via the Web
10.4 Configuring the Router
10.5 DynDNS
11 SOFTWARE INTERFACES
11.1 Overview
11.2 Accessing the Camera's Live Image and the Event Images
11.3 Accessing the Camera's Live Image Using the Second Image Channel
11.4 Video Streaming
11.5 The HTTP API
12 TROUBLESHOOTING
12.1 Overview
12.2 Troubleshooting Checklist
12.3 Diagnostic Tools of the Camera
12.4 Monitoring Tools of the Camera
12.5 Potential Issues
12.6 Additional Information
12.7 Sending Back the Camera
12.8 Warranty
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
5/108
D22M Camera Manual Part 1
More information:
www.mobotix.com
Note
Download the latest version of this document as a PDF file from
www.mobotix.com, Support> Manuals.
Information subject to change without notice!
Copyright © 1999-2008 MOBOTIX AG, Kaiserslautern, Germany.
All rights reserved. MOBOTIX, MxPEG and MxControlCenter are worldwide
trademarks of MOBOTIX AG. Microsoft, Windows and Windows Server are reg-
istered trademarks of Microsoft Corporation. Apple, the Apple logo, Macintosh,
OSX and Bonjour are trademarks of Apple Inc. Linux is a trademark of Linus
Torvalds. All other marks and names mentioned herein may be trademarks or
registered trademarks of the respective owners.
1 INTRODUCTION
The D22M cameras are powerful yet compact MOBOTIX net-
work cameras that are capable of creating high-resolution live
video streams (QXGA format: 2048x1536 pixels) with high im-
age rates. When showing VGA video (640x480), the camera can de-
liver up to 30 fps. Even Megapixel video (1280x960) will still generate up to 10fps.
The camera transmits lip-synchronous audio, both in the browser (ActiveX plug-in)
and when using MxControlCenter (external speaker and microphone required;
not available on D22M-Basic).
The MOBOTIX D22M is
available as SECURE, IT or
Basic model with different
features (the Basic model
does not have audio fea-
tures). The D22M can be fit-
ted with any of the five M14
high-performance lenses.
Because of the low power
consumption of only
3Watts, the MOBOTIX
D22M cameras feature the
highest operating tempera-
ture range in the market
from -30 to + 60°C (-22 to 140°F). Since MOBOTIX cameras neither fog up nor re-
quire heating, power can be supplied via the network cabling using standard PoE
products. D22M IT and Secure models are absolutely dust-proof and resistant
against water jets (IP65; D22M-Basic: IP54). When mounted to the D22M Wall
Mount, the camera can be used in outdoor applications; the wall mount perfectly
covers wall outlets, thus providing completely concealed cabling.
Like all other MOBOTIX cameras, the D22M models have more to offer than only
the camera features. The integrated software features include a multitude of func-
tions, such as video motion detection, long-term recording, alarm messaging
and video IP telephony to name but a few features. Unlike in camera systems
from other manufacturers,
buying and installing addi-
tional software on the com-
puter is thus unnecessary.
Instead of using a web
browser, you can also
download the free MxCon-
trolCenter from the MO-
BOTIX website, which allows
displaying multiple cameras
on one monitor, allows for
comfortably searching and
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
6/108 D22M Camera Manual Part 1
High resolution: QXGA
format with 2048x1536!
30 frames per second in
VGA format!
Everything integrated!
MxControlCenter
evaluating the alarm video clips and provides alerting
features (including audio).
While MxControlCenter has been providing virtual PTZ
features for quite a while, these features are now avail-
able directly in the MOBOTIX camera. This means that
you can continuously zoom into or out of the live image
using either the mouse wheel or a joystick. When stor-
ing images or video sequences, you can choose to store
either the visible image area of the live image or the
full sensor image. The second option would also allow
examining the parts of an image or video after the event
that had not been in the visible image section of the live
image.
Another problem known from photography are the dis-
tortions from wide-angle lenses. Straight lines at the im-
age borders are bent inwards towards the corners. The
integrated distortion correction features of the camera
(and of MxControlCenter) allow correcting the bent lines
of various lenses using software algorithms.
The current MOBOTIX cameras support direct storage on the integrated
Flash storage media, internal SD cards and external USB media. The
MOBOTIX Secure R versions are a highlight in this respect as they are
delivered with an integrated Flash storage device (e.g. R8 with 8GB).
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
7/108
D22M Camera Manual Part 1
Virtual PTZ
Image section with cor-
rection of wide-angle
distortion
D22M-Secure
models support
SD cards and ex-
ternal USB devices.
An internal Flash stor-
age option is currently not
available for D22M mod-
els.
Zoom 1x
Zoom 2x
D22M-Basic
The D22M-Basic, with a diameter of only 12.9cm
(5in) and a height of only 8.5cm (3.3in) is the most
compact and most discrete MOBOTIX camera. The
camera is weatherproof (IP54) and thus suited for
outdoor use.
D22M-IT/Secure
The D22M IT and Secure models feature additional functions and security features.
Among other things, you can connect an external speaker and microphone, store
images and video sequences on an
external file server (including audio)
and call the camera using SIP video*.
MOBOTIX also provides accessories
for indoor and outdoor applications
and vandalism-prone areas. The
camera is weatherproof (IP65) and
thus suited for outdoor use.
Accessories for the MOBOTIX D22M
• On-Wall Set: This set can reliably protect external cables if the cables cannot
be guided from below the housing but have to be led above the wall for
technical or legal reasons. In
addition, the On-Wall mount
provides ample space for ex-
tra modules (batteries, WiFi,
...).
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
8/108 D22M Camera Manual Part 1
D22M-IT and Secure
(IP65)
*Accessories required for
D22M: external micro-
phone and external
speaker
On-Wall Set (IP65)
Note
D22M IT and Secure models are the right choice for more sophisti-
cated surveillance applications.
ø 160mm/6.3in
ø 129mm/5.1in
ø 165mm x 37mm
/6.5x 1.5 in
Note
Die D22M-Basic ist die richtige Wahl für Webcam-Anwendungen und
einfache Überwachungsaufgaben.
• Vandalism Set: The Vandalism Set provides added protection for D22M
cameras. The set consists of a robust camera ring made of stainless steel
and a reinforced dome
made from 3mm thick
polycarbonate. A cam-
era with vandalism set
is perfectly suited for
applications in de-
manding environments
(such as prisons, social
hot-spots, train sta-
tions, etc.).
- Stainless steel, matt
- Stainless steel, polished
- Stainless steel, white powder-coated
- Stainless steel, black powder-coated
- Stainless steel, silver powder-coated
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
9/108
D22M Camera Manual Part 1
Vandalism Set (IP65)
The stainless steel cam-
era ring is available in five
versions:
- matt
- polished
- white powder-coated
- black powder-coated
- silver powder-coated
D22M Vandalism Set in
different material and
color versions
• In-Ceiling Set: The In-Ceiling Set allows mounting the D22M in fake ceilings,
for example. This type
of installation pro-
vides optimum pro-
tection for the camera
and reduces the visi-
ble profile to a mini-
mum since only the
dome is visible.
• Wall Mount: The Wall Mount is the ideal solution for mounting the D22M to
walls for indoor and outdoor applications. The camera is absolutely dust-
proof and resistant
against water jets
(IP65). The wall mount
also covers RJ45 wall
outlets and also has
ample space for addi-
tional modules.
• Pole Mount: If you would like to mount the MOBOTIX D22M to a pole, you
should consider using the MOBOTIX Pole Mount, which is used in combina-
tion with the wall
mount. The supplied
stainless steel straps
allow fixing the mount
to poles with diame-
ters between 60 and
180mm (2.4 to
7.1in).
• Lenses, sensors: You can choose between five different lenses for the MO-
BOTIX D22M (M14 thread). IT and Secure models can be ordered either with
a daylight image sensor (color) or a night image sensor (black and white).
For further information on this topic, please read section 1.4,
Lens Options,
Hardware and Software Features
.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
10/108 D22M Camera Manual Part 1
In-Ceiling Set
Outdoor Wall Mount made
from sturdy PBT 30GF
Pole Mount: Outdoor qual-
ity made of 3mm stain-
less steel
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
11/108
D22M Camera Manual Part 1
Notes:
1.1 MOBOTIX Cost Benefits
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
12/108 D22M Camera Manual Part 1
Overview—MOBOTIX
Cost Benefits
Increased resolution reduces amount of cameras
1536-line, high-resolution sensors give a better overview and allow monitor-
ing an entire room with just one camera from the corner
Reduced installation costs at any distance
Standard Ethernet connection enables the use of common network compo-
nents such as fiber, copper and wireless (WiFi)
Intelligent recording technology reduces storage
Decentralized recording technology in the camera software puts less strain
on PCs and reduces the amount of storage PCs (DVRs) by 10 times
Event-controlled image rate minimizes storage cost
Event-driven, automatically adjusted recording frame rate based on event or
sensor action reduces amount of data and storage costs
No additional power and no heating required
Anti-fogging without heating allows usage of standard PoE technology to
power the system via network and saves costs of power cabling
Backup power requirement reduced by 8 times
Low power consumption, 3 Watt, enables year-round (no heating required)
PoE with one centralized UPS from installation room via network
Robust and practically maintenance free
Fiberglass-reinforced composite housing with built-in cable protection and
no mechanical moving parts (no autoiris) guarantees longevity
No software and no licence costs
Control and recording software is integrated in the camera and is free of
charge; new functions are available via free software downloads
Unlimited scalability and high return on investment
While in use, more cameras and storage can be added at any time; image
format, frame rate & recording parameters can be camera specific
Additional functions and other extras included
Audio support, lens, wall mount and weatherproof housing (-30° to +60°C,
-22° to +140°F) included; microphone & speaker available in certain models
1.2 MOBOTIX Technical Advantages
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
13/108
D22M Camera Manual Part 1
Overview—MOBOTIX
Technical Advantages
Progressive-scan instead of half-frame blur
Megapixel sensor and image processing inside the camera with digital
white balance generates sharp and true color images at every scale
Sun and backlight compensation
CMOS sensor without auto iris, digital contrast enhancement and configur-
able exposure measurement zones guarantee optimum exposure control
Dual camera technology: 2-in-1
Two possible camera views with picture-in-picture technology or 180° pano-
ramic view; one Dual-Fixdome camera with 2.5 megapixel is enough
Long-term, high-performance Terabyte recording incl.
Event detection and ring buffer recording by the camera itself allow record-
ing of 40 smooth video streams on a single PC (1200 VGA images/s)
Simultaneous recording, event search and live viewing
Live video for multiple users, recording and event search simultaneously
possible in seconds from anywhere in the world via network
Very low network load
Efficient MxPEG video codec, motion detection based recording and video
buffering inside camera guarantee a very low network load
Bridging of recording during network failures
Internal camera ring buffer bridges network failures and bandwidth fluctua-
tions of wireless links (WLAN/UMTS) for several minutes
Day & night maintenance free
Unique Day/Night camera technology without moving parts guarantees ex-
treme light sensitivity and ensures long-term reliability
Audio and SIP telephony
Lip-synchronized audio (live & recording); each camera is a video IP tele-
phone based on SIP standard with automatic alarm call and remote control
MxControlCenter included
Dual screen technology with building plans, free camera positioning, event
search, image processing, lens distortion correction and PTZ support
1.3 MOBOTIX D22M Concept
High-resolution live video with up to 30 frames/s
The MOBOTIX cameras deliver smooth live video display in VGA format (640x480
pixels) with synchronous live audio, yet it keeps the network load to a minimum.
Live video display now matches the performance of analog video systems. When
recording, MOBOTIX systems easily outperform analog systems, since MOBOTIX
cameras store the high live image resolution and frame rate without compromising
image quality. MOBOTIX technology thus allows simultaneously recording the
video from 30 cameras in continuous recording mode on one standard PC at
30 frames per second each, including the audio channel of the cameras.
Low bandwidth requirements
MOBOTIX' patent pending MxPEG streaming format allows fast live video with
audio at extremely low network loads (1 to 2Mbps). Since the MOBOTIX camera it-
self detects movements in the image (and not the computer), video is only transmit-
ted if movements occur, and when the video and audio data are being stored.
Voice over IP (with accessories)
Moreover, MxPEG provides for lip-synchronized audio and two-way communica-
tion between the camera and your computer. Room surveillance with audio is pos-
sible using Internet Explorer or MxControlCenter. Alarm notification on your mobile
via Internet (SIP) telephony is just as easy as event-controlled voice messages di-
rectly from the camera (ISDN requires M12 or D12 model).
IP telephony and video SIP (with accessories)
All telephone features can be used
via Internet telephony thanks to the
integrated SIP client. The SIP client al-
lows remote-controlling the camera
using the touchtone keys and also
makes the alarm calls of the camera.
Video telephony allows establishing
SIP audio/video connections to the
camera using Windows Messenger
or similar applications (e.g. Counter-
Path X-Lite/Eyebeam).
Long-term storage on file servers included
MOBOTIX cameras have an integrated long-term storage system for Linux, Win-
dows and Mac OS X computers. Every camera manages its own ring buffer stor-
age on the shared folder. Thanks to this decentralized approach, up to 30 live cam-
eras can store images on one computer with 30 frames per second each, includ-
ing audio.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
14/108 D22M Camera Manual Part 1
*Accessories required for
D22M: external micro-
phone and external
speaker
D22M-IT and Secure
models also allow con-
necting an external
speaker and microphone;
D22M cameras do not
have an inte-
grated
speaker or a
microphone
IP Telephony!
In order to use VoIP and
Internet telephony with
the D22M, you need an IT
or Secure model with an
attached external speaker
and microphone
Recording on Flash, USB and SD storage media
The current MOBOTIX cameras support direct storage on the integrated Flash
storage media, internal SD cards and external USB media.
The MOBOTIX Secure R versions are a highlight in this respect as they are deliv-
ered with an integrated Flash storage device (e.g. R8 with 8GB). These models
have been preconfigured at the factory for Flash device storage. By using Flash, the
camera features these additional possibilities:
•Stand-alone use of the camera without file server thanks to recording on
the Flash device.
•High-security application with recording on a file server or NAS/SAN in
which the Flash device serves as storage buffer. It can thus bridge longer fail-
ures of the network or the file server without losing any video sequences
(supported in a future software version).
•Event downloads to USB media or SD cards for evaluation of the recorded
sequences on a computer.
30 live cameras using MxControlCenter
Instead of using a web browser, you can also
download the free MxControlCenter client from
www.mobotix.com, which allows displaying up
to 30 MOBOTIX cameras on one monitor (Linux
and Mac OSX versions are currently being devel-
oped). In addition, MxControlCenter can process
incoming alarms from the cameras and allows
comfortably searching and evaluating the alarm
video clips (including audio). The integrated Layout
Editor of MxControlCenter provides for quickly cre-
ating floor plans by simply dragging/dropping the
cameras onto a background image. Load a floor
plan as background image, drag&drop the cameras; done.
Event and time-controlled
Just like event-controlled recording upon detecting movements in the image, the
camera can also record when the volume detected by the microphone exceeds a
set trigger value. Using scheduled recording, time tasks can start or stop video re-
cording, uploading of images to a web site or sending of e-mails with video/audio
clips. Special programs control vacation times and holidays.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
15/108
D22M Camera Manual Part 1
*Integrated Flash stor-
age can only be installed
at the factory!
**SD cards are sup-
ported from software
version 3.4.2
*Accessories required for
D22M: external micro-
phone and external
speaker
Int. Flash SD Card USB Device Remarks for USB Devices
M12 X*X** X Adapter cable required
D12
V12
M22M
D22M
X*
X*
X**
X*
X**
X
Adapter cable required
X
X
Device can be connected directly
Adapter cable required
Q22M X**
Remote alerting
In case of an alarm, MOBOTIX cameras automatically pop up windows or activate
other functions at a remote security control center. The cameras can use network/
wireless, GSM/GPRS/UMTS (3G) or Internet connections for this purpose.
Day & Night
The Night versions of the MOBOTIX cameras with only one image sensor (Mono)
deliver crisp and clear B/W images of moving objects even at night, MOBOTIX Day/
Night models (M12D-DNight und D12D-DNight) with two image sensors (1x color, 1x
B/W) deliver brilliant color images during the day and crisp B/W images at night.
The cameras switch lenses automatically, depending on the level of illumination.
Integrated Power-over-Ethernet
Power is supplied as Power-over Ethernet via the network cabling us-
ing the MOBOTIX power supply (in combination with the Network
Power Adapter), a MOBOTIX Network Power Rack (8 to 20 cameras), a
Network Power Box (4 cameras), or by using a PoE-compatible switch (according
to PoE standard IEEE 802.3af).
Since the camera's plastic housing insulates well and is anti-fogging, no additional
heating or fans are necessary. This is why MOBOTIX, unlike other manufacturer's
cameras, have low power requirements (3Watts) and PoE can be used every day
of the year indoors as well as outdoors for supplying power.
Weatherproof
MOBOTIX cameras are certified according to IP65 and are designed for outdoor as
well as indoor usage*. As the cameras do not have any moving parts, they are ex-
tremely robust and resistant against heat and cold (-30°C to +60°C; -22°F to +
140°F).
Logos, animated or freestyle
The logo generator of MOBOTIX
cameras allows integrating ban-
ners and graphics (including files
loaded from any URL) into the cur-
rent camera images—with op-
tional scheduler control. MOBOTIX
cameras are the only network IP
cameras supporting animated
and transparent graphics.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
16/108 D22M Camera Manual Part 1
No heating required—PoE
is no problem even in the
wintertime!
*D12 models together
with Outdoor Wall Mount
Logo generator
More Features
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
17/108
D22M Camera Manual Part 1
Notes:
•Live images of up to 2048x1536 pixels resolution via network, ISDN, GSM,
GPRS, UMTS, wireless with up to 30fps (at VGA resolution 640x480), also
adapted for PDAs.
•Continuous digital zoom (up to 8x zoom) and integrated panning (clicking
with the mouse near the borders of the image will move the visible image
area within the full image).
•True software scaling using the proven and continuously improved MO-
BOTIX algorithms, which delivers brilliant images even with smaller image
formats (e.g. 320 x 240/CIF).
•Audio video recording* with three different recording modes: Event record-
ing with audio, continuous recording with variable frame rate and audio as
well as event-controlled snapsShot recording of JPEG images.
•Storage failure detection can monitor a file server (or a Flash device) and
can use one or more of the defined messaging options for error notification.
•Playback of recorded images/video sequences with audio in the integrated
video management system.
•Multiwatcher screen can display and monitor several cameras via the Inter-
net, with only one camera requiring access from the outside. This “proxy”
camera uses only very little bandwidth, making it an ideal solution for low-
bandwidth connections.
•MultiView screen for displaying multiple cameras or events in one browser
window.
•Event notification by e-mail, SMS (using a provider), voice notification (Phone
Call-Out), sounds and by visual means (e.g. red frame in live image) using
two separate messaging paths.
•Object tracing for analyzing the paths of objects that are moving in the im-
age.
•Logo generator for displaying logos in the camera images with dialogs for
managing image files and defining image and logo profiles for controlling
logo display.
•Logos can have transparent areas and can be displayed partially transpar-
ent at the same time (creating a watermark effect), banner rotation and ani-
mations are also possible.
•Time Tables for handling customized days, e.g. for holidays and vacations.
The time tables are used to control the camera's arming, image recording,
action, messaging, logo, obscure image and other features.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
18/108 D22M Camera Manual Part 1
2048 x 1536 pixels
*Telephony features can
be used via VoIP (Inter-
net telephony; all MO-
BOTIX cameras) or via
ISDN (only M12 and D12
models)!
Logo generator
Table of contents
Other Mobotix IP Camera manuals
Mobotix
Mobotix D12 User manual
Mobotix
Mobotix Mx-c26A User manual
Mobotix
Mobotix M24M Allround CS-Vario User manual
Mobotix
Mobotix Hemispheric i25 Instructions for use
Mobotix
Mobotix D14D User manual
Mobotix
Mobotix NAS 251 G Instructions for use
Mobotix
Mobotix D22 Original operating instructions
Mobotix
Mobotix MOBOTIX M73 Original operating instructions
Mobotix
Mobotix M12 User manual
Mobotix
Mobotix M12 Original operating instructions
